User Manual
1
Declaration of Conformity
Responsible Party: JK Imaging Ltd.
Address: JK Imaging Ltd., 17239 South Main Street, Gardena, CA 90248, USA
JK Imaging Europe, 71 Clarendon road, Watford, WD17 1DS, UK
Company website: www.kodakpixpro.com
For Customers in the U.S.A.
Tested to Comply with FCC Standards FOR HOME OR OFFICE USE
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
For Customers in Europe
"CE" mark indicates that this product complies with the European requirements for safety, health, environment and
customer protection. "CE" marked cameras are intended for sales in Europe.
This symbol [crossed-out wheel bin WEEE Annex IV] indicates separate collection of electrical waste and electronic
equipment in the European countries. Please do not throw the equipment into domestic refuse. Please use the return
and collection systems available in your country for proper, safe disposal of this product.
BEFORE YOU START
2
About this Manual
Thank you for purchasing this KODAK PIXPRO digital camera. Please read this manual carefully and keep it in a safe
place for future reference.
JK Imaging Ltd. reserves all rights of this document. No part of this published manual may be reproduced, transmitted,
transcribed, stored in a retrieval system or translated into any language or computer language, in any form, by any
means, without the prior written permission of JK Imaging Ltd..
All trademarks mentioned in this manual are used for identification purposes only and are properties of their
respective owners.
This manual will instruct you on how to operate the KODAK PIXPRO digital camera. JK Imaging Ltd. has tried its
utmost to ensure the correctness of the user manual contents, but reserves the right to modify as necessary. All of
these contents are subject to change without prior notice.
Throughout this manual, the following symbols are used to help you locate information quickly and easily:
Indicates useful information.
In the instructions below, the following symbols may be used throughout this manual on how to operate the camera.
This is to facilitate better understanding.
「Item properties」： The optional properties in the camera interface are indicated by the symbol「 」.
3
SAFETY NOTES
Safety notes for this camera
Do not drop the camera or allow it to hit solid objects.
Do not attempt to disassemble or repair the camera.
Do not use or store the camera in dusty places or on
a beach to prevent dust or sand from entering the
camera, causing possible damage to it.
Do not use or store the camera in a hot environment
or under direct sunlight.
Do not use or store the camera near a powerful
magnetic field, for example near a magnet or
transformer.
Avoid touching the lens of the camera.
Do not expose the camera to direct sunlight for a long
period of time.
To prevent the camera from being damaged by
moisture, do not use or store the camera in very
humid environments, such as in rain or near bodies of
water.
If water accidentally comes in contact with the
camera, turn the camera off, remove the battery and
the memory card, and dry it within 24 hours.
When you take the camera from a cold place to a
warmer environment, condensation may occur. Please
wait for a reasonable period of time before you turn it
on.
Before you remove the battery and memory card, the
camera should be turned off.
When you clean the body of the camera, do not use
abrasive, alcohol-based or organic cleaner.
Use a professional lens wiping cloth and dedicated
cleaner to wipe and clean the lens.
Download your photos and remove the memory card
when you are going to store the camera for a long
period of time.
If this camera is not in use for a long time, please keep
it in a dry and clean condition.
Our company will not pay compensation for any
failure of playback of pictures or videos caused by
improper operation.
4
Safety notes for battery
Please use a battery that is the same type as the one
included.
Please use the attached charger to charge the battery.
If battery fluid leaks inside the camera, contact our
customer service department. If battery fluid leaks
onto your skin, rinse your skin with clean water and
seek immediate medical attention.
Disposal of used batteries should be carried out
in accordance with the local (national or regional)
regulations.
To prevent the battery from being damaged, do not
drop the battery or allow it to hit solid objects or to be
scratched by the objects.
Do not let the battery come in contact with metal
objects (including coins) to avoid short circuiting,
discharging, excessive heat, or possible leakage.
Do not attempt to disassemble the battery.
Do not expose the battery to water. Always keep the
battery contacts dry.
Do not heat the battery or throw it into a fire to avoid
a possible explosion.
Do not store the battery in a hot environment or in
direct sunlight.
If the battery overheats during charging or use, stop
charging or use immediately. Turn off the product,
remove the battery carefully, and wait until it cools
down.
When the camera is stored for a long period of time,
remove the battery and keep it in a dry place that is
not accessible to infants and children.
In a colder environment, the performance of the
battery could be noticeably reduced.
When you install the battery, install it according to
the positive and negative markings on the battery
compartment. Never force it into the battery
compartment.
5
Safety notes for memory card
We suggest buying only well-known, name brand
memory cards to ensure peak performance.
Format the memory card using the camera before you
use it or insert a new one.
Do not drop the memory card or allow it to hit solid
objects to avoid damaging it.
Do not attempt to disassemble or repair the memory
card.
Do not expose the memory card to water. Always
keep it dry.
Do not remove the memory card when the camera
is turned on. Otherwise, the memory card could be
damaged.
Do not directly edit the data on the memory card.
Copy the data to your PC before you edit them.
When the camera is stored for a long period of time,
be sure to download your photos and remove the
memory card. Store it in a dry environment.
Do not modify the name of the files or folders of the
memory card using your PC. Modifying the file names
may cause the files to not be recognized on the
camera or a possible error may occur.
A photo taken with the camera will be stored in the
folder that is automatically generated on the memory
card. Do not store photos that are not taken using this
camera in these folders as the pictures cannot be
recognized during the playback.
When you insert a memory card, make sure the notch
of the card matches the markings on the top of the
card slot.
6
Other Safety Notes
Do not disconnect the power or turn the camera off during the update process. Doing so may cause incorrect data to
be written and the camera may not power on later.
Do not hang the neck strap of the camera around the neck of a child.
When using your camera on an airplane, observe the relevant rules specified by the airline.
Due to the limitations of manufacturing technology, the LCD may have a few dead or bright pixels. These pixels do no
effect the quality or performance of the camera, photos or video.
Do not expose the LCD to water. In a humid environment, only wipe it with a soft and dry cleaning cloth.
If the LCD is damaged and the liquid crystal comes into contact with your skin, wipe your skin with a dry cloth
immediately and rinse it with clean water. If liquid crystal comes into contact with your eyes, wash them with clean
water at least for 15 minutes and seek immediate medical attention. If you accidentally swallow liquid crystal, rinse
your mouth immediately and seek medical attention.
