Installation instructions
Combi-Steam cooker with fixed water mains connection
Construction type 60–450
J23007113-R06
06/01/2020
J23007113-R06
1
The appliance should be installed by qualified personnel only.
Each step must be carried out and checked in full in the order specified.
The appliance is designed for use up to a max. altitude of 2000m above sea level.
The unpacked appliance has sharp edges.
It is advisable to wear gloves to reduce the risk of injury.
Lift the appliance carefully out of the box. Only lift the appliance using the handles at the side, otherwise there is a risk that the indi-
vidual parts of the appliance will be crushed. The appliance must never be transported upside down.
Validity
These installation instructions apply to:
Combi-Steam: 23007, 23008, 23067, 23068
General information
The directives and standards for low-voltage installations and fire protection must be complied with when installing
in flammable material.
To ensure good ventilation, the niche for the appliance must have a supply air opening of at least 25cm
2
.
Identification plate
Open the appliance door. The identification plate is located on the left of the trim kit
(see illustration).
Connection plate
The connection plate is located on the connection cable.
Electrical connections
Electrical connections must be carried out by qualified personnel in accordance with the guidelines and standards
for low-voltage installations and the specifications of the local electricity supply companies.
A plug-in appliance may only be connected to a socket outlet with earthing contact, installed according to specifications. An
all-pole mains isolating device with 3 mm contact opening should be provided in the house wiring system. Switches, plug and
socket devices, circuit breakers and fusible cut-outs which are accessible after installation and which have all-poles switching
are permissible as isolating devices. Effective earthing and separately installed neutral and earth conductors ensure safe and
fault-free operation. After installation, live parts and cables with basic insulation must not be accessible. Check old installa-
tions.
▸ The appliance is designed for use up to a max. altitude of 2000 m above sea level.
▸ Refer to the identification plate for information on the required mains voltage, current type and fuse protection.
Connection cable (only applies to Switzerland)
brown + black
blue
yellow/green
black
blue
yellow/green
brown
L2
L1
N
N
L1
PE/
PE/
400 V 2N~
230 V~
10A
16A
Connection cable (all other countries)
