Haier HBM450WH1 Bottom Mount Refrigerator

User Manual - Transcript

• Page 1: User Manual RefrigeratorFreezer HBM450WH1 HBM450SA1
• Page 2 - English - : Thank You Legend Warning Important Safety information General information and tips Environmental information Disposal Help protect the environment and human health Put the packaging in applicable containers to recycle it Help to recycle waste of electrical and electronic ap pliances Do not dispose appliances marked with this symbol with the household waste Return the product to your local recycling facility or contact your municipal oce Thank you for purchasing a Haier Product Please read these instructions carefully before using this appliance The instructions con tain important information which will help you get the best out of the appliance and ensure safe and proper installation use and maintenance Keep this manual in a convenient place so you can always refer to it for the safe and proper use of the appliance If you sell the appliance give it away or leave it behind when you move house make sure you also pass this manual so that the new owner can become familiar with the appliance and safety warnings WARNING Risk of injury or suocation Refrigerants and gases must be disposed of professionally Ensure that the tubing of the refrigerant circuit is not damaged before being properly disposed of Disconnect the appliance from the mains supply Cut o the mains cable and dispose of it Remove the trays and drawers as well as the door catch and seals to prevent children and pets to get closed in the appliance
• Page 3 - English - : Thank You Legend Warning Important Safety information General information and tips Environmental information Disposal Help protect the environment and human health Put the packaging in applicable containers to recycle it Help to recycle waste of electrical and electronic ap pliances Do not dispose appliances marked with this symbol with the household waste Return the product to your local recycling facility or contact your municipal oce Thank you for purchasing a Haier Product Please read these instructions carefully before using this appliance The instructions con tain important information which will help you get the best out of the appliance and ensure safe and proper installation use and maintenance Keep this manual in a convenient place so you can always refer to it for the safe and proper use of the appliance If you sell the appliance give it away or leave it behind when you move house make sure you also pass this manual so that the new owner can become familiar with the appliance and safety warnings WARNING Risk of injury or suocation Refrigerants and gases must be disposed of professionally Ensure that the tubing of the refrigerant circuit is not damaged before being properly disposed of Disconnect the appliance from the mains supply Cut o the mains cable and dispose of it Remove the trays and drawers as well as the door catch and seals to prevent children and pets to get closed in the appliance
• Page 4 - English - : Content Intended Use Intended Use 5 Safety 6 Product Description 10 Use 11 Equipment 20 Care and Cleaning 22 Troubleshooting 24 Installation 27 Technical Data31 Intended use This appliance is intended for cooling and freezing food It has been designed exclusively for use in dryinterior households It is not intended for commercial or industrial use Changes or modications to the device are not allowed Unintended use may cause haz ards and loss of warranty claims Accessories Check the accessories and literature in accordance with this list Egg trays Ice cube tray with cover Hinge cover User manual Warranty card Door hinges Notice Due to technical changes and dierent models some of the illustrations in this manual may dier from your model This appliance is intended to be used in household and similar applications such as sta kitchen areas in shops oces and other working environments farm houses and by clients in hotels motels and other residential type environments bed and breakfast type environments catering and similar nonretail applications 4 5
• Page 5 - English - : Content Intended Use Intended Use 5 Safety 6 Product Description 10 Use 11 Equipment 20 Care and Cleaning 22 Troubleshooting 24 Installation 27 Technical Data31 Intended use This appliance is intended for cooling and freezing food It has been designed exclusively for use in dryinterior households It is not intended for commercial or industrial use Changes or modications to the device are not allowed Unintended use may cause haz ards and loss of warranty claims Accessories Check the accessories and literature in accordance with this list Egg trays Ice cube tray with cover Hinge cover User manual Warranty card Door hinges Notice Due to technical changes and dierent models some of the illustrations in this manual may dier from your model This appliance is intended to be used in household and similar applications such as sta kitchen areas in shops oces and other working environments farm houses and by clients in hotels motels and other residential type environments bed and breakfast type environments catering and similar nonretail applications 4 5
• Page 6 - English - : Safety Safety Before switching on the appliance for the rst time do make sure there is no transport damage make sure all packaging is removed and is kept out of childrens reach wait at least two hours before installing the appliance in order to ensure the refrigerant circuit is fully ecient handle the appliance always with at least two persons because it is heavy install the appliance in a wellventilated place Ensure a space of at least 5 cm above and 5 cm around the appliance Install and level the appliance in an area suitable for its size and use keep ventilation openings in the appliance or in the inbuilt struc ture clear of obstruction make sure that the electrical information on the rating plate agrees with the power supply If it does not contact an electrician consider that the appliance is operated by a 220240 VAC50 Hz power supply Abnormal voltage uctuation may cause the appli ance to fail to start or not to operate correctly and damage the temperature control or compressor originating abnormal noise too To eliminate abnormal uctuation it is suggested to use an automatic regulator use a separate earthed socket for the power supply which is easy accessible The appliance must be earthed make sure the plug is easy accessible ensure that the power cable is not trapped by the refrigerator Do not step on the power cable Before switching on the appliance for the rst time do not x install the appliance in direct sunlight or in the near of heat sourceseg stoves heaters x damage the refrigerant circuit If it does become damaged do not use the appliance x use multiplug adapters and extension cables WARNING Make sure not to damage the electric cable and the plug If dam aged it must only be replaced by eighter the manufacturer or the authorised service agent During daily use do make sure that this appliance is only used by children from the age of 8 as well as from persons with reduced physical sensory or mental capabilities or lack of experience and knowledge if they are supervised or have been instructed how to use it in a safe way and understand the hazards involved keep away children under 3 years of age from the appliance unless they are constantly supervised make sure children are not playing with the appliance make sure children are supervised if they carry out cleaning and maintenance hold the plug not the cable when unplugging the appliance replace a damaged supply cord only by the manufacturer its ser vice agent or similarly qualied persons in order to avoid a hazard follow these instructions if coal gas or other inammable gas is leaking in the vicinity of the appliance turn o the valve of the leak ing gas open the doors and windows and do not unplug or plug in the power cable of the appliance or any other appliance open and close the doors only with the handles The gap between the doors and between the doors and the cabinet is very narrow Do not extend your hands in these areas to avoid pinching your n gers Open or close the refrigerator doors only when there are no children standing within the range of door movement disconnect the appliance from the electrical supply before under taking any routine maintenance Allow at least 5 minutes before restarting the appliance as frequent starting may damage the compressor eliminate the dust on the back of the unit at least once in the year to avoid hazard by re as well as increased energy consumption notice that the product is set for operation at a specic ambient range between 10 and 43C The appliance may not work properly 6 7
