OWNER’S MANUAL
MICROWAVE OVEN
Please read this owner’s manual thoroughly before operating.
www.lg.com
(optional, please check model specification)
MS408
***
MFL40 257 837
3
CONTENTS
CONTENTS
4
IMPORTANT SAFETY INSTRUCTIONS
8
BEFORE USE
8
Unpacking & Installing
10
Microwave-Safe Utensils
11
Control Panel
12
Setting The Clock
12
More/Less
12
Quick Start
13
HOW TO USE
13
Timed Cooking
13
Microwave Power Levels
13
Energy Saving
14
Child Lock
14
Sensor Cook
15
Sensor Cook Menu Instructions
18
Sensor Reheat
18
Sensor Reheat Menu Instructions
How the Microwave Function Works
Microwaves are a form of energy similar to radio,
television waves, and ordinary daylight. Normally,
microwaves spread outwards as they travel through the
This oven, however, has a magnetron that is designed
to make use of the energy in microwaves. Electricity,
supplied to the magnetron tube, is used to create
microwave energy.
These microwaves enter the cooking area through
openings inside the oven. A tray is located inside the
oven. Microwaves cannot pass through metal walls
of the oven, but they can penetrate such materials as
glass, porcelain and paper, the materials out of which
microwave-safe cooking dishes are constructed.
Microwaves do not heat cookware, though cooking
vessels will eventually get hot from the heat generated
by the food.
Your Microwave oven, is one of the safest
of all home appliances. When the door
is opened, the oven automatically stops
producing microwaves. Microwave energy
is converted completely to heat when it
enters food, leaving no “left over” energy
to harm you when you eat your food.
A very safe appliance
19
Global Menu
20
Global Menu Instructions
Melt
Soften
Quick Defrost
Quick Defrost Menu Instructions
Auto
Defrost
30 Auto
Defrost Menu Instructions
FOOD CHARACTERISTICS &
MICROWAVE COOKING
QUESTIONS & ANSWERS
TECHNICAL SPECIFICATIONS
2
3
3
3
4
5
2
8
2
8
29
29
30
4
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
CAUTION
CAUTION
IMPORTANT SAFETY INSTRUCTIONS
Please keep for future reference. Read and follow all instructions before using your oven to prevent the risk of fі
electric shock, personal injury, or damage when using the oven. This guide does not cover all possible conditions
that may occur. Always contact your service agent or manufacturer about problems that you do not understand.
WARNING
This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “WARNING” or “CAUTION”.
These word means :
WARNING
This symbol will alert you to hazards or unsafe practices which could cause serious bodily harm or death.
CAUTION
This symbol will alert you to hazards or unsafe practices which could cause bodily injury or property damage.
WARNING
1
D
o not attempt to tamper with, or make any adjustments or repairs to the door, door seals,
control panel, safety interlock switches or any other part of the oven which would involve the
removal of any cover protecting against exposure to of service technician.the microwave oven
are faulty. Repairs should only be undertaken by a qualified service technician.
Unlike other appliances, the microwave oven is a high-voltage and a highelectrical-current piece of equipment.
Improper use or repair could result in harmful exposure to excessive microwave energy or in electric shock.
2
D
o not use the oven for the purpose of dehumidification.(ex. Operating themicrowave oven
with wet newspapers, clothes, toys, electric devices, pet or child etc.)
It can be the cause of serious damage to safety such as a fire, a burn or a sudden death due to an electric shock.
3
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
4
A
ccessible parts may become hot during use. Young children should be kept away.
They may get a burn.
5
L
iquids or other foods must not be heated in sealed containers since they are liable to explode.
Remove the plastic wrapping from food before cooking or defrosting. Note though that in some
cases food should be covered with plastic film, for heating or cooking.
They could burst.
6
B
e certain to use proper accessories on each operation mode
.
Improper use could result in damage to your oven and accessories, or could make spark and a fire.
7
T
he children should not allow to play with accessories or hang down from the door handle.
They may get hurt.
8 I
f the door or door seals are damaged, the oven must not be operated until it has been repaired
by a competent person.
5
IMPORTANT SAFETY INSTRUCTIONS
9
I
t is hazardous for anyone other than a competent person to carry out any service or repair
operation that involves the removal of a cover which gives protection against exposure to
microwave energy.
10
W
hen the appliance is operated in the combination mode, children should only use the oven
under adult supervision due to the temperatures generated.
CAUTION
1
2
3
4
5
6
7
You cannot operate your oven with the door open due to the safety interlocks built into the door
mechanism. It is important not to tamper with the safety interlocks.
Do not place any object (such as kitchen towels, napkins, etc.) between the oven front face and
the door or allow food or cleaner residue to accumulate on sealing surfaces.
It could result in harmful exposure to excessive microwave energy.
Do not operate your oven if it is damaged. It is particularly important that the oven door closes
properly and that there is no damage to the:(1) door(bent), (2) hinges and latches (broken or
loosened), (3) door seals and sealing surfaces.
It could result in harmful exposure to excessive microwave energy.
Please ensure cooking times are correctly set, Small amounts of food require shorter cooking or
heating time.
When heating liquids, e.g. soups, sauces and beverages in your microwave oven,
Avoid using straight sided containers with narrow necks.
Do not overheat.
Stir the liquid before placing the container in the oven and again halfway through the
heating time.
After heating, let it stand in the oven for a short time; stir or shake it again carefully and check
the temperature of it before consuming to avoid burns
(especially, contents of feeding bottles and baby food jars).
Microwave heating of beverages can result in delayed eruptive boiling, therefore care has to
be taken when handling the container.
An exhaust outlet is located on the top, bottom or side of the oven.
Don't block the outlet.
It could result in damage to your oven and poor cooking results.
Do not operate the oven when empty. It is best to leave a glass of water in the oven when not
in use. The water will safely absorb all microwave energy, if the oven is accidentally started.
Improper use could result in damage to your oven.
8
Do not cook food wrapped in paper towels, unless your cook book contains instructions for the
food you are cooking. And do not use newspaper in place of paper towels for cooking.
9
Do not use wooden containers and ceramic containers that have metallic (e.g. gold or silver)
inlays. Always remove metal twist ties. Check that the utensils are suitable for use in
microwave ovens before use.
Metallic containers for food and beverages are not allowed during microwave cooking.
They may heat-up and char. Metal objects in particular may arc in the oven, which can cause serious damage.
6
IMPORTANT SAFETY INSTRUCTIONS
10
D
o not use recycled paper products.
11
D
o not rinse the tray and rack by placing it in water just after cooking. This may cause breakage
or damage.
Improper use could result in damage to your oven.
12
B
e certain to place the oven so the front of the door is 8 cm or more behind the edge of the
surface on which it is placed, to avoid accidental tipping of the appliance.
Improper use could result in bodily injury and oven damage.
13
B
efore cooking, pierce the skin of potatoes, apples or any such fruit or vegetable.
They could burst.
14
D
o not cook eggs in their shell. Eggs in their shell and whole hardboiled eggs should not be
heated in microwave ovens since they may explode, even after microwave heating has ended.
Pressure will build up inside the egg which will burst.
15
D
o not attempt deep fat frying in your oven.
This could result in a sudden boil over of the hot liquid.
16
I
f smoke is observed (or emitted), switch off or unplug the appliance and keep the door closed
17
W
hen food is heated or cooked in disposable containers made of plastic, paper or other
combustible materials, keep an eye on the oven and check it frequently.
18
T
he temperature of accessible surfaces may be high when the appliance is operating. Do not
touch the oven door, outer cabinet, rear cabinet, oven cavity, accessories and dishes during
grill mode, convection mode and auto cook operations, before clearing make sure they are
not hot.
As they will become hot, there is the danger of a burn unless wearing thick culinary gloves .
19
T
he oven should be cleaned regularly and any food deposits should be removed.
Failure to maintain the oven in a clean condition could lead to deterioration of the surface that
could adversely affect the life of the appliance and possibly result in a hazardous situation.
20
O
nly use the temperature probe recommended for this oven.
You can not ascertain that the temperature is accurate with an unsuitable temperature probe.
21
F
ollow exact directions given by each manufacturer for their popcorn product. Do not leave the
oven unattended while the corn is being popped. If corn fails to pop after the suggested times,
discontinue cooking. Never use a brown paper bag for popping corn. Never attempt to pop
leftover kernels.
22
T
his appliance must be earthed.
The wires in the mains lead are colored in accordance with the following codes
BLUE ~ Neutral
BROWN ~ Live
GREEN & YELLOW ~ Earth
7
IMPORTANT SAFETY INSTRUCTIONS
23
As the colours of the wires in the mains lead of this appliance may not correspond with the
coloured markings identifying the terminals in your plug proceed as follows:
The wire which is colored BLUE must be connected to the terminal which is marked with the letter
N or Colored BLACK. The wire which is colored BROWN must be connected to the terminal which
is marked with the letter L or colored RED. The wire which is colored GREEN & YELLOW or
GREEN must be connected to the terminal which is marked with the letter E or .
If the supply cord is damaged, it must be replaced by the manufacturer, a service
Improper use may cause serious electric damage.
This oven should not be used for commercial catering purposes.
Improper use could result in damage to your oven.
24
25
26
27
28
29
30
31
32
33
T
he connection may be achieved by having the plug accessible or by incorporating a switch in
Children should be supervised to ensure that they do not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
The appliance is not intended to be operated by means of an external timer or separate
remote-control system.
