TOOLS YOU WILL NEED
1
Installation
Custom Panel Trim Kit
Instructions
TPK6 (Use with GE Model
GMR06AAPBB, Black Model only)
Nutdriver
Phillips head screwdriver
FOR YOUR SAFETY:
WARNING
–
Unplug the refrigerator
before installing the trim kit.
PARTS INCLUDED
Plastic frame
Plastic wood panel retainers
(weight limitation for custom panels:
5 lbs. max.)
Installation Instructions
Self-threading screws (4)
MATERIALS YOU WILL NEED
A consumer-supplied laminated plastic or
wood panel must be used with this kit.
Thin Panel (recommended):
Use a commonly available, heat and scratch
resistant laminated plastic panel cut to the
following dimensions:
• Thickness – 3/32″ or less
• Width – 22
3
⁄4″
• Length – 29
1
⁄2″
Weight limitation for custom panels is
5 lbs. max.
1/4″ Wood Panel (not recommended):
Use of a 1/4″ wood panel is not recommended,
because wood’s tendency to warp may cause
the trim kit to come off from the door. A thin
plastic panel is recommended whenever
possible.
See 1/4″ Wood Panel Installation for instructions
on installing a wood panel.
197D4679P002
49-60287
06-03 JR
Printed in China
