USER
MANUAL
EN User Manual
Tumble Dryer
T9DHA866C
CONTENTS
1. SAFETY INFORMATION.............................................................................................3
2. CONDITIONS OF USE................................................................................................6
3. SAFETY INSTRUCTIONS.............................................................................................6
4. PRODUCT DESCRIPTION...........................................................................................8
5. CONTROL PANEL....................................................................................................... 9
6. FIRST TIME START-UP................................................................................................ 9
7. USING THE TOUCH SCREEN.................................................................................. 12
8.
WI-FI - CONNECTIVITY SETUP..........................................................................12
9. BEFORE FIRST USE................................................................................................... 14
10. PROGRAMMES........................................................................................................14
11. OPTIONS................................................................................................................. 17
12. DAILY USE................................................................................................................18
13. MACHINE SETTINGS..............................................................................................21
14. HINTS AND TIPS..................................................................................................... 25
15. CARE AND CLEANING.......................................................................................... 25
16. TROUBLESHOOTING.............................................................................................28
17. TECHNICAL DATA..................................................................................................30
18. ACCESSORIES.........................................................................................................31
19. WARRANTY .............................................................................................................32
www.aeg.com
2
IMPORTANT INFORMATION THAT MAY IMPACT
YOUR MANUFACTURER'S WARRANTY
Adherence to the directions for use in this manual is extremely important for
health and safety. Failure to strictly adhere to the requirements in this manual
may result in personal injury, property damage and affect your ability to make a
claim under the AEG manufacturer’s warranty provided with your product.
Products must be used, installed and operated in accordance with this manual.
You may not be able to claim on the AEG manufacturer’s warranty in the event
that your product fault is due to failure to adhere to this manual.
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com
Register your product for better service:
www.registeraeg.com
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1.
SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible if an incorrect
installation and use causes injuries and damages. Always
keep the instructions with the appliance for future
reference.
- Read the supplied instructions.
ENGLISH
3
- Warning; Risk of fire / Flammable materials
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent
disability.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Do not let children play with the appliance.
• Children of less than 3 years should be kept away
unless continuously supervised.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep detergents away from children.
• Keep children and pets away from the appliance when
the door is open.
• If the appliance has a child safety device, this should
be activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2
General Safety
•
Do not change the specification of this appliance.
• If the tumble dryer is put on top of a washing
machine, use the stacking kit. The stacking kit,
available from your authorized vendor, can be used
only with the appliance specified in the instructions,
supplied with the accessory. Read it carefully before
installation (Refer to the Installation leaflet).
• The appliance can be installed as freestanding or
below the kitchen counter with correct space (Refer to
the Installation leaflet).
www.aeg.com
4
• Do not install the appliance behind a lockable door, a
sliding door or a door with a hinge on the opposite
side, that would prevent the appliance door from
being fully opened.
• The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
• WARNING: The appliance must not be supplied
through an external switching device, such as timer, or
connected to a circuit that is regularly switched on and
off by a utility.
• Connect the mains plug to the mains socket only at
the end of the installation process. Make sure that the
mains plug is accessible after installation.
• Ensure good air ventilation in the located room to
avoid the backflow of unwanted gases into the room
from appliances burning gas or other fuels, including
open fires.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• Do not exceed the maximum load of 8 kg (refer to the
"Programme chart" chapter).
• Do not use the appliance if items have been soiled
with industrial chemicals.
• Wipe away lint or packaging debris that has
accumulated around the appliance.
• Do not run the appliance without a filter. Clean the lint
filter before or after each use.
• Do not dry unwashed items in the tumble dryer.
• Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers should
be washed in hot water with an extra amount of
detergent before being dried in the tumble dryer.
• Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes
ENGLISH
5
or pillows fitted with foam rubber pads should not be
dried in the tumble dryer.
• Fabric softeners, or similar products, should only be
used as specified by the product manufacturer’s
instructions.
• Remove all objects from items that could be a source
of fire ignition such as lighters or matches.
• WARNING: Never stop a tumble dryer before the end
of the drying cycle unless all items are quickly
removed and spread out so that the heat is
dissipated.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
2. CONDITIONS OF USE
This appliance is intended to be used in
household and similar applications such
as:
• Farm houses
• By clients in serviced apartments,
holiday apartments and other
residential type environments.
3. SAFETY INSTRUCTIONS
3.1 Installation
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use the appliance
where the temperature can be less
than 5°C or higher than 35°C.
• The floor area where the appliance is
to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Always keep the appliance vertical
when being moved.
• The rear surface of the appliance
must be put against the wall.
• When the appliance is in its
permanent position, check that it is
fully level with the aid of a spirit level.
If it is not, adjust the feet accordingly.
3.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
www.aeg.com
6
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
• This appliance complies with the
E.E.C. Directives.
3.3 Use
WARNING!
Risk of injury, electrical
shock, fire, burns or damage
to the appliance.
• Do not dry the damaged items which
contain padding or fillings.
• Only dry fabrics which are applicable
to dry in the tumble dryer. Follow the
instructions on the fabric label.
• If you have washed your laundry with
a stain remover start an extra rinse
cycle before you start the dryer.
• Do not drink or prepare food with the
condensed water/distilled water. It
can cause health problems to people
and pets.
• Do not sit or stand on the open door.
• Do not dry dripping wet clothes in the
tumble dryer.
• Oil-affected items can ignite
spontaneously, especially when
exposed to heat sources such as in a
tumble dryer. The items become
warm, causing an oxidation reaction
in the oil. Oxidation creates heat. If
the heat cannot escape, the items can
become hot enough to catch fire.
Piling, stacking or storing oil-affected
items can prevent heat from escaping
and create a fire hazard.
• If it is unavoidable that fabrics that
contain vegetable or cooking oil or
have been contaminated by hair care
products be placed in a tumble dryer
they should first be washed in hot
water with extra detergent -this will
reduce, but not eliminate, the hazard.
3.4 Internal light
WARNING!
