Code No.: DE68-02613A
Microwave Oven
Owner’s Manual
MW840WC/BC/CC
tz_[W~iThhUGGwGXGG{SGtGY^SGYWWZGG[aYXGwt
2
S
AVE
T
HESE
I
NSTRUCTIONS
Safety
P
RECAUTIONS TO
A
VOID
P
OSSIBLE
E
XPOSURE TO
E
XCESSIVE
M
ICROWAVE
E
NERGY
:
(a) Do not attempt to operate this oven with the door open
since open-door operation can result in harmful exposure
to microwave energy. It is important not to defeat or tamper
with the safety interlocks.
(b) Do not place any object between the oven front face and
the door or allow soil or cleaner residue to accumulate on
sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly
important that the oven door close properly and that there
is no damage to the
1) Door (bent or dented),
2) Hinges and latches (broken or loosened),
3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone
except properly qualified service personnel.
WARNING
Always observe Safety Precautions when using your
oven. Never try to repair the oven on your own – there is
dangerous voltage inside. If the oven needs to be
repaired, call 1-800-SAMSUNG for the name of an
authorized service center near you.
I
MPORTANT
S
AFETY
I
NSTRUCTIONS
When using any electrical appliance, basic safety precautions
should be followed, including the following:
WARNING
To reduce risk of burns, electric shock, fire, personal
injury or exposure to excessive microwave energy:
• Read all safety instructions before using the appliance.
• Read and follow the specific “
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
” on this page.
• This appliance must be grounded. Connect only to properly grounded
outlets. See “
IMPORTANT GROUNDING INSTRUCTIONS
”onpage3of
this manual.
• Install or place this appliance only in accordance with the installation
instructions provided.
• Some items, like whole eggs and food in sealed containers, may explode
if heated in this oven.
• Use this appliance only for its intended use as described in the manual.
Do not use corrosive chemicals or vapors in this appliance. This type of
oven is specifically designed to heat, cook, or dry food. It is not designed
for industrial or laboratory use.
• As with any appliance, close supervision is necessary when used by
children.
• Do not operate this appliance if it has a damaged cord or plug, if it is not
working properly, or if it has been damaged.
• This appliance should be serviced only by qualified service personnel.
Contact the nearest authorized service facility for examination, repair, or
adjustment.
• Do not cover or block any of the openings on this appliance.
• Do not store this appliance outdoors. Do not use near water – for
example, near a kitchen sink, in a wet basement, or near a swimming
pool, etc.
tz_[W~iThhUGGwGYGG{SGtGY^SGYWWZGG[aYXGwt
3
S
AVE
T
HESE
I
NSTRUCTIONS
Safety
Important Safety Instructions, continued
• Keep the inside of the oven clean. Food particles or spattered oils stuck to
the oven walls or floor can cause paint damage and reduce the efficiency
of the oven.
• Donotimmersecordorpluginwater.
• Keep cord away from heated surfaces.
• Do not let cord hang over edge of table or counter.
• When cleaning door and oven surfaces, use only mild, nonabrasive soaps
or detergents applied with a sponge or soft cloth.
• To reduce the risk of fire in the oven:
a. Do not overcook food. Watch appliance care fully if paper, plastic, or
other combustible materials are inside.
b. Remove wire twist-ties from plastic cooking bags before placing bags
in oven.
c. If materials inside the oven ignite, keep the oven door closed, turn the
oven off,disconnect the power cord, or shut off the power at the fuse or
circuit breaker panel.
d. Do not use the oven compartment for storage purposes. Do not leave
paper products, cooking utensils, or food in the oven when not in use.
• Do not try to preheat oven or operate while empty.
• Do not cook without the glass tray in place on the oven floor. Food will not
cook properly without the tray.
• Do not defrost frozen beverages in narrow-necked bottles. The containers
can break.
• Dishes and containers can become hot. Handle with care.
• Carefully remove container coverings, directing steam away from hands
and face.
• Remove lids from bay food before heating. After heating baby food, stir
well and test temperature by tasting before serving.
• A short power-supply cord is provided to reduce the risk of becoming
entangled in or tripping over a longer cord. Longer cord sets or extension
cords are available and may be used with caution.
• Do not operate any other heating or cooking appliance beneath this
appliance.
• Do not mount unit over or near any portion of a heating or cooking
appliance.
• Do not mount over a sink.
I
MPORTANT
G
ROUNDING
I
NSTRUCTIONS
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electrical current. This
appliance is equipped with a cord that includes a grounding
wireandagroundingplug.Theplugmustbepluggedintoan
outlet that is properly installed and grounded. Plug the three-
prong power cord into a properly grounded outlet of standard
115-120 voltage, 60 Hz. Your oven should be the only
appliance on this circuit.
WARNING
Improper use of the grounding plug can result in a risk of
electric shock. Consult a qualified electrician or servicer
if you do not understand the grounding instructions or if
you are not sure if the appliance is properly grounded.
tz_[W~iThhUGGwGZGG{SGtGY^SGYWWZGG[aYXGwt
4
Safety
Use of Extension Cords
A short power-supply cord is provided to reduce the risk of
becoming entangled in or tripping over a longer cord. Longer
cord sets or extension cords are available and may be used if
care is exercised in their use. If a long cord or extension cord is
used:
1. The marked electrical rating of the cord set or extension cord
should be at least as great as the electrical rating of the
appliance.
2. The extension cord must be a grounding-type 3-wire cord and
it must be plugged into a 3-slot outlet.
