WE8 Instructions for Use
JURA Type 737
K
Original instructions for use
Before using the machine read the instructions for use.
E
2
Table of contents
Your WE8
Control elements 4
Important information 6
Proper use ......................................................................................................................................................6
For your safety ...............................................................................................................................................6
1 Preparing and using for the first time 10
JURA on the Internet ....................................................................................................................................10
Setting up the machine ..............................................................................................................................10
Filling the bean container ...........................................................................................................................10
Determining the water hardness ..............................................................................................................10
First-time use .................................................................................................................................................11
Connecting milk ...........................................................................................................................................14
2 Preparation 15
Latte macchiato, cappuccino and other speciality coffees with milk .................................................15
Ristretto, espresso and coffee ....................................................................................................................16
Two ristretti, two espressi and two coffees .............................................................................................16
Milk foam .......................................................................................................................................................17
Ground coffee ...............................................................................................................................................17
Permanently setting the amount of water for the cup size .................................................................18
Adjusting the grinder ..................................................................................................................................19
Hot water .......................................................................................................................................................19
3 Daily operation 20
Filling the water tank ..................................................................................................................................20
Switching on the machine .........................................................................................................................20
Daily maintenance .......................................................................................................................................21
Regular maintenance ..................................................................................................................................21
Switching off the machine .........................................................................................................................22
4 Permanent settings in programming mode 23
Adjusting the product settings .................................................................................................................24
Enable or disable setting of cup volume ................................................................................................25
Enable or disable one-off settings ...........................................................................................................25
Enable and disable products .....................................................................................................................26
Automatic switch-off ..................................................................................................................................26
Milk system rinsing .....................................................................................................................................27
Setting the water hardness ....................................................................................................................... 27
Unit for amount of water ...........................................................................................................................28
Language ......................................................................................................................................................28
Query counter readings and version .......................................................................................................29
3
Table of contents
Warnings
J WARNING
J CAUTION
Always take note of any information marked with the words CAUTION or
WARNING and a warning sign. The signal word WARNING draws your attention
to potential serious injury, and the signal word CAUTION to potential minor
injury.
CAUTION CAUTION draws your attention to potential damage to the machine.
Symbols used
T
Prompt to take action. This symbol means that you are being prompted to perform
some action.
E
Information and tips to make it even easier to use your JURA.
‘Coffee’ Display
Symbol description
5 Maintenance 30
Rinsing the machine ...................................................................................................................................30
Rinsing the milk system .............................................................................................................................30
Cleaning the milk system ...........................................................................................................................31
Dismantling and rinsing the fine foam frother......................................................................................32
Dismantling and rinsing the professional fine foam frother ............................................................... 32
Inserting the filter .......................................................................................................................................33
Changing the filter ......................................................................................................................................34
Cleaning the machine ................................................................................................................................34
Descaling the machine ..............................................................................................................................35
Cleaning the bean container ..................................................................................................................... 37
Descaling the water tank ........................................................................................................................... 37
6 Display messages 38
7 Troubleshooting 39
8 Transport and environmentally friendly disposal 41
Transport/ Emptying the system ..............................................................................................................41
Disposal ..........................................................................................................................................................41
9 Technical data 42
10 Index 43
11 JURA contact details/ Legal information 48
4
Control elements
Control elements
13
12
3
4
5
7
6
8
14
9
10
11
1
2
1 Filler funnel cover
2 Filler funnel for ground coffee
3 Bean container with aroma
preservation cover
4 Water tank cover
5 Water tank
6 Plug-in mains cable
(back of the machine)
7 Coffee grounds container
8 Drip tray
9 Cover cap for grinder adjustment switch
10 Grinder adjustment switch
11 On/Off button Q
12 Fine foam frother
13 Height-adjustable coffee spout
14 Cup grille
5
Control elements
1
2
1 Display 2 Multi-function buttons (button function depends
on what is shown in the display)
Professional fine foam frother (optional)
Accessories
Container for milk system
cleaning
Measuring spoon for ground
coffee
Hot-water nozzle
é
è
6
6
Important information
Important information
This machine is intended for use by specialist or
trained staff in businesses, light industry and agri-
cultural facilities or for commercial use by non-pro-
fessionals. It should only be used for coffee prepa-
ration and to heat milk and water. Use for any other
purpose will be deemed improper. JURA Elektroap-
parate AG cannot accept any responsibility for the
consequences of improper use.
Before using the machine read these instructions
for use thoroughly and completely and comply
with the instructions they contain. A warranty ser-
vice is not applicable for damage or defects caused
by non-compliance with the instructions for use.
Keep these instructions for use close to the machine
and pass them on to the next user.
The JURA may only be operated by instructed per-
sons. Non-professionals must be supervised dur-
ing use.
Please carefully read and observe the important
safety information set out below.
To avoid danger of potentially fatal electric shock:
U
Never use a machine which is damaged or has
a defective mains cable.
U
In the event of signs of damage, for example if
there is a smell of burning, unplug the machine
immediately from the mains supply and con-
tact JURA service.
U
If the mains cable of this machine is damaged
it must be replaced with a special mains cable,
Proper use
For your safety
J
7
Important information
which is available directly from JURA or from
authorised JURA service centres.
U
Make sure that the JURA and the mains cable
are not located close to hot surfaces.
U
Be careful to ensure that the mains cable is not
trapped and does not rub against sharp edges.
U
Never open and repair the machine yourself.
Do not modify the machine in any way that is
not described in these instructions for use. The
machine contains live parts. If opened, there is
a danger of potentially fatal injury. Repairs
may only be carried out by authorised JURA
service centres, using original spare parts and
accessories.
U
To completely and safely disconnect the
machine from the power supply, first switch
off the JURA using the On/Off button. Only
then should you remove the mains plug from
the power socket.
There is a risk of scalds or burns on the spouts and
fine foam frother:
U
Place the machine out of the reach of children.
U
Do not touch any hot parts. Use the handles
provided.
U
Be careful to ensure that the fine foam frother
is correctly installed and clean. If incorrectly
fitted or if it becomes blocked, the fine foam
frother or its parts might come off.
A defective machine is not safe and could cause
injury or fire. To avoid damage and any associated
risk of injury or fire:
U
Never allow the mains cable to loosely hang
down. The mains cable could pose a tripping
hazard or become damaged.
8
Important information
U
Protect the JURA from environmental influ-
ences such as rain, frost and direct sunlight.
U
Do not immerse the JURA, mains cable or con-
nections in water.
U
Do not put the JURA or any individual parts in
the dishwasher.
U
Before cleaning, switch the JURA off with the
On/Off button. Always wipe the JURA with a
damp cloth rather than a wet one, and protect
it from prolonged exposure to water splash.
