PATIO HEATER USER MANUAL
MODEL: PHF-1500R
Thank you for choosing Trustech patio heater!
This user manual will provide you with valuable information necessary for the proper care and
maintenance of your new product. Please take a few moments to thoroughly read it and start
enjoying your warm winter!
Always here to help you
INTRODUCTION
Please take a few minutes to read this manual carefully.
Proper maintenance and operation of this machine can provide better service.
WARNINGS
Do not use the heater with a programmer, timer, separate remote-control system or any
other device that switches the heater on automatically, since a fire risk exists if the heater is
covered or positioned incorrectly.
It’s dangerous to install the appliance close to curtains and other combustible materials.
Do not use the heater in reach of a shower, bath or a swimming pool.
Heater is not located immediately below a socket-outlet
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
a similarly qualified person in order to avoid a hazard.
In order to avoid overheating, do not cover the heater。
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved.children shall not play with the appliance. cleaning
and user maintenance shall not be made by children unless they are older than 8 and
supervised.
Keep the appliance and its cord out of reach of children less than 8 years.
WARNING: This heater is not equipped with a device to control the room temperature. Do
not use this heater in small rooms when they are occupied by persons not capable of
leaving the room on their own, unless constant supervision is provided
Pay attention that, no combustible material due to Wind or other environmental influences
covers or obstructs the appliance, such as curtains, marquees, flags, plastic foil etc.
CAUTION — Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
When using this electric unit, basic safety precautions should be followed to reduce the risk of
fire, electric shock, and injury to persons, including the following:
Read ALL instructions before using this unit.
CAUTION: Risk of Electric Shock. DO NOT open or try to repair the heater yourself.
This heater may get hot when in use. To avoid burns, DO NOT let bare skin touch hot
surfaces. If provided, use handles when moving this heater.
Keep combustible materials, such as furniture, pillows, bedding, paper, clothes, and curtains
at least 3 ft from the front of the heater and keep them away from the sides, top, and rear.
DO NOT place towels or other objects on the heater.
Extreme caution is necessary when any heater is used by or near children or the disabled, or
when the heater is left operating and unattended.
DO NOT operate any heater with a damaged cord or after the heater malfunctions, has been
drooped or damaged in any manner. Return heater to authorized service facility for
examination, electrical or mechanical adjustment, or repair.
This heater is not intended for use in bathrooms, laundry areas and similar indoor locations.
NEVER locate heater where it may fall into a bathtub or other water container. To protect
against electrical hazards, DO NOT immerse in water or other liquids.
DO NOT touch the control panel with a wet hand.
DO NOT run cord under carpeting. DO NOT cover cord with throw rugs, runners, or similar
coverings. Arrange cord away from traffic area and where it will not be tripped over.
DO NOT insert or allow foreign objects to enter any ventilation or exhaust opening as this
may cause an electric shock or fire, or damage the heater.
To prevent a possible fire, DO NOT blocks the air intakes or exhaust in any manner. DO NOT
use on soft surfaces, like a bed, where openings may become blocked.
A heater has hot and arcing or sparking parts inside. DO NOT use in areas where gasoline,
paint, explosive and/or flammable liquids are used or stored. Keep unit away from heated
surfaces and open flames.
Avoid the use of an extension cord because the extension cord may overheat and cause a
risk of fire. However, if you have to use an extension cord, the cord shall be 1.5m
㎡
minimum size.
To disconnect heater, turn controls to OFF.
Always turn off the unit before moving or cleaning, or whenever the heater is not in use.
Use only for intended household use as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock, or injury to persons. The
use of attachments not recommended or sold by unauthorized dealers may cause hazards.
WARNING: To reduce the risk of fire or electric shock, DO NOT use this unit with any
solid-state speed control device.
DO NOT attempt to repair or adjust any electrical or mechanical functions on this unit. Doing
so will void your warranty. The inside of the unit contains no user serviceable parts.
Qualified personnel should perform all servicing only.
Connect to properly grounded outlets only.
This appliance is not intended for use by persons (including children) with reduced physical.
Sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
The marketing concerning covering shall be visible after the heater has been installed.
Save these instructions
SPECIFICATION
Voltage Rating
120 V(60Hz)
Power Consumption
1500W
Unit Size
24.4in. (W)
×
6.3in. (D)
×
7.3in. (H)
Unit Weight
4.9 lbs
SAFETY FEATURES
CAUTION: Before fitting or removing the appliance, ensure that the heater's power line supplying
the heater is disconnected. Check that the power line is connected to a 30mA differential circuit
breaker.
This appliance is designed for use in gardens ,and any room in your house, including those
where there is a risk of splashing. The installation and use of your appliance must comply
with the applicable standards in your country.
When it is switch on, an electrical heating appliance reaches very high temperature libel to
cause burns. Make sure that all other users are aware of the risks.
If you have any doubts concerning installation possibilities for this heater, please consult a
qualified electrician.
Children, the elderly and the infirm may not always be aware of the danger involved in using
electrical appliances. Never allow this appliance to be used without supervision.