7
BEFORE YOU START ................................1
SAFETY NOTES .........................................3
CONTENTS .................................................7
GETTING READY ......................................11
Accessories Included .................................................... 11
Install neck strap ........................................................... 12
Part Names ..................................................................... 13
Installing Battery and Memory Card ......................... 15
Charging Battery............................................................ 17
Turning Camera On and Off ........................................ 18
How to take pictures ..................................................... 18
Set your Language, Date/Time .................................. 19
Set your Language, Date/Time after the first
power-on ................................................................. 19
Resetting your Language ...................................... 20
Resetting Date/Time ............................................ 21
MODE OVERVIEW ...................................22
Display Setting ............................................................... 22
LCD Screen Display ....................................................... 23
Overview of the Screen Icons in Photo
Shooting Mode ....................................................... 23
Overview of the Screen Icons in Movie Mode ... 25
Using the Mode Button ................................................ 26
Panorama Mode..................................................... 27
Scene Mode ............................................................ 28
Auto Scene Mode (ASCN) .................................. 31
BASIC OPERATION ...................................32
Using the Zoom Function ............................................. 32
Macro Mode ................................................................... 33
Self-timer Setting .......................................................... 34
Flash Mode ..................................................................... 35
EV Setting........................................................................ 36
Exposure Compensation ...................................... 36
CONTENTS
8
ISO ............................................................................ 37
Shutter Adjustment............................................... 37
Using Quick Recording ................................................. 38
PLAYBACK .................................................. 39
Overview of the Screen Icons in Playback Mode .... 39
Viewing Photos and Videos ......................................... 40
Thumbnail View ............................................................. 41
Using Zoom Playback (for still pictures only) ......... 42
Slideshow ........................................................................ 43
Photos and Video Deletion ......................................... 44
USING THE MENUS .................................45
Shooting Menu .............................................................. 45
Expo Metering ....................................................... 45
Image Size ............................................................... 46
OIS ............................................................................ 46
White Balance Setting .......................................... 47
Cont. AF ................................................................... 47
Focus Setting .......................................................... 48
Continuous Shot .................................................... 48
Color Effect ............................................................. 49
Shooting Setting Menu ................................................. 51
Quality ..................................................................... 51
AF Assist Beam ...................................................... 52
Digital Zoom ........................................................... 52
Date Imprint ........................................................... 53
Quick Review .......................................................... 53
Face Detection ....................................................... 54
Movie Menu ................................................................... 55
Expo Metering ........................................................ 55
Video Quality .......................................................... 56
OIS ............................................................................ 57
Color Effect ............................................................. 57
Movie Setting Menu ..................................................... 58
Digital Zoom ........................................................... 58
Playback Menu .............................................................. 59
9
HDR .......................................................................... 59
Red-Eye Reduction ................................................ 60
Rotate ....................................................................... 60
Resize ....................................................................... 61
Color Effect ............................................................. 61
Playback Setting Menu................................................. 62
Protect ...................................................................... 63
Delete ....................................................................... 63
DPOF (Digital Print Order Format) .................... 64
Trim ........................................................................... 64
Setup Menu .................................................................... 65
Sound Settings ....................................................... 66
Power Saver ............................................................ 66
Language ................................................................. 67
World Time ............................................................. 67
Date & Time ............................................................ 67
LCD Brightness ....................................................... 67
File Setting ...................................................................... 68
Format ...................................................................... 68
Copy to Card ........................................................... 69
File Numbering ....................................................... 69
Reset ......................................................................... 70
FW Version ............................................................. 70
CONNECTIONS ......................................... 71
Connecting to a Computer .......................................... 71
Setting the USB Mode .......................................... 71
Transferring files to your computer ................... 72
Connecting to a PictBridge Compatible Printer ...... 73
Setting the USB Mode .......................................... 73
Connecting to your Printer .................................. 74
Using the PictBridge Menu .......................................... 75
Print (with Date) .................................................... 75
Print (without Date) .............................................. 76
Print Index ............................................................... 77
Print DPOF Images ................................................ 78
10
Exit ............................................................................ 78
Video System ................................................................. 79
Set Eye-Fi SD Card Connection Mode ....................... 80
APPENDICES .............................................. 81
Specifications ................................................................. 81
Prompts and Warning Messages ............................... 85
Troubleshooting ............................................................. 89
11
GETTING READY
Your camera box should contain the camera model you purchased along with the following accessories. If anything is
missing or appears to be damaged, please contact your retailer.(Based on sales in different countries or regions, the
shape of the AC adapter will vary. Please subject to the actual product will prevail.)
Accessories Included
Micro USB cable
Warranty card
AC adapter Neck strapRechargeable
Li-ion battery
Quick start guide Service card
Quick Start Guide
STOP
12
Install neck strap
13
Part Names
1. Micro USB port
2. Strap eyelet
3. Zoom lever
4. Shutter button
5. Power button
6. AF assist beam/Self-timer lamp
7. Flash lamp
8. Lens
9. Microphone
3
8
65
2
9
7
1
4
14
10. Flash pop-up button
11. Fast video recording button
12. Mode button
13. Indicator lamp
14. Playback button
15. Menu button
16. Display button/Up button
17. Flash button/Right button
18. Delete button/Down button
19. Macro button/Self-timer button/Left button
20. SET button
21. LCD
22. Speaker
23. Tripod socket
24. Battery cover
2
10
11
12
13
19
20
21
14
15
16
17
18
22 23 24
15
2. Insert the battery into the battery compartment
according to the negative and positive directions as
illustrated in the picture. Push the battery down until
it locks in place.
1. Open the battery cover.
2
1
Installing Battery and Memory Card
16
4. Close the battery cover.
1
2
3. Insert the memory card into the memory card slot as
shown in the diagram below:
The memory card (SD/SDHC) is optional and not
included in all camera packaging. If you have to
purchase a memory card, select one with storage
capacity between 4GB and 32GB to ensure correct
data storage.
To remove your memory card, open the battery
cover, gently press the memory card to eject it and
remove it carefully.
Write protection
buckle
17
Please insert the battery and charge it under shutdown
mode.
1. Connect the camera and the power charger using the
supplied Micro USB cable.
2. Insert the plug of the power charger into the power
outlet to charge the battery.
3. When the camera is turned off, you can also connect
the camera to your PC using a USB cable to charge the
battery.
After the battery is stored for a long period of time,
use the supplied power charger to charge the battery
prior to use.
Charging indicator:
Steady orange: Charging.
The indicator will go out once charging is finished.
To have maximum battery life, charge the battery for
at least 4 hours the first time.
Please charge the battery indoors between 0°C
and 40°C.
The camera will only charge while powered off. If
the camera is turned on while connected to power,
normal camera functions will be available for use, but
the camera will not charge until it is turned off.
Charging Battery
Indicator lamp
18
Turning Camera On and Off
Press the power button to turn the camera on. To turn the
camera off, press the power button again.
Power Button
When the power is off, press and hold the
button to power on and enter playback mode.
How to take pictures
1. Hold the camera with both hands , not blocking the
flash and lens by fingers.
2. Aim the camera at the object and then frame with the
LCD.
3. Use the zoom lever to select Tele or Wide positions
to zoom in or out on your subject.
4. Press the shutter button half way to focus on the
subject. When the focus frame turns green, press the
shutter button completely down to take the picture.
19
Set your Language, Date/Time
Set your Language, Date/Time after the first power-on
1. When you turn the camera on for the first time, the
language selection screen appears.
2. Press the direction buttons to select your desired
language.
3. After you press the button to confirm the
selection, the Date/Time settings screen appears.
4. Press the left/right button to select the Date/Time
to be adjusted: Time is displayed in YYYY.MM.DD
HH:MM.
5. Press the up/down button to adjust the value for the
selected Date/Time.
6. Press the button to confirm the time settings and
the snapshot screen appears.
20
Resetting your Language
After you set your language for the first time, follow the
instructions below to reset your language.
1. Press the button, press the up/down button to
select , and press the button to enter the
menu.
