Sony CMT-M90DVD Micro Hi Fi Component System User Manual

CMT-M90DVD 4-239-826-12(1) GB

Operating Instructions

Micro Hi-Fi

Component

System

4-239-826-12(1)

CMT-M90DVD

Owner’s Record

The model and serial numbers are located on the rear of the unit. Record the serial number in

the space provided below. Refer to them whenever you call upon your Sony dealer regarding

this product.

Model No. Serial No.

WARNING

To prevent fire or shock hazard, do not

expose the unit to rain or moisture.

To avoid electrical shock, do not open the cabinet.

Refer servicing to qualified personnel only.

Do not install the appliance in a confined space,

such as a bookcase or built-in cabinet.

This appliance is

classified as a CLASS 1

LASER product. This

label is located on the

rear exterior.

CAUTION

The use of optical instruments with this product will

increase eye hazard.

As the laser beam used in this CD/DVD player is

harmful to eyes, do not attempt to disassemble the

cabinet. Refer servicing to qualified personel only.

U.S.A. model

This label is located inside the unit.

European model

The following caution label is located inside the

apparatus.

To prevent fire, do not cover the ventilation of the

apparatus with news papers, table-cloths, curtains,

etc. And don’t place lighted candles on the apparatus.

To prevent fire or shock hazard, do not place objects

filled with liquids, such as vases, on the apparatus.

Don’t throw away the battery with

general house waste, dispose of it

correctly as chemical waste.

NOTICE FOR THE CUSTOMERS IN THE

U.S.A.

This symbol is intended to alert the user to

the presence of uninsulated “dangerous

voltage” within the product’s enclosure that

may be of sufficient magnitude to constitute

a risk of electric shock to persons.

This symbol is intended to alert the user to

the presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

WARNING

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there

is no guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television reception,

which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the

interference by one or more of the following

measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and

receiver.

– Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected.

– Consult the dealer or an experienced radio/TV

technician for help.

CAUTION

You are cautioned that any changes or modifications

not expressly approved in this manual could void

your authority to operate this equipment.

CMT-M90DVD 4-239-826-11(2) GB

Note to CATV system installer

This reminder is provided to call the CATV system

installer’s attention to Article 820-40 of the NEC that

provides guidelines for proper grounding and, in

particular, specifies that the cable ground shall be

connected to the grounding system of the building, as

close to the point of cable entry as practical.

NOTICE FOR THE CUSTOMERS IN

CANADA

CAUTION:

TO PREVENT ELECTRIC SHOCK, DO NOT USE

THIS POLARIZED AC PLUG WITH AN

EXTENSION CORD, RECEPTACLE OR OTHER

OUTLET UNLESS THE BLADES CAN BE FULLY

INSERTED TO PREVENT BLADE EXPOSURE.

Except for European model

ENERGY STAR

is a U.S.

registered mark.

As an ENERGY STAR

partner,

Sony Corporation has determined

that this product meets the ENERGY

STAR

guidelines for energy

efficiency.

This system incorporates Dolby* Digital, Pro Logic

Surround, and the DTS** Digital Surround System.

* Manufactured under license from Dolby

Laboratories.

“Dolby”, “Pro Logic” and the double-D symbol are

trademarks of Dolby Laboratories.

** Manufactured under license from Digital Theater

Systems, Inc. “DTS” and “DTS Digital Surround”

are registered trademarks of Digital Theater

Systems, Inc.

Notes on DTS audio playback

• The DTS audio of the DVD is output only from the

OPTICAL OUT jack, not from the speakers. To

listen to the sound of DVD in other than DTS

format, select “DOLBY DIGITAL” or other audio

format (page 25).

• To enjoy DTS Digital Surround of DVD or CD,

connect external 5.1 channel DTS Digital Surround

Decoder to the OPTICAL OUT jack of this unit.

• When you playback the CD recorded in DTS

format, excesive noise may be heard from the

speakers. Set the volume to minumum and be

careful not to damage your speaker system.

IMPORTANT NOTICE

Caution: This system is capable of holding a

still video image or on-screen display image on

your television screen indefinitely. If you leave

the still video image or on-screen display

image displayed on your TV for an extended

period of time, you risk permanent damage to

your television screen. Projection televisions

are especially susceptible to this.

This system can play the following discs.. 6

List of Button Locations and

Reference Pages

Main unit ................................................... 7

Remote Control ......................................... 8

Getting Started

Hooking up the system.............................. 9

Inserting two size AA (R6) batteries

into the remote .................................. 10

Setting the clock ...................................... 11

DVD/VIDEO CD/CD

Playing discs:

Loading a disc ......................................... 12

Playing a disc

— Normal Play/Shuffle Play/Repeat

Play/Scan/Slow-motion Play ............ 12

Creating your own program

— Program Play ............................... 14

Resuming playback from the point you

stopped the disc

— Resume Play ................................ 16

Playing repeatedly

— Repeat Play .................................. 16

Playing DVDs using the menu ................ 17

Playing VIDEO CDs with PBC functions

(Ver. 2.0)

— PBC Play ..................................... 18

Table of Contents

Setting up for DVD/VIDEO CD/CD:

Using the Setup Display.......................... 19

Setting the display or sound track language

— LANGUAGE SETUP.................. 20

Settings for the display

— SCREEN SETUP ........................ 21

Custom settings

— CUSTOM SETUP ....................... 22

Viewing information about the disc:

Checking the playing time and remaining

time ................................................... 23

Checking the playback information

— ADVANCED............................... 24

Sound adjustment:

Changing the sound................................. 25

Enjoying movies:

Searching for a title/chapter/track/index/

scene ................................................. 27

Changing the angles ................................ 28

Displaying the subtitles ........................... 28

Using various additional functions:

Locking discs

— CUSTOM PARENTAL CONTROL/

PARENTAL CONTROL ................. 29

* European model only.

Tuner

Presetting radio stations .......................... 33

Listening to the radio .............................. 34

Using the Radio Data System (RDS)* .... 35

Tape

Loading a tape ......................................... 36

Playing a tape .......................................... 36

Recording to a tape

— CD Synchro Recording/Recording

Manually/Program Edit .................... 37

Timer recording radio programs ............. 39

Sound Adjustment

Adjusting the sound ................................ 40

Enjoying virtual surround sound ............. 40

Display

Turning off the display

— Power Saving Mode .................... 42

Using the display..................................... 42

Other Features

Falling asleep to music

— Sleep Timer ................................. 43

Waking up to music

— Daily Timer ................................. 44

Optional Components

Hooking up optional components ........... 45

Listening to audio from a connected

component ........................................ 46

Enjoying the 5.1 channel sound with the

optional amplifier ............................. 46

Recording on a connected component .... 46

Troubleshooting

Problems and remedies ........................... 47

Additional Information

Precautions .............................................. 51

Specifications .......................................... 53

Glossary .................................................. 55

Language code list .................................. 57

Control Menu Item List........................... 58

Setup Display Item List........................... 59

This system can play the

following discs

DVD VIDEOs Audio CDs VIDEO CD

Disc

logo

Contents Audio + Audio Audio +

Video Video

The “DVD VIDEO” logo is a trademark.

Discs that this system

cannot play

• CD-ROMs (PHOTO CDs included)

• All CD-Rs other than music and VCD format

CD-Rs

• Data part of CD-Extras

• DVD-ROMs

• DVD Audio discs

• Super Audio CDs

Note

Some CD-Rs/CD-RWs or DVD-Rs/DVD-RWs

cannot be played on this system depending upon the

format or the recording quality or physical condition

of the disc, or the characteristics of the recording

device.

Furthermore, the disc will not play if it has not been

correctly finalized. For more information, see the

operating instructions for the recording device.

Region code of DVDs you can

play on this system

Your system has a region code printed on the

back of the unit and will only play DVDs

labeled with identical region code.

DVDs labeled

ALL

will also be played on this

system.

If you try to play any other DVD, the message

“Playback prohibited by area limitations.” will

appear on the TV screen.

Depending on the DVD, no region code

indication may be labeled even though playing

the DVD is prohibited by area restrictions.

Note on playback operations of

DVDs and VIDEO CDs

Some playback operations of DVDs and

VIDEO CDs may be intentionally set by

software producers. Since this system plays

DVDs and VIDEO CDs according to the disc

contents the software producers designed, some

playback features may not be available. Also,

refer to the instructions supplied with the

DVDs or VIDEO CDs.

Note on PBC (Playback Control)

(VIDEO CDs)

This system conforms to Ver. 1.1 and Ver. 2.0

of VIDEO CD standards. You can enjoy two

kinds of playback depending on the disc type.

Disc type

VIDEO CDs

without PBC

functions

(Ver. 1.1 discs)

VIDEO CDs

with PBC

functions

(Ver. 2.0 discs)

Copyrights

This product incorporates copyright protection

technology that is protected by method claims

of certain U.S. patents, other intellectual

property rights owned by Macrovision

Corporation, and other rights owners. Use of

this copyright protection technology must be

authorized by Macrovision Corporation, and is

intended for home and other limited viewing

uses only unless otherwise authorized by

Macrovision Corporation. Reverse engineering

or disassembly is prohibited.

You can

Enjoy video playback (moving

pictures) as well as music.

Play interactive software

using menu screens displayed on the

TV screen (PBC Playback), in

addition to the video playback

functions of Ver. 1.1 discs.

Moreover, you can play high-

resolution still pictures, if they are

included on the disc.

Region code

MODEL NO. HCD-XXX

DVD DECK RECEIVER

AC: 00V 00Hz 00W

SERIAL NO.

XXXXX

List of Button Locations and Reference Pages

Parts Identification

How to use this page

Use this page to find the location of buttons and other

parts of the system that are mentioned in the text.

Illustration number

PLAY MODE qg (9, 13, 14)

Name of button/part Reference page

List of Button Locations and Reference Pages

Main unit

ALPHABETICAL ORDER

A – F

CD SYNCHRO qa (37, 38)

CD SYNCHRO indicator w; (38)

DIRECTION q; (36–38)

Disc tray 9 (12)

Display window 2

DSG qk (40)

DVD N 7 (12–16, 18)

DVD X 7 (13)

FUNCTION ql (12, 14, 36–38,

46)

PHONES jack qf

PLAY MODE/TUNING MODE

qd (12, 14, 15, 33–35, 38)

Remote sensor 4

REPEAT/FM MODE qs (17, 34,

35)

TAPE nN qj (36, 37)

TAPE X qj (36–38)

TUNER AM qg (33–35)

TUNER FM qg (33–35)

TUNING +/– 3 (33–35)

VOLUME +/– 6

P – V

?/1 (power) 1

m/M 3

l/L 3

x 5

Z DVD 8

z REC qh

nN N

?/1

0qaqsqdqf

BUTTON DESCRIPTIONS

CMT-M90DVD 4-239-826-11(1) GB

Remote Control

ANGLE ea (28)

AUDIO ed (25)

BASS/TREBLE 3 (40)

CLEAR ql (14, 15, 17, 27)

CLOCK/TIMER SELECT ws

(39, 44)

CLOCK/TIMER SET wa (11, 39,

44)

CURSOR T/t 5 (11)

DISPLAY qg (23, 35, 42, 43)

DSG 2 (40)

DVD DISPLAY qs (16, 17, 19,

20, 23–25, 27–31, 40)

DVD MENU q; (17)

DVD TOP MENU qf (17)

DVD SETUP ef (19)

DVD N/SELECT qj (12–18,

21, 32)

DVD X qj (13)

DVD x qj (13, 16, 18, 29)

DVD ./> 7 (13, 14, 18)

DVD t / T 8 (13)

ENTER/YES w; (11, 14, 33, 39,

44)

FUNCTION qh (12, 14, 36–38,

46)

Numeric buttons wh (13, 15, 17,

18, 20, 27–32, 34)

PLAY MODE/TUNING MODE

wk (12, 14, 15, 33–35, 38)

REPEAT/FM MODE wl (13, 17,

35)

RETURN O qa (18, 27, 30, 31)

SCROLL eg (43)

SLEEP wd (43)

SUBTITLE e; (28)

TAPE nN qk (36, 37)

TAPE X qk (36–38)

TAPE x qk (36–38)

TAPE m/M 6 (36)

TUNER BAND eh (33–35)

TUNER +/– wj (33–35)

TUNING MEMORY ej (33)

TV @/1 wf (10)

TV CH +/– wg (10)

TV VOL +/– ek (10)

TV VIDEO r; (10)

VES 9 (40)

VOL +/– es

WIDE el (21)

@/1 (power) 1

V/v/B/b/ENTER qd

+/– 4

ALPHABETICAL ORDER

A – E F – W

BUTTON DESCRIPTIONS

NX x

–

––

qaqs

NX x

–

––

Getting Started

CMT-M90DVD 4-239-826-12(1) GB

FM antenna

AM loop antenna

Jack type A

Jack type B

AM loop

antenna

Extend the FM wire

antenna horizontally

AM loop

antenna

Extend the FM

wire antenna

horizontally

FM75

Ω

ANTENNA

FM75

Ω

ANTENNA

1 Connect the speakers.

Connect the right and left speaker cords to

the SPEAKER terminals as shown below.

