Fisher & Paykel DH8060P3 - 8kg Heat Pump Condensing Dryer User Manual

INSTALLATION GUIDE / USER GUIDE

NZ AU

HEAT PUMP CLOTHES DRYER

DH8060P model

CONTENTS

IMPORTANT!

SAVE THESE INSTRUCTIONS

The models shown in this User guide

may not be available in all markets

and are subject to change at any time.

For current details about model and

specification availability in your country,

go to our website fisherpaykel.com or

contact your local Fisher & Paykel dealer.

Registration

provide you with the best service possible.

To register your product visit our website:

fisherpaykel.com

Introduction 3

Safety and warnings 4

Installation instructions 8

Control panel 13

Drying cycles 15

Sorting and loading 16

Getting started quickly 19

Customising drying cycle 20

Caring for your dryer 22

Before you call for service 25

Fault codes 26

Troubleshooting 27

Manufacturer’s warranty 33

Customer care 35

INTRODUCTION

Welcome to your new heat pump clothes dryer

Thank you for purchasing a Fisher & Paykel clothes dryer. We are proud of this dryer

andtrust it will serve you well for many years.

At Fisher & Paykel we aim to provide innovative products that are simple to use,

ergonomic, energy efficient and kind to the environment. Thousands of tonnes of

laundry and 80 years of experience have been programmed into your dryer tohelp

giveyou the best possible performance.

Your dryer has the benefit of heat pump technology, which allows clothes to be dried

atlower temperatures, improving clothes care while saving energy. This dryer also

hasthe advantage of not needing to be vented outside, instead it condenses the

moisture from the clothes and collects this in a water tank, or for convenience, can

pump it directly into a drain.

Your new dryer gives you the convenience of tumble drying and your clothes the

advantage of not being subjected to the harsh over drying effects of the sun.

Yourclothes will feel softer, retain their shape and require less ironing. This dryer has

been specifically designed to complement our front loading Fisher&Paykel washers.

Your heat pump dryer has numerous cycles and options so you can perform every

drying task (including flat drying) with ease, allowing you to spend less time in the

laundry. With the ability to automatically sense when your clothes are dry, your dryer

ismore efficient, making it kinder on your wallet and the environment.

Please take the time to read these instructions carefully before you begin using your

dryer. Following the advice in this user guide will ensure you get the performance

you expect from your dryer and that you get the best possible results. Keep these

instructions for future reference and pass them on with your dryer, if it changes hands.

We hope you enjoy your new dryer. We have certainly enjoyed designing it for you.

Heat pump clothes dryer

SAFETY AND WARNINGS

Meaning of symbols on the dryer

Warning: Risk of fire/Flammable materials

Read the instructions

WARNING!

Fire Hazard

Only dry fabrics that have been washed with water.

Do not use heat to dry articles containing foam rubber or similarly

textured rubber–like materials, dry on ‘Air Dry’.

Never stop a tumble clothes dryer before the end of the drying

cycleunless all items are removed and spread out in order to dissipate

the heat.

A clothes dryer produces combustible lint; the lint filter must be

cleaned before each drying cycle.

Failure to follow the warnings outlined in these user instructions can

cause a fire hazard.

Failure to follow these instructions can result in death or personal injury.

IMPORTANT SAFETY INSTRUCTIONS

WARNING!

The appliance must not be supplied through an external switching device, such as a

timer, or connected to a circuit that is regularly switched on and off by a utility.

We do not recommend the use of extension cords or portable electrical outlet devices

for safety reasons.

Do not touch or operate the machine with wet hands or with bare-feet.

A damaged power cord must be replaced by a Fisher & Paykel trained and supported

service technician, its service agent or similarly qualified persons in order to avoid

a hazard. The appliance must not be operated until it is repaired, as there is risk of

electric shock.

Do not operate this machine if it has been damaged during transport. Contact your

Fisher&Paykel dealer or Fisher & Paykel trained and supported service technician.

SAFETY AND WARNINGS

When using this appliance always exercise basic safety precautions including

the following:

Dryer use

This dryer has been designed for domestic use only, not for commercial applications,

such as massage/beauty clinics where there may be increased lint accumulation or

flammable materials in the atmosphere or load.

The tumble dryer is intended only for drying textile material washed in water.

Undergarments that contain metal reinforcements should not be placed in the dryer.

Damage to the dryer can result if the metal reinforcements come loose during drying.

If you wish to dry these items use a drying rack or place in a garment bag.

Check and remove all objects from pockets, eg lighters and matches.

Never dry rubber articles, or any plastic items or film, eg plastic lined tablecloths

andbaby bibs.

Clothes should go through the cool down/airing phase in the final part of the cycle.

This ensures items are left at a temperature where they will not be damaged. Ifforany

reason the dryer is stopped before the cycle has finished, dry clothes should be

removed immediately and not left in the dryer. Clothes should be quickly spread out

flat to cool so heat can dissipate, not left bunched up, eg in a clothes basket.

Do not operate this product without the lint filter in place or allow lint to accumulate

in or around the dryer.

This dryer is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge,

unless given supervision or instruction concerning the use of the dryer by a person

responsible for their safety.

Children should be supervised to ensure they do not play with the dryer.

Unplug the machine from the power supply when it is not in use.

Do not swing on or put weight on the door.

Your dryer is designed to stop operating in the event of power outage.

When power isresumed, the machine will remain off until the ‘Power’ button is

pressed. To restart the dryer, press ‘Power’, select your drying cycle and touch .

Never attempt to repair the dryer yourself.

The only user-removable parts of the dryer are the lint filter, drying rack and

reversible console. No other parts are designed to be removed by anyone other than

aFisher & Paykel trained and supported service technician.

For problems that cannot be solved from information in this User Guide, turn off and

unplug your dryer and contact a Fisher & Paykel trained and supported service technician.

Do not overload your dryer beyond its rated capacity (eight kilograms of dry clothes).

Never put dripping wet clothes in or on top of the dryer as excess water may cause an

electrical hazard.

Do not under any circumstances dry an electric blanket or any other electrical, plastic

or rubber items in your dryer, unless the care label specifically states it is safe to do

so. Never dry these items at high temperatures.

Do not dry curtains in your dryer. Sunlight makes them brittle and they may

disintegrate during drying.

Do not use the water collected in the water tank for drinking or food processing.

Never run the dryer without the water tank in place.

If the water tank becomes full, the tumble dryer will pause drying and will sound an

alarm. You must empty the water tank before the dryer can continue drying. Empty

the tank, replace it back in the housing then touch to resume the cycle.

SAFETY AND WARNINGS

Lint

Accumulated lint in the dryer can become a fire hazard; it also reduces the efficiency

of the dryer by causing longer drying times and increased power consumption.

Clean the lint filter before every load.

Ensure the area around the dryer is clear of lint.

At regular intervals have the interior of the dryer cleaned of any accumulated lint.

This must be done by a Fisher & Paykel trained and supported service technician.

This must be done when the dryer installation is changed from free standing.

The dryer exhaust ducting should be inspected and cleaned periodically to remove

accumulated lint.

If the lint filter becomes damaged, contact your Fisher & Paykel trained and supported

service technician to arrange getting a new filter. Do not operate your dryer with a

damaged lint filter or without the filter in place, as this will cause damage to your dryer.

