Summary of Contents for Nissan 1999 NISSAN PATHFINDER:
TABLE OF CONTENTS
1
PRECAUTIONS
4
Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
4
Wiring Diagrams and Trouble Diagnosis
4
HARNESS CONNECTOR
5
Description
5
STANDARDIZED RELAY
7
Description
7
POWER SUPPLY ROUTING
7
Schematic
9
Wiring Diagram - POWER -
10
Inspection
16
GROUND
17
Ground Distribution
17
COMBINATION SWITCH
22
Check
22
Replacement
23
STEERING SWITCH
24
Check
24
HEADLAMP (FOR USA)
25
Component Parts and Harness Connector Location
25
System Description
25
Schematic
28
Wiring Diagram - H/LAMP -
29
Trouble Diagnoses
32
Bulb Replacement
34
Aiming Adjustment
34
HEADLAMP (FOR CANADA) - DAYTIME LIGHT SYSTEM -
36
Component Parts and Harness Connector Location
36
System Description
36
Schematic
39
Wiring Diagram - DTRL -
40
Trouble Diagnoses
45
Bulb Replacement
46
Aiming Adjustment
46
PARKING, LICENSE AND TAIL LAMPS
47
System Description
47
Schematic
48
Wiring Diagram - TAIL/L -
49
Trouble Diagnoses
52
STOP LAMP
53
Wiring Diagram - STOP/L -
53
BACK-UP LAMP
55
Wiring Diagram - BACK/L -
55
FRONT FOG LAMP
56
System Description
56
Wiring Diagram - F/FOG -
58
Aiming Adjustment
60
TURN SIGNAL AND HAZARD WARNING LAMPS
61
System Description
61
Wiring Diagram - TURN -
63
Trouble Diagnoses
65
Electrical Components Inspection
65
ILLUMINATION
66
System Description
66
Schematic
68
Wiring Diagram - ILL -
69
INTERIOR, SPOT, VANITY MIRROR AND LUGGAGE ROOM LAMPS
74
System Description
74
Schematic
76
Wiring Diagram - INT/L -
77
METERS AND GAUGES
81
Component Parts and Harness Connector Location
81
System Description
81
Combination Meter/For USA
83
Combination Meter/For Canada
84
Wiring Diagram - METER -
85
Meter/Gauge Operation and Odo/Trip Meter Segment Check in Diagnosis Mode
86
Flexible Print Circuit (FPC)
87
Trouble Diagnoses
88
Electrical Components Inspection
93
COMPASS AND THERMOMETER
95
System Description
95
Wiring Diagram - COMPAS -
96
Trouble Diagnoses
97
Calibration Procedure for Compass
98
WARNING LAMPS
99
Schematic
99
Wiring Diagram - WARN -
100
Fuel Warning Lamp Sensor Check
107
Electrical Components Inspection
107
WARNING CHIME
108
Component Parts and Harness Connector Location
108
System Description
108
Wiring Diagram - CHIME -
110
Trouble Diagnoses
110
FRONT WIPER AND WASHER
117
System Description
117
Wiring Diagram - WIPER -
119
Trouble Diagnoses
121
Removal and Installation
123
Washer Nozzle Adjustment
124
Washer Tube Layout
125
REAR WIPER AND WASHER
126
System Description
126
Schematic
128
Wiring Diagram - WIP/R-
129
Trouble Diagnoses
132
Removal and Installation
132
Washer Nozzle Adjustment
133
Washer Tube Layout
133
Check Valve
133
HORN
134
Wiring Diagram - HORN -
134
CIGARETTE LIGHTER
135
Wiring Diagram - CIGAR -
135
REAR WINDOW DEFOGGER
136
Component Parts and Harness Connector Location
136
System Description
136
Wiring Diagram - DEF -
138
Trouble Diagnoses
140
Electrical Components Inspection
141
Filament Check
141
Filament Repair
142
AUDIO
144
System Description
144
Wiring Diagram - AUDIO - /Base System
145
Schematic/BOSE System
147
Wiring Diagram - AUDIO - /BOSE
148
