Please read this manual carefully before operating
your set and retain it for future reference.
P/NO.: MFL62883329
www.lg.com
ENGLISH
Important
(In the UK Only)
The wires in this mains lead are coloured in accordance
with the following code:
As the colours of the wires in the mains lead of this
apparatus may not correspond with the coloured
markings identifying the terminals in your plug, proceed
as follows:
The wire which is coloured Green and Yellow must be
connected to the terminal in the plug which is marked
with the letter E or by the earth symbol( ) or coloured
Green or Green and Yellow.
The wire which is coloured Blue must be connected to
the terminal which is marked with the letter N or
coloured Black.
The wire which is coloured Brown must be connected to
the terminal which is marked with the letter L or
coloured Red.
If a 13 amp(BS 1363) plug is used, fit a 13 amp BS 1362
fuse.
GREEN AND YELLOW:EARTH
BLUE:NEUTRAL
BROWN:LIVE
This appliance must be earthed
2
3
4
4
13
15
16
16
20
21
23
24
26
26
27
30
31
32
Refrigerator compartment
Use Skills for Multi-use Compartment
22
Door in Door Use Skills (Only apply for some Models)
23
Energy-Saving Method
Use Skills for Freezer Compartment (lower)
37
Smart Diagnosis (Only apply for some Models)
Smart Diagnosis
4
5
Prevent the power cord from being squeezed or imprinted
if the refrigerator is pushed in after the power plug is
extracted during the installation.
It becomes the cause of fire or electric shock. When moving
your appliance away from the wall, be careful not to roll over
or damage the power cord.
Do not allow the power plug to face upward or to be
squeezed at the back of the refrigerator.
The dedicated outlet should be used.
• Using several devices at one outlet may cause fire.
• The electric leakage breaker may damage food and
the dispenser may be leaked.
Water may be flown into or the plug may be damaged,
which causes fire or electric shock.
6
Do not allow the power cord bent or pressed by the
heavy object to be damaged.
Do not extend or modify the length of the power
plug.
It may damage the power cord to cause fire or electric
shock.
It causes electric shock or fire by the electric damage
of the power cord or others.
• It may cause electric shock or injury.
• When replacing the interior lamp of the refrigerator,
make sure that the rubber ring for preventing the
electric spark within the socket is not taken off.
Unplug the power plug when cleaning, handling or
replacing the interior lamp of the refrigerator.
Do not pull out the cord or touch the power plug
with wet hands.
• It may cause electric shock or injury.
Remove water or dust from the power plug and insert
it with the ends of the pins securely connected.
Dust, water or unstable connection may fire or electric
shock.
Make sure of grounding.
Consult a qualified electrician or service person if
the grounding instructions are not completely
understood, or if you have doubts on whether the
appliance is properly grounded or not.
The incorrect grounding may cause breakdown and
electric shock.
Be sure to use grounded exclusive proper voltage consent for the
power plug.
It becomes the cause of fire.
It may cause electric shock or short circuit to fire.
Pull out the power plug not by grasping the cord but
the plug of its end.
7
When the power cord or the power plug is damaged
or the holes of the outlet are loosed, do not use them.
It may cause electric shock or short circuit to make fire.
Wait for 5 minutes or longer when reconnecting
the plug.
It may cause the operation of the freezer to fail.
If the supply cord is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid any
hazard.
Do not place the heavy object or the dangerous object
(container with liquid) on the refrigerator.
It may be dropped to cause injury, fire or electric shock
when opening or closing the door.
Do not install the refrigerator in the wet place or the
place which water or rain splashes.
Deterioration of insulation of electric parts may cause
electric leakage.
Do not cling to the door or the shelves of the door
or the home bar of the freezer or the cool chamber.
It may make the refrigerator fallen down or damage
the hands. Especially, do not allow the children to do
the above.
Prevent children from entering the product.
It may endanger the life of a child if the child enters
the refrigerator.
Opening and closing the door of the refrigerator vigorously may
cause the stored food in the refrigerator basket to fall by shock and
hurt the foot, so take precautions.
8
Don’t insert the hands into the automatic ice maker.
(Only for the model with the automatic ice maker)
It may cause injury.
