INSTRUCTION MANUAL
PERSONAL CERAMIC HEATER
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR
ANY REASON.
If you have a question or experience a problem with your BLACK+DECKER
purchase, go to www.blackanddecker.com/instantanswers
If you can’t find the answer or do not have access to the Internet, call
844-299-0879 from 10:30 a.m. to 6:30 p.m. EST Mon. - Fri. to speak with an
agent. Please have the catalog number available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
CATALOG NUMBER
BHDC500W46
BHDC500B46
Page 2
Thank you for purchasing our
BLACK+DECKER product. This
easy-to-use manual will guide you
in getting the best use of your
heater.
Remember to record the model
and serial numbers. They are on a
label on the rear.
Staple your receipt to your manual.
You will need it to obtain warranty service.
Model number
Serial number
Date of purchase
PRODUCT REGISTRATION
CONTENTS
SAFETY INFORMATION
Important Safety Instructions ......................................................................................................................................... 4-6
Electrical Requirements.......................................................................................................................................................... 5
SET UP & USE
Parts & Features ......................................................................................................................................................................... 7
Operating Instructions ............................................................................................................................................................ 8
Care & Cleaning .......................................................................................................................................................................... 9
TROUBLESHOOTING & WARRANTY
Troubleshooting ....................................................................................................................................................................... 10
Limited Warranty .......................................................................................................................................................................11
Page 3
SPECIFICATIONS
Voltage: 120V, 60Hz
Power Consumption: 1500W
Unit Size (WxDxH): 7.5” x 5.7” x 9.2”
Page 4
SAFETY INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic precautions should always be
followed to reduce the risk of re, electric shock, and injury to persons,
including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin
touch hot surfaces. If provided, use handles when moving this heater.
Keep combustible materials, such as furniture, pillows, bedding,
papers, clothes, and curtains at least 3 feet (0.9m) from the front of
the heater and keep them away from the sides and rear.
3. Extreme caution is necessary when any heater is used by or near
children or invalids and whenever the heater is left operating and
unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord or plug or after the
heater malfunctions, has been dropped or damaged in any manner.
Discard heater or return heater to authorized service facility for
examination, electrical or mechanical adjustment, or repair.
6. Do not use outdoors.
7. This heater is not intended for use in bathrooms, laundry areas and similar
indoor locations. Never locate heater where it may fall into bathtub or
other water container.
8. Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or
appliances. Arrange cord away from trafc area and where it will not be
tripped over.
9. To disconnect heater, rst turn controls to off, then remove plug from
outlet.
10. Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or re, or damage the
heater.
11. To prevent a possible re, do not block air intakes or exhaust in any
manner. Do not use on soft surfaces, like a bed, where openings may
become blocked.
WARNING
When using electrical appliances, basic safety precautions
should be followed, including the following
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
Page 5
12. A heater has hot and arcing or sparking parts inside. Do not use it in the
areas where gasoline, paint, or ammable liquids are used or stored.
13. Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause re, electric shock, or
injury to persons.
14. This heater draws 12.5 amps during operation. To prevent overloading
a circuit, do not plug the heater into a circuit that already has other
appliances working.
15. The output of this heater may vary and its temperature may become
intense enough to burn exposed skin. Use of this heater is not
recommended for persons with reduced sensitivity to heat or an inability
to react to avoid burns.
16. Don’t leave the heater on unattended.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
SAFETY INFORMATION
ELECTRICAL REQUIREMENTS
This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to t into a polarized outlet
only one way. If the plug does not t into the outlet, reverse the plug. If it still
does not t, contact a qualied electrician. Do not attempt to modify the plug in
any way.
NOTE: Neither BLACK+DECKER nor the dealer can accept any liability for damage to the
product or personal injury resulting from failure to observe the electrical connection
procedures.
WARNING: To reduce the risk of electric shock, do not use with an extension cord.
IMPORTANT SAFETY INSTRUCTIONS
(CONT.)
WARNING –RISK OF FIRE
It is important the plug fits tightly into the wall outlet.