2. Press the up/down button to select , and press the
button or right button to enter the menu.
3. Press the up/down button to select「Language」and
press the button or right button to enter the menu.
4. Press the direction buttons to select your desired
language and press the button to confirm.
5. Press the button and the snapshot screen appears.
21
Resetting Date/Time
After you set your Date/Time for the first time, follow
the instructions below to reset date and time.
1. Press the button, press the up/down button to
select , and press the button to enter the
menu.
2. Press the up/down button to select , and press the
button or right button to enter the menu.
3. Press the up/down button to select「Date & Time」
and press the button or right button to enter the
menu.
4. Press the left/right button to select the Date/Time
to be adjusted: Time is displayed in YYYY.MM.DD
HH:MM.
5. Press the up/down button to press the value for your
selected block. After you finish your settings, press
the button to confirm.
6. Press the button and the following snapshot
screen appears.
22
Press the button to display the settings: Classic,
Full, Off.
Classic: Displays the camera parameters on screen
-0.3
EV
400
ISO
1234
SD
16M
00:56:00
Full: Camera parameters with Grid and Histogram
-0.3
EV
400
ISO
1234
SD
16M
00:56:00
Off: Does not display any additional icons on screen
Display Setting
MODE OVERVIEW
23
LCD Screen Display
Overview of the Screen Icons in Photo Shooting Mode
1234
-0.3
EV
400
ISO
00:56:00
SD
16M
x3.
2
15 sec15 sec
1234
-0.3
EV
400
ISO
00:56:00
SD
16M
x3.
2
1 Shooting Mode
Auto Mode Panorama Mode
Manual Mode Scene Mode
Portrait Mode
2 Macro Mode
3 Zoom Display (By turning the Zoom Lever)
4 SD Memory Card/Built-in Memory
5 Battery Status
6 White Balance (Adjustable in mode)
7 Color Effect (Adjustable in mode)
8 Number of remaining shots
9 Image Size
10 Video Quality
11 ISO Value (Adjustable in mode)
12 Remaining Recording time
13 Exposure Compensation (EV value)
(Adjustable in mode)
24
14 Shutter Speed (Adjustable in mode)
15 Histogram
16 Focus Frame
17 Expo Metering
AiAE
Spot
Center
18 AF Mode
Single-AF
Multi-AF
19 Self-timer
Self-timer Off
Self-timer 2 sec
Self-timer 10 sec
Self-timer Smile
20 Flash Mode
Force Off
Flash Auto
Fill Flash
Slow Sync.
Slow Sync. + Red-Eye
Red-Eye Reduction
21 Continuous Shot
Single
Continuous Shot
3 Shots
Time Lapse (30sec/1min/5min/10min)
22 Eye-Fi ON (with signal)
23 Image Stabilization
25
Overview of the Screen Icons in Movie Mode
-0.3 EV
00:56:00
00:56:00
SD
x3.
2
1 Movie Mode
2 Macro Mode
3 Self-timer
Self-timer Off
Self-timer 10 sec
4 Zoom Display (By turning the Zoom Lever)
5 SD Memory Card/Built-in Memory
6 Battery Status
7 Color Effect
8 Video Quality
9 Remaining Recording time
10 Exposure Compensation (EV value)
11 Image Stabilization
12 Focus Frame
13 Eye-Fi ON (with signal)
14 Expo Metering
AiAE
Spot
Center
15 AF Mode
For optimal video shooting, it is recommended that
an SDHC memory card be used.
Optical Zoom and Digital Zoom can be adjusted
(80X in total). Digital Zoom can be adjusted to 4X .
26
Using the Mode Button
This camera provides a convenient mode button that allows you to switch easily among different modes. After pressing
the button to enter the mode selection menu, press the left/right button to choose the selected mode. Press the
button to confirm your selection. All the available modes are listed below:
Mode Name Icon Description
Auto Mode
In this mode, the optimal conditions for taking pictures will be set based on the subject and
environment. It is the most commonly used mode for taking pictures.
Manual Mode This mode is for manually setting EV, shutter speed and ISO value.
Portrait Mode
The best setting for portrait shooting, enables AE/AF for faces. The camera is set to
automatically adjust exposure for realistic capture of skin tones.
Movie Mode Record videos.
Panorama
Mode
In this mode, up to 4 frames can be stitched together to create a single panoramic photo.
Scene Mode Choose from 20 different pre-set scene types and effects for your photos.
27
5. If continuous pictures are less than 4 shots, press
the button, the camera will splice the pictures
automatically. Press playback button to enter
playback mode to see the effect.
6. If you take 4 pictures, the camera will splice the
pictures automatically. Press playback button to enter
playback mode to see the effect.
During shooting, the flash, self-timer, macro modes
and exposure compensation are not available.
Focus adjustment is also not available at this time.
In panorama mode, up to 4 photos can be captured
when the image size is set at 2M.
Panorama Mode
Panorama mode allows you to create a panoramic
picture. The camera will automatically compose a
panoramic picture using the individual shots that you
take.
Follow these easy steps to create a panoramic picture:
1. Press the button to select panorama mode ( ).
2. Press the direction buttons to select a shooting
direction. (The right direction is used as default if you
do not make any choice) 2 seconds later, the camera
is ready to take pictures. You can also press the
button or half press the shutter button to be ready to
take pictures.
3. Compose the first view of the panoramic picture on
the LCD and press the Shutter button to capture the
image.
4. After the first shot is taken, the semi-transparent
image of the first shot will appear at the edge of the
screen. You can use this image to compose your
picture before you press the Shutter button to capture
and finish manual stitching.
28
During panorama mode shooting, press the
button to interrupt shooting and save the current
pictures taken. Press the down button ( ) to
cancel shooting and not to save the previously
taken pictures.
Scene Mode
You can select an appropriate mode from the 20 scene
modes according to the type of environment you
are shooting. The camera then configures the most
appropriate settings automatically.
1. Press the button to select scene mode ( ). The
LCD will display a menu like the example below:
Auto Scene
2. Press the direction buttons to select a scene , and
press the button to confirm.
3. If any need of changing the scene, please press the
button and then the button and finally the
direction buttons to reselect the scene.
29
Scene Description
Auto Scene
Identifies the scene automatically; Person, Backlighting, Landscape, Macro, Night Scene,
Night Scene Person, Auto.
Landscape
For landscapes and outdoor shots. Vivid reproduction of green and blue.
Sport
For fast-moving subjects. Capture sharp, action shots with minimal blur. This mode is not
recommended for shooting indoors.
Beach
For taking pictures in areas with strong sunlight.
Sunset
For sunsets. Capture subjects in strong sunlight.
Fireworks
For fireworks at night. Suggest using tripod.
Night Landscape
For night scenes. Suggest using tripod.
Snow
For snow scenes. Reproduce natural, clear white scenes.
Children
Turns off flash automatically. Avoids disturbing subject, suitable for taking photos of
children.
ID
For shooting ID size photos. (It is recommended to print using 6-inch 4R (6X4)
photographic paper).
Glass
For objects behind transparent glass.
Photo Frame
For adding interesting frame effects to the photo.
30
Scene Description
Panning Shot
Suitable for capturing fast moving objects to have a clear subject with a blurred background.
