COLDEST
COLD
OFF
3
1
2
4
6
5
3.2 Cu.Ft.
REFRIGERATOR
INSTRUCTION MANUAL
210 mm x 140 mm
To ensure proper use of this appliance and your safety, please read the
following instructions completely before operating this appliance.
TABLE OF CONTENTS
Before Putting Into Use
Tips For Energy Saving
Important Safety Instructions
Name Of The Parts
Specifications
How To Operate:
Starting Your New Refrigerator
Temperature Control
How To Clean
How To Install
Door Reversal Instructions
Care And Maintenance
Troubleshooting Guide
What To Do
Refrigerator Warranty
1
1
1-2
3
3
4
4
5
5
6
6-7
7-8
9-10
BEFORE PUTTING INTO USE
NAME OF THE PARTS HOW TO OPERATE
Starting Your New Refrigerator
Temperature Control
NAME OF THE PARTS
Before connecting the appliance to the power supply, let the unit stand upright for 4
hours, which will reduce the possibility of the cooling system malfunctioning due to
improper handling.
Clean your unit thoroughly before pufting into use. (See "How to Clean")
Use the parts diagram on page 4 to insure proper positioning of internal components.
Install refrigerator in a convenient
location away from extreme heat and
cold. Allow sufficient clearance betweer
the refrigerator and sidewall so the doo
will open without obstruction.
Refrigerator is designed for recessed
installation.
Select a space with strong enough and
level floor to support it fully loaded Not
recommended for carpeting or other
soft/uneven surfaces.
Better to allow 2 inches of space
between the refrigerator's side and the
wall to keep the unit' good refrigeration
performance. In addition, sufficient
clearance (160°) should be maintained
to allow the door to open properly and
completely.
HOW TO CLEAN
HOW TO INSTALL
Cleaners: Never use harsh. abrasive cleaners, heavy-duty cleaners, or solvents on any
surface .
Exterior: Wipe with damp, sudsy cloth, rinse and dry. For stubborn stains and for
periodic waxing, use silicon wax.
Refrigeration Section: Wash shelves and other removable parts in warm sudsy water,
rinse and dry. Wash interior with baking soda solution (3 tablespoons to I liter
of water) or wam sudsy water, rinse and dry.
Magnetic Door Seals: Wash with warm sudsy water.
The Finishing Touch: Replace all parts and retum thermostat dial to desired setting.
CARE AND MAINTENANCE
Refrigerator Warranty
Correct Disposal of this product
TROUBLESHOOTING GUIDE
WHAT TO DO...
When the fridge is not in use for a prolonged period:
The refrigerator should be cleaned on a regular basis.
Top performance is achieved with proper or adequate air circulation around the
refrigerator.This allows for dissipation of heat and maintains efficiency, lower power
consumption and enhanced performance.
Door Reversal Instructions
Your refrigerator is built with a reversible door. You have the choice of either opening it
from left or the right sides. In order to reverse the opening direction of your door, please
follow these simple instructions.
TIPS FOR ENERGY SAVINGS
Keep the refrigerator closed as much as possible, particularly in warm / humid
conditions.
Maintain adequate ventilation around the back and sides of the unit.
Maintain a thermostat setting of COLD position under normal use.
Allow warm food to cool to room temperature before placing in the refrigerator.
IMPORTANT SAFETY INSTRUCTIONS
The appliance must be correctly connected to the power supply. (See: HOW TO
INSTALL").
Do not use an extension cord as this can negatively affect the performance of the unit.
When transporting the refrigerator, keep the unit in the upright position. Do not tilt the
appliance beyond 45° or place the unit in upside down position.
Do not touch the cooled surfaces while the appliance operates especially not with wet
hands, because the skin may stick to the cold surfaces.
1. Clean the refrigerator thoroughly. Wipe the outside with a soft dry cloth, the interior
with a clean moist cloth.