Risk of injury.
• Visible LED radiation, do not look
directly into the beam.
• The LED lamp is dedicated to drum
lighting. This lamp cannot be reused
for other lighting purposes.
• To replace the internal light, contact
the Authorised Service Centre.
3.5 Care and cleaning
WARNING!
Risk of injury or damage to
the appliance.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• To prevent damage to the cooling
system be careful when you clean the
appliance.
3.6 Compressor
WARNING!
Risk of damage to the
appliance.
• The compressor and its system in the
tumble dryer is filled with the special
agent which is free from fluoro-chloro-
hydrocarbons. This system must stay
tight. The damage of the system can
cause a leakage.
3.7 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
3.8 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
ENGLISH
7
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
4. PRODUCT DESCRIPTION
1 2
8
3
4
5
6
7
10
9
1
Water container
2
Control panel
3
Internal lighting
4
Appliance door
5
Filter
6
Rating plate
7
Airflow slots
8
Condenser lid
9
Condenser cover
10
Adjustable feet
For ease of loading laundry
or ease of installation the
door is reversible. (see
separate leaflet).
www.aeg.com8
5. CONTROL PANEL
2
4 3
1
1
Program dial
2
Touch screen
3
Start/Pause button
4
On/Off button with
Auto Off
function
6. FIRST TIME START-UP
When you turn on your dryer for the first
time, the Start-up Screen (shows the AEG
logo and the time ) appears on the touch
screen and plays each time you turn on
the dryer.
After the animation plays, you are guided
through the initial setup procedure.
AEG
13.45
6.1 Language setup
1. Scroll the list of languages up or
down to find the language you want
to use and press it.
English
Deutch
Svenska
Italiano
Francais FR
IT
EN
DE
SV
Language1/4
2. To accept the language tap on OK, if
you want to change it tap onChange.
English
You’ve chosen:
Language2/4
Change OK
ENGLISH 9
6.2 Time setup
1. Scroll the bar of hours and minutes
to the right or left to set the current
time.
0124 02
0159 00
Clock 01:00
h
min
Clock3/4
2. To select the time tap on the clock
bar.
0124 02
0159 00
Clock 01:00
h
min
Clock3/4
3. To accept the time tap on OK, if you
want to change it tap onChange.
18:45
Current time:
Clock4/4
Change OK
6.3 More Settings
After you accept the current time, the
More Settings screen pop-up.
More settings to get the best results
from this machine will follow. Set
them now or later?
More Settings
Cancel OK
If you tap on Cancel, the program list
appears and in a few seconds it will
change in to the summary screen. The
dryer is ready to use.
Cottons
Machine Settings
Refresh
Synthetics
Mixed
1
h
50
min
Cupb.
30min
More
Cottons
Max 8kg
1h50min
Cupboard
Cupb.
30min
More
If you tap on OK, proceed to next
settings.
Water Hardness
To set the proper water
hardness level, read the
"
MACHINE SETTINGS:
Water Hardness
" chapter
carefully.
1. For optimal performance set the
water hardness by pressing Change
or press OK to leave the default
Medium water hardness.
For optimal performance set what
kind of water you have; soft, medium
or hard. Keep medium?
Water Hardness1/2
Change OK
2. To change default value scroll the
bar to the right or left, to set the
water hardness: Hard, Medium or
Soft.
www.aeg.com
10
Medium
MedWater Hardness
Water Hardness1/2
3. To select the value press the Water
Hardness bar.
Soft
SoftWater Hardness
2/2 Water Hardness
4. To accept the water hardness level
press OK, if you want to change it
press Change.
Soft
Your water hardness level is:
Water Hardness1/2
Change OK
Water Tank Warning
1.
If the external kit for water discharge
is installed (additional accessory), the
appliance automatically drains the
water from the water tank. In this
condition you are able to deactivate
the warnings of the water tank.
If external kit for water discharge is
setup you can choose to disable the
warnings of full water tank. Keep
warning?
Water Tank Warning2/2
Change OK
If you press OK, the warnings of full
water tank is still enabled. The
program list appears and in a few
seconds it will change in to the
summary screen.
Cottons
Machine Settings
Refresh
Synthetics
Mixed
1
h
50
min
Cupb.
30min
More
Cottons
Max 8kg
1h50min
Cupboard
Cupb.
30min
More
If you press
Change, proceed to next
step.
2. To confirm that the Full water tank
warning is disabled press OK, if you
want to change it press Change.
Full water tank warn-
ing is turned off
Water Tank Warning2/2
Change OK
ENGLISH
11
7. USING THE TOUCH SCREEN
Every time you turn on your dryer, the
Start-up Screen (shows the logo and the
time ) appears on the touch screen.
AEG
13.45
After the Start-up animation plays, the
program summary screen appears on the
touch screen.
Cottons
Max 8kg
1h50min
Cupboard
Cupb.
30min
More
The Summary Screen is divided into four
areas, where you can find:
• Max weight for cycle, program name,
dryness level.
Cottons
Max 8kg
Cupboard
1h50min
Cupb.
30min
More
• Time to end of the program or time
delay (if selected).
Cottons
Max 8kg
1h50min
Cupboard
Cupb.
30min
More
• The currently selected options for the
selected cycle.
Cottons
Max 8kg
1h50min
Cupboard
Cupb.
30min
More
• More options.
Cottons
Max 8kg
1h50min
Cupboard
Cupb.
30min
More
8. WI-FI - CONNECTIVITY SETUP
This chapter describes how to connect
the smart appliance to the Wi-Fi network
and to link it to a mobile devices.
By this functionality you can receive
notifications, monitor and control your
tumble dryer from your mobile devices.
To connect the appliance to enjoy the
full range of features and services you
need:
• Wireless network at home with
internet connection enabled.
• Mobile device connected to wireless
network.