• Page 7 - English - : Safety Safety Before switching on the appliance for the rst time do make sure there is no transport damage make sure all packaging is removed and is kept out of childrens reach wait at least two hours before installing the appliance in order to ensure the refrigerant circuit is fully ecient handle the appliance always with at least two persons because it is heavy install the appliance in a wellventilated place Ensure a space of at least 5 cm above and 5 cm around the appliance Install and level the appliance in an area suitable for its size and use keep ventilation openings in the appliance or in the inbuilt struc ture clear of obstruction make sure that the electrical information on the rating plate agrees with the power supply If it does not contact an electrician consider that the appliance is operated by a 220240 VAC50 Hz power supply Abnormal voltage uctuation may cause the appli ance to fail to start or not to operate correctly and damage the temperature control or compressor originating abnormal noise too To eliminate abnormal uctuation it is suggested to use an automatic regulator use a separate earthed socket for the power supply which is easy accessible The appliance must be earthed make sure the plug is easy accessible ensure that the power cable is not trapped by the refrigerator Do not step on the power cable Before switching on the appliance for the rst time do not x install the appliance in direct sunlight or in the near of heat sourceseg stoves heaters x damage the refrigerant circuit If it does become damaged do not use the appliance x use multiplug adapters and extension cables WARNING Make sure not to damage the electric cable and the plug If dam aged it must only be replaced by eighter the manufacturer or the authorised service agent During daily use do make sure that this appliance is only used by children from the age of 8 as well as from persons with reduced physical sensory or mental capabilities or lack of experience and knowledge if they are supervised or have been instructed how to use it in a safe way and understand the hazards involved keep away children under 3 years of age from the appliance unless they are constantly supervised make sure children are not playing with the appliance make sure children are supervised if they carry out cleaning and maintenance hold the plug not the cable when unplugging the appliance replace a damaged supply cord only by the manufacturer its ser vice agent or similarly qualied persons in order to avoid a hazard follow these instructions if coal gas or other inammable gas is leaking in the vicinity of the appliance turn o the valve of the leak ing gas open the doors and windows and do not unplug or plug in the power cable of the appliance or any other appliance open and close the doors only with the handles The gap between the doors and between the doors and the cabinet is very narrow Do not extend your hands in these areas to avoid pinching your n gers Open or close the refrigerator doors only when there are no children standing within the range of door movement disconnect the appliance from the electrical supply before under taking any routine maintenance Allow at least 5 minutes before restarting the appliance as frequent starting may damage the compressor eliminate the dust on the back of the unit at least once in the year to avoid hazard by re as well as increased energy consumption notice that the product is set for operation at a specic ambient range between 10 and 43C The appliance may not work properly 6 7
• Page 8 - English - : Safety Safety WARNING The appliance contains the ammable refrigerant ISOBUTANE R600a Make sure the refrigerant circuit is not damaged during transportation or installation Leaking refrigerant may cause eye injuries or ignite If a damage has occurred keep away open re sources thoroughly ventilate the room do not plug or unplug the power cords of the appliance or any other appliance Inform the customer service In case of eyes get into contact with the refrigerant rinse immedi ately it under running water and call immediately the eye specialist This refrigerator may contain the ammable refrigerant isobutane R600a It is hazardous for anyone other than an Authorised Service Person to service this appliance In Queensland the authorized Service Person MUST hold a Gas Work Authoriasation for hydrocarbon refrigerants to carry out Ser vicing or repairs which involve the removal of covers if it is left for a long period at a temperature above or below the indicated range check the condition of food if a warming in the freezer has taken place During daily use do not x set unnecessarily low temperature in the refrigerator compart ment Minus temperatures may occur at high settings Attention Bottles can burst x store medicines which need a precision storage temperature or bacteria or chemical agents in the appliance x store liquids in bottles or cans besides high percentage spirits especially carbonated beverages in the freezer as these will burst during freezing x place unstable articles heavy objects containers lled with water on the top of the appliance to avoid personal injury caused by fall ing or electric shock caused by contact with water x pull on the door shelves The door may be pulled slant the bottle rack may be pulled away or the appliance may topple x damage the refrigerant circuit If it does become damaged do not use the appliance x step on the freezer storage compartment door or drawer x touch the inside surface of the freezer storage compartment when in operation especially with wet hands as your hands may freeze onto the surface x touch frozen goods with wet hands wear gloves Especially do not eat ice lollies immediately after removal from the freezer com partment There is the risk to freeze or the formation of frost blis ters FIRST aid keep immediately under running cold water Do not pull away x scrape o frost and ice with sharp objects Do not use sprays elec tric heaters like heater hair dryer steam cleaners or other sources of heat in order to avoid damage to the plastic parts x use mechanical devices or other means to accelerate the defrost ing process other than those recommended by the manufacturer x clean the appliance with hard brushes wire brushes detergent powder petrol amyl acetate acetone and similar organic solu tions acid or alkaline solutions Please clean with special refrigera tor detergent to avoid damage WARNING Do not store or use inammables explosives or corrosive materi als in the appliance or in the vicinity x spray or ush the appliance during cleaning x use water spray or steam to clean the appliance x clean the cold glass shelves with hot water Sudden temperature change may cause the glass to break x use electrical devices inside the food storage compartments of the appliance unless they are of the type recommended by the manufacturer x try to repair the appliance by yourself In case of repair please con tact our customer service x store explosive substances such aerosol cans with a ammable propellant in this appliance Refrigerant gas information 8 9
• Page 9 - English - : Safety Safety WARNING The appliance contains the ammable refrigerant ISOBUTANE R600a Make sure the refrigerant circuit is not damaged during transportation or installation Leaking refrigerant may cause eye injuries or ignite If a damage has occurred keep away open re sources thoroughly ventilate the room do not plug or unplug the power cords of the appliance or any other appliance Inform the customer service In case of eyes get into contact with the refrigerant rinse immedi ately it under running water and call immediately the eye specialist This refrigerator may contain the ammable refrigerant isobutane R600a It is hazardous for anyone other than an Authorised Service Person to service this appliance In Queensland the authorized Service Person MUST hold a Gas Work Authoriasation for hydrocarbon refrigerants to carry out Ser vicing or repairs which involve the removal of covers if it is left for a long period at a temperature above or below the indicated range check the condition of food if a warming in the freezer has taken place During daily use do not x set unnecessarily low temperature in the refrigerator compart ment Minus temperatures may occur at high settings Attention Bottles can burst x store medicines which need a precision storage temperature or bacteria or chemical agents in the appliance x store liquids in bottles or cans besides high percentage spirits especially carbonated beverages in the freezer as these will burst during freezing x place unstable articles heavy objects containers lled with water on the top of the appliance to avoid personal injury caused by fall ing or electric shock caused by contact with water x pull on the door shelves The door may be pulled slant the bottle rack may be pulled away or the appliance may topple x damage the refrigerant circuit If it does become damaged do not use the appliance x step on the freezer storage compartment door or drawer x touch the inside surface of the freezer storage compartment when in operation especially with wet hands as your hands may freeze onto the surface x touch frozen goods with wet hands wear gloves Especially do not eat ice lollies immediately after removal from the freezer com partment There is the risk to freeze or the formation of frost blis ters FIRST aid keep immediately under running cold water Do not pull away x scrape o frost and ice with sharp objects Do not use sprays elec tric heaters like heater hair dryer steam cleaners or other sources of heat in order to avoid damage to the plastic parts x use mechanical devices or other means to accelerate the defrost ing process other than those recommended by the manufacturer x clean the appliance with hard brushes wire brushes detergent powder petrol amyl acetate acetone and similar organic solu tions acid or alkaline solutions Please clean with special refrigera tor detergent to avoid damage WARNING Do not store or use inammables explosives or corrosive materi als in the appliance or in the vicinity x spray or ush the appliance during cleaning x use water spray or steam to clean the appliance x clean the cold glass shelves with hot water Sudden temperature change may cause the glass to break x use electrical devices inside the food storage compartments of the appliance unless they are of the type recommended by the manufacturer x try to repair the appliance by yourself In case of repair please con tact our customer service x store explosive substances such aerosol cans with a ammable propellant in this appliance Refrigerant gas information 8 9