2 Connect the FM and AM antennas.

Set up the AM loop antenna, then connect

it.

SPEAKER

IMPEDANCE USE 6-16Ω

Hooking up the system

Perform the following procedure 1 to 5 to hook up your system using the supplied cords and

accessories.

Right speaker

Left speaker

Getting Started

continued

White

Black

White

Black

3 Connect the video input jack of your TV

to the VIDEO OUT jack with the video

cable.

When using a TV

Turn on the TV and select the video input so you can

view the pictures from this system.

Tip

For even higher quality video images, you can use an

optional S-video cable to connect the S VIDEO input

jack on your TV to the S VIDEO OUT jack.

4 For models with a voltage selector, set

VOLTAGE SELECTOR to the local

power line voltage.

5 Connect the power cord to a wall outlet.

If the plug does not fit the wall socket,

detach the supplied plug adaptor (only for

models equipped with an adaptor).

To turn on the system, press @/1.

Inserting two size AA (R6)

batteries into the remote

Operating a Sony TV

You can use the following buttons on the

remote to operate a Sony TV.

To Press

Turn the TV on or off TV ?/1.

Switch the TV’s video input TV/VIDEO.

Change the TV channels TV CH +/–.

Adjusts the volume of the TV TV VOL +/–.

speaker(s)

Tip

When the remote no longer operates the system,

replace both batteries with new ones.

Note

If you do not use the remote for a long period of time,

remove the batteries to avoid possible damage from

battery leakage and corrosion.

110V-120V

220V-240V

VOLTAGE

SELECTOR

}

]

Hooking up the system (continued)

Getting Started

Setting the clock

1 Press ?/1 to turn on the system.

2 Press CLOCK/TIMER SET on the

remote.

3 Press + or – on the remote repeatedly

to set the hour.

4 Press ENTER/YES or CURSORt on

the remote.

5 Press + or – on the remote repeatedly

to set the minute.

6 Press ENTER/YES on the remote.

The clock starts working.

To adjust the clock

1 Press CLOCK/TIMER SET on the remote.

2 Press + or – on the remote to select “CLOCK

SET?”, then press ENTER/YES on the

remote.

3 Do the same procedures as step 3 to 6 above.

Playing discs

Loading a disc

1 Press Z DVD.

The disc tray slides out.

2 Place a disc with the label side up on

the disc tray.

3 Press Z DVD again to close the disc

tray.

Playing a disc

— Normal Play/Shuffle Play/Repeat

Play/Scan/Slow-motion Play

Before playing a DVD or a VIDEO CD, turn

on your TV and select the video input.

Depending on the DVD or VIDEO CD, some

operations may be different or restricted. Refer

to the operating instructions supplied with the

disc.

1 Press FUNCTION repeatedly to switch

the function to DVD.

2 Press PLAY MODE/TUNING MODE in

stop mode repeatedly until the mode

you want appears in the display.

Select

No display

(Normal Play)

SHUFFLE

(Shuffle Play)

PGM

(Program Play)

3 Press DVD N.

Notes

• You cannot change the play mode during playback.

• When playing DVDs, you cannot use Shuffle Play

in chapters. Besides, you cannot use Shuffle Play

depending on the DVD.

• When you change the function, the DVD indicator

may light up even when there is no disc.

When you play

a 8 cm disc,

place it on the

inner circle of

the tray.

To play

The tracks on the disc in

original order.

All tracks on the disc in

random order.

The tracks on the disc in the

order you want them to be

played (see “Creating your

own program” on page 14).

DVD/VIDEO CD/CD

Track number

Playing time

SEC

MIN

HOUR

DVD

TITLE

DVD indicator

DVD/VIDEO CD/CD

CMT-M90DVD 4-239-826-11(1) GB

Other operations

Stop play

Pause

Select a track or

chapter

Find a point in

a track or

chapter

Play repeatedly*

(Repeat Play)

Locating a point

quickly in fast

forward or fast

reverse (scan)

Change the

playback speed**

(Slow-motion

play)

Remove a disc

* You cannot use Repeat Play depending on the DVD,

or when playing VIDEO CDs with PBC functions.

You cannot select “REPEAT 1” during Program

Play.

** DVD and VIDEO CD only.

Do this

Press x (or DVD x on the

remote).

Press DVD X. Press again to

resume play.

Press l or L (or DVD .

or > on the remote) repeatedly.

Keep pressing m or M during

play and release it at the desired

point.

Press REPEAT/FM MODE

repeatedly during playback until

“REPEAT” or “REPEAT 1”

appears in the display.

REPEAT: For all the tracks on the

disc.

REPEAT 1: For only the currently

playing title, chapter, or track.

To cancel playing repeatedly, press

REPEAT/FM MODE repeatedly

until “REPEAT” and “REPEAT 1”

disappear from the display.

During playback, press DVD t

or T on the remote. Each

time you press the button, the

speed switches (3 steps). To return

to normal playback, press DVD

During pause mode, press DVD

t or T on the remote.

Each time you press the button, the

speed switches (2 steps). To return

to normal playback, press DVD

Press Z DVD.

Tips

• Depending on the disc, a menu may appear on the

TV screen. You can play the disc interactively by

following the instructions on the menu (see page

17 for DVD, and see page 18 for VIDEO CD).

• You can use the Control Menu to play repeatedly

(page 16).

To enter track number using the

remote

You can also select the track you want using

the remote during Normal Play.

Press the numeric buttons, then press

ENTER. The playback automatically starts.

CMT-M90DVD 4-239-826-11(1) GB

5 To programme additional tracks, repeat

steps 3 and 4.

6 Press DVD N.

Other operations

Cancel Program

Play

Check the

program order

Add a track to

the end of the

program

Tips

• The program you made remains after Program Play

finishes. To play the same program again, press

DVD N. However, the program is cleared when

you open the disc tray.

•“---.--” appears when the total program time

exceeds 1000 minutes, or when DVD titles/chapters

are programmed.

Note

Depending on the DVD, you cannot use Program

Play.

Do this

Press PLAY MODE/TUNING

MODE in stop mode repeatedly

until both “SHUFFLE” and

“PGM” disappear.

Press DVD . or > on the

remote repeatedly during Program

Play.

Perform steps 3 and 4 in stop

mode.

Creating your own

program

— Program Play

You can make a program of up to 25 steps.

Using the front panel display

1 Press FUNCTION repeatedly to switch

the function to DVD.

2 Press PLAY MODE/TUNING MODE in

stop mode repeatedly until “PGM”

appears.

3 Press DVD . or > on the remote

repeatedly until the desired title or

track number appears.

When programming a DVD, press ENTER/

YES on the remote, then press DVD .

or > on the remote repeatedly until the

desired chapter number appears.

4 Press ENTER/YES on the remote.

The title/chapter, or track is programmed.

The step number appears, followed by the

last programmed title or track number.

If you made a mistake, you can clear the last

step from the program by pressing CLEAR

on the remote.

Selected title or track number

Last programmed title

or track number

Total playing time

DVD

TITLE

PGM

SEC

MIN

DVD

TITLE

PGM

DVD/VIDEO CD/CD

CMT-M90DVD 4-239-826-11(1) GB

Using the on-screen display

The North American model is the model used

for OSD (on-screen display) illustration

purposes.

1 Press PLAY MODE/TUNING MODE

repeatedly until “PROGRAM” appears

in the on-screen display.

The Program Display appears on the screen.

2 Select the title, chapter, or track you

want to program.

x When programming a DVD

For example, select chapter “03” of title

“02”.

Press V/v or the numeric buttons to select

“02” under “T”, then press ENTER.

Next, press V/v or the numeric buttons to

select “03” under “C”, then press ENTER.

x When programming a VIDEO CD or

For example, select track “02”.

Press V/v or the numeric buttons to select

“02” under “T”, then press ENTER.

PROGRAM

1. TITLE

– –

2. TITLE

– –

3. TITLE

– –

4. TITLE

– –

5. TITLE

– –

6. TITLE

– –

7. TITLE

– –

ALL

– –

PROGRAM

1. TITLE

– –

2. TITLE

– –

3. TITLE

– –

4. TITLE

– –

5. TITLE

– –

6. TITLE

– –

7. TITLE

– –

ALL

– –

PROGRAM

1. TITLE 0 2

–

0 3

2. TITLE

– –

3. TITLE

– –

4. TITLE

– –

5. TITLE

– –

6. TITLE

– –

7. TITLE

– –

ALL

Selected title and chapter

To erase a step

Press CLEAR on the remote. Each time you

press the button, the last programmed step is

erased.

You can also erase a step by selecting “– –”

in the on-screen display and pressing

ENTER.

3 To program other titles, chapters, or

tracks, repeat step 2.

4 Press DVD N to start Program Play.

Program Play starts. When the program

ends, you can restart the same program

again by pressing DVD N.

To return to normal play

Press PLAY MODE/TUNING MODE

repeatedly until “CONTINUE” appears in the

TV screen.

Note

The displayed number of titles, chapters, or tracks is

the same as that recorded on the disc.

Chapters recorded on a disc

Playing repeatedly

— Repeat Play

You can play all the titles/tracks or a single

title/chapter/track on a disc.

In Shuffle or Program Play mode, the system

repeats the titles or tracks in the shuffled or

programmed order.

Use the remote for the operation.

1 Press DVD DISPLAY during playback.

The Control Menu appears.

2 Press V or v repeatedly to select

“REPEAT”, then press ENTER.

The options for “REPEAT” appear.

3 Press V or v repeatedly to select the

Repeat Play setting.

x When playing a DVD and when

Program Play is set to OFF

• OFF: does not play repeatedly.

• DISC: repeats all the titles.

• TITLE: repeats the current title.

• CHAPTER: repeats the current chapter.

x When playing a VIDEO CD/CD and

when Program Play is set to OFF

• OFF: does not play repeatedly.

• DISC: repeats all the tracks.

• TRACK: repeats the current track.

x When Program Play is set to ON

• OFF: does not play repeatedly.

• ON: repeats Program Play or Shuffle Play.

4 Press ENTER.

Resuming playback from

the point you stopped the

disc

— Resume Play

This system memorizes the point where you

stopped the disc so you can resume from that

point.

1 While playing a disc, press x (or DVD

x on the remote) to stop playback.

“RESUME” appears in the display. If

“RESUME” does not appear, Resume Play

is not available.

2 Press DVD N.

The player starts playback from the point

you stopped the disc in step 1.

To view from the beginning of the

disc

Press x (or DVD x on the remote) twice, then

press DVD N.

Notes

• Depending on where you stopped the disc, the

system may resume playback from a different point.

• Resume play is canceled when:

– you open the disc tray.

– you change the play mode.

– you change the settings using the Setup Display.

DVD/VIDEO CD/CD

To cancel Repeat Play

Select “OFF” in step 3, or press CLEAR.

To turn off the Control Menu

Press DVD DISPLAY repeatedly until the

Control Menu is turned off.

Tip

You can set Repeat Play when the playback is

stopped. Press REPEAT/FM MODE repeatedly to

select the setting, then press DVD N. The Repeat

Play starts.

Playing DVDs using the

Some DVDs have menus to help you enjoy the

DVDs. You can play DVDs using these menus.

Use the remote for the operation.

Using the DVD top menu

A DVD is divided into long sections of a

picture or a music feature called “titles”. When

you play a DVD which contains several titles,

you can select the title you want using the

menu.

1 Press DVD TOP MENU.

The menu appears on the TV screen. The

contents of the menu vary from disc to disc.

2 Press V/v/B/b or the numeric buttons

to select the title you want to play.

3 Press ENTER.

The playback starts from the selected title.

Using the DVD menu

Some DVDs allow you to select the disc

contents using a menu. When you play these

DVDs, you can select items such as the

language for the subtitles and the language for

the sound using the DVD menu.

1 Press DVD MENU.

The menu appears on the TV screen. The

contents of the menu vary from disc to disc.

2 Press V/v/B/b or the numeric buttons

to select the item you want to change.

3 To change other items, repeat step 2.

4 Press ENTER.

Playing VIDEO CDs with

PBC functions (Ver. 2.0)

— PBC Play

You can use menus on your TV screen to enjoy

the disc’s interactive software. The menu

format and structure may differ depending on

each disc.

1 Press DVD N to start playing a VIDEO

CD with PBC functions (Ver. 2.0).

The PBC menu appears on the TV screen.

2 Press V/v or the numeric buttons on

the remote repeatedly to select the item

number you want.

3 Press ENTER on the remote.

4 Continue playback according to the

instructions on the menus to enjoy

interactive playback.

Refer to the operating instructions supplied

with the disc, as the operationg procedure

may differ according to the VIDEO CD.

To go back to the menu

Press RETURN O on the remote.

To cancel playback with PBC

functions

When the playback is stopped, press DVD

. or > on the remote, or the numeric

buttons on the remote to select a track, then

press DVD N.

“Play without PBC” appears on the TV screen

and playback starts from the selected track.

Still images, such as the menu screens, will not

be shown.

To return to PBC playback, press DVD x on

the remote twice, then press DVD N.

Note

Depending on the VIDEO CD, “Press ENTER” in

step 3 may appear as “Press SELECT” in the

operating instructions supplied with the disc. In this

case, press DVD N.