3. The longer cord should be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on by
children or tripped over accidentally. If you use an extension
cord, the interior light may flicker and the blower may vary
when the microwave oven is on. Cooking times may be
longer, too.
WARNING
Do not cut or remove the third (ground) prong from the
power cord under any circumstances.
Liquids, such as water, coffee, or tea are able to be overheated
beyond the boiling point without appearing to be boiling. Visible
bubbling or boiling when the container is removed from the
microwave oven is not always present.
This Could Result In Very Hot Liquids Suddenly Boiling Over
When The Container Is Disturbed Or A Spoon Or Other Utensil
Is Inserted Into The Liquid.
To reduce the risk of injury to persons:
1. Do not overheat the liquid.
2. Stir the liquid both before and halfway through heating it.
3. Do not use straight-sided containers with narrow necks.
4. After heating, allow the container to stand in the microwave
oven for a shorttime before removing the container.
5. Use extreme care when inserting a spoon or other utensil into
the container.
Your New Microwave oven
Table of Content
Safety............................................................................2
Your New Microwave oven.........................................4
Table of Content...................................................................4
Checking Parts .....................................................................5
Warranty and Service Information........................................5
Setting Up Your Microwave Oven.........................................5
Operation......................................................................7
Setting the Clock...................................................................7
Using the Pause/Cancel Button............................................7
Using the One Minute+ Button..............................................7
Defrosting .............................................................................7
Using the Instant Cook Buttons............................................8
Instant Cook Chart ............................................................8
Cooking Instructions...................................................9
Setting Cooking Times & Power Levels................................9
Cooking Utensils...................................................................9
Testing Utensils..................................................................10
Cooking Techniques...........................................................11
Cooking Guide....................................................................12
Recipes...............................................................................15
Appendix ....................................................................16
Troubleshooting Guide .......................................................16
Care and Cleaning..............................................................16
Specifications......................................................................17
Warranty.....................................................................17
Guía Rápida ...............................................................23
Quick Reference ........................................................23
tz_[W~iThhUGGwG[GG{SGtGY^SGYWWZGG[aYXGwt
5
Your New Microwave oven
Checking Parts
Unpack your microwave oven and check to make sure that you have all the
parts shown here. If any part is missing or broken, call your dealer.
Warranty and Service Information
To help us better serve you, please complete the enclosed registration card
and promptly return it by mail. If the registration card is missing, you can call
Samsung Electronics America, Inc., at 1-800- SAMSUNG(1-800-726-7864),
or register on-line at WWW.SAMSUNGUSA.COM
When contacting Samsung, please provide the specific model and serial
number information which is usually located on the back or bottom of the
product. Please record these numbers below, along with the other
requested information. Keep this information in a safe place as a permanent
record of your purchase to aid in identification in case of theft or loss, and a
copy of your sales receipt as a proof of purchase if warranty service is
needed.
MODEL NUMBER ____________________
SERIAL NUMBER ____________________
DATE PURCHASED ____________________
PURCHASED FROM ____________________
Warranty service can only be performed by a Samsung Authorized Service
Center. If youshould require warranty service, provide the above information
with a copy of your sales receipt to the Samsung Authorized Service Center.
For service assistance and the location of the nearest service center, please
call 1-800-SAMSUNG (1-800-726-7864), or go on-line to
WWW.SAMSUNGSUPPORT.COM
Setting Up Your Microwave Oven
1 Place the oven on a flat, sturdy surface and plug the cord into a
grounded outlet. Once plugged in, the display on your oven will show:
Make sure there is adequate ventilation for your oven by leaving at
least four inches of space behind, above, and to the sides of the oven.
2 Open the oven door by pressing the button below the control panel.
3 Wipetheinsideoftheovenwithadampcloth.
4 Place the pre-assembled ring in the indentation in the center of the
oven.
5 Place the glass tray on top of the ring so that the three glass tabs in
the center of the tray fit securely into the tabs on the floor of the
oven. .
Microwave oven
Glass tray
Roller guide ring
Instruction manual
Registration card
tz_[W~iThhUGGwG\GG{SGtGY^SGYWWZGG[aYXGwt
6
Your New Microwave oven
Control Panel Buttons
1. One Minute+ p.7
Press once for every minute of cooking at High power.
2. Defrost p.7
Press to set the defrosting time of the food to be defrosted.
3. Instant Cook Buttons p.8
Instant settings to cook popular foods.
4. Number buttons
Sets cooking times.
5. Power Level p.9
Sets power to level other than high.
6. Clock p.7
Sets current time.
7. Pause/Cancel p.7
Presstopauseovenorcorrectamistake.
8. Start
Press to start cooking.
tz_[W~iThhUGGwG]GG{SGtGY^SGYWWZGG[aYXGwt
7
Operation
Setting the Clock
1 Press the Clock button. The display will show:
If the display does not shows “Kg”, you will need to unplug the
microwave and then plug it in again in order to change to the weight
selection.
2 Use the Number buttons to enter the current time. You must press
at least three numbers to set the clock. If the current time is 5:00
enter, 5,0,0:
3 Press Clock again. A colon will appear, indicating that the time is
set.
If there is a power interruption, you will need to reset the clock.
You can check the current time while cooking is in progress by pressing
the
Clock button.
Using the Pause/Cancel Button
The
Pause/Cancel
button allows you to clear instructions you have
entered. It also allows you to pause the oven’s cooking cycle, so that you
can check the food.
• To pause the oven during cooking: press
Pause/Cancel
once. To
restart, press
Start
.
• To stop cooking, erase instructions, and return the oven display to the
time of day: press
Pause/Cancel
twice.