If the plug does not fit securely and appears loose, it should not be used.
Have a licensed electrician replace the receptacle.
Page 6
OVERHEAT SAFETY FEATURE
This heater is equipped with a overheat safety feature. When the heater’s internal
components reach a certain temperature that could cause overheating and
possible re, the heater will automatically shut off. If this should occur, please
contact our Customer Satisfaction Center at 844-299-0879.
TIP-OVER SAFETY FEATURE
This heater is equipped with a tip-over safety feature. Once the heater is tipped
over, an internal switch will automatically shut the heater off. Once the heater is
restored to an upright position, the heater will reset. To continue operation, turn
heater back on.
WARNING
It is normal for the power cord to feel warm to the touch; however, a
loose t between the outlet and the plug may cause overheating of
the plug. If this occurs, try inserting the plug into a different outlet.
Contact a qualied electrician to inspect the original outlet for
damage.
SAFETY INFORMATION
CAUTION
Always plug heaters directly into a wall outlet/receptacle.
Never use with an extension cord or relocatable power tap
(outlet/power strip).
Page 7
PARTS & FEATURES
Adjustable
thermostat Fan/Heat settings
SET UP & USE
Power on
indicator light
Page 8
SET UP & USE
OPERATING INSTRUCTIONS
Place the heater on a rm, level surface and plug the unit directly into a 120 V AC
electrical outlet.
NOTE: Only operate heater in upright position.
1. Turn the heat control knob clockwise (right) from the OFF position to the LOW or
HIGH (1500 watts) heat settings. For Fan Only operation without any heat turn to
the FAN setting.
2. To adjust the thermostat, turn the thermostat knob clockwise (right) from the
MIN position to the MAX position to increase the temperature. When the desired
temperature is reached lower the thermostat setting until the heater stops
operating by turning the thermostat knob to the MIN position.
The power indicator light turns on when either the, FAN, LOW or HIGH setting is
selected.
NOTE: Turning the THERMOSTAT control knob clockwise will increase the
temperature setting.
Turn the fan/heat control knob to “OFF” to shut off the unit.
Thermostat Fan/Heat control knob
Page 9
MAINTENANCE
1. Turn power off before cleaning.
2. Unplug the unit and let it cool completely.
3. To keep the heater clean, the outer shell may be cleaned with a soft, damp cloth.
You may use a mild detergent if necessary. After cleaning, dry the unit with a soft
cloth.
CAUTION: DO NOT let liquid enter the heater.
4. DO NOT use alcohol, gasoline, abrasive powders, furniture polish, or rough brushes
to clean the heater. This may cause damage or deterioration to the surface of the
heater.
5. DO NOT immerse the heater in water.
6. Wait until the unit is completely dry before use.
STORAGE
Store the heater in a cool, dry location when not in use. To prevent dust and dirt
build-up, use the original packaging to repack the unit.
CARE & CLEANING
Page 10
TROUBLESHOOTING & WARRANTY
BEFORE YOU CALL FOR SERVICE
IF THE HEATER/FAN FAILS TO OPERATE:
A) Check to make sure that the heater/fan is plugged in securely. If it is not,
remove the plug from the outlet, wait 10 seconds and plug it in again
securely.
B) Check for a blown circuit fuse or a tripped main circuit breaker. If these seem
to be operating properly, test the outlet with another appliance.
C) Check if electricity to the main power switch in the back of the unit appears
to be working.
D) Make sure the heater is in the upright position.
NOTE: For the heater to function properly, the desired temperature on the
heater must be set a few degrees higher than the temperature in the
room. If the unit seems to not be heating properly, increase the desired
temperature on the heater to fully engage the heating elements.
IF NONE OF THE ABOVE SOLVES THE PROBLEM, CONTACT A QUALIFIED
TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR THE HEATER/FAN
YOURSELF.
