OWNER’S MANUAL

FRENCH DOOR

FRIDGE

Please read this owner's manual thoroughly before

operating and keep it handy for reference at all times.

www.lg.com

TABLE OF CONTENTS

3 PRODUCT FEATURES

IMPORTANT SAFETY

INSTRUCTIONS

8 COMPONENTS

8 Fridge Exterior

9 Fridge Interior

10 INSTALLATION

10 Installation Overview

11 Unpacking Your Fridge

11 Choosing the Proper Location

11 - Flooring

12 - Ambient Temperature

12 - Measuring the Clearances

12 Removing/Refitting the Fridge Door

Handles

13 Removing/Refitting the Freezer Drawer

Handle

13 Removing/Refitting the Doors and

Drawers

14 - Removing the Left Fridge Door

15 - Removing the Right Fridge Door

16 - Refitting the Right Fridge Door

17 - Refitting the Left Fridge Door

18 - Removing the CustomChill™ Drawer

19 - Refitting the CustomChill™ Drawer

19 - Removing the Freezer Drawer

21 - Refitting the Freezer Drawer

22 Connecting the Water Line

22 - Before You Begin

22 Turning On the Power

23 Leveling and Door Alignment

23 - Leveling

23 - Door Alignment

24 HOW TO USE

24 Before Use

25 Control Panel

25 - Control Panel Features

27 In-Door Ice Bin

27 - Removing the In-Door Ice Bin

27 - Refitting the In-Door Ice Bin

28 Automatic Icemaker

- Turning the Automatic Icemaker On or Off

29 - When You Should Turn the Icemaker Off

29 - Normal Sounds You May Hear

29 - Preparing for Vacation

30 Ice and Water Dispenser

30 - Dispenser

30 - Using the Dispenser

30 - Locking the Dispenser

30 - Cleaning the Dispenser Stand

31 Storing Food

31 - Food Preservation Location

32 - Food Storage Tips

32 - Storing Frozen Food

33 Glide‘N’Access™

33 Extra Space

Removing and Refitting the Storage Bins

Door-In-Door

36 CustomChill™ Drawer

37 Adjusting the Fridge Shelves

38 MAINTENANCE

38 Cleaning

39 Replacing the Pure N Fresh Filter

39 Replacing the Water Filter

40 SMART DIAGNOSIS™

40 Using Smart Diagnosis™

41 TROUBLESHOOTING

• This product must only be used with a 240v 50Hz mains supply.

PRODUCT FEATURES

* Depending on the model, some of the following functions may not be available.

FILTERED WATER AND ICE DISPENSER

The water dispenser dispenses the plumbed, chilled water.

The ice dispenser dispenses cubed and crushed ice.

DOOR ALARM

The Door Alarm function sounds if a fridge door or freezer drawer remains

open. If a fridge door or freezer drawer is left open for more than 60

seconds, a warning alarm sounds at 30 second intervals

HUMIDITY CONTROLLED CRISPER

The Humidity Controlled Crisper is designed to help keep your fruits and

vegetables fresh and crisp.

CUSTOMCHILL™ DRAWER

The CustomChill™ Drawer provides storage space with a variable

temperature control that keeps the compartment either colder or warmer

than the rest of the fridge. Use it to store meat and seafood, cold drinks,

deli snacks, or chilled wine.

EXPRESS FREEZE

The freezer section is maintained at the coldest temperature for a 24-hour

period before automatically resuming normal operation. The freezer display

temperature will not change when Express Freeze is engaged. It will also

enhance ice production whilst it is on.

IMPORTANT SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.

This guide contains many important safety messages. Always

read and obey

all safety messages.

WARNING

Death or serious injury can occur if you do not follow instructions.

CAUTION

Indicates an imminently hazardous situation which, if not avoided, may result

in minor or moderate injury, or product damage.

WARNING

To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety

precautions should be followed, including the following:

Power

NEVER unplug your fridge by pulling on the power cord. Always grip the plug firmly and pull it straight

out from the outlet.

If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a

similarly qualified person in order to avoid a hazard. Do not use a cord that shows cracks or abrasion

damage along its length or at either the plug or connector end.

Do not use an uncertified power outlet.

Unplug the power plug immediately in the event of a blackout or thunderstorm.

Plug in the power plug with the power cord facing downward.

Installation

If unsure of any procedure, contact an authorized service center before you install or relocate the

fridge.

When moving your fridge away from the wall, be careful not to roll over or damage the power cord.

Prior to use, ensure that you are connecting this product to a dedicated, grounded electrical outlet

rated for use with this product (240V, 50Hz, AC only). It is the user’s responsibility to replace a

standard 2-prong wall outlet with a standard 3-prong wall outlet.

Do not install the fridge where there may be a danger of the unit falling.

During Use.

DO NOT allow children to climb, stand, or hang on the fridge doors or on the shelves in the fridge.

They could damage the fridge and seriously injure themselves.

Do not hang on to or place heavy objects on the fridge’s dispenser.

Do not place heavy or dangerous objects (bottles with liquid) on the fridge.

Do not put live animals inside the fridge.

Do not allow children to climb into the product when it is in use.

In the event of a gas leak (propane/LPG), ensure adequate ventilation and contact an authorized service

center before resuming use. Do not touch or disassemble the electric outlet of the fridge.

In the event of a refrigerant leak, move flammable objects away from the fridge. Ensure adequate

ventilation and contact an authorized service center.

Do not use or place flammable substances (chemicals, medicine, cosmetics, etc) near the fridge or

store them inside the fridge. Do not place the fridge in the vicinity of flammable gas.

This is the safety alert symbol. It alerts you to safety messages that inform you of

hazards that can cause serious injury and death, or cause damage to the product.

All safety messages will be preceded by the safety alert symbol and the hazard

signal word WARNING or CAUTION. These words mean:

IMPORTANT SAFETY INSTRUCTIONS

This product is not to be used for special purposes such as the storage of medicine or test materials

or for use on ships, etc.

Unplug the power plug before cleaning or repairing the fridge.

If the internal lighting is LED type, and becomes defective, it must only be replaced by an authorised

service provider.

Do not modify or extend the power cord.

Do not use a dryer to dry the interior. Do not light a candle to remove interior odors.

For your safety, this appliance must be properly grounded. Have the wall outlet and the circuit

checked by a qualified electrician to make sure the outlet is properly grounded.

Do not use an outlet that can be turned off with a switch. Do not use an extension cord. It is the

user’s responsibility to replace a standard 2-prong wall outlet with a standard 3-prong wall outlet.

Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.

Do not use an extension cord or a multi outlet power board when connecting the power cord to the

mains supply.

Disconnect the power cord immediately if you hear a noise, smell a strange odor or detect smoke

coming from the appliance.

Turn the power off if water or dust penetrates into the fridge. Call a service agent.

Do not disassemble or modify the fridge.

Do not put hands, feet, or metal objects below or behind the fridge.

Do not operate the fridge or touch the power cord with wet hands.

In fridges with automatic icemakers, avoid contact with the moving parts of the ejector mechanism or

with the heating element that releases the cubes. Do not place fingers or hands on the automatic ice-

making mechanism while the fridge is plugged in.

When dispensing ice from the dispenser, do not use crystal ceramics.

Do not touch the cold surfaces in the freezer compartment with wet or damp hands, when your

fridge is in operation.

Do not put glass containers, glass bottles or carbonated beverages in the freezer.

This appliance is not intended for use by persons (including children) with reduced physical, sensory

or mental capabilities, or lack of experience and knowledge, unless they have been given supervision

or instruction concerning the use of the appliance by a person responsible for their safety.

Do not refreeze frozen food that has thawed completely. Doing so may result in a serious health

issue.

If you are throwing away your old fridge, make sure the CFC refrigerant is removed for proper

disposal by a qualified servicer. If you release CFC refrigerant, you may be fined or imprisoned in

accordance with the relevant environmental law.

Junked or abandoned fridges are dangerous, even if they are sitting for only a few days. When

disposing of the fridge, remove the packing materials from the door or take off the doors but leave

the shelves in place so that children may not easily climb inside.

If connected to a circuit protected by fuses, use time delay fuse.

Do Not store or install the fridge outdoors or anywhere that is directly or indirectly exposed to

weathering conditions.

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.

To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety

precautions should be followed, including the following:

IMPORTANT SAFETY INSTRUCTIONS

CAUTION

Installation

The fridge must be properly installed in accordance with the Installer Instructions that were attached

to the front of the fridge.

Be careful when you unpack and install the fridge. Immediately dispose of plastic and other packing

materials out of reach of children.

The appliance must be positioned for easy access to a power source.

Do not store or install the fridge outdoors or anywhere that is directly or indirectly exposed to

weathering conditions. It should not be used for mobile applications.

During use.

Close the door carefully when children are around.

Keep fingers out of pinch point areas; clearances between the doors and cabinets are necessarily

small. Be careful closing doors when children are nearby.

If you store food improperly, be aware that it may fall and cause injury.

Do not use aerosols near the fridge.

Do not store articles on the top of the appliance.

Maintenance

Do not use strong detergents like wax or thinners for cleaning. Clean with a soft cloth.

Wipe foreign objects (such as dust and water) off the prongs of the power plug and contact areas

regularly.

Do not store, disassemble or repair the fridge by yourself.

Remove any dust or foreign matter from the power plug pins.

Do not use a wet or damp cloth when cleaning the plug.

