JURA Type 739
X8 Instructions for Use
K
For your safety: read and understand manual before use.
E
2
Table of contents
Your X8
IMPORTANT SAFEGUARDS 4
Control elements 8
1 Preparing and using for the first time 10
JURA on the Internet ....................................................................................................................................10
Setting up the machine ..............................................................................................................................10
Filling the bean container ...........................................................................................................................10
Determining the water hardness ..............................................................................................................10
First-time use .................................................................................................................................................11
Connecting milk ...........................................................................................................................................14
Connecting an accessory (via Bluetooth) ................................................................................................14
2 Preparation 15
Espresso, coffee and other specialty coffees ...........................................................................................16
Latte macchiato, cappuccino and other specialty coffees with milk ..................................................16
Preparing two specialty coffees .................................................................................................................17
Permanently setting the amount of water for the cup size .................................................................17
Adjusting the grinder ..................................................................................................................................18
Hot water .......................................................................................................................................................19
3 Daily operation 20
Filling the water tank ..................................................................................................................................20
Switching on the machine .........................................................................................................................20
Daily maintenance ......................................................................................................................................20
Regular maintenance ..................................................................................................................................21
Switching off the machine ..........................................................................................................................21
4 Permanent settings in programming mode 22
Adjusting the product settings .................................................................................................................23
Positioning products on the start screen ...............................................................................................25
Enable or disable one-off settings ...........................................................................................................26
Enable or disable setting of cup volume ................................................................................................26
Enable and disable products .....................................................................................................................27
Automatic switch-off ..................................................................................................................................27
Setting the water hardness .......................................................................................................................28
Milk system rinsing .....................................................................................................................................28
Unit for amount of water ...........................................................................................................................29
Language ......................................................................................................................................................29
Query counter readings and version .......................................................................................................30
5 Maintenance 31
Rinsing the machine ................................................................................................................................... 32
Rinsing the milk system ............................................................................................................................. 32
Cleaning the milk system ..........................................................................................................................33
Dismantling and rinsing the dual spout .................................................................................................34
Inserting the filter .......................................................................................................................................36
Changing the filter ......................................................................................................................................36
3
Table of contents
Cleaning the machine ................................................................................................................................37
Descaling the machine ..............................................................................................................................38
Cleaning the bean container ......................................................................................................................41
Descaling the water tank ............................................................................................................................41
6 Display messages 42
7 Troubleshooting 43
8 Transport and environmentally friendly disposal 44
Transport/ Emptying the system .............................................................................................................44
Disposal .........................................................................................................................................................44
9 Technical data 45
10 Index 46
11 JURA contact details/ Legal information 48
Symbol description
Warnings
This is the safety alert symbol. lt is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury
or death.
DANGER indicates a hazardous situation which, if not avoided, will result in death
or serious injury.
WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
J CAUTION
CAUTION, used with the safety alert symbol, indicates a hazardous situation
which, if not avoided, could result in minor or moderate injury.
NOTICE NOTICE is used to address practices not related to personal injury.
Symbols used
T
Prompt to take action. This symbol means that you are being prompted to
perform some action.
E
Information and tips to make it even easier to use your JURA.
‘Coffee’ Display message
J
J DANGER
J WARNING
4
IMPORTANT SAFEGUARDS
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS.
Pass them on to any subsequent user.
When using electrical appliances, basic safety precautions shall
always be followed, to reduce the risk of fire, electric shock, and/or
injury to persons, including the following:
Z Read all instructions.
Z Do not touch hot surfaces. Use handles or knobs.
Z To protect against fire, electric shock and injury to persons, do
not immerse power cord, plugs, or body of machine in water
or other liquid.
Z Close supervision is necessary when any appliance is used by
or near children.
Z Unplug from outlet when not in use and before cleaning.
Allow to cool before putting on or taking off parts, and before
cleaning the appliance.
Z Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions, or has been damaged in any
manner. Return appliance to the nearest authorized service
facility for examination, repair or adjustment.
Z The use of an accessory attachment not recommended by the
appliance manufacturer may result in fire, electric shock, or
injury to persons.
Z Do not use outdoors.
Z Do not let the cord hang over the edge of a table or counter,
or touch hot surfaces.
Z Do not place on or near a hot gas or electric burner, or in a
heated oven.
Z To disconnect, turn any control to ‘OFF’ then remove plug
from wall outlet.
Z Do not use appliance for other than intended use.
Z Use extreme caution when dispensing hot steam, hot water
or hot coffee.
Follow the basic safety
precautions
5
IMPORTANT SAFEGUARDS
The appliance is designed and intended for domestic and office use
only. It shall only be used for coffee preparation and to heat milk and
water, according to these instructions. Use for any other purpose will
be deemed improper. JURA Elektroapparate AG cannot accept any
responsibility for the consequences of improper use.
People, including children, who
Z do not have the physical, sensory or mental capabilities to use
the appliance safely or
Z are inexperienced or lack knowledge in how to use the
appliance safely
must be supervised by a responsible person when using it, or must
be instructed in how to use it correctly.
Z A short power-supply cord is to be provided to reduce risks
resulting from becoming entangled in or tripping over a
longer cord.
Z The cord shall be arranged so that it will not drape over the
counter top or table top where it can be pulled on by children
or tripped over.
Z This appliance has a 3-pin grounded plug.
Z Do not modify the plug in any way.
Extension cords are available an may be used if care is exercised in
their use.
If the user chooses to use an extension cord,
Z the marked electrical rating of the extension cord should be
at least as great as the electrical rating of the appliance, and
Z if the appliance is of the grounded type, the extension cord
should be a grounding type 3-wire cord, and
Z the longer cord should be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on by
children or tripped over.
To reduce the risk of fire or electric shock, DO NOT remove any
service covers. DO NOT modify the appliance in any way that is not
described in these instructions. NO user serviceable parts included.
Repair MUST be done by authorized personnel only.
In the event of signs of damage, for example if there is a smell of
burning, unplug the machine immediately from outlet and contact
JURA customer service.
Intended use
Special power cord set
instructions
J WARNING
6
IMPORTANT SAFEGUARDS
Any servicing other than cleaning and user maintenance shall be
performed by an authorized service representative:
Z Do not immerse base in water or try to disassemble.
Z Do not put the appliance or any individual parts in the
dishwasher.
Z Check voltage to be sure that the voltage indicated on the
name plate complies with your voltage. The name plate is
located on the underside of the appliance.
Z Never use warm or hot water to fill the water container. Use
cold water only.
Z Keep your hands and the cord away from hot parts of the
appliance during operation.
There is a risk of scalds or burns on the spouts and the cappuccino
frother / nozzle.
Z Keep children away.
Z Do not touch any hot parts. Use the handles or knobs
provided.
Z Ensure that the cappuccino frother / nozzle is correctly fitted
and clean. If incorrectly fitted or if they become blocked, the
cappuccino frother or its parts might come off.
Z Never clean with scouring powders or hard implements.
Z Ensure that the ventilation slots are not covered.
Z Never pull out the drip tray during the brewing process. Only
pull the drip tray when the display instructs you or when the
appliance is ready for use.
