Power ltering
LED indicator
Touch light
control
Advanced protection
LED indicator
USB ports
AC outlets
AC adapter
spaced outlet
Main power switch
Circuit
breaker
QUICK SETUP GUIDE
RF-HTS4119 Premium 6-Outlet Power Center
OVERVIEW
• Main power switch: Controls power on and o to all AC outlets and
USB ports. Press once to turn on the power center. Press again to turn
it o.
• Touch light control: Controls light tracing around AC outlets and
USB ports. Touch once to turn on the light. Touch again to turn o.
• Circuit breaker: Shuts o all power to the Power Center, and allows
the unit to be reset in the event of a circuit overload (after the
overload condition has been resolved). Make sure that the circuit
breaker is in the “RESET” position before using the power center.
• Advanced protection LED indicator: Lights to indicate the
advanced surge protection is working properly. If this LED does not
light or goes out, the surge protection feature has reached full
capacity and can no longer absorb additional surges and spikes. The
Power Center should be replaced if this light goes out.
• Power ltering LED indicator: Lights to indicate the advanced
two-stage power ltration is working properly and removing
interference from the incoming power. The Power Center should be
replaced if this light goes out.
Before using your new product, please read these instructions to prevent any damage.
Final flat size: 10.24 × 8.88 in. (260 × 225.55 mm)
Final fold size: 5.11 × 8.88 in. (130 × 225.55 mm)
PACKAGE CONTENTS
• Premium 6-Outlet Power Center
• Quick Setup Guide
FEATURES
• Provides surge protection for sensitive electronic devices
• Incorporates noise ltering to provide “clean” power that will
maximize the performance of your equipment
• Six outlets to easily connect your TV and AV components
• Fireproof 2,880 joules surge protection: Protects your devices from
damaging power surges and spikes
• 57 dB EMI/RFI noise ltering: Makes sure that your devices receive
only “clean” power for maximum product performance
• Four USB charging ports with 4.8 A of total charging current
• Two AC adapter spaced outlets: Accommodates bulky AC adapter
plugs
• 6 ft (1.8 m) braided outer jacket power cord with right-angle/o-set
plug: Enables placement of the Power Center in the desired location.
The right-angle plug allows you to place furniture as close as
possible to the wall and not block the second AC outlet.
• Smart IC built-in: Allows for faster charging of select phones and
other devices
• Brushed metal decoration: Understated look matches today’s latest
audio video components
