PET731Portable DVD player
Register your product and get support at
www.philips.com/welcome
User manual
1
3
4
5
8
10
13
17
9
16
18
15
14
2
6
12
11
7
1
2
2
5
3
4
1
6
7
8
9
10
11
12
13
14
15
16
Content
1 Control elements
and functional com-
ponents
1.1 Main unit controls
1.2 Remote Control
2 Introduction
2.1 Your portable DVD
player
2.2 Unpacking
2.3 Placement
2.4 Playable disc formats
2.5 Zero Bright Dot
TM
3 General information
4 Charging the units
4.1 Charge the DVD player
4.2 Powering your remote
control
5 Start up
5.1 Setup
5.2 Playback DVD
5.3 Playback VCD
5.4 Playback Super (S)-VCD
5.5 Playback Music CD
5.6 Playback Music
MP3/WMA-CD
5.7 Playback Picture-CD
5.8 Playback from SD/MMC
card
6Addition Functions
6.1 DISPLAY Menu
6.2 Connection
6.2.1 Headphone
6.2.2 TV
6.2.3 Component
Video(YPbPr/YCbCr)
6.2.4 SD/MMC card slot
6.2.5 Coaxial
7Troubleshooting
8Technical data
English
Congratulations on your purchase and welcome
to Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
1.1 Main unit controls (see figure 1)
1POWER Switch the player on / off
2 9 Press once to stop playback and store the stop
position. Press twice to stop playback completely.
3 2; Start / pause / resume playback
4 J( / )K previous/next track or fast search backward/forward
5
- VOL +
Volume control
6 OPTIONS Access additional functions
7 MENU Display MENU page
8 3, 4, 1, 2 Up / down / left / right cursor
OK Confirm selection
9 OPEN Open disc door to insert or remove disc
10 POWER•IR•CHG
Power / Remote sensor / charging indicator
11 SD/MMC CARD
Insert SD/MMC card
12 COAXIAL Digital audio output
13 DC IN 12V Power supply socket
14 COMP. OUT Component video output
15 AV OUT Audio/Video output
16 1 p 2 Headphones jacks
17 RESET Reset the player when it is hanged up
18 Car mounting screw hole
1.2 Remote Control (see figure 2)
1 MENU Display MENU page
2 3, 4, 1, 2 Up / down / left / right navigation key
OK Confirm selection
VOL+ / - Volume control
3 DISPLAY Adjust the display value of the system
4 J( Skip to previous chapter, track or title
5 2; Start / pause / resume playback
6 9 Press twice to stop playback
70- 9 Numeric keypad
8 SUBTITLE Subtitle language selector
9 RETURN For VCD menu page
10 A - B To r epeat or loop a sequence in a title
11 SETUP Enter SETUP menu
12 OPTION Access additional functions
13 )K Skip to next chapter, track or title
14 s Mute player volume
15 AUDIO Audio language selector
16 ZOOM Enlarge video image
2 Introduction
2.1 Your portable DVD player
Your portable DVD player plays digital video discs conforming to
the universal DVD Video standard.With it, you will be able to enjoy
full-length movies with true cinema picture quality, and stereo or
multichannel sound (depending on the disc and on your playback
set-up).
The unique features of DVD-Video, such as selection of soundtrack
and subtitle languages, and of different camera angles (again depend-
ing on the disc), are all included.What’s more, parental lock lets you
decide which discs your children will be able to see.You will find
your player remarkably easy to use with the On-Screen Display and
player display in combination with the remote control.
2.2 Unpacking
First check and identify the contents of your package, as listed below:
•Portable DVD player • Remote Control
• Car adaptor • User manual
•AC power adaptor • Car headrest mounting kit
• Audio/Video cable • Component cable
2.3 Placement
• Place the player on a firm, flat surface.
•Keep away from domestic heating equipment and direct sunlight.
• If the player cannot read CDs/DVDs correctly, try using a com-
monly available cleaning CD/DVD to clean the lens before taking
the player to be repaired. Other cleaning methods may destroy
the lens.
•Always keep the disc door closed to avoid dust on the lens.
• The lens may cloud over when the player is suddenly moved
from cold to warm surroundings. It is then not possible to play a
CD/DVD. Leave the player in a warm environment until the
moisture evaporates.