• Page 10 - English - : Product Description Use Before rst use Remove all packaging materials keep them out of childrens reach and dispose them in an environmentally friendly manner Clean the inside and outside of the appliance with water and a mild detergent before putting any food in it After the appliance has been levelled and cleaned wait for at least 2 hours before connecting it to the power supply See Section INSTALLATION Precool the compartments at high settings before loading with food The function Super Cool and Super Freeze help to cool down the compartments quickly The refrigerator temperature and freezer temperature are automatically set to 5 C and 18 C respectively These are the recommended settings If desired you can change these temperatures manually Please see FUNCTIONS 1 Refrigerator LED lamp 2 Rating plate 3 Glass shelves 4 OKtemperature indicator optional 5 Fruit and vegetable box cover 6 Fruit and vegetable box 7 My Zone glass cover 8 My Zone box 9 Upper freezer storage drawer 10 Middle freezer storage drawer 11 Lower freezer storage drawer 12 Adjustable feet 13 Upper door rack 14 Lower door rack 10 11
• Page 11 - English - : Product Description Use Before rst use Remove all packaging materials keep them out of childrens reach and dispose them in an environmentally friendly manner Clean the inside and outside of the appliance with water and a mild detergent before putting any food in it After the appliance has been levelled and cleaned wait for at least 2 hours before connecting it to the power supply See Section INSTALLATION Precool the compartments at high settings before loading with food The function Super Cool and Super Freeze help to cool down the compartments quickly The refrigerator temperature and freezer temperature are automatically set to 5 C and 18 C respectively These are the recommended settings If desired you can change these temperatures manually Please see FUNCTIONS 1 Refrigerator LED lamp 2 Rating plate 3 Glass shelves 4 OKtemperature indicator optional 5 Fruit and vegetable box cover 6 Fruit and vegetable box 7 My Zone glass cover 8 My Zone box 9 Upper freezer storage drawer 10 Middle freezer storage drawer 11 Lower freezer storage drawer 12 Adjustable feet 13 Upper door rack 14 Lower door rack 10 11
• Page 12 - English - : Use Use Fridge off A B C E F H G a1 a2 b c1 c2 h g e f Control panel Buttons A Fridge selector B My Zone selector C Freezer selector E Fuzzy mode selector F Holiday mode selector G Panel lock selector H Fridge o function sellector Indicators a1 Super cool function a2 Temperature fridge b Temperature My Zone c1 Super freeze function c2 Temperature freezer e Fuzzy mode f Holiday mode g Panel lock h Fridge o function Notice The appliance is preset to the recommended temperature of 5C refrigerator and 18C freezer Under normal ambient condition you need not to set a temperature When the appliance is switched on after disconnection from the main power supply it may take up to 12 hours for the correct temperatures to be reached Select the working mode You may need to select one of the following two ways to set the appliance 1 Fuzzy mode Under fuzzy mode the appliance can automatically adjust the temperature setting ac cording to the ambient temperature and temperature change in the appliance If you do not have any special requirements we recommend that you use fuzzy mode refer to FUZZY MODE 2 Manual adjusting mode If you want to manually adjust the temperature of the appliance in order to store a par ticular food you can set the temperature via a temperature adjusting button refer to ADJUST THE TEMPERATURE Empty the appliance before switching o To switch o the appliancepull the power cord out o the power socket 12 13 Switch on o the appliance The appliance is in operation as soon as it is connected to the power supply When the appliance is powered on for the rst time indicator c2 is shining on the display until the temperature reaches 5C or after 1 hour working The temperatures displayed in a2 b and c2 will shown the actual temperatures in the compartment Standbymode The display screen turns o automatically 30 seconds after pressing a key The display will be automatically locked It lights up automatically when pressing any key or opening the door Alarm does not light up the display screen Sensor keys The buttons on the control panel are sensor keys which already respond when lightly touched with the nger
• Page 13 - English - : Use Use Fridge off A B C E F H G a1 a2 b c1 c2 h g e f Control panel Buttons A Fridge selector B My Zone selector C Freezer selector E Fuzzy mode selector F Holiday mode selector G Panel lock selector H Fridge o function sellector Indicators a1 Super cool function a2 Temperature fridge b Temperature My Zone c1 Super freeze function c2 Temperature freezer e Fuzzy mode f Holiday mode g Panel lock h Fridge o function Notice The appliance is preset to the recommended temperature of 5C refrigerator and 18C freezer Under normal ambient condition you need not to set a temperature When the appliance is switched on after disconnection from the main power supply it may take up to 12 hours for the correct temperatures to be reached Select the working mode You may need to select one of the following two ways to set the appliance 1 Fuzzy mode Under fuzzy mode the appliance can automatically adjust the temperature setting ac cording to the ambient temperature and temperature change in the appliance If you do not have any special requirements we recommend that you use fuzzy mode refer to FUZZY MODE 2 Manual adjusting mode If you want to manually adjust the temperature of the appliance in order to store a par ticular food you can set the temperature via a temperature adjusting button refer to ADJUST THE TEMPERATURE Empty the appliance before switching o To switch o the appliancepull the power cord out o the power socket 12 13 Switch on o the appliance The appliance is in operation as soon as it is connected to the power supply When the appliance is powered on for the rst time indicator c2 is shining on the display until the temperature reaches 5C or after 1 hour working The temperatures displayed in a2 b and c2 will shown the actual temperatures in the compartment Standbymode The display screen turns o automatically 30 seconds after pressing a key The display will be automatically locked It lights up automatically when pressing any key or opening the door Alarm does not light up the display screen Sensor keys The buttons on the control panel are sensor keys which already respond when lightly touched with the nger
• Page 14 - English - : Use Use Notice The control panel is automatically blocked against activation if 30 seconds no button is pressed For any settings the control panel must be unlocked The indoor temperatures are inuenced by the follow ing factors Ambient temperature Frequency of door opening Amount of stored foods Installation of the appliance Super cool function Switch on the Super cool function if larger quan tity of food should be stored for example after the purchase The Super cool function accelerates the cooling of fresh food and protects the goods already stored from undesirable warming The factory setting temperature is 2 C 1 Unlock the panel if it is locked 2 Press button A Fridge for 3 seconds Indicator a1 illuminates and the function is activated 3 The same operation can exit super cool function Super freeze function Fresh food should be frozen as quickly as possible to the core This preserved the best nutritional value appearance and taste The Super freeze function ac celerates the freezing of fresh food and protects the goods already stored from undesirable warming If you need to freeze a large amount of food once it is recommended to set the Super freeze function on ahead for 24h before the usage of frozen room 1 Unlock the panel if it is locked 2 Press button C Freeze for 3 seconds Indicator c1 illuminates and the function is activated 3 The same operation can exit super freeze func tion Notice This function will be automatically disabled after 3 hours 14 15 Lockunlock panel Touch button G for 3 seconds to block all panel elements against activation The related indicator g is now displayed For unlocking press again the button Lock Hold 3 Sec Adjust the temperature for fridge 1 Unlock the panel if it is locked 2 Press button A Fridge for select the fridge com partment Indicator a2 is ashing 3 Press button A to set the refrigerator tempera ture The temperature increases in sequences of 1C from a minimum of 2C to a maximum of 8C switching to 2C again when pressing further The optimum temperature in the refrigerator is 5 C Colder temperatures mean unnecessary energy consumption 4 Press any key except A to conrm or the setting conrms automatically after 5 seconds Indicator a2 stops ashing Doordrawer opening alarm When the refrigerator door or the freezer drawer is opened for more than 3 minutes the doordrawer opening alarm will sound The alarm can be silenced by either closing the doordrawer or touching the control panel If the doordrawer is left open for more than 7 minutes the light inside the refrigeratorunder the re frigerator door and control panel illumination will auto matically switch o Adjust the temperature Adjust the temperature for freezer 1 Unlock the panel if it is locked 2 Press button C Freezer for select the freezer compartment Indicator c2 is ashing 3 Press button C Freezer to set the freezer temperature The temperature increases in sequences of 1C from a minimum of 14C to a maximum of 24C switching to 14C again when pressing further The optimum temperature in the freezer is 18C Colder temperatures mean unnecessary energy consumption 4 Press any key except C Freezer to conrm or the setting conrms automatically after 5 sec onds Indicator c2 stops ashing
