NW-E55/E75
Operating Instructions
3-267-071-21(1)
© 2004 Sony Corporation
Portable IC Audio Player
Network Walkman
“WALKMAN” is a registered trademark of
Sony Corporation to represent Headphone
Stereo products.
is a trademark of Sony
Corporation.
2
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
Do not install the appliance in a confined
space, such as a bookcase or built-in cabinet.
To prevent fire, do not cover the ventilation of the
apparatus with news papers, table cloths, curtains,
etc. And don’t place lighted candles on the
apparatus.
To prevent fire or shock hazard, do not place
objects filled with liquids, such as vases, on the
apparatus.
Note on installation
If you use the unit at a place subject to static or electrical
noise, the track’s transferring information may be
corrupted. This would prevent successful transferring
authorization on your computer.
This manual explains how to operate your
Network Walkman. For details on how to use
the SonicStage (supplied software), refer to
the SonicStage operating instructions.
Notice for users
On the supplied software
• Copyright laws prohibit reproducing the software or the
manual accompanying it in whole or in part, or renting
the software without the permission of the copyright
holder.
• In no event will SONY be liable for any financial
damage, or loss of profits, including claims made by
third parties, arising out of the use of the software
supplied with this player.
• In the event a problem occurs with this software as a
result of defective manufacturing, SONY will replace
it.
However, SONY bears no other responsibility.
• The software provided with this player cannot be used
with equipment other than that which is so designated.
• Please note that, due to continued efforts to improve
quality, the software specifications may be changed
without notice.
• Operation of this player with software other than that
provided is not covered by the warranty.
Program ©2001, 2002, 2003, 2004 Sony Corporation
Documentation ©2004 Sony Corporation
OpenMG and its logo are trademarks of Sony
Corporation.
SonicStage and its logo are trademarks of Sony
Corporation.
ATRAC, ATRAC3, ATRAC3plus and their logos are
trademarks of Sony Corporation.
Microsoft, Windows and Windows Media are trademarks
or registered trademarks of Microsoft Corporation in the
United States and/or other countries.
US and foreign patents licensed from Dolby Laboratories.
All other trademarks and registered trademarks are
trademarks or registered trademarks of their respective
holders.
In this manual,
TM
and ® marks are not specified.
For the customers in the
Netherlands
Voor de Klanten in Nederland
Gooi de batterij niet weg maar lever
deze in als klein chemisch
afval(KCA).
3
Table of Contents
Overview ............................................ 4
What you can do with your
Network Walkman .................... 4
Other features ................................. 5
Step 1: Checking the package
contents ........................................ 6
Step 2: Inserting the battery................ 7
Locating controls ................................ 8
Front side ........................................ 8
Rear side ......................................... 8
Display............................................ 9
Basic Operations
Transferring audio files from the
computer to your Network
Walkman .................................... 10
Note on playing songs with a limited
playing period
(Timeout contents).................. 11
Note on playing songs with a limited
playing count .......................... 11
Listening to music with your Network
Walkman .................................... 12
What is the Group function?......... 13
On other operations ...................... 13
Advanced Operations
Repeat mode ..................................... 14
Selecting the repeat mode ............. 14
Playing the tracks repeatedly
(Track Repeat) ........................ 15
Playing a specified section
repeatedly (A-B Repeat)......... 15
Playing specified sentences
repeatedly
(Sentence Repeat)................... 16
Setting the repeat counts ............... 17
Changing the display mode .............. 17
Selecting the group display
mode ....................................... 18
Adjusting treble and bass
(Digital sound preset) ................ 19
Selecting the Sound quality .......... 19
Adjusting the sound quality .......... 19
Locking the controls (HOLD) .......... 20
Storing non-audio data ..................... 21
Adjusting the settings of your
Network Walkman
Adjusting the time setting of your
Network Walkman to a computer’s
built-in clock .............................. 22
Adjusting the current time setting
(DATE-TIME) ............................ 23
Limiting the volume (AVLS)............ 24
Setting the volume using the preset
volume function ......................... 24
Setting a volume level of the
preset mode ............................ 24
Switching to the manual mode ..... 25
Turning off the beep sound
(BEEP) ....................................... 26
Changing the backlight setting ......... 26
Other functions
Regrouping songs (REGROUP) ....... 27
Formatting memory (FORMAT) ...... 28
Other Information
Precautions ....................................... 29
Troubleshooting................................ 30
To reset the player......................... 30
What happened? ........................... 30
Messages....................................... 33
Specifications ................................... 34
Glossary ............................................ 35
Menu list........................................... 36
Index ....................................... 37
4
Overview
1 Store digital
audio files on
your computer.
2 Transfer files to
your Network
Walkman.
3 Enjoy music with
your Network
Walkman.
USB connection
MP3, WAV and
Windows
®
Media
Format Audio Files
Audio CDs
EMD (Electric Music
Distribution) Services
Download the
latest audio
files!
Store favorite
songs!
What you can do with your Network Walkman
First, you need to install the “SonicStage” software into your computer. You can easily transfer digital
audio files from your computer to the built-in flash memory and carry it anywhere to enjoy.
5
NOTES:
• The recorded music is limited to private use only. Use of the music beyond this limit requires permission of the
copyright holders.
• Sony is not responsible for incomplete recording/downloading or damaged data due to problems of the Network
Walkman or computer.
Other features
• Compact size, light weight, skip-proof operation, high portability.
• Continuous playback time with a battery
NW-E55/NW-E75: Approximately 70*
1
hours
• Recording time*
2
NW-E55: 128MB built-in flash memory, more than 5 hours 50 minutes.
NW-E75: 256MB built-in flash memory, more than 11 hours 40 minutes.
• The supplied SonicStage software enables you to record songs from audio CDs to the hard disk of your
computer using the ATRAC3plus format (high sound quality, high compression).
• Sentence Repeat: Useful function for learning a foreign language.
• High-speed data transfer using the dedicated USB cable.
• Backlight LCD screen: song titles and artist names can be displayed.
• Group function: you can select songs to be played by album.
• Storage function: you can store a variety of data as well as audio files.
*
1
Differs according to the data format. In this case, the figure for the battery duration is when continuously playing
ATRAC3 format audio files.
*
2
Differs according to the bit rate when recording. In this case, the figure for the recordable time is when recording at
48kbps ATRAC3plus format.
6
O
P
E
N
Serial NO.
Serial Number
G
r
o
u
p
M
o
d
e
Please check the accessories in the package.