禁止
Do not place the lit candle within the fridge-freezer
to deodorize. Do not use drier to dry the inside, nor
light a candle to remove odor.
It may cause explosion or fire.
Do not place flower vase, cup, cosmetics, medicine
or any container with water on the refrigerator.
Avoid the heating devices. Install in places away
from the fire such as the place where flammable
gas is leaked.
It may cause fire.
Do not store the medicine or the academic materials
at the refrigerator.
Do not use the combustible spray near the
Do not store explosive substances such as
aerosol cans with a flammable propellant in
this appliance.
refrigerator.
When the material with the strict temperature control
is stored, it may be deteriorated or it may make an
unexpected reaction to cause any risk.
It may cause fire.
It may cause fire, electric shock or injury by dropping
down.
9
Use the submerged refrigerator after checking it.
It may cause electric shock or fir.
In case of thunder and lightning, or not in use for a
long period of time, detach the power plug.
There is a danger of electric shock or fire.
• The explosion by spark may cause fire or burn.
• Because this refrigerator uses natural gas (isobutene,
R600a) as the environment-friendly refrigerant, even
a small amount (80~90g) is combustible. When the
gas is leaked by the severe damage during delivering,
installing or using the refrigerator, any spark may
cause fire or burn.
When gas is leaked, do not touch the refrigerator
or the outlet and ventilate the room immediately.
Do not spray water at the outside or the inside of
the refrigerator or do not clean it with benzene or
thinner.
When any strange smell or smoke is detected
from the refrigerator, disconnect the power plug
immediately and contact to the service center.
Deterioration of insulation of electric parts may cause
electric shock or fire.
It may cause fire.
Do not allow any person except the qualified
engineer to disassemble, repair or alter the
refrigerator.
It may cause injury, electric shock or fire.
10
When disposing the refrigerator, remove the packing
material from the door or take off the doors but leave
the shelves in place so that children may not easily
climb inside.
It many cause to lock out the child.
Installing it on the unstable place may cause death by
falling down the refrigerator when opening or closing
the door.
Do not use the refrigerator for non-domestic
purpose (storing medicine or testing material,
using at the ship, etc.).
It may cause an unexpected risk such as fire,
electric shock, deterioration of stored material or
chemical reaction.
Install the refrigerator on the solid and level floor.
It may cause electric shock or injury.
Do not insert the hands or the metal stick into the exit
of cool air, the cover, the bottom of the refrigerator,
the heatproof grill (exhaust hole) at the backside.
When you want to dispose the large living waste such as
electric home appliance and furniture, you’d better contact
the local down block office.
When you want to dispose the refrigerator, contact to
the down-block office.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play
with the appliance.
Supply the automatic ice maker only with drinkable
water. (Only for the model with the automatic ice
maker) .
· Otherwise, it may cause a risk.
11
Violating this direction may cause injury or damage house or furniture.
Always be careful, please.
Do not touch food or containers at the freezer with
wet hands.
It may cause frostbite.
When the electricity is off for long time, remove ice
from the ice box.
· Ice may melt due to long-time power failure.
Do not put bottle in the freezer.
It may freeze the contents to break the bottle to cause
injury.
Do not place the food in disorder inside the refrigerator.
The food may fall during opening and closing the door of the refrigerator
and hurt people.
The iron plate of the bottom may cause injury.
Do not insert the hands into the bottom of the
refrigerator.
Carry the refrigerator with the handle bar at the
bottom of the front and the top of the rear.
Otherwise, your hands may be slipped to cause injury.
Because the product is heavy, carrying it alone may
hurt people or accidents may occur.
Because opening or closing the door of the
refrigerator may cause injury to the person around
it, be careful, please.
Opening or closing the door may cause feet or hands
to be caught in the chink in door or the child to be get
hurt by the corner.
Do not put any living animal in the refrigerator.