Only use utensils that are suitable for use in microwave ovens.
This microwave oven must not be placed in a cabinet.
This microwave oven is intended to be used freestanding.
Keep the appliance and its cord out of reach of children less than 8 years.
The door or the outer surface may get hot when the appliance is operating.
This appliance is intended to be used in
hou
sehold
and similar applications
such as
- farm houses
- by clients in hotels, motels and other residential environments
- bed and breakfast type environments
The microwave oven is intended for heating food and beverages. Drying of food or clothing
and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of
34
35
T
he contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature
checked before consumption, in order to avoid burns.
According to the installation requirements set, otherwise the impact of heat, prone to danger.
36
37
S
team cleaner is not to be used.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervisionor instruction concerning use of the appliance by a person responsiblefor their safety.
Children should be supervised to ensure that they do not play with the appliance.
8
BEFORE USE
Unpacking & Installing
BEFORE USE
By following the basic steps on these two pages you will be able to quickly check that your oven is operating correctly.
Please pay particular attention to the guidelines on where to install your oven. When unpacking your oven make sure
you remove all accessories and packing materials. Check to make sure that your oven has not been damaged during
shipping.
1 Unpack your oven and place it on a at level surface.
2 Place the oven on the level location of your choice with more
than 85cm height but make sure there is at least 20cm of space
on the top and 10cm at the rear for proper ventilation.
The front of the oven should be at least 8cm from the edge of
the surface to prevent tipping.
An exhaust outlet is located on bottom or side of the oven.
Blocking the outlet can damage the oven.
NOTE
•
THIS OVEN SHOULD NOT BE USED FOR COMMERCIAL CATERING PURPOSES.
3 Plug your oven into a standard household socket. Make sure your oven is the only appliance connected to the socket.
If your oven does not operate properly, unplug it from the electrical socket and then plug it back in.
4
Open your oven door by pressing the door open button. Place the rotating ring inside the oven and place the glass tray on top.
5 Fill a microwave safe container with 300 ml (1/2 pint) of water.
Place on the glass tray and close the oven door.
If you have any doubts about what type of container to use
please refer to Page 10.
GLASS TRAY
ROTATING RING
automatically.
9
BEFORE USE
6
Press the STOP/CLEAR button, and press the START/QUICK START button
one time to set 30 seconds of cooking time.
7 The DISPLAY will count down from 30 seconds.
When it reaches 0 it will sound BEEPS. Open the oven door
and test the temperature of the water.
If your oven is operating the water should be warm.
Be careful when removing the container it may be hot.
YOUR OVEN IS NOW INSTALLED
8 The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before
consumption in order to avoid burns.
10
BEFORE USE
Never use metal or metal trimmed utensils in using microwave function
Microwaves cannot penetrate metal. They will bounce o any metal object in the oven and cause arcing, an alarming
phenomenon that resembles lightning. Most heat resistant non metallic cooking utensils are safe for use in your
oven. However, some may contain materials that render them unsuitable as microwave cookware. If you have any
doubts about a particular utensil, there’s a simple way to nd out if it can be used in the microwave.
Place the utensil in question next to a glass bowl lled with water in using microwave function. Microwave at power
HIGH for 1 minute. If the water heats up but the utensil remains cool to the touch, the utensil is microwave-safe.
However, if the water does not change temperature but the utensil becomes warm, microwaves are being absorbed
by the utensil and it is not safe for use in using microwave function. You probably have many items on hand in your
kitchen right now that can be used as cooking equipment in the microwave. Just read through the following checklist.
Dinner plates
Many kinds of dinnerware are microwave-safe. If in doubt consult the manufacturer’s literature or perform the
microwave test.
Glassware
Glassware that is heat-resistant is microwave-safe. This would include all brands of oven tempered glass cookware.
However, do not use delicate glassware, such as tumblers or wine glasses, as these might shatter as the food warms.
Plastic storage containers
These can be used to hold foods that are to be quickly reheated. However, they should not be used to hold foods
that will need considerable time in the oven as hot foods will eventually warp or melt plastic containers.
Paper
Paper plates and containers are convenient and safe to use in using microwave function, provided that the
cooking time is short and foods to be cooked are low in fat and moisture. Paper towels are also very useful for
wrapping foods and for lining baking trays in which greasy foods such as bacon are cooked. In general, avoid
coloured paper products as the colour may run. Some recycled paper products may contain impurities which
could cause arcing or fіres when used in the microwave.
Plastic cooking bags
Provided they are made specially for cooking, cooking bags are microwave safe. However, be sure to make a slit
in the bag so that steam can escape. Never use ordinary plastic bags for cooking in using microwave function, as
they will melt and rupture.
Plastic microwave cookware
A variety of shapes and sizes of microwave cookware are available. For the most part, you can probably use items
you already have on hand rather than investing in new kitchen equipment.
Pottery, stoneware and ceramic
Containers made of these materials are usually ne for use in using microwave function, but they should be tested
to be sure.
Microwave-Safe Utensils
• Some items with high lead or iron content are not suitable as cooking utensils.
• Utensils should be checked to ensure that they are suitable for use in the microwave.
CAUTION
11
BEFORE USE
part
Sensor Cook allows you to cook most of your
favorite food by selecting the food type and
the weight of the food.
See page 14 "Sensor Cook"
See page 19 “Global Menu”
See page 28 “Melt/Soften”
See page 29 “Quick Defrost”
COOK MODE
• Determine the selected cooking category.
• Set cooking times, temperature and power level.
• While cooking with auto and manual function, you
can increase or decrease the cooking time at any
point by turning the dial (except defrost mode).
STOP / CLEAR
/
• Stop over and clear all entries except time of day.
• ECO ON feature saves energy .
START / QUICK START
• In order to start cooking which is selected,
press button one time.
• The quick start feature allows you to set
30 seconds intervals of HIGH power cooking with a
touch of the quick start button.
Control panel
See page 12 ”Setting the Clock“
COOK
See page 18 “Sensor Reheat”
AUTO DEFROST
See page 30 “Auto Defrost”
GLO
B
A
L
M
E
N
U
See page 13 “Timed Cooking”
SE
N
SOR
QUICK
DEFROST
S
E
N
SOR
REHEAT
E
M
T
L
/
SOFT
E
N
PO
E
R
C
O K L C
W
E
CO O
N
MORE/LESS
By turning the DIAL,
6HQVRU&RRN6HQVRU5HKHDW
*OREDO0HQX,0HOW6RIWHQ and manually timed
cooking programs can be adjusted to cook food for
a longer or shorter time. You can increase or
decrease the cooking time by turning the
DIAL while cooking. The max time possible will be
99min9sec.
The QUICK START feature allows you to set 30
seconds intervals of HIGH power cooking with
a touch of the START
Example: Set 2 minutes of cooking on high
power.
1.
Time of day.
2.
Select 2minutes
on
high power.
Press the START button four times
The oven will start before you have
finished the
fourth press.
During QUICK START cooking,you can extend
the cooking time up to 10 minutes by repeatedly
pressing the START key, or, turn
the DIAL if
longer cooking times are required
QUICK START
1. Press ECO ON / STOP.
3. Turn the DIAL until display
shows “$F”WKHQSUHVV
67$57
To adjust the *OREDO0HQX (ex. Corned Beef
1.2 kg) cooking time for a longer time,
or for a shorter time
NOTE: Turn the
DIAL
during time countdown.
Example:To set 11:11 .
1. Press ECO ON / STOP.
2. Press CLOCK one time.
‘24H’ will show in the
display.(press CLOCK
twice for 12 Hour mode)
3. Turn DIAL until display
shows ‘11:’ ,
then press
START for
hour confirmation.
SETTING CLOCK
When your oven is plugged in for the first time or
when power resumes after a power interruption,
the numbers in the display reset to "0".
4. Turn DIAL until display
shows
‘11:11’ ,then press
START .
The clock now starts
counting.
➠
➠
➠
➠
2. Press */2%$/0(18.
‘Ac’ will show in the
display.
➠
➠
. Press START.
➠
12
BEFORE USE
. Turn the DIAL until display
shows “1.2kg”
➠
4
MICROWAVE POWER LEVELS
Your microwave oven is equipped with ten
power levels to give you maximum flexibility and
control over cooking. The adjacent table will give you
some idea of which foods are prepared at each of
the various power levels.
* The adjacent chart shows the power level settings
for your oven.
MICROWAVE POWER LEVEL CHART
Power
Level
Use
* Boiling water.
* Browning ground beef.
* Making candy.
*
Cooking poultry pieces, fish, & vegetables.
* Cooking tender cuts of meat.
* Reheating rice, pasta, & vegetables.
* Reheating prepared foods quickly.
* Reheating sandwiches.
* Cooking egg, milk and cheese dishes.
* Cooking cakes and breads.
* Melting chocolate.
* Cooking veal.
* Cooking whole fish.
* Cooking puddings and custard.
* Cooking ham, whole poultry and lamb.
* Cooking rib roast and sirloin tip.
* Thawing meat, poultry and seafood.
* Cooking less tender cuts of meat.
* Cooking pork chops and roast.
* Taking chill out of fruit.
* Softening butter.
*
Keeping casseroles and main dishes warm.
* Softening butter and cream cheese.