CMT-M90DVD 4-239-826-11(1) GB

DVD/VIDEO CD/CD

4 Press V or v repeatedly to select the

setup item from the displayed list, then

press ENTER.

The selected setup item appears.

Example: “SCREEN SETUP”

5 Press V or v repeatedly to select an

item, then press ENTER.

The options for the selected item appear.

Example: “TV TYPE”

6 Press V or v repeatedly to select a

setting, then press ENTER.

The setting is selected and the setup is

completed.

Example: “4:3 PAN SCAN”

Setting up for DVD/VIDEO CD/CD

Using the Setup Display

By using the Setup Display, you can make

various adjustments to items such as picture

and sound. You can also set a language for the

subtitles and the Setup Display, among other

things. For details on each Setup Display item,

see pages 20–22. For an overall list of Setup

Display items, see page 59.

The North American model is the model used

for OSD (on-screen display) illustration

purposes in this section.

Use the remote for the operation.

1 When the playback is stopped, press

DVD DISPLAY.

The Control Menu appears.

If you press DVD SETUP, you can go to

step 4 directly.

2 Press V or v repeatedly to select

“SETUP”, then press ENTER.

The options for “SETUP” appear.

3 Press V or v repeatedly to select

“CUSTOM”, then press ENTER.

The Setup Display appears.

Selected item

Setup

items

Options

Selected setting

SCREEN SETUP

TV TYPE:

SCREEN SAVER:

BACKGROUND:

16:9

JACKET PICTURE

SCREEN SETUP

TV TYPE:

SCREEN SAVER:

BACKGROUND:

4:3 LETTER BOX

16:9

4:3 PAN SCAN

SCREEN SETUP

TV TYPE:

SCREEN SAVER:

BACKGROUND:

4:3 PAN SCAN

JACKET PICTURE

RESET

DVD

CUSTOM

1 8

(

3 4

)

1 2

(

2 7

)

1 : 3 2 : 5 5

LANGUAGE SETUP

OSD:

DVD MENU:

AUDIO:

SUBTITLE:

ENGLISH

ORIGINAL

ENGLISH

Main

items

continued

To turn off the Setup Display

Press DVD DISPLAY repeatedly until the

Setup Display is turned off.

Tip

If you select “RESET” in step 3, you can reset all of

the “SETUP” settings on pages 20–22 (except for

PARENTAL CONTROL) to the default settings.

After you select “RESET” and press ENTER, select

“YES” and press ENTER to reset the settings (it takes

a few seconds to complete). Do not press ?/1 when

resetting the system.

Setting the display or

sound track language

— LANGUAGE SETUP

“LANGUAGE SETUP” allows you to set

various languages for the on-screen display or

sound track.

x OSD (on-screen Display)

Switches the display language on the screen.

Select the language from the displayed list.

x DVD MENU (DVD only)

Select the language for the DVD menu.*

x AUDIO (DVD only)

Switches the language of the sound track.

Select the language from the displayed list.*

When you select “ORIGINAL”, the language

given priority in the disc is selected.

x SUBTITLE (DVD only)

Switches the language of the subtitle.

Select the language from the displayed list.*

When you select “AUDIO FOLLOW”, the

language for the subtitles changes according to

the language you selected for the sound track.

* If you select “OTHERS t” in “DVD MENU”,

“AUDIO”, or “SUBTITLE”, select and enter the

language code from the list using the numeric

buttons (page 57). After you selected, the language

code (4 digits) is displayed the next time you select

“OTHERS t”.

Note

When you select a language that is not recorded on

the DVD, one of the recorded languages will be

automatically selected (except for “OSD”).

Select “LANGUAGE SETUP” in the Setup Display.

LANGUAGE SETUP

OSD:

DVD MENU:

AUDIO:

SUBTITLE:

ENGLISH

ORIGINAL

ENGLISH

Using the Setup Display (continued)

DVD/VIDEO CD/CD

Settings for the display

— SCREEN SETUP

Select settings according to the connected TV.

x TV TYPE (DVD only)

Select the aspect ratio of the connected TV.

• 16:9: Select this when you connect a wide-

screen TV or a TV with a wide mode function.

• 4:3 LETTER BOX: Select this when you

connect a 4:3 screen TV. This setting displays a

wide picture with bands displayed on the upper

and lower portions of the screen.

• 4:3 PAN SCAN: Select this when you connect

a 4:3 screen TV. This setting displays the wide

picture on the entire screen and cuts off the

portions that do not fit.

Tip

You can select “16:9” by pressing WIDE.

Note

Depending on the DVD, “4:3 LETTER BOX” may be

selected automatically instead of “4:3 PAN SCAN”

or vice versa.

x SCREEN SAVER

Turn on and off the screen saver. If you turn on

the screen saver, the screen saver image

appears when you leave the player in pause or

stop mode for 15 minutes or when you play a

CD for more than 15 minutes. The screen saver

will help prevent your display device from

becoming damaged (ghosting). Press DVD N

to turn off the screen saver.

• ON: Turns on the screen saver.

• OFF: Turns off the screen saver.

x BACKGROUND

Select the background color or picture on the

TV screen when the playback is stopped or

while playing a CD.

• JACKET PICTURE: The jacket picture (still

picture) appears in the background, but only

when the jacket picture is already recorded on

the disc (CD-EXTRA, etc). If the disc does not

contain a jacket picture, the “GRAPHICS”

picture appears.

• GRAPHICS: The preset picture stored in the

system appears in the background.

• BLUE: The background color is blue.

• BLACK: The background color is black.

Select “SCREEN SETUP” in the Setup Display.

SCREEN SETUP

TV TYPE:

SCREEN SAVER:

BACKGROUND:

16:9

JACKET PICTURE

Custom settings

— CUSTOM SETUP

x COLOR SYSTEM (Except for Pan

American and European models)

Select the color system when you play a

VIDEO CD.

• AUTO: Outputs the video signal in the system

of the disc, either PAL or NTSC. If your TV

uses a DUAL system, select AUTO.

• PAL: Changes the video signal of an NTSC

disc and outputs it in the PAL system.

• NTSC: Changes the video signal of a PAL disc

and outputs it in the NTSC system.

Note

You cannot change the color system of the disc itself.

x PAUSE MODE (DVD only)

Select the picture in pause mode.

• AUTO: A picture including subjects that move

dynamically is output with no jitter. Normally

select this position.

• FRAME: A picture including subjects that do

not move dynamically is output in high

resolution.

x PARENTAL CONTROL t (DVD only)

Set a password and playback limitation level

for DVDs with playback limitation for

children. For details, see “Limiting playback by

children (Parental Control)” on page 30.

x TRACK SELECTION (DVD only)

Gives the priority to the sound track which

contains the highest number of channels when

you play a DVD on which multiple audio

formats (PCM, DTS, or Dolby Digital format)

are recorded.

• OFF: No priority given.

• AUTO: Priority given.

Notes

• When you set to “AUTO”, the language setting may

change. The “TRACK SELECTION” setting has

higher priority than the “AUDIO” setting in

“LANGUAGE SETUP” (page 20).

• If PCM, DTS, and Dolby Digital sound tracks have

the same number of channels, the system selects

PCM, DTS, and Dolby Digital sound tracks in this

order.

• Depending on the DVD, the audio channel with

priority may be predetermined. In this case, you

cannot give priority to the DTS, or Dolby Digital

audio format by selecting “AUTO”.

Select “CUSTOM SETUP” in the Setup Display.

CUSTOM SETUP

PAUSE MODE:

PARENTAL CONTROL

TRACK SELECTION: OFF

AUTO

DVD/VIDEO CD/CD

Checking the playing time

and remaining time

You can check the playing time and remaining

time of the current title, chapter, or track, and

the total playing time of the disc.

Use the remote for the operation.

1 Press DVD DISPLAY during playback.

The Control Menu appears.

2 Press DISPLAY repeatedly to change

the time information.

The display and the kinds of time that you

can change depend on the disc you are

playing.

x When playing a DVD

• T

Playing time of the current title

• T–

Remaining time of the current title

• C

Playing time of the current chapter

• C–

Remaining time of the current chapter

x When playing a VIDEO CD (with PBC

functions)

•

Playing time of the current scene

x When playing a VIDEO CD (without

PBC functions) or CD

• T

Playing time of the current track

• T–

Remaining time of the current track

• D

Playing time of the current disc

• D–

Remaining time of the current disc

To turn off the Control Menu

Press DVD DISPLAY repeatedly until the

Control Menu is turned off.

Time information

Disc type

1 8

(

3 4

)

1 2

(

2 7

)

1 : 3 2 : 5 5

DVD

Viewing information about the disc

Checking the playback

information

— ADVANCED

(DVD only)

You can check information such as the bit rate

or the disc layer that is being played.

While playing a disc, an approximate bit rate of

the playback picture is always displayed as

Mbps (Mega bit per second) and the audio as

Kbps (Kilo bit per second).

Use the remote for the operation.

1 Press DVD DISPLAY during playback.

The Control Menu appears.

2 Press V or v repeatedly to select

“ADVANCED”, then press ENTER.

The options for “ADVANCED” appear.

3 Press V or v repeatedly to select the

item.

For each item, see “Displays of each item”.

• BIT RATE: Displays the bit rate.

• LAYER: Displays the layer and the

pick-up point.

4 Press ENTER.

To close the “ADVANCED” display

Select “OFF” in step 3.

To turn off the Control Menu

Press DVD DISPLAY repeatedly until the

Control Menu is turned off.

Displays of each item

By pressing DVD DISPLAY repeatedly, you

can display either “BIT RATE” or “LAYER”,

whichever was selected in “ADVANCED”.

BIT RATE

Bit rate refers to the amount of video/audio

data per second in a disc. The higher the bit

rate, the larger the amount of data. When the

bit rate level is high, there is a large amount of

data. However, this does not always mean that

you can get higher quality pictures or sounds.

LAYER

This item indicates the approximate point

where the disc is playing. When the DVD has

dual layers, the system indicates which layer is

being read (“Layer 0” or “Layer 1”). For details

on the layers, see page 55 (DVD).

Audio

Video

Appears when the DVD

has dual layers

BIT RATE

kbps

Mbps

384

1 8

(

3 4

)

1 2

(

2 7

)

1 : 3 2 : 5 5

DVD

BIT RATE

LAYER

BIT RATE

OFF

DVD/VIDEO CD/CD

Changing the sound

If a DVD is recorded with multilingual tracks,

you can select the language you want while

playing the DVD. If the DVD is recorded in

multiple audio formats, you can select the

audio format you want while playing the DVD.

With stereo CDs or VIDEO CDs, you can

select the sound from the right or left channel

and listen to the sound of the selected channel

through both the right and left speakers. (In this

case, the sound loses its stereo effect.) For

example, when playing a disc containing a song

with the vocals on the right channel and the

instruments on the left channel, you can select

the left channel and hear only the instruments

from both speakers.

Use the remote for the operation.

1 Press DVD DISPLAY during playback.

The Control Menu appears.

2 Press V or v repeatedly to select

“AUDIO”, then press ENTER.

The options for “AUDIO” appear.

3 Press V or v repeatedly to select the

audio signal you want.

x When playing a DVD

Depending on the DVD, the choice of the

language varies. When 4 digits are

displayed, they represent the language code

(see the language code list on page 57).

When the same language is displayed twice

or more, the DVD is recorded in multiple

audio formats.

x When playing a VIDEO CD or CD

• STEREO: The standard stereo sound.

• 1/L: The sound of the left channel

(monaural).

• 2/R: The sound of the right channel

(monaural).

The default setting is “STEREO”.

4 Press ENTER.

To turn off the Control Menu

Press DVD DISPLAY repeatedly until the

Control Menu is turned off.

Tip

You can select the audio setting by pressing AUDIO.

Each time you press the button, the setting changes.

Notes

• For discs not recorded in multiple audio format, you

cannot change the sound.

• Depending on the DVD, you may not be able to

change the sound even if the DVD is recorded in

multiple audio format.

• For VIDEO CDs and CDs, the setting returns to

“STEREO” when you turn off the system or open

the disc tray.

• During DVD playback, the sound may change

automatically.

Displaying the audio

information of the disc

(DVD only)

When you select “AUDIO”, the channels being

played are displayed on the screen.

* “PCM”, “DTS”, or “DOLBY DIGITAL” is

displayed.

For “DOLBY DIGITAL”, the channels in the

playing track are displayed numerically as follows:

For Dolby Digital 5.1 ch:

Current audio format*

Current playing program format**

Rear component 2

Front component 2 +

Center component 1

LFE (Low Frequency

Effect) component 1

Sound adjustment

DVD

1: ENGLISH

1 8

(

3 4

)

1 2

(

2 7

)

1 : 3 2 : 5 5

LRC

LFE

LS RS

PROGRAM FORMAT

DOLBY DIGITAL 3/2.1

DOLBY DIGITAL

3 / 2

continued

**The letters in the program format display mean the

following sound components recorded in the track,

regardless of the actual number of speakers:

L: Front (left)

R: Front (right)

C: Center (monaural)

LS: Rear (left)

RS: Rear (right)

S: Rear (monaural): The rear component of the

Dolby Surround processed signal or the

Dolby Digital signal.