12
13
Egg Tray
Temperature Sensor
Rotating plate
Air vent
Pure N Fresh
Door rack
Door rack
Small Drawer in
Freezer Compartment
General shelf
Vegetabel drawer
Multi-use
Compartment
ice maker
Ice box
Freezer Compartment
(Top)
Freezer Compartment
(Bottom)
Leveling screw
Type-1
Air vent
Door Rack
Door Rack
14
Temperature Sensor
Vegetable Drawer
Multi-use
Compartment
Small Drawer in
Freezer Compartment
ice maker
Ice box
Freezer Compartment
(Top)
Freezer Compartment
(Bottom)
Type-2
Type-2Type-1
Door Rack
Fresh room
Sliding Shelft
General shelf
Egg Tray
Turnable door rack
Rotating plate
Leveling screw
Button
Display panel
Air vent
Air vent
Pure N Fresh
Note
Parts, features, and options vary by model. Your model may not include
every option.
15
1. Select a good location.Place your fridge-freezer where
it is easy to use.
2. Avoid placing the unit near heat sources, direct sunlight
or moisture.
3. To ensure proper air circulation around the
fridge -freezer, please maintain sufficient space
on both the sides as well as top and maintain at
least 2 inches (5cm) from the rear wall.
4. To avoid vibration, the unit must be leveled. If
required, adjust the leveling screws to
compensate for the uneven floor. The front
should be slightly higher than the rear to aid in
door closing. Leveling screws can be turned
easily by tipping the cabinet slightly.Turn the
leveling screws counterclockwise ( ) to lower
the unit, clockwise( ) to raise it.
5. In case the doors incline downwards after the
refrigerator is installed and foods are placed,
adjust the parallelism of the doors as illustrated
4 – 5 days after the installation. Before
adjusting the adjustable feet, open the bottom
freezer compartment drawer.
6. Clean your fridge-freezer thoroughly and wipe
off all dust accumulated during shipping.
7. Install accessories such as ice box, etc., in
This appliance is intended to be used in household and similar applications such
as staff kitchen areas in shops, offices and other working environments; farm
houses and by clients in hotels, motels and other residential type environments;
bed and breakfast type environments; catering and similar non-retail applications.
their proper places. They are packed together
to prevent possible damage during shipment.
Raise
Lower
16
Lock Unlock
Press for 3 seconds
Air Purification
Function display board
Temperature
adjustment button
for Refrigerator
compartment
Temperature
Adjustment button
for Multi-use
compartment
Temperature
Adjustment button
for freezer
compartment
17
You can adjust temperature of the freezer compartment,
refrigerator compartment and multi-use compartment.
When you press” “ button, the temperature of
refrigerator compartment is repeated in the following
order:
When you press” “ button, the temperature of
multi-use compartment is repeated in the following order:
4°C → 3°C → 2°C → OFF → 8°C → 7°C → 6°C → 5°C
→ 4°C
0°C → -1°C → -2°C → -3°C → -7°C → -12°C → -15°C →
-17°C → OFF → 7°C → 6°C → 5°C → 4°C → 3°C →
2°C → 1°C → 0°C
Multi-use compartment temperature adjustment
Refrigerator compartment temperature adjustment
Freezer compartment temperature adjustment
How to adjust the
temperature in
the refrigerator
compartment
How to adjust the
temperature in
the multi-use
compartment
How to adjust the
temperature in
the freezer
compartment
When you press” “ button, the temperature of
freezer compartment is repeated in the following order:
Fridge
Fridge
Fridge
Freezer
Fridge
Freezer
Freezer
Freezer
Note
The actual inner temperature varies depending on the food status, as the
indicated setting temperature is a target temperature, not actual
temperature within refrigerator.
Refrigeration function is weak in the initial time. Please adjust temperature
as above after using refrigerator for minimum 2~3 days.
-19°C → -20°C → -21°C → -22°C → -23°C → -24°C
→ -26°C(SUPER) → -16°C → -17°C → -18°C→ -19°C
18
Refrigerator
“ECO”
Super Freezer
In order to save electricity when no food needs to be stored in the refrigerator
compartment, you can select the Refrigerator ECO function, that is, to turn off
the refrigerator compartment.
To put the multi-use compartment in the stop state, press “ ” repeatedly
until “ECO” lights up.
Set super freezing: press “ ” key. The panel will display “-26℃” and
“Super” indicating it is in the super freezing state.
Cancel super freezing: press “ ” key. The panel displays a temperature
other than “-26℃” indicating it is not in the super freezing state any more.
When the super freezing time is reached, it exits the super freezing state
automatically and restores the set freezing temperature of “-21℃”.
Please select this function for prompt freezer.