Fish Eye
For interesting fish eye effect.
Party
Suitable for taking indoor party pictures, even under the complicated lighting conditions.
Indoor
For indoor settings. Reduce blur and improve color accuracy.
Leaf
For plants. Capture brilliant shots of greenery and blossoms.
Museum
For museums or flash-free areas. Retain color and reduce blur.
Night Portrait
For portraits against night scenery.
Sketch
For taking photos with pencil sketch effect.
31
Auto Scene Mode (ASCN)
In “ASCN” scene mode, the camera can detect different environments intelligently and automatically select the best scene
and photo settings for you.
“ASCN” can intelligently detect the following scenes:
Mode Name Description
Landscape Mode
For landscapes, will automatically adjust the exposure and reproduce vivid green and
blue colors.
Portrait Mode
Most suitable for capturing people with focus on their faces.
Night Portrait
When you take portraits at night, or in low light conditions, will automatically adjust
the exposure for people and night scenes.
Backlit Portrait
When the sun or any other light source is behind you, will automatically adjust the
foreground exposure to produce the best pictures possible.
Night Landscape Mode
For night scenes, will automatically increase the ISO value to compensate for low light.
Macro Mode
The Macro setting is ideal for shooting small objects or close-up photos.
Auto Mode
The camera will automatically adjusts the exposure and focus to ensure the best
possible pictures.
32
Your camera is equipped with two types of zoom
functions: optical zoom and digital zoom. Toggle the
zoom lever of the camera to zoom in or out of the subject
while taking pictures.
Using the Zoom Function
BASIC OPERATION
Zoom Indicator
When the optical zoom reaches the threshold as digital
zoom, release and turn the zoom lever to T to switch
between the optical zoom and digital zoom.
Zoom Lever
33
Macro Mode
The macro setting is ideal for shooting small objects
or close-up photos. This mode allows you to focus on
subjects very close to the camera.
1. Press the left button ( ) to enter the marco
menu.
2. Press the left/right button to select the following 2
modes:
• Macro Off
Select this option to disable macro.
• Macro On
Select this option to make focusing on the
object closer to the lens (At the W side, the
shooting distance should be more than 3 cm).
3. Press the button to confirm the settings and enter
the shooting screen.
34
Self-timer Setting
Use this function to take pictures at pre-set intervals.
First choose 2 seconds, 10 seconds,or by smile detection.
and then take the pictures.
1. Press the left button ( ) , and then press the
down button ( ) to enter the self-timer menu.
2. Press the left/right button to select the following 4
modes:
• Self-timer Off
Disables the self-timer.
• Self-timer 2 sec
A single picture is shot 2 seconds after the
shutter button is pressed.
• Self-timer 10 sec
A single picture is shot 10 seconds after the
shutter button is pressed.
• Self-timer Smile
Press the shutter button and a picture
will be taken immediately after a smile is
detected.
3. Press the button to confirm the settings and enter
the shooting screen.
When enabling the self-timer, pressing the shutter
or the ( ) button can disable the self-timer and
return to the shooting screen while keeping the
self-timer setting.
When enabling the smile detection, pressing the
shutter or the button can disable the self-timer
and return to the shooting screen without keeping
the Self-timer Smile setting.
35
Flash Mode
The flash provides supplemental light for the scene. The
flash is usually used when shooting against the light to
highlight the object; it is also suitable for metering and
shooting in darker scenes to improve the exposure.
1. Press the flash pop up button to pop up the
flash.
2. Press the right button ( ) to enter the flash settings
menu.
3. Press the left/right button to select the following 6
modes:
• Force Off
Flash is turned off.
• Flash Auto
Camera flash goes off automatically based
on existing light conditions.
• Force Flash
The flash will engage with each shot even
if there is enough available light to take the
photo without flash.
• Slow Sync.
This allows you to take pictures of people at
night that clearly show both your subjects
and the night time backdrop. The use of a
tripod is recommended when shooting with
this setting.
• Slow Sync. + Red-Eye
Use this mode for slow synchrony shots
with red-eye reduction.
• Red-Eye Reduction
The camera emits a brief pre-flash before
the picture is taken to reduce red-eye
effects.
4. Press the button to confirm the settings and enter
the shooting screen.
36
EV Setting
The EV function menu of the camera includes functions,
such as EV, shutter adjustment, ISO. Using the
appropriate function settings can improve your pictures.
To select the best setting for optimum photos, follow
these steps:
1. Press the button to display the settings screen.
2. Press the left/right button to select the setting
options.
3. Press the up/down button to adjust the option values.
4. Press the button to complete the setting and enter
shooting mode.
Exposure Compensation
Set up to adjust the picture brightness. In the case of
a very high contrast between the photographed object
and the background, the brightness of the picture can be
appropriately adjusted. (Adjustable in mode)
The adjustable range of exposure value is from EV -2.0
to EV+2.0.
37
ISO
The ISO function allows you to set the sensitivity of the
camera's light sensor based on the brightness of the
scene. To improve the camera's sensor performance
in darker environments, a higher ISO value is required.
A lower ISO value is needed when shooting in brighter
conditions.
Pictures taken at higher ISO settings will generally have
more noise than those taken at lower ISO settings.
(Adjustable in mode)
The camera's ISO settings include: Auto, 80, 100, 200,
400, 800, 1600.
Shutter Adjustment
For shutter speed, the camera may automatically set the
aperture value corresponding to the manually set shutter
speed so as to obtain a most suitable exposure value.
The movement of object may be shown by adjusting the
shutter speed. High shutter value can make you clearly
capture the movement of fast moving object while low
shutter value can allow you to take a picture for fact
moving object with a strong sense of movement.
(Adjustable in mode)
38
Using Quick Recording
In shooting mode, press the button to begin recording
video.
After recording, press the button or the shutter
button to stop recording. The camera will store the video
and return to the shooting screen.
39
PLAYBACK
1 DPOF File
2 File Protection
3 Memory space (indicating the current number of
photos and total number of photos)
4 SD Memory Card/Built-in Memory
5 Battery Status
6 Zoom Magnification Area
7 Image Zoom Ratios
8 Image Zone
9 Shooting Date
10 Eye-Fi ON (with signal)
11 Red-Eye Reduction
12 HDR
1/45
201
-
:
x2
SD
0
1
00 00
9
321
4
5
11
10
12
6
8
7
4
Overview of the Screen Icons in Playback Mode
40
Viewing Photos and Videos
To view the captured photos and video clips on the LCD:
1. After pressing the button, the last photo or video clip taken will be displayed on the LCD.
2. Use the left/right navigation buttons to scroll through the photos or video clips stored in the internal memory or on
the memory card.
3. To play a selected video clip, press the button to enter the movie playback mode.
An operation guide appears on the screen when playing back a video. Press the appropriate buttons to enable the
corresponding functions.
00:00:47 00:01:23
00:00:47 00:01:23
1 Increase volume
2 Pause
3 Fast forward
4 Decrease volume
5 Rewind
6 Back to the beginning of the video
7 Play
8 Play video forward
9 Cancel playback
10 Play video backward
Mute
41
Thumbnail View
When in playback mode, rotate the zoom lever counter
to the position to display thumbnail images of the
photos and videos on the screen.
