Gourmet Outdoor Grilling
36" Four Burner Gas Griddle
Model NO: CGG-0036
DO NOT RETURN YOUR GRIDDLE TO THE STORE
Before visiting your local retailer, call our customer service department at 1-866-994-6390 from 9:00
am to 5:00 pm Eastern time, Monday through Friday.
Customer Service Hotline
1-866-994-6390
WARNING
WARNING
For Outdoor Use Only (outside any enclosure)
1. Improper installaon, adjustment, alteraon, service or
maintenance can cause injury or property damage.
2. Read this instrucon manual thoroughly before installing
or servicing this equipment.
3. Failure to follow these instrucons could result in fire or
explosion, which could cause property damage, personal
injury or death.
4. This instrucon manual contains important informaon
necessary for proper assembly and safe use of this appliance.
5.
Always keep this manual for convenient future reference.
WARNING
1. DO NOT store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
2. A liquid propane tank not connected for use should not be
stored in the vicinity of this or any other appliance.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Exnguish any open flames.
3. If the odor connues, keep away from the appliance and
immediately call your gas supplier or fire department.
DANGER
Never operate this appliance unaended.
WARNING
Check for leaks every me prior to lighng the griddle, even
if purchased fully assembled. Gas leaks may cause a fire or
explosion. Please read the instrucons on Page 19.
2
TABLE OF CONTENTS
Cover …………….…………………………………….………...….………….………….….…………………..……..1
Table of Contents……………………………………….………...….………….………………..……….…….…..2
Safety Informaon…………………………………….………...….………….….………….……………..……..3
What’s in the Box……………….……………………………………….….......................……….………....6
Assembly Preparaon and Instrucons………………………………………………….….….….....…..8
Folding Instrucons…..............................……………………………………………….….….….....…17
Connecng Regulator to the Liquid Propane Tank…………………..…………………….…........18
Check for Leaks…………….…………………………………….……………...….….……………………...…...19
Liquid Propane Tank Informaon…………….…………………………………….……...….….…...…..20
Lighng Instrucons………….…………………………………….……...….….…………………..…....…...21
Care and Maintenance……………………………….………………………………………..………….……...22
Troubleshoong …………………………………………………………………..….…………………..………...25
Parts List….……………..…..….……...…...................……………....………………..........................26
Exploded View……………….……………………………………………….......................……….………...27
Warranty………………………………………………………………………………………………………..………..28
Please call 1-866-994-6390 for any assistance
SAFETY INFORMATION
IMPORTANT: ALL INSTRUCTIONS AND SAFEGUARDS ON THIS SECTION MUST BE FOLLOWED TO PREVENT FIRE,
DAMAGE AND/OR INJURY.
This griddle is for outdoor use only, and shall not be used in a building, garage, or any other enclosed area.
Do NOT operate, light or use this appliance within 8 feet of walls, structures or buildings.
This griddle is NOT for commercial use.
This griddle is for use with liquid propane (LP) gas
only. The conversion to or aempted use of natural
gas in this LP gas griddle is dangerous and will void
your warranty.
The installaon of this appliance must conform with
local codes or, in the absence of local codes, with
either the Naonal Fuel Gas Code, ANSI Z223.1/NFPA
54, or Natural Gas and Propane Installaon Code,
CSA/CGA-B149.1.
This outdoor cooking gas appliance must not be
placed under overhanging combusble structure.
A minimum clearance of 36 inches from combusble
construcons to the sides of the griddle and 36 inches
from the back of the griddle to combusble
construcons must be maintained.
Keep your griddle in an area clear and free from
combusble materials, gasoline and other flammable
vapors and liquids.
This griddle is intended for use outdoors and must not
be used in a building, garage or any other enclosed or
covered area.
This outdoor griddle is not intended for installaon in or on recreaon vehicles and/or boats.
DO NOT leave a lit griddle unaended. Keep children and pets away from the griddle at all mes.
Do not use the griddle unless it is COMPLETELY assembled and all parts are securely fastened and ghtened.
The griddle should be placed on a flat and level surface.
Never use the griddle in windy areas. The griddle will operate best if it is not facing directly into the wind.
DO NOT touch metal parts of griddle unl it has completely cooled (about 45 minutes) to avoid burns, unless you are
wearing protecve gear (pot holders, gloves, BBQ miens, etc…).
DO NOT obstruct the flow of combuson and venlaon air to this appliance.