• Page 15 - English - : Use Use Notice The control panel is automatically blocked against activation if 30 seconds no button is pressed For any settings the control panel must be unlocked The indoor temperatures are inuenced by the follow ing factors Ambient temperature Frequency of door opening Amount of stored foods Installation of the appliance Super cool function Switch on the Super cool function if larger quan tity of food should be stored for example after the purchase The Super cool function accelerates the cooling of fresh food and protects the goods already stored from undesirable warming The factory setting temperature is 2 C 1 Unlock the panel if it is locked 2 Press button A Fridge for 3 seconds Indicator a1 illuminates and the function is activated 3 The same operation can exit super cool function Super freeze function Fresh food should be frozen as quickly as possible to the core This preserved the best nutritional value appearance and taste The Super freeze function ac celerates the freezing of fresh food and protects the goods already stored from undesirable warming If you need to freeze a large amount of food once it is recommended to set the Super freeze function on ahead for 24h before the usage of frozen room 1 Unlock the panel if it is locked 2 Press button C Freeze for 3 seconds Indicator c1 illuminates and the function is activated 3 The same operation can exit super freeze func tion Notice This function will be automatically disabled after 3 hours 14 15 Lockunlock panel Touch button G for 3 seconds to block all panel elements against activation The related indicator g is now displayed For unlocking press again the button Lock Hold 3 Sec Adjust the temperature for fridge 1 Unlock the panel if it is locked 2 Press button A Fridge for select the fridge com partment Indicator a2 is ashing 3 Press button A to set the refrigerator tempera ture The temperature increases in sequences of 1C from a minimum of 2C to a maximum of 8C switching to 2C again when pressing further The optimum temperature in the refrigerator is 5 C Colder temperatures mean unnecessary energy consumption 4 Press any key except A to conrm or the setting conrms automatically after 5 seconds Indicator a2 stops ashing Doordrawer opening alarm When the refrigerator door or the freezer drawer is opened for more than 3 minutes the doordrawer opening alarm will sound The alarm can be silenced by either closing the doordrawer or touching the control panel If the doordrawer is left open for more than 7 minutes the light inside the refrigeratorunder the re frigerator door and control panel illumination will auto matically switch o Adjust the temperature Adjust the temperature for freezer 1 Unlock the panel if it is locked 2 Press button C Freezer for select the freezer compartment Indicator c2 is ashing 3 Press button C Freezer to set the freezer temperature The temperature increases in sequences of 1C from a minimum of 14C to a maximum of 24C switching to 14C again when pressing further The optimum temperature in the freezer is 18C Colder temperatures mean unnecessary energy consumption 4 Press any key except C Freezer to conrm or the setting conrms automatically after 5 sec onds Indicator c2 stops ashing
• Page 16 - English - : Use Use Notice The Superfreeze function will automatically switch o after 56 hours The appliance is then operated at the previously set temperature Notice Due to dierent water contents of meat some meat with more moisture will be fro zen at temperatures lower than 0C So immediately cut meat should be stored in MyZone box with temperatures min 0C Coldsensitive fruits like pineapple avocado bananas grapefruits and vegetables such as potatoes aubergines beans cucumbers zucchini and tomatoes and cheese should not be stored in the My Zone box Notice My zone storage temperature setting number cannot be higher than the fridge tem perature setting number WARNING During the holiday function no goods must be stored in the refrigerator compartment The temperature of 17 C is too high for storing food Fridge o function This function shuts down the refrigerator This has no eect on the freezer compartment 1 Unlock the panel if it is locked 2 Press button H Fridge o to select the Fridge o function Indicator h illuminates and the function is activated 3 The same operation can exit Fridge o function manually Fridge o Fridge o WARNING Empty the appliance before switching o Keep the door of the refrigerating compartment open when Fridge o function is activated in order to avoid odour or mold 16 17 My Zone box The fridge compartment is equipped with a My Zone box In accordance with the foods storage demands the most suitable temperature can be selected to get the optimal nutritional value of the foods Storage temperature can be adjusted between 3C and 5C 2 C 5 C is suitable to store vegetable and fruit 2 C 2 C is suitable to store fresh sh meat and cooked food in 12 days 3 C can defrost the frozen food after defrosting the food will be part frozen convenient for cutting and cooking M Y Z O N E Adjust the temperature for My Zone box 1 Unlock the panel if it is locked 2 Press button B My Zone for select the My Zone box Indicator b is ashing 3 Press button B My Zone again to set the My Zone box temperature The temperature increases in sequences of 1 C from a minimum of 3 C to a maximum of 5 C switching to 3 C again when pressing further 4 Press any key except B My Zone to conrm or the setting conrms automatically after 5 sec onds Indicator b stops ashing Fuzzy mode In the Fuzzy mode the appliance can automatically ad just the temperature setting according to the ambient temperature and temperature change in the appliance This function is totally hand free Unlock the panel if it is locked Press button E Fuzzy Indicator e illuminates and the function is acti vated The function can be deactivated by pressing but ton E Fuzzy again or by performing any other setting Fuzzy Fuzzy Holiday function This function sets the refrigerator temperature per manently to 17C This allows to keep the door of the empty refrigera tor closed without causing an odour or mold during a long absence eg during holiday The freezer com partment is free for your setting Unlock the panel if it is locked Press button F Holiday Indicator f illuminates and the function is activated The function can be deactivated by pressing but ton F Holiday again or by setting the refrigerator temperature or by performing any other setting Holiday Holiday
• Page 17 - English - : Use Use Notice The Superfreeze function will automatically switch o after 56 hours The appliance is then operated at the previously set temperature Notice Due to dierent water contents of meat some meat with more moisture will be fro zen at temperatures lower than 0C So immediately cut meat should be stored in MyZone box with temperatures min 0C Coldsensitive fruits like pineapple avocado bananas grapefruits and vegetables such as potatoes aubergines beans cucumbers zucchini and tomatoes and cheese should not be stored in the My Zone box Notice My zone storage temperature setting number cannot be higher than the fridge tem perature setting number WARNING During the holiday function no goods must be stored in the refrigerator compartment The temperature of 17 C is too high for storing food Fridge o function This function shuts down the refrigerator This has no eect on the freezer compartment 1 Unlock the panel if it is locked 2 Press button H Fridge o to select the Fridge o function Indicator h illuminates and the function is activated 3 The same operation can exit Fridge o function manually Fridge o Fridge o WARNING Empty the appliance before switching o Keep the door of the refrigerating compartment open when Fridge o function is activated in order to avoid odour or mold 16 17 My Zone box The fridge compartment is equipped with a My Zone box In accordance with the foods storage demands the most suitable temperature can be selected to get the optimal nutritional value of the foods Storage temperature can be adjusted between 3C and 5C 2 C 5 C is suitable to store vegetable and fruit 2 C 2 C is suitable to store fresh sh meat and cooked food in 12 days 3 C can defrost the frozen food after defrosting the food will be part frozen convenient for cutting and cooking M Y Z O N E Adjust the temperature for My Zone box 1 Unlock the panel if it is locked 2 Press button B My Zone for select the My Zone box Indicator b is ashing 3 Press button B My Zone again to set the My Zone box temperature The temperature increases in sequences of 1 C from a minimum of 3 C to a maximum of 5 C switching to 3 C again when pressing further 4 Press any key except B My Zone to conrm or the setting conrms automatically after 5 sec onds Indicator b stops ashing Fuzzy mode In the Fuzzy mode the appliance can automatically ad just the temperature setting according to the ambient temperature and temperature change in the appliance This function is totally hand free Unlock the panel if it is locked Press button E Fuzzy Indicator e illuminates and the function is acti vated The function can be deactivated by pressing but ton E Fuzzy again or by performing any other setting Fuzzy Fuzzy Holiday function This function sets the refrigerator temperature per manently to 17C This allows to keep the door of the empty refrigera tor closed without causing an odour or mold during a long absence eg during holiday The freezer com partment is free for your setting Unlock the panel if it is locked Press button F Holiday Indicator f illuminates and the function is activated The function can be deactivated by pressing but ton F Holiday again or by setting the refrigerator temperature or by performing any other setting Holiday Holiday