1. Slide the zoom lever to switch between 3x3 and 4x4
thumbnails.
2. Press the direction buttons to select a picture or video
clip to view and press the button to restore it to
the original size.
If the indicator appears on the LCD, then a
movie file is currently being displayed.
W Zoom
T Zoom In
42
Using Zoom Playback (for still pictures only)
The zoom lever can also be used during playback. This allows you to magnify photos between x2 to x8.
1. Press the button to switch to playback mode.
2. Press the left/right button to select a picture to be zoomed in.
3. Rotate the zoom lever to ( ) to zoom in.
4. The screen will display the number of times and area of the photo zooming operation.
x2
5. Press the direction buttons to navigate and select a part of the image to be zoomed in.
6. Press the button to return the image to its original scale.
Movie images cannot be magnified.
x2
x2
43
This setting allows you to view all the stored images as a slideshow.
1. Press the button to enter playback screen.
2. Press the button to enter slide option.
3. Press the left/right button to select slideshow playing or 「Cancel」 to return to the playback screen.
4. Press the button to confirm the setting.
Slide playing function supports movie playing.
Images don’t rotate in the slideshow playback.
Slideshow
44
Photos and Video Deletion
In playback mode, press the down button ( ) to delete
your photos and videos.
To delete photos or videos:
1. Press the button to switch to playback mode.
2. Press the left/right button to select the photos and
videos to be deleted.
3. Press the down button ( ) and the deletion screen
is displayed.
4. Press the up/down button to select「Delete One」
or「Exit」and press the button to confirm.
Erased photos/video clips cannot be recovered.
Please refer to page 63 for instructions on deleting
more than one image at a time.
45
Shooting Menu
USING THE MENUS
Functions that can be enabled are different under each
mode.
Mode:
1. In photo shooting mode, press the button to enter
the shooting menu.
2. Press the up/down button to select the shooting
menu to be set.
3. Press the left/right button to select the shooting
menu to be set and press the button to confirm.
Refer to the following pages for more details about each
setting.
Expo Metering
Use this setting to select the "target" size of the camera's
field of view to be metered.
• AIAE (Artificial Intelligence AE)
Automatically selects the central and
peripheral metering, to calculate the
reasonable value of metering by weighting.
• Spot
For metering targets a small area in the center
of the camera's field of view.
• Center
For metering targets a slightly larger area in
the center of the cameras field of view.
46
Image Size
The size setting refers to the image resolution in pixels. A
higher image resolution allows you to print that image in
larger sizes without degrading the image quality.
The larger the number of recorded pixels, the
larger the file size and the fewer files that can be
saved on your memory card.
OIS
This mode can help reduce photo blur caused by
unintentional hand shake, low light .
• OIS: Off
• OIS: On
Use this image stabilization mode in dark
environments.
Shooting in a windy or unstable environment (such
as a moving vehicle) may cause blurred images.
47
Cont. AF
Enable the continuous AF to be able to continuously
focus automatically when taking pictures.
• Cont. AF: Off
• Cont. AF: On
White Balance Setting
The white balance setting allows you to adjust the color
temperature for different lighting sources to ensure the
most accurate color reproduction.
• AWB
• Daylight
• Cloudy
• Fluorescent
• Fluorescent CWF
• Incandescent
• Manual WB (Fully press the shutter button
to detect the white balance value)
48
Focus Setting
In different photo shooting modes, you can select
different focus methods.
• Single-AF: The focus frame appears on the
center of the LCD to focus on the subject.
• Multi-AF: The camera automatically focuses
the subject in a wide area to find the focus
point.
Continuous Shot
Use this setting to perform continuous shooting. After
entering this mode, you can shoot multiple images by
continuously holding the shutter button down.
• Single
• Continuous Shot
• 3 Shots
• Time-Lapse 30sec
• Time-Lapse 1min
• Time-Lapse 5min
• Time-Lapse 10min
The flash is disabled in the continuous shooting in
order to achieve quick succession of shots.
49
Color Effect
The image color setting allows you to select different effects.
1. In photo shooting mode, press the button to enter the shooting menu.
2. Press the up/down button to select the image color setting menu, press the button to enter the
menu.
3. Press the left/right button to select the image color setting options.
• Normal
• Vivid
• Sepia
• Black and White
50
• Options in the shooting mode (O: Disponible X: Indisponible)
Options
Shooting Modes
о о о
х
о
о о о
х
о
о о х х х
о о о
х
х
о о о
х
х
о о х
х
х
х о х х х
х о х х
х
51
Mode:
1. Press the button in photo shooting mode and
press the up/down button to select .
2. Press the button to enter the menu.
3. Press the up/down button to select , and press
the button or right button to enter the menu.
4. Press the up/down button to select the item to be set
and press the button or right button to enter the
menu.
5. Press the up/down buttons to select an option and
press the button to confirm.
Shooting Setting Menu
Quality
The quality setting can be used to adjust the image
compression ratio.
• Best (16M Average File Size: 4.0MB)
• Fine (16M Average File Size: 2.5MB)
• Normal (16M Average File Size: 2.0MB)
52
AF Assist Beam
In a darker environment, AF assist beam can be turned
on for better focus.
• Off
• On
Digital Zoom
This setting is for adjusting digital zoom. If this function
is disabled, only optical zoom can be used.
• Off
• On
53
Quick Review
This option allows quick review of the photos
immediately after they are taken. Each photo is displayed
on the LCD based on the selected time.
• Off
• 1 sec
• 2 sec
• 3 sec
Date Imprint
Include a Date/Time stamp on the photo image.
• Off
• Date
• Date / Time
54
Face Detection
For detecting and focusing on faces to make all faces as
clear as possible in photo mode.
1. Hold the camera steadily and then focus on the object
to detect its face. A focus frame will appear at the
face on the screen when a face is detected.
1/50F2.9
2. Press the shutter button half-way down to focus. The
LCD will show a green focus frame when the subject
is in focus.
1/50F2.9
3. Press the shutter button all the way down to take
pictures.
The closed eyes detection is usually on. If the
camera detects in the course of quick review there
is a face with eyes closed, a prompt of closed eyes
will appear .
55
Movie Menu
Mode:
1. Press the button, select the mode and press
the button to enter the movie menu.
2. Press the up/down button to select the movie menu
to be set.
3. Press the left/right button to select the movie menu
to be set and press the button to confirm.
Expo Metering
Use this setting to select the "target" size of the camera's
field of view to be metered.
• AIAE (Artificial Intelligence AE)
Automatically selects the central and
peripheral metering, to calculate the
reasonable value of metering by weighting.
• Spot
For metering targets a small area in the center
of the camera's field of view.
• Center
For metering targets a slightly larger area in
the center of the cameras field of view.
56
Video Quality
Set the image resolution used during video recording.
The speed requirements for reading and writing high
image pixel images to SD card are as follows:
No.
Image Pixel
Frame
Recommen-
dation
Recording time
(4GB) About
1
1280x720 *
30 Class 4 19 minutes
2
1280x720
15 Class 4
37 minutes
3
640x480
30 Class 4
33 minutes
* The longest recording time is 29 minutes at one
time.
