MS L
Front/Avant/Frente Back/Arrière/Reverso
Align/Aligner/Alinear
SS MS
L
How to use / Utilisation / Utilización Earbuds / Oreillettes / Almohadillas
Arc supporters / Pièces de maintien courbées / Soportes para oído
Microphone
Micro
Micrófono
Arc supporter
Pièce de maintien
courbée
Soporte para oído
Multi-function button
Touche multifonctions
Botón multifunción
English Stereo headphones
Compatible products
Use this unit with smartphones.
Notes
If you connect to an unsupported smartphone, the
microphone of this unit may not function, or the
volume level may be low.
This unit is not guaranteed to operate digital music
players.
Using the Multi-function button*
Press once to answer the call, press again to end;
press to play/pause a track.
Available operations for iPhone
Plays/pauses a track of the connected iPhone
product with a single press. Skips to the next track
with a double press. Skips to the previous track with
a triple press. Starts the “VoiceOver**” feature with a
long press (if available).
Hold down for about two seconds to reject an
incoming call. When you let go, two low beeps
confirm the call was rejected.
* The button function may vary depending on the
smartphone.
** Availability of the “VoiceOver” feature depends on
iPhone and its software version.
Specifications
Headphones
Type: Closed, dynamic / Driver unit: 12 mm, dome
type (CCAW Voice Coil) / Power handling capacity:
100 mW (IEC*) / Impedance: 16Ω at 1kHz /
Sensitivity: 111 dB/mW / Frequency response: 4 Hz
– 24,000 Hz / Cable: Approx. 1.2 m (47
1
/4 in), Litz
wire, Y-type / Plug: L-shaped gold-plated 4-pole
mini plug / Mass: Approx. 9 g (0.32 oz) without cable
Microphone
Type: Electret condenser / Directivity: Omni
directional / Open circuit voltage level: –40 dB
(0dB = 1 V/Pa) / Effective frequency range: 20 Hz
– 20,000 Hz
Supplied accessories:
Long hybrid silicone rubber earbuds: SS (red) (2), S
(orange) (2), M (green) (attached to the unit at the
factory) (2), L (light blue) (2) / Arc supporters: S (2), M
(attached to the unit at the factory) (2), L (2) / Cable
adjuster (winds cable up to 50 cm (19
3
/4 in)) (1) / Clip
(1) / Carrying pouch (1)
* IEC = International Electrotechnical Commission
Design and specifications are subject to change
without notice.
iPhone is a trademark of Apple Inc., registered in the
U.S. and other countries.
Xperia
TM
is a trademark of Sony Mobile
Communications AB.
Android
TM
and Google Play
TM
are trademarks or
registered trademarks of Google, Inc.
Optional replacement earbuds and arc supporters
can be ordered from your nearest authorized Sony
retailer or www.sony.com.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.
Removing the headphones
After use, remove the headphones slowly.
Note
Headphones are designed to fit closely in your ears. If
the headphones are pressed hard while in use or
taken off too quickly, they may cause injury.
Wearing headphones may produce a diaphragm click
sound. This is not a malfunction.
Precautions
High volume may affect your hearing.
For traffic safety, do not use while
driving or cycling.
Install the earbuds firmly. If an earbud
accidentally detaches and is left in
your ear, it may cause injury.
Keep earbuds clean. To clean the
earbuds, wash them with a mild
detergent solution.
Note on static electricity
Static electricity accumulated in the body may cause
mild tingling in your ears.
To minimize the effect, wear clothes made from
natural materials.
If you install the Smart Key app* from Google Play
TM
store, the track and volume adjustment on your
smartphone will be enabled with multi-function
button.
* Smart Key is an application for Xperia
TM
, Android
TM
OS 4.0 and above. The app may not be available
in some countries and/or regions, and may not be
used with unsupported smartphone models.
Si vous installez l’application Smart Key* à partir de la
boutique Google Play
TM
, le réglage de la plage et du
volume de votre téléphone intelligent sera activé à
l’aide de la touche multifonctions.
* Smart Key est une application pour Xperia
TM
,
Android
TM
OS 4.0 et version ultérieure.
L’application pourrait ne pas être disponible dans
certains pays et/ou dans certaines régions et ne
pas fonctionner avec des modèles de téléphone
intelligent qui ne sont pas pris en charge.
Si instala la aplicación* Smart Key desde la tienda
Google Play
TM
, el ajuste de pista y volumen de su
teléfono inteligente se habilitará con el botón
multifunción.
* Smart Key es una aplicación para Xperia
TM
,
Android
TM
OS 4.0 y versiones posteriores. Es
posible que la aplicación no esté disponible en
algunos países o regiones y que no pueda
utilizarse con modelos de teléfonos inteligentes
no compatibles.
https://play.google.com/store/apps/
details?id=com.sonymobile.extras.liveware.
extension.smartkey
Water resistant performance of this unit
The water resistant specifications of this unit are
equivalent to IEC60529 “Degrees of protection
against ingress of water (IP Code)” IPX5
1)
/IPX7
2)
that
specifies as “Degrees of protection against ingress
of water.”
Do not aim pressurized water at internal parts that
emit sound, as doing so may compromise
waterproof performance.
Do not drop the unit into water, and do not use
underwater.
Water entering the unit may cause fire, electric
shock, or a malfunction.
Wipe off with a soft dry cloth any water that gets
on the unit. If water remains in the earbud holes,
the sound may seem low or not be audible at all.
In this case, remove the earbuds, face the sound
conduit downward, and shake the sound conduit a
couple of times.
Before using the unit, read and understand the
following information thoroughly.
Liquids that the water resistant performance
specifications apply to
Applicable :
fresh water, tap water, sweat
Not applicable :
liquids other than those above (Examples:
soapy water, detergent water, water with
bath agents, shampoo, hot spring water, hot
water, pool water, seawater, etc.)
The water resistant performance of the unit is
based on our measurements under the conditions
described above. Note that malfunctions as a
result of water immersion caused by misuse by
the customer are not covered by the warranty.
1)
IPX5 (Degrees of protection against jets of water) :
The unit will maintain its operability even when
exposed to direct jet streams of water from any
direction in the situation where that
approximately 12.5 L/ min of water is supplied for
periods for more than 3 minutes from a distance
of about 3 m by using a nozzle with an inner
diameter of 6.3 mm.
2)
IPX7 (Degrees of protection against exposure of
water) : The unit will maintain its operability even
after immersion in water of one meter in depth for
30 minutes.
MDR-XB510AS
Stereo Headphones
Operating Instructions
Mode d’emploi
Manual de instrucciones
4-691-019-11(2)
