AmazonBasics Mid Back Office Chair
Siège de bureau à demi-dossier AmazonBasics
AmazonBasics silla de oficina con respaldo medio
Amazonベーシックミッドバック オ フィスチェア
B
B0735WMNT5
B0735X2M1J
00IFHPVEU
• Please read the instructions carefully before assembly.
• Remove all parts from the carton and ensure all parts are included prior to assembly.
• Assemble the chair on the carton or a carpet to prevent scratching the floor.
• Be careful not to cross-thread screws and do not use power tools.
• Before using the chair be sure that it is completely and properly assembled.
• Lea las instrucciones cuidadosamente antes del armado.
• Retire todas las partes del cartón y asegúrese de que todas las partes estén incluidas antes del
armado.
• Arme la silla sobre el cartón o sobre una alfombra para evitar rayar el piso.
• Tenga cuidado de no enroscar mal los tornillos y no use herramientas eléctricas.
• Antes de usar la silla asegúrese de que esté armada por completa y adecuadamente armada.
• Veuillez lire attentivement les instructions avant de procéder au montage.
• Retirez tous les éléments de l’emballage, et assurez-vous qu’il n'en manque aucun avant de
procéder au montage.
• Montez le fauteuil sur le carton d’emballage ou sur un tapis afin d'éviter de rayer le sol.
• Veillez à ne pas visser les vis de travers et n'utilisez pas d'outils électriques.
• Avant d’utiliser le fauteuil, assurez-vous qu'il est complètement et correctement assemblé.
• 組み立てる前に説明書をよく読んでください。
• 組み立てる前に箱から全てのパーツを取り出し、全てのパーツが揃っていることを確認して
ください。
• 椅子の組立は段ボールかカーペットの上で行い、床に傷をつけないようにしましょう。
• ネジの条をゆがめないよう気をつけてください。電動ドリルは使用しないでください。
• 椅子を使用する前に、完全に、適正に組み立てられているか確認してください。
AmazonBasics Midback Office Chair
Caps
Wrech
Screws
Screws
Seat Cushion
1
1
1
2
1
1
5
1
4
8
8
Star Base
Seat Plate
Casters
Gas Lift & Cover
1
2
3
4
5
6
7
C
D
B
A
Back Frame
Armrests
SIZE COMPARISON CHART
A
B
7/8” Screw
3/4” Screw
4 1
1
Spare
Parts
Qty
8
6
7
• Turn the base upside down and press the casters into the holes on the legs as shown.
5
6
5
7
• Place the base upright and insert the gas lift with cover into the base as shown.
6
7
A
Attach the seat plate to the seat cushion with screws . Make sure the seat plate faces to
the front. Tighten the screws with the wrench .
D
D
A
3
2
FRONT
Step 4:
8
Align the central hole of the seat plate over the gas lift.
Press down until the connection is secure.
Step 5:
9
Attach the arms to the seat cushion with screws as shown.
DO NOT tighten the screws.
B
4
B
D
4
Step 6:
11
1
2
B
D
Attach the arms to lower nuts on the back cushion with 2 screws as shown.
DO NOT tighten the screws.
B
Step 7:
12
B
D
Push the back cushion to upright position and attach another 2 screws as shown.
TIGHTEN all the screws.
B
Step 8:
13
C
•
Press the cap into the arm holes to cover the bolts.
C
14
To raise your seat, lean forward to lift your body weight from the seat, then pull up the control
handle.
To lower the seat, pull up the control handle while you’re seated.
Control
handle
To Adjust the Seat Height
Function
15
• To unlock the tilt, pull the control handle all the way out.
• Push the control handle in to lock the tilt function.
• Rotate the tension knob clockwise to tighten or counter-clockwise to loosen the tension.
To Adjust the Tilt Tension
To Perform Tilt / Tilt Lock
Tension Knob
Control
Handle
Function
16
12.09 kg / 26.65 lbs
Use a dry cloth to remove dirt.
at theSelect
with
with
17
250 lbs.
Your office chair is equipped with casters for all types of flooring.
This office chair is alternative between Type I and Type III.
on the chair.