2.4 Playable disc formats
In addition to DVD-Video disc, you will also be able to play all
Video CDs, CDs, CDR, CDRW,DVD±R and DVR±RW.
2.4.1 DVD-Video
Depending on the material on the disc (a movie, video clips, a
drama series, etc.) these discs may have one or more Titles, and
each Title may have one or more Chapters.To make access easy
and convenient, your player lets you move between Titles, and also
between Chapters.
2.4.2 Video CD
Depending on the material on the disc (a movie, video clips, a
drama series, etc.) these discs may have one or more Tracks, and
tracks may have one or more indexes, as indicated on the disc
case.To make access easy and convenient, your player lets you
move between tracks and between indexes.
2.4.3 Audio CD / MP3 CD / WMA CD
Audio CDs / MP3 CD / WMA CD contain music tracks only.You
can play them in the conventional way through a stereo system
using the keys on the remote control and/or main unit, or via the
TV using the On Screen Display (OSD).
2.4.4 CD with JPEG files
You can also view JPEG still photos on this player.
2.4.5 DivX video discs
DivX is a popular media technology created by DivX, Inc. DivX
media files contain highly compressed video with high visual quality
that maintains a relatively samll file size. DivX files can also include
advanced media features like menus, subtitles, and alternate audio
tracks. Many DivX media files are available for download online, and
you can create your own using your personal content and easy-to-
use tools from DivX.com.
Offical DivX® Certified product. Plays all versions of DivX® video
(including DivX® 6) with standard playback of DivX® media files.
2.4.6 About SD Memory Card
SD Memory Card is a slim and compact bridge media linking various
kinds of digital equipment through its easy connectivity.The card's
control circuitry allows data to be read and written (in its protec-
tion area) only when appropriate external devices are detected.
Using decoder software, an SD Memory Card-compatible device can
play music, video clips and more without a drive mechanism like
those in CD and DVD players.
2.5 Zero Bright Dot
TM
Enjoy highest-quality images that are free from annoying blank spots
on the LCD screen. LCD displays commonly have imperfections,
termed as 'bright dots' by the LCD industry. A limited number of
bright dots were once considered an inevitable side effect of LCD
mass production.With Philips' strict quality control procedures
used in our Portable DVD Players, our LCD displays are produced
with zero tolerance for bright dots. Select Portable DVD Players
come with Philips Zero Bright Dot
TM
Policy to guarantee optimal
screen quality.Warranty service varies from region to region. Contact
your local Philips representative for more detailed information.
3 General information
Power Sources
This unit operates on a supplied AC adaptor, car adapter, or a
rechargeable battery pack.
• Make sure that the input voltage of the AC adaptor is in line
with the local voltage. Otherwise, the AC adaptor and unit may
be damaged.
• Do not touch the AC adaptor with wet hands to prevent elec-
tric shock.
• When connecting with car power (cigarette lighter) adaptor, be
sure the input voltage of the adaptor is identical with car voltage.
• Unplug the AC adaptor from the outlet when the unit is not
used for long periods of time.
• Hold the plug to disconnect the AC adaptor. Do not pull the
power cord.
Safety and maintenance
• Do not disassemble the unit for laser rays are dangerous to eyes.
Any service should be done by qualified service personnel.
• Unplug the AC adaptor to cut the power if liquid or objects get
inside the unit.
•Take care not to drop the unit or subject it to strong shocks,
which may cause malfunction.
• Do not expose to excessive heat caused by heating equipment
or direct sunlight.
• This product is not waterproof: do not allow your player to be
submersed in water.Water entering the player may cause major
damage.
• Do not use any cleaning agents containing alcohol, ammonia,
benzene, or abrasives as these may harm the player.
Please always use supplied AC/DC adaptor (AY4195)
• Apparatus shall not be exposed to dripping or splashing. Do not
place any sources of danger on the appartus (e.g. liquid filled
objects,lighted candles)
• Do not touch the lens!
Hearing Safety
Listen at a moderate volume.
• Using headphones at a high volume can impair your hearing.This product
can produce sounds in decibel ranges that may cause hearing loss for a
normal person, even for exposure less than a minute.The higher decibel
ranges are offered for those that may have already experienced some
hearing loss.