Fridge
Freezer
Freezer
Freezer
Fridge
ECO
ECO
Super
To put the refrigerator in the stop state, press “ ” repeatedly until “ECO”
lights up.
Multi-use
“ECO”
In order to save electricity when no food needs to be stored in the multi-use
compartment you can select the multi-use compartment ECO function, that is,
to turn off the multi-use compartment.
Fridge
Freezer
Fridge
Freezer
•
When the refrigerator compartment door, multi-use compartment drawer or
freezer upper drawer is left open or not closed completely for more than 1
minute, it sounds 3 times every 30 seconds.
•
If the warning sound remains after the refrigerator door, multi-use compartment
drawer or freezer upper drawer is closed, contact your local service center.
Lock
• Pressing this button stops operation of other buttons.
• Locking or Unlocking is repeated whenever pressing the “ ” button.
(For “Locking” or “UnLocking” press the “ ” button for 3 secs.)
• When you use the “ ” button, you can not use any other button, Until
you unlock the refrigerator. When you press the other buttons when the
refrigerator is locked, the “ ” will flash 2 times to notify the current
lock condition.
LOCK UNLOCK
Power ReplaceAuto OFF
When you need to clean the air please select this function.
Pure N Fresh
Lock
Hold 3sec
(Optional)
Press “Pure N Fresh” key. “ ” pattern and “Power” light will be on.
It enters power mode.
Cancel: Press “Pure N Fresh” key. “Power” light will be off.
It exits power mode.
Note: In power mode, it exits power mode and returns to Automatic
mode when time of power air purification elapses
(Maximum 4 hours).
※ Press “ Pure N Fresh” key to adjust air purification.
※
After normal usage for a year, the "REPLACE HOLD 3SECS"
displays indicating Pure N Fresh need to be replaced.
Customers can replace it based on personal needs.
After replacing Pure N Fresh or when replacement is not
needed, press and hold the “PUSE N FRESH” button for more
than 3 secs, the timer of the indicator starts again and the
reminder is off.
Displayed content about air purification varies as follow
s:
OFF —> Automatic Mode —> Power mode —> OFF
※ Potent air purification Setting:
Lock
Hold 3sec
Lock
Hold 3sec
Lock
Hold 3sec
Lock
Hold 3sec
19
20
Ice making
1. Add water into ice cube tray.
If too much water is added, it cannot be easily
separated into ice cubes. And water will drop
into ice storage tray and already made ice cubes
will freeze together.
Note
Rotating the Ice Dispenser knob before the icing procedure is complete
would add the remaining water into the ice cube container. The ice cubes
may stick together.
Please fill with potable water only.
Memory feature
When the power comes on again after a power failure, it is able to recall the
last settings of refrigerator temperature, Refrigerator ECO, freezing temperature,
multi-use compartment ECO and multi-use compartment temperature.
However, the Super Freezing can not be memorized. If the unit is in the Super
Freezing state when the power is off, the freezing temperature will be set to
“-21°C” after the power is recovered.
Self-diagnosis function operates when a problem occurs in the unit. When an
error occurs in the unit. Immediately contact the service center without turning
the power OFF. If the power is OFF, it will take the engineer longer to find out
where the fault occurs.
The pressing of any function buttons will not alter the temperature setting
when a fault occurs.
2. Rotate ice cube separation button of ice cube
tray and ice cubes will drop into the ice storage
tray.
CAUTION
21
Refrigerator compartment
Sliding Shelf
(Optional)
Note
Remove all items form the rear half shelf and the front sliding shelf.
Caution should be taken when adjusting the shelf as it can fall out if
not handled correctly.
Do not lift up the rear half shelf and keep it in the lifted position.
Tall items are not to be stored at the rear of the shelf.
CAUTION
CAUTION
22
Door in Door Use Skills (Only apply for some Models)
Refrigerator compartment
Rotatable partition
The door can not be closed
when the rotating plate is in
this position.
The door can be closed when
the rotating plate is in this
position.
The door can not be closed when the rotating plate is in the raised position.
It must be put back to its original position to close the door.
Note
To prevent dew drops form, choose rotating plates equipped with heater.
It is normal for rotating plate to generate heat and this does not have
effect on the foods.
