Make
sure
to
read
the
Important
Precautions
before
using
the
product.
Keep
the
User's
Guide(CD)
in
an
accessible
place
for
furture
reference.
See
the
label
attached
on
the
back
cover
and
quote
this
information
to
your
dealer
when
you
require
service.
L2010P
User's
Guide
A1
This
unit
has
been
engineered
and
manufactured
to
ensure
your
personal
safety,
however
improper
use
may
result
in
potential
e
shock
or
fire
hazards.
In
order
to
allow
the
proper
operation
of
all
safeguards
incorporated
in
this
display,
observe
the
following
basic
rules
for
its
installation,
use,
and
servicing.
On
Safety
Use
only
the
power
cord
supplied
with
the
unit.
In
case
you
use
another
power
cord,
make
sure
that
it
is
certified
by
the
applicable
national
standards
if
not
being
provided
by
the
supplier.
If
the
power
cable
is
faulty
in
any
way,
please
contact
the
manufacturer
or
the
nearest
authorized
repair
service
provider
for
a
replacement.
The
power
supply
cord
is
used
as
the
main
disconnection
device.
Ensure
that
the
socket-outlet
is
easily
accessible
after
installation.
Operate
the
display
only
from
a
power
source
indicated
in
the
specifications
of
this
manual
or
listed
on
the
display.
If
you
are
not
sure
what
type
of
power
supply
you
have
in
your
home,
consult
with
your
dealer.
Overloaded
AC
outlets
and
extension
cords
are
dangerous.
So
are
frayed
power
cords
and
broken
plugs.
They
may
result
in
a
shock
or
fire
hazard.
Call
your
service
technician
for
replacement.
Do
not
Open
the
Display.
There
are
no
user
serviceable
components
inside.
There
are
Dangerous
High
Voltages
inside,
even
when
the
power
is
OFF.
Contact
your
dealer
if
the
display
is
not
operating
properly.
To
Avoid
Personal
Injury
:
Do
not
place
the
display
on
a
sloping
shelf
unless
properly
secured.
Use
only
a
stand
recommended
by
the
manufacturer.
To
Prevent
Fire
or
Hazards:
Always
turn
the
display
OFF
if
you
leave
the
room
for
more
than
a
short
period
of
time.
Never
leave
the
display
ON
when
leaving
the
house.
Keep
children
from
dropping
or
pushing
objects
into
the
display's
cabinet
openings.
Some
internal
parts
carry
hazardous
voltages.
Do
not
add
accessories
that
have
not
been
designed
for
this
display.
During
a
lightning
storm
or
when
the
display
is
to
be
left
unattended
for
an
extended
period
of
time,
unplug
it
from
the
wall
outlet.
Important
Precautions
On
Installation
Do
not
allow
anything
to
rest
upon
or
roll
over
the
power
cord,
and
do
not
place
the
display
where
the
power
cord
is
subject
to
damage.
Do
not
use
this
display
near
water
such
as
near
a
bathtub,
washbowl,
kitchen
sink,
laundry
tub,
in
a
wet
basement,
or
near
a
swimming
pool.
Displays
are
provided
with
ventilation
openings
in
the
cabinet
to
allow
the
release
of
heat
generated
during
operation.
If
these
openings
are
blocked,
built-up
heat
can
cause
failures
which
may
result
in
a
fire
hazard.
Therefore,
NEVER:
Block
the
bottom
ventilation
slots
by
placing
the
display
on
a
bed,
sofa,
rug,
etc.
Place
the
display
in
a
built-in
enclosure
unless
proper
ventilation
is
provided.
Cover
the
openings
with
cloth
or
other
material.
Place
the
display
near
or
over
a
radiator
or
heat
source.
Do
not
rub
or
strike
the
Active Matrix
LCD
with
anything
hard
as
this
may
scratch,
mar,
or
damage
the
Active Matrix
LCD
permanently.
Do
not
press
the
LCD
screen
with
your
finger
for
a
long
time
as
this
may
cause
some
afterimages.
Some
dot
defects
may
appear
as
Red,
Green
or
Blue
spots
on
the
screen.
However,
this
will
have
no
impact
or
effect
on
the
display
performance.
