134176300B 11/03
IMPORTANT: Read and save these instructions.
Washer & Dryer Pedestal Kit
NOTICE! This kit is intended to be installed by persons having electrical and mechanical training and a
level of knowledge considered acceptable in the appliance repair trade.
Your safety and the safety of others are very
important. Many important safety messages are
provided in these instructions and on your
appliance. Always read and obey all safety
messages.
WARNING
EXCESSIVE WEIGHT HAZARD
Two or more people may be required to move and
install the washer & dryer with pedestals.
Failure to comply may cause back or other injury.
Tools needed:
Level
9/16” open end wrench or ratchet
Channel-lock adjustable pliers
2# Phillips screwdriver
Flat blade screwdriver
WASHER INSTALLATION
Washer Hardware
1. Remove the 24-3/8” x 27” x 12”pedestal,
installation hardware and instructions from the
shipping carton.
2. Using the pedestal shipping carton for
protection, carefully lay the washer on its back.
NOTE: If washer was previously installed,
disconnect from power supply, remove inlet
hoses from water faucets and tape the drain hose
to the top front of the washer to eliminate excess
water on the floor.
3. Remove the four (4) leveling legs from the
washer base and discard.
4. If the washer has rollers, remove the four (4)
screws securing the rollers to the base.
5. Install the four (4) leveling legs (supplied with
the kit) fully into the pedestal.
6. The words “TOP FRONT” are embossed on the
top front of the pedestal. Position the pedestal so
the words are up with the front of the washer.
Align the pedestal mounting holes with the
threaded leg holes on the washer base.
