Makita 194368-5 Tools - Home Improvement

Product's Documents

Below are documents related to this product, you can read online or download:

User Manual - (English) Read Online | Download pdf

Main document Specification Questions and answers Relateds Products

User Manual

This is the main product document for model 194368-5.

The file format is pdf, 1 pages, you can download this manual here .

Give Review

PRODUCT HIGHLIGHTS

RELATED PRODUCTS

1. 55" Guide Rail (194368-5)

2. 118" Guide Rail (194367-7)

3. Guide Rail Clamp, 2/pk (194385-5)

4. Guide Rail Connector Kit (P-45777)

5. Guide Rail Adapter (193517-1)

GUIDE RAILS

NEW ACCESSORY OVERVIEW

FEATURES

• For use with Makita Plunge Saw models XPS01, XPS02, and

SP6000J

• Plunge Saw base connects directly to guide rail to deliver smooth,

dead-on straight or bevel cuts

• Ideal for ripping sheet material

• Compatible with select Makita circular saws, jig saws and routers

when used in conjunction with required Guide Rail Adapter

SPECIFICATIONS

makitatools.com

All specications subject to change without prior notice. All models and accessories subject to stock on hand. The Makita Teal Color is the trade dress

of Makita Corporation and is protected under common law and registered with the U.S. Patent and Trademark Ofce. NTF-0718 MA-4871-18

APPLICATIONS

Compatible with select

circular saws, jig saws

and routers; requires

optional Guide Rail Adapter

VERSATILITY

Ideal for ripping sheet

material

COMPATIBILITY

For use with Makita Plunge

Saw models XPS01, XPS02,

and SP6000J

DESIGN

Plunge Saw base connects

directly to guide rail to

deliver smooth, dead-on

straight or bevel cuts

1 2 3 4 5

PART NO. ITEM

UPC CODE

(08381)

199140-0 39" Guide Rail 528672

194368-5 55" Guide Rail 313353

194367-7 118" Guide Rail 335201

CORDLESS BLADES

B-57342

6-1/2" 56T Carbide-Tipped

Cordless Plunge Saw Blade

A-98809

6-1/2" 48T Carbide-Tipped

Cordless Plunge Saw Blade

A-99932

6-1/2" 48T Carbide-Tipped

Cordless Plunge Saw Blade

A-99960

6-1/2" 28T Carbide-Tipped

Cordless Plunge Saw Blade

A-99976

6-1/2" 56T Carbide-Tipped

Cordless Plunge Saw Blade

A-99982

6-1/2" 60T (ATB) Carbide-Tipped

Cordless Plunge Saw Blade

A-99998

6-1/2" 60T (TCG) Carbide-Tipped

Cordless Plunge Saw Blade

File type: PDF

File name: 85299733_194368-5.pdf

File size: 2.03 MB

File Language: English

Pages: 1

Author: Makita

Published: 2020-12-10

Updated: 2024-09-30

Verified by Lou Erdman on 2024-09-30

Source: Directly manufacturer

Download: Save file

Specifications

Brand: Makita

Model: 194368-5

Color: ‎Silver

Dimension: 55.11 x 7.28 x 0.43 inches

Weight: 6.6 pounds

Indexed Terms: Tool, Accessory

Makita 194368-5 Questions and Answers

Find answers or ask new question.

#1 can this be use with any makita circula saw?

It says in the description that you can buy an adapter to use it with any circular saw (Makita 199232-5 Guide Rail Adapter for Circular Saws). Altough, having the plunge track saw would give you better cuts and will take less set up time.

#2 Has anyone ever used this to cut a 12 foot long solid surface Corian countertop?

Yes, it works great, I've connected 3 X 55" sections with 2x connecting addaptors for each connection for extra strength. As long as you take your time to set it up straight and then check measurements at the middle before every cut it works great. I've managed to rip full 12ft sheet at just 1/2 inch wide without any issues.