If
possible,
use
the
recommended
resolution
to
obtain
the
best
quality
for
your
LCD
display.
If
used
under
any
mode
except
the
recommended
resolution,
some
scaled
or
processed
images
may
appear
on
the
screen.
However,
this
is
characteristic
of
the
fixed-resolution
LCD
panel.
On
Cleaning
Unplug
the
display
before
cleaning
the
face
of
the
display
screen.
Use
a
slightly
damp
(not
wet)
cloth.
Do
not
use
an
aerosol
directly
on
the
display
screen
because
over-spraying
may
cause
electrical
shock.
On
Repacking
Do
not
throw
away
the
carton
and
packing
materials.
They
make
an
ideal
container
in
which
to
transport
the
unit.
When
shipping
the
unit
to
another
location,
repack
it
in
its
original
material.
Connecting
the
Display
A3
Before
setting
up
the
monitor,
ensure
that
the
power
to
the
monitor,
the
computer
system,
and
other
attached
devices
is
turned
off.
Positioning
your
display
1.
Adjust
the
position
of
the
panel
in
various
ways
for
maximum
comfort.
Tilt
Range
:
-5Ëš~30Ëš
Swivel
:
90Ëš
Ergonomic
It
is
recommended
that
in
order
to
maintain
an
ergonomic
and
comfortable
viewing
position,
the
forward
tilt
angle
of
the
monitor
should
not
exceed
5
degrees.
Height
Range
:
maximun
3.15
inch
(80.0mm)
Landscape
&
Portrait
:
You
can
rotate
the
panel
90o
clockwise.
(*
For
detailed
information,
please
refer
to
the
Pivot
Sofeware
CD
provided.)
*
Make
sure
not
to
touch
the
floor
when
the
head
rotates
to
use
the
Pivot
function.
80.0mm
Unfasten
the
[Stand
lock]
clockwise
to
adjust
the
height
of
the
stand.
A4
Connecting
the
Display
Using
the
Computer
1.
Place
the
monitor
in
a
convenient,
well-ventilated
location
near
your
computer.
To
adjust
height
of
your
monitor,
unlock
the
stand
lock
on
top
of
the
stand.
2.
Connect
the
signal
cable.
When
attached,
tighten
the
thumbscrews
to
secure
the
connection.
3.
Connect
the
power
cord
into
a
proper
power
outlet
that
is
easily
accessible
and
close
to
the
display.
PUSH
Wall-outlet
type*
PC-outlet
type*
MAC
PC
Power
Cord
Signal
Cable
*
Varies
according
to
model.
1
2
Mac
adapter
For
Apple
Macintosh
use,
a
separate
plug
adapter
is
needed
to
change
the
15
pin
high
density
(3
row)
D-sub
VGA
connector
on
thesupplied
cable
to
a
15
pin
2
row
connector.
NOTE
This
is
a
simplified
representation
of
the
rear
view.
This
rear
view
represents
a
general
model;
your
display
may
differ
from
the
view
as
shown.
Analog
signal
D-sub*
Digital
signal
-
DVI*
Connecting
the
Display
A5
To
arrange
cables
in
order
1.
Press
the
push
button,
and
pull
the
stand
cover
down
to
separate
it
from
the
stand.
2.
After
connecting
cables,
put
the
stand
cover
correctly
into
the
holes
on
the
stand.
If
securely
connected,
you
can
hear
the
click
sound
from
the
latch.
PUSH
PUSH
PUSH
DVI
D-Sub
Stand
cover
Push
button
A6
Control
Panel
Functions
Front
Panel
Controls
Buttons
Use
these
buttons
to
choose
or
adjust
items
in
the
On
Screen
Display.
MENU
Button
Use
this
button
to
enter
or
exit
the
On
Screen
Display.
Use
this
button
to
turn
the
display
on
or
off.
This
Indicator
lights
up
green
when
the
display
operates
normally.
If
the
display
is
in
DPM
(Energy
Saving)
mode,
this
indicator
color
changes
to
amber.
Power
Button
Power
(DPMS)
Indicator
Use
this
button
to
enter
a
selection
in
the
On
Screen
Display.
SELECT
Button
Control
Function
A7
Control
Panel
Functions
Control
Direct
Access
Function
Bring
up
Contrast
and
Brightness
adjustment.