High
90
80
70
60
50
40
30
20
10
100%
( )
2 STAGE TIMED COOKING
For Two Stage cooking, repeat timed cooking
steps 2 and 3 from the above example before
pressing the START button. The 2nd stage will
continue on from the 1st stage by applying the set
power level and set time automatically.
ENERGY SAVING
ECO ON feature saves energy by turning off
the display.This feature only operates when the
ECO ON / STOP button is pressed and then cancels
when the door is opened or any button is pressed.
HOW TO USE
13
HoW to use
TIMED COOKING (manual cooking)
This function allows you to cook food for a
desired time. There are 10 power levels available.
The example below shows how to set 80% power
level for the desired time.
Example:To cook food on 80% Power (Power8)
for 5 minutes 30 seconds
1. Press ECO ON / STOP.
3. Turning the DIAL until the
display shows the desired
time.
2. Press Power three times.
‘P-80’ appears in the
display. This is to tell you
that the oven is set on 80
percent power unless a
different power setting is
chosen.
4. Press START.
When cooking is complete, four short beeps will
sound. The word End shows in the display window.
'End' remains in the display and 3 beeps will sound
every minute until the door is opened, or any button is
pressed.
NOTE:
If you do not select the power level, the oven will
operate at power HIGH. To set HI-POWER
cooking, skip step 2 above.
To set the ECO ON
1. Press ECO ON / STOP
The display will go out
and ECO ON will be
active.
Press the ECO ON / STOP or any other button
to cancel this feature when it is on.
CHILD LOCK
This is a unique safety feature that prevents
unwanted oven operations. Once the CHILD
LOCK is set, no cooking can take place.
If the CHILD LOCK was already set and you
touch another cooking pad, the word L
shows in the display. You can cancel the
CHILD LOCK according to below procedure.
After the CHILD LOCK is turned off, the time of
day will return to the display window. The oven
will operate normally.
Categories:
Sensor Reheat
Sensor Cook
For most Sensor Cooking programs, a chart with
specific food examples and cooking instructions is
provided in the next few pages.
1. The Sensor Cook system works by detecting a
build-up of vapor.
2. Make sure the door remains closed.
3. Once the vapor is detected, two beeps will
sound.
4. Opening the door or pressing the ECO ON /STOP
pad before the vapor is detected will abort the
process. The oven will stop, and the sensor
cooking will be cancelled.
5. Before using Sensor Touch, make sure the
glass turntable is dry, to assure the best results.
SENSOR COOK
OPERATION INSTRUCTION
Sensor cooking provides exciting new features to
make microwaving easier. Your new microwave
oven will guide you, step by step, whether it be
simply to reheat food or cook food.
With all the popular food choices, the Sensor menu
helps you to cook perfectly because it has been
pre-programmed and can tell how long to cook or
reheat food items.
SENSOR COOK
SENSOR allows you to cook most of your favorite
foods without having to select cooking times and
power levels. This oven automatically determines
required cooking times for each food item. This
feature has 15 food categories.
Press and hold
disappears in the display.
To cancel the child lock
To cook
1. Press ECO ON / STOP.
2. Press Sensor Cook
one time.
‘S-F1’ will show
in the display.
4. Press
START.
‘SEnS’ will show in the
display and the cooking
will start.
1. Press ECO ON / STOP.
2. Press and hold
ECO ON / STOP
until L
appears in the display
and two beeps are heard.
To set the child lock
ECO ON / STOP until L
Mashed Potato
3. Turning the DIAL until the
display shows ‘S-F2’
Note: To select the S-P1 or the S-d1 menus,
press the Sensor Cook button repeatedly until the
desired sensor menu is displayed.
When using any Sensor function, it is best that the food
remain uncovered, however, if cooking foods with high
fat content, then a perforated microwave safe cover
should be used. Keep the oven cavity clean at all times.
➠
➠
➠
➠
If the time of day was
already set, the time of day will
GLVDSSHDURQ the display window.
14
HOW TO USE
Menu
Code
S-F1
Instructions
SENSOR COOK MENU INSTRUCTIONS - VEGETABLE
Wash & pat potatoes dry with paper towel. Pierce
each potato 3 times with a fork. Place potatoes
around the outer edge of the turntable.
After cooking potatoes should still be firm. Wrap in
foil and stand.
Jacket Potato
Potatoes
(whole)
1 - 4 pieces
(175 g per
piece)
Room 1 piece = 3
2 pieces = 5
3 pieces = 5
4 pieces = 7
Prepare vegetables. Cut vegetables into even size
pieces. Wash the vegetables and arrange in
microwave- safe dish just large enough to contain the
vegetables so they are no more than 2 - 3 layers deep.
wrap loosely. If cooking more than 1 kind of vegetable,
place the harder vegetables around the outer edge of
the dish with the softer vegetables in the centre,
Add amount of water according to
the quantity
tablespoons,
tablespoons).
Cover with lid or plastic
(0.2kg~0.4kg : 2
0.5kg~0.8kg : 4
Fresh Vegetable
Carrots,
Broccoli,
Cauliflower,
Zucchini,
Beans, Peas
0.2 - 0. 8 kg Room 3
Separate the vegetables into single pieces. Arrange the
vegetables in a microwave- safe dish just large enough
to contain them so they are no more than 2 layers
deep.
wrap loosely. If cooking more than 1 kind of vegetable,
place the harder vegetables around the outer edge of
the dish with the softer vegetables in the centre.
Add amount of water according to
the quantity
tablespoons,
tablespoons).
Cover with lid or plastic
(0.2kg~0.4kg : 2
0.5kg~0.8kg : 4
Frozen
Vegetable
Carrots,
Broccoli,
Cauliflower,
Beans,Peas
0.2 - 0. 8 kg Frozen 3
Peel & remove the seeds from the pumpkin. Finely
chop the onion. Place the pumpkin, onion and stock
into a heatproof, microwave- safe bowl. Cover with lid
or two layers of plastic wrap loosely. After cooking,
blend or process to desired consistency. Stir in cream,
nutmeg and season with salt and pepper.
For potato leek soup, replace the pumpkin with desire
potatoes & replace the onion with leek.
For carrot & sweet potato soup, replace the pumpkin
with equal quantities of carrot and sweet potato. Omit
the cream. Replace the nutmeg with ground cumin.
Fresh Soup
2 - 6 serves
Room
Pumpkin Soup
Serves
Ingredients
2 serves 4 serves 6 serves
Pumpkin 500 g 750 g 1 kg
Brown onion
1
/
2
small 1 small 1 medium
Chicken stock 2 cups 3 cups 4 cups
Cream 2 tbs
1
/
4
tbs
1
/
3
tbs
Ground nutmeg,
To taste
Salt & ground black pepper
-
Mashed Potato
2- 4 serves Room
Ingredients 2 serves 3 serves 4 serves
Potato 450 g 675 g 900 g
Hot Milk
1
/
2
cup
2
/
3
cup
3
/
4
cup
Butter 50 g 75 g 100 g
Salt 7 ground black pepper
Peel potatoes and cut into 2cm cubes. Place the
potato into a microwave- safe dish with 2
tablespoons of water. Place a sheet of damp paper
towel directly onto the surface and cover the dish
with lid or plastic wrap loosely. After cooking allow
potatoes to stand. Drain. Mash the potatoes until
smooth. Stir in hot milk and butter. Season with salt
and pepper.
1 - 3
Weight
Limit
Initial
Temperature
Standing Time
(minutes)
S-F2
S-F3
S-F4
S-F5
HOW TO USE
15
Menu
Code
Instructions
SENSOR COOK MENU INSTRUCTIONS - RICE / PASTA
White Rice
1
/
2
- 2 cups
Rice : Room
Water : Room
3 - 5
Wash the rice under cold water until the water runs
clear. Place the rice and water in a microwave-safe
rice cooker or 3-litre bowl. Cover with lid or double
layer of plastic wrap loosely. After cooking allow the
rice to stand without removing the lid or wrap. After
standing stir with a fork to separate the grains.
Replace the water with stock for more flavour.
Weight
Limit
Initial
Temperature
Standing Time
(minutes)
Rice
1
/
2 cup 1 cup 1
1
/
2 cups 2 cups
Tap water
3
/4 cup 1
1
/4 cups 2 cups 2
1
/2 cups
Porridge
1 - 4 serves
Oats : Room
Milk : Cold
1 - 3
Place the oats and milk in a deep 3-litre heatproof
microwave-safe bowl. Cook uncovered. The oven
will beep, stir the oats well and press start to
continue. After cooking, stir well and top with brown
sugar or honey.
1 serve 2 serves 3 serves 4 serves
Oats
1
/2 cup
2
/3 cup 1 cup 1
1
/3 cups
Cold Milk
3
/
4 cup 1
1
/
2 cups 2
1
/
4 cups 3 cups
Dry Pasta
1 - 4 cups
Water :
hot tap water
(60°C)
2 - 4
Place into a microwave-safe large bowl. Pour hot
tap water into a bowl. Cooked uncovered. The oven
will beep, stir well and press start to continue. After
cooking, stand and stir.