Installation

The dryer must be installed in a well-ventilated, dust-free environment.

The dryer must not be installed on any textured floor coverings (eg carpet, rugs) to

ensure that openings at the base of the machine are not obstructed.

Do not install the dryer behind a lockable door, sliding door, or behind a door where

the hinge is on the opposite side to that of the dryer in such a way that the full

opening of the door is inhibited. Ensure the dryer door can always be opened fully.

Please refer to INSTALLATION INSTRUCTION section of this document for detailed

installation steps.

SAFETY AND WARNINGS

Spontaneous combustion

IMPORTANT!

To reduce the risk of fire in a tumble dryer the following should be observed:

Items that have been spotted or soaked with vegetable oil or cooking oil are a fire

hazard and should not be placed in a tumble dryer.

Oil-affected items can ignite spontaneously, especially when exposed to heat sources

such as a tumble dryer. The items become warm causing an oxidation reaction in the

oil. This oxidation creates heat. If the heat cannot escape the items can become hot

enough to catch fire. Piling, stacking or storing oil-affected items can prevent heat

from escaping creating a fire hazard.

If it is unavoidable that fabrics that contain vegetable oil, cooking oil or have been

contaminated by hair care products be placed in a tumble dryer, they should first be

washed in hot water with extra detergent — this will reduce, but not eliminate the fire

hazard. The cool down cycle of the dryer should be used to reduce the temperature

ofthese items. They should not be removed from the tumble dryer and piled or

stacked while hot.

Items that have previously been cleaned in, washed in, soaked in or spotted with

flammable liquids or solids, eg petrol/gasoline, kerosene, dry cleaning solvents,

vegetable or cooking oil, acetone, denatured alcohol, some brands of spot removers,

turpentine, waxes and wax removers or other flammable or explosive substances

should not be placed in a tumble dryer.

Do not dry unwashed items in the tumble dryer.

The dryer is not to be used if industrial chemicals have been used for cleaning.

Fabric Softeners or similar products should not be used in a tumble dryer to

eliminate the effects of static electricity, unless this practice is specifically

recommended by the manufacturer of the fabric softener product.

Rubber backed articles, foam rubber (latex foam), clothes or pillows fitted with

foam rubber pads, fibreglass, shoes containing rubber, shower caps, babies

waterproof napkin covers and waterproof textiles should not be dried in the dryer.

These materials can when heated produce fire by spontaneous combustion.

When choosing to tumble dry a duvet/doona use low-medium heat only and make

sure the drum is not overloaded due to the risk of overheating and scorching.

Exhaust air must not be discharged into a flue which is used for exhausting fumes

fromappliances burning gas or other fuels.

Disposal

Extreme care must be taken when disposing of your old appliance to avoid hazards.

When disposing of the dryer, it is recommended that the door is removed to avoid

children getting trapped inside, and that the electrical cable is cut off close to the dryer.

INSTALLATION INSTRUCTIONS

Read and follow the ‘Safety and warnings’ and ‘Installation instructions’ sections

carefully before using your dryer.

Moving your appliance

When moving your dryer only tip towards the right hand side (when viewed from

thefront). If the dryer has not been transported as described, leave it standing

uprightfor at least one hour before turning on.

Accessories

Check you received the following accessories with your Fisher & Paykel dryer.

You will find them inside the drum:

1 x Drying rack

1 x Drain hose

1 x Installation guide / User guide.

Unpacking

To ensure the best performance from your new dryer please follow the instructions below.

Removing the packaging

1 Remove the outer packaging (including the polystyrene packer and plastic wrapping).

All packaging must be removed prior to use.

2 Tilt the machine backwards and ‘walk’ it off the base one foot at a time.

Notdoingsomay cause damage to your floor and dryer.

3 Remove all packaging and accessories from inside the drum and ensure you

removeprotective covers from door and console.

Ensure packaging materials are kept out of reach of children.

Location

This dryer CANNOT BE INVERTED AND MOUNTED

ON THE WALL.

Free standing

INSTALLATION INSTRUCTIONS

Installation options

Your dryer can be installed one of two ways, either freestanding, or stacked on top

ofaFisher & Paykel front loading washer.

Freestanding

The dryer stands on the floor and can easily be moved into position.

Stacking

Your dryer has been designed to be able to be stacked on top of a Fisher & Paykel

front loading washer. A stacking kit MUST BE USED between the products and fitted

correctly to the washing machine and dryer, as per the stacking kit instructions.

– Stacking Kit White: Part No. 427976.

1 Move the machine into the desired position. Do not lift the dryer by the top panel.

2 Have a minimum clearance on all sides of at least 20mm.

3 Install the machine on a stable and level floor (if not stacking on top of a front

loadingwasher).

Do not install your dryer in such a way that the dryer door cannot be opened fully.

Do not install the dryer outside, in a damp place, where there is a risk of freezing,

whereit may be rained on, in direct sunlight or close to a source of heat.

Do not place your machine on top of its power cable.

Levelling the machine

It is IMPORTANT to level the machine to ensure the machine runs efficiently with minimal

noise. The dryer should be levelled in as close to its final position as possible so it stands

balanced evenly on all four feet. Ensure the dryer does not rock in any direction.

The dryer comes with four adjustable feet, wind

all four feet up or down until the dryer is correctly

level. A spirit level can assist with this process.

The machine is considered level when the bubble

sits in the centre (ie within the two lines or the

circle), when the spirit level is placed flat on top

of your dryer, in the directions from:

1 left to right

2 back to front, and

3 corner to corner.

Never unscrew the feet completely from their housings.

Note: After levelling, the corners of the dryer cabinet should be clear of the floor

andthemachine must not rock in any direction.

Levelling the feet

INSTALLATION INSTRUCTIONS

Draining

The dryer is equipped with a condenser unit which accumulates water during the

dryingcycle. This water is collected in the removable water tank located at the top

leftof the dryer. The accumulated water must be emptied after each drying cycle.

However you can also set up your dryer to drain automatically using the drain

hoseprovided.

Connecting the drain hose:

1 Remove the black hose from the connection at the back of the dryer (A).

2 Uncoil the drain hose (included with your dryer) and connect it to the black hose(B).

3 Place the other end of the drain hose into a tub or standpipe.

If you connect the drain hose onto your dryer, the other end must be secured in a

drain to prevent water draining onto the floor. Ensure the drain hose is securely fixed

in place to an appropriate drain and is leak-free at the connection to the machine.

Check the connection and drain hose regularly.

Maximum standpipe height is 1.0m from ground level.

Regularly check that your standpipe or tub is free from lint and other obstructions,

which may affect drainage and cause flooding.

The drain hose should be checked from time to time and replaced if any damage,

egwear, cuts, bulges, kinks, leaks, etc are found. Do not bend the drain hose sharply,

asthismay cause it to split.

The extended length of the provided drain hose is 1.3m.

In multi-storey apartments or any upper floor, the machine should be installed on

afloorequipped with a drain.

Draining must comply with local by-laws.

INSTALLATION INSTRUCTIONS

Electrical connection

1 This appliance must be connected to a 220V – 240V,50Hz, sinusoidal, 10Aelectricalsupply.

2 Uncoil the power cord, remove and discard the plastic pin cover and plug into a

powersocket.