If the fridge is disconnected from the power supply, you should wait for at least five minutes before

plugging it back in.

If you notice a chemical or burning plastic smell or see smoke, unplug the fridge immediately and

contact your LG Electronics Service Center.

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.

To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety

precautions should be followed, including the following:

IMPORTANT SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.

To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety

precautions should be followed, including the following:

SAVE THESE INSTRUCTIONS

This appliance contains a small amount of isobutane refrigerant (R600a), natural gas with high

environmental compatibility, but it is also combustible. When transporting and installing the

appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.

Refrigerant squirting out of the pipes could ignite or cause an eye injury. If a leak is detected,

avoid any naked flames or potential sources of ignition and air the room in which the appliance is

standing for several minutes.

In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating circuit

occurs, the size of the room in which the appliance may be sited depends on the amount of

refrigerant used. The room must be 1m

in size for every 8g of R600a refrigerant inside the

appliance. The amount of refrigerant in your particular appliance is shown on the identification

plate inside the appliance. Never start up an appliance showing any signs of damage. If in doubt,

consult your dealer.

WARNING

Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

Do not use mechanical devices or other means to accelerate the defrosting process, other than those

recommended by the manufacturer.

Do not damage the refrigerant circuit.

Do not use electrical appliances inside the food storage compartments of the appliance, unless they

are of the type recommended by the manufacturer.

The refrigerant and insulation blowing gas used in the appliance require special disposal procedures.

When disposal, please consult with service agent or a similarly qualified person.

COMPONENTS

Use this page to become more familiar with the parts and features of your fridge.

*The appearance and specifications of the actual product may differ depending on the model.

Fridge Exterior

Button

(Opens only the Door

in Door compartment)

Handle

Opens and closes

the door.

Filtered Water and

Ice Dispenser

Dispenses purified water and ice.

LED Display

Displays the fridge and freezer

temperature, the water filter

condition and the dispenser status.

Control Panel

Sets the fridge and freezer

temperatures, the water filter

condition and the dispenser mode.

Fridge

Preserves food.

Freezer

Preserves frozen food.

Ez Handle

Easily opens the freezer door

by levering upward.

LED Light

LED lights up when the

freezer door is opened.

CustomChill™

Drawer

COMPONENTS

Fridge Interior

Door-In-Door Case

A convenient storage area for

frequently-used items that require

easy access.

Adjustable Fridge Shelf

The shelves in your fridge are adjustable

to meet your individual storage needs.

Cheese & Butter Bin

Cheese & butter and

Condiment bins, that

are specially designed

for these items, making

spreading butter and

slicing cheese easier.

Condiment Bin

Pullout Drawer

Used for extra storage

within the freezer

compartment.

Extra Space

You can store small items,

or defrost an item.

Indoor Ice Bin

Ice cubes are

automatically produced.

Crisper

Helps vegetables and

fruits to stay crisp.

CustomChill™ Drawer

Variable temperature storage

that can be set either colder

or warmer than the rest of

the fridge. The CustomChill™

drawer is not intended for long-

term frozen storage.

Durabase® and Durabase® Divider

The Durabase is a storage space

recommended for the preservation of large

food items. The Durabase Divider is used

to organize the Durabase area into sections.

It can be adjusted from side to side to

accommodate items of different sizes.

LED interior lamps

The interior lamps light up

the inside of the fridge.

INSTALLATION

Installation Overview

Please read the following installation instructions first after purchasing this product or transporting

it to another location.

1 Unpacking your

fridge

2 Choosing the proper

location

3 Disassembling/Refitting

4 Connecting the water

supply and water line

5 Leveling and Door

Alignment

NOTE

Connect to potable water supply only.

INSTALLATION

Choosing the Proper Location

Select a place where a water supply can

be easily connected for the automatic

icemaker.

Unpacking Your Fridge

WARNING

Use two or more people to move and

install the fridge. Failure to do so can

result in back or other injury.

Your fridge is heavy. When moving the

fridge for cleaning or service, be sure to

protect the floor. Always pull the fridge

straight out when moving it. Do not

wiggle or walk the fridge when trying to

move it, as floor damage could occur.

Keep flammable materials and vapors,

such as gasoline, away from the fridge.

Failure to do so can result in fire,

explosion, or death.

Remove tape and any temporary labels from your

fridge before using. Do not remove any warning-

type labels, the model and serial number label, or

the bar coded labels on the side of the unit.

To remove any remaining tape or glue, rub the

area briskly with your thumb. Tape or glue residue

can also be easily removed by rubbing a small

amount of liquid dish soap over the adhesive with

your fingers. Wipe with warm water and dry.

Do not use sharp instruments, rubbing alcohol,

flammable fluids, or abrasive cleaners to remove

tape or glue. These products can damage the

surface of your fridge.

Fridge shelves are installed in the shipping

position. Please reinstall shelves according to

your individual storage needs.

The fridge should always be plugged

into its own individual properly grounded

electrical outlet rated for 240 Volts, 50 Hz,

AC only, and fused at 15 or 20 amperes.

This provides the best performance

and also prevents overloading house

wiring circuits which could cause a fire

hazard from overheated wires. It is

recommended that a separate circuit

serving only this appliance be provided.

WARNING

To reduce the risk of electric shock, do not

install the fridge in a wet or damp area.

NOTE

The water pressure must be 20~120

psi or 138~827 kPa or 1.4~8.4 kgf/cm²

on models without a water filter and

40~120 psi or 276~827 kPa or 2.8~8.4

kgf/cm² on models with a water filter.

Flooring

To avoid noise and vibration, the unit must be

leveled and installed on a solidly constructed

floor. If required, adjust the leveling legs to

compensate for unevenness of the floor. The

front should be slightly higher than the rear to

aid in door closing. Leveling legs can be turned

easily by tipping the cabinet slightly. Turn the

leveling legs to the left to raise the unit or to

the right to lower it. (See Leveling and Door

AlIgnment.)

NOTE

Installing on carpeting, soft tile surfaces,

a platform or weakly supported structure

is not recommended.

INSTALLATION

Ambient Temperature

Install this appliance in an area where the

temperature is between 13°C and 43°C. If the

temperature around the appliance is too low or

high, cooling ability may be adversely affected.

Measuring the Clearances

Too small of a distance from adjacent items

may result in lowered freezing capability and

increased electricity consumption charges.

Allow at least 60cm in front of the fridge to

open the doors, and no less than 5cm between

the back of the fridge and the wall.

5cm

60cm

Removing/Refitting the

Fridge Door Handles

Removing the Handles

Loosen the set screws with a

in.

Allen wrench and remove the handle.

Loosen the mounting fasteners that

connect to the fridge door and handle

using a

in. Allen wrench, and remove

the mounting fasteners.

Refitting the Handles

Assemble the mounting fasteners at

both ends of the handle using a

in.

Allen wrench.

Place the handle on the door by fitting

the handle footprints over the mounting

fasteners and tightening the set screws

with a

in. Allen wrench.

NOTE

When it is necessary to move the fridge

through a narrow opening, removing the

doors is the recommended procedure.

If it is necessary to remove the handles,

follow the directions below.

INSTALLATION

WARNING

If your entrance door is too narrow for

the fridge to pass through, remove the

fridge doors and move the fridge sideways

through the doorway.

Use two or more people to remove and

install the fridge doors. Failure to do so can

result in back or other injury.

Disconnect the electrical supply to the

fridge before installing. Failure to do so

could result in serious injury or death.

Do not put hands, feet or other objects

into the air vents or bottom of the fridge.

You may be injured or receive an electrical

shock.

Be careful when handling the hinge and

stopper, to avoid injury.

Remove food and bins before detaching the

doors and drawers.

Removing/Refitting the Doors

and Drawers. (Disconnect the

mains power before removing

any doors and drawers)

When it is necessary to move the fridge

through a narrow opening, removing the doors

is the recommended procedure.

WARNING

When removing or refitting handles

Hold the handle securely when removing

and refitting.

Do not swing the handle or allow children to

play with them, or use them for any other

purpose.

Always follow the above instructions when

removing or refitting the handles.

Make sure that there is not a gap between

the door and handle after refitting the

handle.

Removing/Refitting the

Freezer Drawer Handle

Removing the Handle

Loosen the set screws located on the

lower side of the handle with a

in. Allen

wrench and remove the handle.

Loosen the mounting fasteners that

connect to the

freezer drawer

and handle

using a

in.

Allen wrench,

and remove

the mounting

fasteners.

Refitting the Handle

Assemble the mounting fasteners at

both ends of the handle using a

in. Allen

wrench.

Place the handle on the door by fitting

the handle

footprints over

the mounting

fasteners and

tightening the

set screws

with a

in.

Allen wrench.

INSTALLATION

Removing the Left Fridge Door (turn

off the water supply to the Fridge

before commencing)

The water supply is connected to the

upper right part of the rear surface of the

fridge. Remove the ring in the joint area.

Hold the water supply connection and

gently push the Collet inward to detach the

water supply line as shown in

NOTE

Detachment of the water supply line is

applicable only when detaching the left

fridge door.

Collet

Remove the screw from the hinge

cover at the top of the fridge. Lift the hook

(not visible), located at the bottom of the

front side of the cover

with a flat-head

screwdriver.

Remove the cover and pull out the tube .