When recording in higher pixel resolutions for
extended periods of time, this can cause the
camera to generate heat. This is not a camera
malfunction.
57
Color Effect
The image color setting allows you to select different
effects.
1. Press the button to select the Image color setting
menu.
2. Press the left/right button to select the image color
setting options.
• Normal
• Vivid
• Sepia
• Black and White
OIS
This mode can help reduce images blur caused by
unintentional hand shake, low light .
• OIS: Off
• OIS: On
Use this image stabilization mode in dark
environments.
Shooting in a windy or unstable environment (such
as a moving vehicle) may cause blurred images.
58
Movie Setting Menu
Mode:
1. Press the button, and select to enter the video
recording screen.
2. Press the button, press the up/down button to
select , and press the button to enter the
menu.
3. Press the up/down button to select , and press
the button or right button to enter the menu.
4. Select the items to be set and press the button or
the right button to enter the menu.
5. Press the up/down buttons to select an option and
press the button to confirm.
Digital Zoom
This setting is for adjusting digital zoom. If this function
is disabled, only optical zoom can be used.
• Off
• On
59
Playback Menu
Mode:
1. Press the button to display the playback screen
and press the button to enter the menu.
2. Press the up/down button to select the playback to
be set and press the button to enter.
3. Press the left/right buttons to select an option and
press the button to confirm.
Refer to the following pages for more details about each
setting.
HDR
With the HDR function, pictures that are overexposed
may be corrected to optimize the highlights and lowlights
captured to more accurately represent the actual scene.
: HDR
: Cancel
After using the HDR function, the image will be
saved as a new file and the original file is still
stored in the memory.
60
Rotate
You can use this setting to change the orientation of the
picture.
: Turn Right
: Turn Left
: Cancel
Videos and panoramic pictures cannot be rotated.
The rotated picture file will replace the original
photo.
Red-Eye Reduction
You can use this setting to reduce the Red-Eye of the
picture.
: Red-Eye Reduction
: Cancel
61
Resize
This setting allows you to resize a picture to a particular
resolution and saves it as a new picture.
: Resize to 1024x768
: Resize to 640x480
： Cancel
Only for adjusting pictures with high resolution to
those with low resolution.
Color Effect
This setting allows you to change the picture color effect.
The file is saved as a new photo and stored in memory
together with the original photo.
: Cancel
: Vivid
: Sepia
: Black and White
62
Mode:
1. Press the button to show the playback screen,
press the button, and press the up/down button to
select .
2. Press the button to enter the menu.
3. Press the up/down button to select , and press
the button or right button to enter the menu.
4. Press the up/down button to select the item to be set
and press the button or right button to enter the
menu.
5. Press the up/down buttons to select an option and
press the button to confirm.
Refer to the following pages for more details about each
setting.
Playback Setting Menu
63
Protect
To prevent any pictures or videos from being accidentally
erased, use this setting to lock one or all of the files.
• One: Lock the selected photo or video if they are
unprotected; unlock the selected photo or
video if they are protected.
• All: Lock all photos or videos.
• Reset: Cancel all locked photos or videos.
Delete
You can delete one or all photo/video files.
• One: Delete one photo or video.
• All: Delete all photos or videos.
The “ ” indicator means a file is protected. File
protection must be removed first before a file can
be deleted.
Deleting files will cause DPOF settings to be reset.
64
Trim
The Trim Setting allows you to crop photos and save
them as new pictures.
1. Select「Yes」to confirm trim. Select a part to be
trimmed using the zoom lever and direction buttons
to trim a photo.
2. Press the button and the「Save change?」prompt
appears. Select「 」to change and save the
picture. Select「 」to cancel changes and return to
the trim prompt screen.
The image cannot be clipped/trimmed again once
it has been clipped to 640X480.
DPOF (Digital Print Order Format)
The DPOF feature allows you to compile and select a
group of pictures that you would like to print and will
save your selection on the memory card so that you
can use the SD memory card to print without having to
individually specify the photos you want to print.
The printer that supports DPOF is needed for
printing.
65
Setup Menu
Mode :
1. Press the button in any mode and press the up/
down button to select .
2. Press the button to enter the menu.
3. Press the up/down button to select , and press
the button or right button to enter the menu.
4. Press the up/down button to select the item to be set
and press the button or right button to enter the
menu.
5. Press the up/down buttons to select an option and
press the button to confirm.
Refer to the following pages for more details about each
setting.
66
Power Saver
This setting allows you to save power and get the
maximum possible running time for your camera’s
batteries. Turn the LCD and camera off automatically
after a consecutive period of inactivity.
• Auto
• Normal
• Best
Sound Settings
With this setting you may adjust the sound volume.
Press the left/right button to adjust the volume and
Press the button to confirm.
Power Saver
LCD power off
time
Turn off time
Auto 3 min 5 min
Normal 1 min 3 min
Best 30 s 1 min
67
Language
Refer to the “Resetting your language” section on page
20.
World Time
The world time setting is a useful function for your
overseas trips. This feature enables you to display the
local time on the LCD while you are abroad.
1. Press the up/down to select the departure place
( ) and destination ( ) fields.
2. Press the left/right button to select a city located in
the same time zone as that of the field. Press the
button to confirm settings.
Date & Time
Refer to the “Resetting Date/Time” section on page 21.
LCD Brightness
Use this setting to adjust the brightness of your LCD.
LCD Brightness Normal
Normal
68
Mode :
1. Press the button, press the up/down button to
select and press the button to enter the menu.
2. Press the up/down button to select and press the
button or right button to enter the menu.
Format
Copy to Card
Reset
FW Version
File Numbering
VX.XX
4. Press the up/down button to select the item to be set
and press the button or right button to enter the
menu.
5. Press the up/down buttons to select an option and
press the button to confirm.
File Setting
Format
Please note: formatting enables you to delete all
contents in the memory card and built-in memory,
including protected photo and movie files.
If you select「Yes」the camera formats its memory.
If there is no memory card in the camera, the built-
in memory will be formatted; if there is a memory
card, it will be formatted only.
69
File Numbering
After you take a picture or video clip, the camera will
save it with a sequential number. You can use this to
reset the file numbering to 1.
Copy to Card
Use this setting to copy the files stored in the built-in
memory to a memory card.
If there is no card available in the camera, this
function will not be displayed.
70
FW Version
Use this setting to view the current camera firmware
version.
FW Version
Current Ver: X.XX
Back
When there is a new firmware version in the SD card,
select「Ye s」to update.
FW Version
Current Ver: X.XX
New Ver: X.XX
Cancel
Yes
Update Firmware?
Reset
Use this setting to restore the camera to its original
default settings.
71
4. Press the up/down buttons to select「PC」and press
the button to confirm.
Connecting to a Computer
You can use a Micro USB cable to connect the camera
and copy (transmit) photos to a computer, printer or
other device.
Setting the USB Mode
The camera’s Micro USB port can be set to connect
with either a computer or a printer. The following steps
will allow you to ensure that the camera is correctly
configured to connect with a PC.
1. Press the button, press the up/down button to
select and press the button to enter the menu.
2. Press the up/down button to select and press the
button or right button to enter the menu.
3. Press the up/down button to select「USB」and press
the button or right button to enter the menu.
