Introducing the Range

01 Oven control panel
02 Surface control knobs
03 Glass surface
04 Oven door
05 Storage drawer
06 Door latch

Newest Added: NE63A6311SS/AA NX60A6511SS/AA LPKIT-3/XAA ME21M706BAS/AA NE63A6711SG/AA
07 Automatic oven light switch
08 Oven light
09 Convection fan
10 Shelf position
11 Gasket


Before you begin

Clean the oven thoroughly before using it for the first time. Then, remove the accessories, set the oven to bake, and then run the oven at 400 °F for 1 hour. There will be a distinctive odor. This is normal.

Ensure your kitchen is well ventilated during this conditioning period.

Energy saving tips

+ During cooking, the oven door should remain closed except when you turn food over.
Do not open the door frequently during cooking to maintain the oven temperature and to save energy.

« If cooking time is more than 30 minutes, you can switch the oven off 5-10 minutes before the end of the cooking time to save energy. The residual heat will complete the cooking process.

« To save energy and reduce the time needed for reheating the oven, plan oven use to avoid turning the oven off between cooking one item and the next.

« Whenever possible, cook more than one item at a time.

Surface cooking

About surface cooking

BEFORE COOKING

+ Do not use the glass cooktop surface as a cutting board.

+ Do not place or store items that can melt or catch fire on the glass cooktop. even when it is not being used.

+ Turn the surface units on only after placing cookware on them.

+ Do not store heavy items above the cooktop surface. They could fall and damage it.

DURING COOKING

  • Do not place aluminum foil or plastic items, such as salt and pepper shakers. spoon holders, or plastic wrappings on the range when it is in use. The hot air from the vent could melt plastics or ignite flammable items.
  • Make sure the correct surface unit is turned on.
  • Never cook directly on the glass. Always use cookware.
  • Always place the pan in the center of the surface unit you are cooking on.
  • Never leave surface units unattended while using a high heat setting.
  • Boilovers cause smoking and greasy spillovers that may catch on fire.
  • Turn the surface units off before removing cookware.
  • Do not use plastic wrap to cover food. Plastic may melt onto the surface and be very difficult to remove.

AFTER COOKING

  • Do not touch the surface units until they have cooled down.
  • The surface may still be hot and burns may occur if you touch the glass surface before it has cooled down sufficiently.
  • Immediately clean spills on the cooking area to prevent a tough cleaning chore later.
  • If cabinet storage is provided directly above the cooking surface, make sure that the items are infrequently used and can be safely stored in an area subjected to heat. Temperatures may be unsafe for items, such as volatile liquids, cleaners, or aerosol sprays.

Location of the radiant surface elements and controls

The radiant control knobs operate the radiant surface elements on the cooktop as shown below.

  • 01 Left Rear: 6", 1200 W
  • 02 Left Front: 6/9", 1400 W / 3300 W
  • 03 Right Front: 9"/12’, 1900 W / 3000 W
  • 04 Right Rear: 6", 1200 W
  • 05 Warming Center: 100 W
  • 06 Hot surface indicator
  • 07 Cooktop On/Off lamp

Hot surface indicator

* Comes on when the unit is turned on or hot to the touch.
+ Stays on even after the unit is turned off.
+ Glows until the unit is cooled to approximately 150 °F.

Cooktop on/off lamp

+ The lamp turns on when the surface control knobs are not in off position.
+ The lamp turns off when the surface control knobs are in off position.

Cooking areas

+ The cooking areas on your range are identified by permanent circles on the glass cooking surface. For the most efficient cooking, fit the pan size to the element size.
+ Pans should not extend more than %" to 1” beyond the cooking area.
+ When a control is turned on, you can see a glow through the glass cooking surface. The element will cycle on and off to maintain the preset heat setting. even at high settings.
+ For more information on selecting proper types of cookware, refer to the section "Using the proper cookware" on page 26.

How to set the appliance for surface cooking

  • The surface elements may be hot even when off and burns can occur. Do not touch the surface elements until they have cooled down sufficiently.
  • At high or medium-high settings, never leave food unattended. Boilovers cause smoking and greasy spillovers may catch on fire
  • Be sure you turn the control knob to OFF when you finish cooking.

Single surface unit control knob (Left Rear, Right Rear)

+ Push the knob in.
+ Turn in either direction to the setting you want.
+ Atboth the off and high settings. the knob clicks into position.

Dual surface unit control knob (Left Front, Right Front)

  • Push the knob in.
  • Turn in either direction to the setting you want.
  • Touse the single surface unit. turn the control knob to the single burner (A) setting.
  • Touse the dual surface unit, turn the control knob to the dual burner (B) setting.

If you remove the knob for cleaning, make sure to reattach it in the correct orientation. (Refer to the illustration above.)

CAUTION

+ Please note, operation of lighting knob may not synchronize with the actual operation of the radiant heater when there is a problem with the product.

+ The area on the knob between the high and off settings is not appropriate for cooking.
Recommended settings

Using the warming center The warming center, located in the back center of the glass surface, will Keep hot. cooked food at serving temperature. @ Nore

The surface warmer will not glow red like the cooking elements.

CAUTION

+ Do not warm food on the warming center for more than two hours.

+ Use only cookware and dishes recommended as safe for oven and cooktop use.