Pasta 1 cup 2 cups 3 cups 4 cups
Hot tap water(60°C)
(1 cup=250 ml)
2
1
/3 cup 4 cups 5 cups 6 cups
Pasta 1 cup 2 cups 3 cups 4 cups
Hot tap water(60°C)
(1 cup=250 ml)
2
1
/3 cup 4 cups 5 cups 6 cups
Pasta 1 cup 2 cups 3 cups 4 cups
Hot tap water(60°C)
(1 cup=250 ml)
2
1
/3 cup 4 cups 5 cups 6 cups
Fresh Pasta
Tortellini
Ravioli
Fettuccine
1 - 4 cups
Water :
hot tap water
(60°C)
2 - 4
Place into a microwave-safe large bowl. Pour hot
tap water into a bowl. Cooked uncovered. The oven
will beep, stir well and press start to continue. After
cooking, stand and stir.
Frozen Pasta
Tortellini
Ravioli
1 - 4 cups
Water :
hot tap water
(60°C)
2 - 4
Place into a microwave-safe large bowl. Pour hot
tap water into a bowl. Cooked uncovered. The oven
will beep, stir well and press start to continue. After
cooking, stand and stir.
Instant Noodle
(1 packet=
approx. 85g)
1 packet
Water :
boiling water
1 - 2
Place unpackaged noodles into a large
microwave-safe bowl.Cook uncovered. When the
Oven beeps,the noodles should be stired well,before
pressing Start to continue the remaining cooking time.
Noodles 1 packet
Boiling water
(1 cup=250 ml)
2 cups
After cooking has finished, briefly stand and
stir before serving.
S-P1
S-P2
S-P3
S-P4
S-P5
S-P6
16
HOW TO USE
Menu
Code
Instructions
SENSOR COOK MENU INSTRUCTIONS - DESSERT
1. Place the butter in a basin and melt on full for
about 1- 1
1
/
2
minutes.
2. Mix together the sugar, cocoa and flour. Beat
together the egg and milk. Stir into the flour
mixture, together with the butter, walnuts and
raisins.
3. Spread in a greased and base- lined shallow dish
measuring 18 x 28cm / 7 x 11 in. Cook
uncovered. At the end of the cooking time,
remove the brownies from the microwave. Stand
or until cooled.
4. For the icing, place the chocolate and coffee in a
basin and cook on full for 3- 4 minutes.
5. Spread the icing over the cake. When almost set
cut the brownies into squares and top each
portion with a piece of walnut.
Brownies
About
10 brownies
Room 10
Prepare the cake following the microwave
instructions on the side of the packet, ignoring the
cooking instructions. Place the cake, uncovered,
onto a microwave- safe rack or upturned plate about
2cm off the turntable. At the end of the cooking time,
remove the cake from the microwave oven, cover
with a plate or piece of foil and stand for 5 minutes
or until the sticky centre portion is completely
cooked.
Cake
Packet
Cake Mix
1 packet Room 5
Prepare the pudding following the microwave
instructions on the side of the packet, ignoring the
cooking instructions. Spoon the pudding batter into
an 8- cup (2 litre) heatproof, microwave- safe bowl.
Top with the sauce mix and boiling water. Place the
cake, uncovered, onto a microwave- safe rack or
upturned plate about 2cm off the turntable. At the
end of the cooking time, remove the pudding from
the microwave oven, cover with a plate or piece of
foil and stand for 5 minutes or until the sticky centre
portion is completely cooked.
Pudding
Self- saucing
sponge pudding
1 packet =
250- 260g
1 packet Room 5
Peel core and roughly chop the fruit. Sprinkle the
fruit with 2- 4 tsp caster sugar. Cover with a lid or
plastic wrap. At the end of the cooking time, allow to
stand.
Stewed Fruit
0.2 - 1.0 kg Room 1 - 3
Weight
Limit
Initial
Temperature
Standing Time
(minutes)
100g butter
100g soft brown sugar
25g cocoa, sifted
50g self- raising flour, sifted
1 egg
1 table spoon milk
25g walnuts, finely chopped
100g plain chocolate
1 table spoon black coffee
walnut halves to decorate
Icing
S-d1
S-d2
S-d3
S-d4
17
HOW TO USE
SENSOR REHEAT
This feature allows you to reheat precooked
room-temperature or refrigerated foods without
selecting cooking times and power levels. This
feature has 6 categories : dinner plate, rice, soup,
casserole, risotto and pizza. To select Sr-1 through
to Sr-6, press the SENSOR REHEAT button
repeatedly.
1. Press ECO ON / STOP.
2. Press Sensor Reheat
one time .
‘Sr1’ will show
in the display.
To reheat DINNER PLATE
Menu
Code
Instructions
SENSOR REHEAT MENU INSTRUCTIONS
Sr1
Arrange the food on a microwave- safe plate. Cover
loosely with plastic wrap. After reheating, allow to
stand.
Dinner Plate
1 serve Refrigerated 2
When reheating 1 or 2 serves soup place into
individual microwave- safe cups or bowls and cover
with plastic wrap loosely. When reheating 3- 4
serves of soup place into 1 large heatproof,
microwave- safe bowl. Cover loosely with two layers
of plastic wrap. After heating stir well before serving.
Note : If reheating soup from the fridge add extra
2- 5 minutes (depending on serving size) on
70% power.
Soup
1- 4 cups
(1 cup=
250 ml)
Room 1 - 2
Place the casserole into a microwave- safe,
heatproof dish. Cover with a lid or double layer of
plastic wrap loosely. After reheating stir well before
serving.
Note : If reheating casserole from the fridge add
extra 2- 6 minutes (depending on serving
size) on 50% power.
Casserole
1- 4 cups
Room 2 - 3
Place the cooked rice into a microwave- safe,
heatproof dish.Cover with a lid or double layer of
plastic wrap loosely. After reheating stir well before
serving.
Note : If reheating rice from the fridge add extra
2- 6 minutes (depending on serving size)
on 50% power.
Rice
1- 4 cups
Room 1
Weight
Limit
Initial
Temperature
Standing Time
(minutes)
1 serve
Meat or chicken 125 g
Mashed potato 200 g
Vegetable, cooked 200 g
3. Press
START.
‘SEnS’ will show in the
display.sensor reheat
starts.
Sr2
Sr3
Sr4
Note: When using any Sensor function, it is best that
the food remain uncovered, however, if reheating
foods with high fat content, then a perforated
microwave safe cover should be used. Keep the
oven cavity clean at all times.
➠ ➠
18
HOW TO USE
Menu
Code
Instructions
SENSOR REHEAT MENU INSTRUCTIONS
Place the cooked risotto into a microwave- safe,
heatproof dish.Cover with a lid or double layer of
plastic wrap loosely.After reheating stir well before
serving.
Note : If reheating risotto from the fridge add extra
2- 6 minutes (depending on serving size)
on 50% power.
Risotto
1- 4 cups
Room 1
Place pizza onto a sheet of non- recycled paper
towel directly on the turntable. Reheat uncovered.
Note: The weight and thickness of pizza varies
considerably, if pizza is not hot enough add
extra time on 50% power.
Pizza
(1 piece=
100 - 120 g)
1 - 4 pieces
Refrigerated
Weight
Limit
Initial
Temperature
Standing Time
(minutes)
GLOBAL MENU
This feature allows you to cook foods by pressing GLOBAL MENU .
1. Press ECO ON / STOP.
2. Press Glabal MENU
RQH timeµ$F¶ZLOOVKRZ
in the
display.
3. Truning the DIAL until
display shows ‘1.2kg’
4. Press START.
To cook four slices of Roast Lamb.
Sr5
Sr6
To select GLOBAL COOK menus Ac)F,F(F, press the GLOBAL MENU button repeatedly.
➠
➠
➠
19
HOW TO USE
$XVVLH)UHQFK,WDOLDQ0LGGOH(DVWHUQDQGWRWDOPHQXV.
It KDVIRRGFDWHJRULHV
Truning the DIAL until
display shows ‘$F’
Press START.
Menu
Code
Ac-1
Instructions
GLOBAL MENU INSTRUCTIONS$866,(0(18
Corned Beef
1.0 - 2.0 kg Refrigerated 15 - 20
Fruity Beef
topside beef
125 ml fruit chutney
1 tbs oil
1 tbs Worcestershire Sauce
1 tbs curry powder
2 tbs mustard powder
1 tbs sweet sherry
Sauce
1
1
/
2
cups stuffing mix
Water to mix
Seasoning
Prepare beef to be seasoned by cutting a pocket in the
centre. Mix sauce Ingredients together and put to one
side. Prepare enough seasoning by following
instructions on the packet. Place loosely into prepared
packet. Tie meat with string. Brush sauce over meat.
Place the meat on a small roasting rack fat side down
in a deep heatproof, microwave- safe bowl. Halfway
through the oven will beep and display turn food over.
Remove the dish from the microwave, carefully turn
the beef over. Press start to continue cooking. At the
end of the cooking time loosely cover the meat with foil
and allow to stand 15 - 20 minutes before serving.
Seasoned Meat
1.0 - 2.0 kg Refrigerated 15 - 20
Corned beef 1 kg 1. 5 kg 2 kg
Warm water 3 cups 4 cups 6 cups
Brown sugar 2 tbs 3 tbs 3 tbs
Malt vinegar 2 tbs 3 tbs 4 tbs
Whole cloves 4 5 6
Peppercorns 6 8 10
Dry bay leaves 2 3 3
Sprigs fresh parsley 3 4 5
Place the corned silverside into an oven bag with
ingredients shown above. Place the bag into a deep
heatproof, microwave- safe bowl. Halfway through
the oven will beep and display turn food over.
Remove the dish from the microwave oven, carefully
turn the beef over. Press start to continue cooking.