• Page 18 - English - : Use Use When storing commercially frozen foods please follow these guidelines Always follow manufacturers guidelines for the length of time you should store food for Do not exceed these guidelines Try to keep the length of time between purchase and storage as short as possible to preserve food quality Buy frozen foods which have been stored at a temperature of 18 C or below Avoid buying food which has ice or frost on the packaging This indicates that the products might have been partially defrosted and refrozen at some point temper ature rises aect the quality of food Storage into the freezer compartment Keep the freezer temperature at 18C 24 hours before freezing switch on the Superfreeze function for small quantities of food 46 hours are sucient Hot food must be cooled to room temperature before storing in the freezer com partment Food cut into small portions will freeze faster and be easier to defrost and cook The recommended weight for each portion is less than 25 kg It is better to pack food before putting it into the freezer The outside of the pack aging must be dry to avoid bags sticking together Packaging materials should be odourfree airtight nonpoisonous and nontoxic In order to avoid expiration of storage periods please note the freezing date time limit and name of the food on the packaging according to the storage periods of dif ferent foods WARNING Acid alkali and salt etc could erode the internal surface of the freezer Do not place the food having these substances eg sea sh directly on the internal surface Salt water in the freezer should be cleaned up immediately Do not exceed the food storage times recommended by the manufacturers Only take the required amount of food out of the freezer Consume defrosted food quickly Defrosted food cannot be refrozen unless it is rst cooked otherwise it may bless edible Do not load excessive quantities of fresh food in the freezer compartment Refer to the freezing capacity of the freezer See TECHNICAL DATA or data at the type plate Food can be stored in the freezer at a temperature of at least 18C for 2 to 12 months depending on its properties eg meat 312 months vegetables 612 months When freezing fresh food avoid bringing it in contact with already frozen food Risk of thawing Defreeze frozen food in the fridge This way you can use the frozen food to decrease the temperature in the compartment and save energy 18 19 Tips on storing fresh food Storing into the refrigerator compartment Keep your fridge temperature below 5C Hot food must be cooled to room temperature before storing in the appliance Foods stored in the refrigerator should be washed and dried before storing Food to be stored should be properly sealed to avoid odour or taste alterations Do not store excessive quantities of food Leave spaces between foods to allow cold air owing around them for a better and more homogeneous cooling Foods eaten daily should be stored at the front of the shelf Leave a gap between foods and the inner walls allowing air owing In special way dont store foods against the rear wall foods could freeze against rear wall Avoid di rect contact of food especially oily or acidic food with the inner liner as oilacid can erode the inner liner Clean away oilyacid dirt whenever it is found Defreeze frozen food in the fridge storage compartment This way you can use the frozen food to decrease the temperature in the compartment and save energy The ageing process of fruit and vegetables such as courgettes melons papaya ba nana pineapple etc can be accelerated in the refrigerator Therefore it is not advis able to store them in the refrigerator However the ripening of strongly green fruits can be promoted for a certain period Onions garlic ginger and other root vegeta bles should also be stored at room temperature Unpleasant odours inside the fridge are a sign that something has spilled and clean ing is required See CARE AND CLEANING Dierent foods should be placed in dierent areas according to their properties Food Location Butter cheese Upper door rack Eggs Door rack Fruit vegetables salad Fruit and vegetable box or My Zone box 2C 5C Meat sausage cheese milk Lower area lowest shelf coverage above the fruit and vegetable box Dairy products canned food cans Upper area or door rack Drinks bottles tubes Door rack Fresh meat fresh sh sau sages cooked foods My Zone box 2C 2C
• Page 19 - English - : Use Use When storing commercially frozen foods please follow these guidelines Always follow manufacturers guidelines for the length of time you should store food for Do not exceed these guidelines Try to keep the length of time between purchase and storage as short as possible to preserve food quality Buy frozen foods which have been stored at a temperature of 18 C or below Avoid buying food which has ice or frost on the packaging This indicates that the products might have been partially defrosted and refrozen at some point temper ature rises aect the quality of food Storage into the freezer compartment Keep the freezer temperature at 18C 24 hours before freezing switch on the Superfreeze function for small quantities of food 46 hours are sucient Hot food must be cooled to room temperature before storing in the freezer com partment Food cut into small portions will freeze faster and be easier to defrost and cook The recommended weight for each portion is less than 25 kg It is better to pack food before putting it into the freezer The outside of the pack aging must be dry to avoid bags sticking together Packaging materials should be odourfree airtight nonpoisonous and nontoxic In order to avoid expiration of storage periods please note the freezing date time limit and name of the food on the packaging according to the storage periods of dif ferent foods WARNING Acid alkali and salt etc could erode the internal surface of the freezer Do not place the food having these substances eg sea sh directly on the internal surface Salt water in the freezer should be cleaned up immediately Do not exceed the food storage times recommended by the manufacturers Only take the required amount of food out of the freezer Consume defrosted food quickly Defrosted food cannot be refrozen unless it is rst cooked otherwise it may bless edible Do not load excessive quantities of fresh food in the freezer compartment Refer to the freezing capacity of the freezer See TECHNICAL DATA or data at the type plate Food can be stored in the freezer at a temperature of at least 18C for 2 to 12 months depending on its properties eg meat 312 months vegetables 612 months When freezing fresh food avoid bringing it in contact with already frozen food Risk of thawing Defreeze frozen food in the fridge This way you can use the frozen food to decrease the temperature in the compartment and save energy 18 19 Tips on storing fresh food Storing into the refrigerator compartment Keep your fridge temperature below 5C Hot food must be cooled to room temperature before storing in the appliance Foods stored in the refrigerator should be washed and dried before storing Food to be stored should be properly sealed to avoid odour or taste alterations Do not store excessive quantities of food Leave spaces between foods to allow cold air owing around them for a better and more homogeneous cooling Foods eaten daily should be stored at the front of the shelf Leave a gap between foods and the inner walls allowing air owing In special way dont store foods against the rear wall foods could freeze against rear wall Avoid di rect contact of food especially oily or acidic food with the inner liner as oilacid can erode the inner liner Clean away oilyacid dirt whenever it is found Defreeze frozen food in the fridge storage compartment This way you can use the frozen food to decrease the temperature in the compartment and save energy The ageing process of fruit and vegetables such as courgettes melons papaya ba nana pineapple etc can be accelerated in the refrigerator Therefore it is not advis able to store them in the refrigerator However the ripening of strongly green fruits can be promoted for a certain period Onions garlic ginger and other root vegeta bles should also be stored at room temperature Unpleasant odours inside the fridge are a sign that something has spilled and clean ing is required See CARE AND CLEANING Dierent foods should be placed in dierent areas according to their properties Food Location Butter cheese Upper door rack Eggs Door rack Fruit vegetables salad Fruit and vegetable box or My Zone box 2C 5C Meat sausage cheese milk Lower area lowest shelf coverage above the fruit and vegetable box Dairy products canned food cans Upper area or door rack Drinks bottles tubes Door rack Fresh meat fresh sh sau sages cooked foods My Zone box 2C 2C
• Page 20 - English - : Equipment Equipment Notice Ensure that all ends of a shelf are level 20 21 Multiairow The refrigerator is equipped with a multiairow sys tem with which cool air ows are located on every shelf level This helps to maintain a uniform temperature to ensure that your food is kept fresher for longer MyZone box For the use and setting of the My Zone box please check section USE My Zone box M Y Z O N E Adjustable shelves The height of the shelves can be adjusted to t your storage needs 1 To relocate a shelf remove it rst by uplifting its hind edge 1 and pulling it out 2 2 To reinstall it put it on the lugs on both sides and push it to the most rearward position until the rear of the shelf is xed inside the slots in the sides Removable door racks The door racks can be removed for cleaning Place hands on each side of the rack lift it upwards 1 and pull it out 2 In order to insert the door rack the above steps are carried out in reverse order Ice cube tray 1 Fill the ice cube tray 34 full of water close t with the cover and put it into the prefreezing com partment 2 Twist the ice cube tray slightly or hold it under ow ing water to loosen the ice cubes Energy saving tips Make sure the appliance is properly ventilated see INSTALLATION Do not install the appliance in direct sunlight or in the near of heat sourceseg stoves heaters Avoid unnecessarily low temperature in the appliance The energy consumption in creases the lower the temperature in the appliance is set Functions like SUPER COOL or SUPER FREEZE consume more energy Allow warm food to cool down before placing it in the appliance Open the appliance door as little and as briey as possible Do not overll the appliance to avoid obstructing the air ow Avoid air within the food packaging Keep door seals clean so that the door always closes correctly Defreeze frozen food in the fridge storage compartment