J CAUTION
NOTICE
7
IMPORTANT SAFEGUARDS
Z Never fill instant coffee, chocolate mix etc. into the bean
container or ground coffee funnel (filler funnel for ground
coffee). It will damage the functioning of the brewing
chamber.
Z Never fill sugar coated coffee beans into the bean container.
In case of doubt, call your dealer.
Z Never fill anything other than coffee beans into the bean
container (no chocolate, no rice, no nuts, no spices, nothing
other than roasted coffee beans).
Z Never fill frozen beans into the bean container. If you store
beans in the freezer, let them thaw 3 to 4 hours before filling
them into the bean container.
Z Never fill anything but fresh, cold and clean water into the
water tank, except when decalcifying.
Z Never use mineral or carbonated water. You can use tap water,
bottled water, spring water and reverse osmosis water.
Z Never do anything with the machine which is not described in
these instructions. In case of doubt, call your dealer.
NEVER DO
(or you will void your
warranty protection):
8
Control elements
Control elements
11
10
4
5
6
8
14
13
12
9
1
2
3
7
J HOT
J HOT
1 Cover
2 Filler funnel for cleaning tablet
3 Bean container with aroma preservation cover
(lockable)
4 Water tank cover (lockable)
5 Water tank
6 Hot-water spout
7 Power cord (back of the machine)
8 Coffee grounds container
9 On/Off button Q
10 Grinder adjustment wheel
11 Height-adjustable dual spout
12 Insert for drip tray
13 Cup platform
14 Drip tray
9
Control elements
1
2
1 Display 2 Multi-function buttons (button function
depends on what is shown in the display)
Back of the machine: Service socket for JURA Smart Connect (behind cover)
Accessories
Spanner for aroma preservation cover,
water tank cover and grinder adjustment wheel
Container for milk system cleaning
10
1 Preparing and using for the first time
1 Preparing and using for the first time
Visit us on the Internet (www.jura.com). You will find interesting and
up-to-date information on your X8 and on every aspect of coffee.
When setting up your X8, please note the following:
U
Place the X8 on a horizontal surface that is not sensitive to
water.
U
Choose a spot for your X8 which protects the machine against
overheating. Ensure that the ventilation slots are not covered.
The aroma preservation cover of the bean container is lockable
(spanner supplied as standard).
Coffee beans which have been treated with additives (e.g. sugar),
ground coffee or freeze-dried coffee will damage the grinder.
T Only use roasted, untreated coffee beans to fill the bean
container.
T Remove the aroma preservation cover.
T Remove any dirt or foreign objects from inside the bean
container.
T Fill the bean container with coffee beans and close the
aroma preservation cover.
When you use the machine for the first time, you must set the water
hardness. If you do not know the hardness of your water, you can
find this out first. Use the Aquadur® test strips supplied with the
machine.
T Hold the test strip briefly (for 1second) under flowing water.
Shake off the water.
T Wait for about 1minute.
JURA on the Internet
Setting up the machine
Filling the bean container
NOTICE
Determining the water
hardness
11
1 Preparing and using for the first time
T You will then be able to read the degree of water hardness
from the discoloration of the Aquadur® test strip and the
description on the packaging.
Level Display German
Degree (°dH)
Degrees of general
hardness (°dGH)
Parts per
million (ppm)
Indicator Strip number
of ‘reddish’ fields
Not active – – – –
Very soft water <3 <3 < 53.4 None
Soft water > 4 > 4 > 71 1
Hard water > 8.4 > 8.4 > 150 2
Very hard water > 14 > 14 > 250 3
When using the machine for the first time, you can choose whether
you want to operate X8 with or without the CLEARYL Pro Smart
filter cartridge. As well as limescale, the filter cartridge filters many
other substances that impair aroma and flavor out of the water.
These substances may negatively affect the coffee. To enjoy the best
quality coffee at all times, we recommend that you use CLEARYL Pro
Smart.
If the machine is operated with a defective power cord, there is a
danger of potentially fatal electric shock.
T Never use a machine which is damaged.
T Never use a machine which has a defective power cord.
E The water volume is given as standard in ‘oz’. You can change
this setting to ‘ml’ in programming mode (see Chapter 4
‘Permanent settings in programming mode – Unit for amount
of water’).
Precondition:The bean container has been filled.
T Insert the mains plug into a power socket.
T Press the On/Off button Q to switch the X8 on.
‘Choose language’
E To display more languages, press the ‘ T’ button (bottom
right).
First-time use
J WARNING
12
1 Preparing and using for the first time
T Press the button that corresponds to the language you want,
e.g.
‘English’.
‘Saved’ appears briefly on the display to confirm the setting.
‘Water hardness’
E If you do not know the hardness of your water, you must find
this out first (see Chapter 1 ‘Preparing and using for the first
time – Determining the water hardness’).
T Press the
‘<’ or ‘>’ button to change the water hardness
setting, for example to
‘25°dH’.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Filter operation’
E Now decide whether you want to operate your X8 with or
without a CLEARYL Pro Smart filter cartridge.
Operation with filter cartridge: go straight to the next section.
Operation without filter cartridge: see Chapter 1 ‘Preparing and
using for the first time – First-time use without filter cartridge
activation’.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Remove the water tank and rinse it with cold water.
T Open the filter holder.
T Insert the filter cartridge into the water tank, exerting slight
pressure.
T Close the filter holder. It will click into place audibly.
First-time use with filter
cartridge activation
NOTICE
13
1 Preparing and using for the first time
T Fill the water tank with fresh, cold water and reinsert the
tank.
E The machine automatically detects that you have just inserted
the filter cartridge.
‘Change the filter’ / ‘Saved’
‘Filter is being rinsed’
, Water flows directly into the drip tray.
Rinsing of the filter stops automatically.
‘System is filling’, the system fills up with water.
‘Empty drip tray’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Machine is rinsing’, the system is rinsed.
The rinse stops automatically. Your X8 is ready for use.
E The start screen shows the products you can prepare. Press
the
‘T’ button to display more products.
E If the filter is active, this is indicated by a blue filter symbol at
the bottom of the display.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Press the
‘No filter’ button.
‘Saved’ appears briefly on the display.
‘Fill water tank’
T Remove the water tank and rinse it with cold water.
T Fill the water tank with fresh, cold water and reinsert the
tank.
‘System is filling’, the system fills up with water.
‘Machine is heating’
‘Machine is rinsing’
, the system is rinsed.
The rinse stops automatically. Your X8 is ready for use.
E The start screen shows the products you can prepare. Press
the
‘T’ button to display more products.
First-time use without filter
cartridge activation
NOTICE
14
1 Preparing and using for the first time
Your X8 creates fine, creamy, feather-light milk foam with a perfect
consistency. The most important requirement for frothing milk is
a milk temperature of 39–46 °F (4–8 °C). We would therefore
recommend using a milk cooler or a milk container.
T Connect the milk pipe to the dual spout.
T Connect the other end of the milk pipe to a milk container
or a milk cooler.
Your X8 is equipped with the JURA Smart Connect. This allows you
to connect the machine to a compatible accessory (e.g. the JURA
Cool Control Wireless milk cooler) via Bluetooth.
Precondition:The start screen is displayed.
T Press the
‘Pc’ button.