LIGHT
VIEW
DAY
TEXT
MOVIE
NIGHT
USER
MODE
TEXT
MOVIE
This
function
allows
you
to
secure
the
current
control
settings,
so
that
they
cannot
be
inadvertently
changed.
Press
and
hold
the
MENU
button
and
button
for
3
seconds:
the
message
"CONTROLS
LOCKED"
appears.
You
can
unlock
the
OSD
controls
at
any
time
by
pushing
the
MENU
button
and
button
for
3
seconds:
the
message
"CONTROLS UNLOCKED"
will
appear.
Use
this
button
to
make
DVI
DIGITAL,
DVI
ANALOG
or
DSUB
ANALOG
connector
active.
This
feature
is
used
when
two
computers
are
connected
to
the
display.
The
default
setting
is
Dsub.
?
DVI
DIGITAL
?
DVI
ANALOG
?
DSUB
ANALOG
SOURCE
Selection:
SOURCE
SELECT
LIGHT
VIEW:
When
adjusting
your
display
settings,
always
press
the
AUTO
button
before
entering
the
On
Screen
Display(OSD).
This
will
automatically
adjust
your
display
to
the
ideal
settings
for
the
current
screen
resolution
size
(display
mode).
The
best
display
mode
is
1600
X
1200@60Hz.
AUTO
adjustment
function
CONTROLS
LOCKED/UNLOCKED:
MENU
and
This
feature
lets
you
easily
select
the
best
desired
condition
optimized
to
the
environment
(ambient
illumination,
types
etc.).
?
DAY
:
Bright
ambient
illumination
?
NIGHT
:
Dark
ambient
illumination
?
TEXT
:
For
text
images
(Word
processing
etc.)
?
MOVIE
:
For
animation
images
in
videos
or
movies
?
:
For
pictures
or
drawings
?
USER
MODE
:
For
use
under
user
setup
conditions
(Brightness,
contrast
and
color
tint
are
selected
by
the
user
in
OSD
Screen
Setup
Menu.)
A8
On
Screen
Display
(OSD)
Control
Adjustment
Screen
Adjustment
Making
adjustments
to
the
size,
position
and
operating
parameters
of
the
display
is
quick
and
easy
with
the
On
Screen
Display
Control
system.
A
short
example
is
given
below
to
familiarize
you
with
the
use
of
the
controls.
The
following
section
is
an
outline
of
the
available
adjustments
and
selections
you
can
make
using
the
OSD.
To
make
adjustments
in
the
On
Screen
Display,
follow
these
steps:
Press
the
MENU
Button,
then
the
main
menu
of
the
OSD
appears.
To
access
a
control,
use
the
or
Buttons.
When
the
icon
you
want
becomes
highlighted,
press
the
SELECT
Button.
Use
the
Buttons
to
adjust
the
item
to
the
desired
level.
Accept
the
changes
by
pressing
the
SELECT
Button.
Exit
the
OSD
by
Pressing
the
MENU
Button.
NOTE
Allow
the
display
to
stabilize
for
at
least
30
minutes
before
making
adjustments.
A9
On
Screen
Display(OSD)
Selection
and
Adjustment
To
adjust
the
brightness
and
contrast
of
the
screen
CONTRAST/
BRIGHTNESS
COLOR
ADJUSTMENT
POSITION
TRACKING
SETUP
OSD
POSITION
Main
menu
Sub
menu
A
D
Reference
The
following
table
indicates
all
the
On
Screen
Display
control,
adjustment,
and
setting
menus.
USER(R/G/B)
9300K
6500K
To
adjust
the
position
of
the
screen
To
customize
the
color
of
the
screen
To
customize
the
screen
status
for
a
user's
operating
environment
To
adjust
position
of
the
OSD
window
on
the
screen
To
improve
the
clarity
and
stability
of
the
screen
:
Adjustable
A
:
Analog
Input
D
:
Digital
Input
CONTRAST
BRIGHTNESS
H
POSITION
V
POSITION
AUTO
CLOCK
PHASE
LANGUAGE
SIZE
TRANSPARENCY
ZOOM
HORIZONTAL
VERTICAL
NOTE
The
order
of
icons
may
differ
depending
on
the
model
(A10~A12).