+ Always use potholders or oven mitts when removing food from the warming center as cookware and plates will be hot.

+ When warming pastries and breads, use covers that have an opening to allow moisture to escape.

+ Donot use plastic wrap to cover foods. Plastic may melt onto the surface and be very difficult to clean off.

+ Always start with hot food. Eating uncooked or cold food placed on the warming center could result in illness.

1. To turn the warming center on, press the Warming Center On/Off pad.

2. Select the power setting you want. Press the Warming Center Level pad once for Low, twice for Medium, or three times for High.

3. To turn the warming center off, press the Warming Center On/Off pad.

NOTE

Pressing OFF/CLEAR does not turn the warming center off.

+ For best results, all foods on the warming center should be covered with a lid or aluminum foil. When warming pastries or breads, the lid or foil should be vented to allow moisture to escape

Recommended settings

Using the proper cookware

Using the right cookware can prevent many problems, such as uneven cooking or extended cooking times. Using the proper pots and pans will reduce cooking times and cook food more evenly.
Check for flatness by rotating a ruler across the bottom of the cookware.

Flat bottom and straight sides.

+ Tight fitting lids.

+ Weight of handle does not tilt pan.

+ Pan is well balanced.

+ Pan size matches the amount of food to be prepared and the size of the surface element.

+ Made of a material that conducts heat well

Always match pot diameter to element surface diameter.

Choosing the proper cookware

What your cookware is made of determines how evenly and quickly heat is transferred from the surface element to the pan bottom.

+ ALUMINUM - Excellent heat conductor. Some types of food will cause the aluminum to darken. (Anodized aluminum cookware resists staining & pitting)
If aluminum pans are slid across the ceramic cooktop, they may leave metal marks that resemble scratches, Remove these marks as soon as the cooktop cools down.

+ COPPER - Excellent heat conductor but discolors easily. May leave metal marks on ceramic glass (to remove, see above)

+ STAINLESS STEEL - Slow heat conductor with uneven cooking results.

It's durable, easy to clean, and resists staining.

+ CASTIRON - A poor conductor; retains heat very well. Cooks evenly once cooking temperature is reached, Not recommended for use on ceramic cooktops.

+ ENAMELWARE - Heating characteristics will vary depending on the base material. Porcelain enamel coating must be smooth to avoid scratching ceramic cooktops

+ GLASS - Slow heat conductor. Not recommended for ceramic cooktop surfaces because it may scratch the surface.

Protecting the cooktop

Cleaning

  • Clean the cooktop before using it for the first time.
  • Clean your cooktop daily or after each use. This will keep your cooktop looking good and can prevent damage.
  • If a spillover occurs while you are cooking, immediately clean the spill from the cooking area while it is hot to prevent a tough cleaning chore later. Using extreme care, wipe the spill with a clean, dry towel.
  • Do not allow spills to remain on the cooking area or the cooktop trim for a long period of time.
  • Do not use abrasive cleansing powders or scouring pads, which will scratch the cooktop.
  • Do not use chlorine bleach, ammonia, or other cleansers not specifically recommended for use on a glass-ceramic surface.

Preventing marks and scratches

  • Do not use glass cookware. It may scratch the cooktop.
  • Do not place a trivet or wok ring between the cooktop and the pan. These items can mark or scratch the cooktop.
  • Make sure the cooktop and the pan bottom are clean.
  • Do not slide metal pans across the cooktop.

Preventing stains

  • Do not use a soiled dish cloth or sponge to clean the cooktop surface. A film will remain, which may cause stains on the cooking surface after the area is heated
  • Continuously cooking on a soiled surface can result in a permanent stain.

Preventing other damage

  • Do not allow plastic, sugar, or foods with high sugar content to melt onto the hot cooktop. Should this happen, clean immediately.
  • Do not let a pan boil dry as this will damage the cooktop and the pan.
  • Do not use the cooktop as a work surface or cutting board.
  • Do not cook food directly on the cooktop. Always use the proper cookware.

Operating the oven

The oven control panel

READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use of your oven, become familiar with the various features and functions of the oven as described below. Detailed instructions for each feature and function follow later in this user manual.

  • 01 Display: Shows the time of day, oven temperature, what mode the oven is operating in, and the time set for the timer or automatic oven operations.
  • 02 Convection Bake: Use to select the Convection bake function of the oven.
  • 03 Convection Roast: Use to select the Convection roast function of the oven.
  • 04 Bake: Use to select the bake function of the oven.
  • 05 Broil: Use to select the broil function of the oven:
  • 06 Air Fry: Use to select the air fry function of the oven
  • 07 Keep Warm: Use to select the keep warm function of the single oven to keep cooked foods warm
  • 08 Bread Proof: Use to select the bread proof function of the oven.
  • 09 Dehydrate: Use to select the dehydrate function of the oven.
  • 10 Steam Clean: Use to select the steam cleaning function of the oven.
  • 11 Self Clean: Use to select the self-cleaning function of the oven.
  • 12 Timer: Use to set or cancel the kitchen timer. The kitchen timer does not start or stop cooking. Press and hold for 3 seconds to turn off the timer.
  • 13 Cook Time: Press and then use the number pad to set the amount of time you want your food to cook. The oven will shut off when the cooking time has run out.
  • 14 Delay Start: Press to set the oven to start and stop automatically at a time you set.
  • 15 Smart Control: Use to select the smart control feature.
  • 16 Number pad: Use to set any function requiring numbers, such as the time of day on the clock, the timer, the oven temperature, the start time and length of operation for timed baking, etc.
  • 17 Lamp: Press to turn the oven light on or off.
  • 18 Clock / Setting : Use to set the time of day. Use to bring up the user preference menu in the display. (Press for 3 seconds.)
  • 19 START / SET: Use to start any cooking or cleaning function in the oven.
  • 20 OFF / CLEAR: Press to cancel all oven operations except the clock and timer. Press to cancel a previously entered temperature or time.
  • 21 Oven lock: Use to disable all oven functions.

