User Manual Samsung DV80T6420LE/SA 8kg Heat Pump Smart Dryer

• Owner's manual - (English)

User manual Heat Pump Dryer for Samsung DV80T6420LE/SA

Contents

• Safety information
• What you need to know about the safety instructions
• Important safety symbols
• Important safety precautions
• To minimize the risk of fire in a tumble dryer, the following should be observed
• Critical installation warnings
• Critical usage warnings
• Usage cautions
• Critical cleaning warnings
• Care for preventing freezing
• Installation
• What’s included
• Installation requirements
• Step-by-step installation
• Door reversal
• Environment
• Before you start
• Initial setup
• Drying guidelines
• Operations
• Control panel
• Operating a cycle
• Cycle overview
• Additional functions
• System functions
• Special features
• Maintenance
• Emptying the water tank
• Cleaning
• Troubleshooting
• Checkpoints
• Information codes
• Appendix
• Fabric care chart
• Protecting the environment
• Specification

Care for preventing freezing

• Install the dryer in an area where the temperature does not drop below zero degree Celsius.
• If draining directly using a long drain hose, water remaining inside the hose can freeze in winter. Make sure there is no water left inside the hose after use.
• If the drain hose has frozen, wrap the hose with a towel soaked in warm water for approximately ten minutes to thaw it.

Cleaning

Exterior

• Clean with a soft, damp cloth. Do not use abrasive cleaners. Avoid using or placing sharp or heavy objects near/on the dryer. Keep detergent and laundry supplies on the pedestal (sold separately) or in a separate storage container.

Control panel

• Clean with a soft, damp cloth. Do not use abrasive cleaners. Do not spray cleaners directly on the panel.
• Immediately wipe up any spills or liquids from the control panel.

Drum

• Clean with a damp cloth with a mild, non-abrasive cleaner suitable for stainless steel.
• Wipe remaining residue with a clean, dry cloth.

Door

• Foreign substances can contaminate or build up on the inside of the door. Clean the inside of the door using a soft piece of cloth or brush.

Lint filter

Clean the lint filter after each use.

1. Open the dryer door, grab the top of the lint filter, and pull to remove the filter. Do not detach the rubber sealing after removing the filter.
2. Open the outer filter and remove the inner filter
3. Spread open the outer filter and the inner filter.
4. Remove the lint from both filters, and then clean the filters with the cleaning brush
5. Put the inner filter into the outer filter, and then reinsert the lint filter into the original position.