Disconnect all wire harnesses

Rotate the hinge lever counterclockwise

. Lift the top hinge free of the hinge

lever latch.

CAUTION

When lifting the hinge free of the latch, be

careful that the door does not fall forward.

Hinge Lever Latch

Lift the door from the middle hinge pin and

remove the door.

CAUTION

Place the door, inside facing up, on a

non-scratching surface. It is advisable to

carry out the removal and refitting process

with 2 people.

INSTALLATION

Removing the Right Fridge Door

Remove the top hinge cover screw .

Lift the hook (not visible), located at the

bottom of the front side of the cover

with a flat-head screwdriver.

Detach the wire harness .

CAUTION

When lifting the hinge free of the hinge

lever latch, be careful that the door

does not fall forward.

Hinge Lever Latch

Rotate the hinge lever clockwise.

Lift the top hinge

free of the hinge

lever latch.

Lift the door from the middle hinge pin and

remove the door.

CAUTION

Place the door, inside facing up, on a

non-scratching surface.

INSTALLATION

Install the right-side door first.

Make sure that the plastic sleeve is

inserted in the bottom of the door. Lower

the door onto the middle hinge pin as

shown in the figure.

Fit the hinge over the hinge lever latch

and slot it into place. Rotate the lever

counterclockwise to secure the hinge.

Refitting the Right Fridge Door

Hinge Lever Latch

Make sure that the door-switch located

inside the cover is tightly connected.

Position the cover in its place. Insert and

tighten the cover screw

Connect the wire harness .

INSTALLATION

Install the left fridge door after the right door is

installed.

Make sure that the plastic sleeve is

inserted in the bottom of the door. Install

the fridge door onto the middle hinge.

Fit the hinge over the hinge lever latch

and slot it into place. Rotate the lever

clockwise

and fasten the hinge.

Refitting the Left Fridge Door

Connect all the wire harnesses.

Hinge Lever Latch

Push the water supply tube into the hole

on the top case and pull it through the

backplate.

Hold the water supply connection and

gently push in the collet to connect the

water supply line as shown in

. Insert

the tube at least

inch (15 mm) into the

connector.

Make sure that the door-switch located

inside the cover is tightly connected. Place

the cover

in its position and tighten the

cover screw .

Collet

INSTALLATION

NOTE

1) Gently insert the tube until only one

line shows on the tube.

(Correct)

(Incorrect)

2) Pull the tube to make sure that the

tube is tightly fastened and then insert

the locking clip under the Collet.

Collet

Tube

Insert Line

Removing the CustomChill™ Drawer

Pull the drawer open to full extension.

Remove the basket by lifting the basket

from the rail system.

Hold both sides of the door and lift it to

remove it from the rail system.

Disconnect the wire harness connection

at the end of the right rail by pressing on

the tabs on either side. It may help to use

a small, flat-blade screwdriver to apply

pressure to the ends of the tabs on either

side.

NOTE

Before removing the CustomChill™

drawer, it must be disconnected from

the temperature control.

INSTALLATION

Refitting the CustomChill™ Drawer

Grasp the door on each side and lower it

into place on the rail system.

Pull the drawer open to full extension.

Lower the basket onto the rail system.

Reconnect the wire harness to the

connection at the end of the right rail by

aligning the two ends and pushing them

together until you hear a click. The tabs

should snap back into place. Tug gently to

make sure the connection is secure.

Pull the freezer drawer open to full extension.

Remove the top pullout drawer by first pulling

the drawer open to full extension.

On the left rail, use a flat blade screwdriver to

push in on the tab to release the drawer from

the rail, as shown below. Once the left side is

loose, push the tab on the right side with your

finger to release the drawer. Lift the front of

the drawer up, then pull it straight out.

CAUTION

Use two or more people to remove and

install the freezer drawer. Failure to do so

can result in back or other injury.

Do not hold the handle when removing

or replacing the drawer. The handle may

come off, causing personal injury.

Be careful of sharp hinges on both sides

of the drawer.

When you lay the drawer down, be

careful not to damage the floor.

Do not sit or stand on the freezer drawer.

To prevent accidents, keep children and

pets away from the drawer. Do not leave

the drawer open.

Removing the Freezer Drawer

NOTE

If you do not reconnect the wire

harness securely, the CustomChill™

drawer will not work properly.

INSTALLATION

Remove the middle drawer by pulling the

drawer out to full extension. Lift the front

of the drawer up, then pull it straight out.

Remove the Durabase by opening the

freezer drawer to full extension and lifting

the basket off of the rail assembly.

Remove the screws from the rails at both

ends.

With both hands, grip both sides of the

drawer and pull it up to remove it from the

rails.

With both hands, hold each rail and push

them in simultaneously.

CAUTION

Do not hold the handle when removing

or replacing the drawer. The handle may

come off and it could cause personal

injury.

INSTALLATION

Lower the door into final position and

tighten the screws located on both sides.

Insert the the top pullout drawer into the

frame, and push the drawer back into place

until you hear a click.

Slightly tilt up the front of the middle

drawer, insert the drawer into the frame,

and push it back into place.

Insert the lower basket in the rail

assembly.

Refitting the Freezer Drawer

With both hands, pull out each rail

simultaneously until both rails are fully

extended.

Grasp the drawer on each side and hook the

drawer supports into the rail tabs located on

both sides.

CAUTION

Do not hold the handle when removing

or replacing the drawer. The handle

may come off and it could cause

personal injury.

INSTALLATION

CAUTION

Wear eye protection during installation

to prevent injury.

Connecting the Water Line

Before You Begin

This water line installation is not covered by the

fridge warranty. Follow these instructions carefully

to minimize the risk of expensive water damage.

If you are not confident or unsure about connecting

to a water supply, then a Licensed plumber

should be called. This cost is not covered by the

manufacturer.

Water hammer (water banging in the pipes) in

house plumbing can cause damage to fridge parts

and can lead to water leakage or flooding. Call a

qualified plumber to correct water hammer before

installing the water supply line to the fridge.

If you use your fridge before connecting the

water line, make sure the icemaker power

switch is in the OFF (O) position.

Water Pressure

The water pressure must be 20~120 psi or

138~827 kPa or 1.4~8.4 kgf/cm² on models

without a water filter and 40~120 psi or 276~827

kPa or 2.8~8.4 kgf/cm² on models with a water

filter.

If a reverse osmosis water filtration system is

connected to your cold water supply, this water

line installation is not covered by the fridge

warranty. Follow the instructions carefully to

minimize the risk of expensive water damage.

If a reverse osmosis water filtration system is

connected to your cold water supply, the water

pressure to the reverse osmosis system needs

to be a minimum of 40 to 60 psi (276~414 kPa or

2.8~4.2 kgf/cm², less than 3.0~5.0 sec. to fill a

cup with a 200ml capacity).

If the water pressure from the reverse osmosis

system is less than 20 psi or 138 kPa or

1.4 kgf/cm² (takes more than 5.0 sec to fill a cup

with a 200ml capacity):

Check to see if the sediment filter in

the reverse osmosis system is blocked.

Replace the filter if necessary.

Allow the storage tank on the reverse

osmosis system to refill after heavy

usage.

If the issue concerning water pressure

from reverse osmosis remains, call a

licensed, qualified plumber.

All installations must be in accordance

with local plumbing code requirements.

CAUTION

Do not install the icemaker tubing in

areas where temperatures fall below

freezing.

CAUTION

To prevent burns and product damage,

only connect the fridge water line to a

cold water supply.

Turning On The Power

Plug in the fridge.

CAUTION

Connect to a rated power outlet.

Have a certified electrician check

the wall outlet and wiring for proper

grounding.

Do not damage or cut off the ground

terminal of the power plug.

(Your plug type might be different

from the picture.)

INSTALLATION

Leveling and Door Alignment

Leveling

After installing, plug the fridge’s power cord

into a 3-prong grounded outlet and push the

fridge into the final position being careful not

to crush the power cord under the unit or its

wheels.

Your fridge has two front leveling legs—one on

the right and one on the left. Adjust the legs to

alter the tilt from front-to-back or side-to-side.

If your fridge seems unsteady, or you want the

doors to close more easily, adjust the fridge’s

tilt using the instructions below:

Turn the leveling leg to the left to raise that

side of the fridge or to the right to lower it.

It may take several turns of the leveling leg

to adjust the tilt of the fridge.

Open both doors again and check to make

sure that they close easily. If the doors do

not close easily, tilt the fridge slightly more

to the rear by turning both leveling legs to

the left. It may take several more turns,

and you should turn both leveling legs the

same amount.

NOTE

A flare nut spanner works best, but an

open-end spanner will suffice.

Do not over-tighten.

Door Alignment

The left fridge door has an adjustable nut, located

on the bottom hinge, to raise and lower the door

for proper alignment.

If the space between your doors is uneven, follow

the instructions below to align the doors:

Use the spanner (included with the Use & Care

Guide) to turn the nut in the door hinge to adjust

the height. To the right to raise or to the left to

lower the height.

The right fridge door does not have an adjustable

nut.

If the space between your doors is uneven, follow

the instructions below to align the right door:

With one hand, lift up both the inner and

outer door sections of the right door to raise

them at the middle hinge. (Opening the door

may make lifting it easier)

With the other hand, use pliers to insert the

snap ring on the middle hinge of the inner

door section as shown. Do not insert the ring

on the hinge of the outer door section.