Oven lock

Lock the oven door and the buttons on the touch pad so they cannot be activated accidentally.
Oven lock can only be activated in standby mode.

How to activate the oven lock feature

Press Oven lock  for 3 seconds.
The display will show the Lock  icon as well as the current time.
All functions must be cancelled before Oven lock is activated.
This function is available only when the oven temperature is under 400 °F.


How to unlock the Oven

Press Oven lock for 3 seconds.
The Lock icon will disappear from the display.

Setting the clock

The clock must be set to the correct time of day for the automatic oven timing functions to work properly.
+ The time of day cannot be changed during timed cooking, delay-timed cooking, or a self-cleaning cycle.

How to set the clock

  • 1. Press Clock .
  • 2. Enter the current time in hours and minutes on the number pad, e.g., 1, 3, 0. for 1:30.
  • 3. Press Clock  or START/SET to save the changes.

Setting the kitchen timer

The kitchen timer serves as an extra timer that will beep when the set time has elapsed. It does not start or stop cooking functions. You can use the kitchen timer with any of the other oven functions.

How to set the timer

  1. Press Timer.
  2. Enter a desired time using the number pad.
  3. When done, press START/SET.
  4. To cancel the Timer settings, press and hold Timer for 3 seconds.
  5. When the set time elapses, the oven beeps and displays the “End” message. Press Timer to delete the message.

NOTE: To change the programmed timer, press Timer, enter a different time, and then press START/SET.

Timed cooking

In timed cooking, the oven turns on immediately and cooks for the length of time you select. At the end of the cooking time, the oven turns off automatically.

* You can use the timed cooking feature only with another cooking operation (bake, convection bake, convection roast, air fly, dehydrate).

How to set the oven for timed cooking

  • 1. Start the cooking operation you want, e.g., Bake. The default temperature is 350 °F.
  • 2. Press Cook Time. You can set the Cook Time at any time. (After selecting the cook mode. during preheating, after preheating.)
  • 3. Enter the cooking time you want, e.g., 45 min, using the number pad. You can set the cooking time for any amount of time from 1 minute to 9 hours and 59 minutes.
  • 4. Press START/SET. The temperature display will start to change once the oven temperature reaches 175 °F. The oven will continue to cook until the set amount of time has elapsed, then turn off automatically unless you set the keep warm feature. (Refer to the section on the keep warm feature on page 37.)
  • 5. You can cancel a cook time at any time by setting the cook time to O minutes. (Press Cook Time -> set cook time to 0 min -> press START/SET)

NOTE: When timed cooking is done, the range will beep several times.

CAUTION: Use caution with the timed cooking or delay start features. Use these features to cook cured or frozen meats and most fruits and vegetables. Foods that can easily spoil, such as milk, eggs, fish, meat, or poultry, should be chilled in the refrigerator first. Even when chilled, they should not stand in the oven for more than 1 hour before cooking begins, and should be removed promptly when cooking is completed. Eating spoiled food can result in sickness from food poisoning.

Delay start

In a delay timed cooking, the oven's timer turns the oven on and off at times you select in advance.

  • + You can use the delay start feature only with another cooking operation (bake. convection bake, convection roast, air fly, dehydrate, or self-clean).
  • + You can set the oven for a delay start before setting other cooking operations.
  • + The clock must be set to the current time.

How to set the oven for delay start

1. Position the oven rack(s) and place the food in the oven.

2. Press the pad for the cooking operation you want, e.g., Bake.
The default temperature is 350 °F.

3. Enter the temperature you want, e.g., 375 °F, using the number pad.

4. Set the cooking time if you want. (Refer to the section on the timed cooking feature on page 29.)

5. Press Delay Start.

6. Enter the time you want the oven to turn on, e.g., 4:30, using the number pad.

7. Press START/SET. At the set time, a short beep will sound. The oven will begin to bake.

Turning the oven light on and off

+ The oven light turns on automatically when the door is opened.
+ The oven light turns off automatically when the door is closed.
+ You can turn the oven light on and off manually by pressing the

Minimum and maximum settings

All of the features listed in the table below have minimum and maximum time or temperature settings. A beep will sound each time a pad on the control panel is pressed and the entry is accepted. An error tone will sound in the form of a long beep if the entered temperature or time is below the minimum or above the maximum setting for the feature.

Note: If you turn off the 12-hour energy saving feature, the feature marked with a * will operate until canceled. (12-hour energy saving's default setting : on) See page 41 for more information.

Using the oven racks

Oven rack positions

Recommended rack position for cooking

This table ts Tor reference only.