At the end of the cooking time allow beef to stand
15 - 20 minutes before serving.
1.0 - 2.0 kg Refrigerated 15 - 20
Apple and Sage Pork
Boned loin pork ( with rind on)
1- 2 cups sage and onion stuffing mix
1
/
2
cup dried apples, chopped
8 - 10 prunes, pitted and chopped
125 g toasted silvered almonds
Seasoning
Following instructions on the packet prepare stuffing.
Add apples, prunes and almonds. Mix well. Pack
loosely down the centre of meat. Roll up tightly and
secure with string. Sprinkle rind with salt. Place the
meat on a small roasting rack fat side down in a deep
heatproof, microwave- safe bowl. Halfway through the
oven will beep and display turn over. Remove the dish
from the microwave oven, carefully turn the meat over.
Press start to continue cooking. At the end of the
cooking time loosely cover the meat with foil and allow
to stand 15- 20 minutes before serving.
Weight
Limit
Initial
Temperature
Standing Time
(minutes)
Ac-2
20
HOW TO USE
Menu
Code
Instructions
GLOBAL MENU INSTRUCTIONS$866,(0(18
Brush both sides of the lamb with olive oil and season
with salt and pepper. Shield the knuckle with foil,
making sure the foil is secure & will not touch the
interior oven walls when rotating. Place the lamb skin-
side side down onto a microwave- safe roasting rack or
upturned plate. Halfway through cooking the oven will
beep and display turn food over. Remove the lamb
from the microwave oven, turn the lamb over and
remove the foil from the knuckle. Press start to
continue cooking. At the end of the cooking time
loosely cover the lamb with foil and allow to stand or
place the lamb into a preheated oven 200°C for 5 - 10
mins to crispen the surface. Allow to stand 15 - 20
minutes before serving
Roast Lamb
1.0 - 2.0 kg Refrigerated 15 - 20
Apricot Lamb
Loin of forequarter lamb (deboned)
1 packet dried apricots
250 ml apricot nectar
1 tbs cornflour
Unroll meat. Place dried apricots down the centre 2
rows deep. Roll up tightly and secure with string.
Mix apricot nectar with corn flour and heat for 3 - 4
minutes on HIGH or until boil. Allow to cool slightly.
Pour apricot juice over the meat and marinade 1 - 2
hours. Remove meat from the marinade, place the
meat on a small roasting rack fat side down in a deep
heatproof, microwave- safe bowl. Halfway through the
oven will beep and display turn food over. Remove the
dish from the microwave oven, carefully turn the meat
over. Press start to continue cooking. At the end of the
cooking time loosely cover the meat with foil and allow
to stand 15 - 20 minutes before serving.
Seasoned Meat
1.0 - 2.0 kg Refrigerated
15 - 20
Wash and pat the chicken dry with paper towel. Brush
both sides of the chicken with olive oil and season with
salt and pepper. Tie the legs together with string.
Shield the legs and wings with foil. Place chicken
breast side down onto a microwave- safe roasting rack
or upturned plate. Halfway through the oven will beep
and display turn food over. Remove the chicken from
the microwave oven, turn the chicken over and remove
the foil from legs and wings. Press start to continue
cooking. At the end of the cooking time, place the
chicken into a preheated oven 200°C for 5- 10 mins to
crispen the skin. Allow to stand 10 minutes before
serving.
Roast Chicken
1.0 - 2.5 kg Refrigerated 10
Brush the chicken pieces with olive oil and season with
salt and pepper. Place chicken skin side up onto a
microwave- safe roasting rack. At the end of cooking.
remove the chicken from the microwave and allow to
stand 2- 3 minutes or place into a preheated oven
200°C for 5 - 10 minutes to crispen the skin
Chicken Pieces
(thigh or cutlets)
0.2 - 0.8 kg Refrigerated 2 - 3
Weight
Limit
Initial
Temperature
Standing Time
(minutes)
Ac-2
Ac-3
Ac-4
Ac-5
21
HOW TO USE
GLOBAL MENU INSTRUCTIONS$866,(0(18
22
HOW TO USE
Weight
Initial
Standing Time
Code
Menu
Instructions
Limit
Temperature
(minutes)
Ac-6
Fish Fillets
0.2 - 0.6 kg Refrigerated Place each fish fillet onto a square of baking paper, 2 - 3
fresh
tuck the tail end under. Drizzle with fresh lemon or
lime juice and season with salt and pepper. Wrap
each fillet in the paper forming a parcel. Place the
fish in a single onto a microwave- safe plate. After
cooking allow to stand 3 mins before carefully
unwrapping the parcel to serve.
Ac-7
Bacon
1 thick or 2 Refrigerated Remove the rind from the bacon and cut the rasher
1 thick rasher= 80 g
thin rashers /
in half crossways. Place between 2 sheets on non-
2 thick or 4
1 thin rasher= 45 g
recycled paper towel on a microwave- safe plate.
thin rashers
After cooking check the result. If you like the bacon
a little more cooked, return to the microwave and
cook in for 20 seconds at a time on 100% power.
Ac-8
Casserole
1 - 4 serves Refrigerated Tuna & Noodle 2 - 3
Ingredients 1 serve 2 serves 3 serves 4 serves
Noodles(pasta),boiled) 140 g 280 g 420 g 560 g
Cream of Mushroom Soup
140 g 280 g 420 g 560 g
Can or equivalent,
Starkist Chunk Light Tuna,
60 g 120 g 180 g 240 g
in spring water, drained
Milk 125 ml 250 ml 375 ml 500 ml
Combine cream of mushroom soup, tuna and milk
in microwave- safe a deep and large bowl. Add
boiled noodles and stir thoroughly. Cover with wrap
or glass lid. Halfway through the oven will beep and
display stir. Press start to continue cooking. At the
end of the cooking time, stand and stir.
Beef Stroganoff
2 - 3
Ingredients 1 serve 2 serves 3 serves 4 serves
Rump steak, cubed 250 g 500 g 750 g 1000 g
Plain flour 2 tbsp
1
/
4
cup
1
/
3
cup
1
/
2
cup
Small onion,
1
/
finely chopped
2
1 1 1
Tomato puree 2 ts 1 tbsp 1
1
/
2
tbsp 2 tbsp
Beef stock 125 ml 200 ml 250 ml 375 ml
Red wine 60 ml 60 ml 60 ml 60 ml
Mushroom, sliced 25 g 50 g 75 g 100 g
Sour cream 75 ml 150 ml 200 ml 300 ml
Salt, Pepper
Toss steak with plain flour, salt and pepper in a flat
dish until coated. Place steak, left flour, chopped
onion, puree, beef stock, red wine and mushroom
into a microwave-safe deep & large dish. Cover with
wrap or glass lid. Halfway through the oven will
beep and display stir. Press start to continue
cooking. At the end of the cooking time, stand and
stir.
GLOBAL MENU INSTRUCTIONS)5(1&+0(18
Weight
Initial
8WHQVLO
Code
Menu
Instructions
Limit
Temperature
Fc-1
Ratatouille
1.5kg Room
0LFURZDYHVDIH
ERZO
Stuffed 7omatoes
1.2kg
Ingredients
1. Add all ingredients in a deep and large bowl and
mix well. Cover with plastic wrap and vent.
2. Place food in the oven. Choose the menu and
press start to cook. Stir at least twice during cooking.
Ingredients
4 medium tomatoes
Salt and pepper to taste
Stuffing
1. Cut tops off tomatoes to form hats and remove
seeds, taking care not to pierce flesh or skin.
Then sprinkle each tomatoes with salt and pepper.
2. Fill tomatoes with stuffing and replace hat.
3. Place stuffed tomatoes on a dish and cover with
plastic wrap.
4. Place food in the oven. Choose the menu and
press start to cook.
※
Stuffing
400g ground beef
½ cup bread crumbs
2 garlic cloves, crushed
1 tablespoon Dijon mustard
1 tablespoon dried greens
1 tablespoon parmesan cheese
1. Add all ingredients in a bowl, mix well, and cover
with plastic wrap.
2. Place food in the oven. Cook for 3~5 minutes on
Microwave 1100 watts. Stir at least once during
cooking.
1 onion, cut into chunks
1 eggplant, cut into chunks
1 zucchini, cut into chunks
1 colored sweet pepper, cut into chunks
3 tomatoes, chopped
1 tablespoon tomato paste
2 garlic cloves, crushed
1 tablespoon fresh greens, chopped
2 tablespoons vinegar
1 teaspoon sugar
Salt and pepper to taste
Fc-2
Room
Ingredients
4 onions, thinly sliced 50g butter
1 teaspoon white sugar
1 tablespoon all-purpose flour
3
cups beef stock
½ cup red wine 1cup grated cheese
French 2nion
6oup
8 slices of toasted French bread
1. Cook onions in a frying pan with butter and sugar
until golden brown.
2. Add cooked onions and flour in a deep and large
bowl, mix well and add beef stock and red wine.
Cover with plastic wrap and vent.
3. Place food in the oven. Choose the menu and
press start to cook. Stir at least twice during cooking.
4.After cooking, stir and ladle soup into serving bowls.
5. Place 1 slice toasted bread on top of the soup in
each bowl and spread cheese on toasted bread.
Cook for 1~2 minutes on Microwave 1100 watts until
cheese melted.