A10
On
Screen
Display(OSD)
Selection
and
Adjustment
NOTE
OSD
(On
Screen
Display)
menu
languages
on
the
monitor
may
differ
from
the
manual.
You
were
introduced
to
the
procedure
of
selecting
and
adjusting
an
item
using
the
OSD
system.
Listed
below
are
the
icons,
icon
names,
and
icon
descriptions
of
the
all
items
shown
on
the
Menu.
OSD
Adjust
Description
BRIGHTNESS
To
adjust
the
brightness
of
the
screen.
CONTRAST
To
adjust
the
contrast
of
the
screen.
Vertical
Position
To
move
up
and
down.
Horizontal
Position
To
move
left
and
right.
To
adjust
the
brightness
and
contrast
of
the
screen
To
adjust
the
position
of
the
screen
OSD
Adjust
Description
CONTRAST/BRIGHTNESS
CONTRAST
100
BRIGHTNESS
99
RGB
OSD
To
customize
the
color
of
the
screen
OSD
Adjust
Description
USER
9300K
6500K
RED/GREEN/BLUE
Set
your
own
color
levels.
Select the
screen
color.
?
9300K:
Slightly
bluish
white.
?
6500K:
Slightly
reddish
white.
COLOR
ADJUSTMENT
USER
9300K 6500K
RGB
RED
50
50
50
GREEN
BLUE
OSD
POSITION
RGB
HORIZONTAL
50
VERTICAL
50
OSD
A11
On
Screen
Display(OSD)
Selection
and
Adjustment
To
improve
the
clarity
and
stability
of
the
screen
OSD
Adjust
Description
This
function
is
suitable
for
analog
signal
input
only.
This
button
is
for
the
automatic
adjustment
of
the
screen
position,
clock
and
phase.
To
minimize
any
vertical
bars
or
stripes
visible
on
the
screen
background.The
horizontal
screen
size
will
also
change.
To
adjust
the
focus
of
the
display.
This
item
allows
you
to
remove
any
horizontal
noise
and
clear
or
sharpen
the
of
characters.
Phase
adjustment
should
be
done
after
adjusting
the
Clock.
AUTO
CLOCK
PHASE
SETUP
LANGUAGE
1600x1200
75kHz
/
60Hz
ELAPSED
TIME
00004H
ENGLISH
RGB
SIZE
FULL
TRANSPARENCY
50
ZOOM
OSD
To
customize
the
screen
status
for
a
user's
operating
environment
OSD
Adjust
Description
To
choose
the
language
in
which
the
control
names
are
displayed.
This
function
displays
the
in
its
original
size
or
enlarged
size
so
as
to
fit
in
the
full
screen
of
the
LCD
panel.
To
adjust
the
transparency
of
the
OSD
menu
screen.
To
adjust
horizontal
and
vertical
size
simultaneously.
If
you
want
to
move
the
zooming
point,
use
the
H/V
POSITION
function
in
the
sub-
menu.
However,
if
the
monitor
turns
off
when
zooming
in
and
out
the
screen,
the
monitor
will
be
returned
to
original
screen.
LANGUAGE
SIZE
TRANSPARENCY
ZOOM
TRACKING
AUTO
CLOCK
PHASE
ON
RGB
50
86
OSD
A12
To
adjust
position
of
the
OSD
window
on
the
screen
OSD
Adjust
Description
Horizontal
Position
To
adjust
horizontal
position
of
the
OSD
window
on
the
screen.
Vertical
Position
To
adjust
vertical
position
of
the
OSD
window
on
the
screen.
OSD
POSITION
RGB
HORIZONTAL
50
VERTICAL
50
OSD
On
Screen
Display(OSD)
Selection
and
Adjustment
A13
Troubleshooting
Check
the
following
before
calling
for
service.
No
appears
Is
the
power
cord
of
the
display
connected?
Is
the
power
indicator
light
on?
Is
the
power
on
and
the
power
indicator
green?
Is
the
power
indicator
amber?
Do
you
see
an
"OUT
OF
RANGE"
message
on
the
screen?
Do
you
see
a
"CHECK
SIGNAL
CABLE"
message
on
the
screen?