Rack and Pan placement

Centering the baking pans in the oven as much as possible will produce better results. If baking with more than one pan, place the pans so each has at least 1” to 1%" of air space around it. When baking on a single oven rack, place the oven rack in position 3 or 4. See the figure on the left.

Cakes place the oven racks in positions 3 and 5, Cookies place the racks in positions 2 and 5.

Using Multiple Oven Racks

Before using the racks

The oven has two racks. Each rack has stops that need to be placed correctly on the supports. These stops will keep the rack from coming completely out.

REMOVING THE RACKS

1. Pull the rack straight out until it stops.

2. Lift up the front of the rack, and then pull it out.

REPLACING THE RACKS

1. Place the end of the rack on the support.

2. Tilt the front end up and push the rack in.

CAUTION

Do not cover a rack with aluminum foil or place aluminum foil on the oven bottom. This will hamper heat circulation, resulting in poor baking. and may damage the oven bottom.
Arrange the oven racks only when the oven is cool

Baking

The oven can be programmed to bake at any temperature from 175 °F to 550 °F.
Baking temperature and time will vary depending on the ingredients and the size and shape of the baking pan used. Dark or nonstick coatings may cook faster with more browning.

How to set the temperature

1. Press Bake. The default temperature is 350 °F.

2. Enter the temperature you want on the number pad, e.g., 3, 7, 5.

3. Press START/SET. The temperature display will start to change once the oven temperature reaches 175 °F.

4. If you want to cancel baking or if you have finished, press OFF/CLEAR.

+ Place food in the oven after preheating if the recipe calls for it. Preheating is very important for good results when baking cakes. cookies, pastry, and breads. After the oven has reached the desired temperature, the range will beep several times.

NOTE: For performance reasons, the convection fan may be turned on or off during the operation.

How to adjust the temperature while cooking

1. Press Bake. The display will show the present temperature, e.g., 375 °F.
2. Enter the temperature you want, e.g., 425 °F, using the number pad.
3. Complete the entry by pressing START/SET.

Convection baking

By using the convection bake feature, you will be able to cook faster. Convection baking uses a fan to circulate the oven's heat evenly and continuously within the oven. This improved heat distribution allows for even cooking and excellent results while using multiple racks at the same time. Foods cooked on a single oven rack will generally cook faster and more evenly with convection baking. Multiple oven rack cooking may slightly increase cook times for some foods, but the overall result is time saved. Breads and pastries brown more evenly. You can program the oven for convection baking at any temperature between 175 °F and 550 °F.

Tips for convection baking

The amount of time you save will vary depending on the amount and type of food you are cooking. When baking cookies or biscuits, you should use pans with no sides or very low sides to allow the heated air to circulate around the food. Using a pan with a dark finish will produce faster cooking times.

When using convection baking with a single rack, place the oven rack in position
3 or 4. If cooking on multiple racks, place the oven racks in position 3 and 5 or 2 and 5.

When baking a cake, using the bake mode (not the convection bake mode) will produce better results.

How to set the oven for convection baking

1. Press Bake. The default temperature is 325 °F.

2. Enter the temperature you want, e.g., 400 °F, using the number pad.

3. Press START/SET.

The temperature display will start to change once the oven temperature reaches 175 F.
The range will beep several times when the oven reaches the adjusted oven temperature.

4. To turn off or cancel convection baking, press OFF/CLEAR.

* The convection oven fan shuts off when the oven door is opened.

+ DO NOT leave the door open for long periods of time while using convection cooking or you may shorten the life of the convection heating element.

NOTE: If you leave the oven door open for more than 2 minutes when the oven is on. all heating elements will shut off automatically. For performance reasons, the convection fan may be turned on or off during the operation.

Convection roasting

Convection roasting is good for cooking large tender cuts of meat, uncovered. Heat comes from the top heating element. The convection fan circulates the heated air evenly over and around the food. Meat and poultry are browned on all sides as if they were cooked on a rotisserie. The heated air seals in juices quickly for moist and tender results while, at the same time, creating a rich golden brown exterior.

How to set the oven for convection roasting

1. Press  Roast. The default temperature is 325 °F.

2. Enter the temperature you want, e.g., 400 °F, using the number pad.

3. Press START/SET. The temperature display will start to change once the oven temperature reaches 175 °F. The range will beep several times when the oven reaches the adjusted oven temperature.

4. To turn off or cancel convection roasting, Press OFF/CLEAR.

+ The convection oven fan shuts off when the oven door is opened.

+ DO NOT leave the door open for long periods of time while using convection cooking or you may shorten the life of the convection heating element. © note

If you leave the oven door open for more than 2 minutes when the oven is on, all heating elements will shut off automatically. © Note

For performance reasons, the convection fan may be turned on or off during the operation.

Broiling

Broiling is a method of cooking tender cuts of meat by direct heat under the broil element of the oven.

The high heat cooks quickly and gives a rich, brown outer appearance. Broil mode is best for meats, fish, and poultry up to 1" thick.

Always preheat the oven for 4 minutes before broiling.