NW-E55:
NW-E75 (Non-Canadian model):
• Network Walkman (1)
• Headphones (1)
NW-E75 (Canadian model):
• Network Walkman (1)
• Headphones (1)
• Dedicated USB cable (1)
Step 1: Checking the package contents
• Carrying pouch (1)*
• Neck strap (1)*
• Extension headphone cord (1)*
• CD-ROM (1)
• Operating instructions (1)
• SonicStage operating instructions (1)
* Only for non-Canadian model
About the Serial Number
The serial number provided for your device is
required for the customer registration. The number
is on the rear side of your Network Walkman.
G
r
o
u
p
M
o
d
e
Record the serial number in the space provided
below. Refer to it whenever you call upon your
Sony dealer regarding this product.
Serial No. _____________________
7
Step 2: Inserting the battery
Insert the LR03 (size AAA) alkaline battery with correct polarity. Be sure to insert it from the E side as
illustrated.
O
P
E
N
O
P
E
N
If the battery compartment lid is accidentally
detached, attach it as illustrated.
Battery duration
*
ATRAC3 format: Approximately 70 hours
ATRAC3plus format: Approximately 60 hours
* The battery life may be shorter due to operating
conditions and the temperature of the location.
On the remaining battery indication
The battery icon in the display changes as shown below.
If “LOW BATT” is displayed in the display, you need to
change the battery.
Notes
If you do not use the battery correctly, it may become
damaged from leakage and corrosion. For best results:
– Use the alkaline battery.
– Make sure the polarity is correct.
– Do not charge a dry cell battery.
– Remove the battery, if you do not intend to use the
player for an extended period of time.
– If you have battery leakage, replace with a new battery
after cleaning the battery compartment.
low battery change the
battery
8
Locating controls
For details about each part, refer to the pages in parentheses.
Rear sideFront side
7 Headphone jack (page 12)
8 Nx button
(page 12 to 20, 22 to 28)
9 Shuttle switch
(page 13 to 20, 22 to 28)
0 VOLUME +/– button (page 12, 24)
qa HOLD (Locking controls) switch
(page 12, 20)
qs USB jack (page 10)
qd Battery compartment (page 7)
G
r
o
u
p
M
o
d
e
1
2
3
4
5
6
7
8
9
0
qz
O
P
E
N
qs
qd
1 Strap hole for attaching the strap
2 REPEAT/SOUND button
(page 15 to 16, 19)
3 MENU button (page 14, 17 to 20, 22 to 28)
You can switch to the Time display by
pressing the MENU button for a while.
4 GROUP button (page 13, 18)
5 Display (page 9, 15, 33)
For details on the display and icons, refer to
page 9.
6 ACCESS lamp (page 10)
9
1
Text/graphic information display (page 14)
Displays track number, track name, current date
and time (page 17 to 23), MESSAGE (page 11,
33) and menu.
Press the MENU button to switch the display
mode. For details, refer to “Changing the
display mode” on page 17.
2 Repeat mode indication (page 14)
The current repeat mode is displayed.
3 AVLS indication (page 24)
The indication appears while the AVLS
function is activated.
4 Digital sound preset indication
(page 19 to 20)
The current sound setting is displayed.
5 Remaining battery indication (page 7)
The remaining battery power is displayed.
Display
10
Basic Operations
Transferring audio files from the computer
to your Network Walkman
1 Install the SonicStage software in your computer using the supplied CD-ROM.
Follow step 1 only for the first time when you connect your Network Walkman to the computer.
For details, refer to the SonicStage operating instructions.
2 Import audio files into the SonicStage software.
For details, refer to the manual “SonicStage operating instructions.”
3 Connect your Network Walkman to your computer.
Connect the small connector of the dedicated USB cable into the USB jack on the Network Walkman,
then the large connector to a USB port on your computer.
“CONNECT” appears in the display.
Notes
• The ACCESS lamp blinks while your Network Walkman accesses the computer.
• Do not disconnect the USB cable when the ACCESS lamp is blinking. The data being transferred may be destroyed.
• Use of your Network Walkman with a USB hub or a USB extension cable is not guaranteed. Always connect your
Network Walkman to the computer directly using the dedicated USB cable.
• Some USB devices connected to the computer may interfere with the proper operation of your Network Walkman.
• The control buttons on your Network Walkman are all disabled while it is connected to a computer.
• You can display the data stored in the built-in flash memory using Windows Explorer when your Network Walkman is
connected to the computer.
Note
Before connecting your Network Walkman to the computer for the first time, be sure to install the
“SonicStage” software from the supplied CD-ROM in your computer. Even if the SonicStage software
is already installed, you need to install the SonicStage software supplied with this Network Walkman
before connecting your Network Walkman to the computer (update programs may be available).
O
P
E
N
O
P
E
N
Dedicated USB cable (supplied)
to a USB portto the USB jack
ACCESS lamp
11
Basic Operations
4 Transfer audio files to your Network Walkman.
For information on transferring audio files to the built-in flash memory, refer to the separate manual
“SonicStage operating instructions.”
z Tip
For information on transferring audio files back to the computer, refer to the manual “SonicStage operating instructions”
or online Help for the SonicStage software.
Note on playing songs with a limited playing period
(Timeout contents)
Some songs distributed via the Internet (EMD service) have a limited playing period.
If you try to play an expired song, “EXPIRED” blinks and the next song will be played after a moment.
In addition, an expired song cannot be played using the SonicStage software, or transferred to your
Network Walkman. Delete any songs as needed.
Note on playing songs with a limited playing count
Your Network Walkman does not support contents with a limited playing count.
When you try to play a song with a limited playing count, “EXPIRED” will be displayed and the song will
not be played.
12
1 Connect the headphones.
2 Start playback.
Listening to music with your Network
Walkman
Please insert the battery before use (see page 7).
Note
When using Network Walkman, be sure do disconnect it from the computer.
G
r
o
u
p
M
o
d
e
1 Press the Nx button.
2 Press the
VOLUME
+/– button to adjust
the volume.
HOLD switch
G
o
u
p
M
o
d
e
to i jack
G
o
u
p
M
o
d
e
to i jack
Extension
headphone
cord
z Tip
If your Network Walkman is not operated for 10 seconds
while in stop mode, the display automatically turns off.
When scrolling track titles, etc., the display turns off after
scrolling is finished.
When the normal playback mode is selected,
playback stops automatically after the last song is
played.
If playback does not start
Make sure that the HOLD switch is set to off
(page 20).
To stop playback
Press the Nx button.
To adjust the volume
The volume can be set in the PRESET and MANUAL
mode (page 24 to 25).
To use the extension headphone cord
(supplied only for non-Canadian model)
The non-Canadian
model is illustrated.
The non-Canadian
model is illustrated.
13
Basic Operations
To
Skip to the beginning
of the next track/
group*
1
Skip to the beginning
of the current track/
group*
1
Fast-forward*
2
Fast-rewind*
2
*
1
Rotating and holding of the Shuttle switch during stop
mode allows you to skip to the beginning of the next
(current and previous) track/group continuously.
