Register your product and get support at
www.philips.com/welcome
EN User manual
HTS4561
HTS4562
3
English
7 Use your home theater 19
Choose sound 19
Discs 20
USB storage devices 22
DivX 23
Audio, video, and picture options 24
Radio 25
MP3 player 26
iPod or iPhone 26
Use smartphone 27
Karaoke 28
Browse PC through DLNA 29
Browse Net TV 32
Rent online video 32
EasyLink 33
8 Change settings 34
Picture 34
Sound 35
Language 36
Parental control 36
Energy saving 37
Apply factory settings 37
9 Update software 38
Check software version 38
Update software through the Internet 38
Update software through USB 38
10 Product specications 39
11 Troubleshooting 43
12 Language code 46
13 Index 47
Contents
1 Using help 4
Navigate the onscreen help 4
2 Help and support 5
Update your onscreen help 5
Tutorials 6
FAQs 6
Contact Philips 6
3 Notice 6
Open source software 6
RMVB end user agreement
(Asia Pacic and China only) 6
Trademarks 7
4 Important 8
Safety 8
Care for your product 9
Care of the environment 9
3D health warning 9
5 Your home theater 10
Main unit 10
Remote control 10
6 Connect your home theater 12
Speakers 12
Connectors 13
Connect to TV 14
Connect audio from TV and other devices 16
Computers and the Internet 17
EN
4
Navigate the onscreen help
a HELP
Access the onscreen help.
b OK
Display the selected page, or expand topics
in Contents.
c Navigation buttons
• Up: Scroll up or move to the previous
page.
• Down: Scroll down or move to the
next page.
• Right: Navigate to the right panel or
next index entry.
• Left: Navigate to the left panel or
previous index entry.
d BACK
Move up in the Contents or Index.
From the right panel, move to the Contents
on the left panel.
e / (Previous/Next)
• : Display the last viewed page in
history.
• : Display the next page from history.
1 Using help
Philips is committed to develop products that
contribute to a greener environment. To save
paper and the environment, access the help on
your home theater through the onscreen interface.
The onscreen help contains all the information
that you need to set up your home theater.
However, if you prefer to print the user manual,
download the PDF version from www.philips.com/
support. Follow the instructions on the website to
select your language, and then enter your model
number.
Access the onscreen help by pressing HELP
(yellow button) on your remote control.
The onscreen help has two panels.
• The left panel contains the Contents and
Index. Navigate the Contents or Index to
select a page.
• The right panel contains the content of each
page. Select Related topics for additional
help on the content.
EN
5
English
2 In your web browser, go to
www.philips.com/support.
3 At the Philips support website, nd your
product and click on User manuals, and
then locate the User Manual Upgrade
Software.
» The help update is available as a zip le.
4 Save the zip le in the root directory of
your USB ash drive.
5 Use the archive utility to extract the help
update le in the root directory of the USB
ash drive.
» A le named ‘HTSxxxxeDFU.zip’ is
extracted under the UPG_ALL folder
of your USB ash drive, ‘xxxx’ being the
model number of your home theater.
6 Disconnect the USB ash drive from your
computer.
Step 3: Update onscreen help
Caution
• Before you connect the USB ash drive to
your home theater, make sure that there is
no disc in the disc compartment, and the disc
compartment is closed.
1 Switch on the TV.
2 Connect the USB ash drive containing the
downloaded le to your home theater.
3 Press (Home).
4 Enter 338 on the remote control.
» Follow the instructions on the TV to
conrm the update. Do not switch off
the home theater or remove the USB
ash drive during the update.
5 Disconnect the USB ash drive from the
home theater.
Warning
• If power fails during the update, do not
remove the USB ash drive from the home
theater.
• If an error occurs during the update, retry
the procedure. If the error reoccurs, contact
Philips Consumer Care.
2 Help and support
Watch video tutorials, download a software
update, and nd answers to many frequently
answered questions (FAQs) on your product at
www.philips.com.
Update your onscreen help
Philips continually tries to improve its products.
To make sure that your onscreen help is up to
date with the latest information, update your
home theater with the latest onscreen help.
Download the latest help from
www.philips.com/support.
What you need
• A USB ash drive, with at least 35MB of
memory. The USB ash drive must be FAT
or NTFS formatted. Do not use a USB hard
drive.
• A computer with Internet access.
• An archive utility that supports the ZIP
le format (for example, WinZip® for
Microsoft® Windows® or Stuft® for
Macintosh®).
Step 1: Check the current version of help
Check the current version of onscreen help
installed in your home theater. If the version is
lower than the version available at www.philips.
com/support, download and install the latest
onscreen help.
