TECHNICAL DATA ATO-65
ENGINE ENAMEL
Form: GDH-118
Rev.: 052517
1
.DESCRIPTION AND USES .
Rust-Oleum
®
Engine Enamel is formulated to create a smooth
finish on automotive engines and other automotive surfaces
which reach intermittent temperatures up to 500°F (260°C).
Engine Enamel features an advanced spray system that allows
you to spray at any angle, even upside down for those hard to
reach areas. A comfort spray tip with a wider finger pad reduces
fatigue caused by continuous spraying.
.PRODUCTS .
SKU Description
248932 Gloss Black (12 oz.)
248936 Semi-Gloss Black (12 oz.)
248938 Low Gloss Black (12 oz.)
248941 Chevy Orange (12 oz.)
248944 Clear (11 oz.)
248945 Ford Blue (12 oz.)
248946 Old Ford Blue (12 oz.)
248947 Chevy Red-Orange (12 oz.)
248948 Ford Red (12 oz.)
248949 Aluminum (11 oz.)
248951 Grabber Green (12 oz.)
248953 Cast Coat Aluminum (11 oz.)
248954 Universal White (12 oz.)
248955 Cast Coat Iron (11 oz.)
248956 Chrysler Industrial Red (12 oz.)
248957 Chrysler Hemi Orange (12 oz.)
248958 Ford Gray (12 oz.)
248959 Ford Dark Blue (12 oz.)
248960 Daytona Yellow (12 oz.)
248961 GM Blue (12 oz.)
248962 Universal Red (12 oz.)
..PRODUCT APPLICATION .
PAINTING CONDITIONS
Use outdoors or in a well ventilated area such as an open
garage. Use when temperature is between 50-90°F (10-
32°C) and humidity is below 85% to ensure proper drying.
Do not apply to galvanized metal. Avoid spraying in very
windy and dusty conditions. Cover surrounding area to
protect from spray mist.
..PRODUCT APPLICATION (cont.) .
SURFACE PREPARATION
Wash the surface with a commercial detergent, or other
suitable cleaning method. Rinse with fresh water and dry
with a clean cloth. Remove loose paint and rust with a wire
brush or sandpaper. Lightly sand smooth and glossy
surfaces.
WARNING: If you scrape, sand, or remove old paint, you may
release lead dust. LEAD IS TOXIC. EXPOSURE TO LEAD
DUST CAN CAUSE SERIOUS ILLNESS, SUCH AS BRAIN
DAMAGE, ESPECIALLY IN CHILDREN. PREGNANT WOMEN
SHOULD ALSO AVOID EXPOSURE. Wear a NIOSH-approved
respirator to control lead exposure. Clean up carefully with a
HEPA vacuum and a wet mop. Before you start, find out how to
protect yourself and your family by contacting the National Lead
Information Hotline at 1-800-424-LEAD or log on to
www.eps.gov/lead.
APPLICATION
Shake can vigorously for one minute after the mixing ball
begins to rattle. If mixing ball fails to rattle DO NOT
STRIKE CAN. Contact Rust-Oleum. Shake often during
use. Hold can 10-16" from surface and spray in a steady
back-and-forth motion, slightly overlapping each stroke.
Keep the can the same distance from the surface and in
motion while spraying. Apply 2 or more light coats a few
minutes apart. Do not use near open flame.
DRY & RECOAT
Dry and recoat times are based on 70°F (21°C) and 50%
relative humidity. Allow more time at cooler temperatures.
Dries to the touch in 20 minutes and dries to handle in 1
hour. Apply a second coat or Clear Coat within 1 hour or
after 24 hours. Wait 7 days for the paint to fully cure.
CLEAN-UP
Wipe off tip when finished. Clean up wet paint with xylene
or mineral spirits. Properly discard empty container. Do
not burn or place in home trash compactor.
CLOGGING
If the valve clogs, twist and pull off spray tip and rinse in a
solvent such as mineral spirits. Do not insert any object
into can valve opening.