‘1/5’
T Press the ‘T’ button several times until ‘5/5’ is displayed.
T Press the
‘Connect accessory’ button.
‘Connect accessory’
T Now follow the instructions on the display to connect the
accessory to the X8.
Connecting milk
Connecting an accessory
(via Bluetooth)
15
2 Preparation
2 Preparation
Hot coffee, hot steam and hot water can cause scalding. Scalding is
a serious burn.
T Use extreme care when handling hot liquid or steam.
T Allow liquid to cool down before drinking.
T In the event of scalding, rinse affected area with cold water
and seek medical attention.
T Keep children AWAY.
Basic information about preparing drinks:
U
The display shows the products you can prepare. Press the ‘T’
button to display more products.
U
During the grinding operation you can select the
coffee strength of single products by pressing the
‘<’ and
‘>’ buttons.
U
During preparation you can change the preset amounts (e.g.
water and amount of milk foam) by pressing the
‘<’ and ‘>’
buttons.
U
The water volume is given as standard in ‘oz’. You can change
this setting to ‘ml’ in programming mode (see Chapter 4
‘Permanent settings in programming mode – Unit for amount
of water’).
U
You can stop the machine at any time while a specialty coffee
or hot water is being prepared. To do this, press the
‘Cancel’
button.
Coffee tastes best served hot. A cold porcelain cup cools the
beverage – and impairs the taste. We therefore recommend
pre-warming the cups. The full coffee aroma can develop only in
pre-warmed cups. You can purchase a JURA cup warmer from
your specialized dealer.
You can make permanent settings for all products in programming
mode (see Chapter 4 ‘Permanent settings in programming mode –
Adjusting the product settings’).
J WARNING
16
2 Preparation
Ristretto, espresso, coffee and special coffee are all prepared
following this model.
For a pot of coffee, you can choose the number of brewing
operations (1–5 strokes) in programming mode.
Example:Proceed as follows to prepare one coffee.
Precondition:The start screen is displayed.
T Place a cup under the dual spout.
T Press the
‘Coffee’ button.
Preparation starts.
‘Coffee’ and the coffee strength are
displayed. The preset amount of water for coffee flows into
the cup.
Preparation stops automatically. Your X8 is once more ready
for use.
Your X8 prepares latte macchiato, cappuccino and other specialty
coffees with milk at the touch of a button. There is no need to move
the glass or cup.
Example:Proceed as follows to prepare one latte macchiato.
Precondition:Milk is connected to the dual spout.
T Place a glass under the dual spout.
T Press the
‘Latte macchiato’ button.
‘Latte macchiato’, the preset amounts of milk and milk foam
flow into the glass.
E There is a short interval while the hot milk separates from the
milk foam. This allows the typical layers of a latte macchiato
to form.
Coffee preparation starts. The preset amount of water for
espresso flows into the glass. Preparation stops
automatically. Your X8 is once more ready for use.
To ensure that the milk system in the dual spout always works
properly, you must clean it daily (see Chapter 5 ‘Maintenance –
Cleaning the milk system’).
Espresso, coffee and
other specialty coffees
Latte macchiato,
cappuccino and other
specialty coffees with
m i l k
17
2 Preparation
To prepare two specialty coffees / specialty coffees with milk, press
the appropriate preparation button twice (within approximately
2 seconds).
Example:Proceed as follows to prepare two espressi.
Precondition:The start screen is displayed.
T Place two cups under the coffee spout.
T Press the
‘Espresso’ button twice (within 2 seconds) to start
preparation.
‘2x Espresso’, the preset amount of water flows into the
cups.
Preparation stops automatically. Your X8 is once more ready
for use.
It is easy to permanently adjust the amount of water for all single
products to the cup size. Adjust the amount once as shown in the
following example. Every time you prepare a drink in the future, this
amount will be dispensed.
Example: Proceed as follows to permanently set the amount of
water for one coffee.
T Place a cup under the dual spout.
T Press and hold the
‘Coffee’ button until ‘Enough coffee?
Press button’
appears.
T Release the
‘Coffee’ button.
Preparation starts and the coffee flows into the cup.
T Press any button except
‘Cancel’ as soon as there is sufficient
coffee in the cup.
Preparation stops.
‘Saved’ appears briefly on the display. The
set amount of water for one coffee is permanently stored.
Your X8 is once more ready for use.
E You can alter this setting at any time by repeating the above
procedure.
E You can also permanently set the amounts for all single
products in programming mode (see Chapter 4 ‘Permanent
settings in programming mode – Adjusting the product
settings’).
Preparing two specialty
coffees
Permanently setting the
amount of water for the
cup size
18
2 Preparation
You can adjust the grinder to suit the degree of roast of your coffee.
If you adjust the consistency of grind when the grinder is not
operating, the grinder adjustment wheel could be damaged.
T Only adjust the consistency of grind when the grinder is
running.
The consistency of grind is correct if the coffee flows regularly from
the coffee spout. In addition a fine, thick crema forms.
You can set the consistency of grind using the spanner provided.
Example: Proceed as follows to change the consistency of grind
during the preparation of an espresso.
T Place a cup under the dual spout.
T Open the cover behind the bean container.
T Press the
‘Espresso’ button to start preparation.
T Turn the grinder adjustment wheel to the desired position
while the grinder is running.
The preset amount of water flows into the cup. Preparation
stops automatically.
T Close the cover.
Adjusting the grinder
NOTICE
19
2 Preparation
Your X8 allows you to prepare different variants of hot water:
U
‘Hot water’
U
‘Hot water for green tea’
There is a danger of scalding from hot water splashes.
T Avoid direct contact with the skin.
Example:Proceed as follows to prepare hot water for green tea.
Precondition:The start screen is displayed.
T Place a cup under the hot-water spout.
E
‘Hot water for green tea’ can be found on page 2 of the start
screen.
T Press the
‘Hot water for green tea’ button.
‘Hot water for green tea’, the preset amount of water flows
into the cup.
Preparation stops automatically. Your X8 is once more ready
for use.
Hot water
J
CAUTION
20
3 Daily operation
3 Daily operation
Daily maintenance of the machine and hygiene when handling
coffee and water are key to a perfect coffee result in the cup every
time. You should therefore change the water daily.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
You can lock the water tank cover with the spanner provided.
T Open the water tank cover.
T Remove the water tank and rinse it with cold water.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Close the water tank cover.
T Press the On/Off button Q to switch the X8 on.
‘Welcome to JURA’
‘Machine is heating’
‘Machine is rinsing’
, the system is rinsed. The rinse stops
automatically. The start screen is displayed. Your X8 is ready
for use.
To ensure that you get many years of reliable service out of your X8
and to guarantee the optimum coffee quality, the machine requires
daily maintenance.
T Pull out the drip tray.
T Empty the coffee grounds container and the drip tray. Rinse
them both with warm water.
E Always empty the coffee grounds container when the machine
is switched on. This is the only way of resetting the coffee
grounds counter.
T Rinse the insert for the drip tray with warm water.
T Refit the coffee grounds container and the drip tray.
T Rinse the water tank with clean water.