Do
you
see
a
"CONTROLS
LOCKED"
message
on
the
screen.
Do
you
see
"CONTROLS
LOCKED"
when
you
push
MENU
button?
You
can
secure
the
current
control
settings,
so
that
they
cannot
be
inadvertently
changed.
You
can
unlock
the
OSD
controls
at
any
time
by
pushing
the
MENU
button
and
button
for
3
seconds:
the
message
"CONTROLS
UNLOCKED"
will
appear.
Check
and
see
if
the
power
cord
is
connected
properly
to
the
power
outlet.
Press
the
Power
button.
Adjust
the
brightness
and
the
contrast.
If
the
display
is in
power
saving
mode,
try
moving
the
mouse
or
pressing
any
key
on
the
keyboard
to
bring
up
the
screen.
Make
sure
if
the
power
is
on.
Try
to
turn
on
the
PC.
This
message
appears
when
the
signal
from
the
PC
(video
card)
is
out
of
horizontal
or
vertical
frequency
range
of
the
display.
See
the
'Specifications'
section
of
this
manual
and
configure
your
display
again.
This
message
appears
when
the
signal
cable
between
your
PC
and
your
display
is
not
connected.
Check
the
signal
cable
and
try
again.
A14
Troubleshooting
Display
is
incorrect
Display
Position
is
incorrect.
On
the
screen
background,
vertical
bars
or
stripes
are
visible.
Any
horizontal
noise
appearing
in
any
or
characters
are
not
clearly
portrayed.
The
screen
color
is
mono
or
abnormal.
The
screen
blinks.
Press
the
AUTO
button
to
automatically
adjust
your
display
to
the
ideal
setting.
If
the
results
are
unsatisfactory,
adjust
the
position
using
the
H
position
and
V
position
icon
in
the
on
screen
display.
Check
Control
Panel
-->
Display
-->
Settings
and
see
if
the
frequency
or
the
resolution
were
changed.
If
yes,
readjust
the
video
card
to
the
recommend
resolution.
Press
the
AUTO
button
to
automatically
adjust
your
display
to
the
ideal
setting.
If
the
results
are
unsatisfactory,
decrease
the
vertical
bars
or
stripes
using
the
CLOCK
icon
in
the
on
screen
display.
Press
the
AUTO
button
to
automatically
adjust
your
display
to
the
ideal
setting.
If
the
results
are
unsatisfactory,
decrease
the
horizontal
bars
using
the
PHASE
icon
in
the
on
screen
display.
Check
Control
Panel
-->
Display
-->
Settings
and
adjust
the
display
to
the
recommended
resolution
or
adjust
the
display
to
the
ideal
setting.
Set
the
color
setting
higher
than
24
bits
(true
color).
Check
if
the
signal
cable
is
properly
connected
and
use a
screwdriver
to
fasten
if
necessary.
Make
sure
the
video
card
is
properly
inserted
in
the
slot.
Set
the
color
setting
higher
than
24
bits
(true
color)
at
Control
Panel
-
Settings.
Check
if
the
screen
is
set
to
interlace
mode
and
if
yes,
change
it
to
the
recommend
resolution.
Make
sure
the
power
voltage
is
high
enough,
It
has
to
be
hgher
than
AC100-240V
50/60Hz.
A15
Troubleshooting
Have
you
installed
the
display
driver?
Have
you
installed
the
display
driver?
Do
you
see
an
"Unrecognized
monitor,
Plug&Play
(VESA
DDC)
monitor
found"
message?
Be
sure
to
install
the
display
driver
from
the
display
driver
CD
(or
diskette)
that
comes
with
your
display.
Or,
you
can
also
download
the
driver
from
our
web
site:
http://www.lge.com.
Make
sure
to
check
if
the
video
card
supports
Plug&Play
function.
USB
function
Check
if
the
USB
cable
is
correctly
connected.
Check
if
the
PC
and
OS
are
USB
compliant.
For
verification
of
USB
support,
consult
the
manufacturer
of
each
system.
USB
function
cannot
be
setup.
"IMAGE
SIZE"
function
on
OSD
menu
does
not
work.
Check
if
the
resolution
is
set
as
1600x1200
or
less
than
512x360.