Frequency 2.412 - 2.472 GHz for Eu-
ropean market
www.aeg.com12
Protocol IEEE 802.11b/g/n two
stream radio
Max power < 20dBm
8.1 Installing and configuring
AEG Life
When connecting the tumble dryer to
the application, stand near it with Your
smart device.
Make sure that your smart device is
connected to the wireless network.
1. Go to the App Store on your smart
device.
2. Download and install App AEG Life .
3. Make sure you started a Wi-fi
connection in the dryer. If not go to
the section below.
4. Start the application. Select the
country and language and login with
Your email and password. If you do
not have an account, create a new
one following the instructions in AEG
Life.
5. Follow the instructions on the App
for the appliance registration and
configuration.
A message appears on the appliance
display to confirm that the configuration
was successful.
8.2 Configuring the dryer
wireless connection
Have AEG Life downloaded and installed
on your smart device.
1. Tap on the Wi-Fi bar to switch the
connection on .
A pop-up message will appear, the icon
starts flashing and wireless module
begins starting up. It may take about 2
minute before it is ready.
Starting up
This might take up to 2 minutes.
Have your app ready
Wi-Fi
Cancel
When the wireless module is ready, pop-
up message will appear to inform you,
that the access point will be open for
about 3 minute.
Trying to connect to your
Access point will be open for 3
minutes.
Wi-Fi
Cancel
2. Configure the AEG Life app on your
smart device.
3. If the connectivity is configured, a
message appears on the dryer
display to confirm that the
configuration was successful.
Connected!
Signal strenght is good, 4/5
Wi-Fi
OK
4. Tap on OK to get back to the
machine settings list.
8.3 Remote Start Mode
You can start and stop a drying
programme remotely.
When the App is installed and the
wireless connection is complete, the
Remote Start Mode option will appear
among the available options.
To activate the remote start:
1. In the programme summery screen,
tap
More to enter the option list.
2. Tap on Remote Start Mode bar (ON
status).
The following message pops up:
ENGLISH
13
Cancel
Please press Start
To activate Remote Start Mode
Remote Start Mode
<Back
3. Press the Start/Pause button to
activate the Remote Start Mode.
The indicator appears on the
programme summary screen.
If the door is open, the
Remote Start Mode is
deactivated.
8.4 Over-the-air update
The App may propose an update for
downloading new features.
The update is accepted via App only.
If a programme is running, the App
notifies that the update will start at the
end of the programme.
During the update, the appliance shows
a message telling that update is running.
The appliance will usable again at the
end of the update, without any
notification about successful update.
If an error occurs, the appliance warns
that update has failed: just press any
buttons or turn the knob to return to
normal use.
9. BEFORE FIRST USE
Rear drum locks are
removed automatically when
dryer is activated for the first
time. Possible to hear some
noise.
To unlock the rear drum locks:
1. Switch on the appliance.
2. Set any programme.
3. Press the Start/Pause button.
Drum starts to rotate. Rear drum locks
are deactivated.
Before you use the appliance to dry
items:
• Clean the tumble dryer drum with a
moist cloth.
• Start a 1 hour programme with moist
laundry.
At the beginning of the
drying cycle (first 3-5 min)
there could be a slightly
higher sound level. This is
due to the compressor
starting up. This is normal for
compressor powered
appliances such as
refrigerators and freezers.
10. PROGRAMMES
Programmes
Load
1)
Properties / Fabric mark
Cottons Eco
2)
8 kg Cotton fabrics - Extra dry
/
Cottons 8 kg
Cycle defined to dry cottons items
of different size / different weaving
altogether.
/
Synthetics 3,5 kg Synthetic and mixed fabrics.
/
www.aeg.com14
Programmes
Load
1)
Properties / Fabric mark
Wool
1 kg
Woollen fabrics. Gentle drying for hand-washa-
ble woollens. Remove items immediately when
the programme is completed.
Silks
1 kg
Gentle drying of hand-washable
silks.
/
Outdoor 2 kg
Outdoor clothing, technical, sports
fabrics, waterproof and breathable
jackets, shell jackets with a remov-
able fleece or inner insulation.
Suitable for drying in tumble dryer.
/
Sports 2 kg
Sportswear, thin and light fabrics,
microfiber, polyester.
/
Jeans 8 kg
Leisure clothing such as jeans,
sweat-shirts of different material
thicknesses (e.g. at the neck, cuffs
and seams).
/
Business Shirts
1,5kg (or 7
shirts)/
Easy care fabrics for which a mini-
mum of ironing is necessary. The
drying results can be different from
one type of fabric to the other.
Shake the items before you put
them in the appliance. When the
programme is completed, Immedi-
ately remove the items and put
them on a hanger.
/
Refresh 1kg Refreshing textiles that were in storage.
Easy Iron
1 kg (or 5
shirts)
Easy care fabrics for which a minimum of ironing
is necessary. The drying results can be different
from one type of fabric to another. Shake the
items before putting them in the appliance.
When the programme has ended, immediately
remove the items and put them on a hanger.
/
Duvet 3 kg
Single or double duvets and pil-
lows (with feather, down or syn-
thetic fillings).
/
Bed Linen 3 kg
Bed linen such as single and dou-
ble sheets, pillowcases, duvet cov-
er.
/
Mixed 3 kg Cotton and synthetic fabrics.
/
1)
The maximum weight refers to dry items.
2)
For test institutes only: The Cottons Eco program is the “Standard Cotton Program”.
ENGLISH 15
10.1 Woolmark Apparel Care - Blue
The wool drying cycle of this machine has been
approved by The Woolmark Company for the
drying of wool garments labelled as "hand
wash" provided that the garments are dried ac-
cording to the instructions issued by the manu-
facturer of this machine. Follow the garment
care label for other laundry instructions. M1641
The Woolmark symbol is a Certification mark in
many countries.