*
2
Fast-forward and fast-rewind speed become faster if
the operation is continued for five seconds.
What is the Group function?
The Group function enables you to select favorite music conveniently on your Network Walkman. You can
transfer to audio files or play songs by album or artist using the Group function.
Tra ck1
Group1
Tra ck2
Tra ck3
Tra ck1
Tra ck2
Tra ck3
Tra ck1
Tra ck2
Tra ck3
Group2
Group3
Tra ck1
Tra ck2
Tra ck3
Tra ck1
Tra ck1
Tra ck2
Tra ck3
Tra ck1
On other operations
z Tip
You can switch to the Group mode by pressing the Group
mode button.
Shuttle switch operation
Rotate the Shuttle switch
clockwise once (+/>).
Rotate the Shuttle switch
counterclockwise once
(./–).
Rotate the Shuttle switch
clockwise (
+/>
) and hold
it.
Rotate the Shuttle switch
counterclockwise (./–)
and hold it.
• The track number is the order of songs in each group.
• You can switch between Track Name mode and Group
mode by pressing the GROUP button.
• In the Group mode, group names are displayed instead
of track names. In addition, any shift operations, such
as Skip or Repeat, are performed by group.
Transferring by group
The audio files transferred to the SonicStage software are
always grouped when transferred to the built-in flash
memory.
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
MENU button
to (+/>)
to (./–)
14
Advanced Operations
Repeat mode
There are three types of repeat mode: Track
Repeat, A-B Repeat and Sentence Repeat.
• Track Repeat (TRK Rep)
This mode plays back tracks repeatedly in the
following five ways.
Track Repeat mode
All Repeat
Single Repeat
Group Repeat
Group Shuffle
Repeat
All Groups Shuffle
Repeat
• A-B Repeat (A-B Rep)
This mode plays back the specified section in a
track repeatedly.
• Sentence Repeat (SENTENCE Rep)
This mode plays back voice data within a
specified section in a track repeatedly.
Selecting the repeat
mode
1 Press the MENU button in stop mode.
The menu screen is displayed.
REPEAT MODE>
Operation
All tracks repeatedly
Current track repeatedly
Current group repeatedly
Current group repeatedly
in random order
All groups repeatedly
in random order
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
MENU button
to (+/>)
to (./–)
2 Rotate the Shuttle switch to select
“REPEAT MODE >” and press the
Nx button to confirm.
3 Rotate the Shuttle switch to select a
desired repeat mode and press the Nx
button to confirm.
TRKRep
You can choose one mode among “TRK
Rep,” “A-B Rep” and “SENTENCE Rep.”
4 Press the MENU button.
The display returns to the normal screen.
You can operate each repeat mode you
selected, as refer to the below.
• TRK Rep: see “Playing the tracks
repeatedly (Track Repeat).”
• A-B Rep: see “Playing a specified section
repeatedly (A-B Repeat).”
• SENTENCE Rep: see “Playing specified
sentences repeatedly (Sentence Repeat).”
To cancel the Menu mode
Select [RETURN] in the menu screen or press the MENU
button.
Notes
• The display automatically returns to the normal
playback screen if you do not operate any button for 60
seconds.
• When there is no audio files in the built-in flash
memory, you cannot set any repeat mode.
• When you connect the Network Walkman to your
computer, the selected desired mode will be cancelled.
• You can select repeat mode only in stop mode.
15
Advanced Operations
Playing the tracks
repeatedly (Track
Repeat)
The Track Repeat mode is changed by pressing
the REPEAT/SOUND button. You can check the
current Track Repeat mode with the icon of the
display.
Select the Track Repeat mode (TRK
Rep) first (page 14).
Then, press the REPEAT/SOUND
button repeatedly to select the repeat
mode you want.
Each press changes the Track Repeat icon as
follows:
Track Repeat icon
G
r
o
u
p
M
o
d
e
REPEAT/
SOUND button
Playing a specified
section repeatedly (A-B
Repeat)
While playing a track, you can set the start point
(A) and end point (B) for a section you wish to
play repeatedly.
1 Select the A-B Repeat mode (A-B Rep)
(page 14).
2 Press the Nx button to start playback.
3 Press the REPEAT/SOUND button to
set the start point (A) while playing
back.
“B” blinks.
:00A00B01
4 Press the REPEAT/SOUND button to
set the end point (B).
“A B” is displayed and the specified section
is played back repeatedly.
:00A55B01
Notes
• You cannot set A-B Repeat for a section that
overlaps two or more tracks.
• If you do not set the end point (B), the end point
is automatically set at the end of the track.
• You cannot use A-B Repeat in the Group mode
or when the current time is displayed.
G
r
o
u
p
M
o
d
e
o
d
e
continued
Shuttle switch
Press
(Confirm)
Nx button
REPEAT/SOUND button
to (+/>)
to (./–)
none (Normal play)
(All Repeat)
(Single Repeat)
(Group Repeat)
(Group Shuffle Repeat)
(All Groups Shuffle Repeat)
The non-Canadian
model is illustrated.
16
Repeat mode
(continued)
z Tips
• You can fast-forward or fast-rewind by rotating the
Shuttle switch, after the start point (A) is set. If the
track reaches the end while fast-forwarding, the end
point is set as point (B) and fast-forwarding continues.
A-B Repeat starts when you release the Shuttle switch.
If the track reaches the beginning while fast-rewinding,
it jumps to the end of the track, the end point is set as
point (B), and fast-rewinding continues.
• You can fast-forward or fast-rewind by rotating the
Shuttle switch, during A-B Repeat playback. If the
track reaches the track start/end while fast-forwarding
or fast-rewinding, playback is stopped (enters Standby).
A-B Repeat restarts when you release the Shuttle
switch.
To clear the start point (A) and end point (B)
• Press the REPEAT/SOUND button during A-B
Repeat playback.
• Press the MENU button during A-B Repeat
playback.
• Select the Group mode by pressing the GROUP
button during A-B Repeat playback.
• Select the previous or next track by rotating the
Shuttle switch during A-B Repeat playback.
(The A-B Repeat mode is not cancelled.)
To cancel the A-B Repeat mode
Change the Repeat mode in the menu screen (page
14).
Playing specified
sentences repeatedly
(Sentence Repeat)
This function automatically detects only voice
data from the setting point and repeats the voice
data for setting counts. It is useful for learning a
foreign language.
z Tip
The default repeat counts setting is 2 times for one
sentence. But you can change the repeat counts setting.
Refer to “Setting the repeat counts” on page 17.
1 Select the Sentence Repeat mode
(SENTENCE Rep) (page 14).