• To Correct a mistake you have just entered: press
Pause/Cancel
once,
then re-enter the instructions.
Using the One Minute+ Button
This button offers a convenient way to heat food in one-minute increments
at the High power level.
1 Press the One Minute+ button once for each minute you wish to cook
the food. For example, press it twice for two minutes. The time will
display, and the oven starts automatically.
Add minutes to a program in progress by pressing the
One Minute+
button for each minute you want to add.
Defrosting
The defrost setting is designed for speedy thawing of frozen food and is one
great advantage of the microwave oven. (Power level of 30% is
automatically set for defrosting)
1 Press the Defrost button. The display shows “ PL:30”.
2 Press the Number buttons to enter the desired defrosting time.
3 Press the Start button to begin defrosting.
• See page 14 for the Defrosting Guide.
tz_[W~iThhUGGwG^GG{SGtGY^SGYWWZGG[aYXGwt
8
Operation
Using the Instant Cook Buttons
1 Press the Instant Cook button corresponding to the food you are
cooking (Popcorn, for example). The display shows the first serving
size:
2 Press the button repeatedly to select the serving size you want.
The display will cycle through all available serving sizes. Once you
select the correct serving size, the microwave will begin cooking
automatically.
Instant Cook Chart
Note
The cooking time of 3.0 oz. microwave-popcorn depends on the
contents of butter and brands. Cooking time is adjustable for desired
taste with numeric pads following package instructions.
Item Weight Remarks
Popcorn
3.5 oz
3.0-3.5 oz
• Use one microwave-only bag of popcorn.
• Use caution when removing and opening hot
bag from oven
• To help prevent the popcorn bag from getting
stuck in the oven, fold each end of the bag up
one inch ( ) before placing the bag in the
center of the oven.
• If it still gets stuck, open the door and
reposition the bag, close the door and press
start.
Fresh
Vegetable
1 cup
2 cups
3 cups
4 cups
• Place the vegetableinto a casserole and add
some water.
• Cover during cooking and stir before
standing.
Frozen
Dinner
7-10 oz
10-12 oz
• Remove package from outerwrapping and
follow package instructions for covering and
standing. After cooking, let stand 1-3 min.
Potato
1EA
2EA
3EA
4EA
• Prick each potato several times with fork.
• Place on turntable in spoke-like fashion.
• Remove from oven, wrap in foil and let stand
3-5 min.
• Once during cooking, the oven will beep to let
you know to turn the food over.
Boil Water
½cup
1 cup
2 cups
• Measure liquid; pour into microwave-safe
container that is 2 times larger than amount
of liquid. Example: For 1 cup liquid use a 2
cup or larger dish.
• Stir well before and after heating to prevent
erupting.
Pizza
Reheat
1Slice
2Slices
3Slices
• Putthepizzaonamicrowave-safeplatewith
wide end of slice towards the outside edge of
the plate.
• Do not let slices overlap. Do not cover.
• Before serving, let stand 1-2 min.
tz_[W~iThhUGGwG_GG{SGtGY^SGYWWZGG[aYXGwt
9
Cooking Instructions
Setting Cooking Times & Power Levels
The power level lets you control the heating intensity from Warm to High
with the
Power Level
button.
1 Press the Power Level button. The power level is automatically set to
high. If you want to set the power level to something other than High,
press the
Power Level button repeatedly.
2 Press the Number buttons sequentially to enter the desired
cooking time.
3 Press the Start button to begin cooking. If you want to change the
power level, press Pause/Cancel before you press Start, and re-
enter all of the instructions.
You can check the Power Level while cooking is in progress by
pressing the
Power Level button.
Cooking Utensils
Recommended Use
•
Glass and glass-ceramic bowls and dishes
— Use for heating or
cooking.
•
Microwave browning dish
— Use to brown the exterior of small items
such as steaks, chops, or pancakes. Follow the directions provided with
your browning dish.
•
Microwavable plastic wrap
— Use to retain steam. Leave a small
opening for some steam to escape and avoid placing it directly on the
food.
•
Wax paper
— Use as a cover to prevent spattering.
•
Paper towels and napkins
— Use forshort-term heating and covering;
they absorb excess moisture and prevent spattering. Do not use recycled
paper towels, which may contain metal and can catch fire.
•
Paper plates and cups
— Use for short-term heating at low
temperatures. Do not use recycled paper, which may contain metal and
can catch fire.
•
Thermometers
— Use only those labeled “Microwave Safe” and follow
all directions. Check the food in several places. Conventional
thermometers may be used once the food has been removed from the
oven.
Pad Touch Display Output
Power
Level
Once PL:Hi 800W
Twice PL:90 720W
3Times PL:80 640W
4Times PL:70 560W
5Times PL:60 480W
7Times PL:50 400W
6Times PL:40 320W
8Times PL:30 240W
9Times PL:20 160W
10 Times PL:10 80W
tz_[W~iThhUGGwG`GG{SGtGY^SGYWWZGG[aYXGwt
10
Cooking Instructions
Limited Use
•
Aluminum foil
— Use narrow strips of foil to prevent overcooking of
exposed areas. Using too much foil can damage your oven, so be
careful.
•
Ceramic, porcelain, and stoneware
— Use these if they are labeled
“Microwave Safe.” If they are not labeled, test them to make sure they
can be used safely. Never use dishes with metallic trim.
•
Plastic
— Use only if labeled “Microwave Safe.” Other plastics can melt.
•
Straw, wicker, and wood
— Use only for short-term heating, as they
can be flammable.
Metal utensils
— These can damage your oven. Remove all metal before
cooking.