2. Insert the power supply cord into the socket.
3. Turn the thermostat dial to COLDEST position. Close the door and let the refrigerator
operate for 30 minutes.
4. Reduce the thermostat to a mid-range setting COLD position on the thermostat control
COLD position is the typical setting.
*Note:
Turning the temperature control to OFF
position stops the cooling cycle, but it does
not shut off the power supply to the
refrigerator.
To control the internal temperature, adjust the thermostat dial. After
changing your setting, allow 24 hours for the refrigerator to reach
the temperature you have set.To turn the refrigerator off, turn the
temperature control knob to OFF position.
It is recommended that the refrierator is positioned away from any combustible sources
such as gas, petrol, alcohol, lacquer and banana oil, etc. The aforementioned objects
should not be stored in the refigerator under any circumstances.
Do not freeze bottled liquids such as carbonated soft drink, beer, wine, etc. Doing so can
cause glass bottles and aluminum cans to rupture.
If the unit fails to cool properly, dispose of spoiled food as needed.
All repairs should be made by a qualified service technician. Repairs made by
non-qualified personnel will void the warranty.
Do not defrost the appliance with other electric devices (hair drver etc.) and never scrape
the ice or frost layer with sharp tools.
Never unplug your refrigerator by pulling on the power cord. Always grip plug firmly and
pull straight out from the outlet.
The rating plate is inside the appliance or outside on the rear wall
This appliance is not intended for use by persons (including children) with reduced
physical.sensory or mental capabilities, or lack of experience and knowledae, unless
they have been given supervision or instruction concerming use of the appliance by a
person responsible for their safety. Children should be supervised to ensure that they do
not play with the appliance.
Do not run cord over carpeting or other heat insulators. Do not cover the cord. Keep cord
away from traffic areas. and do not submerge in water. If the supply cord is damaged, it
must be replaced by the manufacturer or its service agent or a similarly qualifed person
in order to avoid ahazard.
DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer:
Take off the doors.
Leave the shelves in place so that children may not easily climb inside.
(1) Removable Food Shelf
(2) Drip Tray (at the rear, above the compressor)
(3) Temperature Dial
(4) Dairy Rack
(5) Can Rack
(6) Bottle Rack
Product Description
Model No.
Electrical Rating
Refrigerant
Net Weight (Lbs)
Compact Refrigerator
BC-90C-E
115V-/60Hz/0.8A
R600a,0.85Oz/24g
48 lbs.
The refrigerator is not designed to be installed in an outside area such
as a garage or a porch. Ambient temperatures of below 50° or above 90°
will hinder the performance of the appliance.
Note: Wait 3-5 minutes before restarting if you unplug the refrigerator. The
unit may fail to operate properly if restarted too quickly.
The refrigerator is not designed to be installed in an outside area such
as a garage or a porch. Ambient temperatures of below 50° or above 90
will hinder the performance of the appliance.
POWER CORD REPLACEMENT
If the refrigerator's power cord is damaged, have it replaced by a qualified repair agent
Before calling service, please follow the checklist below.
This may save you an expensive service call.
The appliance must be correctly
connected to the power supply
Do not use an extension cord.
Leveling Legs:
Tum counterclockwise to raise,
clockwise to lower
Adjustble legs at the front corners of the refrigerator
should be set so the refrigerator is firmly positioned on
the floor and the front is raised just enough that the door
closes easily when opened about halfiway.
To adjusthe leveling legs, tum the legs counteclockwise
to raise the refrigerator, clockwise to lower it.
To attain proper performance, be sure to plug the appliance into a properly
grounded115/60 Hz outlet.
Do not modify the power cord under any circumstance to allow the unit to be plugged
into a non-grounded outlet. To avoid heat damage to the power cord, please ensure
that it does not come in proximity or in direct contact with the compressor of the
refrigerator.
Please avoid installing the refrigerator in a location where the appliance will come in
contact with water or moisture to minimize rusting of metal parts.