U
Only connect the machine to the mains volt-
age in accordance with the information on the
rating plate. The rating plate is located on the
underside of your JURA. Further technical data
is provided in these instructions for use (see
Chapter 9 ‘Technical data’).
U
Connect the JURA directly to a domestic power
socket. Using multi-socket adapters or exten-
sion cords may cause overheating.
U
Please only use original JURA maintenance
products. Use of products that are not explic-
itly recommended by JURA could damage the
machine.
U
Do not use alkaline cleaning agents when
cleaning, use a soft cloth and a mild detergent.
U
Do not use any coffee beans treated with addi-
tives or caramelised coffee beans.
U
Only fill the water tank with fresh, cold water.
U
Switch the machine off with the On/Off button
if you are going to be absent for a longer
period of time and remove the mains plug
from the power socket.
U
Children may not clean or service the machine
unless supervised by a responsible person.
9
Important information
U
Do not allow children to play with the machine.
U
Keep children under the age of 8 away from
the machine, or supervise them constantly.
U
Children aged 8 and over may only operate
the machine without supervision if they have
been instructed in how to use it safely. Chil-
dren must be able to recognise and under-
stand the potential dangers arising from incor-
rect use.
People, including children, who
U
do not have the physical, sensory or mental
capabilities to use the machine safely or
U
are inexperienced or lack knowledge in how to
use the machine safely
must be supervised by a responsible person when
using it, or must be instructed in how to use it cor-
rectly.
Safety when handling the CLARIS Pro Smart filter
cartridge:
U
Filter cartridges should be kept out of the
reach of children.
U
Store filter cartridges in a dry place in the
sealed packaging.
U
Protect cartridges from heat and direct
sunlight.
U
Do not use damaged filter cartridges.
U
Do not open filter cartridges.
10
1 Preparing and using for the first time
1 Preparing and using for the first time
Visit us on the Internet. You can download short operating instruc-
tions for your machine from the JURA website (www.jura.com). You
will also find interesting and up-to-date information on your JURA
and on every aspect of coffee.
When setting up your JURA, please note the following:
U
Place the JURA on a horizontal surface that is not sensitive to
water.
U
Choose a spot for your JURA which protects the machine
against overheating. Ensure that the ventilation slots are not
covered.
Coffee beans which have been treated with additives (e.g. sugar),
ground coffee or freeze-dried coffee will damage the grinder.
T Only use roasted, untreated coffee beans to fill the bean con-
tainer.
T Remove the aroma preservation cover.
T Remove any dirt or foreign objects from inside the bean
container.
T Fill the bean container with coffee beans and close the
aroma preservation cover.
When you use the machine for the first time, you must set the water
hardness. If you do not know the hardness of your water, you can
find this out first. Use the Aquadur
®
test strips supplied with the
machine.
T Hold the test strip briefly (for 1second) under flowing water.
Shake off the water.
T Wait for about 1minute.
JURA on the Internet
Setting up the machine
Filling the bean container
CAUTION
Determining the water
hardness
11
1 Preparing and using for the first time
T You will then be able to read the degree of water hardness
from the discolouration of the Aquadur® test strip and the
description on the packaging.
When using the machine for the first time, you can choose whether
you want to operate JURA with or without the CLARIS Pro Smart
filter cartridge. If the water hardness is 10 °dH or more (total
hardness), we recommend using the filter cartridge.
If the machine is operated with a defective mains cable, there is a
danger of potentially fatal electric shock.
T Never use a machine which is damaged or has a defective
mains cable.
Precondition:The bean container has been filled.
T Connect the mains cable to the machine.
T Insert the mains plug into a power socket.
T Press the On/Off button Q to switch the JURA on.
‘Sprachauswahl’
E To display more languages, press the ‘ > ’ button (bottom
right).
T Press the button that corresponds to the language you want,
e.g.
‘English’.
‘Saved’ appears briefly on the display to confirm the setting.
‘Water hardness’
E If you do not know the hardness of your water, you must find
this out first (see Chapter 1 ‘Preparing and using for the first
time – Determining the water hardness’).
T Press the
‘<’ or ‘>’ button to change the water hardness
setting, for example to
‘25°dH’.
First-time use
J
WARNING
12
1 Preparing and using for the first time
T Press the ‘Save’ button.
‘Saved’ appears briefly on the display.
‘Use filter’
E Now decide whether you want to operate your JURA with or
without a CLARIS Pro Smart filter cartridge.
Operation with filter cartridge: go straight to the next section (see
Chapter 1 ‘Preparing and using for the first time – First-time use with
filter cartridge activation’).
Operation without filter cartridge (see Chapter 1 ‘Preparing and
using for the first time – First-time use without filter cartridge
activation’).
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Place a receptacle (at least 300 ml) under the fine foam
frother and the coffee spout.
T Remove the water tank and rinse it with cold water.
T Open the filter holder.
T Insert the filter cartridge into the water tank.
T Close the filter holder. It will click into place audibly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
E The machine automatically detects that you have just inserted
the filter cartridge.
‘Use filter’ / ‘Saved’
‘Filter is being rinsed’
, water flows out of the fine foam
frother.
Rinsing of the filter stops automatically after approximately
300ml.
First-time use with filter
cartridge activation
CAUTION
13
1 Preparing and using for the first time
‘System is filling’, the system fills up with water.
‘Empty drip tray’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Machine is rinsing’, the system is rinsed.
The rinse stops automatically. Your JURA is ready for use.
E The start screen shows the products you can prepare. Press
the
‘>’ button to display more products.
E If the filter is active, this is indicated by a blue filter symbol at
the bottom of the display.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Press the
‘No filter’ button.
‘Saved’ appears briefly on the display.
‘Fill water tank’
T Place one receptacle under the coffee spout and another
under the fine foam frother.
T Remove the water tank and rinse it with cold water.
T Fill the water tank with fresh, cold water and reinsert the
tank.
‘System is filling’, the system fills up with water.
‘Machine is heating’
‘Machine is rinsing’
, the system is rinsed.
The rinse stops automatically. Your JURA is ready for use.
E The start screen shows the products you can prepare. Press
the
‘>’ button to display more products.
First-time use without filter
cartridge activation
CAUTION
14
1 Preparing and using for the first time
Your JURA creates fine, creamy, feather-light milk foam with a per-
fect consistency. The most important requirement for frothing milk
is a milk temperature of 4–8°C. We would therefore recommend
using a milk cooler or a vacuum milk container.
T Remove the protective cover from the fine foam frother.
T Connect the milk pipe to the fine foam frother.
T Connect the other end of the milk pipe to a milk container
or a milk cooler.