3 Connect the appliance to an earthed outlet protected by a fuse of suitable capacity.

Check the power cord for damage and make sure it is not squashed or twisted

wheninstallingthe dryer.

Always remove the power cord from the power socket by the plug, not by the cord.

Completing the installation

Installation test cycle

Ensure the installation test cycle is completed before you dry any items in your dryer.

This is to check that your dryer is installed correctly and that it is functioning properly

prior to use.

1 Turn your dryer on by pressing the ‘POWER’ button.

2 Select the ‘Time Dry’ cycle for 30 minutes. Ensure the drum is empty and the door

isclosed (you will hear it click shut).

3 Touch the button. The drum will start rotating.

– Observe the machine for any problems.

– The dryer will beep and display any faults on the screen if there are any problems.

Refer to ‘Before you call for service’, ‘User warnings’.

4 At the completion of the cycle, open the door and check that there is warmth inside

thedryer. This indicates the dryer is operating normally.

If there are any problems, you must address these before proceeding with normal use.

The dryer will automatically turn off at the end of the cycle if there are no problems.

INSTALLATION INSTRUCTIONS

Before you start, it is a good idea to go through the following checklist:

1 Has the packaging been removed?

2 Is the machine correctly levelled, and are the cabinet corners clear of the floor and walls?

3 Are the water tank, condenser filter and lint filter correctly in place?

4 Has the power cord been connected to an appropriate power supply and the power

turnedon?

5 Have you performed the installation test cycle?

6 If external draining is preferred, is the drain hose attached to the correct outlet and

hooked into a standpipe or tub?

Machine specifications

DH8060P

Capacity (kg)* 8

DIMENSIONS (mm)

Width 595

Depth 650

Height** 845

Length of drain hose 1300

ELECTRICAL

Volts 220 – 240

Hz 50

Amps (maximum) 10

Power consumption (W) 900

* Capacity refers to the maximum dry weight of items the machine can dry at any one time.

Note:somecycleshavealower maximum capacity (see the ‘Drying cycles’ section).

** The exact height of your dryer is dependent on how far the feet are extended from the base of the machine.

CONTROL PANEL

POWER Press to turn the dryer on/off.

Keylock Touch and hold for two seconds to disable all buttons on the display

panel, except ‘POWER’ button. This prevents accidental button presses.

SmartTouch™

control dial

Rotate to select your desired drying cycle.

The icon illuminates to indicate the selected drying cycle.

Digital display

screen

Shows the following:

How long the drying cycle has to go.

Delayed start time of the drying cycle.

Notifications if an error is detected or a warning is necessary.

Progress

lights

The progress lights indicate what part of the cycle the dryer is currently

on (‘Dry’, ‘Cool’ or ‘End’). All three lights are on at the beginning of the

cycle. The light for the current part of the cycle flashes, and each one

goes out when that part of the cycle is complete.

Delay Start

Touch ‘More’

to increase the delay start time for drying cycles.

Dryness Level Allows you to select the level of dryness for your load.

Dry Temp Allows you to select the drying temperature for your cycle.

Wrinkle Free Allows you to select a wrinkle free option for your cycle.

Signal This button has two functions:

Alert you that the dryer has finished.

Alert you to remove items once your load reaches the damp/dry stage.

Water tank,

Condenser,

Lint Filter

The lights will flash when the machine is switched on as a

remindertoempty the water filter, condenser or clean the lintfilter.

The warning light will also flash on and off during the cycle if the

filtersbecome blocked.

START/PAUSE Touch to start or pause the selected drying cycle.

2 3 8 976 !0 !1

Timed cycles (Time Dry, Rack Dry, Wool)

When a timed cycle is selected the machine dries for the selected time regardless

ofthelevel of moisture in the load. It is important to check the items throughout

thetimed programmes to avoidover drying.

Timed programmes of 10 to 150 minutes can be selected using the ‘More’

and‘Less’ buttons.

Airing/Cool down (Cool)

When the dryer has sensed that the load is dry it will

automatically go into an airing or cool down cycle.

During‘Cool’ the drum tumbles and cool air is blown

throughthe clothes. This cools the load to reduce creasing

ifthe clothes are left in the dryer.

Time to go

Your dryer displays approximately how many minutes the cycle you are

running has remaining if you have chosen one of the Time Dry cycles.

Ifyou have chosen an automatic cycle (ie not ‘Time Dry’) the word

will appear on the screen until it reaches the cool down phase,

atwhich time the dryer will display how long the cycle has left to go.

Be aware that a number of factors can influence the overall cycle time,

eg the fabric type of garments, load size, the wetness of the load,

environmental conditions etc.

Indicators

There are a number of indicators to alert you when you need to attend

to your dryer, either to clean the lint filter, empty the water tank

or toclean the condenser filter (refer to the ‘Caring for your dryer’

sectionfor more information).

Keylock

This option enables you to deactivate the buttons on the display panel, except for

the‘POWER’

and buttons. This option helps prevent accidental button touches.

To turn Keylock ON or OFF, at any time when the dryer is powered on:

Touch the button for two seconds.

Note: When activated the button is illuminated.

If Keylock is activated and the dryer is off:

Press the ‘POWER’ button, then touch the button for three seconds to turn

Keylockoff. Select your drying cycle, any options and then touch to start the cycle.

CONTROL PANEL

Cool down mode

Time to go

Indicators

DRYING CYCLES

Your dryer has a number of drying cycles to suit your laundry needs. Selecting the most

appropriate cycle for each particular load will help ensure you get the best result.

CYCLE DESIGNED FOR DESCRIPTION

MAX.

LOAD

SIZE (KG)

DEFAULT

DRYNESS

LEVEL*

DEFAULT

DRYING

TEMP

Everyday

Everyday clothing

egt-shirts, trousers.

High heat cycle for rapid

dryingof everyday clothing.

8 Dry High

Heavy Heavy durable garments,

eg work sweatshirts/

jerseys, rugby shorts,

jeans, tea towels.

A longer, high heat cycle for

heavy fabrics and denim.

8 Dry/

Extra Dry

High

Delicate Delicate clothing items,

egsynthetics, silk

andfine fabrics.

A shorter, cooler cycle for

carefully drying delicate

andheat sensitive fabrics.

4 Dry Low

Easy Iron Business shirts

andclothing that

creaseseasily.

A short, medium heat cycle

with the ‘Wrinkle Free’ option

isautomatically selected for

easily creasable items.

4 Damp/Dry Medium

Sheets Sheets, pillowcases

andduvet/doona covers.

High heat cycle with reversing,

to improve the movement

oflarge items such as sheets

andduvet/doona covers

andhelp reduce tangling.

4 Dry High

Towels Towels. High heat cycle for drying thick,

absorbent items such as towels.

6 Dry High

Bulky Bigger items like jackets

and duvet/doona covers.

A medium heat cycle for the

special care of bulky items.

4 Dry Medium

Sports Sports clothing,

egrunning gear.

A low heat cycle designed to

care for synthetic sports clothing.

4 Dry Low

Wool Woollen items,

egjerseys.