LFE: LFE (Low Frequency Effect)

The display examples are as follows:

• PCM (stereo)

• Dolby Surround

• Dolby Digital 5.1ch

“LFE” is always enclosed in a solid line

regardless of the LFE signal component

being output.

PROGRAM FORMAT

PCM 48kHz 24bit

LRC

PROGRAM FORMAT

DOLBY DIGITAL 2/0

DOLBY SURROUND

LRC

LFE

LS RS

PROGRAM FORMAT

DOLBY DIGITAL 3/2.1

LRC

LFE

LS RS

PROGRAM FORMAT

DTS 3/2.1

• DTS

“LFE” is always enclosed in a solid line

regardless of the LFE signal component

being output.

Changing the sound (continued)

DVD/VIDEO CD/CD

Searching for a title/

chapter/track/index/scene

You can search a DVD disc by title or chapter,

and you can search a VIDEO CD or CD by

track, index, or scene. As titles and tracks are

assigned unique numbers on the disc, you can

select the desired one by entering its number.

Or, you can search for a scene using the time

code (TIME SEARCH).

Use the remote for the operation.

1 Press DVD DISPLAY.

The Control Menu appears.

2 Press V or v repeatedly to select the

search method.

x When playing a DVD

“TITLE”, “CHAPTER”, or “TIME”

Select “TIME” for TIME SEARCH.

x When playing a VIDEO CD

“TRACK” or “INDEX”

x When playing a VIDEO CD (with PBC

functions)

“SCENE”

x When playing a CD

“TRACK” or “INDEX”

3 Press ENTER.

“

(

)

” changes to “--

(

)

”.

The number in parentheses indicates the

total number of titles, chapters, tracks,

indexes, or scenes.

4 Press V or v repeatedly, or press the

numeric buttons to select the title,

chapter, track, index, or scene number

you want to search.

If you make a mistake

Press CLEAR to cancel the number, then

select another number.

5 Press ENTER.

The playback starts from the selected

number.

To search for a scene using

the time code (TIME SEARCH)

(DVD only)

1 In step 2, select “TIME”.

“T

” (playing time of the current

title) is selected.

2 Press ENTER.

“T

” changes to “T --:--:--”.

3 Input the time code using the numeric

buttons, then press ENTER.

For example, to find the scene at 2 hours,

10 minutes, and 20 seconds after the

beginning, just enter “2:10:20”.

To cancel

Press RETURN O.

To turn off the Control Menu

Press DVD DISPLAY repeatedly until the

Control Menu is turned off.

Notes

• The displayed number of titles, chapters, or tracks is

the same as that recorded on the disc.

• When playing a VIDEO CD with PBC functions,

index number does not appear.

• When the chapter number does not appear, you

cannot search the disc by chapter.

• The number in parentheses does not appear when it

is 100 or more.

Enjoying movies

Changing the angles

(DVD only)

When playing a DVD on which various angles

(multi-angles) for a scene are recorded, the

“ANGLE” indicator lights in green. This means

that you can change the viewing angle. For

example, while playing a scene of a train in

motion, you can display the view from either

the front of the train, the left window of the

train or from the right window without having

the train’s movement interrupted.

Use the remote for the operation.

1 Press DVD DISPLAY during playback.

The Control Menu appears.

2 Press V or v repeatedly to select

“ANGLE”.

The angle number appears. The number in

parentheses indicates the total number of

angles.

3 Press b or ENTER.

The angle number changes to “–”.

4 Select the angle you want using the

numeric buttons or V/v, then press

ENTER.

The angle is changed to the selected angle.

To turn off the Control Menu

Press DVD DISPLAY repeatedly until the

Control Menu is turned off.

Tip

You can select the angle by pressing ANGLE. Each

time you press the button, the angle changes.

Note

Depending on the DVD, you may not be able to

change the angles even if multi-angles are recorded

on the DVD.

Displaying the subtitles

(DVD only)

With DVDs on which multilingual subtitles are

recorded, you can change the subtitle language

while playing a DVD, or turn the subtitles on or

off whenever you want. For example, you can

select the language you want to master and turn

the subtitles on for better understanding.

Use the remote for the operation.

1 Press DVD DISPLAY during playback.

The Control Menu appears.

2 Press V or v repeatedly to select

“SUBTITLE”, then press ENTER.

The options for “SUBTITLE” appear.

3 Press V or v repeatedly to select the

language you want, then press ENTER.

The subtitles are displayed in the selected

language.

To cancel the SUBTITLE setting

Select “OFF” in step 3.

To turn off the Control Menu

Press DVD DISPLAY repeatedly until the

Control Menu is turned off.

Tip

You can select the subtitle by pressing SUBTITLE .

Each time you press the button, the language changes.

Notes

• When 4 digits are displayed in step 3, they indicate

the language code. Refer to the language code list

on page 57 to see the language the code represents.

• Depending on the DVD, you may not be able to

change the subtitles even if multilingual subtitles

are recorded on the DVD.

DVD/VIDEO CD/CD

Locking discs

— CUSTOM PARENTAL CONTROL/

PARENTAL CONTROL

You can set two kinds of playback restrictions

for the disc.

• Custom Parental Control

You can set the playback restrictions so that

the system will not play inappropriate discs.

You can set the same Custom Parental

Control password for up to 50 discs. When

you set the fifty-first disc, the playback

restriction for the first disc is canceled.

• Parental Control

You can limit the playback of some DVDs

according to a predetermined level such as

the age of the users. The limited scene is not

played, or replaced by a different scene.

The same password is used for both Custom

Parental Control and Parental Control.

Use the remote for the operation.

Custom Parental Control

1 Insert the disc you want to lock.

If the disc is playing, press DVD x to stop

playback.

2 When the playback is stopped, press

DVD DISPLAY.

The Control Menu appears.

3 Press V or v repeatedly to select

“CUSTOM PARENTAL CONTROL”, then

press ENTER.

“CUSTOM PARENTAL CONTROL” is

selected.

4 Press V or v repeatedly to select “ON

t”, then press ENTER.

x If you have not entered a password

The display for registering a new password

appears.

Enter a 4-digit password using the numeric

buttons, then press ENTER.

The display for confirming the password

appears.

x When you have already registered a

password

The display for entering the password

appears.

5 Enter or re-enter your 4-digit password

using the numeric buttons, then press

ENTER.

“Custom parental control is set.” appears

and the screen returns to the Control Menu

Display.

If you make a mistake entering your

password

Press B before you press ENTER and input

the correct number.

CUSTOM PARENTAL CONTROL

Enter a new 4-digit password, then

press

ENTER

CUSTOM PARENTAL CONTROL

Enter password, then press .

ENTER

Using various additional functions

continued

OFF

PASSWORD

DVD

1 8

(

3 4

)

1 2

(

2 7

)

1 : 3 2 : 5 5

Locking discs (continued)

If you make a mistake

Press RETURN O, then start from step 3

again.

To turn off the Control Menu

Press RETURN O, then press DVD

DISPLAY repeatedly until the Control Menu is

turned off.

To turn off the Custom Parental

Control function

1 In step 4, select “OFF t”, then press

ENTER.

2 Enter your 4-digit password using the

numeric buttons, then press ENTER.

To change the password

1 In step 4, select “PASSWORD t”, then

press ENTER.

The display for entering the password

appears.

2 Enter your 4-digit password using the

numeric buttons, then press ENTER.

3 Enter a new 4-digit password using the

numeric buttons, then press ENTER.

4 To confirm your password, re-enter it using

the numeric buttons, then press ENTER.

Playing the disc for which

Custom Parental Control is set

1 Insert the disc

for which Custom

Parental Control is set

The “CUSTOM PARENTAL CONTROL”

display appears.

2 Enter your 4-digit password using the

numeric buttons, then press ENTER.

The system is ready for playback.

Tip

If you forgot your password, enter the 6-digit number

“199703” using the numeric buttons when the

“CUSTOM PARENTAL CONTROL” display asks

you for your password, then press ENTER. The

display will ask you to enter a new 4-digit password.

Limiting playback by children

(Parental Control)

(DVD only)

1 When the playback is stopped, press

DVD DISPLAY.

The Control Menu appears.

2 Press V or v repeatedly to select

“SETUP”, then press ENTER.

3 Press V or v repeatedly to select

“CUSTOM”, then press ENTER.

4 Press V or v repeatedly to select

“CUSTOM SETUP”, then press ENTER.

The “CUSTOM SETUP” display appears.

5 Press V or v repeatedly to select

“PARENTAL CONTROL t”, then press

ENTER.

x If you have not entered a password

The display for registering a new password

appears.

Enter a 4-digit password using the numeric

buttons, then press ENTER.

The display for confirming the password

appears.

CUSTOM SETUP

PAUSE MODE:

AUTO

TRACK SELECTION

OFF

PARENTAL CONTROL

CUSTOM SETUP

PARENTAL CONTROL

Enter a new 4-digit password, then

press

ENTER

DVD/VIDEO CD/CD

x When you have already registered a

password

The display for entering the password

appears.

6 Enter or re-enter your 4-digit password

using the numeric buttons, then press

ENTER.

The display for setting the playback

limitation level and changing the password

appears.

7 Press V or v repeatedly to select

“STANDARD”, then press ENTER.

The options for “STANDARD” appears.

8 Press V or v repeatedly to select a

geographic area as the playback

limitation level, then press ENTER.

The area is selected.

When you select “OTHERS t”, select and

enter the standard code in the table on page

32 using the numeric buttons.

9 Press ENTER.

The options for “LEVEL” appears.

Press V or v repeatedly to select the

level you want, then press ENTER.

The Parental Control setting is completed.

The lower the value, the more strict the

limitation.

If you make a mistake

Press RETURN O to go back to the previous

screen.

To turn off the Control Menu

Press DVD DISPLAY repeatedly until the

Control Menu is turned off.

CUSTOM SETUP

PARENTAL CONTROL

LEVEL:

OFF

STANDARD:

CHANGE PASSWORD

USA

CUSTOM SETUP

PARENTAL CONTROL

LEVEL:

OFF

USA

STANDARD:

CHANGE PASSWORD

USA

OTHERS

CUSTOM SETUP

PARENTAL CONTROL

LEVEL: OFF

OFF

STANDARD:

CHANGE PASSWORD

NC17

CUSTOM SETUP

PARENTAL CONTROL

LEVEL:

STANDARD:

CHANGE PASSWORD

USA

4: PG13

CUSTOM SETUP

PARENTAL CONTROL

Enter password, then press

ENTER

continued

CMT-M90DVD 4-239-826-11(1) GB

Standard Code

number

Argentina 2044

Australia 2047

Austria 2046

Belgium 2057

Brazil 2070

Canada 2079

Chile 2090

China 2092

Denmark 2115

Finland 2165

France 2174

Germany 2109

Hong Kong 2219

India 2248

Indonesia 2238

Italy 2254

Japan 2276

Standard Code

number

Korea 2304

Malaysia 2363

Mexico 2362

Netherlands 2376

New Zealand 2390

Norway 2379

Pakistan 2427

Philippines 2424

Portugal 2436

Russia 2489

Singapore 2501

Spain 2149

Sweden 2499

Switzerland 2086

Taiwan 2543

Thailand 2528

United Kingdom

2184

Area code

To turn off the Parental Control

function and play the DVD after

entering your password

Set “LEVEL” to “OFF” in step 10.

To change the password

1 In step 7, press v to select “CHANGE

PASSWORD t”, then press ENTER.

The display for entering the password

appears.

2 Follow step 6 to enter a new password.

Playing the disc for which

Parental Control is set

1 Insert the disc

and press DVD N

The “PARENTAL CONTROL” display

appears.

2 Enter your 4-digit password using the

numeric buttons, then press ENTER.

The playback starts.

Tip

If you forgot your password, remove the disc, press

DVD SETUP, then repeat steps 4 and 5 of “Limiting

playback by children”. When you are asked to enter

your password, enter “199703” using the numeric

buttons, then press ENTER. The display will ask you

to enter a new 4-digit password. After you enter a

new 4-digit password, replace the disc in the system

and press

DVD N

. When the “PARENTAL

CONTROL” display appears, enter your new

password.

Notes

• When you play DVDs which do not have the

Parental Control function, playback cannot be

limited on this system.

• Depending on the DVD, you may be asked to

change the parental control level while playing the

disc. In this case, enter your password, then change

the level.

Locking discs (continued)

Tuner

Presetting radio stations

You can preset up to 20 FM stations and 10

AM stations. You can then tune in any of those

stations simply by selecting the corresponding

preset number.

There are two ways to store the station presets.

Automatically tune in

all of the stations

that can be received

in your area and then

store them manually

Manually tune in and

store the radio frequency

of your favorite stations

Setting presets through

automatic tuning

1 Press TUNER FM or TUNER AM (or

TUNER BAND on the remote) to select

FM or AM.

2 Press PLAY MODE/TUNING MODE

repeatedly until “AUTO” appears in the

display.

3 Press TUNING +/– (or TUNER +/– on the

remote).

The frequency changes as the system scans

for a station. Scanning stops automatically

when a station is tuned in. At that time,

“TUNED” and “STEREO” (for stereo

program only) appear.