Insert additional snap rings until the right door

is aligned. (Two snap rings are provided with

the unit.)

Outer

Door

Inner

Door

HOW TO USE

Before use

Clean the fridge.

Clean your fridge thoroughly and wipe off all dust that accumulated during shipping.

NOTE

Remove adhesive residue by wiping it off with your thumb or dish detergent.

CAUTION

Do not scratch the fridge with a sharp object or use a detergent that

contains alcohol, a flammable liquid or an abrasive when removing any tape

or adhesive from the fridge,.

Do not peel off the model or serial number label or the technical information

on the rear surface of the fridge.

Connect the power supply.

Check if the power supply is connected before use.

Read the “Turning On The Power” section. (Your plug type might be different from

the picture.)

CAUTION

Running the automatic icemaker before connecting it to the water

supply may cause the fridge to malfunction.

Turn off the icemaker if the fridge is not yet connected to the

water supply.

Turn off the automatic icemaker and then plug the power plug of the fridge into the

grounded electric outlet.

* This is applicable only to certain models.

CAUTION

Putting food in the fridge before it has cooled could cause the food to

spoil, or a bad odor could linger inside the fridge.

Wait for the fridge to cool.

Allow your fridge to run for at least two to three hours before putting food in it.

Check the flow of cold air in the freezer compartment to ensure proper cooling.

The fridge makes a loud noise after initial operation.

This is normal. The general noise levels will decrease as the temperature lowers.

Open fridge doors and freezer drawers to ventilate the interior.

The inside of the fridge may smell like plastic at first. Remove any adhesive tape

from inside the fridge and open the fridge doors and the freezer drawers for one to

two hours before turning on.

HOW TO USE

NOTE

The displayed temperature is the target

temperature, and not the actual temperature

of the fridge. The actual fridge temperature

depends on the food inside the fridge.

Control Panel

* Depending on the model, some of the following functions may not be available.

Control Panel Features

LED Display

Indicator

Control

Button

Ice Type

Press the Ice Type button to choose either cubed

or crushed ice. The cubed or crushed ice icon will

illuminate.

Fridge Temperature

Indicates the target temperature of the fridge

compartment in Celsius (°C).

Freezer Temperature

Indicates the target temperature of the freezer

compartment in Celsius (°C).

Pure N Fresh

The Pure N Fresh helps remove odors from the

fridge. The Pure N Fresh has two settings, Auto

and Power(PWR). In Auto mode, the Pure N Fresh

will cycle on and off in increments of ten minutes

on and one hundred ten minutes off. If set to the

Power(PWR) mode, the Pure N Fresh will stay on

continuously for four hours, cycling on and off in

increments of ten minutes on and five minutes

off. After four hours, the Pure N Fresh will switch

back to Auto mode.

Press the Pure N Fresh button once for

Power(PWR) mode.

Press the Pure N Fresh button again to

switch back to Auto mode.

[

]

( On some

models)

HOW TO USE

Change Filter

When the Change Filter icon turns on, the air filter

needs to be replaced. After replacing the air filter,

press and hold the Pure N Fresh button for three

seconds to turn the icon light off. Change the air

filter approximately every 6 months.

Control Panel Features (continued)

Express Freeze

This function increases both ice making and

freezing capabilities.

When you touch the

Express Freeze

button,

the graphic will illuminate in the display and

will continue for 24 hours. The function will

automatically shut off after 24 hours.

You can stop this function manually by touching

the button one more time.

Light

When you press the Light button, the dispenser

light will turn on and the indicator will appear on

the LED display.

Change Water Filter

When the water filter indicator turns on, it is

recommended to change the water filter. After

changing the water filter, press and hold the

Change Filter button for three seconds to turn the

indicator light off. You should change the water

filter approximately every six months or when the

water quality or the flow is reduced. To clear the

water filter indicator, touch the LIGHT / WATER

FILTER button for 3 seconds whilst the display

panel is illuminated.

Door Alarm

When power is connected to the fridge, the

door alarm is initially set to ON. When you press

the

Alarm

button, the display will change to OFF

and the

Door Alarm

function will deactivate.

When either the fridge or the freezer door is left

open for more than 60 seconds, the alarm tone

will sound to let you know that the door is open.

When you close the door, the door alarm will

stop.

Lock

The Lock function disables every other button

on the display panel. it does not lock or stop

the water or ice dispenser functions.

When power is initially connected to the

fridge, the

Lock

function is off.

If you want to activate the

Lock

function to

lock other buttons, press and hold the

Lock

button for three seconds or more. The

Lock

icon will display and the

Lock

function is now

enabled.

To disable the

Lock

function, press and hold

the

Lock

button for approximately three

seconds.

Power Saving Mode

When the fridge is in the

Power Saving Mode

the display will remain off until a door is

opened or a button is pressed. Once on,

the display will remain on for 20 seconds.

To change any settings, the display must be

illuminated before it will respond. Pressing a

button is required to re activate the display

before making setting changes.

[

]

( On some

models)

CAUTION

Display Mode (For Store Use Only)

The Display Mode disables all cooling in

the fridge and freezer sections to conserve

energy while on display in a retail store. When

activated, OFF will display on the control panel

and the display will remain on for 20 seconds.

To deactivate / activate:

With either fridge door opened, press and hold

the Fridge and press Express Freeze button

3times. The control panel will beep and the

temperature settings will display to confirm

that Display Mode is deactivated. Use the

same procedure to activate the Display Mode.

HOW TO USE

Ice-detecting

sensor

CAUTION

When handling the ice bin,

keep hands away from the

icemaker tray area to avoid

personal injury.

In-Door Ice Bin

* Depending on the model, some of the

following functions may not be available.

Removing the In-Door Ice Bin

Gently pull the handle to open the ice

compartment.

To remove the in-door ice bin, grip the

front handle, slightly lift the lower part,

and slowly pull out the bin as shown.

Refitting the In-Door Ice Bin

Carefully insert the in-door ice bin while

slightly slanting it to avoid contact with the

icemaker.

Avoid touching the ice-detecting sensor

when replacing the ice bin. See the label

on the ice compartment door for details.

CAUTION

Keep hands and tools out of the ice

compartment door and dispenser chute.

Failure to do so may result in damage or

personal injury.

The icemaker will stop producing ice when

the in-door ice bin is full. If you need more

ice, empty the ice bin into the extra ice bin

in the freezer compartment. During use,

the ice can become uneven causing the

icemaker to misread the amount of ice

cubes and stop producing ice. Shaking the

ice bin to level the ice within it can reduce

this problem.

Storing cans or other items in the ice bin will

damage the icemaker.

Keep the ice compartment door closed

tightly. If the ice compartment door is not

closed tightly, the cold air in the ice bin

will freeze food in the fridge compartment.

This could also cause the icemaker to stop

producing ice.

If the O

N/OFF switch on the icemaker is set

to OFF for an extended period of time, the

ice compartment will gradually warm up to

the temperature of the fridge compartment.

To prevent ice cubes from melting and

leaking from the dispenser, ALWAYS empty

the ice bin when the icemaker is set to OFF

for more than a few hours.

HOW TO USE

Automatic Icemaker

* Depending on the model, some of the

following functions may not be available.

Ice is made in the automatic icemaker and sent

to the dispenser. The icemaker will produce

50~140 cubes in a 24-hour period, depending

on freezer compartment temperature, room

temperature, number of door openings and

other operating conditions.

It takes about 12 to 24 hours for a newly

installed fridge to begin making ice. Wait 72

hours for full ice production to occur.

Ice making stops when the in-door ice bin

is full. When full, the in-door ice bin holds

approximately 6 to 8 glasses of ice.

The water pressure must be 20~120 psi or

138~827 kPa or 1.4~8.4 kgf/cm² on models

without a water filter and 40~120 psi or

276~827 kPa or 2.8~8.4 kgf/cm² on models

with a water filter to produce the normal

amount and size of ice cubes.

Foreign substances or frost on the ice-

detecting sensor can interrupt ice production.

Make sure the sensor area is clean at all times

for proper operation.

Ice-detecting

Sensor

Power

Switch

Icemaker

Turning the Automatic Icemaker

On or Off

To turn off the automatic icemaker, set the

icemaker switch to

OFF (O)

. To turn on the

automatic icemaker, set the switch to

ON (I)

It is recommended to turn the switch to the

OFF position when the fridge is not connected

to a water supply. It will also prevent

unnecessary noises.

WARNING

Personal Injury Hazard

DO NOT place fingers or hands on the

automatic ice making mechanism while the

fridge is plugged in.

1 hour later from

supplying water

Tilting

Water fills the ice tray.

60 minutes after water has been added

to the ice tray, the ice tray will sit slightly

tilted to help the cold air reach the ice.

The ice-detecting sensors will sense

when the ice is ready to be dumped

into the ice bin.

HOW TO USE

Automatic Icemaker

(continued)

The first ice and water dispensed may

include particles or odor from the water

supply line or the water tank.

Throw away the first few batches of ice.

This is also necessary if the fridge has not

been used for a long time.

Never store beverage cans or other items in

the ice bin for the purpose of rapid cooling.

Doing so may damage the icemaker or the

containers may burst.

If discolored ice is dispensed, check the

water filter and water supply. If the problem

continues, contact a qualified service

center. Do not use the ice or water until the

problem is corrected.

Keep children away from the dispenser.

Children may play with or damage the

controls.