A low heat cycle for use with

the drying rack to dry machine

washable woollen items without

tumbling. User selectable drying

times of 30 – 150 minutes.

3 n/a Low

Rack Dry Items that cannot be

tumbled, eg shoes, hats,

delicate garments.

Specifically for use with the

drying rack so items can be

dried without tumbling.

3 n/a Low

Freshen Items that have been in

storage or have not been

worn/used for some time.

A short cycle with a burst of

heat followed by cool air to help

de-wrinkle and refresh items.

2 n/a High

Time Dry Drying items for a

selected time period.

A cycle with user select

10 – 150minute drying times.

8 n/a High

Air Dry Drying items for a

specific time period,

without heat.

40 minute cycle with no heat. 4 n/a No Heat

* Dryness level is only an option on automatic sensing cycles. On ‘Time Dry’ and the ‘Rack Dry’ cycle,

drynesswillvary depending on the load and its initial moisture content.

** ‘Everyday’ cycle, ‘Dry’ dryness level and ‘High’ drying temp is the recommended cycle for everyday cotton items.

SORTING AND LOADING

When preparing your load there are some important things to consider:

Sorting

We recommend sorting your garments before placing them into the dryer.

Sortintoloads of similar items, and loads that will likely take similar times to dry.

Heavier items (egtowels, and flannelette sheets) are best dried separately from

lightweight items (egsynthetics, polyester-cotton sheets and shirts). This prevents

thepossibility of some items becoming over-dried whilst others are still damp.

Itwillalso help to extend the lifeofyour clothing and linen.

Care labels on garments provide valuable information about the fabric type and

howthegarment should be dried. Always follow the advice on garment labels.

Onlydryitems in this dryer that have a care label stating tumble drying is suitable.

Drying your clothes as soon as you remove them from the washer will decrease

thechance of wrinkles forming, and dye transfer from coloured items to white items

fromoccurring.

Separate coloured items from white/light items where possible, especially when new.

Colour run may be an issue, especially if you intend to delay the start of the drying cycle.

We recommend that articles of clothing with screen-printing are turned inside out

toprevent damage to the print. Garments with hooks or zippers should be fastened

andwhere possible, turned inside out.

SPECIFIC

ITEM/DRYING

REQUIREMENTS

SUGGESTED

CYCLE AND

OPTIONS

SUGGESTED

TEMPERATURE

COMMENTS

Towels Towels High Towels produce a lot of lint and are best

dried on their own.

Sheets, pillowcases,

duvet/doona covers

Sheets High Ensure duvet/doona cover openings are

buttoned/domed before placing inthe dryer.

Bulky items –

doonas,duvets,

sleeping bags,

jackets

Bulky Medium Dry only one bulky item at a time and place

a knotted towel into the machine at the

same time to ensure thebulky item moves

aroundevenly.

Business shirts,

trousers, other

creasables

Easy Iron Medium ‘Wrinkle Free’ is automatically selected to

help minimise creasing once the drying cycle

has finished.

Woollens, silks Wool Low Designed for items that could be damaged

if they are tumbled, eg woollens. Use the

drying rack.

Delicates, fine

fabrics

Delicate or

Rack Dry

Low You can further reduce the dryness level to

damp or use Rack Dry for verydelicate items.

Jeans Heavy High Turn jeans inside out to help maintain their

appearance. Dry separately from other items.

Shoes, hats, soft

toys or other odd

shapeditems

Rack Dry Low Check on the item regularly throughout

the drying cycle. Ensure the rack has been

correctly fitted. Only dry shoes on ‘Low’

drying temp.

SORTING AND LOADING

Before you load

Check pockets for items that could damage your clothes or get caught in the dryer.

Close zippers, hooks and eyes, and other fastenings (ie fasten the openings of

duvet/doona covers), and remove loose bra wires. These may damage both your

dryerand your clothes.

Check the lint filter is clean and the water tank is empty (if the dryer is not set up

todrain automatically).

Garments need to be loaded correctly to minimise creasing and wrinkling, and to

ensurethe load is dried evenly.

Allow enough room in the dryer for clothes to tumble freely. (Hint: load the dryer in

terms of the space the garments take up when dry, rather than when they are wet).

Shake clothes out and load individually to help items dry evenly and reduce tangling.

Only dry a sheet load up to a maximum of 4kg in the dryer at one time.

Dry permanent press garments (business shirts) together on the ‘Easy Iron’ cyclewith

the ‘Wrinkle Free’ option on. This will help reduce wrinkling and the need forironing.

Hang garments as soon as the drying cycle is complete to reduce the need for ironing.

Drying times

Drying very small loads is inefficient. Try to dry medium to large loads.

Heavier items (towels, flannelette sheets) will take longer to dry than light items

(synthetics and polyester cotton sheets and shirts).

Drying times can be reduced by spinning the wash load at the highest spin speed

suitable for the load type in your washing machine.

Check bulky items during the cycle to ensure even drying. Pause the dryer and

reposition the item if necessary.

Lint

Some items are lint givers, while others are lint collectors. Always dry lint givers

and collectors separately.

LINT GIVERS LINT COLLECTORS

Towels Synthetics eg polar fleece

Flannelette sheets Corduroy

Polyester cottons

Delicate or easily damaged items (eg woollen or silk garments, nylon stockings, fine

fabrics, delicate embroidered fabrics) should be dried separately, using the ‘Delicate’or

‘Ultra Delicate’ cycle, or if you do not want them tumbled use the ‘Wool’ or ‘Rack Dry’

cycle. Sleeping bags and other down items should be dried on the ‘Bulky’ cycle.

Drying rack

There are many items that would benefit from

being dried on a dryingrack. For example items

such as sport shoes, soft toys, hats andwoollen

items that may be damaged if they are tumbled.

A drying rack is installed in your dryer when

it leaves the factory. Toremove it, tilt the top

of the rack towards you to detach the legs

fromthe slots in the lint filter, and gently remove

from the drum.

When you are using the drying rack you must

select the ‘Rack Dry’ or ‘Wool’ cycle.

If the Rack is not properly installed or if a

garment has fallen from it, a user prompt

will appear on the digital display screen.

ReplacetheRack and touch the to

resumethecycle.

SORTING AND LOADING

Drying rack

Drying rack cycle

GETTING STARTED QUICKLY

Check the lint filter is clean and the water tank is empty before every load.

Ensurebothare replaced correctly before using your dryer.

Sort and load items into the dryer drum, ensuring no items are in the way of the door.

Close the door (you will hear it click shut).

1 Press ‘POWER’ to activate your dryer.

2 Your dryer will default to the ‘Everyday’ cycle. Select your desired drying cycle by

turning the SmartTouch™ Control Dial.

3 Select your preferred drying options, using the SmartTouch™ buttons on the

righthandside of the panel (if you wish to select options different from the default

options for thecycle).

4 Touch the button to start the cycle.

If you make an invalid selection the dryer will beep to alert you.

When the cycle finishes, your dryer will beep and then turn off automatically.

If the‘Wrinkle Free’ option has been selected the machine will rotate the drum

periodically blowing cool air into the drum to help minimise wrinkling and creasing

ofyour load.

If you wish to change a cycle or select a different option once a drying cycle has

started, touch the button then select the new cycle or option. Touch to restart

thedryer with the new cycle and/or settings.