How to set the oven for broiling

1. Press Broil once for Hi or twice for Lo. Use Lo to cook foods such as poultry or thick cuts of meat thoroughly without over-browning them

2. To start broiling, press START/SET. Broil one side until the food is browned. Turn over and broil the other side.

3. Press OFF/CLEAR once you have finished cooking or if you want to cancel broiling.

Broil stop position

Leave the door open at the broil stop position. The door will stay open by itself. yet the proper temperature is maintained in the oven

CAUTION

Should an oven fire occur, close the oven door and turn the oven off. If the fire continues, throw baking soda on the fire or use a foam-type fire extinguisher. Do not put water or flour on the fire. Flour can explode and water can cause a grease fire to spread and cause personal injury.

Broiling Recommendation Guide

The size, weight, thickness, starting temperature, and your doneness preference will affect broiling times. This guide is based on meats at refrigerator temperature. Always use a broiler pan and its grid when broiling. Always preheat the oven for 4 minutes before broiling.

Air fry

This feature works special hot air for crispier and healthier frozen or fresh foods without or less oil than normal convection modes, For best results, use this mode on a single oven rack and place the Air fry tray on the position 3. The temperature can be set between 350 °F and 500 °F. Preheating is not necessary for this mode. Follow recipe or package directions for set temperature, time or quantity.

How to set the oven for Air Fry mode

1. Place the tray on rack position 3

2. Select Air Fry mode.

3. Use the number pad to change the default temperature. Enter the suggested temperature for your food as recommended cooking guide. The default temperature is 425 °F.

4. Set the Cook Time or Delay Start, if necessary.

5. Tap START/SET.

6. When cooking is complete, tap OFF/CLEAR and take out the food.

NOTE: Place a baking sheet or tray on the rack below the Air fry tray for getting any drippings. This will help to reduce splatter and smoke.

  • + Before using a baking sheet, check the maximum allowable temperature of baking sheet.
  • + Ai fry is designed for a single oven rack. Place food on rack position 3 for best results
  • + For cooking fresh or homemade foods. spread the oil over a larger area more evenly, crisping up the food more effectively.

Air fry cooking guide

Using the special function

Dehydrate

Dehydrate dries food or removes moisture from food via heat circulation, After drying the food, keep it in a cool and dry place. For fruit, adding lemon, pineapple juice, or sprinkling sugar on the fruit helps the fruit retain sweetness.

See the table below for Dehydrate settings

1. Press Dehydrate.
2. Press START/SET.
3. Press OFF/CLEAR at any time to turn off the Dehydrate feature.

Nore: Use rack position 3 or 4 for dehydrating.

Bread Proof

The Bread Proof function automatically provides the optimum temperature for the bread proof process and, therefore does not have a temperature adjustment.

If you press Bread Proof when the oven temperature is above 95 °F, Hot will appear in the display. Because these functions produce the best results when started while the oven is cool, we recommend that you wait until the oven has cooled down and Hot disappears from the display.

1. Press Bread Proof.

2. Press START/SET.

3. Press OFF/CLEAR at any time to turn off the Bread Proof feature.

Note: Use rack position 3 for bread proofing.

CAUTION

  • + Donot use Bread proof for warming food. The proofing temperature is not hot enough to keep food warm.
  • + Place the dough in a heat-safe container on rack position 3 and cover it with a cloth or with plastic wrap. The plastic wrap may need to be anchored underneath the container so that the oven does not blow the plastic wrap off the dough.
  • + To avoid lowering the temperature and extending proofing time, do not open the oven door.

Using the keep warm feature

When cooking is finished, Keep Warm will hold the food at a safe serving temperature for up to 3 hours. After 3 hours, the feature will shut off automatically. You can use the keep warm feature without any other cooking operations, or you can set it to activate after a timed or delay timed cooking operation. You should not use this feature to reheat cold food.

How to use the keep warm feature

1. Press Keep Warm.

2. Press START/SET.

3. Press OFF/CLEAR at any time to turn the feature off.

How to set the oven to activate the keep warm mode after a timed cooking

1. Set Timed Cooking to start cooking

2. Press Keep Warm to use the feature

3. Cooking mode is switched directly to Keep Warm mode after the Timed cooking period has ended. In this case, you can turn off Keep Warm by pressing OFF/CLEAR
+ Press Keep Warm once again to cancel Keep Warm setting during cooking mode operation.

Note: If you turn off the 12-hour energy saving feature, the keep warm feature will operate until canceled. (12-hour energy saving's default setting : on).

Using the smart control feature

Functions that can be operated from the SmartThings app may not work smoothly if communication condition becomes poor, or the product is installed in a place with a weak Wi-Fi signal.

Please refer to the following table for the main functions that can be operated from the app.

How to connect the oven

1. Download and open the SmartThings app on your smart device

2. Follow the app's on-screen instructions to connect your range

3. Once the process is complete, the connected $ icon located on your range displays and the app will confirm you are connected.

4, If the connection icon does not turn on, follow the instruction in the app to reconnect.

To start the oven remotely

1. Press Smart Control appears in the display. The oven can now be started remotely with a connected device

Oven remote control

+ Transfer the oven setting (mode, time, temperature) from the device to the oven.

+ Remotely start the oven (Only available for Electric range)

+ Turn the oven off remotely.

+ Once cooking starts, you can change the time, temperature remotely.

+ Self clean mode cannot be started remotely.

NOTE:

Opening the oven door or pressing Smart Control will disable Smart Control and prevent you from turning the oven on remotely.

