Owner’s manual Slide-In Electric Range GE JCS630SFSS

Contents

  • Safety Instructions Owner’s Manual
  • Operating Instructions
  • Kitchen Timer
  • Oven
  • Adjust Oven Thermostat
  • Baking or Roasting
  • Broiling, Broiling Guide
  • Controls
  • Convection Oven
  • Lower Oven Drawer
  • Preheating
  • Probe
  • Sabbath Feature
  • Self-Cleaning
  • Special Features
  • Timed Baking and Roasting

GENERAL SAFETY INSTRUCTIONS

  • Be sure your appliance is properly installed and grounded by a qualified installer in accordance with the provided installation instructions.
  • Do not attempt to repair or replace any part of your range unless it is specifically recommended in this manual. All other servicing should be transferred to a qualified technician.
  • Before performing any service, unplug the range or disconnect the power supply at the household distribution panel by removing the fuse or switching off the circuit breaker.
  • Do not leave children alone3children should not be left alone or unattended in an area where an appliance is in use. They should never be allowed to climb, sit or stand on any part of the appliance.

Care and cleaning of the range.

Oven Light Replacement (on some models)

To remove:

  1. Turn the glass cover counterclockwise 1/4 turn until the tabs of the glass over clear the grooves of the socket. wearing latex gloves may offer a better grip.
  2. Using gloves or a dry cloth, remove the bulb by pulling it straight out.

To replace:

  1. Use a new 120/130-volt halogen bulb, not to exceed 50 watts. Replace the bulb with the same type of bulb that was removed. Your model will have one of the two types shown on the left. To determine the correct replacement bulb, check the bulb terminals. Bulbs with 2 straight pin terminals are G6.35 bulbs. Bulbs with 2 looped terminals are G9 bulbs. (Do not interchange.) Be sure the replacement bulbs is rated 120 volts or 130 volts (NOT 12 volts).
  2. Using gloves or a dry cloth, remove the bulb from its packaging. Do not touch the bulb with bare fingers. Oil from skin will damage the bulb and shorten its life.
  3. Push the bulbs straight into the receptacle all the way.
  4. Place the tabs of the glass cover into the grooves of the socket. Turn the glass cover clockwise 1/4 turn. For improved lighting inside the oven clean the glass cover frequently using a wet cloth. this should be done when the oven is completely cool.
  5. Reconnect electrical poweer to the range

Normal Daily Use Cleaning

  1. Before using the cooktop for the first time, clean it with CERAMA BRYTE® Ceramic Cooktop Cleaner. This helps protect the top and makes cleanup easier.
  2. Daily use of CERAMA BRYTE® Ceramic Cooktop Cleaner will help keep the cooktop looking new.
  3. Shake the cleaning cream well. Apply a few drops of CERAMA BRYTE® Ceramic Cooktop Cleaner directly to the cooktop.
  4. Use a paper towel or CERAMABRYTE® Cleaning Pad for Ceramic Cooktops to clean the entire cooktop surface.
  5. Use a dry cloth or paper towel to remove all cleaning residue. No need to rinse.

Troubleshooting

Food does not bake properly

  • See the Cooking Modes section.
  • See the Cooking Modes section and Cooking Guide.
  • See the Cookware section.
  • See the Adjust the oven thermostat-Do it yourself! section.

Food does not broil properly

  • Make sure you touch the BROIL HI/LO pad.
  • See the Broiling Guide.
  • For best results, use a pan designed for broiling.
  • Unplug and remove the probe from the oven.
  • Preheat the broil element for 10 minutes.
  • Broil for the longest period of time recommended in the Broiling Guide.

Oven temperature too hot or too cold

  • See the Adjust the oven thermostat-Do it yourself! section.

Oven and/or display appears not to work

  • Because the oven door is removable, it sometimes gets out of position during installation. To straighten the door, push down on the high corner