CUSTOMER SERVICE
IMPORTANT
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have a problem with this product, please contact the
BLACK+DECKER Customer Satisfaction Center at
844-299-0879 or [email protected]
DATED PROOF OF PURCHASE, MODEL # AND SERIAL #
REQUIRED FOR WARRANTY SERVICE
Page 11
TROUBLESHOOTING & WARRANTY
LIMITED WARRANTY
Any repair, replacement, or warranty service,
and all questions about this product should be
directed to BLACK+DECKER at 844-299-0879
from the USA or Puerto Rico.
BLACK+DECKER warrants to the original purchaser
that the product will be free from defects in material,
parts and workmanship for the period designated for
this product. The warranty commences the day the
product is purchased and covers up to a period of 1
year (12 months) for labor/1 year (12 months) for parts
(manufacturing defects only).
BLACK+DECKER agrees that it will, at its option,
replace the defective product with either a new
or remanufactured unit equivalent to your original
purchase during the warranty period.
Exclusions: This warranty does not apply if any of the
following conditions exist:
1. The appearance or exterior of the product has been
damaged or defaced, or altered or modified in either
design or construction.
2. The product’s original serial number has been
altered or removed, or cannot be readily
determined.
3. Damage is due to a power line surge, or connection
to an improper voltage source.
4. Damage is due to general misuse, accidents, or acts
of God.
5. Repair attempts were made by unauthorized service
providers; parts other than genuine parts were used;
or parts were obtained from unauthorized service
companies.
6. The product was transferred from the original
owner.
7. The product was purchased as refurbished, like
new, or second-hand, or with “As-Is” or “Final Sale”
terms.
8. The product was used in a commercial or rental
setting.
9. The product was used in settings other than
ordinary households, or used other than in
accordance with the provided instructions.
10. Damage is due to improper installation.
The following costs are not covered under this
warranty:
1. Transportation and shipping costs associated with
the replacement of the unit.
2. Service calls to instruct you how to use your
product.
3. Service calls to repair or replace the house fuse,
reset a circuit breaker, or correct the wiring in the
house.
4. Service calls required due to improper installation.
REPAIR OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE EXCLUSIVE REMEDY OF
THE CUSTOMER; BLACK+DECKER SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS PRODUCT, EXCEPT
TO THE EXTENT PROHIBITED BY APPLICABLE LAW.
ANY IMPLIED WARRANTY OF MERCHANTABILITY
OF FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED TO THE DURATION OF THE
WARRANTY.
Some states do not allow the exclusion or limitations
of incidental or consequential damages, or limitations
on how long the warranty lasts. In these cases the
above exclusions or limitations may not apply to you.
This warranty gives you specific legal rights and you
may also have other rights which vary from state to
state.
Obtaining Service: To obtain service, product
literature, supplies or accessories please call
844-299-0879 to create a ticket for exchange/repair.
Please make sure to provide the date of purchase,
model number and a brief description of the problem.
Our customer service representative
will contact you or send detailed return instructions.
BLACK+DECKER does not warrant that the appliance will work
properly in all environmental conditions, and makes no warranty
and representation, either implied or expressed, with respect
to the quality, performance, merchantability, or fitness for a
particular purpose other than the purpose identified within this
user’s manual. BLACK+DECKER has made every eort to ensure
that this user’s manual is accurate and disclaims liability for any
inaccuracies or omissions that may have occurred. Information in
this user’s manual is subject to change without notice and does
not represent a commitment on the part of BLACK+DECKER.
BLACK+DECKER reserves the right to make improvements to
this user’s manual and/or to the products described in this user’s
manual at any time without notice. If you find information in this
manual that is incorrect, misleading, or incomplete, please contact
us at 844-299-0879.
W Appliance Co.
1356 Broadway
New York, NY 10018
Page 12
BLACK & DECKER, BLACK+DECKER, the BLACK & DECKER and
BLACK+DECKER logos and product names and the orange and black color
scheme are trademarks of The Black & Decker Corporation, used under license.
All rights reserved.
Product in this box may differ slightly from that pictured. Does not affect
function. Not all accessories shown in photography are included in this
package.
Imported by W Appliance, Inc., 1356 Broadway, New York, NY 10018
April 2020 Printed in China