Use of Small Rack in Door within Door
Various bagged foods can be put in, such
as ham, chocolate and other small volume
packages for the convenience of reach.
Use of Small Drawer in Door within Door
Various bagged foods can be put in, such
as ham, chocolate and other small volume
packages for the convenience of reach.
2
1.
2.
1
1
1
23
Use Skills for Multi-use Compartment
Use Skills for Freezer Compartment (lower)
When store vegetables and fruits, set the multi-use compartment temperature
to 1-7°C; When store fish and meat for a short time, set the temperature to
below 0℃. Therefore, always check the temperature setting before store food.
· Transparent shallow drawer is used to store pouch packed foods and big
drawer is used to store large packed foods.
Height of food stored should not exceed certain height. Otherwise,
the transparent shallow drawer cannot be put in place. It can cause the
drawer fails to be closed normally and foods cannot be frozen.
Transparent Shallow Drawer
of Freezer Compartment (lower)
Big Drawer of Freezer
Compartment (lower)
24
Location on foods
Door rack
1
Bottle door rack
2
General self
3
Vegetable drawer
5
Egg tray (Optional)
6
Turnable Rack (Optional)
8
Fresh room (Optional)
7
Removable Shelf (optional)
4
Suggestions
on refrigerator
storage
Store small packages
of milk or spices.
Store water and
beverage.
Store refrigerated food
(The foods should be
kept a certain distance
between each other
and the air outlet should
never be blocked by the foods.)
요
구
르
트
균
Store fruits and
Store common food, like drinks,
wine and so on.
vegetables.
TYPE-2TYPE-1
Refrigerator
Compartment
Multi-use
Compartment
Freezer
Compartment
For instructions on
Store eggs.
(Take the egg tray out of the multi-use
compartment when storing eggs.
Store it in refrigerator compartment
instead of the multi-use compartment.)
how to use, refer to
the tips. (See page 21.)
(The foods should be kept a certain
distance between each other and
the air outlet should never be
blocked by the foods.)
Store milk or condiment of small
packages.
It can prevent dust from entering
the rack.
Suggestion on food storage
25
Drawer (bottom)
13
Suggestions
on freezer
compartment
Drawer (top)
12
Store frozen food for a
long time.
Ice maker
10
For instructions on
how to make ice,
refer to the user
guide.
Small drawer
11
Store frozen foods of
small size.
Store frozen foods
of large size.
Drawer
9
Suggestions
on multi-use
compartment
Store refrigerated or frozen foods.
※ If food is too bulky, remove shelf, vegetable drawer and drawers, etc.
Suggestion on food storage
26
Note
Suggestion on food storage
•
Install the fridge in a shady,cool and well-ventilated place.
• Do not open and close the door frequently if not necessary.
• Please do not keep the door open for a long time, close door in the shortest time.
• Allow hot food to cool prior to storing.
• Too much food are not advised to be put in.
Enough space should be kept for cool air circulating freely.
• Do not set the temperature of refrigerator lower than needed.
Do not put the food near the temperature sensor.
• Food need’t store is not advised to be put in.
• Place the deep-frozen food for thawing intorefrigerator;
they can be used for cooling the refrigerator.(Applicabe to some models only)
• Clean up the back cover and anti-condensation pipe termly (once a year) to
make sure heat exchange in gear.(Applicabe to some models only)
• Do not block air vents with food.( Applicabe to some models only)
Energy-Saving Method
27
General shelf
Removal and Cleaning
of Fresh room in Door
within Door
Removable Shelf
(only apply to some types)
(only apply to some types)
Door rack
Tightly hold side of fresh room with one hand and
gently tap upward with another hand from bottom.
Lift up and take out the fresh room;
Then take out the door rack and wash it with water.
Wipe it dry with soft cloth;
Install the rack in the reverse order.
1. First press switch button of door to open the fresh room.
2. Raise and take out small drawer above the fresh room.
3. Tightly hold side of fresh room with one hand and gently tap upward with
another hand from bottom. Lift up and take out the fresh room.
4. Wash the drawer and the fresh room with water.
Then dry it with soft cloth; Install the fresh room in the reverse order.
• Lift the inside of the shelf and pull it out to
•
•
•
remove the shelf;
Slightly raise the front half of the removable
shelf and slide inward. Raise the back half of
the shelf and make the front half slide in below it.