The
optimal
resolution
is
1600x1200
and
the
is
fully
displayed
on
the
monitor
and
is
not
converted
as
1:1
size.
If
the
resolution
is
less
than
512x360,
the
size
is
smaller
than
that
of
the
OSD's
and
is
also
not
converted
as
1:1
size.
"IMAGE
SIZE"
function
on
OSD
menu
does
not
work?
A16
Specifications
20.1
inches
(51.0cm)
Flat
Panel
Active
matrix-TFT
LCD
Anti-Glare
coating
20.1
inches
viewable
0.255mm
pixel
pitch
Horizontal
Freq.
Analog
:
28
-
92kHz
(Automatic)
Digital
:
28-80kHz
(Automatic)
Vertical
Freq.
56
-
85Hz
(Automatic)
Input
Form
Separate
TTL,
Positive/Negative
Composite
TTL
Positive/Negative
SOG
(Sync
On
Green)
Digital
Signal
Input
15
pin
D-Sub
Connector
DVI
-
I
connector
(Digital/Analog)
Input
Form
RGB
Analog
(0.7Vp-p/75ohm),
Digital
Max
D-Sub
:
Analog
-
VESA
1600
x
1200@60Hz
DVI
:
Analog
-
VESA
1600
x
1200@60Hz
Digital
-
VESA
1600
x
1200@60Hz
VESA
1280
x
1024@70Hz
Recommend
VESA
1600
x
1200@60Hz
DDC
2B
Normal
:
60W
Stand-by/Suspend
≤
3W
DPM
Off
≤3W
Power
key
Off
≤
3W
Power
Cut-off
switch
off
≤
1W
*():withUSB
Width
44.6
0cm
/
17.56
inches
Height
44.56
cm
/
17.54
inches(Min)
52.56cm
/
20.69
inches(Max)
Depth
23.73cm
/
9.34
inches
Net
9.5
kg
Tilt
range
-5Ëš~30Ëš
Swivel
range
90Ëš
Height
range
80/
3.15
inches
Rotate
90Ëšclockwise(Landscape
->
Portrait
AC
100-240V
~
50/60Hz
1.2A
Operating
Conditions
Temperature
10ËšC
to
35
ËšC
Humidity
10
%
to
80
%
non-Condensing
Storage
Conditions
Temperature
-20ËšC
to
60
ËšC
Humidity
5
%
to
95
%
non-Condensing
Display
Sync
Input
Video
Input
Resolution
Plug&Play
Power
Consumption
Dimensions
&Weight
(with
tilt/
swivel
stand)
Tilt/Swivel
Range
Power
Input
Environmental
Conditions
A17
Specifications
Attached(
O
),
Detached
( )
Attached(
),
Detached
(
O
)
Wall-outlet
type
or
PC-outlet
type
Tilt/Swivel
Stand
Signal
cable
Power
cord
NOTE
Information
in
this
document
is
subject
to
change
without
notice.
Preset
Modes
(Resolution)
123456789
10
11
12
13
14
15
16
17
18
640
x
350
640
x
480
640
x
480
640
x
480
720
x
400
800
x
600
800
x
600
800
x
600
832
x
624
1024
x
768
1024
x
768
1024
x
768
1152
x
870
1152
x
900
1280
x
1024
1280
x
1024
1600
x
1024
1600
x
1200
31.47
31.47
37.50
43.27
31.47
37.88
46.88
53.67
49.72
48.36
60.02
68.68
68.68
61.80
63.98
79.98
62.11
75.00
70
60
75
85
70
60
75
85
75
60
75
85
75
65.96
60.02
75.02
60
60
Indicator
Normal
Stand-by/Suspend
DPMS
Off
green
amber
amber
A19
Specifications
VESA
wall
mounting
Connected
to
another
object
(stand
type
and
wall-
mounted
type.
This
monitor
accepts
a
VESA-
compliant
mounting
interface
pad.-
optional)
For
further
information,
refer
to
the
VESA
Wall
Mounting
Instruction
Guide.
Kensington
Security
Slot-
optional
Connected
to
a
locking
cable
that
can
be
purchased
separately
at
most
computer
stores
A20
Specifications
Signal
Connector
Pin
Assignment
1
8
917
24
16
C1
C4
C3
C2
C5
Pin
Signal(DVI-I)
123456789
10
11
12
13
14
15
T.