Keep all electrical cords away from a hot griddle.
DO NOT use griddle for indoor cooking or heang. TOXIC fumes can accumulate and cause asphyxiaon. Aer a period of
storage and/or non use, check for leaks, burner obstrucons and inspect for any abrasion, wear, cuts to the hose.
3
4
SAFETY INFORMATION
The LP gas cylinder used with this appliance must be:
(a) Constructed and marked in accordance with the Specificaons for
LP-Gas Cylinders of the U.S. Department of Transportaon (D.O.T.)
or the Naonal Standard of Canada, CAN/CSA-B339, Cylinders,
Spheres and Tubes for Transportaon of Dangerous Goods; and
Commission, as applicable; and
(b) Provided with a listed overfilling prevenon device.
(c) Provided with a cylinder connecon device compable with the connector
for outdoor cooking appliances.
The LP cylinder used must include a collar to protect the cylinder valve.
DO NOT store a spare LP-gas cylinder under or near this appliance.
An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
Never fill the cylinder beyond 80 percent full.
Inspect the hoses before each use for excessive abrasion or wear, or cuts that may affect safe operaon of the griddle. If there
is evidence of excessive abrasion or wear, or the hose is cut, it must be replaced prior to the griddle being put into operaon.
The replacement hose assembly must be those specified by the manufacturer.
Never use charcoal, lighter fluid, lava rocks, gasoline, kerosene, or alcohol with this product.
Move gas hoses as far away as possible from hot surfaces and dripping hot grease.
If griddle is not in use, the gas must be turned off at the supply tank.
DO NOT completely cover the top surface in foil as this can lead to excessive heat and the potenal for a possible fire.
Doing so will void your warranty.
Never use the griddle without the drip cup installed and hung under the grease pan. Without the drip cup, hot grease and
debris could leak downward and produce a fire hazard.
Never operate this griddle without the hose ring secured to the leg. This can keep the regulator hose away from hot surfaces
and dripping hot grease. Failure to do this may cause a fire or explosion.
Always use a meat thermometer to ensure food is cooked to a safe temperature.
Please use protecve gloves when assembling this product.
DO NOT force parts together as this can result in personal injury or damage to the product.
This griddle should be thoroughly cleaned and inspected on a regular basis. Clean and inspect the hose before each use of the
appliance. If there is evidence of abrasion, wear, cuts, or leaks, the hose must be replaced prior to the appliance being put
into operaon.
Keep the venlaon openings of the tank enclosure free and clear from debris.
Your griddle has been checked at all factory connecons for leaks. Recheck all connecons, as movement in shipping can
loosen connecons.
Check for leaks even if your unit was assembled for you by someone else.
DO NOT operate if gas leak is present. Gas leaks may cause a fire or explosion.
Deaths, serious injury or damage to property may occur if the above is not followed exactly.
5
SAFETY INFORMATION
WARNING: This product can expose you to chemicals including Carbon Monoxide, which are known to the
State of California to cause cancer and birth defects or other reproducve harm.
For more informaon, go to www.P65Warnings.ca.gov.
WARNING: We urge you to read this manual carefully and follow the recommendaons enclosed. This
will ensure you receive the most enjoyable and trouble-free operaon of your new gas griddle. We also
advise you retain this manual for future reference.
WARNING: Your griddle has been designed to operate using only the gas specified by the manufacturer on
the rang plate. DO NOT aempt to operate your griddle on other gases.
Failure to follow this warning could lead to a fire hazard and bodily harm and will void your warranty.
WARNING: Make certain your LP (propane) tank is filled by a reputable propane dealer. An incorrectly
filled or an overfilled LP tank can be dangerous. The overfilled condion combined with the warming of
the LP tank (a hot summer day, tank le in the sun, etc.) can cause LP gas to be released by the pressure
relief valve on the tank since the temperature increase causes the propane to expand. LP gas released
from the tank is flammable and can be explosive. Refer to your Owner’s Manual for more informaon
concerning filling your LP tank.