Or manually raise the back half towards the back
wall to make the front half easily slide.
Wash the removed shelf with water.
Then wipe clean with dry soft cloth;
The removable shelf can be easily pulled out
and returned to its original position by taking
contrary steps.
• Install the shelf in the reverse order.
Note
Be cautious when adjusting the shelf.
If it is handled improperly, it may fall.
(1)
(2)
(3)
28
The drawer of
multi-use
compartment
The drawer(top)
of freezer
compartment
1. For some models, small drawer should be taken out beforehand.
2. Pull the drawer all the way out, lift the outside of the whole set of the
drawers and pull out slightly, then lift the white plastic drawer and take it
out.
3. Install the white plastic drawer in reverse order, then install the small
drawer. Pay attention to the direction when installing the small drawer.
SMALL DRAWER
• Pull the drawer all the way out, then lift the
white plastic drawer to take it out.
• Install the white plastic drawer in the reverse
order.
Note
• If the whole set of the drawers has been removed, please refer to the
install method of freezer lower drawer.
• The small drawer is applicable to some models only. Pay attention to the
direction when installing the small drawer. It can not be closed if
installed in reverse direction.
Vegetable drawer
Pull out the vegetable drawer till it cannot move.
Raise outer side of the vegetable drawer and pull
out the vegetable drawer;
Wash the vegetable drawer with water and dry it
with soft cloth;
Install the vegetable drawer in the reverse order.
1. Pull out the ice maker,ice bin and small drawer
beside them.
2. Wash the ice maker, ice bin and small drawer
with water, wipe them with a clean soft cloth.
3. Reassemble in the reverse direction.
Dismantle and Cleaning
of Ice Maker, Ice Bin
and Small Drawer
Care and maintenance
29
Note
The transparent shallow drawer is applicable to some models only. Pay
attention to the direction when installing the transparent shallow drawer.
It can not be closed if installed in the reverse direction.
4. Install the whole set of drawer, keeping the rollers of the drawer
underneath the rollers of the compartment;
5. Install the transparent shallow drawer.
The drawer
(bottom)
of freezer
compartment
1. Pull the drawer of the freezer (lower) all the way out;
2. Remove the transparent shallow drawer.
3. Lift the whole set of drawer and pull out to remove it;
Cleaning of Door
and Drawer Gaskets
Dirty door seals will get aged and damaged easily
and that will cause cold air leakages, so the gaskets
of door and drawer should always be clean
If LED lamp is damaged,it should be replaced by the service center in
stead of on your own.
•
Lamp Replacement
30
Be sure to unplug the power.
For products with a stainless steel exterior, use a clean sponge or soft cloth
and a mild Detergent in warm water.
Do not use abrasive or harsh cleaners.
Dry thoroughly with a Soft cloth.
Do not use appliance wax, bleach, or other products containing chlorine on
stainless steel.
Always remove power cord from the wall outlet prior to cleaning in the
vicinity of electrical parts (lamps, switches, controls, etc.).
Wipe up excess moisture with a sponge or cloth to prevent water or liquid
from getting into any electrical part and causing an electric shock.
Never use metallic scouring pads, brushes, coarse abrasive cleaners, strong
alkaline solutions, flammable or toxic cleaning liquids on any surface.
Do not touch frozen surfaces with wet or damp hands, because damp object
will stickor adhere to extremely cold surfaces.
Care and maintenance
31
When the ice
maker is not to
be used for
a long time
• Discard the water in the water tank;
• Remove the ice cubes and water in the ice bin;
In case the lamp is damaged, contact service center to replace it. Never
replace it by yourself.
Disposal of your old appliance
1. All electrical and electronic products should be disposed of separately from
the municipal waste stream via designated collection facilities appointed by
the government or the local authorities.
2. The correct disposal of your old appliance will help prevent potential negative
consequences for the environment and human health.
3. For more detailed information about disposal of your old appliance, please
contact your city office, waste disposal service or the shop where you
purchased the product.
32
Trouble shooting
Wait for a while until the refrigerator
compartment, multi-use compartment
and freezer compartment reach the
set temperature.