Connecting milk
15
2 Preparation
2 Preparation
E The display shows four products you can prepare. Press the
‘>’ button to display more products.
E You can stop the machine at any time while a speciality coffee
or hot water is being prepared. To do this, press the
‘Cancel’
button.
E During the grinding operation you can select the coffee
strength of single products by pressing the
‘<’ and ‘>’ but-
tons.
E During preparation you can change the preset amounts (e.g.
water and amount of milk) by pressing the
‘<’ and ‘>’ but-
tons.
Coffee tastes best served hot. A cold porcelain cup cools the bever-
age – and impairs the taste. We therefore recommend prewarming
the cups. The full coffee aroma can develop only in prewarmed cups.
You can purchase a JURA cup warmer from your specialised dealer.
You can make permanent settings for all products in programming
mode (see Chapter 4 ‘Permanent settings in programming mode –
Adjusting the product settings’).
Your JURA prepares latte macchiato, cappuccino and flat white at the
touch of a button. There is no need to move the glass or cup.
E This chapter applies to the professional fine foam frother and
the fine foam frother.
Example:Proceed as follows to prepare one latte macchiato.
Precondition:Milk is connected to the fine foam frother.
T Place a glass under the fine foam frother.
E If you are using the professional fine foam frother, turn the
setting wheel to the Milk Foam positioné.
T Press the
‘Latte macchiato’ button.
‘Latte macchiato’, the preset amount of milk foam flow into
the glass.
Latte macchiato,
cappuccino and other
speciality coffees with
milk
16
2 Preparation
E There is a short interval while the hot milk separates from the
milk foam. This allows the typical layers of a latte macchiato
to form. You can choose the length of this interval in program-
ming mode (see Chapter 4 ‘Permanent settings in program-
ming mode – Adjusting the product settings’).
Coffee preparation starts. The preset amount of water for
espresso flows into the glass. Preparation stops automati-
cally. Your JURA is once more ready for use.
To ensure that the fine foam frother always works properly, you
must clean it daily when you have been preparing milk (see Chap-
ter 5 ‘Maintenance – Cleaning the milk system’).
Example:Proceed as follows to prepare one coffee.
T Place a cup under the coffee spout.
T Press the
‘Coffee’ button.
Preparation starts.
‘Coffee’ and the coffee strength are dis-
played. The preset amount of water for coffee flows into the
cup.
Preparation stops automatically. Your JURA is once more
ready for use.
To prepare two speciality coffees, press the appropriate preparation
button twice (within approximately 1 second).
Example:Proceed as follows to prepare two espressi.
T Place two cups under the coffee spout.
T Press the
‘Espresso’ button twice (within 1 second) to start
preparation.
‘2 espressi’, the preset amount of water flows into the cups.
Preparation stops automatically. Your JURA is once more
ready for use.
Ristretto, espresso and
coffee
Two ristretti, two
espressi and two coffees
17
2 Preparation
E This chapter applies to the professional fine foam frother and
the fine foam frother.
Precondition:Milk is connected to the fine foam frother.
T Place a cup under the fine foam frother.
E If you are using the professional fine foam frother, turn the
setting wheel to the Milk Foam positioné.
E If you want to prepare hot milk, turn the setting wheel of the
professional fine foam frother to the Milk position è.
T Press the
‘Milk foam’ button.
‘Milk foam’, the milk foam is prepared. The preset amount
flows into the cup.
Preparation stops automatically. Your JURA is once more
ready for use.
To ensure that the fine foam frother always works properly, you
must clean it daily when you have been preparing milk (see Chap-
ter 5 ‘Maintenance – Cleaning the milk system’).
You can choose to use a second coffee variety, for example decaf-
feinated coffee, with the filter funnel for ground coffee.
E Never add more than two level measuring spoons of ground
coffee.
E Use ground coffee which is not ground too finely. Very fine
coffee can block up the system so that the coffee only comes
out in drips.
E If you did not fill the machine with a sufficient amount of
ground coffee,
‘Not enough ground coffee’ is displayed and
the JURA stops the operation.
E The desired speciality coffee must be prepared within approx-
imately one minute after filling with the ground coffee. Oth-
erwise the JURA stops the operation and is once more ready
for use.
All speciality coffees with ground coffee are always prepared follow-
ing the same model.
Milk foam
Ground coffee
18
2 Preparation
Example:Proceed as follows to prepare one espresso using ground
coffee.
T Place a cup under the coffee spout.
T Open the powder chute cover.
‘Ground coffee’ / ‘Please add ground coffee’
T Place one level measuring spoon of ground coffee into the
filler funnel.
T Close the cover of the filler funnel.
T Press the
‘Espresso’ button.
Preparation starts.
‘Espresso’, the preset amount of water for
espresso flows into the cup.
Preparation stops automatically. Your JURA is once more
ready for use.
It is easy to permanently adjust the amount of water for all single
products to the cup size. Adjust the amount once as shown in the
following example. Every time you prepare a drink in the future, this
amount will be dispensed.
Example: Proceed as follows to permanently set the amount of
water for one coffee.
T Place a cup under the coffee spout.
T Press and hold the
‘Coffee’ button until ‘Enough coffee?
Press button’
appears.
T Release the
‘Coffee’ button.
Preparation starts and the coffee flows into the cup.
T Press any button except
‘Cancel’ as soon as there is sufficient
coffee in the cup.
Preparation stops.
‘Saved’ appears briefly on the display. The
set amount of water for one coffee is permanently stored.
Your JURA is once more ready for use.
E You can alter this setting at any time by repeating the above
procedure.
E You can also permanently set the amounts for all single prod-
ucts in programming mode (see Chapter 4 ‘Permanent set-
tings in programming mode – Adjusting the product set-
tings’).
Permanently setting the
amount of water for the
cup size
19
2 Preparation
You can adjust the grinder on a continuous scale to suit the degree
of roast of your coffee.
If you adjust the consistency of grind when the grinder is not oper-
ating, the grinder adjustment switch could be damaged.
T Only adjust the consistency of grind when the grinder is run-
ning.
The consistency of grind is correct if the coffee flows regularly from
the coffee spout. In addition a fine, thick crema forms.
Example: Proceed as follows to change the consistency of grind
during the preparation of an espresso.
T Place a cup under the coffee spout.
T Open the cover of the grinder adjustment switch.
T Press the
‘Espresso’ button to start preparation.
T Turn the grinder adjustment switch to the desired position
while the grinder is running.
The preset amount of water flows into the cup. Preparation
stops automatically.
T Close the cover of the grinder adjustment switch.
To obtain a perfect water flow, use the hot-water nozzle.
There is a danger of scalding from hot water splashes.
T Avoid direct contact with the skin.