1.5kg Room
Fc-3
HOW TO USE
23
0LFURZDYHVDIH
ERZO
0LFURZDYHVDIH
GLVK
GLOBAL MENU INSTRUCTIONS)5(1&+0(18
Weight
Initial
Utensil
Code
Menu
Instructions
Limit
Temperature
Fc-4
1.2kg Room
Microwave-safe
bowl
Ingredients
Fc-5
Stuffed
0.5kg Room
Ingredients
Microwave-safe
0ushrooms
15~20 champignon mushrooms, stemmed
dish
Stuffing
50g grated cheese
1. Remove stem of each mushroom and put on a dish.
2. Fill each mushroom cap with stuffing.
3. Add cheese on top of each stuffed mushroom.
4. Place food on the rack. Choose the menu and
press start to cook.
※
Stuffing
2 tablespoons butter
Remaining mushroom stems, chopped
¼ cup red wine
30g bread crumbs
3 tablespoons fresh greens, chopped
½ cup cream
Salt and pepper to taste
1.Cook mushroom stems in a frying pan with butter.
Add red wine, bread crumbs and parsley, mix well.
2. Add cream and simmer on low heat until cream
has thickened. Season with salt and pepper.
1.2kg Room
Fc-6
Microwave-safe
bowl
Spinach &ream
6oup
600g vegetable purée
1 ½ cups chicken stock
2 tablespoons all-purpose flour
2 tablespoons butter
1 cup cream
Nutmeg, salt and pepper to taste
1. Add all ingredients in a deep and large bowl and
mix well. Cover with plastic wrap and vent.
2. Place food in the oven. Choose the menu and
press start to cook. Stir at least twice during cooking.
※
Vegetable purée
400g spinach, chopped
2 onions, chopped
4 tablespoons water
1. Place vegetables in a microwave-safe bowl.
2. Add water and cover with plastic wrap.
3. Place food in the oven. Cook for 7~9 minutes
on Microwave 1100 watts.
4. After cooking, blend cooked vegetables using a
blender or food processor until the purée is
smooth and uniform in texture.
Ingredients
1 onion, sliced 1 carrot, sliced
500g chicken legs 1 cup chicken stock
Chicken /egs
with 3runes
15 pitted prunes, halved
Salt and pepper to taste
1. Add all ingredients in a deep and large bowl and
mix well. Cover with plastic wrap and vent.
2. Place food in the oven. Choose the menu and
press start to cook. Stir at least twice during cooking.
HOW TO USE
2
4
GLOBAL MENU INSTRUCTIONS,7$/,$10(18
Weight
Initial
Code
Menu
Instructions
Limit
Temperature
Ic-1
1.0kg Room
Ingredients for bolognaise sauce
1 tablespoon olive oil
1 onion, chopped
1 garlic clove, crushed
400g ground beef
100g tomato paste
2 chopped tomatoes
1 tablespoon dried greens
Spaghetti
%olognaise
Salt and pepper to taste
Ingredients for pasta
150g pasta, cooked as package direction
1 tablespoon parmesan cheese
1. Add all ingredients of the bolognaise sauce in a
deep and large bowl and mix well. cover with plastic
wrap and vent.
2. Place food in the oven. Choose the menu and
press start to cook. Stir at least twice during cooking.
3. After cooking, stir and add bolognaise sauce to
cooked pasta and garnish with parmesan cheese or
as desired before serving.
Ingredients for carbonara sauce
100g smoked bacon, chopped
1 garlic clove, crushed
½ cup cream
4 egg yolks
100g parmesan cheese
Salt and pepper to taste
Spaghetti
&arbonara
Ingredients for pasta
150g pasta, cooked as package direction
1 tablespoon parmesan cheese
1. Cook bacon in a lightly oiled frying pan with garlic
until lightly browned and drain away excess fat.
2. Add cooked bacon, cream, egg yolks, parmesan
cheese, salt and pepper in a deep and large bowl and
mix well. Cover with plastic wrap and vent.
3. Place food in the oven. Choose the menu and
press start to cook.
4. After cooking, stir and add carbonarasauce to
cooked pasta and garnish with parmesan cheese or
as desired before serving.
Ingredients
1~2 eggplants
Eggplant with
7omato and &heese
1~2 tomatoes
Salt and pepper to taste
100g grated cheese
1. Cut eggplants and tomatoes into 1.5cm slices and
season with salt and pepper.
2. Layer the eggplants and tomatoes on a dish and
add cheese on top of each tomatoes.
3. Place food on the rack. Choose the menu and
press start to cook.
Ic-2
0.4kg Room
Ic-3
1.0kg Room
0LFURZDYHVDIH
ERZO
0LFURZDYHVDIH
ERZO
0LFURZDYHVDIH
GLVK
8WHQVLO
HOW TO USE
2
5
GLOBAL MENU INSTRUCTIONS,7$/,$10(18
Weight
Initial
Code
Menu
Instructions
8WHQVLO
Limit
Temperature
Ic-4
1.5kg Room
Ingredients
Risotto
1. Add all ingredients in a deep and large bowl and
mix well. Cover with plastic wrap and vent.
2. Place food in the oven. Choose the menu and
press start to cook. Stir at least twice during cooking.
4 colored sweet peppers
2 canned tuna
2 piece dry black bread, chopped
1 garlic clove, crushed
100g parmesan cheese
Stuffed 3epper
Salt and pepper to taste
200g tomato puree
1. Cut tops off peppers, remove seeds.
2. Mix tuna, bread, garlic, parmesan cheese, salt
and pepper.
3. Stuff peppers with tuna mixture and place stuffed
peppers on a dish.
4. Add tomato puree on top and cover with plastic
wrap.
5. Place food in the oven. Choose the menu and
press start to cook.
Ingredients
200grisotto rice
1 ½ cups water or stock
½ cup milk
200g beef, chopped
2 eggs
1 onion, chopped
50g green peas
100g grated cheese
Salt and pepper to taste
1.2kg Room
Ic-5
(c-1
Curry &hicken
1.5kg Room
Ingredients
0LFURZDYHVDIH
ERZO
400g chicken breasts, cut into chunks
¼ cup olive oil
2 onions, chopped
4 garlic cloves, crushed
1 ginger root, peeled
1 cinnamon stick
2 dried red chilies
1 teaspoon tumericpowder
400g tomato sauce
½ cup water or stock
½ cup plain yogurt
1 tablespoon lemon juice
Salt and pepper to taste
1. Add all ingredients in a deep and large bowl and
mix well. Cover with plastic wrap and vent.
2.Place food in the oven. Choose the menu and
press start to cook. Stir at least twice during cooking.
0LFURZDYHVDIH
ERZO
0LFURZDYHVDIH
GLVK
HOW TO USE
26
GLOBAL MENU INSTRUCTIONS0,''/(($67(510(18
Weight
Initial
Code
Menu
Instructions
Utensil
Limit
Temperature
GLOBAL MENU INSTRUCTIONS0,''/(($67(510(18
Weight
Initial
Code
Menu
Instructions
Limit
Temperature
E
E
E
c-2
1.0kg Room
Ingredients
Dolma
1. Add cooked rice, ground beef, onion, salt and
pepper in a bowl and mix well.
2. Place grape leaf on a flat surface and place 1 ½
spoonfuls of the rice mixture in the center of the leaf.
Wrap rice mixture with leaf.
3. Put all wrapped leaves in rows into a deep and
large bowl and add water. Cover with plastic wrap.
4. Place food in the oven. Choose the menu and
press start to cook.
5. After cooking, serve with sour cream or as desired.
Ingredients
300g beef, cut into chunks
1 onion, chopped
1 carrot, chopped
3 garlic cloves, crushed
1 teaspoon tumeric
Rice 3ilaf
Salt and pepper to taste
200g long grain rice, rinsed and drained
2 cups water or stock
1. Cook beef, onion, carrot and garlic in a lightly oiled
frying pan until lightly browned. Add tumeric, salt and
pepper, mix well.
2. Place the cooked beef mixture into a deep and
large bowl and add rice and water. Cover with plastic
wrap and vent.
3. Pla
ce food in the oven. Choose the menu and
press start to cook. Stir at least twice during cooking.
Ingredients
4~6 lavash or thin bread
200g chicken breasts, cooked and chopped
1 tomato, chopped
1 cucumber, chopped
3 tablespoons fresh greens, chopped
Shawarma
Sauce :
1 tablespoon mayonnaise
1 tablespoon sour cream
1 tablespoon ketchup
1 garlic clove, crushed
1. Add chicken breasts, tomato, cucumber and
greens in a deep and large bowl and mix well.
2. Mixall ingredients of the sauce in anotherbowl.
3. Place lavashon a flat surface and put sauce and
chicken mixture. Wrap into rolls.
4. Place rolls on a dish and cover with plastic wrap.
5.Place food in the oven. Choose the menu and
press start to cook.
1 pot of grapes leaves
200g cooked rice
500g ground beef
1 onion, chopped
Salt and pepper to taste
½ cup water
½ cup sour cream
1.2kg Room
c-3
c-4
0.8kg Room
0LFURZDYHVDIH
GLVK
0LFURZDYHVDIH
ERZO
0LFURZDYHVDIH
ERZO
8WHQVLO
HOW TO USE
27
SOFTEN TABLE
Butter
Ice Cream
Cream
Cheese
Frozen
Juice
Unwrap and place in microwavable
container. No need to cover butter.
Butter will be at room temperature
and ready for use in recipe.