10.2 Programs and options selection
Options
Programs
1)
Extra
Silent
Eco
Dry-
ness Level
Time
Dry
Anti-
crease
Load
Cottons Eco
Cottons
Synthetics
Wool
Silks
Outdoor
Sports
Jeans
Business
Shirts
Refresh
Easy Iron
Duvet
Bed Linen
Mixed
1)
Together with the program you can set 1 or more options.
www.aeg.com16
11. OPTIONS
11.1 Extra Silent
The appliance operates with low noise
without effect on the drying quality. The
appliance operates slowly with longer
cycle time.
11.2 Eco
This option is on by default with all
programs.
The power consumption is at the
minimum level.
11.3 Dryness Level
This function helps to get the laundry
more dried. There are 4 possible
selections:
• Extra Dry
• Cupboard Dry+ (for Cotton only)
• Cupboard Dry
• Iron Dry
11.4 Time Dry
For cottons, synthetics and mixed. Lets
the user to set drying time from
minimum 10 min to maximum of 2 hours
(in 10 min steps). When this option is
maximum, load indicator disappears.
The cycle lasts as long as set
time regardless the drying
result.
TIME DRYING RECOMMENDATION
10 min
action of cool air only (no dry-
ing).
20 - 40
min
additional drying to improve
dryness after previous drying
cycle.
>40 min
full drying of the small laundry
loads up to 4 kg, well centri-
fuged (>1200 rpm).
11.5 Anti-crease
Extends up to 120 minutes the anticrease
phase (30 minutes) at the end of the
drying cycle. After drying phase drum
rotates time to time what prevents the
clothes from creases. Laundry can be
removed during the anti-crease phase.
11.6 Load
This option is applicable only to the
Wool programme to get laundry more
dried. There are 3 possible selections:
• Heavy
• Normal
• Light
11.7 Delay Start
Lets to delay the start of a
drying program from
minimum of 10 minutes to
maximum of 24 hours.
1. Set the drying program and options.
2. In the option menu tap on the Delay
Start bar to enter the submenu.
3. Scroll left or right the hour and
minute bars to set the desired delay
start.
4. To activate Delay Start option, touch
the Start/Pause button.
After touching the Start/Pause button,
the appliance begins the countdown.
Cottons
Finished at 1:24 tomorrow
Starts in
10h30min
Reset
Any time you can stop the
countdown of the delay time
by pressing the Reset
button.
11.8 Memory
Lets you memorise up to 2 of your
favorite configurations of programmes
and options in the appliance memory.
After memorising configurations you are
able to choose them from the program
list.
ENGLISH
17
Your favorite configurations are marked
in the program list as M1 and M2.
12. DAILY USE
12.1 Preparing the laundry
• Close the zips.
• Close the fasteners of duvet covers.
• Do not dry ties or ribbons loose (e.g.
apron ribbons). Tie them before you
start a programme.
• Remove all items from pockets.
• Turn items with internal layer made of
cotton inside out. Cotton layer must
be faced outward.
• Always set the programme suitable
for the type of laundry.
• Do not put light and dark colours
together.
• Use suitable programme for cottons,
jersey and knitwear to reduce
shrinkage.
• Do not exceed the maximum load
stated in programmes chapter or
shown on the display.
• Dry only the laundry that is suitable
for tumble drying. Refer to the fabric
label on the items.
• Do not dry large and small items
together. Small items can be trapped
inside the large items and remain wet.
Fabric label Description
Laundry is suitable for tumble drying.
Laundry is suitable for tumble drying at higher temperatures.
Laundry is suitable for tumble drying at low temperatures only.
Laundry is not suitable for tumble drying.
12.2 Loading the laundry
CAUTION!
Ensure the laundry is not
trapped between the
appliance door and rubber
seal.
1. Pull open the appliance door.
2. Load the laundry one item at a time.
3. Close the appliance door.
12.3 Turning on the appliance
To turn on the appliance:
Push the On/Off button.
If the appliance is on the display lights
up.
12.4 Auto Off function
To decrease the energy consumption,
the Auto Off function turns off the
appliance automatically:
www.aeg.com
18
• if no selection was done in the last 5
minutes.
• after 5 minutes from the program
end.
Push the On/Off button to turn on the
appliance.
If the appliance is on the display lights
up.
12.5 Setting a program
• Use the program dial to set the
program.
Cottons
Machine Settings
Refresh
Synthetics
Mixed
1
h
50
min
Cupb.
30min
More
• You can also set the program, by
using the touch screen.
If the summary screen is on, tap on it
once to see the program list.
Cottons
Max 8kg
1h50min
Cupboard
Cupb.
30min
More
Scroll the program list up or down to
set the program.
Cottons
Machine Settings
Refresh
Synthetics
Mixed
1
h
50
min
Cupb.
30min
More
The possible time to complete the
program comes into the time bar.
The drying time you see is
related to the load of 5 kg
for cotton program. For the
other programs the drying
time is related to the
recommended loads. The
drying time of the cotton
program with the load more
than 5 kg is longer.
12.6 Options
Together with the program you can set 1
or more special options.
If you want to change the parameters of
the options currently selected, tap on the
option you want to edit.
Cottons
Max 8kg
1h50min
Cupboard
Cupb.
30min
More
To select additional options:
1. Tap on More to see list of the
options dedicated for the selected
program.
Cottons
Max 8kg
1h50min
Cupboard
Cupb.
30min
More
2. Scroll the options list up or down to
browse it.
ENGLISH
19
30min
00h00min
Cup.
ON
OFF
Dryness Level
Eco
Extra silent
Dry Time
Anti-crease
1
h
50
min
<Cottons
3. Tap the option to select it.
There are two types of options:
• with the status ON or OFF (eg. Eco).
• with the editable parameters (eg.
Dryness Level).
To change the parameter scroll the
parameter bar to the right or left.
Cupb.
Dryness Level
Cupb.
1
h
50
min
<Cottons
Tap on the previously selected option
to go back to the option list.
Cupb.
Dryness Level
Cupb.
1
h
50
min
<Cottons
Any time, you can get
directly to the summary
screen, if you tap on left part
of the top bar with the name
of the program.
Cupb.