Trouble Diagnoses
152
Inspection
153
AUDIO ANTENNA
154
System Description
154
Wiring Diagram - P/ANT -
155
Trouble Diagnoses
156
Location of Antenna
156
Antenna Rod Replacement
156
Fixed Antenna Rod Replacement
157
POWER SUNROOF
158
System Description
158
Wiring Diagram - SROOF -
159
DOOR MIRROR
161
Wiring Diagram - MIRROR -
161
POWER SEAT
162
Wiring Diagram - SEAT -
162
HEATED SEAT
164
Wiring Diagram - HSEAT -
164
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
165
Component Parts and Harness Connector Location
165
System Description
166
Schematic/M/T Models
168
Schematic/A/T Models
169
Wiring Diagram - ASCD -
170
Fail-safe System
175
Trouble Diagnoses
176
Electrical Component Inspection
185
ASCD Wire Adjustment
185
POWER WINDOW
187
System Description
187
Schematic
189
Wiring Diagram - WINDOW -
190
Trouble Diagnoses
194
POWER DOOR LOCK
195
Component Parts and Harness Connector Location
195
System Description
195
Schematic
196
Wiring Diagram - D/LOCK -
197
Trouble Diagnoses
202
MULTI-REMOTE CONTROL SYSTEM
210
Component Parts and Harness Connector Location
210
System Description
210
Schematic
213
Wiring Diagram - MULTI -
214
Trouble Diagnoses
217
CONSULT
226
ID Code Entry Procedure (Without CONSULT)
228
Remote Controller Battery Replacement
229
THEFT WARNING SYSTEM
230
Component Parts and Harness Connector Location
230
System Description
231
Schematic
234
Wiring Diagram - THEFT -
236
Trouble Diagnoses
242
SMART ENTRANCE CONTROL UNIT
254
Description
254
Schematic
256
Smart Entrance Control Unit Inspection Table
258
INTEGRATED HOMELINK TRANSMITTER
259
Wiring Diagram - TRNSMT -
259
Trouble Diagnoses
260
NVIS (NISSAN VEHICLE IMMOBILISER SYSTEM - NATS)
262
Component Parts and Harness Connector Location
262
System Description
263
System Composition
263
Wiring Diagram - NATS -
264
CONSULT
265
Trouble Diagnoses
267
How to Replace NATS IMMU
276
NISSAN COMMUNICATOR (IVCS)
277
Precaution
277
Communicator Response Center Telephone Number for Technicians
277
Component Parts and Harness Connector Location
278
System Description
279
Schematic
287
Wiring Diagram - IVCS -
288
CONSULT
292
Trouble Diagnoses
297
Trouble Diagnoses for Intermittent Incident
306
Demonstration Mode
308
System Setting (When IVCS Unit is Replaced)
310
ELECTRICAL UNITS LOCATION
314
Engine Compartment
314
Passenger Compartment
315
HARNESS LAYOUT
317
How to Read Harness Layout
317
Outline
318
Main Harness
320
Engine Room Harness
322
Engine Control Harness
324
Body Harness LH
326
Body Harness RH
327
Back Door Harness
328
Engine and Transmission Harness
329
Room Lamp
330
Air Bag Harness
331
Front Door Harness
332
Rear Door Harness
333
BULB SPECIFICATIONS
334
Headlamp
334
Exterior Lamp
334
Interior Lamp
334
WIRING DIAGRAM CODES (CELL CODES)
335
File type: PDF
File name: 1999-nissan-pathfinder.pdf
File size: 7.99 MB
File Language: English
Pages: 336
Author: Nissan
Updated: 2023-06-04
Download File
Specifications
Brand:
Nissan
Model: 1999 NISSAN PATHFINDER
Category:
Cars
View in the file:
Full Specifications
See other models:
2008 NISSAN ROGUE
2005 NISSAN X-TRAIL
1996 NISSAN ALTIMA
2011 LEAF