• Sound can be deceiving. Over time your hearing “comfort level”
adapts to higher volumes of sound. So after prolonged listening,
what sounds “normal” can actually be loud and harmful to your
hearing.To guard against this, set your volume to a safe level
before your hearing adapts and leave it there.
• Excessive sound pressure from earhones and headphones can
cause hearing loss.
To establish a safe volume level:
• Set your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and
clearly, without distortion.
Listen for reasonable periods of time:
•Prolonged exposure to sound, even at normally “safe” levels, can
also cause hearing loss.
• Be sure to use your equipment reasonably and take appropriate
breaks.
Be sure to observe the following guidelines when using
your headphones.
• Listen at reasonable volumes for reasonable periods of time.
• Be careful not to adjust the volume as your hearing adapts.
• Do not turn up the volume so high that you can’t hear what’s
around you.
•You should use caution or temporarily discontinue use in poten-
tially hazardous situations.
• Do not use headphones while operating a motorized vehicle,
cycling, skateboarding, etc.; it may create a traffic hazard and is
illegal in many areas.
• Important (for models with by-packed headphones): Philips guaran-
tees compliance with the maximum sound power of its audio players
as determined by relevant regulatory bodies only with the original
model of provided headphones. In case this one needs replacement,
we recommend that you contact your retailer to order a model
identical to that of the original provided by Philips.
•Traffic safety: do not use while driving or cycling as you may cause an
accident.
When the player is in use for a long period of time, the sur-
face will be heated.This is normal.
CAUTION Use of controls or adjustments or performance
of procedures other than herein may result in hazardous radia-
tion exposure or other unsafe operation.
Handling discs
• Do not attach paper or tape to the disc.
•Keep the disc away from direct sunlight or heat
sources.
• Store the disc in a disc case after playback.
•To clean, wipe the disc outwards from the center with a soft,
lint-free clean cloth.
On handling the LCD screen
The LCD is manufactured using high precision technology.You may,
however, see tiny black points that continuously appear on the
LCD.This is a normal result of the manufacturing process and does
not indicate a malfunction.
Environmental information
We have reduced the packaging to its minimum and made it easy to
separate into mono materials: cardboard, PS, PE and PET.Your set
consists of material which can be recycled if disassembled by a spe-
cialized company. Please observe the local regulations to dispose of
packaging, exhausted batteries and old equipment.
Copyright information
“DivX, DivX” Certified, and associated logos are trademarks of
DivX, Inc. and are used under license.”
All other brand and product names are trademarks of their respec-
tive companies or organizations.
Unauthorized duplication of any recordings downloaded from the
internet or made from CDs / VCDs / DVDs is a violation of copy-
right laws and international treaties.
The Windows Media and the Windows logo are registered trade-
marks of Microsoft Corporation in the United States and/or other
countries.
4 Charging the units
4.1 Charge the DVD player
Plug in the AC/DC adaptor
• The RED LED indicates that
charging is in progress.
• When the set is not in use,
it will take about 4 hours
to fully charge it.
The RED LED will turn off when the set is fully charged.
Tips:
* You can operate the DVD player while charging. However, it takes
longer time to fully charge the battery.
* When the low battery icon appears on the screen, please charge
the player.
* Rechargeable batteries have a limited number of charge cycles
and may eventually need to be replaced. Battery life and number
of charge cycles vary by use and settings.
4.2 Powering your remote control
1 Open the battery compartment. Remove the
protective plastic tab (first time users only).
2 Insert 1 x lithium 3V battery, type CR2025, then close
the compartment.
CAUTION
• Batteries contain chemical substances, so they should be
disposed of properly.
• Batteries shall not be exposed to excessive heat such as
sunshine, fire or the like.
• Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
• Incorrect use of batteries can cause electrolyte leakage and
will corrode the compartment or cause the batteries to burst.
• Remove the batteries if the set is not to be used for a long
time.
•Perchlorate Material – special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate.
5 Start up
5.1 Setup
1 Press SETUP.A list of features is shown.
2 Use 3 / 4 to highlight your selection.
3 Use 2 to enter a sub-menu
4 Use 3, 4, 1, 2 to highlight your desired setting and press OK to
confirm.