Dryness Level
Cupb.
1
h
50
min
<Cottons
Cottons
Max 8kg
1h50min
Cupboard
Cupb.
30min
More
12.7 Starting a program
To start the program, Touch the Start/
Pause button.
The appliance starts and the LED above
the button stops flashing and stays on.
On the screen you can find:
• the name of the program.
• the remaining drying time.
• the progress bar.
• the phase of a cycle (drying,
anticrease, cooling).
• the possible end time of the program.
www.aeg.com
20
Cottons
Drying
Finished at 15:18
1h20min
Child lock option activation:
At any time during the drying you can
activate the child lock option.
1. Tap on the option icon to get to
the option list.
2. Tap on the child lock
option.
The option icon will change into the
child lock icon.
Cottons
Drying
Finished at 15:18
1h20min
To deactivate the child lock option tap
on and hold the child lock icon a few
seconds.
12.8 Program change
To change a program:
1. Push the On/Off button to turn the
appliance off.
2. Push the On/Off button again to turn
on the appliance.
3. Set a new program.
12.9 Program end
Clean the filter and drain the
water container after each
drying cycle. (See chapter
CARE AND CLEANING.)
If the drying cycle is finished, the symbol
0 appears on the display. If the Cycle
End Buzzer option is activated, the
acoustic signal sounds intermittently for
1 minute.
If you do not turn off the
appliance, the anti-crease
phase starts (not active with
all programs). Laundry can
be removed during this
phase.
At the end of the anti-crease
phase the display tells that
the anti-crease phase is
finished and shows 0h00min
To remove the laundry:
1. Push the On/Off button for 2
seconds to turn the appliance off.
2. Open the appliance door.
3. Remove the laundry.
4. Close the appliance door.
13.
MACHINE SETTINGS
In the programs screen scroll up or down
to find machine settings, and tap on the
icon to get to the settings list.
Machine Settings
Refresh
Easy Iron
Cottons
Syntetics
3
15h18min
ENG
Language
Set Clock
Display Brightness
<Programs
Machine Settings
13.1 Set Clock
You can change the clock each time you
want.
To change the time:
ENGLISH
21
1. Tap on the Set Clock bar.
2. Scroll the bar of hours and minutes
to the right or left to set the current
time.
01h00min
Set Clock
0124 02
0159 00
h
min
<Programs
Machine Settings
3. Tap on the Set Clock bar to get back
to the machine settings list or tap on
the <Programmes bar to get to the
summary screen.
13.2 Language
To change the language:
1. Tap on the Language bar.
2. Scroll the list of languages up or
down to find the language you want
to use and tap on it.
English
Deutch
Svenska
Italiano
Francais FR
IT
EN
DE
SV
LanguageBack
13.3 Display Brightness
You can control the brightness level of
the Display. There are 6 brightness
levels.
To improve readability of the
display when a dryer is
stacked over a washing
machine set the 6th level of
the display brightness. When
the dryer is not stacked level
1 to 5 are suggested.
To change the display brightness:
1. Tap on Display Brightness bar.
2. Scroll the bar to the right or left to
set the level of the brightness.
4
Dispaly Brightness
4 53
<Programs
Machine Settings
3. Tap on Display Brightness bar to
get back to the machine settings list
or tap on <Programmes bar to get
to the summary screen.
13.4 Cycle End Buzzer
The sound is heard at the:
• cycle end
• start and end of crease guard phase
You can use this option to deactivate the
buzzer or control the duration of the
buzzer . There are 3 levels of sound
duration (Short, Mid and Long).
To deactivate the buzzer or set the new
duration of the sound:
1. Tap on Cycle End Buzzer bar.
2. Scroll the bar to the right or left to
set the desired value.
Mid
Cycle End Buzzer
LongMidShort
<Programs
Machine Settings
3. Tap on Cycle End Buzzer bar to get
back to the machine settings list or
tap on <Programmes bar to get to
the summary screen.
www.aeg.com
22
13.5 Water Hardness
Water hardness can be
different for different
locations. Water hardness
has an effect on the water
conductivity and the
operation of the conductivity
sensor in the appliance. If
you know the value of the
water conductivity you can
adjust the sensor to dry with
the better results
(recommended to set the
"soft water hardness" to get
the laundry more dried).
The appliance allows you to chose
between 3 levels (Hard, Medium, Soft)
corresponding to different ranges of
water hardness.
ppm
the results from
the included
water hardness
kit.
Soft < 150 C01-C03
Medium 150 - 300 C04-C05
Hard > 300 C06-C07
Depending on the country, the water
hardness is expressed in equivalent
scales: e.g. French degrees (°f), German
degrees (°d), English degrees (°e),
mmol/l and ppm
If necessary, please contact your local
water authority to check the water
hardness in your area.
To change the default water hardness
level:
1. Tap on Water Hardness bar.
2. Scroll the bar to the right or left to
set the desired level.
Medium
Water Hardness
Medium
<Programs
Machine Settings
3.
Tap on Water Hardness bar to get
back to the machine settings list or
tap on <Programmes bar to get to
the summary screen.
13.6 Washing Spin Speed
This option helps to set the best
condition to dry the laundry. If you know
the initial spin speed when you washed
you can use this option. Higher spin
speed causes that the laundry contains
less water.
To change the washing spin speed:
1. Tap on the Washing Spin Speed bar
to expand the list of programmes for
which you can change the spin
speed.
2. Tap on the Cottons bar or Other
programmes bar.
OFF
Washing Spin Speed
Cottons
Other programmes
<Programs
Machine Settings
3. Scroll the bar to the right or left to
set the desired value of a spin speed
for .
OFF
Cottons
140012001000
<Programs
Machine Settings
ENGLISH
23
OFF
Others programmes
140012001000
<Programs
Machine Settings
4. Tap on the Cottons bar or Other
programmes bar to close the choice.
5. Tap on the Washing Spin Speed bar
to get back to the machine settings
list or tap on <Programs bar to get
to the summary screen.