T Place a cup under the hot-water nozzle.
T Press the
‘Hot water’ button.
‘Hot water’, the preset amount of water flows into the cup.
Preparation stops automatically. Your JURA is once more
ready for use.
Adjusting the grinder
CAUTION
Hot water
J
CAUTION
20
3 Daily operation
3 Daily operation
Daily maintenance of the machine and hygiene when handling cof-
fee and water are key to a perfect coffee result in the cup every time.
You should therefore change the water daily.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Open the water tank cover.
T Remove the water tank and rinse it with cold water.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Close the water tank cover.
T Place a receptacle under the coffee spout.
T Press the On/Off button Q to switch the JURA on.
‘Welcome to JURA’
‘Machine is rinsing’
, the system is rinsed. The rinse stops
automatically. The start screen is displayed. Your JURA is
ready for use.
Filling the water tank
CAUTION
Switching on the
machine
21
3 Daily operation
To ensure that you get many years of reliable service out of your
JURA and to guarantee the optimum coffee quality, the machine
requires daily maintenance.
T Pull out the drip tray.
T Empty the coffee grounds container and the drip tray. Rinse
them both with warm water.
E Always empty the coffee grounds container when the machine
is switched on. This is the only way of resetting the coffee
grounds counter.
T Refit the coffee grounds container and the drip tray.
T Rinse the water tank with clean water.
T Clean the fine foam frother (see Chapter 5 ‘Maintenance –
Cleaning the milk system’).
T Remove the milk pipe and rinse it thoroughly under running
water.
T Dismantle and rinse the fine foam frother (see Chapter 5
‘Maintenance – Dismantling and rinsing the fine foam
frother’).
T Wipe the surface of the machine with a clean, soft, damp
cloth (e.g. microfibre cloth).
Carry out the following maintenance actions regularly or as
required:
U
In the interests of hygiene, we recommend changing the milk
pipe and interchangeable milk spout on a regular basis
(approximately every 3 months). Replacements are available
from specialised dealers.
U
Clean the inside of the water tank, e.g. with a brush. Further
information about the water tank is provided in these instruc-
tions for use (see Chapter 5 ‘Maintenance – Descaling the
water tank’).
U
Traces of milk and coffee may stick to the top and bottom of
the cup grille. If this happens, clean the cup grille.
Daily maintenance
Regular maintenance
22
3 Daily operation
When the JURA is switched off, the system is automatically rinsed if
a speciality coffee has been prepared.
T Place one receptacle under the coffee spout and another
under the fine foam frother.
T Press the On/Off button Q.
E If milk has been prepared, you will be prompted to clean the
milk system (
‘Clean the milk system’). After 10 seconds the
switch-off process continues automatically.
E If milk has been prepared but you have not started milk sys-
tem cleaning, the milk system is rinsed first (
‘Milk system is
being rinsed’
).
‘Machine is rinsing’, the system rinses itself. The operation
stops automatically. Your JURA is switched off.
Switching off the
machine
23
4 Permanent settings in programming mode
4 Permanent settings in programming mode
Press the ‘Pc’ button to enter programming mode. You can navi-
gate through the programme items and permanently save the
required settings using the multi-function buttons. The following
settings can be made:
Programme
item
Sub-item Explanation
‘1/6’ ‘Clean’,
‘Descale’,
‘Clean the milk system’,
‘Filter’ (only if filter is
activated)
T Start the required maintenance programme here.
‘2/6’ ‘Rinse the milk system’,
‘Rinse the coffee system’,
‘Information’
T Here you can start the required maintenance
programme or find out what maintenance actions
are required.
‘3/6’ ‘Expert mode’
T Select your settings for speciality coffees and hot
water.
‘Customise cup fill volume’
T Disable the function "Permanently setting the
amount of water for the cup size".
‘One-off settings’
T Specify whether or not to allow one-off settings
during preparation.
‘Lock/enable’
T Enable or disable individual products.
‘4/6’ ‘Choose language’
T Select your language.
‘Units’
T Select the unit for the amount of water.
‘Switch off after’
T Set the time after which the JURA should switch
off automatically.
‘Rinse the milk system’
T Change the setting for the milk system rinsing.
‘5/6’ ‘Water hardness’
T Adjust the water hardness.
‘6/6’ ‘Product counter’,
‘Day counter’,
‘Maintenance counter’,
‘Version’
T Keep track of all products prepared and view the
number of maintenance programmes performed.
24
4 Permanent settings in programming mode
In the programme item ‘Expert mode’ you can make individual set-
tings for all speciality coffees and hot water. The following perma-
nent settings can be made:
Product Coffee strength Amount Temperature
‘Ristretto’,
‘Espresso’
8 levels Coffee: 15ml–80ml normal, high
‘Coffee’ 8 levels Coffee: 25ml–240ml normal, high
‘2 ristretti’,
‘2 espressi’,
‘2 coffees’
– Coffee: The amount set for
the single product is doubled.
as for single product
‘Flat white’ 8 levels Coffee: 25ml–240ml
Milk: 3sec.–120sec.
normal, high
‘Cappuccino’,
‘Latte macchiato’
8 levels Coffee: 25ml–240ml
Milk: 3sec.–120sec.
Interval: 0sec.–60sec.
normal, high
‘Milk foam’ – Milk: 3sec.–120sec. –
‘Hot water’ – Water: 25ml–450ml low, normal, high
Permanent settings in programming mode always follow the same
model.
Example:Proceed as follows to change the coffee strength for one
coffee.
T Press the
‘Pc’ button.
T Press the
‘>’ button several times until ‘3/6’ is displayed.
T Press the
‘Expert mode’ button.
‘Expert mode’
E Next select the button of the product for which you would like
to make settings. No product is prepared at this point.
E To display more products, press the
‘>’ button (bottom right).
T Press the
‘Coffee’ button.
‘Coffee’
T Press the ‘Coffee strength’ button.
‘Coffee’ and the coffee strength is displayed.
T Press the
‘<’ or ‘>’ button to change the setting for the cof-
fee strength.
Adjusting the product
settings
25
4 Permanent settings in programming mode
T Press the ‘Save’ button.
‘Saved’ appears briefly on the display.
‘Coffee’
T Press the ‘’ button for around 2 seconds to exit program-
ming mode.
In the programme item
‘3/6’/ ‘Customise cup fill volume’ you can
make the following setting:
U
‘Active’: The function ‘Permanently setting the amount of
water for the cup size’ is activated. You can adjust the amount
of water to the cup size by pressing and holding the relevant
preparation button.
U
‘Inactive’: The function ‘Permanently setting the amount of
water for the cup size’ is deactivated. The amount of water
cannot be adjusted to the cup size by pressing and holding
the relevant preparation button.