Not Recommended
•
Glass jars and bottles
— Regular glass is too thin to be used in a
microwave, and can shatter.
•
Paper bags
— These are a fire hazard, except for popcorn bags that are
designed for microwave use.
•
Styrofoam plates and cups
— These can melt and leave an
unhealthy residue on food.
•
Plastic storage and food containers
— Containers such as
margarine tubs can melt in the microwave.
Testing Utensils
If you are not sure whether a dish is microwave-safe or not, you can perform
this test:
1 Fill one measuring cup with water and put it inside your oven, next to
thedishyouwanttotest.
2 Press the One Minute+ button once to heat them for one minute at
High power.
The water should be warm and the dish you are testing should be cool. If the
dish is warm, then it is absorbing microwave energy and is not acceptable
for use in the microwave.
tz_[W~iThhUGGwGXWGG{SGtGY^SGYWWZGG[aYXGwt
11
Cooking Instructions
Cooking Techniques
Stirring
Stir foods such as casseroles and vegetables while cooking to distribute
heat evenly. Food at the outside of the dish absorbs more energy and heats
more quickly, so stir from the outside to the center. The oven will turn off
when you open the door to stir your food.
Arrangement
Arrange unevenly shaped foods, such as chicken pieces or chops, with the
thicker, meatier parts toward the outside of the turntable where they receive
more microwave energy. To prevent overcooking, place thin or delicate
parts toward the center of the turntable.
Shielding
Shield food with narrow strips of aluminum foil to prevent overcooking.
Areas that need shielding include poultry wing-tips, the ends of poultry legs,
and corners of square baking dishes. Use only small amounts of aluminum
foil. Larger amounts can damage your oven.
Turning
Turn foods over midway through cooking to expose all parts to microwave
energy. This is especially important with large items such as roasts.
Standing
Foods cooked in the microwave build up internal heat and continue to cook
for a few minutes after the oven stops. Let foods stand to complete cooking,
especially foods such as roasts and whole vegetables. Roasts need this
time to complete cooking in the center without overcooking the outer areas.
All liquids, such as soup or hot chocolate, should be shaken or stirred when
cooking is complete. Let liquids stand a moment before serving. When
heating baby food, stir well and test the temperature before serving.
Adding Moisture
Microwave energy is attracted to water molecules. Food that is uneven in
moisture content should be covered or allowed to stand so that the heat
disperses evenly. Add a small amount of water to dry food to help it cook.
General Tips
• Dense foods, such as potatoes, take longer to heat than lighter foods.
Foods with a delicate texture should be heated at a low power level to
avoid becoming tough.
• Altitude and the type of cookware you are using can affect cooking time.
When using a new recipe, use the minimum cooking time and check the
food occasionally to prevent overcooking.
• Foods with a non-porous skin or shell, such as potatoes, eggs, or hot
dogs, should be pierced to prevent bursting.
• Frying with heating oil or fat is not recommended. Fat and oil can
suddenly boil over and cause severe burns.
• Some ingredients heat faster than others. For example, the jelly inside a
jelly doughnut will be hotter than the dough. Keep this in mind to avoid
burns.
• Home canning in the microwave oven is not recommended because all
harmful bacteria may not be destroyed by the microwave heating
process.
Although microwaves do not heat thecookware, the heat is often transferred
to the cookware. Always use pot holders when removing food from the
microwave and instruct children to do the same.
tz_[W~iThhUGGwGXXGG{SGtGY^SGYWWZGG[aYXGwt
12
Cooking Instructions
Cooking Guide
GUIDE for Cooking Meat in Your Microwave
• Place meat on a microwave-safe roasting rack in a microwave-safe dish.
• Start meat fat-side down. Use narrow strips of aluminum foil to shield any
bone tips or thin meat areas.
• Check the temperature inseveral placesbefore letting the meat stand the
recommended time.
• The following temperatures are removal temperatures. The temperature
of the food will rise during the standing time.
GUIDE for Cooking Poultry in Your Microwave
• Place poultry on a microwave-safe roasting rack in a microwave-safe
dish.
• Cover poultry with wax paper to prevent spattering.
• Use aluminum foil to shield bone tips, thin meat areas, or areas that start
to overcook.
• Check the temperature in several places before letting the poultry stand
the recommended time.
Food Cook Time/Power Level Directions
Roast Beef
Boneless
Upto4lbs.
Cooking Time:
7-10 min. / lb. for 115° F - Rare
8-11 min. / lb. for 120° F - Medium
9-14 min. / lb. for 145° F - Well Done
Power Level:
High(Hi) for first 5
min., then Medium(50).
Place roast fat-side
down on roasting rack.
Cover with wax paper.
Turn over when
cooking time is half up.
Let stand 10 min.
Pork
Boneless
or bone-in
Upto4lbs.
Cooking Time:
8-12 min. / lb. for 160° F Well Done
Power Level:
High(Hi) for first 5
min., then Medium(50).
Place roast fat-side
down on roasting rack.
Cover with vented
plastic wrap. Turn over
when cooking time is
half up. Let stand 10
min.
Bacon
2-6 slices
Cooking Time:
2slices:1½-2min.
4 slices: 2½- 3½ min.
6 slices: 4-5½ min.
Power Level:
High(Hi).
Arrange slices on
roasting rack or a dish
lined with paper-towel.
Cover with paper towel.
Microwave until crisp.
Food Cook Time/Power Level Directions
Whole
Chicken
Up to 4
lbs.
Cooking Time:
8-11 min. / lb. 170° -180°F
Power Level:
High(Hi).