13.7 Water Tank Warning
The water container indicator illuminates
at the end of the drying cycle or during
the cycle if the water reservoir is full. If
the draining kit is installed the water
container is drained automatically and
the indicator can be deactivated.
To deactivate or activate the indicator
tap on the Water Tank Warning bar.
One of 2 configurations is possible:
• The indicator is activated (status is
ON)
• The indicator is deactivated (status is
OFF)
13.8
Service
These settings are dedicated only for a
authorized service.
Reserved for service
Back
Services
13.9
Shortcuts
To activate the desirable shortcuts:
1. Tap on the Shortcuts bar to expand
the list of available shortcuts.
Child Lock
Cycle End Buzzer
ON
ON
<Back
Shortcuts
2. Tap on these shortcuts which you
want to activate by changing the
status to ON.
3. Tap on the <Back bar to get back to
the machine settings list.
The shortcuts shows up in the left corner
of the summary screen.
Cottons
Max 8kg
1h50min
Cupboard
Cupb.
30min
More
13.10
Machine Information
Here you can find a short description
about all programmes, options and
settings.
To find the desired description, e.g.:
1. Tap on the Machine Information
bar.
2. Tap on 1. Programmes bar.
3. Tap on Cottons bar and the relevant
description will appear.
13.11 Factory Reset
Factory Reset restores the settings to the
state where it was made out in the
factory.
To activate the factory reset :
1. Tap on the Factory Reset bar.
www.aeg.com
24
The dialog window pops up.
Do you want to clear all your
programmed settings?
Cancel OK
2. To confirm the factory reset tap on
OK or Cancel to leave the current
settings.
14. HINTS AND TIPS
14.1 Ecological hints
• Spin the laundry well before drying.
• Do not exceed the load sizes which
are specified in the programs chapter.
• Clean the filter after each drying
cycle.
• Do not use fabric softener to wash
and then dry. In the tumble dryer
laundry becomes soft automatically.
• Use distilled water like that used for
steam ironing. If it is necessary, clean
the distilled water before (e.g. with a
coffee filter) to remove any particles.
• Always keep the airflow slots at the
bottom of the appliance clear.
• Make sure there is good airflow where
the appliance is to be installed.
15. CARE AND CLEANING
15.1 Cleaning the filter
At the end of each cycle the message
Clean the lint filter comes on the
display and you must clean the filter.
The filter collects the fluff
during the drying cycle.
1. Open the door. Pull the filter up.
2. Push the hook to open the filter.
3. Use a moist hand to clean both parts
of the filter.
ENGLISH 25
4. If necessary, clean the filter with a
vacuum cleaner. Close the filter.
5. If necessary, remove fluff from the
filter socket and gasket. You can use
a vacuum cleaner. Place the filter
back inside the filter socket.
15.2 Emptying the water
container
Empty the condensed water container
after each drying cycle.
If the condensed water container is full,
the programme stops automatically. The
message Water Tank Warning comes
on the display and you must empty the
water container.
To empty the water container:
1. Pull the water container out keeping
it in a horizontal position.
2. Pull the plastic connection out and
drain the water into a basin or
equivalent receptacle.
3. Push the plastic connection back in
and place the water container back
into position.
4. To continue the programme press
the Start/Pause button.
15.3 Cleaning the condenser
If the message Clean the heat
exchanger area comes on the display,
inspect the condenser and its
compartment. If it is dirty, clean it. Do
the check not less than once a 6 months.
WARNING!
Do not touch the metal
surface with bare hands. Risk
of injury. Wear protective
gloves. Clean carefully to
avoid damaging the metal
surface.
To inspect:
1. Open the door. Pull the filter up.
2. Open the condenser cover.
3. Turn the lever to unlock the
condenser lid.
www.aeg.com
26
4. Lower the condenser lid.
5. If necessary, remove the fluff from
the condenser and its compartment.
You can use a wet cloth and/or a
vacuum cleaner with a brush
attachment.
6. Close the condenser lid.
7. Turn the lever until it clicks into
position.
8. Put the filter back.
15.4 Cleaning the drum
WARNING!
Disconnect the appliance
before you clean it.
Use a standard neutral soap detergent to
clean the inner surface of the drum and
drum lifters. Dry the cleaned surfaces
with a soft cloth.
CAUTION!
Do not use abrasive
materials or steel wool to
clean the drum.
15.5 Cleaning the control
panel and housing
Use a standard neutral soap detergent to
clean the control panel and housing.
Use a moist cloth to clean. Dry the
cleaned surfaces with a soft cloth.
CAUTION!
Do not use furniture
cleaning agents or cleaning
agents which can cause
corrosion.
15.6 Cleaning the airflow slots
Use a vacuum cleaner to remove fluff
from the airflow slots.
ENGLISH
27
16. TROUBLESHOOTING
Problem
1)
Possible cause Remedy
The tumble dry-
er does not op-
erate.
The tumble dryer is not connected
to the mains supply.
Connect to the mains socket.
Check fuse in fuse box (domestic
installation).
The door is open. Close the door.
The On/Off button was not push-
ed.
Push the On/Off button.
The Start/Pause button was not
touched.
Touch the Start/Pause button.
The appliance is in standby mode. Push the On/Off button.
Unsatisfactory
drying result.
Incorrect program selection.
Select a suitable program.
2)
The filter is clogged.
Clean the filter.
3)
Dryness Level option was set to
Iron Dry
.
Change Dryness Level option to
higher level.
The load was too large. Do not exceed the maximum load
size.
Load size is small. Select time programme. The time
value must be related to the load.
To dry 1 item or a few wet items up
to 4 kg after a washing cycle with
well centrifuged (>1200 rpm), set a
short drying time (>40 min).
If the time is set to less than 10
min, there will be action of cool air
only (no drying).
Selected drying time for Time Dry
option was to short.
Select time programme and set
additional drying (20 - 40 min) to
improve dryness after previous
drying cycle.