The ice passage may become blocked with

frost if only crushed ice is used. Remove the

frost that accumulates by removing the ice

bin and clearing the passage with a rubber

spatula. Dispensing cubed ice can also help

prevent frost buildup.

Never use thin crystal glass or crockery to

collect ice. Such containers may chip or

break resulting in glass fragments in the ice.

Dispense ice into a glass before filling it

with water or other beverages. Splashing

may occur if ice is dispensed into a glass

that already contains liquid.

Never use a glass that is exceptionally

narrow or deep. Ice may jam in the ice

passage and fridge performance may be

affected.

Keep the glass at a proper distance from

the ice outlet. A glass held too close to the

outlet may prevent ice from dispensing.

To avoid personal injury, keep hands out of

the ice door and passage.

Never remove the dispenser cover.

If ice or water dispenses unexpectedly, turn

off the water supply and contact a qualified

service center.

CAUTION

When You Should Turn the

Icemaker Off

When the water supply will be shut off

for several hours.

When the ice bin is removed for more

than one or two minutes.

When the fridge will not be used for

several days.

Normal Sounds You May Hear

The icemaker water valve will buzz as

the icemaker fills with water. If the

power switch is in the ON (I) position,

it will buzz even if it has not yet been

connected to water. To stop the buzzing,

move the power switch to OFF (O).

You will hear the sound of cubes

dropping into the bin and water running

in the pipes as the icemaker refills.

Preparing for Vacation

Set the icemaker power switch to OFF (O) and

shut off the water supply to the fridge.

If the ambient temperature is expected to drop

below freezing, have a qualified technician

drain the water supply system to prevent

serious property damage due to flooding

caused by ruptured water lines or connections.

NOTE

The ice bin should be emptied when the

icemaker on/off switch is turned to the

OFF

position.

NOTE

Keeping the power switch in the ON

(I) position before the water line is

connected can damage the icemaker.

NOTE

The ice bin should be emptied anytime

the icemaker on/off switch is turned to

the OFF (O) position.

HOW TO USE

Ice and Water Dispenser

* Depending on the model, some of the

following functions may not be available.

CAUTION

Keep children away from the dispenser

to prevent children playing with or

damaging the controls.

Dispenser

Ice switch

Stand

Water switch

Using the Dispenser

To dispense

cold

water

, push on the

water switch with a glass.

To dispense

ice

, push on the ice switch

with a glass.

NOTE

If discolored ice is dispensed, check

the water filter and water supply. If the

problem continues, contact a qualified

service center. Do not use the ice or

water until the problem is corrected.

The dispenser will not operate when

either of the fridge doors are open.

If dispensing water or ice into a container

with a small opening, place it as close to

the dispenser as possible.

Some dripping may occur after

dispensing. Hold your cup beneath

the dispenser for a few seconds after

dispensing to catch all of the drops.

Incorrect Way Correct Way

Water

Ice

CAUTION

Throw away the first few batches of ice

(about 24 cubes). This is also necessary

if the fridge has not been used for a

long time.

Cleaning the Dispenser Stand

Grip the stand with both hands and pull it

out.

Wipe out dirty areas with a clean cloth.

HOW TO USE

Storing Food

Food Preservation Location

Each compartment inside the fridge is designed to store different types of food.

Store your food in the optimal space to enjoy the freshest taste.

NOTE

If you are leaving home for a short period of time, like a short vacation, the fridge should be

left on. Refrigerated foods that are able to be frozen will stay preserved longer if stored in the

freezer.

If you are leaving the fridge turned off for an extended period of time, remove all food and

unplug the power cord. Clean the interior, and leave the door open to prevent fungi from

growing in the fridge.

Adjustable fridge shelf

Adjustable shelves to meet

your individual storage needs.

CustomChill™ Drawer

Adjust the temperature to store

meat and seafood, cold drinks,

deli snacks, or chilled wine.

Door-in-Door

Recommended types of food

to store in the Door-In-Door

section are butter, margarine,

cream cheese, peanut butter,

ketchup, mustard, relish, etc.

Vegetable storage

(Crisper)

Preserves vegetables

and fruit.

Durabase

Largest storage space in

the freezer.

Extra Space

You can store small

items, or put an item to

defrost.

CAUTION

Do not store food with high moisture content towards the top of the fridge. The moisture could

come in direct contact with the cold air and freeze.

Wash food before storing it in the fridge. Vegetables and fruit should be washed, and food

packaging should be wiped down to prevent adjacent foods from being contaminated.

If the fridge is kept in a hot and humid place, frequent opening of the door or storing a lot of

vegetables in the fridge may cause condensation to form. Wipe off the condensation with a clean

cloth or a paper towel.

If the fridge door or freezer drawer is opened too often, warm air may penetrate the fridge and raise

its temperature. It can also increase the cost to run the appliance.

Do not overfill or pack items too tightly into door bins. Doing so may cause damage to the bin or

personal injury if items are removed with excessive force.

The temperature inside the Extra Space is slightly lower than in the shelf or door bin area.

HOW TO USE

Food Storage Tips

* The following tips may not be applicable

depending on the model.

Wrap or store food in the fridge in airtight and

moisture-proof material unless otherwise noted.

This prevents food odor and taste transfer

throughout the fridge. For dated products, check

date code to ensure freshness.

Food How to

Butter or

Margarine

Keep opened butter in a covered

dish or closed compartment.

When storing an extra supply,

wrap in freezer packaging and

freeze.

Cheese

Store in the original wrapping

until you are ready to use it.

Once opened, rewrap tightly in

plastic wrap or aluminum foil.

Milk Wipe milk cartons. For coldest

milk, place containers on

interior shelf.

Eggs Store in original carton on

interior shelf, not on door shelf.

Fruit Do not wash or hull the fruit

until it is ready to be used. Sort

and keep fruit in its original

container, in a crisper, or store

in a completely closed paper

bag on a fridge shelf.

Leafy

Vegetables

Remove store wrapping and

trim or tear off bruised and

discolored areas. Wash in cold

water and drain. Place in plastic

bag or plastic container and

store in crisper.

Vegetables

with skins

(carrots,

peppers)

Place in plastic bags or plastic

container and store in crisper.

Fish Store fresh fish and shellfish

in the freezer section if they

are not being consumed the

same day of purchase. It is

recommended to consume

fresh fish and shellfish the

same day purchased.

Leftovers

Cover leftovers with plastic wrap

or aluminum foil, or store in

plastic containers with tight lids.

Storing Frozen Food

Freezing

Your freezer will not quick-freeze a large

quantity of food. Do not put more unfrozen

food into the freezer than will freeze within

24 hours (no more than 2 to 3 lbs. of food per

cubic foot of freezer space). Leave enough

space in the freezer for air to circulate around

packages. Be careful to leave enough room at

the front so the door can close tightly.

Storage times will vary according to the quality

and type of food, the type of packaging or wrap

used (how airtight and moisture-proof) and

the storage temperature. Ice crystals inside a

sealed package are normal. This simply means

that moisture in the food and air inside the

package have condensed, creating ice crystals.

NOTE

Check a freezer guide or a reliable cookbook

for further information about preparing food

for freezing or food storage times.

NOTE

Allow hot foods to cool at room temperature

for 30 minutes, then package and freeze.

Cooling hot foods before freezing saves

energy. Never freeze or store sealed glass

bottles or beverage cans in the freezer as they

may explode.

HOW TO USE

Glide‘N’Access™

The Glide’N’Access™ slides out for easy loading

of large items, like sheet cakes or deli trays, and

to give you easy access to items stored at the

back of the shelf.

To slide out, grasp the handle at the front of the

shelf and gently pull forward. Push back to slide

in.

Storing Frozen Food (continued)

Packaging

Successful freezing depends on correct

packaging. When you close and seal the

package, it must not allow air or moisture in or

out. If it does, you could have food odor and

taste transfer throughout the fridge and could

also dry out frozen food.

Packaging recommendations:

Rigid plastic containers with tight-fitting

lids

Straight-sided canning/freezing jars

Heavy-duty aluminum foil

Plastic-coated paper

Non-permeable plastic wraps

Specified freezer-grade self-sealing plastic

bags

Follow package or container instructions for

proper freezing methods.

Do not use

Bread wrappers

Non-polyethylene plastic containers

Containers without tight lids

Wax paper or wax-coated freezer wrap

Thin, semi-permeable wrap

Extra Space

The Extra Space compartments are slightly

cooler than the shelf or door bin areas, so they

are a convenient place to store dairy snacks or

other small items you want to keep especially

cold. They are also a handy place to defrost

meat.

Open and close by pulling the handle.

CAUTION

Take care when sliding the

Glide'N'Access™ in and out, as taller

items may fall, causing damage or injury.

HOW TO USE

Removing and Refitting the

Storage Bins

Glide‘N’Access™ Crisper

To remove the Glide‘N’Access™ Crisper, pull

out the Crisper to full extension, lift the front

up, and pull straight out.

To refit, slightly tilt up the front, insert the

drawer into the frame and push it back into

place.

To Remove Glide‘N’Access™

To remove the Glide‘N’Access™, pull out the

shelf to full extension, lift the front up and pull

straight out.

Door Bins

The door bins are removable for easy cleaning

and adjustment.

To remove the bin, simply lift the bin up

and pull straight out.

To replace the bin, slide it in above the

desired support and push down until it

snaps into place.

NOTE

Some bins may vary in appearance and

will only fit in one location.