• Page 21 - English - : Equipment Equipment Notice Ensure that all ends of a shelf are level 20 21 Multiairow The refrigerator is equipped with a multiairow sys tem with which cool air ows are located on every shelf level This helps to maintain a uniform temperature to ensure that your food is kept fresher for longer MyZone box For the use and setting of the My Zone box please check section USE My Zone box M Y Z O N E Adjustable shelves The height of the shelves can be adjusted to t your storage needs 1 To relocate a shelf remove it rst by uplifting its hind edge 1 and pulling it out 2 2 To reinstall it put it on the lugs on both sides and push it to the most rearward position until the rear of the shelf is xed inside the slots in the sides Removable door racks The door racks can be removed for cleaning Place hands on each side of the rack lift it upwards 1 and pull it out 2 In order to insert the door rack the above steps are carried out in reverse order Ice cube tray 1 Fill the ice cube tray 34 full of water close t with the cover and put it into the prefreezing com partment 2 Twist the ice cube tray slightly or hold it under ow ing water to loosen the ice cubes Energy saving tips Make sure the appliance is properly ventilated see INSTALLATION Do not install the appliance in direct sunlight or in the near of heat sourceseg stoves heaters Avoid unnecessarily low temperature in the appliance The energy consumption in creases the lower the temperature in the appliance is set Functions like SUPER COOL or SUPER FREEZE consume more energy Allow warm food to cool down before placing it in the appliance Open the appliance door as little and as briey as possible Do not overll the appliance to avoid obstructing the air ow Avoid air within the food packaging Keep door seals clean so that the door always closes correctly Defreeze frozen food in the fridge storage compartment
• Page 22 - English - : Care and Cleaning Care and Cleaning Cleaning Clean the appliance when only little or no food is stored The appliance should be cleaned every four weeks for good maintenance and to prevent bad stored food odors WARNING Do not clean the appliance with hard brushes wire brushes detergent powder petrol amyl acetate acetone and similar organic solutions acid or alkaline solutions Please clean with special refrigerator detergent to avoid damage Do not spray or ush the appliance during cleaning Do not use water spray or steam to clean the appliance Do not clean the cold glass shelves with hot water Sudden temperature change may cause the glass to break Do not touch the inside surface of the freezer storage compartment especially with wet hands as your hands may freeze onto the surface In case of heating check the condition of frozen goods WARNING Disconnect the appliance from the power supply before cleaning WARNING Do not replace the LED lamp yourself it must only be replaced by either the manufac turer or the authorised service agent Notice Turn the appliance o only if strictly necessary WARNING Do not lift the appliance by its handles Never place the appliance horizontally on the ground 22 23 Always keep the door gasket clean Clean the inside and housing of the appliance with a sponge dampened in warm water and neutral detergent Rinse and dry with soft cloth Do not clean any of the parts of the appliance in a dishwasher Allow at least 5 minutes before restarting the appliance as frequent starting may damage the compressor Defrosting The defrosting of the refrigerator and the freezer compartment are done automatically no manual operation is needed Replacing the LEDlamps The lamp adopts LED as its light source featuring low energy consumption and long ser vice life If there is any abnormality please contact the customer service See CUSTOMER SERVICE Nonuse for a longer period If the appliance is not used for an extended period of time and you will not use the Holiday function for the refrigerator Take out the food Unplug the power cord Clean the appliance as described above Keep the door and freezer drawersdoor open to prevent the creation of bad odours inside Parameters of the lamp Model Refrigerator compartment Freezer compartment Voltage max Power Voltage max Power HBM450WH1 HBM450SA1 12V 2 W Moving the appliance 1 Remove all food and unplug the appliance 2 Secure shelves and other moveable parts in the fridge and the freezer with adhesive tape 3 Do not tilt the refrigerator more than 45 to avoid damaging the refrigerating system
• Page 23 - English - : Care and Cleaning Care and Cleaning Cleaning Clean the appliance when only little or no food is stored The appliance should be cleaned every four weeks for good maintenance and to prevent bad stored food odors WARNING Do not clean the appliance with hard brushes wire brushes detergent powder petrol amyl acetate acetone and similar organic solutions acid or alkaline solutions Please clean with special refrigerator detergent to avoid damage Do not spray or ush the appliance during cleaning Do not use water spray or steam to clean the appliance Do not clean the cold glass shelves with hot water Sudden temperature change may cause the glass to break Do not touch the inside surface of the freezer storage compartment especially with wet hands as your hands may freeze onto the surface In case of heating check the condition of frozen goods WARNING Disconnect the appliance from the power supply before cleaning WARNING Do not replace the LED lamp yourself it must only be replaced by either the manufac turer or the authorised service agent Notice Turn the appliance o only if strictly necessary WARNING Do not lift the appliance by its handles Never place the appliance horizontally on the ground 22 23 Always keep the door gasket clean Clean the inside and housing of the appliance with a sponge dampened in warm water and neutral detergent Rinse and dry with soft cloth Do not clean any of the parts of the appliance in a dishwasher Allow at least 5 minutes before restarting the appliance as frequent starting may damage the compressor Defrosting The defrosting of the refrigerator and the freezer compartment are done automatically no manual operation is needed Replacing the LEDlamps The lamp adopts LED as its light source featuring low energy consumption and long ser vice life If there is any abnormality please contact the customer service See CUSTOMER SERVICE Nonuse for a longer period If the appliance is not used for an extended period of time and you will not use the Holiday function for the refrigerator Take out the food Unplug the power cord Clean the appliance as described above Keep the door and freezer drawersdoor open to prevent the creation of bad odours inside Parameters of the lamp Model Refrigerator compartment Freezer compartment Voltage max Power Voltage max Power HBM450WH1 HBM450SA1 12V 2 W Moving the appliance 1 Remove all food and unplug the appliance 2 Secure shelves and other moveable parts in the fridge and the freezer with adhesive tape 3 Do not tilt the refrigerator more than 45 to avoid damaging the refrigerating system
• Page 24 - English - : Troubleshooting Troubleshooting Many occuring problems could be solved by yourself without specic expertise In case of a problem please check all shown possibilities and follow below instructions before you contact an after sales service See CUSTOMER SERVICE Problem Possible Cause Possible Solution The compressor does not work Mains plug is not connected in the mains socket The appliance is in the defrosting cycle Connect the mains plug This is normal for an automatic defrosting The appliance runs frequently or runs for a too long period of time The indoor or outdoor tempera ture is too high The appliance has been o power for a period of time A doordrawer of the appliance is not tightly closed The doordrawer has been opened too frequently or for too long The temperature setting for the freezer compartment is too low The doordrawer gasket is dirty worn cracked or mismatched The required air circulation is not guaranteed In this case it is normal for the appliance to run longer Normally it takes 8 to 12 hours for the appliance to cool down completely Close the doordrawer and ensure the appliance is located on a level ground and there is no food or container jarring the door Do not open the doordrawer too frequently Set the temperature higher until a satisfactory refrigera tor temperature is obtained It takes 24 hours for the refrig erator temperature to become stable Clean the doordrawer gasket or replace them by the cus tomer service Ensure adequate ventilation The inside of the re frigerator is dirty and or smells The inside of the refrigerator needs cleaning Food of strong odour is stored in the refrigerator Clean the inside of the refrig erator Wrap the food thoroughly WARNING Before maintenance deactivate the appliance and disconnect the mains plug from the mains socket Electrical equipment should be serviced only by qualied electrical experts because improper repairs can cause considerable consequential damages A damaged supply should only be replaced by the manufacturer its service agent or similarly qualied persons in order to avoid a hazard Problem Possible Cause Possible Solution It is not cold enough i nside the appli ance The temperature is set too high Too warm goods has been stored Too much food has been stored at one time The goods are too close to each other A doordrawer of the appliance is not tightly closed The doordrawer has been opened too frequently or for too long Reset the temperature Always cool