Filling the water tank
NOTICE
Switching on the
machine
Daily maintenance
21
3 Daily operation
T Clean the milk system in the dual spout (see Chapter 5
‘Maintenance – Cleaning the milk system’).
T Remove the milk pipe and rinse it thoroughly under running
water.
T Dismantle and rinse the dual spout (see Chapter 5
‘Maintenance – Dismantling and rinsing the dual spout’).
T Wipe the surface of the machine with a clean, soft, damp
cloth (e.g. microfiber cloth).
You will find more information about caring for your X8 in
programming mode under
‘2/5’ / ‘Information’ (‘Maintenance
information’
).
Carry out the following maintenance actions regularly or as
required:
U
In the interests of hygiene, we recommend changing the milk
pipe and interchangeable milk spout on a regular basis
(approximately every 3 months). Replacements are available
from specialized dealers.
U
Clean the inside of the water tank, e.g. with a brush. Further
information about the water tank is provided in these
instructions for use (see Chapter 5 ‘Maintenance – Descaling
the water tank’).
U
Traces of milk and coffee may stick to the top and bottom of
the cup platform. If this happens, clean the cup platform.
When the X8 is switched off, the system is automatically rinsed if a
specialty coffee has been prepared. If milk has been prepared, you
will also be prompted to clean the milk system.
T Press the On/Off button Q.
E If milk has been prepared, you will be prompted to clean the
milk system (
‘Clean the milk system’ / ‘Do you want to clean
the milk system now?’
). After 10 seconds the switch-off
process continues automatically.
If milk has been prepared but you have not started milk
system cleaning, the milk system is rinsed first (
‘Milk system
is being rinsed’
).
‘Machine is rinsing’, the system rinses itself. The operation
stops automatically. Your X8 is switched off.
Regular maintenance
Switching off the
machine
22
4 Permanent settings in programming mode
4 Permanent settings in programming mode
Hot coffee, hot steam and hot water can cause scalding. Scalding is
a serious burn.
T Use extreme care when handling hot liquid or steam.
T Allow liquid to cool down before drinking.
T In the event of scalding, rinse affected area with cold water an
seek medical attention.
T Keep children AWAY.
Press the
‘ Pc’ button to enter programming mode. You can
navigate through the program items and permanently save the
required settings using the multi-function buttons. The following
settings can be made:
Program
item
Sub-item Explanation
‘1/5’ ‘Clean’,
‘Descale’,
‘Clean the milk system’,
‘Filter’ (only if filter is fitted)
T Here you can start the required maintenance
program or find out what maintenance actions
are required.
‘2/5’ ‘Rinse the milk system’,
‘Rinse the coffee system’,
‘Information’
‘3/5’ ‘Expert mode’
T Select your settings for specialty coffees and hot
water.
‘Customise cup fill volume’
T Disable the function ‘Permanently setting the
amount of water for the cup size’.
‘One-off settings’
T Specify whether or not to allow one-off settings
during preparation.
‘Lock/enable’
T Enable or disable individual products.
‘4/5’ ‘Choose language’
T Select your language.
‘Units’
T Select the unit for the amount of water.
‘Rinse the milk system’
T Change the setting for the milk system rinsing.
‘Switch off after’
T Set the time after which the X8 should switch
off automatically.
‘Water hardness’
T Adjust the water hardness.
J WARNING
23
4 Permanent settings in programming mode
Program
item
Sub-item Explanation
‘5/5’ ‘Product counter’,
‘Day counter’,
‘Maintenance counter’,
‘Version’
T Keep track of all products prepared and view the
number of maintenance programs performed.
‘Connect accessory’,
‘Disconnect accessories’ (Only
displayed if the JURA Smart
Connect is being used.)
T Connect the X8 to a compatible accessory via
Bluetooth or disconnect the connection again.
Hot coffee, hot steam and hot water can cause scalding. Scalding is
a serious burn.
T Use extreme care when handling hot liquid or steam.
T Allow liquid to cool down before drinking.
T In the event of scalding, rinse affected area with cold water an
seek medical attention.
T Keep children AWAY.
In the program item
‘3/5’ / ‘Expert mode’ you can make individual
settings for all specialty coffees and hot water. The following
permanent settings can be made:
Product Coffee
strength
Amount More settings
‘Ristretto’,
‘Espresso’
10 levels Water: 0.5 oz – 2.5 oz
(15ml–80ml)
Temperature (normal, high),
position
‘Coffee’,
‘Special’
10 levels Water: 0.5oz–8.0oz
(25 ml – 240 ml)
Temperature (normal, high),
position
‘Cappuccino’,
‘Caffè latte’,
‘Flat White’
10 levels Water: 0.5oz–8.0oz
(25 ml – 240 ml)
Milk foam: 0sec.–120sec.
Milk: 0sec.–120sec.
Milk and milk foam temperature,
Temperature (normal, high),
position
Adjusting the product
settings
J WARNING
24
4 Permanent settings in programming mode
Product Coffee
strength
Amount More settings
‘Latte macchiato’ 10 levels Water: 0.5oz–8.0oz
(25 ml – 240 ml)
Milk foam: 0sec.–120sec.
Milk: 0sec.–120sec.
Interval: 0sec.–60sec.
Milk and milk foam temperature,
Temperature (normal, high),
position
‘1 portion milk’ – Milk foam: 0sec.–120sec.
Milk: 0sec.–120sec.
Milk and milk foam temperature,
position
‘Jug of coffee’ 10 levels Water: 25ml–240ml
Number of strokes (1–5; set
number is displayed during
preparation)
Temperature (normal, high),
position
‘Hot water’,
‘Hot water for
green tea’
– Water: 0.5oz–15.0oz
(25 ml – 450 ml)
Temperature (low, normal, high),
position
E When preparing double products, the amounts set for the
single product are doubled. The temperature of the single
product remains unchanged.
Permanent settings in programming mode always follow the same
model.
Example:Proceed as follows to change the coffee strength for one
coffee.
T Press the
‘Pc’ button.
T Press the
‘T’ button several times until ‘3/5’ is displayed.
T Press the
‘Expert mode’ button.
‘Expert mode’
E Next select the button of the product for which you would like
to make settings. No product is prepared at this point.
E To display more products, press the
‘T’ button (bottom right).
T Press the
‘Coffee’ button.
‘Coffee’
T Press the ‘Coffee strength’ button.
‘Coffee’ and the coffee strength is displayed.
25
4 Permanent settings in programming mode
T Press the ‘<’ or ‘>’ button to change the setting for the cof-
fee strength.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Coffee’
T Press the ‘’ button for around 2 seconds to exit
programming mode.
You can reposition the products on the start screen.
Example:Proceed as follows to replace
‘Flat White’ on the first page
of the start screen with
‘Ristretto’.
T Press the
‘Pc’ button.
T Press the
‘T’ button several times until ‘3/5’ is displayed.
T Press the
‘Expert mode’ button.
‘Expert mode’
E Next select the button of the product you want to move. No
product is prepared at this point.
E To display more products, press the
‘T’ button (bottom right).
T Press the
‘Ristretto’ button.
‘Ristretto’
T Press the ‘Position’ button.
‘Select position’
T Press the ‘Flat White’ button.
‘Replace product?’
T Press the ‘Yes’ button.