The refrigerator should not be installed near any heat source or in a location where it
will come in direct contact with the sunlight.
Remove the plug from the outlet.
Remove all contents from the fridge.
Dry the interior and leave the door open for a few days.
When the refrigerator does not work:
Check if there is a power failure.
Check if the power plug is plugged into the power outlet.
Check that the fuse has not blown in main supply circuit.
If the refrigerator seems too warm inside:
Check to see that the door is closing properly and the door seal is not damaged.
Check that the interior circulation is not obstructed by having too many goods stored.
(The fridge is overloaded)
Did you store anything hot, without first cooling it to room temperature?
Is there sufficient clearance around all sides and above the fridge?
When the refrigerator is cooling excessively:
The temperature control dial may be set too high.
If you place food sorts which contain a lot of moisture directly under the cool outlets,
they will freeze easily. This does not indicate a unit malfunction.
When the defrosting water overflows inside the refrigerator and onto the floor:
Check that the drain pipe and the drain hose are not clogged.
Check that the drain pan is housed properly.
When the refrigerator's cabinet front heats up:
In order to avoid condensation, there is an anti-condensation pipe which heats up the
cabinet front when running. A warm cabinet front does not indicate a unit malfuntion.
Condensation may form on the outside when the humidity level is high such as during
a wet season. This is the same result as the condensation formed when chilled water
is poured into aglass. It does not, therefore, indicate a failure, wipe dry with a dry
cloth.
WARNING:
- WARNING: Keep ventilation openings, in the appliance enclosure or in the built-n
structure, clear of obstruction.
- WARNING: Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
- WARNING: Do not damage the refrigerant circuit.
- WARNING: Do not use electrical appliances inside the food storage compartments of
the appliance, unless they are of the type recommended by the manufacturer.
- WARNING: To avoid a hazard due to instability of the appliance ,it must be fixed in
accordance with the instructions.
- WARNING: The instructions for heaters with heating elements that are in direct
contact with accessible glass panels shall state that the heater must not be used if the
glass is damaged.
- WARNING: This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerming use of
the appliance by a person responsible for their safety.
- WARNING: Children should be supervised to ensure that they do not play with the
appliance.
- WARNING: If the supply cord is damaged, it must be replaced by a special cord or
assembly available from the manufacturer or is service agent.
- WARNING: If the supply cord is damaged, it must be replaced by the manufacturer,
is service agent or similarly qualified persons in order to avoid a hazard.
CAUTION -Risk of Fire or Explosion
Dispose of property in accordance with Federal or Local.
Regulations. Flammable refrigerant used.
DANGER
Risk of child entrapment. Before you throw away your old refrigerator or freezer, take
off the doors. Leave the shelves in place so that children may not easily climb inside.
Note: If the refrigerator has been placed in a horizontal or tilted position for any
period of time wait 24 hours before plugging the unit in.
CAUTION
Risk of Fire or Explosjon due to puncture refrigerant tubing.
Flammable refrigerant used. Handle with care when moving
refrigerator to avoid either damagingthe refrigerant tubing or
increasing the risk of a leak.
When condensation forms on the outside of the refrigerator:
Is it wobbling? Re-level it and check if it now operates normally
Have any objects fallen behind the fridge? If so, remove them and check if operation
is now normal
Are any containers inside the fridge vibrating or resonating? If so, rearrange them then
check to see if operation has returned to normal
If the fridge starts making any unusual noises:
When you wish to move the fridge:
Secure all movable parts and contents. (Package them separately if necessary.)
Transport the fridge only in an upright position. In any other position you may
damage the compressor.
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm to
the environmen or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
Model： BC-90C-E
E-Mail: ANEKEN8888@163.com
Address: NO.102, Building P09, China South City,
Pinghu Town, Longgang District, Shenzhen City,
P.R China
Made in China
.
.
1 2
76543
8 9 10
