2016 Manual B Series Product Brochure
Manual B series is an entry-level manual pull-down screen designed for today's various projection applications
Manual B Series
Manual B series is an entry-level manual pull-down screen designed for today's various
projection applications
1
www.elitescreens.com/manualb
Screen Material
• MaxWhite B screen material is durable and easy to clean
• 180˚ wide viewing angle for commercial presentations or
amenic emoh laitnediser
• Black backed screen material eliminates light penetration for
superior color reproduction
Casing & Installation
• Dual wall and ceiling installation design
Control System
• Auto-locking system at 2" intervals provides variable height
settings
• Screen lanyard for easy operation included - allows screen's pull
down handle to be reached from high areas
Warranty
• 2-year parts and labor
• 3-year warranty for ENR-G (Educational, Non-profit,
ylno SU - )yratiliM/tnemnrevoG ro suoigileR
S
c
re
•
Ma
•
1
8
re
s
•
Bl
a
s
u
C
a
si
•
Du
C
o
n
•
Au
s
et
•
Sc
d
ow
W
a
r
•
2-
y
•
3-
y
Re
Model
Manual B Series
Manual B Series Dimensions Table (100”) and (120”)
Note: Data Error ±1". The listed measurements are for general reference only. Please contact Elite Screens to verify product design and dimensions before attempting to integrate its products with any structural
or furniture modification. Although a manufacturer may offer product advice, it may be taken or disregarded at the integrator’s discretion. Elite Screens will not be held responsible or be otherwise liable for faulty
installations.
Unit: inch
Unit: mm
Screen Diag. &
Aspect Ratio
View Height
(in)
View Width
(in)
View Height
(cm)
View Width
(cm)
Left/Right
Black Border
N.W.
(lbs)
G.W.
(lbs)
N.W.
(Kgs)
N.W.
(Kgs)
Gain Screen Material
Case
Color
Packaging Dimensions
(LxHxW)
M100S 100" (1:1) 71.0 71.0 180.3 180.3 1.1" 12.2 14.5 5.6 6.6 89" x 4.7" x4.7" 1.0 MaxWhite B White
M100V 100" (4:3) 60.0 80.0 152.4 203.2 1.1" 12.3 15.0 5.6 6.8 96"x 4.7" x 4.7" 1.0 MaxWhite B White
M100H 100" (16:9) 49.0 87.0 124.5 221.0 1.1" 10.6 13.0 4.8 5.9 79.2" x 4.7" x 4.7" 1.0 MaxWhite B White
M100X 100" (16:10) 53.0 84.5 134.6 214.6 1.1" 11.8 14.4 5.4 6.6 93.58"X4.72"X4.53" 1.0 MaxWhite B White
M120V 120" (4:3) 72.0 96.0 182.9 243.8 1.5" 21.6 25.4 9.8 11.5 114.7"x5.51"x5.51" 1.0 MaxWhite B White
M120H 120" (16:9) 58.8 104.6 149.4 265.7 1.5" 21.7 25.7 9.9 11.7 112"X5.51"X5.51" 1.0 MaxWhite B White
M120X 120" (16:10) 63.6 101.8 161.5 258.4 1.5" 21.4 24.7 9.7 11.2 106.1"x5.51"x5.51" 1.0 MaxWhite B White
M135H 135" (16:9 66.2 117.2 168.1 267.7 1.5” 32.1 41.4 14.6 18.8 128”x6.3”x6” 1.0 MaxWhite B White
M135V 135" (16:9) 81.0 108.0 205.7 274.3 1.5” 30.3 37.6 13.7 17.0 118”x6.5”x6” 1.0 MaxWhite B White
Model Number Diag. Size Aspect Ratio
Screen
Material
Case Length
(A)
View Width
(A1)
Screen Width (A2)
Weight bar
Length (A3)
Screw Hole
Distance (A4)
Overall Height
(B)
View Height
(B1)
(B2) (B3)
Model Number Diag. Size Aspect Ratio
Screen
Material
Case Length
(A)
View Width
(A1)
Screen Width (A2)
Weight bar
Length (A3)
Screw Hole
Distance (A4)
Overall Height
(B)
View Height
(B1)
(B2) (B3)
M100S
100"
1:1
MaxWhite B
77.1
70.5
72.7
75.7
75.3
79.4
70.5
2.9
76.1
M100V
100"
4:3
MaxWhite B
86.4
80.0
82.2
85.2
84.8
71.6
60.0
5.5
68.2
M100H
100"
16:9
MaxWhite B
93.8
87.2
89.4
92.4
92
59.8
49.0
4.7
56.4
M100X
100"
16:10
MaxWhite B
91.5
84.8
87.0
87.7
87.4
63.7
53.0
4.7
60.4
M120V
120"
4:3
MaxWhite B
102.3
99
96
102.1
101.6
83.4
71.9
4.5
79.6
M120H
120"
16:9
MaxWhite B
110.9
107.6
104.6
110.7
111.4
82.5
65.7
4.5
69.4
M120X
120"
16:10
MaxWhite B
108.1
104.8
101.8
107.9
107.3
74.9
63.5
4.5
71.2
M100S
100"
1:1
MaxWhite B
1958
1790
1846
1923
1913
2017
1790
74
1933
M100V
100"
4:3
MaxWhite B
2194
2032
2088
2164
2154
1819
1524
140
1732
M100H
100"
16:9
MaxWhite B
2382
2214
2270
2347
2337
1519
1245
119
1433
M100X
100"
16:10
MaxWhite B
2323
2154
2210
2228
2220
1618
1346
119
1534
M120V
120"
4:3
MaxWhite B
2598
2515
2438
2593
2581
2118
1826
114
2026
M120H
120"
16:9
MaxWhite B
2817
2733
2657
2812
2829
2096
1670
114
1763
M120X
120"
16:10
MaxWhite B
2746
2662
2586
2741
2725
1902
1613
114
1808
www.elitescreens.com/manualb2
Manual B Series Dimension Table (135”)
Note: Data Error ±1". The listed measurements are for general reference only. Please contact Elite Screens to verify product design and dimensions before attempting to integrate its products with any structural
or furniture modification. Although a manufacturer may offer product advice, it may be taken or disregarded at the integrator’s discretion. Elite Screens will not be held responsible or be otherwise liable for faulty
installations.
Unit: inch
Unit: mm
Model
Number
Diag. Size
Aspect
Ratio
Screen
Material
Case Length
(A)
Viewable
Width (A1)
Screen Width
(A2)
Weight bar
Length (A3)
Screw Hole
Distance (A4)
Overall
Height (B)
Viewable
Height (B1)
Black Masking
(B2)
(B3)
Model
Number
Diag. Size
Aspect
Ratio
Screen
Material
Case Length
(A)
Viewable
Width (A1)
Screen Width
(A2)
Weight bar
Length (A3)
Screw Hole
Distance (A4)
Overall
Height (B)
Viewable
Height (B1)
Black Masking
(B2)
(B3)
M135V
135”
4:3
MaxWhite B
115.8
108.0
111.0
111.2
113.8
102.7
81.0
17.7
98.9
M135H
135”
16:9
MaxWhite B
126.0
117.2
121.3
121.5
124.0
89.7
66.2
17.7
85.9
M135V 135” 4:3
MaxWhite B
2940
2743
2820
2825
2890
2609
2057
450
2513
M135H 135” 16:9
MaxWhite B
3200
2977
3080
3085
3150
2279
1681
450
2183
www.elitescreens.com/manualb3