Place chicken breast-side down
on roasting rack. Cover with wax
paper. Turn over when cooking
time is half up. Cook until juices
run clear and meat near the bone
is no longer pink. Let stand 5-10
min.
Chicken
Pieces
Up to 2
lbs.
Cooking Time:
6-9 min. / lb.
180°F dark meat
170°F light meat
Power Level:
High(Hi).
Place chicken bone-side down on
dish, with the thickest portions
towards the outside of the dish.
Cover with wax paper. Turn over
when cooking time is half up.
Cook until juices run clear and
meat near the bone is no longer
pink. Let stand 5-10 min.
tz_[W~iThhUGGwGXYGG{SGtGY^SGYWWZGG[aYXGwt
13
Cooking Instructions
Guide for Cooking Seafood in Your Microwave
• Cook fish until it flakes easily with a fork.
• Place fish on a microwave-safe roasting rack in a microwave-safe dish.
• Use a tight cover to steam fish. A lighter cover of wax paper or paper
towel provides less steaming.
• Do not overcook fish; check it at minimum cooking time.
Guide for Cooking Eggs in Your Microwave
• Never cook eggs in the shell, and never warm hard-cooked eggs in the
shell; they can explode.
• Always pierce whole eggs to keep them from bursting.
• Cook eggs just until set; they become tough if overcooked.
Guide for Cooking Vegetables in Your Microwave
• Vegetables should be washed just before cooking. Often, no extra water
is needed. If dense vegetables such as potatoes, carrots and green
beans are being cooked, add about ¼ cup water.
• Small vegetables (sliced carrots, peas, lima beans, etc.) will cook faster
than larger ones.
• Whole vegetables, such as potatoes, acorn squash or corn on the cob,
should be arranged in a circle on the turntable before cooking. They will
cook more evenly if turned over after half the cooking time.
• Always place vegetables like asparagus and broccoli with the stem ends
pointing towards the edge of the dish and the tips toward the center.
• When cooking cut vegetables, always cover the dish with a lid or vented
microwavable plastic wrap.
• Whole, unpeeled vegetables such as potatoes, squash, eggplant, etc.,
should have their skin pricked in several spots before cooking to prevent
them from bursting.
• For more even cooking, stir or rearrange whole vegetables halfway
through the cooking time.
• Generally, the denser the food, the longer the standing time. (Standing
time refers to the time necessary for dense, large foods and vegetables
to finish cooking after they come out of the oven.) A baked potato can
stand on the counter for five minutes before cooking is completed, while a
dish of peas can be served immediately.
Food Cook Time/Power Level Directions
Steaks
Up to 1.5
lbs.
Cooking Time:
6-9 min. / lb.
Power Level:
Medium-
High(70).
Arrange steaks on roasting rack
with meaty portions towards the
outside of rack. Cover with wax
paper. Turn over and rearrange
when cooking time is half up.
Cook until fish flakes easily with a
fork. Let stand 3-5 min.
Fillets
Up to 1.5
lbs.
Cooking Time:
3-7 min. / lb
Power Level:
High(Hi).
Arrange fillets in a baking dish,
turning any thin pieces under.
Cover with wax paper. If over 1/2
inch thick, turnover and rearrange
when cooking time is half up.
Cook until fish flakes easily with a
fork. Let stand 2-3 min.
Shrimp
Up to 1.5
lbs.
Cooking Time:
3-6 min. / lb.
Power Level:
High(Hi).
Arrangeshrimpinabakingdish
without overlapping or layering.
Cover with wax paper. Cook until
firm and opaque, stirring 2 or 3
times. Let stand 5 min.
tz_[W~iThhUGGwGXZGG{SGtGY^SGYWWZGG[aYXGwt
14
Cooking Instructions
Defrosting Guide
• Unwrap food. Place food on microwave-safe rack, plate or shallow dish.
• After first half of defrosting time: remove any remaining wrap, break food
apart or separate pieces if possible, remove any thawed food, if possible,
shield tips, thin meat or warm areas of food with foil.
• When defrosted, food should be cool, but softened in all areas. If still
slightly icy, return to microwave oven very briefly, or let stand a few
minutes.
• Poultry and fish may be placed under running cool water until defrosted.
Food
Microwave Time at
Defrost Level
Procedure
Beef
Chuck
Roast
up to 5 lbs
Steaks
up to 5 lbs
Ground
Beef
up to 3 lbs
Microwave Time:
7-9 min / lb
Let Stand: 5-10 min.
Microwave Time:
6-9 min / lb
Let Stand: 5-10 min
Microwave Time:
8-10 min / lb
Let Stand: 5-10 min.
Place on plate or rack. Microwave until a
wooden pick can be easily inserted in
center. Turn over twice. Place onplate or
rack. Microwave until pliable, then
separate steaks and rearrange. Turn
over twice. Place on plate or rack.
Microwave until pliable, then break apart
and remove defrosted portions at
halftime. Turn over twice.
Pork
Spareribs
up to 3 lbs
Pork
Chops
up to 3 lbs
Microwave Time: 6-
8min/lb
Let Stand: 5-10 min.
Microwave Time: 6-
8min/lb
Let Stand: 5-10 min.
Place on plate or rack. Microwave until
pliable, then separate and rearrange.
Turn over twice.
Place on plate or rack. Microwave until
pliable, then separate and rearrange.
Turn over twice.
Poultry
Whole
Chicken
up to 5 lbs
Pieces
up to 2 lbs
Microwave Time: 7-
9min/lb
Let Stand: 5-10 min.
Microwave Time: 9-
11 min / lb
LetStand:5-10 min.