Example:Proceed as follows to disable the function ‘Permanently
setting the amount of water for the cup size’.
T Press the
‘Pc’ button.
T Press the
‘>’ button several times until ‘3/6’ is displayed.
T Press the
‘Customise cup fill volume’ button.
‘Customise cup fill volume’
T Press the ‘Inactive’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘3/6’
T Press the ‘’ button to exit programming mode.
In the programme item
‘3/6’/ ‘One-off settings’ you can make the
following setting:
U
‘Active’: One-off settings can be made during preparation (e.g.
coffee strength or amount of water).
U
‘Inactive’: One-off settings cannot be made during prepara-
tion. The product is prepared according to the settings in pro-
gramming mode (
‘3/6’ / ‘Expert mode’).
Enable or disable setting
of cup volume
Enable or disable one-off
settings
26
4 Permanent settings in programming mode
Example:Proceed as follows to disable one-off settings during prep-
aration.
T Press the
‘Pc’ button.
T Press the
‘>’ button several times until ‘3/6’ is displayed.
T Press the
‘One-off settings’ button.
‘One-off settings’
T Press the ‘Inactive’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘3/6’
T Press the ‘’ button to exit programming mode.
In the programme item
‘3/6’/ ‘Lock/enable’ you can enable or disa-
ble each product individually.
Example:Proceed as follows to disable the preparation of hot water.
T Press the
‘Pc’ button.
T Press the
‘>’ button several times until ‘3/6’ is displayed.
T Press the
‘Lock/enable’ button.
‘Lock/enable’
E The lock symbol beside the product name indicates whether
the product is enabled or disabled. If the lock is closed, the
product is disabled.
T Press the
‘>’ button until the product ‘Hot water’ is dis-
played.
T Press the
‘Hot water’ button.
The lock is closed. Hot water preparation is now disabled.
T Press the
‘’ button for around 2 seconds to exit program-
ming mode.
By instructing your JURA to automatically switch itself off, you can
cut down your energy consumption. If this function is activated,
your JURA switches off automatically after the preset time following
the last action on the machine.
You can set the automatic switch-off to 15minutes, 30minutes or
1–9hours.
T Press the
‘Pc’ button.
Enable and disable
products
Automatic switch-off
27
4 Permanent settings in programming mode
T Press the ‘>’ button several times until ‘4/6’ is displayed.
T Press the
‘Switch off after’ button.
‘Switch off after’
T Press the ‘<’ or ‘>’ button to change the switch-off time.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘4/6’
T Press the ‘’ button to exit programming mode.
In the programme item
‘4/6’ / ‘Rinse the milk system’ you can make
the following settings:
U
‘Manual’: You are prompted to perform milk system rinsing
10minutes after preparation of a speciality coffee with milk.
U
‘Automatic’: The milk system rinsing is automatically initiated
10minutes after preparation of a speciality coffee with milk.
Example:Proceed as follows to set the milk system rinsing to be ini-
tiated automatically 10 minutes after the preparation.
T Press the
‘Pc’ button.
T Press the
‘>’ button several times until ‘4/6’ is displayed.
T Press the
‘Rinse the milk system’ button.
‘Rinse the milk system’
T Press the ‘Automatic’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘4/6’
T Press the ‘’ button to exit programming mode.
The harder the water is, the more frequently the JURA needs to be
descaled. It is therefore important to set the water hardness accu-
rately.
The water hardness was set when the machine was first used. You
can change this setting at any time.
The total water hardness can be adjusted on a continuous scale
between 1°dH and 30°dH.
T Press the
‘Pc’ button.
T Press the
‘>’ button several times until ‘5/6’ is displayed.
Milk system rinsing
Setting the water
hardness
28
4 Permanent settings in programming mode
T Press the ‘Water hardness’ button.
‘Water hardness’
T Press the ‘<’ or ‘>’ button to change the setting for the
water hardness.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘5/6’
T Press the ‘’ button to exit programming mode.
Example:Proceed as follows to change the unit for the amount of
water from
‘ml’ to ‘oz’.
T Press the
‘Pc’ button.
T Press the
‘>’ button several times until ‘4/6’ is displayed.
T Press the
‘Units’ button.
‘Units’
T Press the ‘oz’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘4/6’
T Press the ‘’ button to exit programming mode.
Example:Proceed as follows to change the language from
‘English’
to
‘Deutsch’.
T Press the
‘Pc’ button.
T Press the
‘>’ button several times until ‘4/6’ is displayed.
T Press the
‘Choose language’ button.
‘Choose language’
E To display more languages, press the ‘ > ’ button (bottom
right).
T Press the button that corresponds to the language you want,
e.g.
‘Deutsch’.
‘Gespeichert’ appears briefly on the display.
‘4/6’
T Press the ‘’ button to exit programming mode.
Unit for amount of water
Language
29
4 Permanent settings in programming mode
In the programme item ‘6/6’ you can view the following information.
U
‘Product counter’: Number of prepared speciality coffees and
hot water
U
‘Day counter’: Number of prepared speciality coffees and hot
water. This counter can be reset to zero.
U
‘Maintenance counter’: Number of maintenance programmes
performed (cleaning, descaling etc.)
U
‘Version’: Software version
Example:Proceed as follows to reset the day counter.
T Press the
‘Pc’ button.
T Press the
‘>’ button several times until ‘6/6’ is displayed.
T Press the
‘Day counter’ button.
T Press the
‘’ button.
‘Delete the day counter?’
T Press the ‘Yes’ button.
‘Saved’ appears briefly on the display.
‘6/6’
T Press the ‘’ button to exit programming mode.
Query counter readings
and version
30
5 Maintenance
5 Maintenance
Your JURA has the following integrated maintenance programmes:
U
Rinsing the machine (‘Rinse the coffee system’)
U
Rinsing the fine foam frother (‘Rinse the milk system’)
U
Cleaning the fine foam frother (‘Clean the milk system’)
U
Changing the filter (‘Filter’)
U
Cleaning the machine (‘Clean’)
U
Descaling the machine (‘Descale’)
E Carry out each maintenance programme when you are
prompted to do so.
E Press the
‘Pc’ button to view a list of the maintenance pro-
grammes. When the bar is completely filled with red, your
JURA will prompt you to perform the appropriate mainte-
nance programme.
You can start coffee system rinsing manually at any time.
T Place a receptacle under the coffee spout.
T Press the
‘Pc’ button.
T Press the
‘>’ button.
T Press the
‘Rinse the coffee system’ button to start the rinse
operation.
‘Machine is rinsing’, water flows out of the coffee spout. The
operation stops automatically.