2 Press the Nx button to start playback.
3 Press the REPEAT/SOUND button to
place the setting point during playback.
The Network Walkman detects spoken
sections and non-spoken sections from the
set point, and Sentence Repeat starts. (The
spoken section is repeated once (during
detection), and the setting is counted.)
1:0201 0
Notes
• You cannot use Sentence Repeat in the Group
mode, or when the current time is displayed.
•A spoken or non-spoken section of less than 1
second will not be detected.
• If a non-spoken section is not detected until the
track end, the track end point is recognized as a
non-spoken section and Sentence Repeat begins
from the previous spoken section.
To clear the setting point
• Press the REPEAT/SOUND button during
Sentence Repeat playback.
• Press the MENU button during Sentence Repeat
playback.
• Select the Group mode by pressing the GROUP
button during Sentence Repeat playback.
• Select the previous or next track by rotating the
Shuttle switch during Sentence Repeat playback.
(The Sentence Repeat mode is not cancelled.)
To cancel the Sentence Repeat mode
Change the Repeat mode in the menu screen (page
14).
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
REPEAT/SOUND button
to (+/>)
to (./–)
17
Advanced Operations
continued
Setting the repeat
counts
You can set the repeat counts (1-9) of one
sentence for the Sentence Repeat mode.
1 Press the MENU button.
The menu screen is displayed.
REPEAT MODE>
2 Rotate the Shuttle switch to select
“REPEAT MODE >” and press the
Nx button to confirm.
3 Rotate the Shuttle switch to select
“SENTENCE Rep” and press the Nx
button to confirm.
“COUNT:” is displayed on the screen.
COUNT:2
4 Rotate the Shuttle switch to select a
desired repeat counts and press the
Nx button to confirm.
5 Press the MENU button.
The display returns to the normal screen.
To cancel the Menu mode
Select [RETURN] in the menu screen or press the MENU
button.
Changing the
display mode
You can view information such as track numbers
or titles in the display while music is played or
stopped. Change the display mode by operating
the Shuttle switch in the Menu mode.
• Lap Time: Elapsed time display mode
The following will be displayed after a music title and
artist name are displayed.
* Play: Displays and alternately.
Stop: Displays .
Search track: Displays > or ..
Fast-forward/Fast-rewind: Displays M or m.
• Title: Title display mode
When the music title includes more than 12 characters,
the title will be automatically scrolled.
T itle/Artis
• Track info: Track information display mode
The track title, CODEC, and bit rate are displayed.
When the information includes more than 12
characters, the information will be automatically
scrolled.
T itle/Codec/
While searching, fast-forwarding, or fast-rewinding a
track, the current playing position is displayed.
009 01:36
Track number Elapsed time
Play status*
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
MENU button
to (+/>)
to (./–)
18
Selecting the group
display mode
For any menu mode, you can select the group
display by pressing the GROUP button.
G
r
o
u
p
M
o
d
e
GROUP button
Changing the display mode
(continued)
1 Press the MENU button.
The menu screen is displayed.
REPEAT MODE>
2 Rotate the Shuttle switch to select
“DISPLAY >” and press the Nx
button to confirm.
The selected display mode blinks.
LapT ime
3 Rotate the Shuttle switch to select a
desired display mode and press the
Nx button to confirm.
The display switches to the selected display
mode.
DISPLAY>
4 Press the MENU button.
The display returns to the normal screen.
To cancel the menu mode
Select [RETURN] in the menu screen or press the MENU
button.
Note
The display automatically returns to the normal playback
screen if you do not press any buttons for 60 seconds.
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
MENU button
to (+/>)
to (./–)
To cancel the group mode
Press the GROUP button in the group mode screen.
Note
The display automatically returns to the normal playback
screen if you do not operate any button for 30 seconds.
The non-Canadian
model is illustrated.
19
Advanced Operations
Adjusting treble
and bass (Digital
sound preset)
You can adjust the treble and bass. You can preset
two settings, which can be selected during
playback.
Selecting the Sound
quality
Default settings
Sound SOUND 1 SOUND 2 SOUND OFF
quality
(S1) (S2)
(NORMAL SOUND)
Bass +1 +3 ±0
Treble ±0 ±0 ±0
Press and hold the REPEAT/SOUND
button for half a second.
The Sound quality setting is changed as follows:
To return to the normal Sound quality
Select “SOUND OFF.”
G
r
o
u
p
M
o
d
e
REPEAT/
SOUND button
Adjusting the sound
quality
You can adjust the sound quality of bass and
treble parts.
Sound quality Emphasis level
Bass -4 to +3
Treble -4 to +3
You can preset desired sound quality settings as
“Sound 1” and “Sound 2.” While playing music,
you can assign a preset sound quality to music.
1 Press the MENU button.
The menu screen is displayed.
REPEAT MODE>
2 Rotate the Shuttle switch to select
“SOUND >” and press the Nx button
to confirm.
SOUND: 2 >
continued
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
MENU button
to (+/>)
to (./–)
S1 S2 (none)
The non-Canadian
model is illustrated.
20
Locking the
controls (HOLD)
You can protect your Network Walkman against
accidental operation by using the HOLD function
when carrying it.
Slide the HOLD switch in the direction
of the arrow.
All operation buttons are disabled.
If you press buttons while the HOLD switch is on,
“HOLD” blinks in the display.
To release the HOLD function
Slide the HOLD switch in the opposite direction of the
arrow.
G
r
o
u
p
M
o
d
e
HOLD switch
3 Set the tone for “SOUND 1.”
1 Rotate the Shuttle switch to select
“SOUND 1 >” and press the Nx button
to confirm.
2 “BASS:+1” appears, rotate the Shuttle
switch to adjust the emphasis level of
bass sound and press the Nx button to
confirm.
3 “TREBLE: 0” appears, rotate the Shuttle
switch to adjust the emphasis level of
treble sound and press the Nx button to
confirm.
4 Press the MENU button
The display returns to the normal screen.
To adjust the “SOUND 2” setting
Select “SOUND 2” in step 3.
To cancel the menu mode
Select [RETURN] in the menu screen or press the MENU
button.
Adjusting treble and bass
(Digital sound preset)
(continued)
The non-Canadian
model is illustrated.
21
Advanced Operations
Storing non-audio
data
You can transfer data from the hard disk of your
computer to the built-in flash memory using
Windows Explorer.
The built-in flash memory is displayed in
Windows Explorer as an external drive (for
example: as the D drive).
Notes
• You cannot operate the SonicStage software while
operating the data storage function of your Network
Walkman to use files stored in the built-in flash
memory. The error message “Cannot access the Device/
media.” will be displayed when you try to operate both
of them simultaneously.
• If you store a lot of non-audio data into the built-in
flash memory, the space for audio data is reduced by
the same amount.