Place on plate or rack. Microwave until
pliable, then break apart and rearrange
portions at half time. Rinse cavity with
cool water. Remove giblets.
Place on plate or rack. Microwave until
pliable, then break apart and rearrange
portions at half time.
Seafood
Steaks
up to 3-5
lbs
Fillets
up to 3-5
lbs
Shrimp
up to 3 lbs
Microwave Time:
6-9 min / lb
Let Stand: 5-10
min.
Microwave Time:
4-7 min / lb
Let Stand: 5-10
min.
Microwave Time:
4-7 min / lb
Let Stand: 5-10
min.
Placeon plate or rack. MIcrowave until a
wooden pick can be easily inserted in
center, break apart and rearrange at half
time.
Place on plate or rack. Microwave until a
wooden pick can be easily inserted in
center, break apart and rearrange at half
time.
Place on plate or rack. Microwave until
pliable, then separate and rearrange at
half time.
Food
Microwave Time at
Defrost Level
Procedure
tz_[W~iThhUGGwGX[GG{SGtGY^SGYWWZGG[aYXGwt
15
Cooking Instructions
Recipes
Beef and Barley Stew
1½ lbs. beef stew cubes, cut into ½-inch pieces
½ cup chopped onion
2 Tbs. all-purpose flour
1 Tbs Worcestershire sauce
1 can (13.75-14.5 oz.) beef broth
2 medium carrots, cut into ½-inch slices (about 1 cup)
½ cup barley
1 bay leaf
¼ tsp. pepper
1 pkg. (9-10 oz.) frozen peas, thawed
1. In a 2-quart casserole, combine beef, onion, flour, and Worcestershire;
mix well. Cover with lid. Cook at High for 6 to 8 minutes until beef is no
longer pink, stirring once.
2. Stir in beef broth, carrots, barley, bay leaf, and pepper. Cover with lid.
Cook at Medium for 45 to 50 minutes until carrots and beef are tender,
stirring2to3times.
3. Stir in peas. Cover with lid. Cook at Medium for 10 minutes. Let stand for
10 minutes. Remove bay leaf before serving.
Makes 6 servings.
Broccoli and Cheese Casserole
¼ cup butter or margarine
¼ cup chopped onion
1½ Tbs. flour
½ tsp. salt
¼ tsp. dry mustard
1
/
8
tsp. pepper
1½ cups milk
¼ cup chopped red pepper
8 oz. (2 cups) cheddar cheese, shredded
1 pkg. (9-10 oz.) frozen chopped broccoli, thawed
4 cups cooked spiral shaped pasta (8 oz. dry)
1. In a 2-quart casserole, cook butter and onion at High for 2 to 3 minutes
until onion is soft, stirring once.
2. Add flour, salt, mustard, and pepper; mix well. Cook at High for 60 to 90
seconds until mixture boils. Stir in milk until smooth.
3. Stir in red pepper. Cook at High for 2 to 3 minutes until mixture boils and
thickens slightly, stirring twice. Stir in cheese until melted.
4. Add broccoli and pasta, mix well. Cover with lid. Cook at High for 4 to 6
minutes until heated through, stirring once. Stir before serving.
Makes 6
servings.
Warm Potato Salad
2 lbs. small red potatoes, cut into ½-inch pieces
4 slices bacon (uncooked), cut into ½-inch pieces
¼ cup chopped onion
2 tsp. sugar
1 tsp. salt
1 tsp. flour
½ tsp. celery seed
1
/
8
tsp. pepper
2½ Tbs. apple cider vinegar
1. In a 2-quart casserole, combine potatoes and ¼ cup water. Cover with
lid. Cook at High until potatoes are tender (10-12 min.); stir twice. Drain
and set aside to cool slightly.
2. In a medium bowl, cook bacon at High until crisp (3-5 min.); stir once.
Place bacon on a paper towel. Reserve 1 Tbs. drippings.
3. Combine drippings and onion. Cover with plastic wrap; turn back a
corner to vent steam. Cook at High until tender (3-4 min.); stir once.
4. Stir in sugar, salt, flour, celery seed, and pepper. Cook at High until
mixture boils (30-40 sec.). Stir in vinegar and ½ cup water. Cook at High
until liquid boils and thickens slightly (1-2 min.); stir once. Add bacon to
dressing. Pour dressing over potatoes. Stir well.
Makes 6 servings.
Black Bean Soup
1 cup chopped onion
1 clove garlic, minced
2 cans (15 oz. each) black beans, drained
1 can (14-16 oz.) stewed tomatoes, chopped
1 can (13.75-14.5 oz.) chicken broth
1 can (7-8.5 oz.) corn
1 can (4 oz.) chopped green chilies
1-2 tsp. ground cumin, or to taste
1. Place onion and garlic in a 3-quart casserole. Cover with lid. Cook at
High for 3 to 5 minutes until tender.
2. Add one can of beans, mash beans with a fork. Add remaining
ingredients; mix well.
3. Cook uncovered, at High for 10 minutes; stir. Reduce power to Medium
and cook for 5 minutes. Stir before serving.
Makes about 2 quarts.
tz_[W~iThhUGGwGX\GG{SGtGY^SGYWWZGG[aYXGwt
16
Appendix
Troubleshooting Guide
Before you call a repair person for your oven, check this list of possible
problems and solutions.
Neither the oven’s display nor the oven operate.
• Properly insert the plug into a grounded outlet.
• If the outlet is controlled by a wall switch, make sure the wall switch is
turned on.
• Remove the plug from the outlet, wait ten seconds, then plug it in again.