If you wish to stop the dryer before the cycle has finished, you MUST remove

theclothes IMMEDIATELY and spread them out to cool. DO NOT leave the clothes

in thedryer or bunched up in a clothes basket. Take extreme care as the drum

andtheload items may be hot.

Failure to follow the advice in this guide may result in damage to your garments

andyour expectations of drying performance may not be met.

Delay Start

The ‘Delay Start’ option enables you to delay the start of the drying cycle from

between15minutes and 12hours. Delayed start options are15minutes, 30minutes,

1hour, then hourly up to 12hours. This can be useful to time your drying to finish

whenyou arrive home from work, or to start when power rates are lower.

To ‘Delay Start’ your cycle:

1 Select the cycle.

2 Press ‘More’ to increase the delay time.

3 Press to confirm your selection and start the countdown.

4 The display will indicate the time until the cycle will start.

To decrease or turn off ‘Delay Start’:

1 Press ‘Less’ to decrease the delay start time or to turn ‘Delay Start’ off.

Avoid using ‘Delay Start’ for damp, non-colourfast items asthismay cause dye run to

occur.

Drying Cycle Options

All drying cycles default to the recommended options for that cycle based on

the average expected load to be dried using that cycle. You can vary the options

(eg‘Dryness Level’, ‘Dry Temp’) to create your desired cycle.

After using your dryer a few times you may discover there are some drying options

youprefer for some cycles. You can programme your dryer to remember the

dryingoptions you prefer for each drying cycle. For instance, you may want to set

the‘Easy Iron’ cycle to a lower drying temperature or programme the ‘Everyday’

cycleso it automatically has the ‘Wrinkle Free’ option selected.

To change a drying cycle option:

1 Press ‘POWER’ to turn the machine on.

2 Turn the dial to select the cycle you wish to customise.

3 Touch and hold any of the drying options buttons for three seconds. The lights will

flash on and off and the display will show ‘ ’ to indicate that the machine is in

cycleadjustment mode.

4 Select the drying options you prefer by touching the relevant option button.

5 Touch to save the selected settings. The dryer will beep to indicate your customised

cycle has been saved.

Note: Touching before pressing will exit the cycle adjustment mode and start

thecycle using the settings shown on the display panel.

To change the cycle or options you have selected after a cycle has started:

Touch and select your new cycle or options, then touch again to resume drying.

Note: Some options may not be available for selection under certain conditions

andafter particular stages of the drying cycle have passed.

CUSTOMISING DRYING CYCLE

DESCRIPTION OPTIONS

Dryness Level

When your dryer senses that the

clotheshave driedto the dryness level

selected, the dryer willautomatically

finish thecycle.

Note: Two lights are used to show

somedryness levels, eg to achieve the

‘Damp Dry’ setting boththe ‘Dry’ and the

‘Damp’ dry lights willbeilluminated.

Five dryness levels from

‘Damp’through to ‘Extra Dry’.

Ifyou want to change from the

default dryness, you can choose

the dryness level to suityour load

depending on how dry you want

youritemsto be.

Dry Temp

There are four drying temperatures you

can choose from for your cycle.

Clothes temperatures reach up to:

High: 80°C.

Medium: 70°C.

Low: 45°C.

No heat: Cool air is blown through

thedryer for the period selected.

Wrinkle Free

To minimise wrinkling, select one of the

‘WrinkleFree’ options. Atthe end of the

cycle, the drum will rotateperiodically

and cool air will be circulated through

the load to minimise wrinkling and

creasing. Thisisparticularly useful

if you cannotremove the items

immediatelyafterthe cycle ends.

‘ON’ provides ‘Wrinkle Free’

operationfor 1 hour.

‘Extra’ provides ‘Wrinkle Free’

operationfor 24 hours.

If you wish to stop the dryer at any

point during the ‘Wrinkle Free’ stage

of the cycle, simply touch

Youcanthen open the dryer door

andremove your items.

Press‘POWER’ to turn the dryer off.

Signal

‘Signal’ has two functions:

1 Alert you that the dryer has finished.

Aseries of beeps will sound at the

endofa cycle.

2 Alert you to remove items once your

load reaches the damp/dry stage,

then it will continue drying until the

remaining load reaches the dryness

level you selected.

The ‘Signal’ option automatically

defaults to ‘On’ for all cycles.

Youcanturn the ‘Signal’ off by

touching the ‘Signal’ button twice

(nolights will then be illuminated).

To turn ‘Damp/dry’ signal on:

Touch the ‘Signal’ button once.

Ensure‘On’ is also selected.

Reset defaults

You can reset your dryer to the default settings it left the factory with:

1 Turn the dial to select the ‘Freshen’ cycle.

2 Touch and hold the ‘Delay Start’, ‘More’ , the ‘Delay Start’, ‘Less’ and ‘Signal’

buttonstogether for three seconds.

3 Your dryer will now be reset to the default settings it left the factory with.

CUSTOMISING DRYING CYCLE

CARING FOR YOUR DRYER

When you have finished using your dryer

Unplug the machine from the power socket.

Wipe around the door to remove any remaining condensation and foreign matter.

Clear the lint filter and empty the water tank (if not set up to automatically drain).

Cleaning your dryer

Before you start cleaning your dryer, ensure that it is disconnected from the power

(ieunplug the machine from the power socket).

Cleaning the control panel and outer surfaces of the dryer

Use a soft damp cloth to wipe all surfaces, then wipe dry. Avoid using chemical or

scouring cleaners, as these will damage the paint and plastic surfaces of your dryer.

Cleaning the inside of your dryer

It is important that you occasionally clean the inside of your dryer. If the drum has

anyresidual dirt or lint stuck to it, remove this and wipe it clean with a damp cloth.

Donot leave any metal objects in the drum, as these may cause rust.

Cleaning the filters

Cleaning the door lint filter

Lint is generally formed during wearing and washing.

Fibres (ielint) released from theclothes during the drying

cycle are collected in the lint filter.

It is important to clean the door lint filter after every load,

as the lint produced in the drying process can become a fire

hazard if it is allowed to accumulate in or around your dryer.

A warning light will flash at the start of every cycle to

remindyou to clean the door lint filter, then turns off once

youtouch to start your cycle.

The warning light will flash on and off during the cycle if the door lint filter

becomes blocked. When this occurs the lint filter should be cleaned immediately.

The door lint filter is located in the door opening (at the bottom).

To clean the door lint filter:

1 Open the dryer door.

2 Remove the lint filter by pulling it up and out of the

filter slot. Open it out and wipe the surfaces clean

with your hand.

3 Close the lint filter and place it back in the opening.

Ensurethe filter is fitted correctly back in place

before operating the dryer.

Lint filter

Cleaning the condenser filter and evaporator grid

To maintain optimum performance of your dryer the condenser filter andevaporator

grid must be cleaned. The condenser filter and lint filter lights will flash when the

condenser filter requires cleaning, then turn off once you touch to start your cycle.

The condenser filter is located below the door on the left-hand side.

The evaporator grid is located behind the condenser filter.

To clean the condenser filter:

1 Switch off the power supply and remove

thepower plug.