If “TUNED” does not appear and the

scanning does not stop

Set the frequency of the desired radio

station as described in steps 2 through 5 of

“Setting presets through manual tuning”.

Method

Automatic Tuning Preset

Manual Tuning Preset

Preset number

4 Press TUNING MEMORY on the remote.

5 Press TUNING +/– (or TUNER +/– on the

remote) repeatedly to select the desired

preset station.

6 Press ENTER/YES on the remote.

The station is stored to the selected preset

number.

7 Repeat steps 1 through 6 to preset

other stations.

Setting presets through

manual tuning

1 Press TUNER FM or TUNER AM (or

TUNER BAND on the remote) to select

FM or AM.

2 Press PLAY MODE/TUNING MODE

repeatedly until “AUTO” and “PRESET”

disappear from the display.

3 Press TUNING +/– (or TUNER +/– on the

remote) repeatedly to tune in the

desired station.

4 Press TUNING MEMORY on the remote.

5 Press TUNING +/– (or TUNER +/– on the

remote) repeatedly to select the desired

preset station.

6 Press ENTER/YES on the remote.

The station is stored to the selected preset

number.

7 Repeat steps 1 through 6 to preset

other stations.

Preset number

STEREOTUNED

DVD

REC

VCD

AUTO

STEREOTUNED

DVD

REC

VCD

continued

Other Operations

Tune in a station

with a weak

signal

Change the preset

station

Change the preset

number

To change the AM tuning interval

(Except for the European, Middle

Eastern and Philippine models)

The AM tuning interval is factory-preset to 9 kHz (or

10 kHz for some areas). To change the AM tuning

interval, tune in any AM station first, then turn off the

system. While holding REPEAT/FM MODE, press

?/1. When you change the interval, all the AM

preset stations are erased. To reset the interval, tune

in any AM station first, then turn off the system.

While holding REPEAT/FM MODE, press

?/1.

Note

You cannot change the AM tuning interval in the

Power Saving Mode.

Tips

• The preset stations are retained for about a day even

if you disconnect the mains lead or if a power

failure occurs.

• To improve the reception, adjust the supplied

antennas or connect an external antenna.

Do this

Follow the procedure described

in “Setting presets through

manual tuning”.

Start over from step 1.

Listening to the radio

You can listen to a radio station either by

selecting a preset station, or by manually tuning

in the station.

Listening to a preset station

— Preset Tuning

Preset radio stations in the tuner’s memory first

(see “Presetting radio stations” on page 33).

1 Press TUNER FM or TUNER AM (or

TUNER BAND on the remote) to select

FM or AM.

2 Press PLAY MODE/TUNING MODE

repeatedly until “PRESET” appears in

the display.

3 Press TUNING +/– (or TUNER +/– on the

remote) repeatedly to select the desired

preset station.

To select the desired preset number

using the numeric buttons on the

remote

Press numeric buttons instead of performing

step 3.

To enter preset number 10 or higher, press >10

and the corresponding numeric buttons. To

enter 0, press 10/0.

Example:

To enter preset number 20, press >10, then 2 and

10/0.

Presetting radio stations (continued)

Tuner

Listening to non-preset radio

station

— Manual Tuning

Press TUNER

FM or TUNER AM (or

TUNER BAND on the remote)

to select

FM or AM.

2 Press PLAY MODE/TUNING MODE

repeatedly until “AUTO” and “PRESET”

disappear from the display.

3 Press TUNING +/– (or TUNER +/– on the

remote) repeatedly to tune in the

desired station.

Tips

• To improve broadcast reception, adjust the supplied

antennas, or connect a commercially available

external antenna.

• When an FM stereo program has static noise, press

REPEAT/FM MODE repeatedly until “MONO”

appears. There will be no stereo effect, but the

reception will improve.

• Press PLAY MODE/TUNING MODE repeatedly

until “AUTO” appears in step 2 above, then press

TUNING +/– (or TUNER +/– on the remote). The

frequency indication changes and scanning stops

when the system tunes in a station (Automatic

Tuning).

Using the Radio Data

System (RDS)

(European model only)

What is the Radio Data

System?

Radio Data System (RDS) is a broadcasting

service that allows radio stations to send

additional information along with the regular

program signal. RDS is available only on FM

stations.*

Note

RDS may not work properly if the station you are

tuned in is not transmitting the RDS signal properly

or if the signal is weak.

* Not all FM stations provide RDS service, nor do

they provide the same types of services. If you are

not familiar with the RDS system, check with your

local radio stations for details on RDS services in

your area.

Receiving RDS broadcasts

Simply select a station from the FM band.

When you tune in a station that provides RDS

services, the station name appears in the

display.

To check the RDS information

Each time you press DISPLAY on the remote,

the display changes cyclically as follows:

Station name* t Frequency t Clock display

t BASS level t TREBLE level

* If the RDS broadcast is not properly received, the

station name may not appear in the display.

Tape

Loading a tape

1 Press Z PUSH.

2 Load a recorded/recordable tape into

the cassette holder.

Playing a tape

You can use TYPE I (normal) tape.

1 Press FUNCTION repeatedly to switch

the function to TAPE.

2 Press DIRECTION repeatedly to select

“g” to play one side of a tape, “h”

to play both sides, or “j”

to play

both sides repeatedly.

* The tape deck stops automatically after

repeating the sequence five times.

3 Press TAPE nN.

Press TAPE nN again to play the

bottom side.

Other operations

Stop play

Pause

Fast-forward or

rewind

Remove the tape

Do this

Press x (or TAPE x on the

remote).

Press TAPE X. Press again to

resume play.

Press m or M (or TAPE m or

M on the remote).

Press Z PUSH.

With the side you

want to play/

record facing up

Tape

Recording from a VIDEO CD/CD

(CD Synchro Recording)

Recording manually

Load a recordable tape into the cassette holder.

Load a disc onto the disc tray.

Load a disc (or other audio source), or

tune in the desired station.

Press FUNCTION repeatedly until

“DVD” appears in the display.

Press FUNCTION repeatedly to select

the source you want to record from.

Press CD SYNCHRO. Press z REC.

The tape stands by for recording.

“

” and “B” (or “b”) appear.

To start recording on the side facing away from you, press TAPE nN until

“ ” changes to “ ”.

Press DIRECTION repeatedly to select “g” to record on one side of the tape, or

“h” or “j” to record on both sides.

Press TAPE X.

Steps

Recording to a tape

–– CD Synchro Recording/Recording Manually/Program Edit

You can record from a DVD, VIDEO CD, CD (or connected components) or radio. You can use

Type I (normal) tape.

Press TAPE X, and then start playing

the desired source.

To stop recording

Press x (or TAPE x on the remote).

Note

Depending on the VIDEO CD, you cannot use the CD

Synchro Recording. In this case, record from the

VIDEO CD manually.

Tip

For recording manually:

To pause recording, press TAPE X.

continued

Recording to a tape (continued)

Recording a VIDEO CD/CD by

specifying the track order

— Program Edit

1 Insert a recordable tape into the

cassette holder.

2 Press FUNCTION repeatedly until

“DVD” appears in the display.

3 When the playback is stopped, press

PLAY MODE/TUNING MODE repeatedly

until “PGM” appears.

4 Press DVD . or > on the remote

repeatedly until the desired track

number appears.

5 Press ENTER/YES on the remote.

The track is programmed. The step number

appears, followed by the last programmed

track number.

If you made a mistake, you can clear the last

step from the program by pressing CLEAR

on the remote.

6 To program additional steps, repeat

steps 4 and 5.

7 Press CD SYNCHRO.

The tape stands by for recording and the CD

stands by for playback.

“ ” and “B” (or “b”) appear, and the CD

SYNCHRO indicator lights up.

To start recording on the side facing away

from you, press TAPE nN until

“

” changes to “ ”.

8 Press DIRECTION repeatedly to select

“g” to record on one side of the tape,

or “h” or “j” to record on both

sides.

9 Press TAPE X.

Stop recording

Cancel Program

Edit

Do this

Press x (or TAPE x on the

remote).

Press PLAY MODE/TUNING

MODE repeatedly until “PGM”

disappears from the display.

Selected track number

Last programmed

track number

Total playing time

PGM

SEC

MIN

PGM

Tape

Timer recording radio

programs

To timer record, you must first preset the radio

station (see “Presetting radio stations” on page

33) and set the clock (see “Setting the clock”

on page 11).

1 Tune in the preset radio station (see

“Listening to the radio” on page 34).

2 Press CLOCK/TIMER SET on the

remote.

3 Press + or – on the remote repeatedly

to select “REC SET?”, then press

ENTER/YES on the remote.

“ON” appears and the hour indication

flashes.

4 Set the time to start recording.

Press + or – on the remote repeatedly to set

the hour, then press ENTER/YES on the

remote.

The minute indication flashes.

Press + or – on the remote repeatedly to set

the minute, then press ENTER/YES on the

remote.

5 Set the time to stop recording following

the same procedure as step 4.

6 Load a recordable tape.

7 Press ?/1 to turn off the system.

Other operations

Check the settings/

activate the timer

Change the setting

Cancel the timer

Notes

• You cannot activate the Daily Timer and recording

timer at the same time.

• If you use the recording timer and the Sleep Timer

at the same time, the Sleep Timer has priority.

• Do not operate the system from the time the system

turns on until the recording starts (about 15 seconds

before the preset time).

• If the system is on about 15 seconds before the

preset time, the timer-recording will not be

activated.

• The volume is reduced to minimum during

recording.

Do this

1Press CLOCK/TIMER

SELECT on the remote.

2Press + or – on the remote

repeatedly until “REC

SELECT?” appears, then press

ENTER/YES on the remote.

Start over from step 1.

1Press CLOCK/TIMER

SELECT on the remote.

2Press + or – on the remote

repeatedly until “TIMER

OFF?” appears, then press

ENTER/YES on the remote.

Sound Adjustment

Enjoying virtual surround

sound

VES (Virtual Enhanced Surround) lets you

enjoy surround sound effects by using sound

imaging to create virtual rear speakers from the

sound of the front speakers (L, R) without

using actual rear speakers.

Use the remote for the operation.

1 Press DVD DISPLAY during playback.

The Control Menu appears

2 Press V or v repeatedly to select

“VIRTUAL SURROUND”, then press b

or ENTER.

The options for “VIRTUAL SURROUND”

appear.

3 Press V or v repeatedly to select a

surround effect.

For each item, see “Effects of each item”.

• VES TV

• VIRTUAL SEMI MULTI

DIMENSION

• VES NIGHT

• VES A

4 Press ENTER.

To cancel

Select “OFF” in step 3.

To turn off the Control Menu

Press DVD DISPLAY repeatedly until the

Control Menu is turned off.

Tip

You can select the surround effect by pressing VES.

Each time you press the button, the surround effect

changes.

Adjusting the sound

Generating a more dynamic sound

(Dynamic Sound Generator)

Press DSG.

To cancel the DSG, press DSG again.

Adjusting the bass and treble

1 Press BASS/TREBLE on the remote

repeatedly to select “BASS” or “TREBLE”.

2 While “BASS” or “TREBLE” appears, press

+ or – on the remote repeatedly to adjust the

level.

Sound Adjustment

Effects of each item

VES (Virtual Enhanced Surround) TV

Uses sound imaging to create virtual rear

speakers from the sound of the front speakers

(L, R) without using actual rear speakers

(shown below). The sound imaging effect is

distinct and clearly reproduces each aural

element of the audio track. This mode is

effective when the distance between the front L

and R speakers is short, such as with built-in

speakers on a stereo TV.

VIRTUAL SEMI MULTI DIMENSION

Uses sound imaging to create 5 sets of virtual

rear speakers from the sound of the front

speakers (L, R) without using actual rear

speakers. The virtual speakers are reproduced

as shown in the illustration below. This gives

the sound an expanded effect that fills the area

surrounding the listener.

VES (Virtual Enhanced Surround)

NIGHT

The large sounds, such as explosions, are

compressed, but the quieter sounds are

unaffected. This feature is useful when you

don’t want to disturb other people but still want

to hear the dialog and enjoy the surround sound

effects of VIRTUAL SEMI MULTI

DIMENSION.

VES (Virtual Enhanced Surround) A

Uses sound imaging to create 3 sets of virtual

rear speakers from the sound of the front

speakers (L, R) without using actual rear

speakers. The virtual speakers are reproduced

as shown in the illustration below. Use this

setting to enhance the sound quality.

L : Front speaker (left)

R : Front speaker (right)

: Virtual speaker

continued

CMT-M90DVD 4-239-826-11(1) GB

Notes

• When you select an item, the sound cuts off for a

moment.

• When the playing signal does not contain a signal

for the rear speakers, the surround effects may be

difficult to hear.

• Make sure that your listening position is between

and at an equal distance from your speakers, and

that the speakers are located in similar

surroundings. Otherwise, the VES effect may be

hard to discern.

• “VES NIGHT” only works with Dolby Digital

discs. However, not all discs will respond to the

“VES NIGHT” in the same way.

• If you use the DIGITAL OUT jack, sound will

come from your speakers but it will not have the

VES effect.

Enjoying virtual surround sound

(continued)

Display

Turning off the display

— Power Saving Mode

Even if the system is off, the system consumes

power to display the clock and to stay

responsive to commands from the remote.