The SETUP menu includes:
General
Language Set On Screen Display (OSD) languages
PBC settings Set Playback Control function ON/OFF.This fea-
ture is available for Super VCD.
Power save Set Power Saving mode ON/OFF
DivX (VOD) Get the DivX (Video-On-Demand) code
Parental Set parental options
Set password Change password (default: 9999)
Factory settings Restore factory settings
Video
TV Display Set screen display aspect ratio
TV standard Set video output format to TV system
Mpeg 4 subtitle Select subtitle language for Mpeg 4 video, e.g.
DivX video
Audio
Dolby Set Dolby output
Digital (SPDIF) Set digital output format
5.2 Playback DVD
1 Briefly press POWER on the main control of the player to
switch on the set.
2 Open the disc door and insert the disc.
• The player will start to play the disc automatically.
3 Use 1, 2, 3, 4 to select an item from the DVD disc menu, such
as play now, select languages and subtitle, and press OK to con-
firm.
The following functions are available during playback:
Pause Press 2; to pause playback.You can resume
playback by pressing 2; again
Previous/Next Briefly press J( or )K once or several times to
select your desired chapters
Fast backward / Fast forward
Keep pressing J( or )K to initiate backward/for-
ward when 2x is shown on screen, press J( or )K
briefly to change speed to 4x, 8x, 16x, 32x or
resume normal playback.You may also press 2; to
resume normal playback.
Volume Control
Press + or - briefly or repeatedly to increase or
decrease the sound volume
Stop Briefly press 9 to stop playback
Subtitle Change subtitle display.The function is available
by pressing either the SUBTITLE or
OPTIONS key
Language Change language.The function is available by
pressing either the AUDIO or OPTIONS key
Angle Change the viewing angle provided in the DVD
disc.The function is available by pressing the
OPTIONS key.
Zoom Zoom in the screen, and then use the navigation
keys to pan the screen.The function is available by
pressing either the ZOOM or OPTIONS key
A-B Repeat Set repeat loop playback. Press A-B to set the
starting point and press A-B again to set the end-
ing point.Then, the player will repeat the loop
playback. Press A-B to cancel the loop playback
5.3 Playback VCD
1 Briefly press POWER on the main control of the player to
switch on the set.
2 Open the disc door and insert the disc.
• The set will start to play the disc automatically.
The following functions are available during playback:
Pause Press 2; to pause playback.You can resume
playback by pressing 2; again
Previous/Next Briefly press J( or )K once or several times to
select your desired track
Fast backward / Fast forward
Keep pressing J( or )K to initiate backward/for-
ward when 2x is shown on screen, press J( or )K
briefly to change speed to 4x, 8x, 16x, 32x or
resume normal playback.You may also press 2; to
resume normal playback.
Volume Control
Press + or - briefly or repeatedly to increase or
decrease the sound volume
Stop Briefly press 9 to stop playback
Language Some VCDs only contain 2 languages for selec-
tion.You can change the language using this func-
tion.The function is available by pressing either
the AUDIO or OPTIONS key
Zoom Zoom in the screen, and then use the navigation
keys to pan the screen.The function is available
by pressing either the ZOOM or OPTIONS
key
A-B Repeat Set repeat loop playback. Press A-B to set the starting
point and press A-B again to set the ending point.
Then, the player will repeat the loop playback. Press
A-B to cancel the loop layback
5.4 Playback Super (S)-VCD
(Super) Video CDs may feature PBC (Play Back Control).This
allows you to play the video CDs interactively, following the menu
on the display.
1 Briefly press POWER on the main control of the player to
switch on the set.
2 Open the disc door and insert the disc. If PBC is on, the disc
index menu will appear on the screen.
3 Use numeric keypad 0-9 to input your selection or select a play
option.
4 Press RETURN on the remote control to return to the previ-
ous menu.
5 To turn Playback Control mode on/off, please go to SETUP and
select PBC settings.
5.5 Playback Music CD
1 Briefly press POWER on the main control of the player to
switch on the set.
2 Open the disc door and insert the disc.
• The set will start to play the disc automatically.
