INSTALLATION DIAGRAM:
INTRODUCTION
WARNING!
1. Please make sure to turn off the power before starting the installation.
2. Installation should only be done by a certified electrician.
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these
instructions carefully before starting the installing and keep this manual handy for future reference.
If you have any another query, please contact our dealer or local vendor from whom you have
purchased the product. They are trained and ready to serve you at the best.
TECHNICAL DATA
This marking indicates that this
product should not be disposed
of with other household wastes.
SPOTLIGHT FITTING
INSTALLATION INSTRUCTION
• Switch off the power.
• Drill the appropriate hole on the ceiling, then put the plastic wall plug into the hole (Pic 2 and 3).
• Install GU10 lamp into the holder & the fitting (Pic 4).
• Connect to the AC wires & install the fitting into the bracket (Pic 5 and 6).
• Switch on the power if above steps done properly without any mistakes (Pic 7)
Model VT-882SQ VT-882RD
Shape Square Round
Base GU10 GU10
IP Rating IP20 IP20
Dimension 74x74x140mm Ø80x140mm
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