• Reset the circuit breaker or replace any blown fuse.
• Plug another appliance into the outlet; if the other appliance doesn’t work,
have a qualified electrician repair the outlet.
• Plug the oven into a different outlet.
The oven’s display works, but the power won’t come on.
• Make sure the door is closed securely.
• Check to see if packing material or other material is stuck to the door
seal.
• Check for door damage.
• Press Cancel twice and re-enter all cooking instructions.
The power goes off before the set time has elapsed.
• If there has not been a power outage, remove the plug from the outlet,
wait ten seconds, then plug it in again. If there was a power outage, the
time indicator will display
“”
Reset the clock and any cooking
instructions.
• Reset the circuit breaker or replace any blown fuse.
The food is cooking too slowly.
• Make sure the oven is on its own 15 amp circuit line. Operating another
appliance on the same circuit can cause a voltage drop. If necessary,
movetheoventoitsowncircuit.
You see sparks or arcing.
• Remove any metallic utensils, cookware, or metal ties. If using foil, use
only narrow strips and allow at least one inch between the foil and interior
oven walls.
The turntable makes noises or sticks.
• Clean the turntable, roller ring and oven floor.
• Make sure the turntable and roller ring are positioned correctly.
Using your microwave causes TV or radio interference.
• This is similar to the interference caused by other small appliances, such
as hair dryers. Move your microwave further away from other appliances,
like your TV or radio.
Care and Cleaning
Follow these instructions to clean and care for your oven.
• Keep the inside of the oven clean. Food particles and spilled liquids can
stick to the oven walls, causing the oven to work less efficiently.
• Wipe up spills immediately. Use a damp cloth and mild soap. Do not use
harsh detergents or abrasives.
• To help loosen baked on food particles or liquids, heat two cups of water
(add the juice of one lemon if you desire to keep the oven fresh) in a four-
cup measuring glass at High power for five minutes or until boiling. Let
stand in the oven for one or two minutes.
• Remove the glass tray from the oven when cleaning the oven or tray. To
prevent the tray from breaking, handle it carefully and do not put it in
water immediately after cooking. Wash the tray carefully in warm sudsy
water or in the dishwasher.
• Clean the outside surface of the oven with soap and a damp cloth. Dry
with a soft cloth. To prevent damage to the operating parts of the oven,
don’t let water seep into the openings.
• Wash the door window with very mild soap and water. Be sure to use a
soft cloth to avoid scratching.
• If steam accumulates inside or outside the oven door, wipe with a soft
cloth. Steam can accumulate when operating the oven in high humidity
and in no way indicates microwave leakage.
• Never operate the oven without food in it; this can damage the magnetron
tube or glasstray. You may wish to leave a cup of water in the oven when
it is not in use to prevent damage if the oven is accidentally turned on.
If you have a problem you cannot solve,
please call our service line:
1-800-SAMSUNG (1-800-726-7864)
tz_[W~iThhUGGwGX]GG{SGtGY^SGYWWZGG[aYXGwt
17
Appendix
Specifications
Warranty
Warranty Information
SAMSUNG MICROWAVE OVEN
This SAMSUNG brand product, as supplied and distributed by SAMSUNG
ELECTRONICS AMERICA, INC. (SAMSUNG) and delivered new, in the
original carton to the original consumer purchaser, is warranted by
SAMSUNG against manufacturing defects in materials and workmanship for
a limited warranty period of:
One (1) Year Parts and Labor, Eight (8) Years Parts Warranty for Magnetron
This limited warranty begins on the original date of purchase, and is valid
only on products purchased and used in the United States. To receive
warranty service, the purchaser must contact SAMSUNG for problem
determination and service procedures. Warranty service can only be
performed by aSAMSUNG authorized service center. The original datedbill
of sale must be presented upon request as proof of purchase to SAMSUNG
or SAMSUNG’s authorized service center. Transportation of the product to
and from the service center is the responsibility of the purchaser.
SAMSUNG will repair or replace this product, at our option and at no charge
as stipulated herein, with new or reconditioned parts or products if found to
be defective during the limited warranty period specified above. All replaced
parts and products become the property of SAMSUNG and must be
returned to SAMSUNG. Replacement parts and products assume the
remaining original warranty, or ninety (90) days, whichever is longer.
This limited warranty covers manufacturing defects in materials and
workmanship encountered in normal, non-commercial use of this product
and shall not apply to the following, including, but not limited to: damage
which occurs in shipment; delivery and installation; applications and uses for
which this product was not intended; altered product or serial numbers;
cosmetic damage or exterior finish; accidents, abuse, neglect, fire, water,
lightning or other acts of nature; use of products, equipment, systems,
utilities, services, parts, supplies, accessories, applications, installations,
repairs, external wiring or connectors not supplied or authorized by
SAMSUNG which damage this product or result in service problems;
incorrect electrical line voltage, fluctuations and surges; customer
adjustments and failure to follow operating instructions, cleaning,
maintenance and environmental instructions that are covered and
prescribed in the instruction book; product removal and reinstallation;
problems caused by pest infestations, and overheating or overcooking by
user; glass tray or turntable; reduced magnetron power
output related to
normal aging. SAMSUNG does not warrant uninterrupted or error-free
operation of the product.