Power saving mode reduces the amount of

power consumed during standby.

In this mode, the clock is not displayed.

Press DISPLAY on the remote repeatedly

while the system is off until the clock

display disappears.

To cancel Power Saving Mode

Press DISPLAY while the system is off. Each

time you press the button, the display switches

as follows:

Clock display y No display (Power Saving

Mode)

Tip

The timer continues to operate in Power Saving

Mode.

Using the display

Checking the remaining time/

titles (DVD/VIDEO CD/CD)

When a CD TEXT disc is loaded, you can

check the information stored on the disc, such

as the titles. When the unit detects CD TEXT

discs, the “TEXT” indication appears in the

display.

Sound Adjustment

Falling asleep to music

— Sleep Timer

You can set the system to turn off after a

certain time, so that you can fall asleep to

music.

Press SLEEP on the remote.

Each time you press the button, the minute

display (the turn-off time) changes cyclically as

follows:

SLEEP OFF t AUTO* t 90min t 80min

…

t 10min

* The system automatically turns off in 100 minutes

or after the current CD or tape finishes playing.

Other operations

Check the

remaining time**

Change the time

to turn off

Cancel the Sleep

Timer Function

** You cannot check the remaining time if you select

“AUTO”.

Note

Do not set to “AUTO” during Synchro Recording on

a tape.

Press DISPLAY on the remote during

playback.

Each time you press the button, the display

changes cyclically as follows:

x When playing a DVD

Current title number and the playing time t

Current title number and the remaining time t

Current chapter number and the playing time

t Current chapter number and the remaining

time t Clock display t BASS level t

TREBLE level

x When playing a VIDEO CD/CD

Current track number and the playing time*

t Current track number and the remaining

time*

t Playing time of the current disc*

Remaining time of the disc*

t Track title*

t Clock display t BASS level t TREBLE

level

Checking the total playing

time/titles (DVD/VIDEO CD/

CD)

Press DISPLAY on the remote in stop

mode.

Each time you press the button, the display

changes cyclically as follows:

Total number of tracks and the total playing

time t Disc title*

t Clock display t

BASS level t TREBLE level

When playing VIDEO CDs with PBC functions,

only the scene number and the playing time are

displayed.

These are not displayed during Shuffle Play or

Program Play.

With CD TEXT discs only (certain characters

cannot be displayed). Depending on the disc, some

CD TEXT information may not appear.

To scroll a long text

Press SCROLL on the remote.

Tip

You can check the current track title during playback.

If you press SCROLL on the remote, a track title

appears scrolling in the display. Press SCROLL on

the remote at any point to stop scrolling. Press

SCROLL on the remote again to restart the scrolling.

Note

Dependeing on the DVD, the disc information may

not be displayed.

Press

SLEEP on the remote once.

SLEEP on the remote to select the

time you want.

SLEEP on the remote repeatedly

until “SLEEP OFF” appears.

Other Features

Display / Other Features

7 Press + or – on the remote repeatedly

until the desired sound source appears.

Each time you press the button, the

indication changes cyclically as follows:

TUNER

DVD PLAY

TAPE PLAY

8 Press ENTER/YES on the remote.

The start time, the stop time, and the sound

source appear in turn, before the original

display returns.

9 Press ?/1 to turn off the system.

Other operations

Check the settings/

activate the timer

Change the setting

Cancel the timer

Notes

• You cannot activate the Daily Timer and recording

timer at the same time.

• If you use the Daily Timer and the Sleep timer at

the same time, the Sleep Timer has priority.

• Do not operate the system from the time the system

turns on until the play starts (about 15 seconds

before the preset time).

• You cannot use the optional components connected

to AUDIO IN MD (VIDEO) jacks as the sound

source for Daily Timer.

Waking up to music

— Daily Timer

You can wake up to music at a preset time.

Make sure you have set the clock (see “Setting

the clock” on page 11).

1 Prepare the sound source you want to

play.

• DVD/VIDEO CD/CD: Load a disc. To

start from a specific track, make a

programme (see “Creating your own

program” on page 14).

• Tape: Load a tape.

• Radio: Tune in the preset radio station

(see “Listening to the radio” on

page 34).

2 Press VOLUME + or – (or VOL + or – on

the remote) to adjust the volume.

3 Press CLOCK/TIMER SET on the

remote to display “DAILY SET?”.

4 Press ENTER/YES on the remote.

“ON” appears and the hour indication

flashes.

5 Set the time to start playing.

Press + or – on the remote repeatedly to set

the hour, then press ENTER/YES on the

remote.

The minute indication flashes.

Press + or – on the remote repeatedly to set

the minute, then press ENTER/YES on the

remote.

6 Set the time to stop playing following

the same procedure as step 5.

Do this

1Press CLOCK/TIMER

SELECT on the remote.

2Press + or – on the remote

repeatedly until “DAILY

SELECT?” appears, then press

ENTER/YES on the remote.

Start over from step 1.

1Press CLOCK/TIMER

SELECT on the remote.

2Press + or – on the remote

repeatedly until “TIMER

OFF?” appears, then press

ENTER/YES on the remote.

CMT-M90DVD 4-239-826-11(2) GB

Sound Adjustment

Hooking up optional components

To enhance your system, you can connect optional components. Refer to the operating instructions

provided with each component.

A AUDIO IN MD (VIDEO) jacks

Use audio cords (not supplied) to connect an

MD deck or VCR to these jacks. You can then

listen to analog audio from the MD deck or

VCR through this system.

B OPTICAL OUT jack

Use a digital optical cable (square, not

supplied) to connect an amplifier, MD deck, or

DAT deck with a digital optical input jack. You

can then output the digital audio to the

component from this system. If the jack is

covered with a cap, remove it before use.

Optional Components

MD deck / VCR

From the audio

output jacks of an

MD deck / VCR

To the digital input

jack of an optional

digital component

Optional digital

component

To the S video

input jack of a

Optional TV

To the video

input jack of a

Optional Components

C S VIDEO OUT jack

Use an S video cable (not supplied) to connect

an optional component (such as a TV) to this

jack. You can then output the video to the

component from this unit, and enjoy higher

quality video images.

D VIDEO OUT jack

Use a video cable (supplied) to connect an

optional component (such as a TV) to this jack.

You can then output the video to the

component from this unit, and enjoy the video

images of DVDs, etc.

CMT-M90DVD 4-239-826-11(1) GB

Listening to audio from a

connected component

1 Connect the audio cords.

2 Press FUNCTION repeatedly until “MD”

or “VIDEO” appears.

Start playing the connected component.

Tip

If you cannot select “VIDEO” by pressing

FUNCTION repeatedly, turn off the system, then

press ?/1 while pressing FUNCTION. The function

will change from “MD” to “VIDEO”, and “VIDEO”

will appear in the display. To change back to “MD”,

repeat this procedure.

Note

You cannot perform the above procedure during

Power Saving Mode.

Enjoying the 5.1 channel

sound with the optional

amplifier

By connecting this unit to the optical input jack

of the optional amplifier eqipped with Dolby

Digital or DTS decoder, you can enjoy the 5.1

channel sound. Connect 6 speakers to the

amplifier.

For the speaker placement, refer to the

operating instructions supplied with the

amplifier.

1 Connect the digital optical cable.

2 Press FUNCTION repeatedly until

“DVD” appears.

Tip

It is recommended to use the surround effect such as

5.1 channel Dolby Digital or DTS sound through the

amplifier. You cannot use the surround effect of this

unit.

Note

When you enjoy the 5.1 channel sound through the

optional amplifier, set the volume on this unit to

minimum.

Recording on a connected

component

1 Connect the digital optical cable.

2 Start recording.

Refer to the operating instructions provided

with connected component.

Note

You can digitally record from the discs only.

However, you cannot record from copy prohibited

discs.

CMT-M90DVD 4-239-826-11(1) G

Troubleshooting

Problems and remedies

Should you encounter a problem with your

system, do the following:

1 Make sure the power cord and speaker cords

are correctly and firmly connected.

2 Find your problem in the troubleshooting

checklist below and take the indicated

corrective action.

If the problem persists after doing all of the

above, consult your nearest Sony dealer.

General

“--:--” lights up in the display.

• A power interruption has occured. Set the clock

(see page 11) and timer settings (see pages 39

and 44) again.

There is no sound.

• Press VOLUME + (or VOL + on the remote).

• Make sure the headphones are not connected.

• Check the speaker connections (see page 9).

Sound comes from one channel, or unbalanced

left and right volume.

• Place the speakers as symmetrically as possible.

• Connect the supplied speakers.

There is severe hum or noise.

• Move the system away from the source of noise.

• Connect the system to a different mains.

• Install a noise filter (commercially available) to

the mains line.

The timer cannot be set.

• Set the clock again (see page 11).

The timer does not function.

• Press CLOCK/TIMER SELECT on the remote to

set the timer and light up “cDAILY” or

“cREC” in the display (see pages 39 and 44).

• Check the timer setting and set the correct time

(see pages 39 and 44).

• Cancel the Sleep Timer Function (see page 43).

The remote does not function.

• Remove the obstacle.

• Move the remote closer to the system.

• Point the remote at the system’s sensor.

• Replace the batteries (R6/size AA).

• Locate the system away from the fluorescent

light.

DVD/VIDEO CD/CD Player

The disc tray does not open and “LOCKED”

appears on the front panel display.

• Contact your Sony dealer or local authorized

Sony service facility.

The disc tray does not close.

• Place the disc correctly in the center of the tray.

• Always close the tray by pressing Z DVD.

Trying to press the tray closed with your fingers

may cause problems with the player.

The disc does not eject.

• You cannot eject the disc during CD Synchro

Recording. Press x to cancel the CD Synchro

Recording, then press Z DVD to eject the disc.

• Consult your nearest Sony dealer.

Play does not start.

• Open the disc tray and check whether a disc is

loaded.

• Wipe the disc clean (see page 51).

• Replace the disc.

• Place the disc correctly in the center of the tray.

• Place the disc in the tray with the label side up.

• Remove the disc and wipe away the moisture on

the disc, then leave the system turned on for a

few hours until the moisture evaporates.

• Press DVD N to start play.

• The region code on the DVD does not match the

system.

• Cancel the Custom Parental Control function.

The sound skips.

• Wipe the disc clean (see page 51).

• Replace the disc.

• Try moving the system to a place without

vibration (e.g., on top of a stable stand).

• Try moving the speakers away from the system,

or placing them on separate stands.

When you listen to a track with bass sounds at

high volume, the speaker vibration may cause the

sound to skip.

Play does not start from the first track.

• Press PLAY MODE/TUNING MODE

repeatedly until both “PGM” and “SHUFFLE”

disappear to return to normal play.

• Resume Play has been selected. When the

playback is stopped, press x, then start DVD

playback (see page 16).

• The title, DVD, or PBC menu automatically

appears on the TV screen. Follow the

instructions on the TV screen.

continued

Problems and remedies (continued)


There is no sound.

• The DTS format is selected. Select other audio

format such as Dolby Digital (see page 25).

Playback starts automatically.

• The DVD features an auto playback function.

Refer to the operating instructions supplied with

the disc.

Playback stops automatically.

• Some discs may contain an auto pause signal.

While playing such a disc, the playback stops at

the auto pause signal. Refer to the operating

instructions supplied with the disc.

You cannot perform some functions such as

Stop, Scan, Slow-motion Play, Repeat Play,

Shuffle Play, or Program Play.

• Depending on the disc, you may not be able to

do some of the operations described above. Refer

to the operating instructions supplied with the

disc.

Messages do not appear on the screen in the

language you want.

• Select the language you want for the on-screen

display in “OSD” under “LANGUAGE SETUP”

in the Setup Display (see page 20).

The language for the sound track cannot be

changed.

• Multilingual tracks are not recorded on the DVD

being played.

• The DVD prohibits changing the language for

the sound track. Refer to the operating

instructions supplied with the disc.

The subtitle language cannot be changed.

• Multilingual subtitles are not recorded on the

DVD being played.

• The DVD prohibits changing the subtitles. Refer

to the operating instructions supplied with the

disc.

The subtitle cannot be turned off.

• The DVD prohibits turning off subtitles. Refer to

the operating instructions supplied with the disc.

The angles cannot be changed.

• Multi-angles are not recorded on the DVD being

played. The angle can be changed only when the

“ANGLE” indicator lights up on the front panel

display (see page 28).

• The DVD prohibits changing the angles. Refer to

the operating instructions supplied with the disc.

There is no picture.

• Press FUNCTION repeatedly to select “DVD”.

• Check that the system is connected securely.

• The video cable is damaged. Replace it with a

new one.

• Make sure you connect the system to the video

input jack of your TV (see page 10).

• Make sure you turn on the TV.

• Make sure you select the video input on the TV

so that you can view the pictures from the

system.

The picture noise appears.

• Clean the disc.

• If video from this system has to go through your

VCR to get to your TV, the copy-protection

applied to some DVD programs could affect

picture quality. If you still experience problems

after checking your connections, please try

connecting this system directly to your TV’s S

video-input, if your TV is equipped with this

input (see page 45).

