If the time is in 12-hour format, press
key to select [am] or [pm] (country
dependent).
D630
D650
Register your product and get support on our website
Short user manual
Important safety instructions
Warning
• The electrical network is rated as dangerous. The
only way to turn off the charger is to unplug the
power at the outlet. You must therefore ensure
that the electrical outlet is always easily
accessible.
• Refer to the safety information before using the
product.
• This product complies with European directive
RED2014/53/EU.
• Use only the power supply type listed in the user
instructions.
• Use only the battery type listed in the user
instructions.
• Do not allow the product to come into contact
with liquids.
• Risk of explosion if an incorrect battery type is
inserted in the device.
• Dispose of used batteries according to the
instructions.
• When the handset rings or when the handsfree is
activated, keep the handset away from your ear
to avoid hearing damage.
When using the phone as a baby monitor
• Ensure that children do not play with the
appliance.
• Make sure the baby unit and the cord are always
out of reach of the baby (at least 1 meter).
• Keep the parent unit at least 1.5 meters from the
baby unit to prevent acoustic feedback.
• Never place the baby unit inside the baby’s bed
or playpen.
• Never cover the parent unit and the baby unit
with anything (e.g. a towel or blanket). Always
make sure the cooling vents of the baby unit are
free.
• This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
• If you place the parent unit next to a transmitter
or other DECT appliance (e.g. a DECT telephone
or wireless router for the internet), the connection
with the baby unit may be lost. Move the baby
monitor further away from the other wireless
appliances until the connection is restored.
• This baby monitor is intended as an aid. It is not a
substitute for responsible and proper adult
supervision and should not be used as such.
Overview
Icons
Earpiece
Loud-
speaker
(back)
Loudspeaker
Microphone
Find
handset
(bottom)
During a call Standby
Phonebook /
redial list
Change the
sound prole.
Adjust the
volume.
Recall
(network
dependent).
End calls.
Enter a pause
(press and
hold the key).
Mute/unmute
the
loudspeaker.
Mute/unmute
the
microphone.
In menu
Confirm /
Select /
Enter the
option menu.
Cancel /
Back
Up / Down
Exit menu.
Access the main menu.
Access the redial list.
Phonebook
Call log
Make and answer calls.
Switch the handset on
or off (press and hold
the key).
Make an intercom call
(press and hold the key).
Lock/unlock the keypad
(press and hold the key).
Make and receive calls
through the loudspeaker.
D635 only : Press to play
a new message
recorded in the
answering machine /
Access to the answering
machine menu.
In text input
Delete text.
Enter a space.
Switch upper/lower
case (press and hold
the key).
Left / Right
Main menu icons
Alarm Phonebook
Services Sounds
Settings Baby monitor
Privacy
mode
Answering machine
(D635 only)
Incoming calls (D630 only)
Icons
It shows the connection status between
the handset and base station. The more
bars are shown, the better the signal
strength is.
It flashes when there is a new missed call.
It remains steadily on when browsing
unread missed calls in call log, or when
browsing the read missed calls in call log.
It remains steadily on when browsing
blocked calls in the call log.
It flashes when there is an incoming
mobile number call.
It flashes when there is an incoming
mobile number call.
It flashes when there is an incoming
home number call.
The loudspeaker is on.
The ringer is off. The silent mode is set
and within active period (the phone does
not ring).
The silent mode is set, but is outside of
active period.
Activated alarm.
D635 only : Answering machine: this
symbol flashes when there is a new
message or when the memory is full. It is
displayed when the answering machine
is turned on.
Voice message indicator: it flashes for
new messages, it is steady for reviewed
messages.
* This is network dependent.
The ECO mode is activated.
The ECO+ mode is activated.
Connection
Multi-handset
version only.
Get started
Inserting the batteries
Phone setup
When using your phone for the first time, you
see a welcome message (country dependent).
Set the country and language if prompted.
Set the date and time.
Charge your phone
> 70%
40% - 70%
10% - 40%
Flashing: low
battery
Charge the device
for 8 hours.
www.philips.com/support
Scrolling: charging
in progress.