Griddle
Grease Cups
Side Table Assembly
Baery
Firebox Assembly
1
2
2
1
1
13
15
11
1
16
Le Back Cart Leg Fixing Bracket
12 Le Front Cart Leg Fixing Bracket
13
Right Back Cart Leg Fixing Bracket
Right Front Cart Leg Fixing Bracket
Knobs
Propane Tank Bracket
Wheels
Le Cart Leg Assembly
1
1
1
1
2
4
1
1
2
4
5
7
10
9
14
12
6
8
Right Cart Leg Assembly
Cart Boom Panel
Staonary Feet
7
HARDWARE
Phillips Head
Screw
Cart Leg Pin
Coer Pin
M6 Flat
Washer
16
4
4
2
A
B
C
D
PART DESCRIPTION QTY
Feet Fixing
Nuts
Handle
Screws
Wheel Fixing
Nuts
2
2
5
E
F
G
PART DESCRIPTION QTY
ASSEMBLY INSTRUCTIONS
Assembly Tip: To avoid scratching griddle body and to protect floor/pao surfaces, reuse
cardboard packaging and lay main grill body on top.
ASSEMBLY PREPARATION
Some parts may contain sharp edges. Wear protecve gloves if necessary. Read and follow all safety
statements, warnings, assembly instrucons and use and care instrucons before aempng to assemble and
use.
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents
list and hardware contents list. If any part is missing or damaged, DO NOT aempt to assemble the product.
Esmated Assembly Time: 1 hour
Tools required for assembly (not included): Phillips Head Screwdriver and Wrench
ASSEMBLY INSTRUCTIONS
A
x16
1
2
3
5
4
1. Flip the firebox assembly upside down, with the
knobs facing away. Attach the leg fixing brackets by
screwing them in with the screws, as shown below.
9
ASSEMBLY INSTRUCTIONS
3. Rotate and stand the left leg up. Slide the right cart leg
assembly into the two leg fixing brackets. Align the holes,
and slide the cart leg pins through the holes.
Insert the cotter pins through the holes at the ends of the
leg pins to secure.
B
x2
C
x2
6
2. Slide the left cart leg assembly into the two leg fixing
brackets. Align the holes, and slide the cart leg pins through
the holes.
Insert the cotter pins thr
ough the holes
at the ends of the leg pins to secure.
3
B
x2
C
x2
7
10
ASSEMBLY INSTRUCTIONS
4. Rotate and stand the right leg up.
Attach the wheels on the left leg assembly using
the flat washers and the wheel fixing nuts.
7
x2
D
x2
E
D
E
8
D
E
11
5. Screw on the feet fixing nuts to
the stationary feet, then twist those
into place on the right leg. Tighten
with a wrench to secure.
F
x2
ASSEMBLY INSTRUCTIONS
9
F
9
Note: If your griddle feels
wobbly or uneven, adjust the
stationary feet until they are
level on the ground, then use a
wrench on the fixing nuts to
secure in place.
ASSEMBLY INSTRUCTIONS
6. Install the cart bottom
panel by lining up the
notches with the left side of
the griddle first, and then
let the right side fall in
place. Use the handle
screw to secure the shelf.
Note: Use 2 people to flip
the griddle body over.
12
1010
G
x1
1010
13
7. Slide the side table assemblies into the corresponding slots on the left
and right side of the griddle. Use the handle screws to secure the side tables.
ASSEMBLY INSTRUCTIONS
11
11
G
x4
14
8. Take the propane
tank bracket and mount it to
the tabs on the left side of the
griddle. Insert the right side
first, then the left side.
9. Place the griddle plate on
the firebox - line up the holes
on the front of the griddle
plate with the holes on the
front of the fire box. Insert
the pegs on the griddle plate
into the slots in the front of
the firebox to secure in place.
Note: Griddle plate is very heavy.
Use 2 people to place griddle plate
on top.
ASSEMBLY INSTRUCTIONS
1212
13
THIS SIDE
SECOND
THIS SIDE
FIRST
15
ASSEMBLY INSTRUCTIONS
14
!
15
10. Place control
knobs onto valve
stems.
11. Slide the grease cups into
the openings on the front of
the griddle, lining them up
under the hole. Hook the
cups onto the loops inside
the openings.
16
ASSEMBLY INSTRUCTIONS
16
+
-
-
+
12. Unscrew the starter button
from the control panel and
insert the included battery with
negative side going in first.
13. Your griddle is now fully assembled.
17
FOLDING INSTRUCTIONS
1. To collapse your griddle, begin by
removing the griddle plate, side tables, and
the cart bottom panel. Then flip the griddle
body upside down.
