©2016 Sony Corporation
Printed in China
Earbuds / Oreillettes / Almohadillas
Note on static electricity
Static electricity accumulated in the body may cause
mild tingling in your ears.
To minimize the effect, wear clothes made from
natural materials.
Optional replacement earbuds can be ordered from
your nearest authorized Sony retailer or www.sony.
com.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.
Precautions
High volume may affect your hearing.
For traffic safety, do not use while
driving or cycling.
Install the earbuds firmly. If an earbud
accidentally detaches and is left in
your ear, it may cause injury.
Keep earbuds clean. To clean the
earbuds, wash them with a mild
detergent solution.
Specifications
Headphones
Type: Closed, dynamic
Driver unit: 9 mm, dome type
Power handling capacity: 100 mW (IEC*)
Impedance: 16 Ω at 1 kHz
Sensitivity: 100 dB/mW
Frequency response: 8 Hz – 22,000 Hz
Cable: Approx. 1.2 m (47
1
/4 in), Litz wire, Y-type
Plug: L-shaped 4-pole mini plug
Mass: Approx. 3 g (0.11 oz) without cable
Microphone
Type: Electret condenser
Directivity: Omni directional
Open circuit voltage level: –40 dB (0 dB = 1 V/Pa)
Effective frequency range: 20 Hz – 20,000 Hz
Supplied accessories
Earbuds: S (2 lines) (2), M (3 lines) (attached to the
unit at the factory) (2), L (4 lines) (2)
* IEC = International Electrotechnical Commission
Design and specifications are subject to change
without notice.
iPhone is a trademark of Apple Inc., registered in the
U.S. and other countries.
Xperia
TM
is a trademark of Sony Mobile
Communications AB.
Android
TM
and Google Play
TM
are trademarks or
registered trademarks of Google, Inc.
English Stereo headphones
Compatible products
Use this unit with smartphones.
Notes
• If you connect to an unsupported smartphone, the
microphone of this unit may not function, or the
volume level may be low.
• This unit is not guaranteed to operate digital music
players.
Using the Multi-function button*
Press once to answer the call, press again to end;
press to play/pause a track.
Available operations for iPhone
Plays/pauses a track of the connected iPhone
product with a single press. Skips to the next track
with a double press. Skips to the previous track with
a triple press. Starts the “VoiceOver**” feature with a
long press (if available).
Hold down for about two seconds to reject an
incoming call. When you let go, two low beeps
confirm the call was rejected.
* The button function may vary depending on the
smartphone.
** Availability of the “VoiceOver” feature depends on
iPhone and its software version.
LMS
Microphone
Micro
Micrófono
Multi-function
button
Touche
multifonctions
Botón
multifunción
How to use/Utilisation/Utilización
* Smart Key es una aplicación para Xperia™,
Android™ OS 4.0 y versiones posteriores. Es
posible que la aplicación no esté disponible en
algunos países o regiones y que no pueda
utilizarse con modelos de teléfonos inteligentes
no compatibles.
https://play.google.com/store/apps/
details?id=com.sonymobile.extras.liveware.
extension.smartkey
If you install the Smart Key app* from Google Play™
store, the track and volume adjustment on your
smartphone will be enabled with multi-function
button.
* Smart Key is an application for Xperia™, Android™
OS 4.0 and above. The app may not be available in
some countries and/or regions, and may not be
used with unsupported smartphone models.
Si vous installez l’application Smart Key* à partir de la
boutique Google Play™, le réglage de la plage et du
volume de votre téléphone intelligent sera activé à
l’aide de la touche multifonctions.
* Smart Key est une application pour Xperia™,
Android™ OS 4.0 et version ultérieure.
L’application pourrait ne pas être disponible dans
certains pays et/ou dans certaines régions et ne
pas fonctionner avec des modèles de téléphone
intelligent qui ne sont pas pris en charge.
Si instala la aplicación* Smart Key desde la tienda
Google Play™, el ajuste de pista y volumen de su
teléfono inteligente se habilitará con el botón
multifunción.
MDR-EX14AP
Stereo
Headphones
Operating Instructions
Mode d’emploi
Manual de instrucciones
4-596-689-11(2)