The airflow slots are clogged. Clean the airflow slots at the bot-
tom of the appliance.
Dirt on the humidity sensor in the
drum.
Clean the front surface of the
drum.
Dryness level not set to desired
level.
Adjust the dryness level.
4)
The condenser is clogged.
Clean the condenser.
3)
www.aeg.com28
Problem
1)
Possible cause Remedy
The loading
door does not
close
The filter is not locked into posi-
tion.
Put the filter in the correct posi-
tion.
Laundry is trapped between the
door and the seal.
Remove trapped items and close
the door.
Not possible to
change the pro-
gram or option.
After cycle start it is not possible to
change the program or option.
Turn the tumble dryer off and on.
Change the program or option as
required.
Not possible to
select an option.
Acoustic signal
is emitted.
The option you tried to select is
not available for the selected pro-
gram.
Turn the tumble dryer off and on.
Change the program or option as
required.
No drum light
Defective drum lamp. Contact the service centre to re-
place the drum lamp.
Unexpected du-
ration time on
the display.
The drying duration is calculated
according to load size and damp-
ness.
This is automated — the appliance
is working correctly.
Program inac-
tive.
The water container is full. Drain the water container, push
the Start/Pause button.
3)
Drying cycle too
short.
The laundry is too dry. Select time program or higher dry-
ness level (e.g.
Extra Dry
)
Drying cycle too
long
5)
The filter is clogged. Clean the filter.
The load is too large. Do not exceed the maximum load
size.
The laundry was not spun suffi-
ciently.
Spin the laundry well.
Too low or too high room temper-
ature - this is not the appliance
malfunction.
Ensure a room temperature higher
than +5°C and lower than +35°C.
Optimal room temperature to ach-
ieve best drying results is between
19°-24°C.
A message
Failed to con-
nect to your
WiFi appears on
the dryer screen
Disrupted wireless signal. Check Your home network and
router.
Restart the router.
Contact your wireless service pro-
vider if there are further problems
with the wireless network.
ENGLISH 29
Problem
1)
Possible cause Remedy
The App cannot
connect to the
dryer.
Disrupted wireless signal. Check if your smart device is con-
nected to the wireless network.
Check your home network and
router.
Restart the router.
Contact your wireless service pro-
vider if there are problems with the
wireless network.
A new home router has been in-
stalled or the router configuration
has been changed.
The dryer, the smart device, or
both, need to be configured again.
The App fre-
quently cannot
connect to the
dryer.
The wireless signal does not reach
the dryer.
Try to move the home router as
near the dryer as possible or con-
sider purchasing a wireless range
extender.
The wireless signal is disrupted by
microwave.
Turn the microwave off. Avoid us-
ing the microwave and the Remote
Control of the dryer at the same
time. The microwaves disrupt the
Wi-Fi signal.
1)
If there is an error message on the display (e.g. E51): Turn the tumble dryer off and on. Select a new
program. Push the Start/Pause button. If the appliance does not operate contact the service centre and
provide the error code.
2)
Follow the program description — see PROGRAMS chapter
3)
See chapter CARE AND CLEANING
4)
See HINTS AND TIPS chapter
5)
Note: After a maximum of 5 hours the drying cycle ends automatically.
17. TECHNICAL DATA
Height x Width x Depth 850 x 600 x 630 mm (maximum 660 mm)
Max. depth with the appliance door open 1100 mm
Max. width with the appliance door open 950 mm
Adjustable height 850 mm (+ 15 mm - feet regulation)
Drum volume 118 l
Maximum load volume 8 kg
Voltage 230-240 V
Frequency 50 Hz
Total power 700 W
www.aeg.com30
Type of use Household
Permitted ambient temperature + 5°C to + 35°C
Level of protection against ingress of solid
particles and moisture ensured by the pro-
tective cover, except where the low voltage
equipment has no protection against mois-
ture
IPX4
This product contains fluorinated greenhouse gases, hermetically sealed
Gas designation R134a
Weight 0,28 kg
Global-warming potential (GWP) 1430
18. ACCESSORIES
18.1 Stacking kit
Accessory name: SKP11, STA9
Available from your authorised vendor.
Stacking kit can be used only between
washing machines and tumble dryers
specified in the leaflet. See the leaflet
attached.
Read carefully the instructions supplied
with the accessory.
18.2 Draining kit
Accessory name: DK11.
Available from your authorised vendor
(can be attached to some types of
tumble dryer)
For thorough draining of the condensed
water into a basin, siphon, gully, etc.
After installation, the water container is
drained automatically. The water
container must stay in the appliance.
The installed hose must be minimum 50
cm to maximum 100 cm from floor level.
The hose cannot be in a loop. Decrease
the length of the hose if necessary.
Read carefully the instructions supplied
with the accessory.
ENGLISH
31
18.3 Pedestal with drawer
Accessory name: PDSTP10, E6WHPED2.
Available from your authorised vendor.
For increasing the height of the
appliance in order to ease loading and
unloading of laundry.
The drawer can be used for laundry
storage e.g. : towels, cleaning products
etc.
Read carefully the instructions supplied
with the accessory.
19. WARRANTY
FOR SALES IN AUSTRALIA AND NEW
ZEALAND
ALL AEG BRANDED APPLIANCES
This document sets out the terms and
conditions of the product warranties
for AEG Appliances. It is an important
document. Please keep it with your
proof of purchase documents in a safe
place for future reference should there
be a manufacturing defect in your
Appliance. This warranty is in addition
to other rights you may have under
the Australian Consumer Law.