CONNECTIONS
72
Transferring files to your computer
The computer will automatically detect the camera as a
removable drive. Double-click the my computer icon on
the desktop to locate the removable drive and to copy
folders and files in the drive to a directory on your PC as
you would copy any typical folder or file.
Follow the steps below to connect the camera to a
computer.
1. Make sure both the camera and computer are turned
on.
2. Connect one end of the supplied Micro USB cable to
the USB Micro port on your camera.
3. Connect the other end of the cable to an available
USB port on your computer.
4. After the transmission is complete, disconnect
the Micro USB cable according to the instructions
specifying how to safely remove USB devices.
73
Connecting to a PictBridge Compatible Printer
PictBridge technology allows printing of the
photos saved in the memory card by the
printer.
To find out if a printer is PictBridge
compatible, simply look for the PictBridge
logo on the packaging or check the owner's manual for
specifications. With the PictBridge function on your
camera, you can print the captured photos directly to
a PictBridge compatible printer using the supplied USB
cable, without the need for a PC.
Setting the USB Mode
The camera’s USB port can be set to connect with either
a PC or a Printer, the following steps will ensure that the
camera is correctly configured to connect with a Printer.
1. Press the button, press the up/down button to
select and press the button to enter the menu.
2. Press up/down button to select and press the
button or right button to enter the menu.
3. Press the up/down button to select「USB」and press
the button or right button to enter the menu.
4. Press the up/down button to select「Printer」and
press the button to confirm.
After the camera is reset, it will switch to PC mode
automatically from USB mode.
See “Using the PictBridge Menu“ section on page
75.
74
Connecting to your Printer
1. Make sure both the camera and printer are turned on.
2. Connect one end of the supplied Micro USB cable to
the Micro USB port on your camera.
3. Connect the other end of the cable to the USB port on
the printer.
If the camera is not connected to a PictBridge compatible
printer, the following error message will appear on the
LCD.
The error message above will also appear if the
USB mode is set incorrectly, in which case you
should disconnect the USB cable, check the USB
mode settings, ensure that the Printer is turned on,
and then try connecting the USB cable again.
75
Using the PictBridge Menu
After setting the USB mode to Printer, the PictBridge
menu will appear.
Press the up/down button to select a menu item and
press the button or right button to enter the item.
Refer to the following sections for more detailed
information on each setting.
Print (with Date)
If you have set the date and time on your camera, the
date and time will be recorded and saved with each
photo you take.
1. In the PictBridge menu, select「Print (with Date)」
and the screen as shown below appears.
2. Press the left/right button to select a photo to be
printed.
76
3. Press the up/down button to select the number of
copies for the currently displayed photo.
4. Press the button and the following screen will
appear.
5. Select「Yes」and press the button to confirm;
select「Cancel」to cancel printing.
Print (without Date)
Use this setting to print the photos without dates on
them.
1. In the PictBridge menu, select
「Print (without Date)
」
and the screen as shown below appears.
2. Press the left/right button to select a photo to be
printed.
3. Press the up/down button to select the number of
copies for the currently displayed photo.
4. Press the
button and the following screen will
appear.
77
5. Select「Yes」and press the button to confirm;
select「Cancel」to cancel printing.
Print Index
You can print all photos in the camera via this function.
1. In the PictBridge menu, select「Print Index」and the
screen as shown below appears.
2. Select「Yes」and press the button to confirm;
select「Cancel」to cancel printing.
78
Print DPOF Images
To use DPOF printing, you must select your photos
for printing using the DPOF settings beforehand. See
“DPOF” section on page 64.
1. In the PictBridge menu, select「Print DPOF Images」
and the screen as shown below appears.
2. Select「Yes」and press the button to confirm;
select「Cancel」to cancel printing.
Exit
Select「Exit」to exit the PictBridge menu. At this time,
the message「Remove USB Cable!」appears on the
screen.
Disconnect the USB cable from the camera and printer.
79
Video System
Use this feature to switch the video system from either
NTSC or PAL.
1. Press the button, press the up/down button to
select and press the button to enter the menu.
2. Press the up/down button to select and press the
button or right button to enter the menu.
3. Press the up/down button to select「TV-System」
and press the button or right button to enter the
menu.
4. Press the up/down button to select「NTSC」
or「PAL」and press the button to confirm.
NTSC: English, Chinese (Traditional), Japanese,
French, Korean, Russian, Vietnamese, Greek,
Hungarian
PAL: German, Spanish, Italian, Chinese (Simplified),
Portuguese, Swedish, Danish, Finnish,
Indonesia, Norwegian, Dutch, Turkish, Polish,
Thai, Croatian, Czech, Arabic, Hindi
The video output system would change accordingly
based upon the changes of the selected language.
80
This camera supports wireless connection for Eye-Fi memory cards. Enable the Eye-Fi connection by following the steps
below.
1. Press the button, press the up/down button to select and press the button to enter the menu.
2. Press the up/down button to select and press the button or right button to enter the menu.
3. Press the up/down button to select「Eye-Fi」and press the button or right button to enter the menu.
4. Press the up/down buttons to select「On」or「Off」and press the button to confirm.
If the Eye-Fi card is not available in the camera, this feature is not displayed.
Set Eye-Fi SD Card Connection Mode
81
Specifications
APPENDICES
Design and specifications are subject to change without notice.