2 Open the condenser filter cover.

3 Turn the four condenser lock levers 90°

thenpull out the condenser filter.

4 Remove rear filter and wipe the surface

cleanwith your hand.

To clean the evaporator grid:

5 With the condenser filter removed you will

be able to see the evaporator grid. Ifthesurface

of the evaporator grid is dirty, clean it carefully

with avacuum cleaner using a dusting brush or

anarrow crevice nozzle.

Begentle and do not bend the finemetalfins.

Cut Hazard. The surface of the evaporator has

sharp edges and contact may result in injury.

Handle with care when cleaning the grid

andalways keep blades away from fingers

andbody.

6 Replace the condenser filter.

7 Turn the four condenser filter lock levers to

lock the condenser filter back inplace again.

Make sure that these locksare engaged securely.

8 Close the condenser filter cover.

CARING FOR YOUR DRYER

Turning the condenser

filter locking levers

Pulling out the

condenser filter

Emptying the water collection tank

During the drying cycle, steam condenses into water

andis collected in the water tank, located at the top

left of the dryer. It is important to empty the water

tank after every load.

Ifthewater tank becomes full during operation,

thedryer will pause, display a user prompt and beep

to alert you. You must emptythe tank before the

dryer can continue drying. Empty the tank, replace

itin the housing then touch

to resume the cycle.

Note: You do not need to empty the water tank

ifyou have set up the drain hose to drain the

waterautomatically.

To empty the water tank:

1 Remove the water tank by holding onto the

handleand pulling outwards gently to remove it.

Ensurethat you keep the tank level when it is being

removed to prevent the water collected from spilling.

2 Pour the water down the sink or into a bucket,

andthen put the tank back in place.

Never run the dryer without the water tank in place

unless thedrainhosehasbeeninstalled.

Cleaning the sensors

There are sensors in your dryer that detect whether the laundry is dry or not.

Thesesensors need to be cleaned periodically (we recommend approximately

fourtimes a year).

To clean the sensors:

1 Open the door of your machine.

2 Allow the machine to cool if drying hasbeen carried out.

3 Locate the metal sensors just behind thelint filter.

4 Wipe the sensors with a soft cloth, dampened

withvinegar. Dry the sensors with a soft dry cloth.

CARING FOR YOUR DRYER

Location of the sensors

Removing the

water collection tank

Tipping out the water

from the condensing tank

BEFORE YOU CALL FOR SERVICE

User warnings

Your dryer is capable of diagnosing a number of its own problems. It will sound a

continuous series of beeps and display a user prompt when it has a problem that you

can correct yourself. To stop the beeps sounding, touch any button on the control panel.

Donot try to continue your drying cycle once you stop the noise. You must address

theproblem the dryer is alerting you to.

Check the below table before you call for service.

PROBLEM DISPLAYED AS WHAT TO DO

Keylock is

activated

Touch and hold the ‘Keylock’ button for 2seconds

todeactivate the Keylock.

The lint filter

is blocked

and needs to

be emptied

Empty the lint filter and then replace it.

Check the lint filter is not damaged.

Check there is nothing else stuck in the lint filter holder

which may be blocking the air flow.

Check the lint filter is in place correctly in your dryer.

Clean the condenser filter (refer to the ‘Caring for your

dryer’ section). Ensure the condenser filter unit has

been placed or replaced correctly into your dryer.

The water

tank is full

and needs to

be emptied

Check if the water tank is full.

Empty the water tank.

If using the drain hose, check whether the water tank

ordrain hose is blocked.

Check the drain hose is still attached at the back

ofthemachine, and is not kinked or squashed.

The door is

not closed

Close the door fully and touch .

Try opening and closing the door again.

Reposition the load, making sure the load is correctly

inthe drum and that protruding items are not

preventing the door from closing.

The drying

rack is not

inplace

Fit the drying rack.

Once you have addressed the issue the user prompt was alerting you to,

tryusingyourdryer as per usual. If the issue persists, call your Fisher & Paykel

trainedandsupported service technician.

When a continuous series of beeps sounds, all the lights turn off onthe control panel

and a number appears on the display, a fault hasoccurred. The dryer will automatically

enter this mode if a fault occurs. The word ‘Fault’ will be shown in the control panel

display followed by a number. To stop the beeps, touch any button then perform the

following steps:

1 Turn your machine off at the power point.

2 Wait one minute and turn it back on.

3 Check your machine is installed correctly (refer to ‘Installation instructions’ section).

4 Remove your load from the dryer and retry.

5 Perform a ‘Time Dry’ cycle, eg Time Dry for 30 minutes.

6 If the fault re-occurs repeat steps

and

7 If the machine still will not work call a Fisher & Paykel trained and supported

servicetechnician to arrange service (refer to ‘Customer care’ section).

Recordthefaultcode number displayed and the serial number of your dryer

(locatedonthe rear of the machine, or on the insideof the door below the glass)

beforecalling. The fault code will indicateto the service technician what the

problemcould potentially be.

If a fault code is being displayed, you can still turn your dryer off by pressing

‘POWER’ .

FAULT CODES

TROUBLESHOOTING

The following is a list of problems you may encounter when using this appliance and

some suggestions that may help to correct the problem. If you still have problems,

contact your Fisher & Paykel trained and supported service technician.

PROBLEM POSSIBLE CAUSES WHAT TO DO

Pressing ‘POWER’

does not turn

on thedryer

Fault with household

power supply.

Try plugging in and turning on another

electrical device.

Dryer does

notheat

Dryer set to ‘Air Dry’ cycle. Check what cycle the dryer is setto

(refer‘Drying cycles’). Changeto

preferredcycle.

Full water tank. Refer to ‘Emptying the water collection tank’.

The dryer has progressed

to ‘Cool’.

Check the progress lights– are

‘Cool’or‘End’ lights illuminated?

Referto‘Dry progress’.

Touching

does not start

thedrying cycle

Dryer door not closed properly. Open and close the door. Checkthat the

lint filter is correctly in place and not

obstructing the door.

Is the dryer displaying a user

warning or fault code?

Refer to ‘User warnings’ and ‘Fault codes’.

Water tank full or not properly

in place.

Refer to ‘Emptying the water collection

tank’. Ensure the water tank is properly

inplace.

Lint filter needs to be emptied. Empty the lint filter and ensure it is

correctly in place.

Dryer is overloaded. Remove some items from the dryer.

‘Delay Start’ function is set. Refer to ‘Delay Start’ for more information.

Keylock is ON.

To disable touch and hold

button

fortwoseconds.

Dryer keeps

stopping

andstarting

The ‘Wrinkle Free’ option

hasbeen selected.

Refer to ‘Wrinkle Free’ for more

information.

Dryer stops

working

mid-cycle

Power failure.

Press ‘POWER’

and restart the

desiredcycle.

Dryer has been paused.

Touch the

button to restart thecycle.

Dryer door is open. Ensure the door is firmly shut.

Items fell off the rack

whenusing ‘Rack Dry’ cycles.

Ensure the rack is installed correctly

(refer to ‘Sorting and loading’,

‘Drying rack’) and replace garments

thatmay have fallen from it.

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSES WHAT TO DO

Dryer is taking

toolong

/results were

notsatisfactory

Drying cycle selected not

appropriate for the load.