‘Saved’ appears briefly on the display.
‘Ristretto’
T Press the ‘’ button for around 2 seconds to exit
programming mode.
Positioning products on
the start screen
26
4 Permanent settings in programming mode
In the program item ‘3/5’ / ‘One-off settings’ you can make the
following setting:
U
‘Active’: One-off settings can be made during preparation (e.g.
coffee strength or amount of water).
U
‘Inactive’: One-off settings cannot be made during
preparation. The product is prepared according to the
settings in programming mode (
‘3/5’ / ‘Expert mode’).
Example: Proceed as follows to disable one-off settings during
preparation.
T Press the
‘Pc’ button.
T Press the
‘T’ button several times until ‘3/5’ is displayed.
T Press the
‘One-off settings’ button.
‘One-off settings’
T Press the ‘Inactive’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘3/5’
T Press the ‘’ button to exit programming mode.
In the program item
‘3/5’ / ‘Customise cup fill volume’ you can make
the following setting:
U
‘Active’: The function ‘Permanently setting the amount of
water for the cup size’ is activated. You can adjust the amount
of water to the cup size by pressing and holding the relevant
preparation button.
U
‘Inactive’: The function ‘Permanently setting the amount of
water for the cup size’ is deactivated. The amount of water
cannot be adjusted to the cup size by pressing and holding
the relevant preparation button.
Example:Proceed as follows to disable the function ‘Permanently
setting the amount of water for the cup size’.
T Press the
‘Pc’ button.
T Press the
‘T’ button several times until ‘3/5’ is displayed.
T Press the
‘Customise cup fill volume’ button.
‘Customise cup fill volume’
T Press the ‘Inactive’ button.
Enable or disable one-off
settings
Enable or disable setting
of cup volume
27
4 Permanent settings in programming mode
T Press the ‘Save’ button.
‘Saved’ appears briefly on the display.
‘3/5’
T Press the ‘’ button to exit programming mode.
In the program item
‘3/5’ / ‘Lock/enable’ you can enable or disable
each product individually.
Example:Proceed as follows to disable the preparation of
‘Jug of
coffee’
.
T Press the
‘Pc’ button.
T Press the
‘T’ button several times until ‘3/5’ is displayed.
T Press the
‘Lock/enable’ button.
‘Lock/enable’
E The lock symbol beside the product name indicates whether
the product is enabled or disabled. If the lock is closed, the
product is disabled.
T Press the
‘ > ’ button until the product ‘Jug of coffee’ is
displayed.
T Press the
‘Jug of coffee’ button.
The lock is closed. Preparation of
‘Jug of coffee’ is now
disabled.
T Press the
‘’ button for around 2 seconds to exit
programming mode.
By instructing your X8 to automatically switch itself off, you can cut
down your energy consumption. If this function is activated, your X8
switches off automatically after the preset time following the last
action on the machine.
You can set the automatic switch-off to 15minutes, 30minutes or
1–9hours.
T Press the
‘Pc’ button.
T Press the
‘T’ button several times until ‘4/5’ is displayed.
T Press the
‘Switch off after’ button.
‘Switch off after’
T Press the ‘<’ or ‘>’ button to change the switch-off time.
Enable and disable
products
Automatic switch-off
28
4 Permanent settings in programming mode
T Press the ‘Save’ button.
‘Saved’ appears briefly on the display.
‘4/5’
T Press the ‘’ button to exit programming mode.
The harder the water is, the more frequently the X8 needs to be
descaled. It is therefore important to set the water hardness
accurately.
The water hardness was set when the machine was first used. You
can change this setting at any time.
The total water hardness can be adjusted on a continuous scale
between 1°dH and 30°dH.
T Press the
‘Pc’ button.
T Press the
‘T’ button several times until ‘4/5’ is displayed.
T Press the
‘Water hardness’ button.
‘Water hardness’
T Press the ‘<’ or ‘>’ button to change the setting for the
water hardness.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘4/5’
T Press the ‘’ button to exit programming mode.
In the program item
‘4/5’ / ‘Rinse the milk system’ you can make the
following settings:
U
‘Manual’: You are prompted to perform milk system rinsing
10minutes after preparation of a specialty coffee with milk.
U
‘Automatic’: The milk system rinsing is automatically initiated
10minutes after preparation of a specialty coffee with milk.
Example:Proceed as follows to set the milk system rinsing to be
initiated automatically 10 minutes after the preparation.
T Press the
‘Pc’ button.
T Press the
‘T’ button several times until ‘4/5’ is displayed.
T Press the
‘Rinse the milk system’ button.
‘Rinse the milk system’
T Press the ‘Automatic’ button.
Setting the water
hardness
Milk system rinsing
29
4 Permanent settings in programming mode
T Press the ‘Save’ button.
‘Saved’ appears briefly on the display.
‘4/5’
T Press the ‘’ button to exit programming mode.
Example:Proceed as follows to change the unit for the amount of
water from
‘ml’ to ‘oz’.
T Press the
‘Pc’ button.
T Press the
‘T’ button several times until ‘4/5’ is displayed.
T Press the
‘Units’ button.
‘Units’
T Press the ‘oz’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘4/5’
T Press the ‘’ button to exit programming mode.
Example:Proceed as follows to change the language from
‘English’
to
‘Deutsch’.
T Press the
‘Pc’ button.
T Press the
‘T’ button several times until ‘4/5’ is displayed.
T Press the
‘Choose language’ button.
‘Choose language’
E To display more languages, press the ‘ T’ button (bottom
right).
T Press the button that corresponds to the language you want,
e.g.
‘Deutsch’.
‘Gespeichert’ appears briefly on the display.
‘4/5’
T Press the ‘’ button to exit programming mode.
Unit for amount of water
Language
30
4 Permanent settings in programming mode
In the program item ‘5/5’ you can view the following information.
U
‘Product counter’: Number of prepared specialty coffees and
hot water
U
‘Day counter’: Number of prepared specialty coffees and hot
water. This counter can be reset to zero.
U
‘Maintenance counter’: Number of maintenance programs
performed (cleaning, descaling etc.)
U
‘Version’: Software version
Example:Proceed as follows to reset the day counter.
T Press the
‘Pc’ button.
T Press the
‘T’ button several times until ‘5/5’ is displayed.
T Press the
‘Day counter’ button.
T Press the
‘’ button.
‘Delete the day counter?’
T Press the ‘Yes’ button.
‘Saved’ appears briefly on the display.
‘5/5’
T Press the ‘’ button to exit programming mode.
Query counter readings
and version
31
5 Maintenance
5 Maintenance
Use of maintenance products that are harmful to health and
discharge of liquids during maintenance program. Harmful if
swallowed. Irritating to eyes and skin.
T Keep children AWAY.
T Keep children away from the machine while it is performing a
maintenance program.
T Avoid contact with skin and eyes.
T Avoid generation of dust. Do not inhale dust.
T When using do not eat or drink.
T Keep maintenance products away from food, drink and
animal food.
T Keep container tightly closed and dry. Keep in a cool place.