CAUTION

Do not apply excessive force while

removing or refitting the storage bins.

Do not use the dishwasher to clean

the storage bins and shelves.

Regularly remove and wash the

storage bins and shelves; they can

become easily contaminated by the

food.

HOW TO USE

To remove the Door-In-Door case, lift up

and pull out.

To replace the Door-In-Door case, line up

the tabs on the Door-In-Door Case with

the slots on the door and push the case

down until it snaps into place.

Door-In-Door Case

To open the Door-In-Door case, slightly push

the marked area to pop it open. The Door-In-

Door Case is removable for easy cleaning and

adjustment.

Door-In-Door

Door-In-Door Compartment

To access the Door-in-Door compartment, gently

press the button on the right fridge door handle to

open the door.

It is not necessary to grip the

door handle when pressing

the button to open the Door-

In-Door compartment.

If the handle is gripped when

the button is pressed you

may hear a clicking noise.

This is normal.

Door-In-Door Door Bins

The Door-In-Door inner and outer door bins are

removable for easy cleaning.

To remove the door bins, lift up and pull

out.

To replace the door bins, slide the door

bin in above the desired support and push

down until it snaps into place.

HOW TO USE

CustomChill™ Drawer

The CustomChill™ Drawer provides storage

space with a variable temperature control that

can be adjusted to keep the compartment

either slightly colder or warmer than the fridge.

Setting the Temperature

Press the Select/Lock button repeatedly to

toggle through the four temperature settings.

Store meat and seafood at -1°C, cold drinks at

1°C, deli snacks at 3°C, or chilled wine at 5°C.

Control Lock

The control panel can also be locked to prevent

the temperature from accidentally being

changed or tampered with by children. To

lock the panel, press and hold the Select/Lock

button for three seconds until the Lock icon

lights up. To unlock the panel, press and hold

the Select/Lock button until the Lock icon light

turns off.

Control Panel

NOTE

Do not store beverages at -1 deg

setting. They may freeze and explode.

HOW TO USE

Adjusting the Fridge Shelves

The shelves in your fridge are adjustable to

meet your individual storage needs. Your

model may have glass or wire shelves.

Adjusting the shelves to fit items of different

heights will make finding the exact item you

want easier. Doing so will also reduce the

amount of time the fridge door is open which

will save energy.

Removing the Shelf

Tilt up the front of the shelf and lift it straight

up. Pull the shelf out.

Refitting the Shelf

Tilt the front of the shelf up and guide the shelf

hooks into the slots at a desired height. Then,

lower the front of the shelf so that the hooks

drop into the slots.

Using the Folding Shelf

You can store taller items, such as a gallon

container or bottles, by simply pushing the

front half of the shelf underneath the back half

of the shelf. Pull the front of the shelf toward

you to return to a full shelf.

CAUTION

Do not clean glass shelves with

warm water while they are cold.

Shelves may break if exposed to

sudden temperature changes or

impact.

Glass shelves are heavy. Use special

care when removing them.

CAUTION

Make sure that shelves are level from

one side to the other. Failure to do so

may result in the shelf falling or spilling

food.

MAINTENANCE

Cleaning

Both the fridge and freezer sections defrost automatically; however, clean both sections

about once a month to prevent odors.

Wipe up spills immediately.

Always unplug the fridge before cleaning.

General Cleaning Tips

Unplug fridge or disconnect power.

Remove all removable parts, such as

shelves, crispers, etc.

Use a clean sponge or soft cloth and a

mild detergent in warm water. Do not

use abrasive or harsh cleaners.

Hand wash, rinse and dry all surfaces

thoroughly.

Exterior

Waxing external painted metal surfaces helps

provide rust protection. Do not wax plastic

parts. Wax painted metal surfaces at least

twice a year using appliance wax (or auto paste

wax). Apply wax with a clean, soft cloth.

For products with a stainless steel exterior,

use a clean sponge or soft cloth and a mild

detergent in warm water. Do not use abrasive

or harsh cleaners. Dry thoroughly with a soft

cloth.

Inside Walls (allow freezer to warm

up so the cloth will not stick)

To help remove odors, you can wash the inside

of the fridge with a mixture of baking soda

and warm water. Mix 2 tablespoons of baking

soda to 1 quart of water (26 g soda to 1 liter

water) Be sure the baking soda is completely

dissolved so it does not scratch the surfaces of

the fridge.

Door Liners and Gaskets

Use a clean sponge or soft cloth and a mild

detergent in warm water. Do not use cleaning

waxes, concentrated detergents, bleaches, or

cleaners containing petroleum on plastic fridge

parts.

Plastic Parts (covers and panels)

Use a clean sponge or soft cloth and a mild

detergent in warm water. Do not use glass

cleaners, abrasive cleansers, or flammable

fluids. These can scratch or damage the

material.

Condenser Coils

Use a vacuum cleaner with an attachment to

clean the condenser cover and vents. Do not

remove the panel covering the condenser coil

area.

CAUTION

Do not use a rough cloth or sponge

when cleaning the interior and exterior

of the fridge.

Do not place your hand on the bottom

surface of the fridge when opening

and closing.

WARNING

Use non-flammable cleaner. Failure to do

so can result in fire, explosion, or death.

MAINTENANCE

Install a New Pure N Fresh Filter.

Place the new filter inside of the cover with

the side that says “Front” facing outward.

Then refit and turn the filter cover to the right

to secure it to the fridge wall.

After changing the filter, push and hold the

Pure N Fresh button for three seconds to

reset the filter sensor.

Replacing the Pure N Fresh Filter

It is recommended that you replace the Pure N

Fresh Filter:

Approximately every six months.

When the CHANGE FILTER light turns on.

Remove the Old Filter

Turn the filter cover to the left to detach

from the fridge wall. The filter is located on

the inside of the filter cover. Remove the

filter from the cover and replace it with a

new filter.

Replacing the Water Filter

It is recommended that you replace the water filter:

Approximately every six months.

When the water filter indicator turns on.

When the water dispenser output decreases.

When the ice cubes are smaller than normal.

Assemble the door bin. When a new filter is

inserted the water may appear to be clouded.

flush through at least 3 glasses of water.

Even though safe to

drink, the cloudiness will

eventually disappear once

all of the air in the filter

has been passed through.

Remove the old water filter.

Lift up and remove the lower door bin on the

Left hand fridge door. Swing the right end

of the water filter out of the compartment

and then grasp and rotate the filter

counterclockwise to remove it from the filter

head.

NOTE

Replacing the water filter could cause a

small amount of water to drain. Place a cup

under the filter head to catch any water.

NOTE

This fridge does not require a filter bypass

plug when the filter is not in place.

Replace with a new water filter.

Insert the new filter into the filter head and

rotate it clockwise until the arrow on the

new filter lines up with the arrow on the

filter head. Swing the filter back into the

compartment.

SMART DIAGNOSIS

Hold the mouthpiece

of your phone in front

of the speaker that is

located on the right

hinge of the fridge

door, when instructed

to do so by the call

center.

Press and hold

the Freezer button

for three seconds

while continuing

to hold your phone

to the speaker.

After you hear three beeps, release the

Freezer button.

Keep the phone in place until the tone

transmission has finished. This takes about

6 seconds, and the display will count down

the time. Once the countdown is over

and the tones have stopped, resume your

conversation with the specialist, who will then

be able to assist you in using the information

transmitted for analysis.

Should you experience any problems with your

fridge, it has the capability of transmitting data

via your telephone to the LG service center.

This allows you to speak directly to our trained

specialists. The specialist records the data

transmitted from your machine and uses it to

analyze the issue, providing a fast and effective

diagnosis.

If you experience problems with your fridge,

call to the LG service center. Only use the

Smart Diagnosis™ feature when instructed

to do so by the LG call center agent. The

transmission sounds that you will hear are

normal and sound similar to a fax machine.

Smart Diagnosis™ cannot be activated

unless your fridge is connected to power.

If your fridge is unable to turn on, then

troubleshooting must be done without using

Smart Diagnosis™.

Using Smart Diagnosis™

First, call to the LG service center. Only use

the Smart Diagnosis feature when instructed

to do so by the LG call center agent.

Lock the display. To lock the display,

press and hold the Lock button for three

seconds. (If the display has been locked

for over five minutes, you must deactivate

the lock and then reactivate it.)

Open the right fridge door.

SMART DIAGNOSIS

NOTE

For best results, do not move the phone

while the tones are being transmitted.

If the call center agent is not able to get

an accurate recording of the data, you

may be asked to try again.

NOTE

Call quality differences by region may

affect the function.

Use a land line rather than a cell phone

for better communication performance,

resulting in better service.

Bad call quality may result in poor data

transmission from your phone to the

machine, which could cause Smart

Diagnosis™ to malfunction.

TROUBLESHOOTING

Review the Troubleshooting section before calling for service; doing so will save you both time

and money.

Problem Possible Causes Solutions

Fridge and

Freezer section

are not cooling.

The fridge control is set to OFF

(some models).

Turn the control ON. Refer to the Setting the

Controls section for proper temperature settings.

Fridge is in the defrost cycle. During the defrost cycle, the temperature of

each compartment may rise slightly. Wait 30

minutes and confirm the proper temperature

has been restored once the defrost cycle has

completed.

Fridge was recently installed. It may take up to 24 hours for each compartment

to reach the desired temperature.