On the right back cart leg fixing bracket, pull
the the silver ring to release pin and guide the
right leg down. Then pull the silver ring on the
left front cart leg fixing bracket and guide the
left leg down.
2. Secure the legs shut by using
the latch on the right front cart leg
fixing bracket with the hook on
the bottom of the left leg assembly.
CONNECTING REGULATOR TO THE LP TANK
1. Check the tank valve to ensure it has proper external mang threads to fit the hose and regulator assembly
provided (Type 1 connecon per ANSI Z21.58b-2002).
2. Make sure all burner knobs are in the OFF posion.
3. Remove the protecve cap from the LP tank valve and coupling
nut. And inspect the valve connecon port of the regulator
assembly. Look for damage or debris. Remove any debris. Inspect
hose for damage. Never use damaged or plugged equipment.
4. Hold regulator by one hand in a straight line with LP tank valve
and insert nipple into LP tank valve. Be sure the nipple is centered
in the valve outlet. (see Fig. 1). Hand-ghten the coupling nut clockwise
unl it comes to a full stop. DO NOT use tools!
5. Open the tank valve fully (counterclockwise).
6. Perform leak test before aempng to light your grill.
See “CHECKING FOR LEAKS " on page 19.
Fig. 1
Fig. 2
WARNING: The Type I connecve coupling (see Fig. 2) supplied with your grill must not be replaced
with a different type of grill/tank connecon system. Removal will result in loss of warranty, gas leakage, fire
and severe bodily harm.
18
Perform Leak Test
Although all gas connecons on the griddle are leak tested prior to shipment, a complete gas ghtness check
must be performed at the installaon site due to possible shis during shipment, installaon or excessive
pressure unknowingly being applied to the unit. Periodically check the whole system for leaks and immediately
check the system if the smell of gas is detected.
1. Create a mixture of 50% water and 50% liquid dishwashing soap.
2. Ensure all control knobs are set to the "OFF" posion.
3. Turn ON LP gas tank at valve.
4. Brush soapy soluon at all ”X” locaons (see Fig.3).
5. Check each place for growing bubbles
If “growing” bubbles appear, turn the Tank Valve off and
DO NOT use your griddle unl the leak is repaired.
A slight leak could cause a fire.
If no bubbles appear aer one minute, turn tank OFF, wash off
soapy soluon with cold water and towel dry.
DANGER WARNING
WHEN TO PERFORM A LEAK TEST:
Ù Every me prior to lighng the griddle,
even if purchased fully assembled.
Ù Repeat every me the LP gas cylinder is refilled
or exchanged
Ù Any me your griddle has been moved.
Ù At least once per year or if your griddle has not
been used for more than 60 days.
FOR YOUR SAFETY
Ù Always perform leak tests outdoors
ONLY in a well-venlated area.
Ù DO NOT smoke during leak test.
Ù DO NOT use an open flame to check
for gas leaks
Ù Never perform a leak test while the
griddle is in use or while griddle is sll
hot.
When leak tesng this appliance, make sure to test and ghten all loose connecons. A slight leak
in the system can result in a low flame or hazardous condion. Most L.P. gas tanks now come
equipped with a leak detector mechanism internal to the tank. When gas is allowed to escape
rapidly, it shuts off the gas supply. A leak may significantly reduce the gas flow, making the griddle
difficult to light or causing low flames.
WARNING
CHECKING FOR LEAKS
Fig. 3
19
20
L.P. TANK INFORMATION
Never use a dented or rusted L.P. tank or cylinder with a damaged valve.
L.P. cylinders are equipped with an O.P.D. (Overfilling Prevenon Device). The device shuts off the flow of gas to a
cylinder aer 80% capacity is reached. This limits the potenal for release of gas when the cylinder is heated,
averng a fire or possible injury.
The L.P. cylinder must have a shut-off valve terminang in an L.P. gas supply cylinder outlet specified, as applicable,
for connecon No. 510 in the standard for compressed gas cylinder valve outlet and inlet connecon ANSI/CGA-V-1.
Cylinders must not be stored in a building, garage, or any other enclosed area. (The L.P. cylinder must have an
overfill protecon device and a collar to protect the cylinder valve.)
The L.P. gas supply cylinder must be constructed and marked in accordance with the specificaons for L.P. gas
cylinders of the U.S. Department of Transportaon (DOT) or the Naonal Standard of Canada, CAN/CAS-B339,
“Cylinders, Spheres and Tubes for the Transportaon of Dangerous Goods and Commission.”