• Except for Pan American and European models,

the color system is different. Set the color system

to match your TV (see pages 22).

The aspect ratio of the screen cannot be

changed even though you set “TV TYPE” in

“SCREEN SETUP” in the Setup Display when

you play a wide picture.

• The aspect ratio is fixed on your DVD.

• If you connect the system with the S-video cable,

connect directly to the TV. Otherwise, you may

not change the aspect ratio.

• Depending on the TV, you may not change the

aspect ratio.

A 5-character service number is displayed on

the screen and on the front panel display.

• The self-diagnosis function is activated. (See the

table on page 50.)

Troubleshooting

continued

Tape Deck

The tape does not record or play, or there is a

decrease in sound level.

• The heads are dirty. Clean them.

• The record/playback heads are magnetised.

Demagnetise them (see page 52).

The tape does not erase completely.

• The record/playback heads are magnetised.

Demagnetise them (see page 52).

There is excessive wow or flutter, or the sound

drops out.

• The capstans in the tape deck are dirty. Clean

them using a cleaning cassette (see page 52).

Noise increases or the high frequencies are

erased.

• The record/playback heads are magnetised.

Demagnetise them (see page 52).

The tape does not record.

• No cassette is loaded. Load a cassette.

• The tab has been removed from the cassette.

Cover the broken tab with adhesive tape (see

page 52).

• The tape has wound to the end.

Optional components

There is no sound.

• Refer to General item “There is no sound.” on

page 47 and check the condition of the system.

• Connect the component properly (see page 45)

while checking:

– if the cords are connected properly.

– if the cord plugs are firmly inserted all the way.

• Turn on the connected component.

• Refer to the operating instructions supplied with

the connected component and start playing.

The sound is distorted.

• Set the volume of the connected component

lower.

The sound from the component connected to the

AUDIO IN MD (VIDEO) jacks is distorted.

• If “VIDEO” appears when you press

FUNCTION repeatedly, switch the function to

“MD” (see the tip for “Listening to audio from a

connected component” on page 46).

Tuner

Severe hum or noise/stations cannot be

received.

• Set the proper band and frequency (see page 33).

• Connect the antenna properly (see page 9).

• Find a place and an orientation that provide good

reception, then set up the antenna again. If you

cannot obtain good reception, we recommend

you connect a commercially available external

antenna.

• The supplied FM lead antenna receives signals

along its entire length, so make sure you extend

it fully.

• Locate the antennas as far away from the speaker

cords as possible.

• Consult your nearest Sony dealer if the supplied

AM antenna has come off the plastic stand.

• Try turning off surrounding electrical

equipments.

A stereo FM program cannot be received in

stereo.

• Press REPEAT/FM MODE until “STEREO”

appears in the display.

If the system still does not operate

properly after performing the above

measures, reset the system as

follows:

1 Disconnect the mains lead.

2 Reconnect the mains lead.

3 Press ?/1 to turn on the system.

4 Press ?/1 while pressing x and z REC.

The system is reset to the factory settings

except for DVD settings. You should set the

settings you made, such as the preset stations,

clock, and timer.

To reset the DVD settings, select “RESET” in

step 3 of “Using the Setup Display” (page 19).

After you select “RESET” and press ENTER,

select “YES”, then press ENTER to reset the

settings (it takes a few seconds to complete).

Do not press ?/1 when resetting the system.

Self-diagnosis function

(When letters/numbers appear in the

display)

When the self-diagnosis function is activated to

prevent the system from malfunctioning, a five-

character service number (e.g., C 13 00) with a

combination of a letter and digits appears on

the screen. In this case, check the following

table.

First three

characters of

the service

number

C 13

C 31

E XX

(XX is a number)

Cause and/or Corrective

Action

The disc is dirty

, Clean the disc with a soft

cloth (see page 51).

The disc is not inserted correctly.

, Re-insert the disc correctly.

To prevent a malfunction, the

system has performed the self-

diagnosis function.

, Contact your nearest Sony

dealer or local authorized

Sony service facility and give

the 5-character service

number.

Example: E 61 10

C:13:00

Problems and remedies (continued)

Additional Information

Precautions

On operating voltage

Before operating the system, check that the operating

voltage of your system is identical with the voltage of

your local power supply.

On safety

• The unit is not disconnected from the AC power

source (mains) as long as it is connected to the wall

outlet, even if the unit itself has been turned off.

• Unplug the system from the wall outlet (mains) if it

is not to be used for an extended period of time. To

disconnect the power cord (mains lead), pull it out

by the plug. Never pull the cord itself.

• Should any solid object or liquid fall into the

system, unplug the system and have it checked by

qualified personnel before operating it any further.

• AC power cord must be changed only at the

qualified service shop.

On placement

• Do not place the system in an inclined position.

• Do not place the system in locations where it is;

— Extremely hot or cold

— Dusty or dirty

— Very humid

— Subject to vibrations

— Subject to direct sunlight.

On heat buildup

• Although the system heats up during operation, this

is not a malfunction.

• Place the system in a location with adequate

ventilation to prevent heat build-up in the system.

If you continuously use this system at a large volume,

the cabinet temperature of the top, side and bottom

rises considerably. To avoid burning yourself, do not

touch the cabinet.

To prevent a malfunction, do not cover the ventilation

hole for the cooling fan.

On operation

• If the system is brought directly from a cold to a

warm location, or is placed in a very damp room,

moisture may condense on the lens inside the DVD

player. Should this occur, the system will not

operate properly. Remove the disc and leave the

system turned on for about an hour until the

moisture evaporates.

• When you move the system, take out any disc.

If you have any questions or problems concerning

your system, please consult your nearest Sony dealer.

Notes on discs

• Before playing, clean the disc with a cleaning cloth.

Wipe the disc from the center out.

• Do not use solvents such as benzene, thinner,

commercially available cleaners or anti-static spray

intended for vinyl LPs.

• Do not expose the disc to direct sunlight or heat

sources such as hot air ducts, nor leave it in a car

parked in direct sunlight.

• Do not use discs encircled with a protection ring.

This may cause a malfunction to the system.

• When using discs that have glue or similar tacky

substance on the label side of the disc or that used a

special ink when the label was printed, there is a

chance that the disc or label may become attached

to parts inside this unit. When this occurs, it may

not be possible to remove the disc, and may also

cause this unit to malfunction. Be sure to check that

the label side of the disc is not sticky before using.

The following types of disc should not be used:

— Rental or used discs with attached seals where

the glue extends beyond the seal. The perimeter

of the seal on the disc is tacky.

— Discs that have labels printed using a special ink

that feels tacky when touched.

• Discs with non-standard shapes (e.g., heart, square,

star) cannot be played on this unit. Attempting to do

so may damage the unit. Do not use such discs.

Note on CD-R/CD-RW playback

Discs recorded on CD-R/CD-RW drives may not be

played back because of scratches, dirt, recording

condition or the drive’s characteristics. Besides, the

discs, which are not yet finalized at the end of

recording, cannot be played back.

Cleaning the cabinet

Clean the cabinet, panel and controls with a soft cloth

slightly moistened with mild detergent solution. Do

not use any type of abrasive pad, scouring powder or

solvent such as thinner, benzene or alcohol.

continued

To save a tape permanently

To prevent a tape from being accidentally recorded

over, break off the cassette tab from side A or B as

illustrated.

If you later want to reuse the tape for recording, cover

the broken tab with adhesive tape.

Before placing a cassette in the tape

deck

Take up any slack in the tape. Otherwise, the tape

may get entangled in the parts of the tape deck and

become damaged.

When using a tape longer than

90 minutes

The tape is very elastic. Do not change the tape

operations such as play, stop, and fast-winding

frequently. The tape may get entangled in the tape

deck.

Cleaning the tape heads

Clean the tape heads after every 10 hours of use.

Be sure to clean the tape heads before you start an

important recording or after playing an old tape.

Use a separately sold dry-type or wet-type cleaning

cassette. For details, refer to the instructions of the

cleaning cassette.

Demagnetising the tape heads

Demagnetise the tape heads and the metal parts that

have contact with the tape after every 20 to 30 hours

of use with a separately sold demagnetising cassette.

For details, refer to the instructions of the

demagnetising cassette.

In case color irregularity is observed

on nearby a TV screen

With the magnetically shielded type of speaker

system, the speakers can be installed near a TV set.

However, color irregularity may still be observed on

the TV screen depending on the type of your TV set.

If color irregularity is observed…

Turn off the TV set once, then turn it on after 15 to 30

minutes.

If color irregularity is observed

again…

Place the speakers farther away from the TV set.

Break off the

cassette tab

Messages

One of the following messages may appear or

flash in the display during operation.

DVD

No Disc

There is no DVD in the player.

Push STOP!

You pressed PLAY MODE/TUNING MODE

during play.

Cannot use

You pressed an invalid button.

Cannot Edit

You tried to label a CD TEXT disc.

No Disc

There is no CD in the player.

OVER

You have reached the end of the CD while

pressing M during play or pause.

Step Full!

You tried to program 26 or more tracks (steps).

TAPE

Cannot SYNC!

There is no tape in the tape deck, or the tab has

been removed from the cassette.

No Tab

You cannot record the tape because the tab has

been removed from the cassette.

No Tape

There is no tape in the tape deck.

Protect

Consult your nearest Sony dealer.

TUNER

WAIT

The function is switching to the tuner.

Precautions (continued)

Additional Information

Specifications

Main Unit (HCD-M90)

Amplifier section

For the U.S. model

AUDIO POWER SPECIFICATIONS

POWER OUTPUT AND TOTAL

HARMONIC DISTORTION:

With 6-ohm loads, both channels driven, from

70 - 20,000 Hz; rated 18 watts per channel

minimum RMS power, with no more than 0.9%

total harmonic distortion from 250 milliwatts to

rated output.

North American model:

Continuous RMS power output (reference):

20 + 20 W

(6 ohms at 1 kHz, 10%

THD)

Total harmonic distortion less than 0.07% (6 ohms at

1 kHz, 12 W)

European model:

DIN power output (rated): 15 + 15 W

(6 ohms at 1 kHz, DIN)

Continuous RMS power output (reference):

20 + 20 W

(6 ohms at 1 kHz, 10%

THD)

Music power output (reference):

40 + 40 W

Other models:

The following measured at 230 V AC, 60 Hz

DIN power output (rated): 15 + 15 W

(6 ohms at 1 kHz, DIN)

Continuous RMS power output (reference):

18 + 18 W

(6 ohms at 1 kHz, 10%

THD)

The following measured at 220 V AC, 60 Hz

DIN power output (rated): 12 + 12 W

(6 ohms at 1 kHz, DIN)

Continuous RMS power output (reference):

15 + 15 W

(6 ohms at 1 kHz, 10%

THD)

Inputs

AUDIO IN MD (VIDEO) (phono jacks):

Sensitivity 500/250 mV,

impedance 47 kilohms

Outputs

VIDEO OUT: max. output level

(phono jack) 1 Vp-p, unbalanced,Sync

negative, load impedance

75 ohms

S-VIDEO OUT: Y: 1 Vp-p, unbalanced,

(4-pin/mini-DIN jack) Sync negative,

C: 0.286Vp-p,

load impedance 75 ohms

OPTICAL OUT: Optical

Wavelength: 660 nm

PHONES: Accepts headphones with

an impedance of 8 ohms

or more

SPEAKER: accepts impedance of 6 to

16 ohms.

DVD player section

Laser Semiconductor laser

(DVD: λ=650 nm,

CD: λ=780 nm)

Emission duration:

continuous

Frequency response DVD (PCM 48 kHz):

2 Hz – 22 kHz = (±1 dB)

CD: 2 Hz – 20 kHz =

(±1 dB)

Signal-to-noise ratio More than 90 dB

Dynamic range More than 90 dB

Video color system format

NTSC, PAL

Tape deck section

Recording system 4-track 2-channel stereo

Frequency response 50 – 13,000 Hz (±3 dB),

using Sony TYPE I

cassettes

Wow and flutter ±0.15% W. Peak (IEC)

0.1% W. RMS (NAB)

±0.2% W. Peak (DIN)

continued

CMT-M90DVD 4-239-826-11(2) GB

Tuner section

FM stereo, FM/AM superheterodyne tuner

FM tuner section

Tuning range

North American model: 87.5 - 108.0 MHz

(100-kHz step)

Other models: 87.5 - 108.0 MHz

(50-kHz step)

Antenna FM wire antenna

Antenna terminals 75 ohms unbalanced

Intermediate frequency 10.7 MHz

AM tuner section

Tuning range

Pan American model: 530 - 1,710 kHz

(with the tuning interval

set at 10 kHz)

531 - 1,710 kHz

(with the tuning interval

set at 9 kHz)

European model: 531 - 1,602 kHz

(with the tuning interval

set at 9 kHz)

Other models: 530 - 1,710 kHz

(with the tuning interval

set at 10 kHz)

531 - 1,602 kHz

(with the tuning interval

set at 9 kHz)

Antenna AM loop antenna, external

antenna terminal

Intermediate frequency 450 kHz

Speaker (SS-CM90)

Speaker system 2-way, bass-reflex type

Speaker units

Woofer: 10 cm dia., cone type

Tweeter: 2.5 cm dia., balanced

drive type

Nominal impedance 6 ohms

General

Power requirements

North American model: 120 V AC, 60 Hz

European model: 230 V AC, 50/60 Hz

Australian model: 230 V AC, 50/60 Hz

Other models: 110 – 120 V or

220 – 240 V AC,

50/60 Hz

Adjustable with voltage

selector

Power consumption

European model: see the name plate

0.3 watts (at the Power

Saving mode)

Other models: see the name plate

Dimensions (w/h/d) incl. projecting parts and controls

Amplifier/Tuner/Tape/DVD section:

Approx. 159 × 217 ×

335 mm

Speaker: Approx. 140 × 217 ×

226 mm

Mass

Amplifier/Tuner/Tape/DVD section:

Approx. 5.7 kg

Speakers: Approx. 2.4 kg net per

speaker

Supplied accessories Remote (1)

R6 (size AA) batteries (2)

AM loop antenna (1)

FM lead antenna (1)

Video cable (1)

Design and specifications are subject to change

without notice.