After each milk preparation, the JURA prompts you to perform a milk
system rinse.
E In programming mode, you can set whether the milk system
rinsing is to be prompted 10 minutes after preparation or initi-
ated automatically (see Chapter 4 ‘Permanent settings in pro-
gramming mode – Milk system rinsing’).
Precondition:
‘Rinse the milk system’ is displayed.
Rinsing the machine
Rinsing the milk system
31
5 Maintenance
T Place a receptacle under the fine foam frother.
T Press the
‘Pc’ button.
‘Milk system is being rinsed’, the fine foam frother is rinsed.
The operation stops automatically.
To ensure that the fine foam frother always works properly, you
must clean it daily when you have been preparing milk.
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
E JURA milk system cleaner is available from specialised dealers.
E To clean the milk system, use the container supplied.
T Press the
‘Pc’ button.
T Press the
‘Clean the milk system’ button.
‘Clean the milk system’
T Press the ‘Start’ button.
T Press the
‘Next’ button.
‘Clean the milk system’ / ‘Milk system cleaner’
T Remove the milk pipe from the milk container or carton.
T Add milk system cleaner to the front part of the container
up to the bottom mark (indicated by 6).
T Then fill with water up to the upper mark.
T Place the container under the fine foam frother.
T Connect the milk pipe to the container.
E To connect the milk pipe to the container correctly, the pipe
must be fitted with a connector.
Cleaning the milk system
CAUTION
6
é
è
6
32
5 Maintenance
T Press the ‘Next’ button.
‘Milk system is being cleaned’ appears and the fine foam
frother and the milk pipe are cleaned.
‘Clean the milk system’ / ‘Fresh water’
T Rinse the container thoroughly and fill the front part with
fresh water up to the upper mark.
T Place this under the fine foam frother and reconnect the
milk pipe to the container.
T Press the
‘Next’ button.
‘Milk system is being cleaned’, the fine foam frother and the
milk pipe are rinsed with fresh water.
The operation stops automatically.
To make sure the fine foam frother works properly, and in the inter-
ests of hygiene, it must be dismantled and rinsed daily if you have
been preparing milk. Your JURA will not prompt you to dismantle
and rinse the frother.
T Remove the milk pipe and rinse it thoroughly under running
water.
T Carefully remove the fine foam frother from the Connector
System
©
by twisting slightly.
T Dismantle the fine foam frother into its individual parts.
T Rinse all the parts under running water. If there are severely
dried-on milk residues, firstly immerse the individual parts
in a solution of 250ml cold water and 1 capful of JURA milk
system cleaner. Then rinse the parts thoroughly.
T Re-assemble the fine foam frother.
E Ensure that all individual parts are correctly and firmly con-
nected to ensure optimum operation.
T Firmly attach the fine foam frother to the Connector Sys-
tem
©
.
To make sure the professional fine foam frother works properly, and
in the interests of hygiene, it must be dismantled and rinsed daily if
you have been preparing milk. Your JURA will not prompt you to dis-
mantle and rinse the professional fine foam frother.
T Remove the milk pipe and rinse it thoroughly under running
water.
Dismantling and rinsing
the fine foam frother
Dismantling and rinsing
the professional fine
foam frother
33
5 Maintenance
T Carefully remove the professional fine foam frother from the
Connector System
©
by twisting slightly.
T Dismantle the professional fine foam frother into its individ-
ual parts.
T Rinse all the parts under running water. If there are severely
dried-on milk residues, firstly immerse the individual parts
in a solution of 250ml cold water and 1 capful of JURA milk
system cleaner. Then rinse the parts thoroughly.
T Re-assemble the professional fine foam frother.
E Ensure that all individual parts are correctly and firmly con-
nected to ensure optimum operation of the professional fine
foam frother.
T Firmly attach the professional fine foam frother to the Con-
nector System
©
.
Your JURA no longer has to be descaled if you are using the CLARIS
Pro Smart filter cartridge. If you did not insert the filter cartridge the
first time you used the machine, you can do this now as follows.
T Remove and empty the water tank.
T Open the filter holder.
T Insert the filter cartridge into the water tank.
T Close the filter holder. It will click into place audibly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
E The machine automatically detects that you have just inserted
the filter cartridge.
‘Saved’ appears briefly on the display.
‘Filter is beingrinsed’, the water flows directly into the drip
tray.
Rinsing of the filter stops automatically.
E If the filter is active, this is indicated by a blue filter symbol at
the bottom of the display.
é
è
Inserting the filter
34
5 Maintenance
E Once the filter cartridge stops working (depending on the
water hardness setting), the JURA will prompt you to change
the filter.
E CLARIS Pro Smart filter cartridges are available from special-
ised dealers.
Precondition:The filter symbol at the bottom of the display lights
up red.
T Remove and empty the water tank.
T Open the filter holder and remove the old CLARIS Pro Smart
filter cartridge.
T Insert the filter cartridge into the water tank.
T Close the filter holder. It will click into place audibly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
‘Saved’ appears briefly on the display. The machine has
automatically detected that you have just changed the filter
cartridge.
‘Filter is beingrinsed’, the water flows directly into the drip
tray.
Rinsing of the filter stops automatically.
After 180preparations or 80switch-on rinses, the JURA will prompt
you to clean it.
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
E The cleaning programme lasts approximately 20 minutes.
E Do not interrupt the cleaning programme. The quality of
cleaning will be impaired if you do so.
E JURA cleaning tablets are available from specialised dealers.
Precondition:
‘Clean machine’ is displayed.
T Press the
‘Pc’ button (red Maintenance symbol).
T Press the
‘Start’ button.
T Press the
‘Next’ button.
‘Empty coffee grounds container’
Changing the filter
Cleaning the machine
CAUTION
35
5 Maintenance
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Clean’
T Place one receptacle under the coffee spout and another
under the fine foam frother.
T Press the
‘Next’ button.
‘Machine is being cleaned’, water flows out of the coffee
spout.
The operation is interrupted,
‘Add cleaning tablet’.
T Open the cover of the filler funnel for ground coffee.
T Insert a JURA cleaning tablet into the filler funnel.
T Close the cover of the filler funnel.
T Press the
‘Next’ button.
‘Machine is being cleaned’, water flows repeatedly out of the
coffee spout and the fine foam frother.
The operation stops automatically.
‘Empty coffee grounds container’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
Cleaning is now complete.
The JURA builds up deposits of limescale over time and automati-
cally prompts you to descale it when necessary. The degree of calci-
fication depends on the hardness of your water.
E If you are using a CLARIS Pro Smart filter cartridge, you will not
be prompted to descale.
If the descaling agent comes into contact with the skin or eyes, this
can cause irritation.