Fridge was recently relocated. If the fridge was stored for a long period of

time or moved on its side, it is necessary for

the fridge to stand upright for 24 hours before

connecting it to power.

Cooling System

runs too much.

Fridge is replacing an older

model.

Modern fridges require more operating time

but use less energy due to more efficient

technology.

Fridge was recently plugged in

or power restored.

The fridge will take up to 24 hours to cool

completely.

Door opened often or a large

amount of food / hot food was

added.

Adding food and opening the door warms the

fridge, requiring the compressor to run longer in

order to cool the fridge back down. In order to

conserve energy, try to get everything you need

out of the fridge at once, keep food organized so

it is easy to find, and close the door as soon as

the food is removed. (Refer to the Food Storage

Guide.)

Doors are not closed

completely.

Check that food items are not obstructing the

door from closing then firmly push the doors

shut.

Fridge is installed in a hot

location.

The compressor will run longer under warm

conditions. At normal room temperatures (21°C)

expect your compressor to run about 40% to

80% of the time. Under warmer conditions,

expect it to run even more often. The fridge

should not be operated above 43°C.

Condenser / back cover is

clogged.

Use a vacuum cleaner with an attachment to

clean the condenser cover and vents. Do not

remove the panel covering the condenser coil

area.

TROUBLESHOOTING

Problem Possible Causes Solutions

Fridge or Freezer

section is too

warm.

Fridge was recently installed. It may take up to 24 hours for each compartment

to reach the desired temperature.

Air vents are blocked. Rearrange items to allow air to flow throughout

the compartment. Refer to the Airflow diagram in

the Using Your Fridge section.

Doors are opened often or for

long periods of time.

When the doors are opened often or for long

periods of time, warm, humid air enters the

compartment. This raises the temperature and

moisture level within the compartment. To lessen

the effect, reduce the frequency and duration of

door openings.

Unit is installed in a hot location. The fridge should not be operated in

temperatures above 43°C.

A large amount of food or

hot food was added to either

compartment.

Adding food warms the compartment requiring

the cooling system to run. Allowing hot food to

cool to room temperature before putting it in the

fridge will reduce this effect.

Doors not closed correctly. See the Doors will not close correctly or pop

open section in Troubleshooting.

Temperature control is not set

correctly.

If the temperature is too warm, adjust the

control one increment at a time and wait for the

temperature to stabilize. Refer to the Setting the

Controls section for more information.

Defrost cycle has recently

completed.

During the defrost cycle, the temperature of each

compartment may rise slightly and condensation

may form on the back wall. Wait 30 minutes

and confirm the proper temperature has been

restored once the defrost cycle has completed.

TROUBLESHOOTING

Problem Possible Causes Solutions

Interior moisture

buildup.

Doors are opened often or for

long periods of time.

When the doors are opened often or for long

periods of time, warm, humid air enters the

compartment. This raises the temperature and

moisture level within the compartment. To

lessen the effect, reduce the frequency and

duration of door openings.

Doors not closed correctly. See the Doors will not close correctly section in

the Troubleshooting section.

Weather is humid. Humid weather allows additional moisture

to enter the compartments when the doors

are opened leading to condensation or frost.

Maintaining a reasonable level of humidity in the

home will help to control the amount of moisture

that can enter the compartments.

Defrost cycle recently

completed.

During the defrost cycle, the temperature of each

compartment may rise slightly and condensation

may form on the back wall. Wait 30 minutes and

confirm that the proper temperature has been

restored once the defrost cycle has completed.

Food is not packaged correctly. Food stored uncovered or unwrapped, and damp

containers can lead to moisture accumulation

within each compartment. Wipe all containers

dry and store food in sealed packaging to prevent

condensation and frost.

Food is freezing

in the fridge

compartment.

Food with high water content

was placed near an air vent.

Rearrange items with high water content away

from air vents.

Fridge temperature control is

set incorrectly.

If the temperature is too cold, adjust the control

one increment at a time and wait for the

temperature to stabilize. Refer to the Setting the

Controls section for more information.

Fridge is installed in a cold

location.

When the fridge is operated in temperatures below

5°C, food can freeze in the fridge compartment.

The fridge should not be operated in temperatures

below 13°C.

Frost or ice

crystals form

on frozen food

(outside of

package).

Door is opened frequently or for

long periods of time.

When the doors are opened often or for long

periods of time, warm, humid air enters the

compartment. This raises the temperature and

moisture level within the compartment. Increased

moisture will lead to frost and condensation.

To lessen the effect, reduce the frequency and

duration of door openings.

Door is not closing properly. Refer to the Doors will not close correctly or pop

open section in the Troubleshooting section.

Fridge or Freezer

section is too

cold.

Incorrect temperature control

settings.

If the temperature is too cold, adjust the control

one increment at a time and wait for the

temperature to stabilize. Refer to the Setting the

Controls section for more information.

TROUBLESHOOTING

Problem Possible Causes Solutions

Frost or ice

crystals on frozen

food (inside of

sealed package).

Condensation from food with a

high water content has frozen

inside of the food package.

This is normal for food items with a high water

content.

Food has been left in the freezer

for a long period of time.

Do not store food items with high water content

in the freezer for a long period of time.

Icemaker is not

making enough

ice.

Demand exceeds ice storage

capacity.

The icemaker will produce approximately 70~182

cubes in a 24 hour period.

House water supply is not

connected, valve is not turned

on fully, or valve is clogged.

Connect the fridge to a cold water supply with

adequate pressure and turn the water shutoff

valve fully open.

If the problem persists, it may be necessary to

contact a plumber.

Water filter has been

exhausted.

It is recommended that you replace the water

filter:

Approximately every six months.•

When the water filter indicator turns on.•

When the water dispenser output decreases. •

When the ice cubes are smaller than normal.•

Low house water supply

pressure.

The water pressure must be 20~120 psi or

138~827 kPa or 1.4~8.4 kgf/cm² on models

without a water filter and 40~120 psi or 276~827

kPa or 2.8~8.4 kgf/cm² on models with a water

filter.

If the problem persists, it may be necessary to

contact a plumber.

Reverse Osmosis filtration

system is used.

Reverse osmosis filtration systems can reduce

the water pressure below the minimum amount

and result in icemaker issues.

(Refer to Water Pressure section.)

Tubing connecting fridge to

house supply valve is kinked.

The tubing can kink when the fridge is moved

during installation or cleaning resulting in reduced

water flow. Straighten or repair the water supply

line and arrange it to prevent future kinks.

TROUBLESHOOTING

Problem Possible Causes Solutions

Icemaker is not

making enough

ice (continued).

Doors are opened often or for

long periods of time.

If the doors of the unit are opened often, ambient

air will warm the fridge which will prevent the unit

from maintaining the set temperature. Lowering

the fridge temperature can help, as well as not

opening the doors as frequently.

Doors are not closed

completely.

If the doors are not properly closed, ice

production will be affected. See the Doors will

not close completely or pop open section in Parts

& Features Troubleshooting for more information.

The temperature setting for the

freezer is too warm.

The recommended temperature for the freezer

compartment for normal ice production is -18°C. If

the freezer temperature is warmer, ice production

will be affected.

Dispensing water

slowly.

Water filter has been exhausted. It is recommended that you replace the water

filter:

Approximately every six months.•

When the water filter indicator turns on.•

When the water dispenser output decreases. •

When the ice cubes are smaller than normal.•

Reverse osmosis filtration

system is used.

Reverse osmosis filtration systems can reduce

the water pressure below the minimum amount

and result in icemaker issues.

If the problem persists, it may be necessary to

contact a plumber.

Low house water supply

pressure.

The water pressure must be 20~120 psi or

138~827 kPa or 1.4~8.4 kgf/cm² on models

without a water filter and 40~120 psi or 276~827

kPa or 2.8~8.4 kgf/cm² on models with a water

filter.

If the problem persists, it may be necessary to

contact a plumber.

TROUBLESHOOTING

Problem Possible Causes Solutions

Not dispensing

ice.

Doors are not closed

completely.

Ice will not dispense if any of the fridge doors are

left open.

Infrequent use of the dispenser. Infrequent use of the ice dispenser will cause

the cubes to stick together over time, which

will prevent them from properly dispensing.

Check the ice bin for ice cubes clumping/sticking

together. If they are, break up the ice cubes to

allow for proper operation.

The delivery chute is clogged

with frost or ice fragments.

Eliminate the frost or ice fragments by removing

the ice bin and clearing the chute with a plastic

utensil. Dispensing cubed ice can also help

prevent frost or ice fragment buildup.

The dispenser display is locked. Press and hold the Lock button for three seconds

to unlock the control panel and dispenser.

Ice bin is empty. It may take up to 24 hours for each compartment

to reach the desired temperature and for the

icemaker to begin making ice. Make sure that the

shutoff (arm/sensor) is not obstructed.

Once the ice supply in the bin has been

completely exhausted, it my take up to 90

minutes before additional ice is available, and

approximately 24 hours to completely refill the

bin.

Icemaker is not

making ice.

Fridge was recently installed or

icemaker recently connected.

It may take up to 24 hours for each compartment

to reach the desired temperature and for the

icemaker to begin making ice.

Icemaker not turned on. Locate the icemaker ON/OFF switch and confirm

that it is in the ON (I) position.

The ice detecting sensor is

obstructed.