Specifications (continued)

Additional Information

DTS

Digital audio compression technology that the

Digital Theater Systems, Inc. developed. This

technology conforms to 5.1-channel surround.

The rear channel is stereo and there is discrete

subwoofer channel in this format. DTS

provides the same 5.1 discrete channels of high

quality digital audio. The good channel

separation is realized because the all channel

data is recorded discrete and processed in

digital.

DVD

A disc that contains up to 8 hours of moving

pictures even though its diameter is the same as

a CD.

The data capacity of a single-layer and single-

sided DVD, at 4.7 GB (Giga Byte), is 7 times

that of a CD. Furthermore, the data capacity of

a dual-layer and single-sided DVD is 8.5 GB, a

single-layer and double-sided DVD 9.4 GB,

and a dual-layer and double-sided DVD 17 GB.

The picture data uses the MPEG 2 format, one

of the worldwide standards of digital

compression technology. The picture data is

compressed to about 1/40 of its original size.

The DVD also uses the variable rate coding

technology that changes the data to be allocated

according to the status of the picture.

The audio data is recorded in Dolby Digital as

well as in PCM, allowing you to enjoy more

real audio presence. Furthermore, various

advanced functions such as the multi-angle,

multilingual, and Parental Control functions are

provided with the DVD.

Index (CD) / Video Index (VIDEO CD)

A number that divides a track into sections to

easily locate the point you want on a VIDEO

CD or a CD. Depending on the disc, no indexes

may be recorded.

Glossary

Bit Rate

Value indicating the amount of video data

compressed in a DVD per second. The unit is

Mbps (Mega bit per second). 1 Mbps indicates

that the data per second is 1,000,000 bits. The

higher the bit rate is, the larger the amount of

data. However, this does not always mean that

you can get higher quality pictures.

Chapter

Sections of a picture or a music piece on a

DVD that are smaller than titles. A title is

composed of several chapters. Each chapter is

assigned a chapter number enabling you to

locate the chapter you want.

Dolby Digital

This sound format for movie theaters is more

advanced than Dolby Pro Logic Surround. In

this format, the rear speakers output stereo

sound with an expanded frequency range and a

subwoofer channel for deep bass is

independently provided. This format is also

called “5.1” because the subwoofer channel is

counted as 0.1 channel (since it functions only

when a deep bass effect is needed). All six

channels in this format are recorded separately

to realize superior channel separation.

Furthermore, since all the signals are processed

digitally, less signal degradation occurs.

Dolby Pro Logic Surround

As one method of decoding Dolby Surround,

Dolby Pro Logic Surround produces four

channels from two-channel sound. Compared

with the former Dolby Surround system, Dolby

Pro Logic Surround reproduces left-to-right

panning more naturally and localizes sounds

more precisely. To take full advantage of

Dolby Pro Logic Surround, you should have

one pair of rear speakers and a centre speaker.

The rear speakers output monaural sound.

continued

Multi-angle function

Various angles, or viewpoints of the video

camera, for a scene are recorded on some

DVDs.

Multilingual function

Several languages for the sound or subtitles in a

picture are recorded on some DVDs.

Parental Control

A function of the DVD to limit playback of the

disc by the age of the users according to the

limitation level in each country. The limitation

varies from disc to disc; when it is activated,

playback is completely prohibited, violent

scenes are skipped or replaced with other

scenes and so on.

Playback Control (PBC)

Signals encoded on VIDEO CDs (Version 2.0)

to control playback. By using menu screens

recorded on VIDEO CDs with PBC functions,

you can enjoy playing simple interactive

programs, programs with search functions, and

so on.

Region Code

This system is used to protect copyrights. A

region number is allocated on each DVD

system or DVD disc according to the sales

region. Each region code is shown on the

system as well as on the disc packaging. The

system can play the discs that match its region

code. The system can also play discs with the

“

ALL

” mark. Even when the region code is not

shown on the DVD, the region limit may still

be activated.

Scene

On a VIDEO CD with PBC functions (page

18), the menu screens, moving pictures, and

still pictures are divided into sections called

“scenes”. Each scene is assigned a scene

number enabling you to locate the scene you

want.

Title

The longest sections of a picture or a music

piece on a DVD; a movie, etc., for a picture

piece on video software; or an album, etc., for a

music piece on an audio software. Each title is

assigned a title number enabling you to locate

the title you want.

Track

Sections of a picture or a music piece on a CD

or VIDEO CD. Each track is assigned a track

number enabling you to locate the track you

want.

Virtual Enhanced Surround (VES)

Technology from Sony developed to produce

surround sound for home use using only the

supplied front speakers. You can enjoy the

surround effect using the sound imaging to

create virtual rear speakers from the sound of

the front speakers without using actual rear

speakers.

VIDEO CD

A compact disc that contains moving pictures.

The picture data uses the MPEG 1 format, one

of the worldwide standards of digital

compression technology. The picture data is

compressed to about 1/140 of its original size.

Consequently, a 12 cm VIDEO CD can contain

up to 74 minutes of moving pictures.

VIDEO CDs also contain compact audio data.

Sounds outside the range of human hearing are

compressed while the sounds we can hear are

not compressed. VIDEO CDs can hold 6 times

the audio information of conventional audio

CDs.

There are 2 versions of VIDEO CDs.

• Version 1.1: You can play only moving pictures

and sounds.

• Version 2.0: You can play high-resolution still

pictures and enjoy PBC functions.

This system conforms to both versions.

DVD

structure

VIDEO CD

or CD

structure

Title

Disc

Index

Track

Chapter

Disc

Glossary (continued)

Additional Information

Language code list

For details, see pages 20, 25 and 28.

The language spellings conform to the ISO 639: 1988 (E/F) standard.

Code Language Code Language Code Language Code Language

1027 Afar 1186 Scots Gaelic 1350 Malayalam 1513 Siswati

1028 Abkhazian 1194 Galician 1352 Mongolian 1514 Sesotho

1032 Afrikaans 1196 Guarani 1353 Moldavian 1515 Sundanese

1039 Amharic 1203 Gujarati 1356 Marathi 1516 Swedish

1044 Arabic 1209 Hausa 1357 Malay 1517 Swahili

1045 Assamese 1217 Hindi 1358 Maltese 1521 Tamil

1051 Aymara 1226 Croatian 1363 Burmese 1525 Telugu

1052 Azerbaijani 1229 Hungarian 1365 Nauru 1527 Tajik

1053 Bashkir 1233 Armenian 1369 Nepali 1528 Thai

1057 Byelorussian 1235 Interlingua 1376 Dutch 1529 Tigrinya

1059 Bulgarian 1239 Interlingue 1379 Norwegian 1531 Turkmen

1060 Bihari 1245 Inupiak 1393 Occitan 1532 Tagalog

1061 Bislama 1248 Indonesian 1403 (Afan) Oromo 1534 Setswana

1066 Bengali; Bangla 1253 Icelandic 1408 Oriya 1535 Tonga

1067 Tibetan 1254 Italian 1417 Punjabi 1538 Turkish

1070 Breton 1257 Hebrew 1428 Polish 1539 Tsonga

1079 Catalan 1261 Japanese 1435 Pashto; Pushto 1540 Tatar

1093 Corsican 1269 Yiddish 1436 Portuguese 1543 Twi

1097 Czech 1283 Javanese 1463 Quechua 1557 Ukrainian

1103 Welsh 1287 Georgian 1481 Rhaeto-Romance 1564 Urdu

1105 Danish 1297 Kazakh 1482 Kirundi 1572 Uzbek

1109 German 1298 Greenlandic 1483 Romanian 1581 Vietnamese

1130 Bhutani 1299 Cambodian 1489 Russian 1587 Volapük

1142 Greek 1300 Kannada 1491 Kinyarwanda 1613 Wolof

1144 English 1301 Korean 1495 Sanskrit 1632 Xhosa

1145 Esperanto 1305 Kashmiri 1498 Sindhi 1665 Yoruba

1149 Spanish 1307 Kurdish 1501 Sangho 1684 Chinese

1150 Estonian 1311 Kirghiz 1502 Serbo-Croatian 1697 Zulu

1151 Basque 1313 Latin 1503 Singhalese 1703 Not specified

1157 Persian 1326 Lingala 1505 Slovak

1165 Finnish 1327 Laothian 1506 Slovenian

1166 Fiji 1332 Lithuanian 1507 Samoan

1171 Faroese 1334 Latvian; Lettish 1508 Shona

1174 French 1345 Malagasy 1509 Somali

1181 Frisian 1347 Maori 1511 Albanian

1183 Irish 1349 Macedonian 1512 Serbian

Control Menu Item List

Control Menu Items

TITLE (DVD only)

SCENE (VIDEO CD

in PBC Playback only)

TRACK (VIDEO CD only)

CHAPTER (DVD only)

INDEX (VIDEO CD only)

TRACK (CD only)

INDEX (CD only)

TIME

AUDIO

SUBTITLE (DVD only)

ANGLE (DVD only)

REPEAT

VIRTUAL SURROUND

ADVANCED (DVD only)

CUSTOM PARENTAL CONTROL

SETUP

Function

Selects the title (DVD), the scene (VIDEO CD in PBC Playback), or the

track (VIDEO CD) to be played.

Selects the chapter (DVD) or the index (VIDEO CD) to be played.

Selects the track to be played.

Selects the index to be played.

Checks the elapsed time and the remaining playback time.

Input the time code for picture and music searching.

Changes the audio setting.

Displays the subtitles.

Changes the subtitle language.

Changes the angle.

Plays the entire disc (all titles/all tracks) repeatedly or one title/chapter/track

repeatedly.

Uses 3D sound imaging to create virtual speakers to enjoy virtual surround

sound.

Checks the information (bit rate or layer) on the disc while playing a DVD.

Sets the disc to prohibit playback.

CUSTOM Setup

Adjusts the image and sound quality, Parental Control, and other various

settings.

RESET

Returns the settings in “SETUP” to the default setting.

Tips

• Each time you press DVD DISPLAY, the Control Menu display changes cyclically as follows.

Control Menu display t “ADVANCED” display (Appears if you select any setting other than “OFF”. See page

24.) t Control Menu display off

The Control Menu items differ depending on the disc.

• The Control Menu icon indicator lights in green when you select any item except for “OFF” (“REPEAT” and

“VIRTUAL SURROUND” only). The “ANGLE” indicator lights in green only when the angles can be changed.

Additional Information

Setup Display Item List

You can set the following items in the Setup Display.

The order of the displayed items may be different from the actual display.

CUSTOM

– COLOR AUTO

SYSTEM* – PAL

– NTSC

– PAUSE AUTO

MODE – FRAME

–

PARENTAL

LEVEL OFF

CONTROL

– 8.

– 7. NC17

– 6. R

– 5.

– 4. PG13

– 3. PG

– 2.

– 1. G

– STANDARD USA

– OTHERS

– CHANGE PASSWORD

–

TRACK

OFF

SELECTION – AUTO

LANGUAGE

– OSD (Select the language you

want to use from the

displayed language list.)

– DVD MENU (Select the language you

want to use from the

displayed language list.)

– AUDIO (Select the language you

want to use from the

displayed language list.

When you select

ORIGINAL, you can enjoy

the language given

priority on the disc.)

– SUBTITLE (Select the language you

want to use from the

displayed language list.

When you select AUDIO

FOLLOW, the setting is

automatically switched to

the language selected in

AUDIO.)

* Except for Pan American and European models.

SCREEN

– TV TYPE 16:9

– 4:3 LETTER BOX

– 4:3 PAN SCAN

– SCREEN SAVER ON

– OFF

– BACKGROUND JACKET PICTURE

– GRAPHICS

– BLUE

– BLACK

Sony Corporation Printed in Korea

Sony CMT-M90DVD Micro Hi Fi Component System

Product's Documents

User Manual

Specifications

Sony CMT-M90DVD Questions and Answers

Related Products

Sony CMT-CP333 Micro Hi Fi Component System

Sony CMT-HPX10W Micro Hi Fi Component System

Sony CMT-BX5BT Micro HI-FI Component System

Sony CMT-EX200 Micro Hi Fi Component System

Sony CMT-EP707 Micro Hi Fi Component System

Sony CMT-CP33MD Micro Hi Fi Component System