1. In this warranty:
a) ‘ACL’ or ‘Australian Consumer
Law’ means Schedule 2 to the
Competition and Consumer Act
2010;
b) ‘Appliance’ means any Electrolux
product purchased by you and
accompanied by this document;
c) ‘ASC’ means Electrolux’s
authorised serviced centres;
d) ‘AEG’ is the brand controlled by
Electrolux Home Products Pty
Ltd of 163 O’Riordan Street,
Mascot NSW 2020, ABN 51 004
762 341 in respect of Appliances
purchased in Australia and
Electrolux (NZ) Limited
(collectively “Electrolux”) of 3-5
Niall Burgess Road, Mount
Wellington, in respect of
Appliances purchased in New
Zealand;
e) ‘Warranty Period’ means the
period specified in clause 3 of
this warranty;
f) ‘you’ means the purchaser of the
Appliance not having purchased
the Appliance for re-sale, and
‘your’ has a corresponding
meaning.
2. Application: This warranty only
applies to new Appliances,
purchased and used in Australia or
New Zealand and is in addition to
(and does not exclude, restrict, or
modify in any way) other rights and
remedies under a law to which the
Appliances or services relate,
including any non-excludable
statutory guarantees in Australia and
New Zealand.
3. Warranty Period: Subject to these
terms and conditions, this warranty
continues for in Australia for a period
of 60 months and in New Zealand for
a period of 60 months, following the
date of original purchase of the
Appliance.
4. Repair or replace warranty: During
the Warranty Period, Electrolux or its
ASC will, at no extra charge if your
Appliance is readily accessible for
service, without special equipment
and subject to these terms and
www.aeg.com
32
conditions, repair or replace any
parts which it considers to be
defective. Electrolux may, in its
absolute discretion, choose whether
the remedy offered for a valid
warranty claim is repair or
replacement. Electrolux or its ASC
may use refurbished parts to repair
your Appliance. You agree that any
replaced Appliances or parts
become the property of Electrolux.
5. Travel and transportation costs:
Subject to clause 7, Electrolux will
bear the reasonable cost of
transportation, travel and delivery of
the Appliance to and from Electrolux
or its ASC. Travel and transportation
will be arranged by Electrolux as part
of any valid warranty claim.
6. Proof of purchase is required before
you can make a claim under this
warranty.
7. Exclusions: You may not make a
claim under this warranty unless the
defect claimed is due to faulty or
defective parts or workmanship. This
warranty does not cover:
a) light globes, batteries, filters or
similar perishable parts;
b) parts and Appliances not
supplied by Electrolux;
c) cosmetic damage which does
not affect the operation of the
Appliance;
d) damage to the Appliance caused
by:
– negligence or accident;
– misuse or abuse, including
failure to properly maintain or
service;
– improper, negligent or faulty
servicing or repair works done
by anyone other than an
Electrolux authorised repairer
or ASC;
– normal wear and tear;
– power surges, electrical storm
damage or incorrect power
supply;
– incomplete or improper
installation;
– incorrect, improper or
inappropriate operation;
– insect or vermin infestation;
– failure to comply with any
additional instructions
supplied with the Appliance;
In addition, Electrolux is not
liable under this warranty if:
– the Appliance has been, or
Electrolux reasonably believes
that the Appliance has been,
used for purposes other than
those for which the Appliance
was intended, including
where the Appliance has
been used for any non-
domestic purpose;
– the Appliance is modified
without authority from
Electrolux in writing;
– the Appliance’s serial number
or warranty seal has been
removed or defaced.
8. How to claim under this warranty:
To enquire about claiming under this
warranty, please follow these steps:
a. carefully check the operating
instructions, user manual and the
terms of this warranty;
b. have the model and serial
number of the Appliance
available;
c. have the proof of purchase (e.g.
an invoice) available;
d. telephone the numbers shown
below.
9. Australia: For Appliances and
services provided by Electrolux in
Australia: Electrolux goods come
with guarantees that cannot be
excluded under the Australian
Consumer Law. You are entitled to a
replacement or refund for a major
failure and for compensation for any
other reasonably foreseeable loss or
damage. You are also entitled to
have the Appliance repaired or
replaced if the Appliance fails to be
of acceptable quality and the failure
does not amount to a major failure.
‘Acceptable quality’ and ‘major
failure’ have the same meaning as
referred to in the ACL.
10. New Zealand: For Appliances and
services provided by Electrolux in
New Zealand, the Appliances come
with a guarantee by Electrolux
pursuant to the provisions of the
Consumer Guarantees Act, the Sale
ENGLISH
33
of Goods Act and the Fair Trading
Act. Where the Appliance was
purchased in New Zealand for
commercial purposes the Consumer
Guarantee Act does not apply.
11. Confidentiality: You accept that if
you make a warranty claim, Electrolux
and its agents including ASC may
exchange information in relation to
you to enable Electrolux to meet its
obligations under this warranty.
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have been
followed.
SERVICE AUSTRALIA
aeg.com/au
FOR SERVICE
or to find the address of your nearest au-
thorised service centre in Australia
PLEASE CALL 1300 363 664
OR EMAIL
For the cost of a local call (Australia only)
FOR SPARE PARTS
or to find the address of your nearest spare
parts centre in Australia
PLEASE CALL 13 13 50
OR EMAIL
For the cost of a local call (Australia only)
SERVICE NEW ZEALAND
aegnewzealand.co.nz
FOR SERVICE
or to find the address of your nearest au-
thorised service centre in New Zealand
PLEASE CALL 0800 234 234
OR EMAIL
(New Zealand only)
FOR SPARE PARTS
or to find the address of your nearest spare
parts centre in New Zealand
PLEASE CALL 0800 10 66 20
OR EMAIL
(New Zealand only)
AEG_Warr_May_17
20. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
www.aeg.com
34
ENGLISH 35
The software included in this product contains copyrighted software that is licensed under the BSD, GPL-2.0,
LGPL-2.0, LGPL-2.1, zLib, MIT, ISC, Apache 2.0 and others. It is possible to display the complete copy of the licenses
in the AEG App that can be downloaded from the corresponding App store from the License menu section. It is possible
to download the source code of the open source software used in the product by searching for Wi-Fi Module Software
version in NIUX subfolder at the following website: http://aeg.opensoftwarerepository.com.
www.aeg.com/au
136DRAFTPNC458-A-102019