T Avoid contact with the skin or eyes.
T Rinse off the descaling agent with clean water. Should you get
any descaling agent in your eye, see a doctor.
If the wrong descaling agent is used, the machine could be dam-
aged and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
Descaling the machine
J
CAUTION
CAUTION
36
5 Maintenance
If the descaling operation is interrupted, there may be damage to
the machine.
T Allow the descaling programme to run to the end.
If the descaling agent comes into contact with sensitive surfaces
(e.g. marble), damage cannot be ruled out.
T Clean up any splashes immediately.
E The descaling programme lasts approximately 40minutes.
E JURA descaling tablets are available from specialised dealers.
Precondition:
‘Decalcify machine’ is displayed.
T Press the
‘Pc’ button (red Maintenance symbol).
T Press the
‘Start’ button.
T Press the
‘Next’ button.
‘Empty drip tray’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Agent in tank’
T Remove and empty the water tank.
T Completely dissolve 3JURA descaling tablets in a receptacle
holding 500ml of water. This may take several minutes.
T Pour the solution into the empty water tank and insert it into
the machine.
T Place a receptacle under the fine foam frother.
T Press the
‘Next’ button.
‘Machine is being descaled’, appears and water flows out of
the fine foam frother repeatedly.
The operation is interrupted,
‘Empty drip tray’.
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Fill water tank’
T Remove the water tank and rinse it thoroughly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
CAUTION
CAUTION
37
5 Maintenance
T Place one receptacle under the coffee spout and another
under the fine foam frother.
T Press the
‘Next’ button.
‘Machine is being descaled’, the descaling operation is
continued.
The operation is interrupted,
‘Empty drip tray’.
T Empty the drip tray and coffee grounds container and put
them back into the machine.
Descaling is now complete.
E If the descaling operation stops unexpectedly, rinse the water
tank thoroughly.
Coffee beans may be covered with a slight oil film which remains on
the walls of the bean container. These traces may negatively affect
the coffee result. For this reason clean the bean container from time
to time.
Precondition:
‘Fill bean container’ is displayed.
T Switch the machine off with the On/Off button Q.
T Remove the aroma preservation cover.
T Clean the bean container with a soft, dry cloth.
T Fill the bean container with coffee beans and close the
aroma preservation cover.
Limescale deposits may form in the water tank. To ensure correct
function of the machine, descale the water tank from time to time.
T Remove the water tank.
T If you use a CLARIS Pro Smart filter cartridge, remove this.
T Completely fill the water tank and dissolve 3 JURA descaling
tablets in it.
T Leave the water tank with the descaling solution for several
hours (e.g. overnight).
T Empty the water tank and rinse it thoroughly.
T If you use a CLARIS Pro Smart filter cartridge, insert this
again.
T Fill the water tank with fresh, cold water and reinsert the
tank.
Cleaning the bean
container
Descaling the water tank
38
6 Display messages
6 Display messages
Message Cause/Result Action
‘Fill water tank’ The water tank is empty.
You cannot prepare any products.
T Fill the water tank (see Chapter 3 ‘Daily
operation – Filling the water tank’).
‘Empty coffee
grounds
container’
The coffee grounds container
is full. You cannot prepare any
products.
T Empty the coffee grounds container
and the drip tray (see Chapter 3 ‘Daily
operation – Daily maintenance’).
‘Drip tray not
fitted’
The drip tray is not inserted
correctly or is not inserted at all.
You cannot prepare any products.
T Fit the drip tray.
‘Fill bean
container’
The bean container is empty.
You cannot prepare any speciality
coffees, but you can prepare hot
water and milk.
T Fill the bean container (see Chapter 1
‘Preparing and using for the first time –
Filling the bean container’).
‘Rinse the milk
system’
The JURA requests a milk system
rinse.
T Perform milk system rinsing (see
Chapter 5 ‘Maintenance – Rinsing the
milk system’).
The filter symbol
at the bottom of
the display lights
up red.
The filter cartridge no longer
works.
T Replace the CLARIS Pro Smart filter
cartridge (see Chapter 5 ‘Maintenance –
Changing the filter’).
‘Clean machine’ The JURA is prompting you to
clean it.
T Perform cleaning (see Chapter 5
‘Maintenance – Cleaning the machine’).
‘Decalcify
machine’
The JURA is prompting you to
descale it.
T Perform descaling (see Chapter 5
‘Maintenance – Descaling the machine’).
‘Too hot’ The system is too hot to start a
maintenance programme.
T Wait for several minutes until
the system has cooled or prepare a
speciality coffee or hot water.
39
7 Troubleshooting
7 Troubleshooting
Problem Cause/Result Action
Insufficient foam is
produced when the milk
is frothed or milk sprays
out of the fine foam
frother.
The fine foam frother is
dirty.
T Clean the fine foam frother (see
Chapter 5 ‘Maintenance – Cleaning the
milk system’).
T Dismantle and rinse the fine foam
frother (see Chapter 5 ‘Maintenance –
Dismantling and rinsing the fine foam
frother’).
Coffee only comes out in
drips when it is being
prepared.
The coffee is ground too
finely and obstructs the
system.
T Set the grinder to a coarser setting (see
Chapter 2 ‘Preparation – Adjusting the
grinder’).
‘Fill water tank’ is
displayed although the
water tank is full.
The water tank float is
trapped.
T Descale the water tank (see Chapter 5
‘Maintenance – Descaling the water
tank’).
Little or no water or
steam comes out of the
fine foam frother.
The pump is very quiet.
The connector of the fine
foam frother may be
blocked by milk residues
or limescale fragments
loosened during
descaling.
T Remove the fine foam frother.
T Unscrew the black connector with the
aid of the hexagonal hole on the
measuring spoon for ground coffee.
T Clean the connector thoroughly.
T Screw the connector back on by hand.
T Carefully tighten it using the hexagonal
hole on the measuring spoon, turning by
no more than a quarter of a rotation.
Grinder is making a very
loud noise.
There are foreign objects
in the grinder.
T Contact customer support in your
country (see Chapter 11 ‘JURA contact
details/ Legal information’).
‘ERROR2’ or ‘ERROR5’ is
displayed.
If the machine has been
exposed to the cold for a
long period of time,
heating may be disabled
for safety reasons.
T Warm the machine at room tempera-
ture.
40
7 Troubleshooting
Problem Cause/Result Action
Other
‘ERROR’ messages
are displayed.
–
T Switch the JURA off with the On/Off
button Q. Contact customer support in
your country (see Chapter 11 ‘JURA
contact details/ Legal information’).
E If you were unable to solve the problem, contact customer
support in your country (see Chapter 11 ‘JURA contact details/
Legal information’).