The following functions are available during playback:
Pause Press 2; to pause playback.You can resume
playback by pressing 2; again
Previous/Next Briefly press J( or )K once or several times to
select your desired track
Fast backward / Fast forward
Keep pressing J( or )K to initiate backward/for-
ward when 2x is shown on screen, press J( or )K
briefly to change speed to 4x, 8x, 16x, 32x or
resume normal playback.You may also press 2; to
resume normal playback.
Volume Control
Press + or - briefly or repeatedly to increase or
decrease the sound volume
Repeat Press OPTIONS key to select Repeat 1 track
or Repeat all tracks
Shuffle Press OPTIONS key to turn shuffle playback
on or off
Stop Briefly press 9 to stop playback
A-B Repeat Set repeat loop playback. Press A-B to set the starting
point and press A-B again to set the ending point.
Then, the player will repeat the loop playback. Press
A-B to cancel the loop layback
5.6 Playback Music MP3/WMA-CD
1 Briefly press POWER on the main control of the player to
switch on the set.
2 Open the disc door and insert the disc.
• The set will start to play the disc automatically.
3 Use 1,2,3, 4 to select the folder and MP3/WMA file to be played.
The following functions are available during playback:
Pause Press 2; to pause playback.You can resume
playback by pressing 2; again
Previous/Next Briefly press J( or )K once or several times to
select your desired track
Fast backward / Fast forward
Keep pressing J( or )K to initiate backward/for-
ward when 2x is shown on screen, press J( or )K
briefly to change speed to 4x, 8x, 16x, 32x or
resume normal playback.You may also press 2; to
resume normal playback.
Volume Control
Press + or - briefly or repeatedly to increase or
decrease the sound volume
Repeat Press OPTIONS key to select Repeat 1 track
or Repeat all tracks
Shuffle Press OPTIONS key to turn shuffle playback
on or off
Stop Briefly press 9 to stop playback
5.7 Playback Picture-CD
The player can only read pictures in JPEG format.
1 Briefly press POWER on the main control of the player to
switch on the set.
2 Open the disc door and insert the disc.
• The set will start to play the disc automatically.
3 Use 1, 2, 3, 4 to select the folder and JPEG file to be played.
Pause Press 2; to pause playback.You can resume
playback by pressing 2; again
Previous/Next Briefly press J( or )K once or several times to
select your desired track
Rotate Press OPTIONS key to select rotate mode.
Then, use 1 to rotate the picture clockwise.
Use 2 to rotate the picture anti-clockwise.
Press OPTIONS key to exit rotate mode.
Slide show Press OPTIONS key to select Slide Show,
then press OK to confirm.
Zoom Zoom in the screen, and then use the navigation
keys to pan the screen.The function is available
by pressing either the ZOOM or OPTIONS
key
Stop Briefly press 9 on the right side of the player to
stop playback
5.8 Playback from SD MMC card
The SD/MMC card slot of the DVD player supports the playback of
JPEG/MP3/WMA/ DivX/ MPG-4 files.
1 Briefly press POWER on the main control of the player to
switch on the set.
2 Insert an SD/MMC memory card into the SD/MMC card slot.
• The player will browse and show the contents of the SD/MMC card
automatically.
3 Use 3, 4, 1, 2 to select the file you want to access, then press
OK to play it.
4 At the end of the playback, take out the SD/MMC memory card
from the DVD player.
• Transferring and recording of data from the DVD player to
the SD/MMC card is not possible.
• The DVD player does not support SDHC (high capacity SD
memory card).
• The browsing time varies with memory capacity of the
SD/MMC card.
6Addition Functions
6.1 DISPLAY Menu
When you press DISPLAY during playback, the following menu
will appear and you can access the corresponding function and
information:
Brightness It allows you to adjust the brightness of the
screen
Contrast It allows you to adjust the contrast of the
screen
Color It allows you to adjust the color of the screen
from cool, warm and normal.
Turn off LCD You can turn off the screen in some situations,
such as when connected to TV or playing music
discs.This can save the battery power
Battery level It shows type of power source in using.
6.2 Connection
6.2.1 Headphone
Connect the headphone to either one of the headphone jacks on the side
of the player.
6.2.2 TV
You can connect the player to a TV and enjoy your DVD.