Select an appropriate cycle for the

load. Refer to ‘Drying cycles’.

Dryness level selected not

appropriate for the load.

Select a higher dryness level.

Refer to ‘Dryness Level’.

Dryer overloaded for

thecycle.

Some cycles have a lower max load

size. Refer to ‘Drying cycles’.

Try dividing the load in half and

dryhalf at a time.

Lint and/or condenser filter

isblocked.

Clean the lint/condenser filter.

Water tank is full. Refer to ‘Emptying the water

collection tank’.

Environmental conditions

maybe affecting dryer

operation.

In particularly hot or cold conditions

the dryer will take longer to dry a load

and beless efficient.

Ensure the dryer is installed in a

well-ventilated, dust-free environment.

Donot operate this dryer behind

closeddoors (ie inside a cupboard).

Load overly wet at the

start of cycle.

Remove more water from the

load before placing it in the dryer,

egselecta faster spin speed on your

washer, if appropriate for your load.

Load was damp dry at

thestart of cycle.

If the load had been partially air dried,

eg has been washed and placed on

the line, use a ‘Time Dry’ cycle and

monitor the dryness of your clothes.

Dryer not draining water

out properly.

Check the drain hose (if connected)

forblockages or damage.

Youmayneed to call for service

referto ‘Customer care’ section.

Items got tangled. Try separating items and

dryingsimilaritems together.

Referto‘Loading’ forfurther tips.

Dryer is not

draining

Drain hose not connected

tothe water tank.

Ensure the drain hose is connected

correctly. Refer to ‘Draining’ in the

installation section of this guide.

Water tank not in place

correctly.

Ensure water tank is properly inplace.

Drain hose or drain blocked

ordamaged.

Check drain hose (if connected)

anddrain for blockages or damage.

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSES WHAT TO DO

Clothes getting too

hot or damaged

Cycle selected not

appropriate for the load.

Ensure the cycle selected is

appropriatefor items in the load.

Referto ‘Drying cycles’.

Items removed from dryer

before the end of cycle cool

down had finished.

Removing items before cool down

maydamage clothing if it is not

spread out and exposed to air to

coolonce removed from the dryer.

Dryer is beeping

and displaying

acode on the

digital display

Dryer has a fault. Try turning the dryer off and waiting

30seconds before turning it back on.

Refer to ‘Fault codes’.

Small puddle

ofwater coming

from under

themachine

Water tank not correctly

inplace.

Ensure the water tank is correctly

in place.

Water tank may need

tobeemptied.

Refer to ‘Emptying the water

collection tank’.

Water tank may be damaged. Check the water tank for any signs

ofdamage.

Drain hose may not be

attached properly at the

machine end.

Ensure the drain hose is attached

properly. Refer to ‘Draining’ in the

installation section of this guide.

Drain hose could be damaged. Check the drain hose for damage.

Drain hose has slipped

outofthe drain.

Ensure the drain hose is securely fixed

in place. Sometimes drain hoses can

move or get displaced, which may

lead to water draining onto the floor.

Drain may be blocked. Check the drain for any blockages.

Dryer door not closing

properly, affecting the seal.

Ensure the dryer door is closed

properly and there is nothing

obstructing the door opening.

Small amount

ofwater in

thedrum at

endofcycle

Water tank needs to be

emptied.

Refer to ‘Emptying the water

collection tank’.

Environmental conditions

maybe affecting dryer

operation.

If conditions are particularly hot,

humidor cold, it is possible vaporised

water may re-condense in the drum

oron the inside of the door.

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSES WHAT TO DO

Noises Dryer is overloaded. Remove some items from the dryer.

Dryer has a fault. Continuous beeping or a musical

seriesof beeps with a message

displayed on the display.

Referto‘Fault codes’.

Beeps signalling the end

ofadrying cycle.

End of cycle beeps can be turned off

refer to ‘Customising drying cycle’.

Dryer has not been

levelledproperly.

Refer to ‘Levelling the machine’ in the

installation section of this guide.

Dryer makes unfamiliar noises. At the start of the cycle the dryer may

make some unfamiliar noises when the

compressor turns on. Thisis normal.

Vibration Dryer is not installed on

astable surface.

Ensure the dryer is installed on a flat,

stable surface. Refer to ‘Levelling the

machine’ in the installation section of

this guide.

Dryer is not level. Ensure the dryer is correctly levelled.

Refer to ‘Levelling the machine’ in the

installation section of this guide.

Dryer is overloaded. Remove some items from the dryer.

Creasing Cycle selection not

appropriate for the load.

Select the ‘Easy Iron’ cycle to

minimisecreasing.

Dryer is overloaded. Remove some items from the dryer.

‘Dryness Level’ selected

toohigh for load type.

Try selecting a lower ‘Dryness Level’.

‘Wrinkle Free’ option

notselected.

Select the ‘Wrinkle Free’ option to

rotate the load at the end of the

drying cycle. Refer to ‘Wrinkle Free’

section of this guide for details.

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSES WHAT TO DO

Linting Lint filter not cleaned or

replaced.

Ensure the lint filter is cleaned after

every cycle and replaced correctly.

Refer to ‘Cleaning the filters’.

Loads not sorted correctly. Dry lint-giving items separately

from lint receivers. Also, dry similar

colours together, eg light coloured

items withlight coloured items, dark

itemswith dark items.

Refer to ‘Sorting and loading’, ‘Lint’.

Clothes over dried. Over drying clothes in the dryer

cancause them to attract lint.

Useanauto sensing cycle or ensure

you check your load if using the time

dry cycles to avoid over drying.

Referto ‘Drying cycles’.

New items have been dried

inthe dryer recently.

Clean the lint filter and use

‘Cool Air’cycle to clear any

remaininglintfrom the dryer.

New towels or flannelette

sheets can leave lint in the

dryer, which may be picked

up by subsequent loads.

Fabric damage Instructions on care label

notfollowed.

Follow the instructions on the

carelabel of the items.

‘Dryness Level’ selected

notappropriate for the

fabrictype.

Ensure the ‘Dryness Level’ selected

is appropriate for the fabric type.

Referto the items care label.

Refertopages ‘Drying cycles’

Metal parts on the items or

inthe load.

Fasten zips and other clasps

beforeplacing items in the dryer.

Items not separated or

driedon an appropriate

cyclefor the fabric type.

Dry similar items together.

Ensureanappropriate cycle is selected.

Refer to ‘Drying cycles’.

Items fell off the rack when

using ‘Rack Dry’.

Ensure the rack is installed correctly

(refer to ‘Sorting and loading’, ‘Drying

rack’) and only one or twogarments

are placed on the rackata time.

Used a ’Time Dry’ cycle

anddid not monitor the

dryness of clothes during

the cycle.

Ensure that clothes are checked

fordryness during the cycle

whenusing the timed programmes

toavoid over drying.

Referto ’Customising drying cycle’.

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSES WHAT TO DO

Dye transfer White/light and coloured

items not separated

beforedrying.

Remember to separate white/light

and coloured items before placing

them in the dryer.

Wet items left sitting in

thedryer for long periods

oftime before drying.

Refer to ‘Sorting’ for tips to prevent

dye transfer.