Image Sensor
Type 1/2.3"CCD
Effective Pixels 16.15 Megapixels
Total Pixels 16.44 Megapixels
Lens
Focal Length 4.5mm (Wide) — 90.0mm (Tele)
35mm film equivalent 25mm (Wide) — 500mm (Tele)]
F number F3.5 (Wide) — F4.9 (Tele)
Lens Construction 9 groups 11 elements
Optical Zoom 20x
Focusing Range
Normal: (Wide) 60cm ~
∞
(Tele) 200cm ~
∞
Macro: 3cm ~
∞
(Wide Only)
Autofocus System TTL Autofocus
Anti-Handshake Optical Image Stabilization
Digital Zoom 4x Digital Zoom (Combined Zoom: 80x)
82
Number of
Recording
Pixels
Still Image
(4:3)
16MP: 4608
×
3456
10MP: 3648
×
2736
5MP: 2592
×
1944
3MP: 2048
×
1536
0.3MP: 640
×
480
(3:2)
14MP: 4608
×
3072
(16:9)
12MP: 4608
×
2592
2MP: 1920
×
1080
Movie
1280
×
720(15/30fps), 640
×
480(30fps)
Image Compression Best, Fine, Normal
DCF, DPOF (Ver1.1) Support Yes
File Format
Still Image Exif 2.3 (JPEG)
Movie MOV [Image: Motion JPEG; Audio: G.711(Monaural)]
Shooting Modes Auto Mode, Manual Mode, Portrait, Movie Mode, Panorama Mode, Scene Mode
Scene Mode
ASCN Scene, Landscape, Sport, Beach, Sunset, Fireworks, Night Landscape, Snow,
Children, ID, Glass, Photo Frame, Panning Shot, Night Portrait, Fish Eye, Party,
Indoor, Leaf, Museum , Night Portrait, Sketch
Detection Features Face, Smile, Blink
Red-Eye Removal Yes
HDR Yes(Post-Processing)
83
Panorama Up to 180° (Horizontal)
LCD Display 3.0inch (230k Pixels)
Image Auto Rotation Yes
ISO Sensitivity Auto, ISO80/100/200/400/800/1600
AF Method Single AF, Multi-AF (TTL 9-point), Face-Detection
Exposure Metering Method
Artificial Intelligence AE (AiAE), Center-Weighted Average, Spot (Fixed to Center of
Frame), Face AE
Exposure Control Method Program AE (AE-Lock Available)
Exposure Compensation
±
2EV in 1/3 Step Increments
Shutter Speed 1/2000 ~ 4 Seconds (Manual: 30 Seconds)
Continuous Shooting Yes
Playback Modes
Single Photo, Index (9/16 Thumbnails), Slide Show
Zoom (Approx. x2~x8)
White Balance Control AWB, Daylight, Cloudy, Fluorescent, Fluorescent CWF, Incandescent, Manual
84
Flash
Flash Method Pop-up (Manual)
Flash Modes
Force Off, Flash Auto, Red-Eye Reduction, Fill Flash, Slow Synchro, Red-Eye
Reduction + Slow Synchro
Recording Media
Internal Memory: Approx. 8MB
SD/SDHC Card (Up to 32GB Support) (MMC Card Not support )
PictBridge, ExifPrint Support Yes
Multi-Language Support 27 Languages
Jacks AV-OUT/USB 2.0 (Micro 5 pin USB)
Eye-Fi Support Yes
Power Rechargeable Li-ion Battery LB-052, 3.7V 880mAh, In-Camera Charging
Shooting Capability (Battery Performance) Approx. 210 Shots (Based on CIPA Standards)
Operation Environment Temperature: 0 ~ 40
o
C, Humidity: 0 ~ 90%
Dimensions (W
×
H
×
D) Approx. 109.7
×
69.6
×
38.3mm (Based on CIPA Standards)
Weight Approx. 202 g (Body Only)
85
Prompts and Warning Messages
Message Description Action
Warning! Battery exhausted.
The camera battery is used up. It is a warning
indicating that the camera is going to shut down.
Replace with new batteries.
The camera will shut down in
2 seconds.
Lens obstruction, Re-start
Camera.
The lens is jammed or some foreign object is
preventing the lens from functioning properly.
Turn off the camera and
restart it to reset the lens.
Suggest using tripod.
When continuous exposure is enabled, this prompt
message is displayed when the photo shooting
screen is displayed for the first time.
The message will disappear
after 2 seconds
Built-in memory error! An error occurs in internal memory.
The message will disappear
after 2 seconds
Slow shutter is on: may easily
cause overexposure.
When the B shutter is on, the prompt appears on
the screen after you go back to the photo shooting
screen.
The message will disappear
after 2 seconds.
Improper alignment.
Please try again.
The offset is too big for panorama shooting.
The message will disappear
after 2 seconds.
86
Message Description Action
Connection Failed!
In the case of failing to connect to a PC or a printer.
Remove transmission line
to stop connection, and the
message is removed.
Warning! Do not turn off your
camera during update!
The message appears during the firmware update
process.
The message disappears
after the camera update and
restart.
Remove USB Cable !
Indicates that you can disconnect the Micro USB
cable.
The message disappears after
you disconnect the Micro USB
cable.
Write Protect !
When you boot, press the shutter button or edit
the files under playback mode, and the SD card is
locked, the message appear.
The message will disappear
after 2 seconds.
Card Full !
When you boot, press the shutter button or edit
the files under playback mode, and the SD card is
locked, the message appear.
The message will disappear
after 2 seconds.
Memory Full !
When you boot, press the shutter button or edit
the files under playback mode, and the SD card is
locked, the message appear.
The message will disappear
after 2 seconds.
87
Message Description Action
Card Error !
The card cannot be recognized after being
formatted.
Normal display.
Card is not formatted.
When an error occurs in the SD card, the
message "Not Formatted" appears.
Disappear after 2 seconds and enter the
formatting process.
Slow access
When a SD card lower than Class 4 is used
to record a HD movie, the writing speed will
be slower and recording will not continue.
Remove the message after 2 seconds and
return to the shooting image.
Cannot write to SD card.
The photo shooting or video recording
has been interrupted so recording cannot
continue.
Remove the message after 2 seconds and
return to the shooting image.
No Red-Eye Detected!
No red-eye detected when pressing for red-
eye removing in playback touch-up.
The message will disappear after 2
seconds.
88
Message Description Action
This image cannot be edited.
The file format does not support editing
or the edited file cannot be edited again.
The message will disappear after 2
seconds.
Exceeded maximum folder
number.
This indicates that the SD card exceeded
the maximum number of folders (999).
This could cause a long read time during
the camera's power up.
The message will end after the camera
processing is complete.
Too many pictures for quick
processing.
During the playback by date, the images
exceed specifications so that it is not
possible to play by date.
The message disappears after 2 seconds
and the camera returns to the normal
playback mode.
Unable to recognize files.
The format of the file to be viewed is not
supported or the file is corrupted so it
cannot be properly read.
This image message disappears only after
the file is deleted.
No Picture!
When you press the play button, no image
files exist in the camera or memory card.
The message disappears 2 seconds later
to return to the photo shooting screen.
Protected! Undeletable!
The file is protected. The message
appears when you delete it.
The message will disappear after 2
seconds.
89
Troubleshooting
Problem Possible causes Solution
Camera does not turn on
The battery has been depleted.
The battery is not inserted
correctly.
Recharge the battery.
Correctly reinstall the battery.
Camera turns off suddenly during
operation
The batteries have been
depleted.
Recharge the battery.
The picture is blurred
Camera shakes while taking a
picture.
Turn on OIS feature.
Please use tripod for high magnification
(above 15X) optical zoom.
Images and video files cannot be
saved
The SD memory card is full.
The memory card is locked.
Use another memory card or delete
unnecessary files.
Unlock the memory card.
Images will not print from the
connected printer
The camera is not connected to
the printer correctly.
The printer is not PictBridge
compatible.
The printer is out of paper or ink.
The printer paper is jammed.
Check the connection between the
camera and printer.
Use a PictBridge compatible printer.
Load paper into the printer or replace the
ink cartridge in the printer.
Remove the jammed paper.
90
Problem Possible Causes Solution
Saving data to memory card is
slow
Using a memory card below Class
4 may result in slower recording
times.
Use a memory card with write
Class 4 or higher than 4 to improve
performance.
Cannot write to the memory card
The SD memory card has been
locked.
Release the write lock of the memory
card or replace with another card.
Too many movies to process
The number of pictures or folders
in the memory card exceed the
specifications, so the playback of
data folder can not be displayed.
Delete unwanted files.
The flash flashes on the LCD
screen.
Current shooting environment
requires flash.
Turn on flash.
The Kodak trademark and trade dress are used under license from Kodak.
© 2014 by JK Imaging Ltd. All Rights Reserved.
JK Imaging Ltd., 17239 South Main Street, Gardena, CA 90248, USA
JK Imaging Europe, 71 Clarendon road, Watford, WD17 1DS, UK
www.kodakpixpro.com
Ver. 5