L.P. TANK USE
When turning the L.P. tank on, make sure to open the valve SLOWLY two (2) complete turns to ensure proper
gas flow. Most gas tanks now come equipped with a leak detector mechanism internal to the tank. When gas is
allowed to escape rapidly it shuts off the gas supply. Opening the valve rapidly may simulate a gas leak, causing
the safety device to acvate, and restricng gas flow causing low flames. Opening the valve slowly will ensure
this safety feature is not falsely triggered.
• When not in use, gas supply cylinder valve is to be in the OFF posion.
• Storage of an outdoor gas cooking appliance indoor is permissible only if the cylinder is disconnected and
removed from the appliance.
• The tank supply system must be stored upright to allow for vapor withdrawal.
• The regulator and hose assembly must be inspected before each use of the griddle. If there is excessive
abrasion or wear or if the hose is cut, it must be replaced prior to the griddle being used again.
• Cylinders must be stored outdoors out of the reach of children and must not be stored in a building, garage or
any other enclosed area.
If this informaon is not followed exactly, a fire causing death or serious injury may occur.
• Place dust cap on cylinder valve outlet whenever
the cylinder is not in use. Only install the type of
dust cap on the cylinder valve outlet that is
provided with the cylinder valve. Other types of
caps or plugs may result in leakage of propane.
• Only a qualified gas supplier should refill the
L.P. tank.
DO NOT store a spare L.P. gas tank under or near the
grill. Never fill the cylinder beyond 80% full.
If this informaon is not followed exactly, a fire
causing death or serious injury may occur.
WARNING
LIGHTING INSTRUCTIONS
WARNING:
1. Read all instrucons before lighng.
2. Make sure the gas control knob is in “OFF” posion.
3. Press and turn the knobs counterclockwise to the "HIGH" posion.
Press the ignion buon. The ignion will click repeatedly while the
buon is pressed and light the burners.
4. If ignion does not occur in 5 seconds, turn the gas control knob off,
wait 5 minutes, and repeat steps 2 - 5.
MATCH LIGHTING
1. Remove cooking surface before lighting
2. Place a match in the end of Match Holder (hanging on the Right Front Leg). Strike the match and place it near
side of the burner (see Fig.4)
3. Push and turn the control knob to HIGH. The burner should ignite.
4. Replace cooking surface. Be sure to use protective gloves, such as over mitts or BBQ gloves.
NOTE: If the burner does not ignite within the first few aempts of match lighng, there is a problem with the
gas supply. Turn off the gas at the burner and tank. DO NOT aempt to operate the griddle unl the problem is
found and corrected. See "Trouble Shoong" secon of this manual or call the customer service department at
1-866-994-6390 from 9:00 am to 5:00 pm Eastern me, Monday through Friday for assistance.
21
Fig. 4
CARE AND MAINTENANCE
Always check that the outdoor cooking appliance area is clear and free from combusble material, gasoline and
other flammable vapors and liquids before lighng.
Regularly check and clean the burner/venturi tubes for insects and insect nests. A clogged tube can lead to a fire
beneath the griddle.
Regularly check that the flow of combuson and venlaon air is not obstructed.
GREASE PAN AND CUP
The grease cups should be kept clean on a regular basis to prevent heavy buildup of debris.
Accumulated grease is a fire hazard.
Important: DO NOT leave the griddle outside during inclement weather unless it is covered. Rain water can collect
inside of the griddle, the griddle body or the grease cups if le uncovered.
CONTROL PANEL
Aer inial usage, areas of the griddle may discolor from the intense heat given off by the burners. Discoloraon
may sll be present, this is normal.
PAINTED SURFACES:
Wash with mild detergent or nonabrasive cleaner and warm soapy water. Wipe dry with a so nonabrasive cloth.
Ensure the griddle is cool before cleaning and conducng maintenance and with the gas supply turned off
at the LP-Gas Cylinder.
To avoid the possibility of burns, maintenance should be done only when the griddle is cool.
Avoid unprotected contact with hot surfaces.
A leak test must be performed annually and whenever any component of the gas train is replaced or gas
smell is present.
For your safety, always wear protecve gloves and safety glasses when cleaning your griddle.