+ If itis not shown on the display, you can still monitor the oven and cooktop status and turn the oven off.

+ When oven cooking is finished or cancelled, Smart Control will turn off.

Using the voice control

To use the Range's Voice Control function, you need Bixby / Amazon Alexa App / Google Assistant App on your mobile device. Refer to the table below for all available functions.

Bixby

Start conversation with Bixby on SAMSUNG mobile by saying "Hi Bixby" or by pressing the side key.

Amazon Alexa & Google Assistant

Samsung smart home appliances are supported by SmartThings skill in Alexa & action in Google Assistant

Installation Guide

Here's how to link SmartThings account into Amazon Alexa or Google Assistant. SmartThings App and Alexa App(or Google Assistant App) should be installed on your phone

  1. Setup the supported devices to SmartThings
  2. After device setup, tap + button on the screen.
  3. Tap Voice assistant’ and link your Samsung account to Amazon Alexa. (or Google Assistant)
  4. Check the devices are visible on Amazon Alexa app. Then account linking is complete. (Check the devices are visible and set the location(homegroom) of devices in Google home app. Then account linking is complete)

Note: On/Off spec of smart control is same as guided in SmartThings app.

Using the options function

This function enables you to control various electronic contro! options. Refer to the following table for available options. The option menu is only available when the oven is not being used (not cooking).

Note: Options key location.

Temp Adjust

The temperature in the oven has been calibrated at the factory. When first using the oven, be sure to follow recipe times and temperatures. If you think the oven is too hot or too cool, you can correct the temperature in the oven. Before correcting. test a recipe by using a temperature setting that is higher or lower than the recommended temperature. The baking results should help you to decide how much of an adjustment is needed.

The oven temperature can be adjusted #35 F (#19 °C)

How to correct the oven temperature

1. Press Options for 3 seconds, and then Press 1 on the number pad.
2. Press Clock  to select higher or lower than the current temperature
3. Enter the adjustment you want to make using the number pad. (0-35)
4. Press START/SET to save the changes. © note

This adjustment will not affect the broiling or the self-cleaning temperatures. The adjustment will be retained in memory after a power failure.

Temp Unit (Fahrenheit or Celsius temperature selection)

You can program the oven control to display the temperature in Fahrenheit or Celsius. The oven has been preset at the factory to display in Fahrenheit

How to change the display from Fahrenheit to Celsius or Celsius to Fahrenheit

1. Press Options for 3 seconds, and then Press 2 on the number pad.
2. Press 1 (Fahrenheit) or 2 (Celsius) on the number pad.
3. Press START/SET to save the changes.

Auto Conversion

When you use the auto conversion feature, the convection auto conversion feature will automatically convert entered regular baking temperatures to convection baking temperatures. If this feature is activated, the display will show the actual converted (reduced) temperature. For example, if you enter a regular recipe temperature of 350 °F and press Oven Start/Set, the display will show the converted temperature of 325 °F. (Default setting : off)

How to enable or disable the auto conversion feature

1. Press  Options for 3 seconds, and then Press 3 on the number pad.

2. Press 1 (On) or 2 (Off) on the number pad.

3. Press START/SET to save the changes.

12-hour energy saving

If you accidently leave the oven on, this feature will automatically turn off the oven after 12-hours during baking functions or after 3 hours during a broil function. (Default setting : on)

How to turn the 12-hour energy saving feature on or off

1. Press Options for 3 seconds, and then Press 4 on the number pad.
2. Press 1 (On) or 2 (Off) on the number pad.

3. Press START/SET to save the changes.

Sound On/Off

Using Sound On/OFF, you can set the oven controls to operate silently.

How to turn the sound on or off

1. Press Options for 3 seconds, and then Press 5 on the number pad.
2. Press 1 (On) or 2 (Off) on the number pad.

3. Press START/SET to save the changes.

Wi-Fi On/Off

You can turn the range’s Wi-Fi connection on or off.

How to turn the Wi-Fi on or off

1. Press Options for 3 seconds, and then Press 6 on the number pad.
2. Press 1 (On) or 2 (Off) on the number pad.

3. Press START/SET to save the changes.

Note: When you turn the range’s Wi-Fi connection off, users can't set to easy setup.

Demo mode

This option is for use by retail establishments for display purposes only. (The heating element does not operate)

How to enable or disable the demo mode

1. Press Options for 3 seconds, and then Press 0 on the number pad.
2. Press 1 (On) or 2 (Off) on the number pad.

3. Press START/SET to save the changes.

Using the Sabbath feature

You can use the Sabbath feature with baking only. The oven temperature may be set higher or lower after you set the Sabbath feature. (The oven temperature adjustment feature should be used only during Jewish holidays) The display. however, will not change and tones will not sound when a change occurs. Once the oven is properly set for baking with the Sabbath feature active, the oven will remain on continuously until the Sabbath feature is cancelled. This will override the factory preset 12-hour energy saving feature. If the oven light is needed during the Sabbath, press before activating the Sabbath feature. Once the oven light is turned on and the Sabbath feature is active, the oven light will remain on until the Sabbath feature is turned off. If the oven light needs to be off, be sure to turn the oven light off before activating the Sabbath feature

How to use the Sabbath feature

  • 1. Press Bake. The default temperature is 350 *F.
  • 2. Enter the temperature you want, e.g., 375 “F, by using the number pad
  • 3. Press START/SET. The temperature display will start to change once the oven temperature reaches 175 °F.
  • 4. Press Bake and 1 at the same time for 3 seconds. The display will show SAb. Once SAb appears in the display, the oven will not beep or display any further changes. You may change the oven temperature once baking has started. Remember that the oven will not beep or display any further changes once the Sabbath feature is engaged.
  • 5. You can turn the oven off at any time by pressing OFF/CLEAR. This will turn only the oven off. If you want to deactivate the Sabbath feature, hold down
  • Bake and 1 at the same time for 3 seconds. Sab will disappear from the display.