The appliance must be positioned so that the plug is accessible.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent
or similar qualified person in order to avoid a hazard
The heater must not be located immediately below a socket-outlet
Do not use this heater with a programmer, timer or any other device that switches the
heater on automatically, since a fire risk exists if the heater is covered or positioned
incorrectly.
Do not place the appliance close to curtains and other combustible materials.
INSTALLATION INSTRUCTIONS
There are 4 brackets and fasteners used with the heater. Furthermore, in the canal of back side of
the heater there are 4 square fastener washers 25
×
25mm.Relieve square washers and fasten 2
brackets to the canal of the backside of the heater by the help of screws
Fasten the brackets at the appropriate distance of each other(45-55cm)
Two other brackets are fastened by the help of fasteners at the appropriate
distance on the wall parallel to the floor(At least 1.8 m from the floor and at
least 0.5 m from the ceiling).
Join the brackets on the heater with the brackets, fastened on the wall, with
help of figured screw-nuts.Install the heater under necessary
angle(in the direction to the area being heated)
Electric wiring for the heater has to be done by the qualified specialist.
APPLICATION FIELDS
Install the heater strict in horizontal position i.e.
PARALLEL TO FLOOR
Prevent the lost of directed heat through the windows.
OPERATING INSTRUCTION
Turn on the power and the power indicator will light. Then turn
the thermostat to maximum and the heater starts to work. When
the desired room temperature is reached, slowly turn the
thermostat knob counterclockwise until the thermostat is turned
off and the power indicator is dark
After that, the heater will maintain the indoor air temperature at
the set temperature by automatically turning it on and off.
MAINTENANCE
Attention! Careful and regular maintenance of heater is required to attain a long and efficient
operation of your appliance.
1. Check the cleanliness of the reflector and IR-filament at least once a month. If necessary,
apply cleaning and maintenance instructions.
2. The number of checks may be increased considering the amount of the dust in the
environment.
3. Check the deformation of the reflector, wire and frame visually while cleaning the appliance.
In case of any deformation, consult a qualified technician.
4. Check the power cable and plug visually while cleaning the appliance. In case of any
deformation, consult a qualified technician.
5. It is recommended to change the reflector every 2 years for more efficient operation.
CLEANING
1. Attention! Regular and careful cleaning helps your heater operate for longer years and more
efficiently.
2. Unplug your power cable for your safety before cleaning your appliance.
3. Take out the front grid wire through the inlets on the frame using a slotted screwdriver.
4. Make sure that the power is off for your safety. Power cable plug must be unplugged.
5. The reflector and filament must be cleaned with a soft cloth, a smooth brush or cool or dry
air. The cloth may be damp but never too wet and the cleaner should not include any
chemical.
6. Refrain from using cleaning material likely to damage the reflector (cleanser etc.).
7. Insert the wire grid using a slotted screwdriver.
TROUBLESHOOTING
If the heater will not operate, please check the following before seeking repair advice:
1. Check if the power cord is plugged into an electrical outlet, if not, plug in.
2. Check if electricity to the main power switch (in the beside) is working.
NOTE: For the heater to function properly, the desired temperature on the heater must
be set a few degrees higher than the temperature in the room. If the seems to not be
heating, increase the desired temperature on the heater to engage the heat elements.
STORAGE
Store the heater in a cool, dry location when not in use. To prevent dust and dirt build-up, use the
original packaging to repack the unit.
WARRANTY
TRUSTECH warrants this product against defects in materials and/or workmanship under normal
use for a period of ONE (1) YEAR from the date of purchase by the original purchaser (
“
Warranty
Period
”
). If a defect arises and a valid claim is received within the Warranty Period, at its option,
TRUSTECH will either 1) repair the defect at no charge, using new or refurbished replacement
parts, or 2) replace the product with a new product that is at least functionally equivalent to the
original product, or provide a store credit in the amount of the purchase price of the original
product. A replacement product or part, including a user-installable part installed in accordance
with instructions provided by TRUSTECH, assumes the remaining warranty of the original product.
When a product or part is exchanged, any replacement item becomes your property and the
replaced item becomes TRUSTECH
’
s property. When a store credit is given, the original product
must be returned to TRUSTECH and becomes TRUSTECH
’
s property. To obtain warranty service,
e-mail TRUSTECH Limited Warranty Service at Support@trustechproducts.com. Please be
prepared to describe the product that needs service and the nature of the problem.
This warranty does not apply to:
a. damage caused by failure to follow instructions relating to product’ use or the installation
of components;
b. damage caused by accident, abuse, misuse, fire, floods, earthquake or other external
causes;
c. damage caused by service performed by anyone who is not a representative of AIR CHOICE;
d. accessories used in conjunction with a covered product
e. a product or part that has been modified to alter functionality or capability;
f. items intended to be periodically replaced by the purchaser during the normal life of the
product including, without limitation, batteries or light bulbs;
g.
any product sold
“
as is
”
including, without limitation, floor demonstration models and
refurbished items; or
h. a product that is used commercially or for a commercial purpose.
CONTACT US
Thank you for choosing TRUSTECH product.
For any customer product questions or honor your warranty, please write to
Support@trustechproducts.com. Our usual response time is within 12 hours!