WARNING
22
CARE AND MAINTENANCE
IGNITER
In order to prevent cracking of the burner's ceramic igniter surfaces, never allow hard objects to the strike ceramic
igniter. This will cause the burners to malfuncon. Care should be taken when inserng or removing the griddle
plate and accessories into or from the griddle. If hard objects fall onto the ceramic igniter, it is likely to crack the
ceramic.
Damage resulng from failure to follow these steps is not covered under the warranty.
GRIDDLE SEASONING
Let’s Talk About Seasoning
In this case we are not talking about salt and pepper. We are talking about the process of condioning your griddle
surface for opmal performance and longevity. Seasoning your griddle will help create a non-sck surface for
cooking while also protecng it from any rust. It’s worth the effort. When you receive your griddle it will already
have a thin layer of oil applied. We do this to protect from rust in shipping and storing, but it’s going to need a lile
more work to perfect it.
First Seasoning
• This is the most important one so let’s get this right. You’ll want to start by using some soapy water and a towel
or paper towels to wash off the shipping oil. Use addional water to wash the soap from the griddle surface.
Dry the surface with a towel or paper towels. This gives you a fresh and clean start.
• Next, you’ll want to select your oil. Feel free to use Extra Virgin Olive Oil, Vegetable Oil or Soy Oil.
• Now we can season. In this process you’ll be using high heat to bond the oil to the surface. Using a paper towel
rub a thin coat of oil on the enre surface of the griddle. Then turn your griddle on high. The oil will eventually
begin to smoke which is good. Leave it on high unl the smoke stops. That means you passed the smoke point.
• Finally, you’ll want to cool the surface and repeat the process above unl you get a smooth black
surface on the griddle. If the griddle surface is hot you can use tongs or other protecve gear to protect your
hands while oiling.
• Once you’ve completed this process you’ll have the perfect griddling surface to get cooking on!
NOTE: When seasoning your cooktop, make sure the oil is in a thin, even layer. Do not allow oil to puddle or leave
any heavy streaks on the surface, as this can lead to a gummy cooktop.
Aer extended use, you may noce that some of your seasoning is wearing off. This is normal and can be fixed by
cleaning the cooktop and repeang the seasoning process unl you get a smooth black surface on the griddle.
Preheang Instrucons
Food cooks faster with a preheated cooking surface. By preheang your griddle cooking surface to about 300° F, you
can start cooking immediately and properly.
To preheat your griddle cooking surface, turn the gas control knobs to a medium heat for approximately 8- 10
minutes. WARNING: Make sure to use protecve gloves as griddle will be warm to the touch.
23
24
CARE AND MAINTENANCE
Cleaning Main Burner
To prevent flash backs and good performance of burner, the procedure below should be followed at least
once a month in late summer or early fall when spiders are most acve or when your griddle has not been
used for a period of me:
1. Turn off at control knobs and LP cylinder.
2. Remove the griddle surface.
3. Remove the screws from the rear of the burners. Detach ignion wire from the ignion pin by hand only.
DO NOT use tool. Then Li burner slowly.
4. Check all burner ports are clear of clogs. Use of a pin or paper clip works well.
5. Ensure the end of the burner and primary air screen are clear from insect nests, dirt or debris. Using a bent
sff wire in the shape of a hook , or a bole brush, run it through the burner tube and inside several mes to
remove any debris.
6. Inspect each burner for damage (cracks or holes) and if such damage is found, order and install a new burner.
TROUBLE SHOOTING
Many soluons given here can make your griddling experience safer and more enjoyable. You can also call
consumer care department at 1-866-994-6390 from 9:00 am to 5:00 pm Eastern me, Monday through Friday
for assistance.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Griddle will not
light.
Flashback
(fire in burner
tube(s))
Sudden drop in gas
flow or low flame
What if my griddle
starts to rust?
Can I use dish
detergents to clean
my griddle?
Do not use dish detergent or dish soap
on the griddle surface.
Your griddle surface is probably in need
of a seasoning.
Why does my
griddle surface
look dull and dry
instead of shiny
and clean?
Seasoning your griddle is a connuous
process in order to maintain a shiny,
black non-sck surface.
For tough spots use oil and a grill screen to
help remove caked on residue.
Rust occurs when the griddle is exposed to
air and water, especially in climates
suscepble to high humidity. While not all
rust is preventable, the griddle is very easy
to clean and recover to its original condion.
Follow these simple steps to get your
griddle looking like new:
NOTE: CUSTOMERS IN COASTAL CLIMATES
MAY REQUIRE MORE FREQUENT
SEASONINGS TO AVOID RUSTING AND
CORROSION.