Your X8 has the following integrated maintenance programs:
U
Rinsing the machine (‘2/5’ / ‘Rinse the coffee system’)
U
Rinsing the milk system in the dual spout (‘2/5’ / ‘Rinse the
milk system’
)
U
Cleaning the milk system in the dual spout (‘1/5’ / ‘Clean the
milk system’
)
U
Changing the filter (‘1/5’ / ‘Filter’) (only if filter is fitted)
U
Cleaning the machine (‘1/5’ / ‘Clean’)
U
Descaling the machine (‘1/5’ / ‘Descale’)
E Carry out each maintenance program when you are prompted
to do so.
E In the interests of hygiene, you should clean the milk system
daily when you have been preparing milk.
E Press the
‘ Pc’ button to view a list of the maintenance
programs. When the bar is completely filled with red,
your X8 will prompt you to perform the appropriate
maintenance program.
J WARNING
32
5 Maintenance
You can start coffee system rinsing manually at any time.
T Place a receptacle under the dual spout.
T Press the
‘Pc’ button.
T Press the
‘T’ button.
‘2/5’
T Press the ‘Rinse the coffee system’ button to start the rinse
operation.
‘Machine is rinsing’, water flows out of the dual spout. The
operation stops automatically.
After each milk preparation, the X8 prompts you to perform a milk
system rinse.
Precondition:
‘Rinse the milk system’ is displayed.
T Place a receptacle under the dual spout.
T Press the
‘Pc’ button.
‘Milk system is being rinsed’, water flows out of the dual
spout. The operation stops automatically.
Rinsing the machine
Rinsing the milk system
33
5 Maintenance
To ensure that the milk system in the dual spout always works prop-
erly, you must clean it daily when you have been preparing milk.
Non-recommended cleaning agents will not optimally remove milk
residues. This may cause the cappuccino frother to become blocked
and fly off the machine. Discharge of hot steam.
T Use only original JURA milk system cleaner.
Harmful and irritating cleaning agent. Harmful if swallowed.
Irritating to eyes and skin.
T Keep children AWAY.
T Avoid contact with skin and eyes.
T After contact with skin, wash immediately with plenty of
water. In case of skin irritation, seek medical advice.
T After eye contact, immediately flush eyes with plenty of water
and seek medical advice.
T If swallowed, rinse mouth immediately and drink large
quantities of water. Do not induce vomiting. Seek medical
advice immediately and show label.
E JURA milk system cleaner is available from specialized dealers.
E To clean the milk system, use the container supplied.
Precondition:The start screen is displayed.
T Press the
‘Pc’ button.
‘1/5’
T Press the ‘Clean the milk system’ button.
‘Clean the milk system’
T Press the ‘Start’ button.
T Press the
‘Next’ button.
‘Cleaning agent for milk system’
T Add a capful of milk system cleaner to the rear part of the
container.
T Press the
‘Next’ button.
‘Connect the milk tube’
Cleaning the milk system
J WARNING
J WARNING
34
5 Maintenance
T Place the container under the dual spout.
T Remove the milk pipe from the milk container.
T Connect the milk pipe to the container for milk system
cleaning.
E To connect the milk pipe to the container correctly, the pipe
must be fitted with a connector.
T Press the
‘Next’ button.
‘Cleaning milk system’, the dual spout and the pipe are
cleaned.
The operation stops automatically. Your X8 is once more
ready for use.
The dual spout must be dismantled and rinsed daily if milk has been
prepared to make sure it functions perfectly and also in the interests
of hygiene.
T Remove the milk pipe and rinse it thoroughly under running
water.
T Pull the cover of the dual spout forwards and off.
T Remove the milk system from the dual spout.
Dismantling and rinsing
the dual spout
35
5 Maintenance
T Dismantle the milk system into its individual parts.
T Rinse all the parts under running water. If there are severely
dried-on milk residues, firstly immerse the individual parts
in a solution of 8.5 oz (250 ml) cold water and 1 capful of JURA
milk system cleaner. Then rinse the parts thoroughly.
T Reassemble the milk system.
T Fit the assembled individual parts back in the dual spout and
press it firmly.
T Fit the cover of the dual spout.
T Connect the milk pipe to the dual spout.
1
2
3
3
2
1
36
5 Maintenance
Your X8 no longer has to be descaled if you are using the CLEARYL
Pro Smart filter cartridge. If you did not insert the filter cartridge the
first time you used the machine, you can do this now as follows.
T Remove the water tank and rinse it with cold water.
T Open the filter holder.
T Insert the filter cartridge into the water tank, exerting slight
pressure.
T Close the filter holder. It will click into place audibly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
E The machine automatically detects that you have just inserted
the filter cartridge.
‘Saved’ appears briefly on the display.
‘Filter is being rinsed’, Water flows directly into the drip tray.
Rinsing of the filter stops automatically.
‘Empty drip tray’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
Your X8 is once more ready for use.
E If the filter is active, this is indicated by a blue filter symbol at
the bottom of the display.
E Once the filter cartridge stops working (depending on the
water hardness setting), the X8 will prompt you to change the
filter.
E CLEARYL Pro Smart filter cartridges are available from
specialized dealers.
Precondition:The filter symbol at the bottom of the display lights
up red.
T Remove and empty the water tank.
T Open the filter holder and remove the old CLEARYL Pro
Smart filter cartridge.
Inserting the filter
Changing the filter
37
5 Maintenance
T Insert a new CLEARYL Pro Smart filter cartridge into the
water tank, exerting slight pressure.
T Close the filter holder. It will click into place audibly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
‘Saved’ appears briefly on the display. The machine has
automatically detected that you have just changed the filter
cartridge.
‘Filter is being rinsed’, Water flows directly into the drip tray.
Rinsing of the filter stops automatically.
‘Empty drip tray’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
Your X8 is once more ready for use.
E If the filter is active, this is indicated by a blue filter symbol at
the bottom of the display.
After 180preparations or 80switch-on rinses, the X8 will prompt you
to clean it.
Non-recommended (e.g. liquid) cleaning agents may contain
substances that could damage the machine or leave residues.
T Use only original JURA cleaning tablets. These are specially
formulated for your machine.
Harmful and irritating cleaning agent. Harmful if swallowed.
Irritating to eyes and skin.
T Keep children AWAY.
T Avoid contact with skin and eyes.
T Avoid generation of dust. Do not inhale dust.
T After contact with skin, wash immediately with plenty of
water. In case of skin irritation, seek medical advice.
T After eye contact, immediately flush eyes with plenty of water
and seek medical advice.
T If swallowed, rinse mouth immediately and drink large
quantities of water. Do not induce vomiting. Seek medical
advice immediately and show label.
Cleaning the machine
J WARNING
J WARNING
38
5 Maintenance
E The cleaning program lasts approximately 20 minutes.
E Do not interrupt the cleaning program. The quality of cleaning
will be impaired if you do so.
E JURA cleaning tablets are available from specialized dealers.
Precondition:
‘Clean machine’ is displayed.
T Press the
‘Pc’ button.
‘Clean’
T Press the ‘Start’ button.
T Press the
‘Next’ button.
‘Empty coffee grounds container’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Clean’
T Place a receptacle under the dual spout.
T Press the
‘Next’ button.
‘Machine is being cleaned’, water flows out of the dual spout.
The operation is interrupted,
‘Add cleaning tablet’.