Tangling Loads not separated

duringloading.

Try separating out larger items

fromsmaller items.

Items loaded into the

dryerincorrectly.

Load items individually into the dryer.

Do not place folded items inthe dryer.

Incorrect cycle selection. Try using the ‘Easy Iron’ cycle to

dryshirts and the ‘Sheets’ cycle to

drysheets. Refer to ‘Drying cycles’.

Load size too large. Try drying smaller load sizes.

Somecycles have a lower maximum

load size. Refer to ‘Drying cycles’.

Delicate items not dried

on‘Rack dry’.

Dry pantyhose, bras, stockings

andany other delicate items prone

totangling on the ‘Rack Dry’ cycle.

Sheets and duvet/doona

covers due to their size,

areprone to tangling.

Dry sheets and duvet/doona covers

separately from other laundry,

apartfrom towels. Ensure duvet/

doona covers are buttoned or

fastened closed before drying.

Tryadding a knotted towel to sheets

loads if you are experiencing a lot

oftangling.

MANUFACTURER’S WARRANTY

For New Zealand and Australia only. You automatically receive a 2 year Manufacturer’s

Warranty with the purchase of this heat pump clothes dryer covering parts and labour

for servicing within the country ofpurchase.

Fisher & Paykel undertakes to:

Repair or, at its option, replace without cost to the owner either for material or

labourany part of the product, the serial number of which appears on the product,

which is found to be defective within TWO YEARS of the date of purchase.

Note: This Manufacturer’s Warranty is an extra benefit and does not affect your

legalrights.

This Manufacturer’s Warranty DOES NOT cover

Service calls which are not related to any defect in the product. The cost of a

servicecall will be charged if the problem is not found to be a product fault.

For example:

1 Correcting the installation of the product.

2 Instructing you how to use the product.

3 Replacing house fuses or correcting house wiring or plumbing.

4 Correcting fault(s) caused by the user.

5 Noise or vibration that is considered normal, egdrain/fan sounds, machine noises

oruser warning beeps.

6 Correcting damage caused by pests, egrats, cockroaches, etc.

7 Poor drying performance due to incorrect installation and maintenance

egblockedlint filter, blocked condenser or full water tank.

Poor drying performance due to incorrect loading, egoverloading or underloading.

9 Damage from articles in the drum, eg bra wires, pens, crayons, dye transfer or

flammable material.

Defects caused by factors other than:

1 Normal domestic use; or

2 Use in accordance with the product’s User guide.

Defects to the product caused by accident, neglect, misuse or ‘act of God’.

The cost of repairs carried out other than by a Fisher & Paykel trained and supported

service technician or the cost of correcting such repairs.

Normal recommended maintenance as set out in the product’s User guide.

Repairs when the appliance has been dismantled, repaired or serviced by other

thanaFisher& Paykel trained and supported service technician or the selling dealer.

Pick-up and delivery.

Transportation or travelling costs involved in the repair when the product is

installedoutside the Fisher & Paykel trained and supported service technician’s

normalservicearea.

Nothing in this Manufacturer’s Warranty is intended to, or does, limit any rights you

mayhave under law to recover the costs of inspecting or returning the goods to us.

MANUFACTURER’S WARRANTY

This product has been designed for use in a normal domestic (residential) environment.

This product is not designed for commercial use (whatsoever). Any commercial use

byacustomer will affect this product’s Manufacturer’s Warranty.

Service under this Manufacturer’s Warranty must be provided by a Fisher&Paykel

trained and supported service technician (refer to the ‘Customer care’ section at

theback of this book). Such service shall be provided during normal business hours.

This Manufacturer’s Warranty certificate should be shown when making any claim.

For Australian Customers

This Manufacturer’s Warranty is an extra benefit and does not affect your legal rights.

Our goods come with guarantees that cannot be excluded under the Australian

Consumer Law. You are entitled to a replacement or refund for a major failure and

for compensation for any other reasonably foreseeable loss or damage. You are also

entitled to have the goods repaired or replaced if the goods fail to be of acceptable

quality and the failure does not amount to a major failure.

Please keep this User guide in a safe place.

CUSTOMER CARE

Before you call for service or assistance...

Check the things you can do yourself. Refer to your User guide and check:

1 Your product is correctly installed.

2 You are familiar with its normal operation.

3 You have read the ‘Before you call for service’, ‘Fault codes’ and ‘Troubleshooting’

sections at the back of the book.

If after checking these points you still need assistance or parts, please refer to your

nearest Fisher&Paykel trained and supported service technician, Customer Care, or

In New Zealand if you need assistance…*

Call the Fisher & Paykel Customer Care Centre and talk to one of our Customer

CareConsultants.

Toll Free: 0800 FP CARE or 0800 372 273

Fax: (09) 273 0656

Website: fisherpaykel.com

Postal address: Fisher & Paykel Appliances Ltd, PO Box 58550, Botany, Auckland 2163

If you need service…*

Fisher & Paykel has a network of Fisher & Paykel trained and supported service technicians

that can carry out any service necessary on your appliance. Our Customer Care Centre

can recommend a Fisher & Paykel trained and supported service technician in your area.

In Australia if you need assistance…*

Call the Fisher & Paykel Customer Care Centre and talk to one of our

CustomerCareConsultants.

Toll Free: 1300 650 590

Fax: (07) 3826 9298

Website: fisherpaykel.com

Postal address: Fisher & Paykel Appliances Australia Pty Ltd, PO Box 798,

ClevelandQLD4163

If you need service…*

Fisher & Paykel has a network of Fisher & Paykel trained and supported service technicians

that can carry out any service necessary on your appliance. Our Customer Care Centre

canrecommend a Fisher & Paykel trained and supported service technician in your area.

*If you call, write or contact us via our website please provide:

your name and address, model number, serial number, date of purchase and a complete

description of the problem. This information is needed in order to better respond to

yourrequest for assistance.

Product details can be found on the rear of the machine, and/or on the inside of the

door below the glass (when the door is open).

CUSTOMER CARE

Registration

To register your product visit our website: fisherpaykel.com

Complete and keep for safe reference:

Model

Serial No.

Purchase Date

Purchaser

Dealer

Suburb

Town

Country

NZ AU

428104F 09.19

FISHERPAYKEL.COM

The product specifications in this document apply to the specific

products and models described at the date of issue. Under our policy

of continuous product improvement, these specifications may change

at any time. You should therefore check with your Dealer to ensure this

document correctly describes the product currently available.

Fisher & Paykel DH8060P3 - 8kg Heat Pump Condensing Dryer

Product's Documents

User Manual

Specifications

Fisher & Paykel DH8060P3 Questions and Answers

Related Products

Fisher & Paykel DH9060HG1 Heat Pump Dryer, 9kg, Steam Care

Fisher & Paykel DH9060HLG1 Heat Pump Dryer, 9kg, Steam Care

Fisher & Paykel DH9060P2 Heat Pump Dryer, 9kg

Fisher & Paykel DH9060FSG1 Heat Pump Condensing Dryer, 9kg, Steam Care

Fisher & Paykel DH9060PG2 - 9kg Heat Pump Dryer

Fisher & Paykel DH9060FS1 HEAT PUMP CLOTHES DRYER