down goods be fore storing them Always store small quantities of food Leave a gap between several foods allowing air owing Close the doordrawer Do not open the doordrawer too frequently It is too cold inside the appliance The temperature is set too low The Super freezeSuper cool function is activated or is running too long Reset the temperature Switch o the Super freezeSu per coolfunction Moisture formation on the inside of the refrigerator com partment The climate is too warm and too damp A doordrawer of the appliance is not tightly closed The doordrawer has been opened too frequently or for too long Food containers or liquids are left open Increase the temperature Close the doordrawer Do not open the doordrawer too frequently Let hot foods cool to room temperature and cover foods and liquids Moisture accumu lates on the refrig erators outside surface or between the doorsdoor and drawer The climate is too warm and too damp The doordrawer is not closed tightly The cold air in the appliance and the warm air outside it con densates This is normal in damp climate and will change when the hu midity decreases Ensure that he doordrawer is tightly shut Strong ice and frost in the freezer com partment The goods were not adequately packaged A doordrawer of the appliance is not tightly closed The doordrawer has been opened too frequently or for too long The doordrawer gasket is dirty worn cracked or mismatched Something on the inside prevents the doordrawer to close properly Always pack the goods well Close the doordrawer Do not open the doordrawer too frequently Clean the doordrawer gasket or replace them by new ones Reposition the shelves door racks or internal containers to allow the doordrawer to close 24 25
• Page 25 - English - : Troubleshooting Troubleshooting Many occuring problems could be solved by yourself without specic expertise In case of a problem please check all shown possibilities and follow below instructions before you contact an after sales service See CUSTOMER SERVICE Problem Possible Cause Possible Solution The compressor does not work Mains plug is not connected in the mains socket The appliance is in the defrosting cycle Connect the mains plug This is normal for an automatic defrosting The appliance runs frequently or runs for a too long period of time The indoor or outdoor tempera ture is too high The appliance has been o power for a period of time A doordrawer of the appliance is not tightly closed The doordrawer has been opened too frequently or for too long The temperature setting for the freezer compartment is too low The doordrawer gasket is dirty worn cracked or mismatched The required air circulation is not guaranteed In this case it is normal for the appliance to run longer Normally it takes 8 to 12 hours for the appliance to cool down completely Close the doordrawer and ensure the appliance is located on a level ground and there is no food or container jarring the door Do not open the doordrawer too frequently Set the temperature higher until a satisfactory refrigera tor temperature is obtained It takes 24 hours for the refrig erator temperature to become stable Clean the doordrawer gasket or replace them by the cus tomer service Ensure adequate ventilation The inside of the re frigerator is dirty and or smells The inside of the refrigerator needs cleaning Food of strong odour is stored in the refrigerator Clean the inside of the refrig erator Wrap the food thoroughly WARNING Before maintenance deactivate the appliance and disconnect the mains plug from the mains socket Electrical equipment should be serviced only by qualied electrical experts because improper repairs can cause considerable consequential damages A damaged supply should only be replaced by the manufacturer its service agent or similarly qualied persons in order to avoid a hazard Problem Possible Cause Possible Solution It is not cold enough i nside the appli ance The temperature is set too high Too warm goods has been stored Too much food has been stored at one time The goods are too close to each other A doordrawer of the appliance is not tightly closed The doordrawer has been opened too frequently or for too long Reset the temperature Always cool down goods be fore storing them Always store small quantities of food Leave a gap between several foods allowing air owing Close the doordrawer Do not open the doordrawer too frequently It is too cold inside the appliance The temperature is set too low The Super freezeSuper cool function is activated or is running too long Reset the temperature Switch o the Super freezeSu per coolfunction Moisture formation on the inside of the refrigerator com partment The climate is too warm and too damp A doordrawer of the appliance is not tightly closed The doordrawer has been opened too frequently or for too long Food containers or liquids are left open Increase the temperature Close the doordrawer Do not open the doordrawer too frequently Let hot foods cool to room temperature and cover foods and liquids Moisture accumu lates on the refrig erators outside surface or between the doorsdoor and drawer The climate is too warm and too damp The doordrawer is not closed tightly The cold air in the appliance and the warm air outside it con densates This is normal in damp climate and will change when the hu midity decreases Ensure that he doordrawer is tightly shut Strong ice and frost in the freezer com partment The goods were not adequately packaged A doordrawer of the appliance is not tightly closed The doordrawer has been opened too frequently or for too long The doordrawer gasket is dirty worn cracked or mismatched Something on the inside prevents the doordrawer to close properly Always pack the goods well Close the doordrawer Do not open the doordrawer too frequently Clean the doordrawer gasket or replace them by new ones Reposition the shelves door racks or internal containers to allow the doordrawer to close 24 25
• Page 26 - English - : Troubleshooting Installation Problem Possible Cause Possible Solution The appliance makes abnormal sounds The appliance is not located on level ground The appliance touches some ob ject around it Adjust the feet to level the ap pliance Remove objects around the appliance A slight sound is to be heard si milar to that of owing water This is normal You will hear an alarm beep The fridge storage compartment door is open The temperature in the freezer is too high Close the door or silence the alarm manually The alarm is normal when it is rst started due to relatively higher temperature You can silence the alarm manually see section USE You will hear a faint hum The anticondensation system is working This prevents condensation and is normal The interior lighting or cooling system does not work Mains plug is not connected in the mains socket The power supply is not intact The LEDlamp is out of order Connect the mains plug Check the electrical supply to the room Call the local elec tricity company Please call the service for changing the lamp Unpacking Take the appliance out of the packaging Remove all packaging materials Environmental conditions The room temperature should always be between 10 C and 43 C since it can inuence the temperature inside the appliance and its energy consumption Do not install the appli ance near other heatemitting appliances ovens refrigerators without isolation Door reversibility Before the appliance is permanently installed check the correct position of the door hinge If necessary see section the DOOR REVERSIBILITY Space requirement Required space when door is opened W2 W1 D2 D1 WARNING The appliance is heavy Always handle with at least two persons Keep all packaging materials out of childrens reach and dispose them in an environ mentally friendly manner Ventilaton crosssection To achieve sucient ventilation of the appliance for safety reasons the information of the required venti lation cross sections must be observed 50 mm 50 mm 50 mm 26 27 Power interruption In the event of a power cut food should remain safely cold for about 16 hours Follow these tips during a prolonged power interruption especially in summer Open the doordrawer as few times as possible Do not put additional food into the appliance during a power interruption If prior notice of a power interruption is given and the interruption duration is longer than 16 hours make some ice and put it in a container in the top of the refrigerator compartment An inspection of the goods is required immediately after the interruption As temperature in the refrigerator will rise during a power interruption or other fail ure the storage period and edible quality of food will be reduced Any food that de frosts should be either consumed or cooked and refrozen where suitable soon afterwards in order to prevent health risks Model Appliance width in mm Appliance depth in mm W1 W2 D1 D2 HBM450WH1 HBM450SA1 1100 700 1323