T Open the cover behind the bean container.
T Insert a JURA cleaning tablet into the filler funnel.
T Close the cover.
T Press the
‘Next’ button.
‘Machine is being cleaned’, water flows out of the dual spout
repeatedly.
The operation stops automatically.
‘Empty coffee grounds container’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
Cleaning is now complete.
The X8 builds up deposits of limescale over time and automatically
prompts you to descale it when necessary. The degree of
calcification depends on the hardness of your water.
E If you are using a CLEARYL Pro Smart filter cartridge, you will
not be prompted to descale.
Descaling the machine
39
5 Maintenance
Non-recommended descaling agents (e.g. vinegar) may contain
substances that could damage the machine or leave residues.
T Use only original JURA descaling tablets. These are specially
formulated for your machine.
Harmful and irritating descaling agent. Harmful if swallowed.
Irritating to eyes and skin.
T Keep children AWAY.
T Avoid contact with skin and eyes.
T Avoid generation of dust. Do not inhale dust.
T After contact with skin, wash immediately with plenty of
water. In case of skin irritation, seek medical advice.
T After eye contact, immediately flush eyes with plenty of water.
Remove contact lenses. Seek medical advice.
T If swallowed, rinse mouth immediately and drink large
quantities of water. Do not induce vomiting. Seek medical
advice immediately and show label.
If the descaling operation is interrupted, there may be damage to
the machine.
T Allow the descaling program to run to the end.
E The descaling program lasts approximately 45minutes.
E JURA descaling tablets are available from specialized dealers.
E If the descaling agent comes into contact with sensitive
surfaces (e.g. marble), damage cannot be ruled out. Clean up
any splashes immediately.
Precondition:
‘Decalcify machine’ is displayed.
T Press the
‘Pc’ button.
‘Descale’
T Press the ‘Start’ button.
T Press the
‘Next’ button.
‘Empty drip tray’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Agent in tank’
T Remove and empty the water tank.
J WARNING
J WARNING J WARNING
NOTICE
40
5 Maintenance
T Completely dissolve 3JURA descaling tablets in a receptacle
holding 20 oz (600 ml) of water. This may take several
minutes.
T Pour the solution into the empty water tank and insert it
into the machine.
T Place one receptacle under the dual spout and another
under the hot-water spout.
T Press the
‘Next’ button.
‘Machine is being descaled’, water flows repeatedly out of
the dual spout and the hot-water spout.
The operation is interrupted,
‘Empty drip tray’.
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Fill water tank’
T Remove the water tank and rinse it thoroughly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Place one receptacle under the dual spout and another
under the hot-water spout.
T Press the
‘Next’ button.
‘Machine is being descaled’, the descaling operation is
continued.
The operation is interrupted,
‘Empty drip tray’.
T Empty the drip tray and coffee grounds container and put
them back into the machine.
Descaling is now complete.
E If the descaling operation stops unexpectedly, rinse the water
tank thoroughly.
41
5 Maintenance
Coffee beans may be covered with a slight oil film which remains on
the walls of the bean container and on the aroma preservation cover.
These traces may negatively affect the coffee result. For this reason,
clean the bean container and the aroma preservation cover from
time to time.
The bean container cover is lockable (spanner supplied as standard).
Precondition:
‘Fill bean container’ is displayed.
T Switch the machine off with the On/Off button Q.
T Remove the aroma preservation cover.
T Clean the bean container with a soft, dry cloth.
T Fill the bean container with coffee beans and close the
aroma preservation cover.
Limescale deposits may form in the water tank. To ensure correct
function of the machine, descale the water tank from time to time.
T Remove the water tank.
T If you use a CLEARYL Pro Smart filter cartridge, remove this.
T Completely fill the water tank and dissolve 3 JURA descaling
tablets in it.
T Leave the water tank with the descaling solution for several
hours (e.g. overnight).
T Empty the water tank and rinse it thoroughly.
T If you use a CLEARYL Pro Smart filter cartridge, insert this
again.
T Fill the water tank with fresh, cold water and reinsert the
tank.
Cleaning the bean
container
Descaling the water tank
42
6 Display messages
6 Display messages
Message Cause/Result Action
‘Fill water tank’ The water tank is empty. You
cannot prepare any products.
T Fill the water tank (see Chapter 3
‘Daily operation – Filling the water
tank’).
‘Empty coffee
grounds container’
/
‘Empty drip tray’
The coffee grounds container is
full. / The drip tray is full. You
cannot prepare any products.
T Empty the coffee grounds
container and the drip tray (see
Chapter 3 ‘Daily operation – Daily
maintenance’).
‘Drip tray not fitted’ The drip tray is not inserted
correctly or is not inserted at all.
You cannot prepare any products.
T Fit the drip tray.
‘Fill bean container’ The bean container is empty. You
cannot prepare any specialty
coffees, but you can prepare hot
water and milk.
T Fill the bean container (see
Chapter 1 ‘Preparing and using for
the first time – Filling the bean
container’)
‘Rinse the milk
system’
The X8 requests a milk system
rinse.
T Perform milk system rinsing (see
Chapter 5 ‘Maintenance – Rinsing
the milk system’).
The filter symbol at
the bottom of the
display lights up red.
The filter cartridge no longer
works.
T Replace the CLEARYL Pro Smart
filter cartridge (see Chapter 5
‘Maintenance – Changing the
filter’).
‘Clean machine’ The X8 is prompting you to clean
it.
T Perform cleaning (see Chapter 5
‘Maintenance – Cleaning the
machine’).
‘Decalcify machine’ The X8 is prompting you to
descale it.
T Perform descaling (see Chapter 5
‘Maintenance – Descaling the
machine ’).
‘Too hot’ The system is too hot to start a
maintenance program.
T Wait for several minutes until the
system has cooled or prepare a
specialty coffee or hot water.
43
7 Troubleshooting
7 Troubleshooting
Problem Cause/Result Action
Insufficient foam is
produced when the milk
is frothed or milk sprays
from the dual spout.
The dual spout is dirty.
T Clean the milk system in the dual spout
(see Chapter 5 ‘Maintenance – Cleaning
the milk system’).
TDismantle and rinse the dual spout (see
Chapter 5 ‘Maintenance – Dismantling
and rinsing the dual spout’).
Coffee only comes out in
drips when it is being
prepared.
The coffee is ground too
finely and obstructs the
system.
T Set the grinder to a coarser setting (see
Chapter 2 ‘Preparation – Adjusting the
grinder’).
‘Fill water tank’ is not
displayed although the
water tank is empty.
There is a lot of
limescale in the water
tank.
T Descale the water tank (see Chapter 5
‘Maintenance – Descaling the water
tank’).
Grinder is making a very
loud noise.
There are foreign objects
in the grinder.
T Contact customer support in your
country (see Chapter 11 ‘JURA contact
details/ Legal information’).
‘ERROR2’ or ‘ERROR5’ is
displayed.
If the machine has been
exposed to the cold for a
long period of time,
heating may be disabled
for safety reasons.
T Warm the machine at room
temperature.
Other
‘ERROR’ messages
are displayed.
–
T Switch the X8 off with the On/Off
button Q. Contact customer support in
your country (see Chapter 11 ‘JURA
contact details/ Legal information’).