1987 300ZX
Download User Manual
Related Products
Ion BPATHFINDERXUS
Ion PATHFNDERYELLOWXUS
Ford 1999 FORD E-250
Toyota 1999 CAMRY
BMW 1999 BMW 7 SERIES
Ford 1999 FORD WINDSTAR
Nissan 2002 NISSAN PATHFINDER
Lincoln LINCOLN 1999 NAVIGATOR
Honda PASSPORT 1999
Ford ESCORT 1999
Ford EXPEDITION 1999
Ford NAVIGATOR 1999
Nissan 2005 NISSAN PATHFINDER
Nissan 1996 NISSAN ALTIMA
Nissan 2018 NISSAN SENTRA
Table of Contents
×
TABLE OF CONTENTS
1
PRECAUTIONS
4
Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
4
Wiring Diagrams and Trouble Diagnosis
4
HARNESS CONNECTOR
5
Description
5
STANDARDIZED RELAY
7
Description
7
POWER SUPPLY ROUTING
7
Schematic
9
Wiring Diagram - POWER -
10
Inspection
16
GROUND
17
Ground Distribution
17
COMBINATION SWITCH
22
Check
22
Replacement
23
STEERING SWITCH
24
Check
24
HEADLAMP (FOR USA)
25
Component Parts and Harness Connector Location
25
System Description
25
Schematic
28
Wiring Diagram - H/LAMP -
29
Trouble Diagnoses
32
Bulb Replacement
34
Aiming Adjustment
34
HEADLAMP (FOR CANADA) - DAYTIME LIGHT SYSTEM -
36
Component Parts and Harness Connector Location
36
System Description
36
Schematic
39
Wiring Diagram - DTRL -
40
Trouble Diagnoses
45
Bulb Replacement
46
Aiming Adjustment
46
PARKING, LICENSE AND TAIL LAMPS
47
System Description
47
Schematic
48
Wiring Diagram - TAIL/L -
49
Trouble Diagnoses
52
STOP LAMP
53
Wiring Diagram - STOP/L -
53
BACK-UP LAMP
55
Wiring Diagram - BACK/L -
55
FRONT FOG LAMP
56
System Description
56
Wiring Diagram - F/FOG -
58
Aiming Adjustment
60
TURN SIGNAL AND HAZARD WARNING LAMPS
61
System Description
61
Wiring Diagram - TURN -
63
Trouble Diagnoses
65
Electrical Components Inspection
65
ILLUMINATION
66
System Description
66
Schematic
68
Wiring Diagram - ILL -
69
INTERIOR, SPOT, VANITY MIRROR AND LUGGAGE ROOM LAMPS
74
System Description
74
Schematic
76
Wiring Diagram - INT/L -
77
METERS AND GAUGES
81
Component Parts and Harness Connector Location
81
System Description
81
Combination Meter/For USA
83
Combination Meter/For Canada
84
Wiring Diagram - METER -
85
Meter/Gauge Operation and Odo/Trip Meter Segment Check in Diagnosis Mode
86
Flexible Print Circuit (FPC)
87
Trouble Diagnoses
88
Electrical Components Inspection
93
COMPASS AND THERMOMETER
95
System Description
95
Wiring Diagram - COMPAS -
96
Trouble Diagnoses
97
Calibration Procedure for Compass
98
WARNING LAMPS
99
Schematic
99
Wiring Diagram - WARN -
100
Fuel Warning Lamp Sensor Check
107
Electrical Components Inspection
107
WARNING CHIME
108
Component Parts and Harness Connector Location
108
System Description
108
Wiring Diagram - CHIME -
110
Trouble Diagnoses
110
FRONT WIPER AND WASHER
117
System Description
117
Wiring Diagram - WIPER -
119
Trouble Diagnoses
121
Removal and Installation
123
Washer Nozzle Adjustment
124
Washer Tube Layout
125
REAR WIPER AND WASHER
126
System Description
126
Schematic
128
Wiring Diagram - WIP/R-
129
Trouble Diagnoses
132
Removal and Installation
132
Washer Nozzle Adjustment
133
Washer Tube Layout
133
Check Valve
133
HORN
134
Wiring Diagram - HORN -
134
CIGARETTE LIGHTER
135
Wiring Diagram - CIGAR -
135