22
Adjusting the settings of
your Network Walkman
2 Rotate the Shuttle switch to select “PC
CLK:” and press the Nx button to
confirm.
PC CLK:ON
3 Rotate the Shuttle switch to select
“OFF” and press the Nx button to
confirm.
4 Press the MENU button
The display returns to the normal screen.
To change the setting to “ON”
Select “ON” in step 3.
To cancel the menu mode
Select [RETURN] in the menu screen or press the MENU
button.
Adjusting the time
setting of your
Network Walkman
to a computer’s
built-in clock
If the function is set to “ON,” the time setting of
your Network Walkman is automatically adjusted
to the computer’s built-in clock when your
Network Walkman is connected and audio file
transferring is executed (the SonicStage software
must be started). “ON” is selected by default.
You cannot play a song with a limited playing
period without the time setting of your Network
Walkman. Be sure to adjust the time setting.
To set the date and time on your Network
Walkman, refer to “Adjusting the current time
setting (DATE-TIME)” on page 23.
Changing the setting to “OFF”
The time setting of your Network Walkman does
not change even when your Network Walkman is
connected to a computer.
1 Press the MENU button.
The menu screen is displayed.
REPEAT MODE>
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
MENU button
to (./–)
to (+/>)
23
Adjusting the settings of your Network Walkman
4 As you did in step 3, adjust the settings
for “month” and “date.”
After rotating the Shuttle switch to adjust the
“date” setting and pressing the Nx button
to confirm, the display switches to the time
setting screen.
0:00
5 Rotate the Shuttle switch to adjust the
“hour” setting and press the Nx
button to confirm.
The “minute” digit blinks.
0:00
6 As you did in step 5, adjust the settings
for “minute.”
After rotating the Shuttle switch to adjust the
“minute” setting and pressing the Nx
button to confirm, the display switches to the
time setting screen.
DAT E-T IME
7 Press the MENU button.
The display returns to the normal screen.
To cancel the menu mode
Select [RETURN] in the menu screen or press the MENU
button.
To display the current time
Press the MENU button and hold it.
You can display the current time while pressing the
button.
Notes
• If the unit is not used for a long time, your settings of
the date and time may be reset.
• If the current time is not set, the display for the date and
time will be “-- --.”
• If PC CLK is set to “ON” (page 22), the time setting of
your Network Walkman is automatically adjusted to a
computer’s built-in clock when your Network
Walkman is connected to the computer.
• Depending on the shipping area, the time display
format of the unit is set to a 12-hour display or a 24-
hour display.
You cannot switch between a 12-hour display and a 24-
hour display in the unit.
A 24-hour display is shown in this manual.
Adjusting the
current time
setting (DATE-
TIME)
You can set and display the current time.
You can also adjust the time setting of your
Network Walkman to a computer’s built-in clock
by connecting your Network Walkman to the
computer (page 22).
1 Press the MENU button.
The menu screen is displayed.
REPEAT MODE>
2 Rotate the Shuttle switch to select
“DATE-TIME” and press the Nx
button to confirm.
The “year” digit blinks.
2004y 1m 1d
3 Rotate the Shuttle switch to adjust the
“year” setting and press the Nx
button to confirm.
The “month” digit blinks.
2004y 1m 1d
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
MENU button
to (+/>)
to (./–)
24
Limiting the
volume (AVLS)
You can set AVLS (Automatic Volume Limiter
System) to limit the maximum volume to prevent
auditory disturbance or distraction. With AVLS,
you can listen to music at a comfortable volume
level.
1 Press the MENU button.
The menu screen is displayed.
REPEAT MODE>
2 Rotate the Shuttle switch to select
“AVLS” and press the Nx button to
confirm.
“OFF” blinks.
AVLS :OFF
3 Rotate the Shuttle switch to select “ON”
and press the Nx button to confirm.
The
(AVLS) indication is displayed. The
volume is kept at a moderate level.
4 Press the MENU button.
To change the setting to “OFF”
Select “OFF” in step 3.
To cancel the menu mode
Select [RETURN] in the menu screen, or press the
MENU button.
Setting the
volume using the
preset volume
function
There are two modes to adjust the volume level.
Manual mode: Press the VOLUME +/– button to
adjust the volume level in the
range of 0 to 31.
Preset mode: Press the VOLUME +/– button to
set the volume level to any of
three preset levels: LO, MID, or
HI.
Setting a volume level of
the preset mode
1 Press the MENU button.
The menu screen is displayed.
REPEAT MODE>
2 Rotate the Shuttle switch to select
“VOL: MAN.”
VOL :MAN
3 Press the Nx button to confirm.
“MAN” blinks.
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
MENU button
to (+/>)
to (./–)
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
MENU button
to (+/>)
to (./–)
VOLUME +/–
button
25
Adjusting the settings of your Network Walkman
Switching to the manual
mode
1 Press the MENU button.
The menu screen is displayed.
2 Rotate the Shuttle switch to select
“VOL: SET.”
VOL :SET>
3 Press the Nx button to confirm.
“SET >” blinks.
4 Rotate the Shuttle switch to select
“MAN.”
VOL :MAN
5 Press the Nx button to confirm.
6 Press the MENU button.
The display returns to the normal screen.
With this setting, you can adjust the volume
level by pressing the volume button.
4 Rotate the Shuttle switch to select “SET
>.”
VOL :SET>
5 Press the Nx button to confirm.
“VOL LO xx”* blinks.
* “xx” stands for numeric values of the
volume level.
VOL LO xx
6 Set volume levels of three preset levels:
LO, MID, or HI.
1 Press the VOLUME +/– button to set the
volume level of the LO preset.
2 Rotate the Shuttle switch to select “VOL
MID xx,” and then press the VOLUME
+/– button to set the volume level of the
MID preset.
3 Rotate the Shuttle switch to select “VOL
HI xx,” and then press the VOLUME +/–
button to set the volume level of the HI
preset.
7 Press the Nx button to confirm.
8 Press the MENU button.
The display returns to the normal screen.
With these settings, you can adjust the
volume level to any of three preset levels:
LO, MID, or HI.
To cancel the menu mode
Select [RETURN] in the menu screen or press the MENU
button.
Note
If AVLS (page 24) is set, the actual volume may be lower
than the settings.
26
Changing the
backlight setting
You can select ON or OFF.
Menu Backlight mode
OFF Always off
ON Turns on for three seconds
after each operation
(or until scrolling is complete)
To set “ON”
1 Press the MENU button.
The menu screen is displayed.
REPEAT MODE>
2 Rotate the Shuttle switch to select
“LIGHT:” and press the Nx button to
confirm.
“OFF” blinks.
LIGHT:OFF
3 Rotate the Shuttle switch to select “ON”
and press the Nx button to confirm.