• Turn the griddle to a high heat for about
20 minutes to loosen debris.
• Turn the griddle off and let it cool down
and use a metal scraper to remove the
debris. Scrape the griddle dry, do not
add any water.
• Use oil and a cooking stone or steel wool
to connue to scrub the griddle surface
clean.
• Use paper towels to wipe the griddle
top clean. Connue this process with oil
and paper towels unl the griddle
surface is completely clean.
• Now season your griddle top and get
cooking!
1. The ignion wire came off the igniter/valve.
2. The distance between the ignion pin and
the burner is greater than 5/32 in. - 3/16 in.
3. The ignion wire is broken.
4. No gas supplied.
1. Reconnect the ignion wire.
2. Adjust the ignion pin and adjust the
distance, then fasten it again.
3. Call customer service for a replacement
ignion wire.
4. Turn on the regulator valve.
Turn knobs to OFF.
Clean burner and/or burner tubes.
See burner cleaning secon of Use and Care.
1. Check for gas in LP cylinder.
2. Turn off knobs, wait 30 seconds and light
griddle. If flames are sll low, turn off knobs
and LP cylinder valve. Disconnect regulator.
Reconnect regulator and perform a leak-test.
Turn on LP cylinder valve slowly, wait 30
seconds and then light griddle.
3. Turn off knobs and LP cylinder valve.
Disconnect coupling nut from cylinder.
Reconnect and retry.
1. Out of gas
2. Vapor lock at coupling nut/LP cylinder
connecon.
Burner and/or burner tubes are blocked
25
REPLACEMENT PARTS
26
1 Griddle 1
2 Griddle Support
3 Burner Assembly 4
4 Burner Igniter Wire A 2
5 Burner Igniter Wire B 2
6 LP Tank Heat Shield 1
7 Match Holder 1
8 Burner Support 2
9 Grease Cups 2
10 Side Table Assembly 2
11 Firebox Assembly 1
12 Handle Screws 5
13 Heat Shield 1
14 Igniter Module 1
15 Baery 1
16 Cart Leg Pin 4
17 Le Back Cart Leg Fixing Bracket 1
18 Right Back Cart Leg Fixing Bracket 1
19 Le Front Cart Leg Fixing Bracket 1
20 Right Front Cart Leg Fixing Bracket 1
21 Right Cart Leg Assembly 1
22 Cart Boom Panel 1
23 Staonary Feet 2
24
Gas Valve and Mainfold Assembly
1
25 Knobs Bezel 4
26 Knobs 4
27
Regulator and Hose Assembly
1
28 Cylinder Fixing Line 1
29 Le Cart Leg Assembly 1
30 Wheels 2
31 Wheel nuts 2
PART DESCRIPTION PART NO QTY
2
27
REPLACEMENT PARTS
27
16
2
6
8
9
10
12
19
28
29
30
31
31
30
13
15
16
16
16
1
2
3
3
4
5
7
8
9
10
12
11
14
12
17
18
20
21
22
23
24
25
26
This warranty covers defects in parts and workmanship for a period of 3 years from the original
purchase date. Any damage claim regarding the enameling must be submied within 30 days of
purchase to be covered by the warranty.
The following condions are NOT covered by this warranty:
• Unevenness and color variaons in the coated surfaces.
• Damage caused by improper assembly or disregard of the manual.
• Use of spare parts not supplied by manufacturer.
• Damage resulng from modificaons or inappropriate use.
• Abuse of the griddle.
• Damage caused by improper maintenance or repairs by an unauthorized person.
Limitaons and exclusions:
1. This warranty applies only to the original purchaser and may not be transferred.
2. If you can not verify the purchase date of the grill the warranty period will begin on the date the
griddle was manufactured.
3. Replacement or repair parts are warranted for the remaining period of the original part warranty.
Your obligaons:
This griddle must be assembled, installed, operated and maintained in accordance with all applicable
codes and the instrucon manual furnished with this griddle. You must keep an invoice, canceled
check or payment record to verify the purchase date of the griddle.
Warranty
For FAQ’s and replacement parts, please contact us at [email protected].
For our consumer care department, please contact us at [email protected]
or call 1-866-994-6390.
Model # CGG-0036
North American Distributor:
The Fulham Group
Newton, MA 02466
28