Place container in oven. Ice cream
will be soft enough to make
scooping easier.
Unwrap and place in microwavable
container. Cream cheese will be at
room temperature and ready for
use in recipe.
Remove top.
Place in oven.
Frozen juice will be soft enough to
easily mix with water.
1, 2 or 3
sticks
Pint, Quart,
Half gallon
85 or 227g
170, 340 or
454g
AmountCategory Direction
Butter
Chocolate
Cheese
Marshmallows
Unwrap and place in
microwavable container. No
need to cover butter. Stir at the
end of cooking to complete
melting.
Chocolate chips or squares of
baking chocolate may be used.
Unwrap squares and place in
microwavable container. Stir at
the end of cycle to complete
melting.
Use processed cheese food
only. Cut into cubes. Place in a
single layer in microwavable
container. Stir at the end of
cooking to complete melting.
Large or miniature
marshmallows may be used.
Place in microwavable
container. Stir at the end of
cycle to complete melting.
1, 2 or 3
sticks
113 or 227g
227 or 454g
142 or 284g
AmountCategory Direction
1. Touch STOP/CLEAR.
1. Touch STOP/CLEAR.
2. Touch
MHOW6RIWHQ
two times.
‘2’ appears in the display.
2. Touch
MHOW6RIWHQ
seven times.
‘7’ appears in the display.
4. Touch
START/Q-START.
4. Touch
START/Q-START.
When the cook time is over,
you will hear four beeps and
END will be displayed.
When the cook time is over,
you will hear four beeps and
END will be displayed.
MELT TABLE
3. Truning the DIAL until
display shows ‘2’
3. Truning the DIAL until
display shows ‘2’
MELT
SOFTEN
The oven uses low power to melt foods (butter,
The oven uses low power to soften foods (butter, ice
chocolate, marshmallows and cheese). See the
cream, cream cheese, and frozen juice)
following table.
See the following table.
Example : To Melt 227g Chocolate.
Example : To Soften 227g Cream Cheese.
HOW TO USE
28
QUICK DEFROST
The Quick Defrost feature provides you with
the express defrosting method for 500g
of frozen minced meat. If more than 500g is
required to be defrosted, this should be done
separately in weights of 500gms for each cycle.
NOTE:
The oven will beep during the DEFROST CYCLE.
At this time open the door and turn over, separate,
or rearrange the food.
Quick Defrost provides just enough defrosting that
the foods can be used in recipes or for cooking.
There will be some ice crystals remaining.
1. Press ECO ON / STOP.
2. Press
QUICK DEFROST.
Menu
Code
Instructions
QUICK DEFROST MENU INSTRUCTIONS
1
Use this function to defrost mince meat.
Remove the meat completely from it’s wrapping.
Place the mince onto a microwave- safe rack over a
plate or shallow dish. During the program the oven
will beep and display ‘turn food over’. At this point
remove the mince from the microwave oven,
remove any defrosted mince to a plate, cover and
set aside. Turn the frozen mince over and return to
the microwave oven. Press start to continue. At the
end of the program remove the mince from the
microwave oven, cover with foil and allow to stand
5- 20 minutes or until completely thawed.
Minced Meat
0.5 kg
Frozen 5 - 20
Initial
Temperature
Standing Time
(minutes)
Weight
Limit
Example: To defrost 0.5 kg meat.
➠
HOW TO USE
29
AUTO DEFROST
Seven defrost sequences are preset in the oven.
The defrost feature provides you with the best
defrosting method for frozen foods. The cooking
guide will show you which defrost sequence is
recommended for the food you are defrosting.
With the Auto Defrost feature, the oven
automatically sets the defrosting time and power
levels for you.
The oven automatically determines required
defrosting times for each food item according to
the weight you enter.
For added convenience, the Auto Defrost
includes a built-in beep mechanism that reminds
you to check, turn over, separate, or rearrange.
Seven different defrosting levels are provided.
1. Minced Meat 4. Roast Beef
2. Steak/Chops 5. Whole Chicken
3. Roast Lamb 6. Chicken Pieces
7. Sliced Bread
NOTE:
When you press the START button, the display
changes to defrost time count down. The oven
will beep twice during the DEFROST cycle. At
each beep, open the door and turn, separate, or
rearrange the food.
Remove any portions that have thawed.
Return frozen portions to the oven and press
START to resume the defrost cycle.
*For best results, remove fish, shellfish, meat,
and poultry from its original wrapping paper or
plastic package. Otherwise, the wrap
will hold steam and juice close to the foods,
which can cause the outer surface of the foods
to cook.
*For best results, shape your ground meat into
the form of a doughnut before freezing. When
defrosting, separate any thawed meat when the
beep sounds and continue defrosting.
*Place foods in a shallow container or on a
microwave roasting rack to catch drippings.
*Food should still be somewhat icy in the center
when removed from the oven.
1. Press ECO ON / STOP.
2. Press
AUTO DEFROST
3. Turning the DIAL until
display shows ‘1.2kg’.
Turning the dial will
change the available
weights in each
AUTO DEFROST
sequence.
4. Press
START.
Defrosting starts.
once. ‘dEF1’ will
show in the display.
Other AUTO DEFROST
sequences can be
selected by pressing the
AUTO DEFROST button
repeatedly.
Example: To defrost 1.2 kg of Minced Meat,
select Meat menu, enter the
weight, and press START
➠ ➠ ➠
HOW TO USE
30
AUTO DEFROST MENU INSTRUCTIONS
Weight
Initial
Standing Time
Code
Menu
Instructions
Limit
Temperature
(minutes)
dEF1
Minced Meat
0.1 - 2.0 kg
Frozen Remove the meat completely from it’s wrapping. 5 - 20
Place the mince onto a microwave- safe rack over a
plate or shallow dish. During the program the oven
will beep and display turn food over. At this point
remove the mince from the microwave, remove any
defrosted mince to a plate, cover and set aside.
Turn the frozen mince over and return to the
microwave oven. Press start to continue. At the end
of the program remove the mince from the
microwave oven, cover with foil and allow to stand
5- 20 minutes or until completely thawed.
AUTO DEFROST MENU INSTRUCTIONS
Weight
Initial
Standing Time
Code
Menu
Instructions
Limit
Temperature
(minutes)
d EF2
Steak / Chops
Roast Lamb
feeB tsaoR
Whole Chicken
Chicken Pieces
Sliced Bread
1 piece = 30g
0.1- 1.5kg
Frozen Remove the meat completely from it’s wrapping. 5 - 30
Using thin strips of foil, shield the fatty areas with the
foil, making sure the foil is secure. Place the meat
onto a microwave- safe rack over a plate or shallow
dish. During the program the oven will beep and
display ‘turn food over’. At this point remove the
meat from the microwave, remove any defrosted
steak or chops to a plate, cover and set aside. Turn
the meat over and return to the microwave oven.
Press start to continue. At the end of the program
remove the meat from the microwave oven, cover
with foil and allow to stand 5- 30 minutes or until
completely thawed.
d EF3
1.0 - 2.0 kg
Frozen
Remove the lamb completely from it’s wrapping.
5 - 45
Using a piece of foil wrap the shank to prevent
cooking. Place the lamb onto a microwave- safe
rack over a plate or shallow dish. During the
program the oven will beep and display ‘turn food
over’. At this point remove the lamb from the
microwave oven and turn over. Press start to
continue. At the end of the program remove the
lamb from the microwave oven, cover with foil and
allow to stand 5 - 45 minutes or until completely
thawed.
d EF4
1.0 - 2.0 kg
Frozen Remove the beef completely from it’s wrapping. 5 - 45
Using strips of foil, shield fatty areas with foil to
prevent cooking. Place the beef onto a microwave-
safe rack, fat side down over a plate or shallow dish.
During the program the oven will beep and display
‘turn food over’. At this point remove the beef from
the microwave oven and turn over. Press start to
continue. At the end of the program remove the
beef from the microwave oven, cover with foil and
allow to stand 5- 45 minutes or until completely
thawed.
HOW TO USE
3
1
d EF5
1.0 - 2.5 kg
Frozen Remove the chicken completely from it’s wrapping. 5 - 40
Place a thin strip of foil down the centre of the
breast. Place the chicken breast side down onto a
microwave- safe rack over a plate or shallow dish.
During the program the oven will beep and display
‘turn food over’. At this point remove the chicken
from the microwave oven and turn over. Press start
to continue. At the end of the program remove the
chicken from the microwave oven, cover with foil
and allow to stand 5- 40 minutes or until completely
thawed.
d EF6
0.1 - 2.0 kg
Frozen Remove the chicken pieces completely from it’s 5 - 10
wrapping. Place the chicken Pieces onto a
microwave- safe rack over a plate or shallow dish.
During the program the oven will beep and display
‘turn food over’. At this point remove the chicken
pieces from the microwave oven and turn over.
Press start to continue. At the end of the program
remove the chicken pieces from the microwave
oven, cover with foil and allow to stand 5- 10
minutes hour or until completely thawed.
d EF7
1- 4 pieces
Frozen Separate the frozen bread into single pieces. Place
1
/
2
- 1
in a single layer directly on the microwave turntable.
At the end of the program remove the bread from
the microwave oven, stand
1
/
2
- 1minute.