Maintaining Appliance

Do not to attempt to activate any other program feature except BAKE while the Sabbath feature is active. ONLY the following key pads will function correctly with the Sabbath feature on: Number, Bake, START/SET and OFF/

CLEAR All other keys should not be used once the Sabbath feature is. activated.

You can change the oven temperature, but the display will not change and tones will not sound when a change occurs. (The oven temperature adjustment feature should be used only on Jewish holidays) After changing the temperature while the unit is in Sabbath mode, there is a 15-second delay before the unit recognizes the change.

You can set the Cook time function before activating the Sabbath feature.

Should you experience a power failure or interruption, the oven will shut off.

When power is returned, the oven will not turn back on automatically. SAb will be displayed in the oven control display, but the oven will not operate. Food may be safely removed from the oven while it is still in the Sabbath mode, however the oven cannot be turned back on until after the Sabbath/Holidays, After the Sabbath observance, turn OFF the Sabbath mode. Press and hold both Bake and 1 for at least 3 seconds simultaneously to turn the Sabbath mode off. The oven can then be used with all normal functions

Do not open the oven door or change the oven temperature for about 30 minutes after you have started Sabbath mode to allow the oven to reach the set temperature. Note that, for best performance, the oven fan operates only when the oven temperature is rising.

Do not cover the surface cooktop with a blech.

Self-cleaning

This self-cleaning oven uses high temperatures (well above cooking temperatures) to burn off leftover grease and residue completely or reduce them toa finely powdered ash that you can wipe away with a damp cloth.

CAUTION

+ During the self-cleaning cycle, the outside of the range will become very hot to the touch. Do not leave small children unattended near the appliance.

+ Some birds are extremely sensitive to the fumes given off during the self- cleaning cycle of any range. Move birds to another well-ventilated room.

+ Do not line the oven walls, racks, bottom, or any other part of the range with aluminum foil. Doing so will result in poor heat distribution, poor baking results, and cause permanent damage to the oven interior. Aluminum foil will melt and adhere to the interior surface of the oven.

+ Do not force the oven door open. This can damage the automatic door locking system. Use care when opening the oven door after the self-cleaning cycle is complete. Stand to the side of the oven when opening the door to allow hot air or steam to escape. The oven may still be VERY HOT.

+ Wear the glove during cleaning

Before a self-cleaning cycle

We recommend venting your kitchen with an open window or using a ventilation fan or hood during the self- cleaning cycle.

Remove the wire rack, broil pan, broil pan insert, all cookware, and any aluminum foil from the oven.

Wipe up debris from the oven bottom (Fig. 1)

The silver-colored oven racks can be self-cleaned, but they will darken, lose their luster, and become hard to slide.

Residue on the front frame of the range and outside the gasket on the door will need to be cleaned by hand. Clean these areas with hot water, soap-filled steel-wool pads, or cleansers, such as Soft Scrub. Rinse well with clean water and dry.

Do not clean the gasket. The fiberglass material of the oven door gasket cannot withstand abrasion. It is essential for the gasket to remain intact. If you notice it becoming worn or frayed, have it replaced. (Fig. 2)

Make sure the oven light bulb cover is in place and the oven light is off. @ nore

Remove oven racks and accessories before starting the self-clean mode.

How to run a self-cleaning cycle

1. Select the length of time for the self-cleaning operation, eg., 3 hours. Press Self Clean once for a 3 hour clean time, twice for a5 hour clean time, or
3 times for a 2 hour clean time The default setting is 3 hours
2. Press START/SET to start the self-cleaning cycle. The motor-driven door lock will engage automatically. @ note

+ You will not be able to start a self-cleaning cycle if the Oven lock feature is activated or if the oven's temperature is too hot.

+ The oven door locks automatically. The display will show the cleaning time remaining, It is not be possible to open the oven door until the temperature drops to a safe and cool temperature

+ The self-cleaning feature will not operate when the warming center is on.

3. When the self-cleaning cycle is done, End will appear in the display and the range will beep several times

How to delay the start of self-cleaning

1. Press Self Clean. Select the desired self-clean time by pressing Self Clean.
2. Press Delay Start Enter the time you want the clean cycle to start.
4, Press START/SET. The display will show Delay, Self clean, and the Lock icon. The motor-driven door lock will engage automatically.
5. The Self-Cleaning cycle will turn on automatically at the set time. »

How to turn off the self-cleaning feature

You may find it necessary to stop or interrupt a self-cleaning cycle due to smoke in the oven

1. Press OFF/CLEAR

2. You will be able to open the oven door once the oven has cooled down for approximately 1 hour.

After a self-cleaning cycle

+ You may notice some white ash in the oven. Wipe it up with a damp cloth after the oven cools. (If white spots remain, remove them with a soap-filled steel wool pad and rinse thoroughly with a vinegar and water mixture)

+ If the oven is not clean after one cycle, repeat the cycle.