• Page 27 - English - : Troubleshooting Installation Problem Possible Cause Possible Solution The appliance makes abnormal sounds The appliance is not located on level ground The appliance touches some ob ject around it Adjust the feet to level the ap pliance Remove objects around the appliance A slight sound is to be heard si milar to that of owing water This is normal You will hear an alarm beep The fridge storage compartment door is open The temperature in the freezer is too high Close the door or silence the alarm manually The alarm is normal when it is rst started due to relatively higher temperature You can silence the alarm manually see section USE You will hear a faint hum The anticondensation system is working This prevents condensation and is normal The interior lighting or cooling system does not work Mains plug is not connected in the mains socket The power supply is not intact The LEDlamp is out of order Connect the mains plug Check the electrical supply to the room Call the local elec tricity company Please call the service for changing the lamp Unpacking Take the appliance out of the packaging Remove all packaging materials Environmental conditions The room temperature should always be between 10 C and 43 C since it can inuence the temperature inside the appliance and its energy consumption Do not install the appli ance near other heatemitting appliances ovens refrigerators without isolation Door reversibility Before the appliance is permanently installed check the correct position of the door hinge If necessary see section the DOOR REVERSIBILITY Space requirement Required space when door is opened W2 W1 D2 D1 WARNING The appliance is heavy Always handle with at least two persons Keep all packaging materials out of childrens reach and dispose them in an environ mentally friendly manner Ventilaton crosssection To achieve sucient ventilation of the appliance for safety reasons the information of the required venti lation cross sections must be observed 50 mm 50 mm 50 mm 26 27 Power interruption In the event of a power cut food should remain safely cold for about 16 hours Follow these tips during a prolonged power interruption especially in summer Open the doordrawer as few times as possible Do not put additional food into the appliance during a power interruption If prior notice of a power interruption is given and the interruption duration is longer than 16 hours make some ice and put it in a container in the top of the refrigerator compartment An inspection of the goods is required immediately after the interruption As temperature in the refrigerator will rise during a power interruption or other fail ure the storage period and edible quality of food will be reduced Any food that de frosts should be either consumed or cooked and refrozen where suitable soon afterwards in order to prevent health risks Model Appliance width in mm Appliance depth in mm W1 W2 D1 D2 HBM450WH1 HBM450SA1 1100 700 1323
• Page 28 - English - : Installation Installation Waiting time To the maintenancefree lubrication oil is located in the capsule of the compressor This oil can get through the closed pipe system during slanting transport Be fore connecting the appliance to the power supply you have to wait 2 hours so that the oil runs back into the capsule 2 h Aigning the appliance The appliance should be placed on a at and solid sur face 1 Tilt the appliance slightly backwards 2 Set the feet to the desired level Make sure the distance to the wall on the hinge side is at least 100 mm for the door to open properly 3 The stability can be checked by alternately bump ing on the diagonals The slightly swaying should be the same in both directions Otherwise the frame can warp possible leaking door seals are the result A low tendency to the rear facilitates the closing of the door max 45 1 2 WARNING To avoid risks a damaged power cord must be replaced by the customer service see warranty card Electrical connection Before each connection check if power supply socket and fusing are appropriate to the rating plate the power socket is earthed and no multiplug or extension the power plug and socket are strictly according Connect the plug to a properly installed household socket Door Reversibility Before connecting the appliance to the power supply you should check whether the door swing must changed from right as delivered to left if this is required by the installation location and the usability WARNING The appliance is heavy You need two persons to carry out the door reversibility Before any operation rst unplug the appliance from the mains Do not tilt the appliance more than 45 to prevent damage of the cooling system 1 Provide necessary tool 2 Unplug the appliance 3 Remove the xation of the cover 4 Remove the faceplate of the body 5 Remove the topplate of the upper door 6 Remove the hinge cover 7 Unplug the connection cable 8 Unscrew the upper hinge 9 Lift the loose upper door carefully o the lower hinge 10 Turn the upper door upside down and change the position of the hinge barrel on the lower side of the door 11 Change the door stop from the current position to opposite side 12 Unscrew the lower hinge of the upper door 1 2 3 4 7 8 28 29
• Page 29 - English - : Installation Installation Waiting time To the maintenancefree lubrication oil is located in the capsule of the compressor This oil can get through the closed pipe system during slanting transport Be fore connecting the appliance to the power supply you have to wait 2 hours so that the oil runs back into the capsule 2 h Aigning the appliance The appliance should be placed on a at and solid sur face 1 Tilt the appliance slightly backwards 2 Set the feet to the desired level Make sure the distance to the wall on the hinge side is at least 100 mm for the door to open properly 3 The stability can be checked by alternately bump ing on the diagonals The slightly swaying should be the same in both directions Otherwise the frame can warp possible leaking door seals are the result A low tendency to the rear facilitates the closing of the door max 45 1 2 WARNING To avoid risks a damaged power cord must be replaced by the customer service see warranty card Electrical connection Before each connection check if power supply socket and fusing are appropriate to the rating plate the power socket is earthed and no multiplug or extension the power plug and socket are strictly according Connect the plug to a properly installed household socket Door Reversibility Before connecting the appliance to the power supply you should check whether the door swing must changed from right as delivered to left if this is required by the installation location and the usability WARNING The appliance is heavy You need two persons to carry out the door reversibility Before any operation rst unplug the appliance from the mains Do not tilt the appliance more than 45 to prevent damage of the cooling system 1 Provide necessary tool 2 Unplug the appliance 3 Remove the xation of the cover 4 Remove the faceplate of the body 5 Remove the topplate of the upper door 6 Remove the hinge cover 7 Unplug the connection cable 8 Unscrew the upper hinge 9 Lift the loose upper door carefully o the lower hinge 10 Turn the upper door upside down and change the position of the hinge barrel on the lower side of the door 11 Change the door stop from the current position to opposite side 12 Unscrew the lower hinge of the upper door 1 2 3 4 7 8 28 29
• Page 30 - English - : Installation Technical Data 13 Change the positions of the blanking plugs and the screw on the side After the change of the door check that the door seals are located properly on the housing and all screws are tightened well a Remove lower door b Change the positions of the blanking plug at the top of the lower door c Change the door stop at the bottom of the lower door from the current position to opposite side d Unscrew the lower hinge e Take out the new lower hinges from the accessory bag and screw the new lower hinge to the other side of the door opening f Lift the lower door carefully on to the lower hinge so that the pivot ts into the hinge barrel a b c d e f 14 Take out the new hinges from the accessory bag and screw the new lower hinge of upper door to the other side of the door opening Be sure the pivot ts into the hinge barrel of lower door 15 Lift the door carefully on to the lower hinge so that the pivot ts into the hinge barrel 16 Fix the upper hinge with the screws 17 Put the connection cable through the hinge cover delivered in the accessory bag and put it over the hinge 18 Plug in the connection cable and t it into the opening 19 Replace faceplate and cover x it with the screws and reinsert the xation see g 3 15 16 17 18 30 31 Trade mark Haier Category of the model Refrigeratorfreezer Frostfree system Yes Climate class Model No HBM450WH1 HBM450SA1 Energy Star Voltage Frequency 220V240V50Hz 4 star Product group 5B Total gross volume 450L Total storage volume 386L Fresh food compartment volume 312L Freezer compartment volume 74L Insulation blowing gas HCC601 Dimension DxWxH 676x700x1725mm Rrefrigerant R600a 63g T Protection class I
• Page 31 - English - : Installation Technical Data 13 Change the positions of the blanking plugs and the screw on the side After the change of the door check that the door seals are located properly on the housing and all screws are tightened well a Remove lower door b Change the positions of the blanking plug at the top of the lower door c Change the door stop at the bottom of the lower door from the current position to opposite side d Unscrew the lower hinge e Take out the new lower hinges from the accessory bag and screw the new lower hinge to the other side of the door opening f Lift the lower door carefully on to the lower hinge so that the pivot ts into the hinge barrel a b c d e f 14 Take out the new hinges from the accessory bag and screw the new lower hinge of upper door to the other side of the door opening Be sure the pivot ts into the hinge barrel of lower door 15 Lift the door carefully on to the lower hinge so that the pivot ts into the hinge barrel 16 Fix the upper hinge with the screws 17 Put the connection cable through the hinge cover delivered in the accessory bag and put it over the hinge 18 Plug in the connection cable and t it into the opening 19 Replace faceplate and cover x it with the screws and reinsert the xation see g 3 15 16 17 18 30 31 Trade mark Haier Category of the model Refrigeratorfreezer Frostfree system Yes Climate class Model No HBM450WH1 HBM450SA1 Energy Star Voltage Frequency 220V240V50Hz 4 star Product group 5B Total gross volume 450L Total storage volume 386L Fresh food compartment volume 312L Freezer compartment volume 74L Insulation blowing gas HCC601 Dimension DxWxH 676x700x1725mm Rrefrigerant R600a 63g T Protection class I