LIGHT:ON
4 Press the MENU button.
The display returns to the normal screen.
To change the setting to “OFF”
Select “LIGHT: OFF” in step 3.
To cancel the menu mode
Select [RETURN] in the menu screen or press the MENU
button.
Turning off the
beep sound
(BEEP)
You can turn off the beep sounds of your Network
Walkman.
1 Press the MENU button.
The menu screen is displayed.
REPEAT MODE>
2 Rotate the Shuttle switch to select
“BEEP:” and press the Nx button to
confirm.
“ON” blinks.
BEEP:ON
3 Rotate the Shuttle switch to select
“OFF” and press the Nx button to
confirm.
BEEP:OFF
4 Press the MENU button.
The display returns to the normal screen.
To change the setting to “ON”
Select “ON” in step 3.
To cancel the menu mode
Select [RETURN] in the menu screen, or press the
MENU button.
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
MENU button
to (+/>)
to (./–)
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
MENU button
to (+/>)
to (./–)
27
Other functions
Other functions
Regrouping songs
(REGROUP)
The songs group function may be disabled* when
a song has been deleted from or added the built-in
flash memory by operating the computer in which
the SonicStage software is not installed (page 10).
In such a case, you may enable the group function
by regrouping audio file. When you need to edit
audio file, make sure that you connect your
Network Walkman to the computer and use the
SonicStage software.
* The order of songs will not be changed even if the song
group function is disabled.
1 Press the MENU button.
The menu screen is displayed.
REPEAT MODE>
2 Rotate the Shuttle switch to select
“REGROUP” and press the Nx
button to confirm.
REGROUP: N
You cannot regroup audio file while playing
music.
3 Rotate the Shuttle switch to select “Y”
and press the Nx button to confirm.
“Really?” is displayed.
Really?
4 Press the Nx button.
Regrouping starts and “REGROUPING”
blinks. When regrouping audio file is
complete, “COMPLETE” is displayed and
the display returns to the indication in step 2.
5 Press the MENU button.
The display returns to the normal screen.
To cancel the menu mode
Select [RETURN] in the menu screen or press the MENU
button.
Note
You cannot regroup songs while playing music.
(“REGROUP” will not be displayed in the menu screen.)
z Tip
In some cases, you may not be able to restore the
former grouping. When you need to edit audio
file, connect your Network Walkman to the
computer and use the SonicStage software.
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
MENU button
to (+/>)
to (./–)
28
Formatting
memory (FORMAT)
You can use your Network Walkman to format the
built-in flash memory.
If memory is formatted, all data previously stored
in the memory will be erased. Be sure to verify the
data stored in the memory prior to formatting.
1 Press the MENU button.
The menu screen is displayed.
REPEAT MODE>
2 Rotate the Shuttle switch to select
“FORMAT” and press the Nx button
to confirm.
FORMAT:N
You cannot format memory while playing
music.
3 Rotate the Shuttle switch to select “Y”
and press the Nx button to confirm.
“Really?” is displayed.
4 Press the Nx button.
“FORMATTING” blinks and formatting
starts.
When formatting is complete,
“COMPLETE” is displayed and the display
returns to the indication in step 2.
5 Press the MENU button.
The display returns to the normal screen.
To cancel the menu mode
Select [RETURN] in the menu screen or press the MENU
button.
To cancel formatting
Select “N” in step 3.
Note
You cannot format memory while playing music.
(“FORMAT” will not be displayed in the menu screen.)
G
r
o
u
p
M
o
d
e
o
d
e
Shuttle switch
Press
(Confirm)
Nx button
MENU button
to (+/>)
to (./–)
29
Other Information
Other Information
Precautions
On installation
Never use your Network Walkman where it will
be subjected to extremes of light, temperature,
moisture or vibration.
On the headphones
Road Safety
Do not use headphones while driving, cycling, or
operating any motorized vehicle. It may create a
traffic hazard and is illegal in many areas. It can
also be potentially dangerous to play your
Network Walkman at a high volume while
walking, especially at pedestrian crossings. You
should exercise extreme caution or discontinue
use in potentially hazardous situations.
Preventing hearing damage
Avoid using the headphones at a high volume.
Hearing experts advise against continuous, loud
and extended play. If you experience a ringing in
your ears, reduce the volume or discontinue use.
Caring for others
Keep the volume at a moderate level. This will
allow you to hear outside sounds and to be
considerate to the people around you.
Warning
If there is lightning when you are using your
Network Walkman, take off the headphones
immediately.
On cleaning
• Clean your Network Walkman casing with a soft
cloth slightly moistened with water or a mild
detergent solution.
• Clean the headphone plug periodically.
Note
Do not use any type of abrasive pad, scouring powder or
solvent such as alcohol or benzene as it may mar the
finish of the casing.
If you have any questions or problems concerning
your Network Walkman, please consult your
nearest Sony dealer.
30
Troubleshooting
If you experience any of the following difficulties while using your Network Walkman, use this
troubleshooting guide to help you to remedy the problem prior to consult a Sony dealer. Should any
problem persist, consult your nearest Sony dealer. For trouble concerning operations while connected to
your computer, please refer to “Troubleshooting” in the online help of the supplied software in addition.
To reset the player
If your Network Walkman does not operate normally or if there is no sound, even after checking the
troubleshooting guide below, remove the battery, then re-insert it.
What happened?
On operating
Symptom
There is no sound.
Noise is generated.
Buttons do not work.
The volume is not loud enough.
There is no sound from the right
channel of the headphones.
Playback has stopped suddenly.
Cause/Remedy
• The volume level is set to zero.
c Turn the volume up (page 12).
• The headphone jack is not connected properly.
c Connect the headphone jack properly (page 12).
• The headphone plug is dirty.
c Clean the headphone plug with a soft dry cloth.
• Songs with a limited playing period is played.
c Songs with an expired playing period cannot be played.
• No audio files are stored in the memory.
c If “NO DATA” is displayed, transfer audio file(s) from the
computer.
• The HOLD switch is set to on.
c Set the HOLD switch to off (page 20).
• Your Network Walkman contains moisture condensation.
c Keep your Network Walkman aside for a few hours.
• The remaining battery power is insufficient.
c Replace the battery (page 7).
The AVLS is enabled.
c Disable the AVLS (page 24).
• The headphone jack is not fully connected.
c Connect the headphone jack fully (page 12).
• The extension headphone cord (supplied only for non-Canadian
model) is not properly connected to the headphone jack of your
Network Walkman or the headphone cord.
c Connect them properly (page 12).
The remaining battery power is insufficient.
c Replace the battery (page 7).
31
Other Information
continued
On the display window
Symptom
The backlight is not turned on.