41
8 Transport and environmentally friendly disposal
8 Transport and environmentally friendly disposal
Keep the packaging for your JURA. It should be used to protect the
machine during transport.
In order to protect the JURA from frost during transport, the system
must be emptied.
T Remove the milk pipe from the fine foam frother.
T Place a receptacle under the fine foam frother.
T Press the
‘Milk foam’ button.
‘Milk foam’ appears and hot steam is discharged from the
fine foam frother.
T Remove and empty the water tank.
T Press the
‘>’ button several times until ‘Amount of milk’ /
‘60sec.’ is displayed.
Steam will continue to be discharged from the fine foam
frother until the system is empty.
‘Fill water tank’
T Press the On/Off button Q.
Your JURA is switched off.
Please dispose of old machines in an environmentally neutral way.
H
Old machines contain valuable, recyclable materials which should
be recycled. Please therefore dispose of old machines via suitable
collection systems.
Transport/ Emptying the
system
Disposal
42
9 Technical data
9 Technical data
Voltage 220–240V~, 50Hz
Power 1450W
Ambient conditions Humidity max. 80 %
Ambient temperature
10–35°C
Conformity mark
A
Pump pressure static, max. 15bar
Holding capacity of water tank
(without filter)
3l
Holding capacity of bean container 500g
Holding capacity of coffee grounds
container
max. 25portions
Cable length approx. 1.1m
Weight approx. 10.0kg
Dimensions (WHD) 29.5 41.75 44.36cm
Information for testers (repeat test in accordance with DIN VDE
0701-0702): The central grounding point (CGP) is located on the
underside of the machine, right next to the mains cable's connec-
tion point.
43
10 Index
10 Index
A
Addresses 48
Adjusting the product settings 24
Aroma preservation cover
Bean container with aroma preservation
cover 4
Automatic switch-off 26
B
Bean container
Bean container with aroma preservation
cover 4
Cleaning 37
Filling 10
Bus bar
Technical data 42
Button
On/Off button 4
C
Cappuccino 15
Cappuccino frother cleaning
Cleaning the milk system 31
Cappuccino frother rinsing
Rinsing the milk system 30
Central grounding point 42
CLARIS Pro Smart filter cartridge
Change 34
Insert 33
Cleaning
Bean container 37
Machine 34
Coffee 16
Two coffees 16
Coffee grounds container 4
Coffee spout
Height-adjustable coffee spout 4
Consistency of grind
Adjusting the grinder 19
Grinder adjustment switch 4
Contact details 48
Cover
Filler funnel for ground coffee 4
Water tank 4
Cup grille 4
Customer support 48
D
Daily maintenance 21
Day counter 29
Descaling
Machine 35
Water tank 37
Disable
Products 26
Display 5
Display messages 38
Disposal 41
Double product 16
Drip tray 4
E
Emptying the system 41
Enable
Products 26
Errors
Troubleshooting 39
Espresso 16
Two espressi 16
F
Filler funnel
Filler funnel for ground coffee 4
Filling
Bean container 10
Water tank 20
Filter
Change 34
Insert 33
Fine foam frother 4
Cleaning 31
Dismantling and rinsing 32
Professional fine foam frother 5
Rinsing 30
First-time use 11
With filter cartridge activation 12
Without filter cartridge activation 13
Flat white 15
G
Grinder adjustment switch 4
Ground coffee 17
Measuring spoon for ground coffee 5
Grounding point 42
44
10 Index
H
Height-adjustable coffee spout 4
Homepage 10
Hotline 48
Hot water 19
Hot-water nozzle 5
I
Instant coffee
Ground coffee 17
Internet 10
J
JURA
Contact details 48
Internet 10
L
Language 28
Latte macchiato 15
M
Machine
Cleaning 34
Daily maintenance 21
Descaling 35
Regular maintenance 21
Rinsing 30
Setting up 10
Switching off 22
Switching on 20
Mains cable 4
Maintenance 30
Daily maintenance 21
Regular maintenance 21
Maintenance counter 29
Measuring spoon for ground coffee 5
Messages, display 38
Milk
Connecting milk 14
Milk foam 17
Milk system
Cleaning 31
Rinsing 30
Milk system rinsing 27
N
Number
Maintenance programmes 29
Preparations 29
P
Permanently setting the water for the cup
size 18
Permanent settings in programming mode
23
Preparation 15
Cappuccino 15
Coffee 16
Espresso 16
Flat white 15
Ground coffee 17
Hot water 19
Latte macchiato 15
Milk foam 17
Ristretto 16
Two coffees 16
Two espressi 16
Two ristretti 16
Two speciality coffees 16
Problems
Troubleshooting 39
Product counter 29
Products
Disable 26
Enable 26
Product settings
Adjusting 24
Professional fine foam frother 5
Dismantling and rinsing 32
Programming mode 23
Automatic switch-off 26
Counter readings and version 29
Enable or disable setting of cup volume
25
Language 28
Milk system rinsing 27
One-off settings 25
Setting the water hardness 27
Unit for amount of water 28
Proper use 6
R
Regular maintenance 21
Rinsing
Machine 30
Ristretto 16
Two ristretti 16
45
10 Index
S
Safety 6
Safety information 6
Settings
Permanent settings in programming
mode 23
Setting up
Setting up the machine 10
Short operating instructions 10
Switching off 22
Switching on 20
Switch-off
Automatic switch-off 26
Symbol description 3
T
Technical data 42
Tel 48
Transport 41
Troubleshooting 39
Two products 16
U
Unit for amount of water 28
Use, First-time 11
V
Version 29
W
Water hardness
Determining the water hardness 10
Setting the water hardness 27
Water tank 4
Descaling 37
Filling 20
Website 10
46
47
48
11 JURA contact details/ Legal information
11 JURA contact details/ Legal information
Your JURA service partner
JURA Elektroapparate AG
Kaffeeweltstrasse 10
CH-4626 Niederbuchsiten
Tel. +41 (0)62 38 98 233
www.jura.com
The machine complies with the following directives:
U
2006/42/EC– Machinery Directive
U
2014/30/EU– Electromagnetic Compatibility
U
2009/125/EC– Ecodesign Directive
U
2011/65/EU– RoHS Directive
We reserve the right to make technical changes. The diagrams used
in these instructions for use are for illustration purposes only and do
not represent the original colours of the machine. Some details of
your JURA may vary.
Your opinion is important to us! Use the contact details at
www.jura.com.
The instructions for use contain information which is protected by
copyright. It is not permitted to photocopy these instructions for use
or translate them into another language without the prior written
consent of JURA Elektroapparate AG.
Directives
Technical changes
Feedback
Copyright
J72636/WE8/en/201702
