REMOVE THE LEVELING LEGS
A
Carefully lay down the appliance to access
the leveling legs on its bottom. The washer
shipping bolts must remain in place until the
washer is returned to an upright position.
Washer – Lay on its back
Dryer – Lay on its side
B
Use an adjustable wrench to remove the
washer or dryer leveling legs.
INSTALLATION PREPARATION
Remove the packaging.
Flatten the product carton to use as a pad to lay
the washer or dryer down on its side. Continue using
the carton to protect the finished floor in front of the
installation location.
4 Mounting screws -
Dryer
4 Mounting bolts -
Washer
Drawer divider
TOOLS YOU WILL NEED
Phillips-head
screwdriver
9/16” socket wrench
8 mm socket wrench
10” Adjustable
wrench
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•
IMPORTANT – Save these instructions for local
inspector’s use.
•
IMPORTANT – Observe all governing codes and
ordinances.
•
Note to Consumer – Keep these instructions for future
reference.
•
Completion time – 1 to 2 hours
•
Proper installation is the responsibility of the installer.
•
Product failure due to improper installation is not
covered under the Warranty
.
CAUTION ³'XHWRWKHVL]HDQGZHLJKW
of these products, and to reduce the risk of
SHUVRQDOLQMXU\RUGDPDJHWRWKHSURGXFW7:2
PEOPLE ARE REQUIRED FOR PROPER INSTALLATION.
• See washer and dryer Owner’s Manual & Installation
Instructions for additional installation requirements and
guidelines.
Instructions en français : . . . . . . . . . .. . . . . .5
Instrucciones en español: . . . . . . . . . . . . . . .9
Installation
Instructions
White Pedestal: GFXP1308FWW
Red Pedestal: GFXP1308FRR
Metallic Carbon Pedestal: GFXP1308FMC
For Washer Models:
GFWS2500, GFWS2505, GFWS2600, GFWS2605,
GHWS3600, GHWS3605, GFWS3700 and GFWS3705
For Dryer Models:
GFDS250, GFDS255, GFDS260, GFDS265, GHDS360,
GHDS365, GFDS370 and GFDS375
Pedestal
1
31-16708-1 11-13 GE
Printed in the United States
KIT CONTENTS