6.2.3 Component Video(YPbPr/YCbCr)
Component Video connection provides higher picture quality.This
option must be available on your TV.
1 Press OPTION.
2 Press 3 or 4 to select SOURCE, then press 2 to enter its
sub-menu.
3 Press 3 or 4 to select YPbPr or YCbCr according to your
TV setting.
4 Press OK to confirm.
To exit the component video mode, press and hold RETURN.
Pr/Cr
Pb/Cb
Y
White
Red
White
Red
Yellow
White
Red
Yellow
6.2.4 SD/MMC card slot
You can play video/audio/picture files stored in an SD/MMC card by
inserting it into the SD/MMC CARD slot.
TIP Make sure the metal contact of the card to be inserted is fac-
ing down.
6.2.5 Coaxial
It provides digital audio output signal that you can connect to your
home theater equipment to decode the digital audio signal.
Yellow
7Troubleshooting
If it appears that the DVD-Video player is faulty, first consult this
checklist. It may be that something has been overlooked.
WARNING Under no circumstances should you try to
repair the set yourself as this will invalidate the guarantee.
If a fault occurs, first check the points listed, before taking the
set for repair. If you are unable to solve a problem by following
these hints, consult your dealer or service centre.
Symptom Remedy
No power • Check if both plugs of the mains cord
are properly connected.
• Check if there is power at the AC outlet
by plugging in another appliance.
• Check if battery pack is inserted appro-
priately.
• Check if car adaptor is connected
appropriately.
Distorted picture • Check the disc for fingerprints and clean
with a soft cloth, wiping from centre to
edge.
• Sometimes a small amount of picture
distortion may appear.This is not a mal-
function.
Completely distorted
picture / no colour in
the TV screen
The NTSC/PAL setting may be in the
wrong status. Match your TV’s setting with
the player’s setting.
No sound Check audio connections. If using a HiFi
amplifier, try another sound source.
Symptom Remedy
Disc can’t be played • Ensure the disc label is upwards.
• Clean the disc.
• Check if the disc is defective by trying
another disc.
The player does not
respond to the remote
control
Aim the remote control directly at the
sensor on the front of the player.Avoid all
obstacles that may interfere with the signal
path. Inspect or replace the batteries.
Distorted or B/W
picture with DVD
Use only discs formatted according to the
TV-set used (PAL/NTSC).
No audio at digital output • Check the digital connections.
Player does not respond
to all operating com-
mands during playback
• Operations are not permitted by the disc.
• Refer to the instructions in the disc inlay.
Cannot detect
SD/MMC card
•Take out the SD/MMC card and insert it
in again.The browsing time varies with
memory capacity of the SD/MMC card.
• The DVD player does not support
SDHC (high capacity SD memory card).
Player feels warm When the player is in use for a long period of
time, the surface will be heated.This is normal.
Display goes dimmer
when AC is unplugged
The unit is saving power to ensure longer
playtime with battery. It is normal. Réglez la
luminosité en appuyant sur le bouton DIS-
PLAY button.
8Technical data
Dimensions 20.4 x 16.8 x 3.3 cm
8.0 x 6.6 x 1.3 inches
Weight 1.0 kg / 2.19 lb
Power supply DC 12V 1.0A
Power Consumption ≤20W
Operating temperature range
0 - 50°C (32 - 122°F)
Laser wavelength 650nm
Video system NTSC / PAL / AUTO
PHILIPS reserves the right to make design and specification
changes for product improvement without prior notice.
Modifications not authorized by the manufacturer may
void users authority to operate this device.
All rights reserved.
Copyright information
The making of unauthorized copies of copy-protected material, including
computer programmes, files, broadcasts and sound recordings, may be an
infringement of copyrights and constitute a criminal offence.This equipment
should not be used for such purposes.
Disposal of your old product
Your product is designed and manufactured with high quality
materials and components, which can be recycled and
reused.When this crossed-out wheeled bin symbol is
attached to a product, it means the product is covered by
the European Directive 2002/96/EC.
Please be informed about the local separate collection system for elec-
trical and electronic products. Please act according to your local rules
and do not dispose of your old product with your normal household
waste.The correct disposal of your old product will help prevent
potential negative consequences to the environment and human health.