Foreign substances or frost on the ice-detecting

sensor can interrupt ice production. Make sure

that the sensor area is clean at all times for proper

operation.

The fridge is not connected to

a water supply or the supply

shutoff valve is not turned on.

Connect fridge to the water supply and turn the

water shutoff valve fully open.

Icemaker shutoff (arm or

sensor) obstructed.

If your icemaker is equipped with an ice shutoff

arm, make sure that the arm moves freely. If

your icemaker is equipped with the electronic ice

shutoff sensor, make sure that there is a clear

path between the two sensors.

Reverse osmosis water filtration

system is connected to your

cold water supply.

Reverse osmosis filtration systems can reduce

the water pressure below the minimum amount

and result in icemaker issues.

(Refer to the Water Pressure section.)

TROUBLESHOOTING

Problem Possible Causes Solutions

Not dispensing

water.

New installation or water line

recently connected.

Dispense 10 liters of water (flush for

approximately 5 minutes) to remove trapped air

and contaminants from the system.

Do not dispense the entire 10 liters amount

continuously. Depress and release the dispenser

pad for cycles of 30 seconds ON and 60 seconds

OFF.

The dispenser panel is locked. Press and hold the Lock button for three seconds

to unlock the control panel and dispenser.

The dispenser is not set for

water dispensing.

The dispenser can be set for ice or water. Make

certain that the control panel is set for the proper

operation. Press the Water button on the control

panel to dispense water.

Fridge or freezer doors are not

closed properly.

Water will not dispense if any of the fridge doors

are left open.

Water filter has been recently

removed or replaced.

After the water filter is replaced, dispense

10 liters of water (flush for approximately 5

minutes) to remove trapped air and contaminants

from the system. Do not dispense the entire 10

liters amount continuously. Depress and release

the dispenser pad for cycles of 30 seconds ON

and 60 seconds OFF.

Tubing connecting fridge to

house supply valve is kinked.

The tubing can kink when the fridge is moved

during installation or cleaning resulting in reduced

water flow. Straighten or repair the water supply

line and arrange it to prevent future kinks.

The house water supply is not

connected, the valve is not

turned on fully, or the valve is

clogged.

Connect fridge to the water supply and turn the

water shutoff valve fully open.

If the problem persists, it may be necessary to

contact a plumber.

TROUBLESHOOTING

Problem Possible Causes Solutions

Ice has bad taste

or odor.

Water supply contains minerals

such as sulfur.

A water filter may need to be installed to

eliminate taste and odor problems.

NOTE: In some cases, a filter may not help. It

may not be possible to remove all minerals / odor

/ taste in all water supplies.

Icemaker was recently installed. Discard the first few batches of ice to avoid

discolored or bad tasting ice.

Ice has been stored for too

long.

Ice that has been stored for too long will shrink,

become cloudy, and may develop a stale taste.

Throw away old ice and make a new supply.

The food has not been stored

properly in either compartment.

Rewrap the food. Odors may migrate to the ice if

food is not wrapped properly.

The interior of the fridge needs

to be cleaned.

See the Care and Cleaning section for more

information.

The ice storage bin needs to be

cleaned.

Empty and wash the bin (discard old cubes).

Make sure that the bin is completely dry before

reinstalling it.

Dispensing warm

water.

Fridge was recently installed. Allow 24 hours after installation for the water

storage tank to cool completely.

The water dispenser has been

used recently and the storage

tank was exhausted.

Depending on your specific model, the water

storage capacity will range from approximately

20 to 30 oz.

Dispenser has not been used

for several hours.

If the dispenser has not been used for several

hours, the first glass dispensed may be warm.

Discard the first 10 oz.

Fridge is connected to the hot

water supply.

Make sure that the fridge is connected to a cold

water pipe.

WARNING: Connecting the fridge to a hot

water line may damage the icemaker.

Water has bad

taste or odor.

Water supply contains minerals

such as sulfur.

A water filter may need to be installed to

eliminate taste and odor problems.

Water filter has been exhausted. It is recommended that you replace the water

filter:

Approximately every 6 months.•

When the water filter indicator turns on.•

When the water dispenser output decreases. •

When the ice cubes are smaller than normal.•

Fridge was recently installed. Dispense 10 liters of water (flush for

approximately 5 minutes) to remove trapped

air and contaminants from the system. Do not

dispense the entire 10 liters amount continuously.

Depress and release the dispenser pad for cycles

of 30 seconds ON and 60 seconds OFF.

TROUBLESHOOTING

Problem Possible Causes Solutions

Icemaker is

making too much

ice.

Icemaker shutoff (arm/sensor)

is obstructed.

Empty the ice bin. If your icemaker is equipped

with an ice shutoff arm, make sure that the arm

moves freely. If your icemaker is equipped with

the electronic ice shutoff sensor, make sure that

there is a clear path between the two sensors.

Reinstall the ice bin and wait 24 hours to confirm

proper operation.

Clicking The defrost control will click

when the automatic defrost

cycle begins and ends. The

thermostat control (or fridge

control on some models) will

also click when cycling on and

off.

Normal Operation

Rattling Rattling noises may come from

the flow of refrigerant, the

water line on the back of the

unit, or items stored on top of

or around the fridge.

Normal Operation

Fridge is not resting solidly on

the floor.

Floor is weak or uneven or leveling legs need to

be adjusted. See the Door Alignment section.

Fridge with linear compressor

was jarred while running.

If the rattling continues for more than 15 seconds

after the fridge was moved, turn the power off,

wait 3 minutes and then turn back on again.

Whooshing Evaporator fan motor is

circulating air through the fridge

and freezer compartments.

Normal Operation

Air is being forced over the

condenser by the condenser

fan.

Normal Operation

Gurgling Refrigerant flowing through the

cooling system.

Normal Operation

Popping Contraction and expansion of

the inside walls due to changes

in temperature.

Normal Operation

Sizzling Water dripping on the defrost

heater during a defrost cycle.

Normal Operation

Vibrating If the side or back of the fridge

is touching a cabinet or wall,

some of the normal vibrations

may make an audible sound.

To eliminate the noise, make sure that the sides

and back cannot vibrate against any wall or

cabinet.

Dripping Water running into the drain pan

during the defrost cycle.

Normal Operation

TROUBLESHOOTING

Problem Possible Causes Solutions

Pulsating or

High-Pitched

Sound

Your fridge is designed to

run more efficiently to keep

your food items at the desired

temperature. The high efficiency

compressor may cause your

new fridge to run longer than

your old one, but it is still more

energy efficient than previous

models. While the fridge is

running, it is normal to hear a

pulsating or high-pitched sound.

Normal Operation

Doors will not

close correctly or

pop open.

Food packages are blocking the

door open.

Rearrange food containers to clear the door and

door shelves.

Ice bin, crisper cover, pans,

shelves, door bins, or baskets

are out of position.

Push bins all the way in and put crisper cover,

pans, shelves and baskets into their correct

positions. See the Using Your Fridge section for

more information.

The doors were removed during

product installation and not

properly replaced.

Remove and replace the doors according to the

Removing and Replacing Fridge Handles and

Doors section.

Fridge is not leveled properly. See Door Alignment in the Fridge Installation

section to level fridge.

Doors are difficult

to open.

The gaskets are dirty or sticky. Clean the gaskets and the surfaces that they

touch. Rub a thin coat of appliance polish or

kitchen wax on the gaskets after cleaning.

Door was recently closed. When you open the door, warmer air enters

the fridge. As the warm air cools, it can create

a vacuum. If the door is hard to open, wait one

minute to allow the air pressure to equalize, then

see if it opens more easily.

Fridge wobbles or

seems unstable.

Leveling legs are not adjusted

properly.

Refer to the Leveling and Door Alignment section.

Floor is not level. It may be necessary to add shims under the

leveling legs or rollers to complete installation.

Lights do not

work.

LED interior lighting failure. The fridge compartment lamp is LED interior

lighting, and service should be performed by a

qualified technician.

Fridge has an

unusual odor.

The Pure N Fresh filter may

need to be set to the POWER

setting or replaced.

Set the Pure N Fresh filter to the POWER setting.

If the odor does not go away within 24 hours, the

filter may need to be replaced. See the Replacing

the Pure N Fresh filter section for replacement

instructions.

The interior of the

fridge is covered

with dust or soot.

The fridge is located near a fire

source, such as a fireplace,

chimney or candle.

Make sure that the fridge is not located near a fire

source, such as a fireplace, chimney or candle.

Printed in Korea

128, Yeoui-daero, Yeongdeungpo-gu,

Seoul, 150-721 Korea

LG Electronics GF-AD910SL - 910l Door-in-door French Door Refrigerator With Customchill Drawer

Product's Documents

User Manual

Specifications

LG Electronics GF-AD910SL Questions and Answers

Related Products

LG Electronics LRFCS25D3SS LG Refrigerator French Door 25 Cu Ft in PrintProof

LG Electronics LRFXS3106SS LG French Door Refrigerator 30.7 Cu. Ft. Smart Standard-Depth MAX in Stainless Steel Finish

GR-L218STSL French Door Refrigerator - Refrigerators - - Lg Electronics Australia

GM-B208BVS French Door Refrigerator - Refrigerators - - Lg Electronics Australia

GR-B218STS French Door Refrigerator - Refrigerators - - Lg Electronics Australia

GR-B218NID French Door Refrigerator - Refrigerators - - Lg Electronics Australia