E If you were unable to solve the problem, contact customer
support in your country (see Chapter 11 ‘JURA contact details/
Legal information’).
44
8 Transport and environmentally friendly disposal
8 Transport and environmentally friendly disposal
Keep the packaging for your X8. It should be used to protect the
machine during transport.
In order to protect the X8 from frost during transport, the system
must be emptied.
T Place one receptacle under the dual spout and another
under the hot-water spout.
T Press the
‘Pc’ button.
T Press the
‘T’ button.
‘2/5’
T Press the ‘Rinse the milk system’ button.
‘Milk system is being rinsed’, water flows out of the dual
spout. The operation stops automatically.
T Press the
‘Hot water’ button.
‘Hot water’, water flows out of the hot-water spout.
T Remove and empty the water tank.
Water will flow out of the hot-water spout until the system
is empty.
‘Fill water tank’
T Press the On/Off button Q.
Your X8 is switched off.
Please dispose of old machines in an environmentally neutral way.
H
Transport/ Emptying the
system
Disposal
45
9 Technical data
9 Technical data
Voltage 120V~, 60Hz
Power 1450W
Ambient conditions Humidity max. 80%
Ambient temperature
50–95 °F (10–35 °C)
Sound pressure level
≤ 70 dB
Conformity mark
Pump pressure static, max. 15bar
Holding capacity of water tank
(without filter)
170 oz
(5l)
Holding capacity of bean
container
17.6 oz
(500g)
Holding capacity of coffee
grounds container
max. 40 portions
Cord length approx. 47 in.
(approx. 1.2 m)
Weight approx. 30.9lb
(approx. 14kg)
Dimensions (W×H×D) approx. 14.7 × 18.5 × 18.2in.
(approx. 37.3 × 47 × 46.1cm)
The machine complies with the following directives:
U
Standard UL 1082
U
Canadian Standard CSA C22.2 No. 64
Directives
46
10 Index
10 Index
A
Addresses 48
Adjusting the product settings 23
Aroma preservation cover
Bean container with aroma preservation
cover 8
Automatic switch-off 27
B
Bean container
Bean container with aroma preservation
cover 8
Cleaning 41
Filling 10
Bluetooth 14
Bus bar
Technical data 45
Button
On/Off button 8
C
Caffè latte 16
Cappuccino 16
Cappuccino frother cleaning
Cleaning the milk system 33
Cappuccino frother rinsing
Rinsing the milk system 32
Cleaning
Bean container 41
Machine 37
CLEARYL Pro Smart filter cartridge
Change 36
Insert 36
Coffee 16
Coffee grounds container 8
Connecting an accessory 14
Consistency of grind
Adjusting the grinder 18
Grinder adjustment wheel 8
Contact details 48
Cover 8
Water tank 8
Cup platform 8
Customer support 48
D
Daily maintenance 20
Day counter 30
Descaling
Machine 38
Water tank 41
Disable
Products 27
Display 9
Display messages 42
Disposal 44
Double product 17
Drip tray 8
Insert 8
Dual spout
Dismantling and cleaning 34
Height-adjustable dual spout 8
E
Emptying the system 44
Enable
Products 27
Errors
Troubleshooting 43
Espresso 16
F
Filler funnel
Filler funnel for cleaning tablet 8
Filling
Bean container 10
Water tank 20
Filter
Change 36
Insert 36
First-time use 11
With filter cartridge activation 12
Without filter cartridge activation 13
Flat white 16
G
Green tea 19
Grinder adjustment wheel 8
H
Homepage 10
Hotline 48
Hot water 19
Hot-water spout 8
I
Important safeguards
Safety 4
Insert for drip tray 8
Internet 10
J
JURA
Contact details 48
Internet 10
L
Language 29
Latte macchiato 16
M
Machine
Cleaning 37
Daily maintenance 20
Descaling 38
Regular maintenance 21
Rinsing 32
Setting up 10
Switching off 21
47
10 Index
Switching on 20
Maintenance 31
Daily maintenance 20
Regular maintenance 21
Maintenance counter 30
Messages, display 42
Milk
Connecting milk 14
Milk system
Cleaning 33
Rinsing 32
Milk system rinsing 28
N
Number
Maintenance programs 30
Preparations 30
P
Permanently setting the water for the cup
size 17
Permanent settings in programming mode
22
Positioning products 25
Position of products
Change 25
Pot of coffee 16
Power cord 8
Preparation 15, 16
Caffè latte 16
Cappuccino 16
Coffee 16
Espresso 16
Flat white 16
Green tea 19
Hot water 19
Latte macchiato 16
Pot of coffee 16
Ristretto 16
Special coffee 16
Two specialty coffees 17
Problems
Troubleshooting 43
Product counter 30
Products
Disable 27
Enable 27
Product settings
Adjusting 23
Programming mode 22
Automatic switch-off 27
Counter readings and version 30
Enable or disable setting of cup volume
26
Language 29
Milk system rinsing 28
One-off settings 26
Positioning products on the start screen
25
Setting the water hardness 28
Unit for amount of water 29
R
Regular maintenance 21
Rinsing
Machine 32
Ristretto 16
S
Safety
Important safeguards 4
Service socket 9
Settings
Permanent settings in programming
mode 22
Setting up
Setting up the machine 10
Short operating instructions 10
Smart Connect 9
Special coffee 16
Spout
Height-adjustable dual spout 8
Hot-water spout 8
Switching off 21
Switching on 20
Switch-off
Automatic switch-off 27
Symbol description 3
T
Technical data 45
Tel 48
Transport 44
Troubleshooting 43
Two products 17
U
Unit for amount of water 29
Use, First-time 11
V
Version 30
W
Water hardness
Determining the water hardness 10
Setting the water hardness 28
Water tank 8
Descaling 41
Filling 20
Website 10
48
11 JURA contact details/ Legal information
11 JURA contact details/ Legal information
JURA Elektroapparate AG
Kaffeeweltstrasse 10
CH-4626 Niederbuchsiten
Switzerland
USA: JURA Inc.
Canada: FAEMA
Customer Service
Phone
E-Mail
1-800-220-5701
1-(855)-544-8600
info@juracanada.ca
Opening Hours (EST) Mon – Thu 9 am – 9 pm,
Fri 9 am – 8 pm,
Sat 9 am – 5 pm
Distributor Address
Phone
Fax
20 Craig Road
Montvale, NJ 07645
001 (201) 767-3999
001 (201) 767-9684
115 Matheson Boulevard East
Mississauga, Ontario, L4Z 1X8
1-(905)-501-8600
Internet www.us.jura.com www.ca.jura.com
@ You will find additional contact details for your country at
www.jura.com.
We reserve the right to make technical changes. The diagrams used
in these instructions for use are for illustration purposes only and do
not represent the original colors of the machine. Some details of
your JURA may vary.
Your opinion is important to us! Use the contact details at
www.us.jura.com.
The instructions for use contain information which is protected by
copyright. It is not permitted to photocopy these instructions for use
or translate them into another language without the prior written
consent of JURA Elektroapparate AG.
Technical changes
Feedback
Copyright
J73476/X8/US-en/201803