“s” is displayed for a title.
On the connection with the computer or supplied software
Symptom
The software cannot be installed.
“CONNECT” is not displayed when
connecting to the computer with the
dedicated USB cable.
Your Network Walkman is not
recognized by the computer when it is
connected to the computer.
Song cannot be transferred to your
Network Walkman.
Cause/Remedy
LIGHT is set to “OFF.”
c In the menu mode, set “LIGHT” to “ON” (page 26).
Characters that cannot be displayed on your Network Walkman are
involved.
c Use the supplied SonicStage software to rename the title with
appropriate characters.
Cause/Remedy
An operating system not compatible with the software is used.
c For details, refer to the separate manual “SonicStage operating
instructions.”
• Please wait for the authentication of the SonicStage software.
• Another application is running on the computer.
c Wait for a while and reconnect the USB cable. If the problem
persists, disconnect the USB cable, restart the computer, and then
reconnect the USB cable.
• The dedicated USB cable is disconnected.
c Connect the dedicated USB cable.
•A USB hub is used.
c Connecting via a USB hub is not guaranteed. Connect the dedicated
USB cable directly to the computer.
The dedicate USB cable is disconnected.
c Connect the dedicated USB cable.
• The dedicated USB cable is not connected properly.
c Connect the USB cable properly.
• The free space of the built-in flash memory to where you want to
transfer audio files to is insufficient.
c Transfer any unnecessary songs back to your computer to increase
free space.
• You have already transferred to 400 songs or 400 groups to the built-
in flash memory using the SonicStage software.
c The maximum number of songs or groups that you can transfer to
the built-in flash memory using the SonicStage software is 400.
• Audio files with a limited playing period or playing count may not be
transferred due to restrictions set by copyright holders. For details on
the settings of each audio file, contact the distributor.
32
Troubleshooting (continued)
Symptom
The number of audio files that can be
transferred to is limited. (Available
recording time is short.)
The operation of the Network
Walkman becomes unstable while it is
connected to the computer.
“Failed to authenticate Device/Media”
is displayed on the computer screen
while connecting the Network
Walkman to the computer.
Other
Symptom
There is no beep sound when your
Network Walkman is operated.
Your Network Walkman gets warm.
Cause/Remedy
• The free space of the built-in flash memory to where you want to
transfer to is not enough for the size of audio files you wish to
transfer.
c Transfer any unnecessary audio files back to the computer to
increase free space.
• Non-audio data is stored in the built-in flash memory to where you
want to transfer audio files to.
c Move non-audio data to the computer to increase free space.
USB hub or USB extension cable is used.
c Connecting via a USB hub or USB extension is not guaranteed.
Connect the dedicated USB cable directly to the computer.
Your Network Walkman is not connected to the computer properly.
c Quit the SonicStage software and verify the connection of the
dedicated USB cable. Restart the SonicStage software.
Cause/Remedy
BEEP is set to “OFF.”
c In the menu mode, set “BEEP” to ”ON” (page 26).
Sometimes, during normal conditions, the player becomes
slightly warm.
33
Other Information
Messages
Follow the instructions below if an error message appears in the display.
Message
ACCESS
AVLS
CANNOT PLAY
CONNECT
ERROR
EXPIRED
FILE ERROR
HOLD
LOW BATT
MEMORY FULL
MG ERROR
NO AUDIO
Meaning
Accessing the built-in flash memory.
The volume level exceeds the rated
value while the AVLS is enabled.
• Your Network Walkman cannot play
certain files because of incompatible
formats.
• Transferring has been interrupted
forcefully.
Your Network Walkman is connected to
the computer.
A malfunction is detected.
• The song with a playback restriction
has expired.
• The current time has not been set to
play the song with a playback
restriction.
• The song is protected by the playback
restriction that is not compatible with
your Network Walkman.
• The file cannot be read.
• The file is not normal.
All operation buttons are disabled since
the HOLD switch is set to on.
The battery is low.
The memory is full or there are 400
groups.
An unauthorized distribution file is
detected for copyright protection.
There is no audio files in the built-in
flash memory.
Remedy
Please wait for access to complete. This message
appears while transferring audio files and during
initialization of the built-in flash memory.
Turn the volume down or disable the AVLS.
If the file cannot be played, you can erase it from
the built-in flash memory.
For details, refer to “To delete abnormal data from
the built-in flash memory” (page 33).
You can operate your Network Walkman using the
SonicStage software, but you cannot operate the
controls on your Network Walkman.
Please consult your nearest Sony dealer.
• If the current time has not been set yet, set the
current time in the menu mode (page 23).
• If song cannot be played, you can erase it from
the built-in flash memory.
For details, refer to “To delete abnormal data
from the built-in flash memory (page 33).
• Your Network Walkman does not support
contents with a limited playing count. For details,
refer to “Note on playing songs with a limited
playing count” (page 11).
Transfer the normal audio file back to the computer
and then format your Network Walkman. (For
details, refer to “To delete abnormal data from the
built-in flash memory” on page 33.)
Set the HOLD switch to off to operate the buttons.
You must change the battery (page 7).
Delete songs or groups. A group without song is
also regarded as one group. To delete groups
without song, use the SonicStage software.
Transfer normal audio files back to the computer and
then format the built-in flash memory of your Network
Walkman. (For details, refer to “To delete abnormal
data from the built-in flash memory” on page 33.)
If there is no audio files in the built-in flash memory,
use the SonicStage software to transfer audio files.
To delete abnormal data from the built-in flash memory
If “CANNOT PLAY,” “EXPIRED,” or “FILE ERROR” is displayed, there is a problem with all or part of
the data stored in the built-in flash memory.
Please follow the procedures below to erase data you cannot play.
1 Connect your Network Walkman to the computer, and start the SonicStage software.
2 If you have already specified the data with problems (such as expired songs), erase the data from the
Portable Player window of the SonicStage software.
3 If the problem persists, click the button on the SonicStage software to transfer all data
without problems while your Network Walkman is connected to the computer.
4 Disconnect your Network Walkman from the computer and then format the built-in flash memory using
the FORMAT menu (page 28).
34
Dimension
56 × 37.3 × 15 mm
(w/h/d, projecting parts not included)
Mass
Approx. 40 g (battery not included)
Supplied accessories
Headphones (1)
Dedicated USB cable (1)
Carrying pouch (1)*
Neck strap (1)*
Extension headphone cord (1)*
CD-ROM (1)
Operating Instructions (1)
SonicStage operating instructions (1)
* Only for non-Canadian model
Design and specifications are subject to change
without notice.