REAR WINDOW DEFOGGER
136
Component Parts and Harness Connector Location
136
System Description
136
Wiring Diagram - DEF -
138
Trouble Diagnoses
140
Electrical Components Inspection
141
Filament Check
141
Filament Repair
142
AUDIO
144
System Description
144
Wiring Diagram - AUDIO - /Base System
145
Schematic/BOSE System
147
Wiring Diagram - AUDIO - /BOSE
148
Trouble Diagnoses
152
Inspection
153
AUDIO ANTENNA
154
System Description
154
Wiring Diagram - P/ANT -
155
Trouble Diagnoses
156
Location of Antenna
156
Antenna Rod Replacement
156
Fixed Antenna Rod Replacement
157
POWER SUNROOF
158
System Description
158
Wiring Diagram - SROOF -
159
DOOR MIRROR
161
Wiring Diagram - MIRROR -
161
POWER SEAT
162
Wiring Diagram - SEAT -
162
HEATED SEAT
164
Wiring Diagram - HSEAT -
164
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
165
Component Parts and Harness Connector Location
165
System Description
166
Schematic/M/T Models
168
Schematic/A/T Models
169
Wiring Diagram - ASCD -
170
Fail-safe System
175
Trouble Diagnoses
176
Electrical Component Inspection
185
ASCD Wire Adjustment
185
POWER WINDOW
187
System Description
187
Schematic
189
Wiring Diagram - WINDOW -
190
Trouble Diagnoses
194
POWER DOOR LOCK
195
Component Parts and Harness Connector Location
195
System Description
195
Schematic
196
Wiring Diagram - D/LOCK -
197
Trouble Diagnoses
202
MULTI-REMOTE CONTROL SYSTEM
210
Component Parts and Harness Connector Location
210
System Description
210
Schematic
213
Wiring Diagram - MULTI -
214
Trouble Diagnoses
217
CONSULT
226
ID Code Entry Procedure (Without CONSULT)
228
Remote Controller Battery Replacement
229
THEFT WARNING SYSTEM
230
Component Parts and Harness Connector Location
230
System Description
231
Schematic
234
Wiring Diagram - THEFT -
236
Trouble Diagnoses
242
SMART ENTRANCE CONTROL UNIT
254
Description
254
Schematic
256
Smart Entrance Control Unit Inspection Table
258
INTEGRATED HOMELINK TRANSMITTER
259
Wiring Diagram - TRNSMT -
259
Trouble Diagnoses
260
NVIS (NISSAN VEHICLE IMMOBILISER SYSTEM - NATS)
262
Component Parts and Harness Connector Location
262
System Description
263
System Composition
263
Wiring Diagram - NATS -
264
CONSULT
265
Trouble Diagnoses
267
How to Replace NATS IMMU
276
NISSAN COMMUNICATOR (IVCS)
277
Precaution
277
Communicator Response Center Telephone Number for Technicians
277
Component Parts and Harness Connector Location
278
System Description
279
Schematic
287
Wiring Diagram - IVCS -
288
CONSULT
292
Trouble Diagnoses
297
Trouble Diagnoses for Intermittent Incident
306
Demonstration Mode
308
System Setting (When IVCS Unit is Replaced)
310
ELECTRICAL UNITS LOCATION
314
Engine Compartment
314
Passenger Compartment
315
HARNESS LAYOUT
317
How to Read Harness Layout
317
Outline
318
Main Harness
320
Engine Room Harness
322
Engine Control Harness
324
Body Harness LH
326
Body Harness RH
327
Back Door Harness
328
Engine and Transmission Harness
329
Room Lamp
330
Air Bag Harness
331
Front Door Harness
332
Rear Door Harness
333
BULB SPECIFICATIONS
334
Headlamp
334
Exterior Lamp
334
Interior Lamp
334
WIRING DIAGRAM CODES (CELL CODES)
335