Gaps may be formed on the
refrigerator compartment door,
multi-use compartment drawer or
freezer compartment drawer
The gaskets of the refrigerator
compartment door, multi-use
compartment drawer or freezer
compartment drawer is dirty, worn or
deformed.
Refrigerator
does not run
Care and maintenance
33
Trouble shooting
The freezer compartment
is too cold but the
temperatures in other
compartments are normal
The refrigerator compartment
is too cold but the
temperatures in other
compartments are normal
The multi-use compartment is
too cold but the temperatures
in other compartments are
normal
Multi-use compartment temperature
is set too cold.
Refigerator temperature is set too
cold.
Freezer temperature is set too
cold.
Set the multi-use control to
a warmer setting.
The refrigerator compartment is
too warm but the temperatures
in other compartments are normal
The multi-use compartment is too
warm but the temperatures in
other compartments are normal
The refrigerator compartment is set to
a high temperature or in refrigerator
compartment ECO state.
The multi-use compartment is set to
a high temperature or in multi-use
compartment ECO state.
The temperature in
refrigerator
compartment, multi-use
compartment or freezer
compartment is too high
Multi-use compartment temperature
is set too warm.
Set the multi-use compartment temperature
to a colder setting until the multi-use
compartment temperature is satisfactory.
Set the refrigerator temperature to
a colder setting until the refrigerator
temperature is satisfactory.
Set the freezer temperature to
a colder setting until the freezer
temperature is satisfactory.
Freezer temperature is set too
warm.
Set the multi-use control to a colder
setting.
34
Trouble shooting
35
Trouble shooting
The ice cubes have an odor.
• Check if the ice cubes are tainted by
foods with strong odor in the
compartment.
• The interiors of ice bin and the unit
need cleaning.
Ice maker problems
Close the door or drawer gently.
Remove the food that blocks the drawer
or reduce the amount of food in the
drawer.
The door or drawer is closed with so
much force that other drawers and
door are opened.
The drawer is stuck by packing bag or
the food in the drawer is too heavy.
The door or drawer
is not closed tightly
The drawer is hard
to pull out or can
not be closed tightly
Smart Diagnosis
36
Smart Diagnosis
(Only apply for some Models)
Should you experience any problems with your refrigerator, it has the capability of
transmitting data via your telephone to the LG service center. This gives you the
capability of speaking directly to our trained specialists. The specialist records the data
transmitted from your machine and uses it to analyze the issue, providing a fast and
effective diagnosis.
If you experience problems with your refrigerator, call to the LG service center.
Only use the Smart Diagnosis feature when instructed to do so by the LG call center
agent. The transmission sounds that you will hear are normal and sound similar to a fax
machine.
Smart Diagnosis cannot be activated unless your refrigerator is connected to power.
If your refrigerator is unable to turn on, then troubleshooting must be done without
using Smart Diagnosis.
First, call to the LG service center. Only use the Smart Diagnosis feature when
instructed to do so by the LG call center agent.
nottub kcoL eht dloh dna sserp ,yalpsid eht kcol oT .yalpsid eht kcoL .1
for three seconds. (If the display has been locked for over five minutes,
you must deactivate the lock and then reactivate it.)
2. Open the right refrigerator door.
3. Hold the mouthpiece of your phone in front of the speaker
that is located on the right hinge of the refrigerator door,
when instructed to do so by the call center.
sdnoces eerht rof nottub erutarepmeT rezeerF eht dloh dna sserP .4
while continuing to hold your phone to the speaker.
.nottub erutarepmeT rezeerF eht esaeler ,speeb eerht raeh uoy retfA .5
tuoba sekat sihT .dehsinif sah noissimsnart enot eht litnu ecalp ni enohp eht peeK .6
3 seconds, and the display will count down the time. Once the countdown is over
and the tones have stopped, resume your conversation with the specialist, who will
then be able to assist you in using the information transmitted for analysis.
Using Smart
Diagnosis
•
For best results, do not move the phone while the tones are being transmitted.
•
If the call center agent is not able to get an accurate recording of the data, you may
be asked to try again.
•
Call quality differences by region may affect the function.
•
Use the home telephone for better communication performance, resulting in better
service.
•
Bad call quality may result in poor data transmission from your phone to the
machine, which could cause Smart Diagnosis to not work properly.
NOTE