+ You cannot set the oven for cooking until the oven is cool enough for the door to unlock.

Steam-cleaning

How to set the oven for steam-cleaning

For light cleaning, the steam-cleaning function saves time and energy. For heavier- duty cleaning, use the self-cleaning function.

Remove all accessories from the oven.

Pour approximately 10 oz. (300 mi) of water onto the bottom of the empty oven and then close the oven door.

Use normal water only, not distilled water.

Press Steam Clean.

Press START/SET.

When the operation is complete, the display will blink and a beep will sound.
Press OFF/CLEAR

Clean the oven's interior.

There will be a significant amount of water remaining on the bottom of the oven after a steam-cleaning cycle Remove the residual water with a sponge or soft dry cloth

When steam-cleaning, use exactly 10 oz. of water since this produces the best results. @ nore

If you press Steam Clean when the oven temperature is above 100’F, Hot will appear in the display. Because this function produces the best results when started while the oven is cool, we recommend that you wait until the oven has cooled down and Hot disappears from the display.

Caution: Wear the glove during cleaning.

Removing and reinstalling the oven door

How to remove the door

CAUTION

  • + The door is very heavy. Be careful when removing and lifting the door. Do not lift the door by the handle.
  • + Turn the power OFF before removing the door.

  1. Open the door completely.
  2. Pull the hinge locks down toward the door frame to the unlocked position.
  3. Firmly grasp both sides of the door at the top.
  4. Close the door to the door removal position, which is approximately
  5. degrees from vertical (Fig. 1)
  6. Lift door up and out until the hinge arm is clear of the slot (Fig. 2).

How to re-install the door

  1. Firmly grasp both sides of the door at the top.
  2. With the door at the same angle as the removal position, slide the indentation of the hinge arm into the bottom edge of the hinge slot. The notch in the hinge arm must be fully inserted into the bottom of the slot.
  3. Open the door fully. If the door will not open fully, the indentation is not inserted correctly in the bottom edge of the slot.
  4. Push the hinge locks up against the front frame of the oven cavity to the locked position.
  5. Close the oven door.

Removing and reinstalling the storage drawer

How to remove the storage drawer

  1. Pull the drawer out until it stops.
  2. Tilt the front of the drawer and pull out it.

How to replace the storage drawer

  1. Put the left side of the drawer over the left hook and the right side over the right hook.
  2. Push the drawer until it stops.

Changing the oven light

The oven light is a standard 40-watt appliance bulb. It will come on when the oven door is open. When the oven door is closed, press the  pad to turn it on or off. It will not work during a self-cleaning cycle.

  1. 1. Make sure the oven and the bulb are cool
  2. 2. Unplug the range or disconnect the power.
  3. 3. Turn the glass bulb cover in the back of the oven counterclockwise to remove
  4. 4, Turn the bulb counterclockwise to remove it from its socket.
  5. 5. Insert a new 40 watt appliance bulb. and then turn it clockwise to tighten.
  6. Replace the bulb cover by turning clockwise.
  7. 6. Plug in the range or reconnect the power.

CAUTION

Before changing your oven light bulb. disconnect the electrical power to the range at the main fuse or circuit breaker panel. Make sure the oven and the bulb are cool

Troubleshooting

- See more at page 53 in pdf file.

- Warranty: Page 58



Also, These documents are for others Samsung models: NE63*6511S*, NE63A6511SS

Tags: Samsung Electric 6.3 Air Fry Stainless, Horno Samsung Dual Cook Manual, Samsung Air Fryer Cooking Guide, Samsung Rb36r8899sr Manual, Samsung Oven Nv70k3370bs/eu, Samsung Ranges User Manuals, Samsung Ranges Use Manual

Samsung NE63A6511SS/AA | Pages: 186 | Created on: 2021-01-29 | File type: PDF | Filename: 81670034_ne63a6511ss-aa.pdf | Size: 21.01 MB | Language: English, French, Spanish | Other documents: 1 files.

Download User Manual

Specs Sheet

  • Two Dual Ring Burners Rapid Boil: 3000W
  • Voltage: 240/208V/60Hz/40A
  • Large Oven Capacity: 6.3 cu. ft.
  • Dimension: 24 13/16" W x 22 7/16" H x 19 3/4" D
  • Weight: 148 lbs
  • Oven Capacity: 6.3 cu. ft.
  • Wifi connect: Yes
  • Voice Enabled: Yes
  • Total Number of Burners: 5
  • Burner - Left Front: 6"/9", 3300 W Rapid Boil™
  • Burner - Left Rear: 6", 1200 W
  • Burner - Right Front: 9"/12", 3000 W
  • Burner - Right Rear: 6", 1200 W
  • Burner - Center: Warming Center, 100 W

Product Infomation and Reviews - NE63A6511SS/AA photo

NE63A6511SS AA Photo

View more photos

Samsung in United States

1-800-726-7864 Mon - Fri: 8AM - 12AM (EST) / Sat - Sun: 9AM - 11PM (EST) Sat - Sun: HOME APPLIANCE 9AM - 6PM (EST)
