4-Shelf Shelving Unit on 3'' Casters- Chrome
Unité De Rayonnage à 4 Étagères Montée Sur Des Roues De 7,6 cm- Chromée
Regal auf 7,6 cm Rollen mit 4 Regalböden - Verchromt
Scaffale a 4 Ripiani con Ruote da 7,6 cm - Cromato
Estantería Con Ruedas de 7,6 cm, 4 Estantes - Cromado
7.6cmキャスター付き4段シェルフユニット、クローム
4层滚轮（7.6 厘米）置物架- 铬合金
B0727YYPR2
English Français Deutsch Italiano Español
日本語 中文
English ........................................... 3
Français ....................................... 14
Deutsch ........................................ 25
Italiano ......................................... 36
Español ........................................ 47
日本語 ...........................................58
中文 .............................................. 69
3
English Français Deutsch Italiano Español
日本語 中文
4-Shelf Shelving Unit on 3''
Casters- Chrome
Contents:
Make sure that the package contains the following parts:
Part
Qty.
A
4
B
4
C
4
D
2
E
2
F
1
G
TOP
16
H
12
I
1
Note: Discard the protective covers
H
. These are used to separate the shelves for
shipping purposes.
Welcome Guide
•
English
G1-1pc
G2-1pc
G3-2pcs
G4-2pcs
G5-1pc
FURNITURE TIPPING RESTRAINT
J
4
4
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 1:
Setting Up the Product
TOP
T
OP
T
O
P
T
OP
TOP
C
D
E
E
D
F
G
G
A
H H
• Remove the protective covers
H
from the shelves
A
and dispose of them.
• Screw one caster
D
/
E
into the bottom of each lower pole
C
and fasten it
using the wrench
F
. Position them as shown in the illustration.
• Attach one half of the plastic sleeve
G
to each lower pole. Then attach the other
half of the plastic sleeve to each lower pole, so both halves are connected with
each other. The arrow above the TOP marks on the plastic sleeves should point
upwards. Four plastic sleeves are necessary to support one shelf.
If preferred,leveling feet can be used instead of casters for a static shelving unit.
•
Remove all items from shelving units and disassemble shelving unit before switching
between casters and leveling feet.
J
5
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 2:
Setting Up the Product
Brakes engaged
Brakes not engaged
G
G
D
E
D
C
A
• Put the first shelf
A
onto the poles
C
and lower it down until it rests on the
plastic sleeves
G
. Note:
• Attach another set of plastic sleeves to each lower pole for the second shelf
from the bottom.
Poles connected to casters with brakes should
be placed at the back, poles connected to casters without brakes should
be placed at the front of the assembly (as shown above).
E
D
6
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 3:
Setting Up the Product
C
A
G
• Put the next shelf
A
onto the poles
C
and lower it down until it rests on the
plastic sleeves
G
.
7
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 4:
Setting Up the Product
B
B
C
C
• Screw the upper poles
B
onto the lower poles
C
in a clockwise direction.
9
English Français Deutsch Italiano Español
日本語 中文
Assembly
Step 6:
Setting Up the Product
G
G
B
A
• Put the next shelf
A
onto the poles
B
and lower it down until it rests on the
plastic sleeves
G
.
• Attach another set of plastic sleeves to the upper poles.
10
Assembly
Step 7:
Setting Up the Product
• Put the last shelf
A
onto the poles
B
and lower it down until it rests on the
plastic sleeves
G
. Place cardboard over the corners of each shelf and gently tap
down with a rubber mallet (or similar tool) until the shelf is level.
• To improve stability (if needed), drill two tiny holes (Ø 4 mm) into the wall and
insert the dowels
I
A
G
B
I
. Secure the shelf to the wall by installing the Furniture Tipping
Please read and install the tipping restraint. The shelf is now sec
Restraint hardware. The full instructions are inside the hardware bags.
Wall
11
Cleaning and Maintenance
• Wipe with a dry cloth as needed to remove dust and dirt.
• Avoid contact with corrosive substances like acids, alkaline or similar
substances.
Safety and Compliance
• Warning: Do not let children climb on or play with the unit.
• Handle with care.
• For ease and efficiency, the product should be assembled by two adults.
• Regularly check if all screw connections are tight and if all shelves are attached
in a stable way.
• To avoid scratching the floor, assemble the shelving unit on a soft surface such
as a carpet.
• Warning: Make sure not to drill into water or electricity lines when securing the
shelving unit on the wall.
Use a wire tracer and/or a water pipe finder if necessary.
• Load the unit evenly and place the heaviest items on the lower shelves.
Maximum Load US Standard Metric
Shelving unit with wheel
Static 440 lbs 200 kg
In motion 353 lbs 160 kg
One single shelf with wheel 110 lbs 50 kg
Shelving unit with leveling feet Static 1400 lbs 635 kg
Static 350 lbs 156 kgOne single shelf with leveling feet
English Français Deutsch Italiano Español
日本語 中文
12
Warranty Information
To obtain a copy of the warranty for this product:
Visit amazon.com/AmazonBasics/Warranty
— or —
Contact Customer Service at 1-866-216-1072
13
Feedback
Love it? Hate it?
Let us know with a customer review.
AmazonBasics is committed to delivering customer-driven products that live up to
your high standards. We encourage you to write a review sharing your experience
with the product.
Please visit: amazon.com/review/review-your-purchases#
For further services:
Visit amazon.com/gp/help/customer/contact-us
— or —
Contact Customer Service at 1-866-216-1072