ATRAC3plus
1 hr. 00 min. (256 kbps)
4 hr. 10 min. (64 kbps)
5 hr. 50 min. (48 kbps)
ATRAC3
2 hr. 00 min. (132 kbps)
2 hr. 30 min. (105 kbps)
4 hr. 10 min. (66 kbps)
Sampling frequency
ATRAC3, ATRAC3plus: 44.1 kHz
Audio compression technology
Adaptive Transform Acoustic Coding3 (ATRAC3)
Adaptive Transform Acoustic Coding3plus
(ATRAC3plus)
Frequency response
20 to 20,000 Hz (single signal measurement)
Output
Headphone: Stereo mini-jack
Signal-to-noise ratio (S/N)
80 dB or more (excluding ATRAC3 66 kbps)
Dynamic range
85 dB or more (excluding ATRAC3 66 kbps)
Operating temperature
5˚C to 35˚C (67˚F to 95˚F)
Power source
LR03 (size AAA) alkaline battery
Battery life (continuous playback)
ATRAC3 format: Approximately 70 hours
ATRAC3plus format: Approximately 60 hours
Specifications
Maximum recording time (Approx.)
NW-E55
ATRAC3plus
2 hr. 00 min. (256 kbps)
8 hr. 30 min. (64 kbps)
11 hr. 40 min. (48 kbps)
ATRAC3
4 hr. 10 min. (132 kbps)
5 hr. 10 min. (105 kbps)
8 hr. 20 min. (66 kbps)
NW-E75
35
Other Information
Glossary
MagicGate
Copyright protection technology that consists of authentication and encryption technology. Authentication
ensures that protected content is transferred only between compliant devices and media, and that protected
content is recorded and transferred in an encrypted format to prevent unauthorized copying or playback.
Note
is terminology denoting the copyright protection system developed by Sony. It does not guarantee
conversion among other media.
OpenMG
Copyright protection technology that securely manages music content from the EMD/Audio CD on a
personal computer. Application software that is installed on the computer encrypts the digital music content
when recording on the hard drive. This allows you to enjoy music content on the computer, but prevents
unauthorized transmission of this content across a network (or elsewhere). This PC copyright protection
complies with “MagicGate”, and allows you to transfer digital music content from a PC’s hard drive to a
compliant device.
SonicStage
Copyright protection technology that securely manages music content from the EMD/Audio CD on a
personal computer. Application software that is installed on the computer encrypts the digital music content
when recording on the hard drive. This allows you to enjoy music content on the computer, but prevents
unauthorized transmission of this content across a network (or elsewhere). This PC copyright protection
complies with “MagicGate”, and allows you to transfer digital music content from a computer’s hard disk
to a compliant device.
ATRAC3
ATRAC3, which stands for Adaptive Transform Acoustic Coding3, is audio compression technology that
satisfies the demand for high sound quality and high compression rates.
The ATRAC3 compression rate is approximately 10 times higher than that of the Audio CD, resulting in an
increased data capacity for the media.
ATRAC3plus
ATRAC3plus, which stands for Adaptive Transform Acoustic Coding3plus, is audio compression
technology that compresses data higher than ATRAC3. The ATRAC3plus is new audio compression
technology that enables equal or higher quality sound comparing to ATRAC3.
Bit rate
Indicates the data amount per second. The rate is reflected in bps (bit per second).
64 kbps means 64000 bits of information per second. If the bit rate is large, that means a large amount of
information is used to play music. Comparing music of the same format (e,g., ATRAC3plus), 64 kbps data
offers better sound quality than 48 kbps data. However, audio files in formats such as MP3 have different
encoding methods, and thus sound quality cannot be determined by simply comparing the bit rate.
36
Display
(Menu mode)
FORMAT >
(Formatting
memory)
REGROUP >
(Regrouping data)
[RETURN]
Menu list
Press the MENU button to display the menu mode and use the Shuttle switch (rotate:
select/press: confirm) to change the settings of your Network Walkman.
For details about each menu, refer to the pages in parentheses. The menu with a “>” mark will be followed
by a detailed-setting screen when you press the Shuttle switch to confirm.
Display
(Menu mode)
REPEAT MODE >
DISPLAY >
(Display mode)
VOL:
(Preset volume)
SOUND >
(Digital sounds
preset)
AVLS:
(Automatic Volume
Limiter System)
BEEP:
(Operation sounds
setting)
LIGHT:
(LCD backlight
setting)
DATE-TIME
(Current time
setting)
PC CLK:
(Adjusting the time
setting to a computer
built-in clock)
Purposes
You can select your favorite
repeat mode. (page 14)
You can select your favorite
display mode. (page 17)
You can preset your desired
volume level. (page 24)
You can preset your desired
sound quality. (page 19)
You can set to “ON” or
“OFF.” (page 24)
You can set to “ON” or
“OFF.” (page 26)
“OFF”: Always off
“ON”: Turns on for three
seconds after each operation
(page 26)
You can set and display the
current time. (page 23)
You can adjust the time setting
of your Network Walkman to
a computer built-in clock.
(page 22)
Purposes
You can format the built-in
flash memory. (page 28)
You can restore the group
function. (page 27)
You can switch to the normal
mode by selecting [RETURN]
and pressing the Nx button.
37
A
A-B Repeat 15
ACCESS lamp 10
Accessories 6
ATRAC3 35
ATRAC3plus 35
Audio CDs 4
AVLS (Limiting the volume)
9, 24
B
Backlight 26
Battery 5, 7
BEEP (Beep sound) 26
Bit rate 35
C
CD (Audio CDs) 4
CD-ROM 6, 10
Clock 22, 23
Computer 4, 10
D
DATE-TIME 23
Display 9, 15, 33
Display mode 17
Download 4
E
EMD service 4, 11
Explorer (Windows Explorer)
10, 21
F
Fast-forward 13
Fast-rewind 13
FORMAT 28
Formatting 28
G
Group 13, 18
H
Headphones 6, 12, 29
HOLD 20
HOLD function (Locking the controls)
20
L
LIGHT 26
Limiting the volume (AVLS)
24
Listening 12
Locking the controls (HOLD function)
20
M
MENU button 14, 17-20, 22-28
Menu list 36
MP3 4
O
OpenMG 35
P
PC CLK 22
Play 12
Index
continued
38
R
Regroup 27
Remaining battery indication
7
Repeat 14
Repeat count 17
Reset 30
RETURN 36
S
Sentence Repeat 16
Serial Number 6
Shuffle Repeat 14
Shuttle switch 13-20, 22-28
Skip to the beginning of a track
13
SonicStage 35
Sound preset (Digital Sound Preset)
19
T
Time setting 22, 23
Title 17
Track Repeat 15
Transferring 4, 10
Troubleshooting 30
U
USB cable 6, 10
V
Volume 24
W
WAV format 4
Windows Explorer 10, 21
Index (continued)
39
Printed in China
