Electromagnetic elds (EMF)
This Philips appliance complies with all
standards regarding electromagnetic elds
(EMF). If handled properly and according
to the instructions in this user manual, the
appliance is safe to use based on scientic
evidence available today.
Preparing for use
Inserting the batteries
The appliance operates on two R6 AA
1.5-volt alkaline batteries. Preferably insert
new Philips alkaline batteries to get optimal
shaving performance.
Make sure that your hands are dry when
you insert the batteries.
1 Remove the lid of the battery
compartment (Fig. 3)
2 Place two batteries in the battery
compartment (Fig. 4).
Note: Make sure the + and - indications on
the batteries match the indications in the
battery compartment.
Note: The shaver does not work if the
batteries have been placed incorrectly.
3 Put the lid of the battery
compartment back onto the appliance.
First place the top part of the lid (1)
and then press down the bottom part
until you hear a click (2) (Fig. 5).
How to avoid damage due to
battery leakage
- Do not expose the appliance to
temperatures higher than 35°C.
- Remove the batteries if you are not
going to use the appliance for a month
or more.
- Do not leave empty batteries in the
appliance.
Shaving time
Two new Philips alkaline batteries offer a
shaving time of 60 minutes.
Using the appliance
1 Remove the protection cap.
2 Press the on/off slide to unlock it
and push it upwards to switch on the
shaver (Fig. 6).
The on/off slide has an integrated switch
lock to prevent accidental switching on of
the shaver.
ENGLISH
Introduction
Congratulations on your purchase and
welcome to Philips! To fully benet from
the support that Philips offers, register your
product at www.philips.com/welcome.
General description (Fig. 1)
1 Protection cap
2 Shaving heads
3 Shaving unit
4 Retaining frame
5 Central spring of retaining frame
6 Release button
7 Hair chamber
8 On/off slide
9 Lid of battery compartment
10 Philips Cleaning Spray (HQ 110)
(Optional)
11 Cutter
12 Guard
13 Cleaning brush
Important
Read this user manual carefully before you
use the appliance and save it for future
reference.
Warning
- Keep the appliance dry.
- This symbol means: Forbidden to clean
with water (Fig. 2).
- This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning
use of the appliance by a person
responsible for their safety.
- Children should be supervised to
ensure that they do not play with the
appliance.
Caution
- Use and store the appliance at a
temperature between 5°C and 35°C.
- Remove the batteries from the
appliance if you are not going to use it
for a month or more.
- Use Philips batteries to achieve optimal
shaving performance.
- Only use the cleaning brush supplied.
- Make sure the cleaning brush remains
clean.
3 Move the shaving heads over your
skin. Make both straight and circular
movements (Fig. 7).
Note: Shave on a dry face only. Do not use the
shaver in combination with gel, foam or water.
Note: Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
4 Push the on/off slide downwards to
switch off the shaver.
5 Clean the shaver after every
shave, see chapter ‘Cleaning and
maintenance’.
6 Put the protection cap on the shaver
after use to prevent damage and to
avoid dirt accumulation in the shaving
heads (Fig. 8).
Cleaning and maintenance
Never use scouring pads, abrasive cleaning
agents or aggressive liquids such as petrol
or acetone to clean the appliance.
Clean the shaver after every shave to
guarantee better shaving performance.
For the best cleaning result, we advise you
to use Philips Cleaning Spray (HQ110).
Ask your Philips dealer for information.
Note: Philips Shaving Head Cleaning Spray
(HQ110) may not be available in all countries.
Contact the Customer Care Centre in your
country about the availability of this accessory.
After every shave: shaving unit
and hair chamber
1 Switch off the shaver.
2 Clean the top of the appliance with
the cleaning brush supplied (Fig. 9).
3 Press the release button (1) and pull
the shaving unit a straight up off the
shaver (2) (Fig. 10).
4 Clean the inside of the shaving unit
with the cleaning brush (Fig. 11).
5 Clean the hair chamber with the
cleaning brush (Fig. 12).
6 Put the shaving unit back onto the
shaver (Fig. 13).
PQ208, PQ207, PQ206, PQ205,
PQ203, PQ202
Register your product and get support at
www.philips.com/welcome
4222.002.5270.3
1
2
3 4
5
6 7
8 9
10
11
12 13
14
15 16
17
18 19
20 21
22
23
24 25