Model Number MW840WC/BC/CC
Oven Cavity 0.8cuft
Controls 10 power levels, including defrost
Timer 99 minutes, 99 seconds
Power Source 120 VAC, 60 Hz
Power Output 800 Watts
Outside Dimensions 19
1/4
”(W) X 10
13/16
”(H) X 13
13/16
”(D)
Oven Cavity Dimensions 13(W) X 7
29/32
”(H) X 12
15/16
”(D)
Net/Gross Weight 26.5/28.5 lbs
tz_[W~iThhUGGwGX^GG{SGtGY^SGYWWZGG[aYXGwt
18
Warranty
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED
AND DESCRIBED ABOVE, AND NO WARRANTIES WHETHER EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS
WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS
WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR
CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE
BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS
OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR
OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR
INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL
THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR
SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN
AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY
SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT
LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND
LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND
PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY
ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS
PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE
NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT
EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF
THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR
EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts,
or the exclusion or limitation of incidental or consequential damages, so the
above limitations or exclusions may not apply to you. This warranty gives
you specific legal rights, and you may also have other rights which vary from
state to state.
To obtain warranty service, please contact:
SAMSUNG ELECTRONICS
AMERICA, INC. - WWW.SAMSUNGUSA.COM
SAMSUNG CUSTOMER SERVICE 400
VALLEY ROAD, SUITE 201, MT. ARLINGTON, NJ 07856
Tel: 973-601-6000, Fax: 973-601-6001
1-800-SAMSUNG (1-800-726-7864)
WWW.SAMSUNGSUPPORT.COM
SAMSUNG ELECTRONICS
Subject to the requirements, conditions, exclusions and limitations of the
Original Limited Warranty supplied with Samsung Electronics (SAMSUNG)
products, and the requirements, conditions, exclusions and limitations
contained herein, SAMSUNG will additionally provide Warranty Repair
Service in the United States on SAMSUNG products purchased in Canada,
and in Canada on SAMSUNG products purchased in the United States, for
the warranty period originally specified, and to the Original Purchaser only.
The above described warranty repairs must be performed by a SAMSUNG
Authorized Service Center. Along with this Statement, the Original Limited
Warranty Statement and a dated Bill of Sale as Proof of Purchase must be
presented to the Service Center. Transportation to and from the Service
Center is the responsibility of the purchaser.
Conditions covered are limited only to manufacturing defects in material or
workmanship, and only those encountered in normal use of the product.
Excluded, but not limited to, are any original specified provisions for, in-
home or on-site services, minimum or maximum repair times, exchanges or
replacements, accessories, options, upgrades, or consumables.
For the locations of a SAMSUNG Authorized Service Center in the United
States and Canada, please contact SAMSUNG at:
1-800-SAMSUNG (1-800-726-7864)
Or on-line at:
WWW.SAMSUNGUSA.COM and WWW.SAMSUNGCANADA.COM
tz_[W~iThhUGGwGX_GG{SGtGY^SGYWWZGG[aYXGwt
19
Note
tz_[W~iThhUGGwGX`GG{SGtGY^SGYWWZGG[aYXGwt
20
Note
tz_[W~iThhUGGwGYWGG{SGtGY^SGYWWZGG[aYXGwt
21
Note
tz_[W~iThhUGGwGYXGG{SGtGY^SGYWWZGG[aYXGwt
22
Note
tz_[W~iThhUGGwGYYGG{SGtGY^SGYWWZGG[aYXGwt
23
Guía Rápida Quick Reference
Feature Operation
Programar el Reloj 1. Presione CLOCK.
1. Use los botones numéricos para
ingresar la hora del día.
1. Presione nuevamente CLOCK.
Cocinando con Un Minuto
Más
1. Presione el botón ONE MINUTE + una
vez por cada minuto de cocción.
1. Se mostrará el tiempo en la pantalla y
el horno comenzará.
Botones Cocción
Instantánea
1. Presione el botón que corresponda al
alimento que va a cocinar. (Por
ejemplo POPCORN).
1. Presione repetidamente el botón para
seleccionar la porción.
Descongelar 1. Presione DEFROST.
1. Presione en secuencia los botones
numéricos (del 0 al 9) para ingresar el
tiempo deseado de descongelado.
1. Presione START.
Para programar el Tiempo
de Cocción y los Niveles
de Potencia
1. Presione el botón POWER LEVEL. Si
usted desea programar un nivel de
potencia diferente a ALTO, entonces
presione repetidamente el botón
POWER LEVEL.
1. Use los botones numéricos para
programar el tiempo de cocción.
1. Presione START para comenzar a
cocinar.
Feature Operation
Set Clock 1. Press CLOCK.
2. Use the Number buttons to enter the
current time.
3. Press CLOCK again.
One Minute+ Cooking 1. Press the ONE MINUTE + button once
for each minute of cooking.
2. The time will display and the oven will
start.
Instant Cook Buttons 1. Press button that corresponds to the
food you are cooking (for example,
POPCORN).
2. Press the button repeatedly to select
serving size.
Defrost 1. Press DEFROST.
2. Press the buttons(0-9) sequentially to
enter the desired defrosting time.
3. Press START.
Set Cooking Time and
Power Levels
1. Press the POWER LEVEL button. If
you wnat to set the power level to
something other than High, press the
POWER LEVEL button repeatedly.
2. Use NUMBER buttons to set cooking
time.
3. Press START to begin cooking.
tz_[W~iThhUGGwGYZGG{SGtGY^SGYWWZGG[aYXGwt
ELECTRONICS
SAMSUNG ELECTRONICS AMERICA, INC.
HEADQUARTERS
105 CHALLENGER ROAD
RIDGEFIELD PARK, NEW JERSEY 07660-0511
Samsung Electronics Co., Ltd.
PrintedinMalaysia
tz_[W~iThhUGGwGY[GG{SGtGY^SGYWWZGG[aYXGwt