M.
D.
S.
Data2-
T.
M.
D.
S.
Data2+
T.
M.
D.
S.
Data2/4
Shield
T.
M.
D.
S.
Data4-
T.
M.
D.
S.
Data4+
DDC
Clock
DDC
Data
Analog
Vertical
Sync.
T.
M.
D.
S.
Data1-
T.
M.
D.
S.
Data1+
T.
M.
D.
S.
Data1/3
Shield
T.
M.
D.
S.
Data3-
T.
M.
D.
S.
Data3+
+5V
Power
Ground
(return
for
+5V,
H.
Sync.
and
V.
Sync.)
Pin
Signal(DVI-I)
16
17
18
19
20
21
22
23
24
C1
C2
C3
C4
C5
Hot
Plug
Detect
T.
M.
D.
S.
Data0-
T.
M.
D.
S.
Data0+
T.
M.
D.
S.
Data0/5
Shield
T.
M.
D.
S.
Data5-
T.
M.
D.
S.
Data5+
T.
M.
D.
S.
Clock
Shield
T.
M.
D.
S.
Clock+
T.
M.
D.
S.
Clock-
Analog
Red
Analog
Green
Analog
Blue
Analog
H.
Sync.
Analog
Ground
T.
M.
D.
S.
(Transition
Minimized
Differential
Signaling)
DVI-I
Connector
A21
PUSH
Making
use
of
USB
(Universal
Serial
Bus)
-
Optional
USB
(Universal
Serial
Bus)
is
an
innovation
in
connecting
your
different
desktop
peripherals
conveniently
to
your
computer.
By
using
the
USB,
you
will
be
able
to
connect
your
mouse,
keyboard,
and
other
peripherals
to
your
display
instead
of
having
to
connect
them
to
your
computer.
This
will
give
you
greater
flexibility
in
setting
up
your
system.
USB
allows
you
to
connect
a
chain
of
up
to
120
devices
on
a
single
USB
port;
and
you
can
"hot"
plug
(attach
them
while
the
computer
is
running)
or
unplug
them
while
maintaining
the
Plug
and
the
Plug
auto
detection
and
configuration.
This
display
has
an
integrated
BUS-
powered
USB
hub,
allowing
up
to
2
other
USB
devices
to
be
attached
it.
USB
connection
1.
Connect
the
upstream
port
of
the
display
to
the
downstream
port
of
the
USB
compliant
PC
or
another
hub
using
the
USB
cable.
(Computer
must
have
a
USB
port)
2.
Connect
the
USB
compliant
peripherals
to
the
downstream
ports
of
the
display.
NOTE
To
activate
the
USB
hub
function,
the
display
must
be
connected
to
a
USB
compliant
PC(OS)
or
another
hub
with
the
USB
cable(enclosed).
When
connecting
the
USB
cable,
check
that
the
shape
of
the
connector
at
the
cable
side
matches
the
shape
at
the
connecting
side.
Even
if
the
display
is
in
a
power
saving
mode,
USB
compliant
devices
will
function
when
they
are
connected
the
USB
ports(both
the
upstream
and
downstream)
of
the
display.
USB
downstream
Port
connect
the
cables
from
USB
compliant
peripherals-such
as
keyboard,
mouse,
etc
This
is
a
simplified
representation
of
rear
view.
To
USB
downstream
port
of
the
USB
compliant
PC
or
another
hub
cable
USB
upstream
Port
Power
ON/OFF
Switch of
the
monitor
A22
Making
use
of
USB
(Universal
Serial
Bus)
-
Optional
IMPORTANT:
These
USB
connectors
are
not
designed
for
use
with
high-power
USB
devices
such
as
a
video
camera,
scanner,
etc.
LGE
recommends
connecting
high-power
USB
devices
directly
to
the
computer
Rev.
1.1
complied
BUS-powered
hub
500mA
for
each
(MAX)
12
Mbps
(full),
1.5
Mbps
(low)
1
Upstream
port
2
Downstream
ports
USB
standard
Downstream
power
supply
Communication
speed
USB
port
USB
Specifications
Digitally
yours