FOOD CHARACTERISTICS & MICROWAVE COOKING
Keeping an eye on things
The recipes in the book have been formulated with great care, but your success in preparing them depends on
how much attention you pay to the food as it cooks. Always watch your food while it cooks. Your microwave
function is equipped with a light that turns on automatically when the oven is in operation so that you can see
inside and check the progress of your food. Directions given in recipes to elevate, stir, and the like should be
thought of as the minimum steps recommended. If the food seems to be cooking unevenly, simply make the
necessary adjustments you think appropriate to correct the problem.
Factors affecting microwave cooking times
Many factors aect cooking times. The temperature of ingredients used in a recipe makes a big dierence in
cooking times. For example, a cake made with ice-cold butter, milk, and eggs will take considerably longer to
bake than one made with ingredients that are at room temperature. All of the recipes in this book give a range
of cooking times. In general, you will nd that the food remains under-cooked at the lower end of the time
range, and you may sometimes want to cook your food beyond the maximum time given, according to personal
preference. The governing philosophy of this book is that it is best for a recipe to be conservative in giving cooking
times because overcooked food is ruined for good. Some of the recipes, particularly those for bread, cake, and
custards, recommend that food be removed from the oven when they are slightly undercooked.
This is not a mistake. When allowed to stand, usually covered, these foods will continue to cook outside of the oven
as the heat trapped within the outer portions of the food gradually travels inward. If the food is left in the oven
until it is cooked all the way through, the outer portions will become overcooked or even burnt. You will become
increasingly skillful in estimating both cooking and standing times for various foods.
Density of food
Light, porous food such as cakes and breads cook more quickly than heavy, dense foods such as roasts and casseroles.
You must take care when microwaving porous food so that the outer edges do not become dry and brittle.
Height of food
The upper portion of tall foods, particularly roasts, will cook more quickly than the lower portion.
Therefore, it is wise to turn tall food several during cooking.
Moisture content of food
Since the heat generated from microwaves causes moisture to evaporate, relatively dry food such as roasts and
some vegetables should either be sprinkled with water prior to cooking or covered to retain moisture.
Bone and fat content of food
Bones conduct heat and fat cooks more quickly than meat. Care must be taken when cooking bony or fatty cuts of
meat in order to prevent unevenly or overcooked meat.
Quantity of food
The number of microwaves in your oven remains constant regardless of how much food is being cooked.
Therefore, the more food you place in the oven, the longer the cooking time. Remember to decrease cooking
times by at least one third when halving a recipe.
Shape of food
Microwaves penetrate only about 2 cm into food, the interior portion of thick foods are cooked as the heat
generated on the outside travels inward. Only the outer edge of food is cooked by microwave energy; the rest is
cooked by conduction. The worst possible shape for a food that is to be microwaved is a thick square.
The corners will burn long before the centre is even warm. Round thin foods and ring shaped foods cook most
successfully in the microwave.
Covering
A cover traps heat and steam which causes food to cook more quickly. Use a lid or microwave cling lm with a
corner folded back to prevent splitting.
FOOD CHARACTERISTICS & MICROWAVE COOKING
23
FOOD CHARACTERISTICS & MICROWAVE COOKING
Browning
Meats and poultry that are cooked fteen minutes or longer will brown lightly in their own fat. Foods that are
cooked for a shorter period of time may be brushed with a browning sauce such as worcestershire sauce, soy
sauce or barbecue sauce to achieve an appetizing colour. Since relatively small amounts of browning sauces
are added to food, the original avour of the recipe is not altered.
Covering with greaseproof paper
It is a looser cover than a lid or cling lm, the food may dry out slightly. But because it makes a looser cover
than a lid or clinglm, it allows the food to dry out slightly.
Arranging and spacing
Individual foods such as baked potatoes, small cakes and hors d’oeuvres will heat more evenly if placed in the
oven an equal distance apart, preferably in a circular pattern. Never stack foods on top of one another.
Stirring
Stirring is one of the most important of all microwaving techniques. In conventional cooking, food is stirred
for the purpose of blending. Microwaved food, however, is stirred in order to spread and redistribute heat.
Always stir from the outside towards the centre as the outside of the food heats rst.
Turning over
Large, tall foods such as roasts and whole chickens should be turned so that the top and bottom will cook
evenly. It is also a good idea to turn cut up chicken and chops.
Placing thicker portions facing outwards
Since microwaves are attracted to the outside portion of food, it makes sense to place thicker portions of
meat, poultry and sh to the outer edge of the baking dish. This way, thicker portions will receive the most
microwave energy and the food will cook evenly.
Shielding
Strips of aluminium foil (which block microwaves) can be placed over the corners or edges of square and
rectangular foods to prevent those portions from overcooking. Never use too much foil and make sure the foil
is secured to the dish or it may cause‘arcing’ in the oven.
Elevating
Thick or dense foods can be elevated so that microwaves can be absorbed by the underside and centre of the
foods.
Piercing
Foods enclosed in a shell, skin or membrane are likely to burst in the oven unless they are pierced prior to
cooking. Such foods include yolks and whites of eggs, clams and oysters and whole vegetables and fruits.
Testing if cooked
Food cooks so quickly in a oven, it is necessary to test it frequently. Some foods are left in the microwave
until completely cooked, but most foods, including meats and poultry, are removed from the oven while still
slightly undercooked and allowed to nish cooking during standing time. The internal temperature of foods
will rise between 5° F (3° C) and 15° F (8° C) during standing time.
Standing time
Foods are often allowed to stand for 3 to 10 minutes after being removed from the oven. Usually the foods
are covered during standing time to retain heat unless they are supposed to be dry in texture (some cakes
and biscuits, for example). Standing allows foods to nish cooking and also helps avour blend and develop.
FOOD CHARACTERISTICS & MICROWAVE COOKING
33
FOOD CHARACTERISTICS & MICROWAVE COOKING / QUESTIONS & ANSWERS
1 Keep the inside of the oven clean
Food spatters or spilled liquids stick to oven walls and between the seal and door surfaces. It is best to wipe
up spillovers with a damp cloth right away. Crumbs and spillovers will absorb microwave energy and lengthen
cooking times. Use a damp cloth to wipe out crumbs that fall between the door and the frame. It is important to
keep this area clean to assure a tight seal. Remove greasy spatters with a soapy cloth then rinse and dry.
Do not use harsh detergent or abrasive cleaners. The metal tray can be washed by hand or in the dishwasher.
2 Keep the outside of the oven clean
Clean the outside of your oven with soap and water then with clean water and dry with a soft cloth or paper
towel. To prevent damage to the operating parts inside the oven, the water should not be allowed to seep into
the ventilation openings. To clean control panel, open the door to prevent the oven from accidentally starting, and
wipe a damp cloth followed immediately by a dry cloth. Press Stop/Clear after cleaning.
3
If steam accumulates inside or around the outside of the oven door, wipe the panels with a soft cloth. This may occur
when the oven is operated under high humidity conditions and in no way indicates a malfunction of the unit.
4
The door and door seals should be kept clean. Use only warm, soapy water, rinse then dry thoroughly.
DO NOT USE ABRASIVE MATERIALS, SUCH AS CLEANING POWDERS OR STEEL AND PLASTIC PADS.
Metal parts will be easier to maintain if wiped frequently with a damp cloth.
5
Do not use steam cleaners.
6
Unplug your oven from the electrical socket when you clean control panel with wet cloth or spray water on control
glass to clean. If it is not unplugged, this product can be operated by touching the Quick Start button.
To Clean Your Oven
FAQ
Answer
What’s wrong when the oven light will not glow?
There may be several reasons why the oven light will not glow.
Either the light bulb has blown or the electric circuit has failed.
Does microwave energy pass through the
viewing screen in the door?
No. The holes, or ports, are made to allow light to pass; they do not
let microwave energy through.
Why does the BEEP tone sound when a button
on the control panel is touched?
The BEEP tone sounds to assure that the setting is being properly
entered.
Will the microwave function be damaged if it
operates empty?
Yes. Never run it empty.
Why do eggs sometimes pop? When baking, frying, or poaching eggs, the yolk may pop due to
steam build up inside the yolk membrane. To prevent this, simply
pierce the yolk before cooking. Never microwave eggs in the shell.
Why is standing time recommended after
microwave cooking is over?
After microwave cooking is nished, food keeps on cooking
during standing time. This standing time nishes cooking evenly
throughout the food. The amount of standing time depends on the
density of the food.
Why doesn’t my oven always cook as fast as the
cooking guide says?
Check your cooking guide again to make sure you’ve followed
directions correctly, and to see what might cause variations
in cooking time. Cooking guide times and heat settings are
suggestions, chosen to help prevent overcooking, the most
common problem in getting used to this oven. Variations in the
size, shape, weight and dimensions of the food require longer
cooking time. Use your own judgment along with the cooking
guide suggestions to test food conditions, just as you would do
with a conventional cooker.
QUESTIONS & ANSWERS
34
TECHNICAL SPECIFICATIONS
35
TECHNICAL SPECIFICATIONS
Power Input 230 V ~ 240V/50 Hz
Microwave Output Power.
1100 Watt (IEC60705 rating standard)
Microwave Frequency
2450 MHz
Oven Cavity Dimension
398 mm(W) X 265 mm(H) X 402 mm(D)
Outside Dimension 556 mm(W) X 320 mm(H) X 440 mm(D)
MS408
Net Weight
***
17.1 Kg
Shipping Weight 19.8 Kg
Power Consumption
Microwave
1600 watt
MS408
***
Printed in China
LGEAP