The last two digits indicate the version of the
onscreen help installed in your home theater.
For example, if the version in the home theater
is ‘Subsystem SW: 35-00-00-05’, ‘05’ represents
the version of the onscreen help currently
installed.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [Version Info.], and
then press OK.
Step 2: Download the latest onscreen
help
1 Connect a USB ash drive to your
computer.
EN
6
3 Notice
This section contains the legal and trademark
notices.
Open source software
Philips Electronics Singapore Pte Ltd hereby
offers to deliver, upon request, a copy of the
complete corresponding source code for the
copyrighted open source software packages used
in this product for which such offer is requested
by the respective licenses. This offer is valid up
to three years after product purchase to anyone
in receipt of this information. To obtain source
code, please contact open.source@philips.com.
If you prefer not to use email or if you do not
receive conrmation receipt within a week after
mailing to this email address, please write to
“Open Source Team, Philips Intellectual Property
& Standards, P.O. Box 220, 5600 AE Eindhoven,
The Netherlands”. If you do not receive timely
conrmation of your letter, please email to the
email address above. The texts of the licenses
and acknowledgements for open source
software used in this product are included in the
user manual.
RMVB end user agreement
(Asia Pacic and China only)
Notes to End User:
By using this product with RealNetworks
software and services, the end user agrees to the
following terms of REALNETWORKS, INC:
• End User may only use the software for
private, non-commercial use in accordance
with the terms of RealNetworks EULA .
• End User is not allowed to modify, translate,
reverse engineer, decompile, dissemble or
use other means to discover the source
code or otherwise replicate the functionality
of the Real Format Client Code, except to
the extent that this restriction is expressly
prohibited by applicable law.
Tutorials
To set up your home theater and get additional
information, refer to the video tutorials at
www.philips.com/support.
FAQs
If you have a problem, refer to the frequently
asked questions (FAQs) for this home theater at
www.philips.com/support.
If you still need help, contact Philips Consumer
Care in your country.
Warning
• Do not attempt to repair your home theater
yourself. This may cause severe injury,
irreparable damage to your home theater, or
void your warranty.
Contact Philips
If you contact Philips, you will be asked for the
model and serial number of your product. The
model number and serial number are on the
back or bottom of your product. Note the
numbers before you call Philips:
Model No. __________________________
Serial No. ___________________________
EN
7
English
Manufactured under license under U.S. Patent
#’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762;
6,226,616; 6,487,535; 7,392,195; 7,272,567;
7,333,929; 7,212,872 & other U.S. and worldwide
patents issued & pending. DTS and the Symbol
are registered trademarks, & DTS-HD, and DTS-
HD Master Audio | Essential and the DTS logos
are trademarks of DTS, Inc. Product includes
software. DTS, Inc. All Rights Reserved.
Manufactured under license from Dolby
Laboratories. Dolby, Pro Logic, and the
double-D symbol are trademarks of Dolby
Laboratories.
DivX , DivX Certied , DivX Plus™ HD and
associated logos are trademarks of DivX, Inc. and
are used under license.
ABOUT DIVX VIDEO: DivX® is a digital
video format created by DivX, Inc. This is an
ofcial DivX Certied® device that plays DivX
video. Visit divx.com for more information and
software tools to convert your les into DivX
video.
ABOUT DIVX VIDEO-ON-DEMAND: This
DivX Certied device must be registered
in order to play purchased DivX Video-on-
Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section
in your device setup menu. Go to vod.divx.com
for more information on how to complete your
registration.
HDMI, the HDMI logo, and High-Denition
Multimedia Interface are trademarks or
registered trademarks of HDMI licensing LLC in
the United States and other countries.
• RealNetworks Inc. disclaims all warranties
and conditions other than those set forth in
this Agreement which are in lieu of all other
warranties, whether express and implied,
including but not limited to any implied
warranties or conditions of merchantability
and tness for a particular purpose; and
effectively exclude all liability for indirect,
special, incidental and consequential
damages, such as but not limited to lost
prots.
Trademarks
“Blu-ray 3D” and “Blu-ray 3D” logo are
trademarks of Blu-ray Disc Association.
BONUSVIEW™
‘BD LIVE’ and ‘BONUSVIEW’ are trademarks of
Blu-ray Disc Association.
‘DVD Video’ is a trademark of DVD Format/
Logo Licensing Corporation.
Java and all other Java trademarks and logos are
trademarks or registered trademarks of Sun
Microsystems, Inc. in the United States and/or
other countries.
‘x.v.Colour’ is a trademark of Sony
Corporation.
EN
8
4 Important
Read and understand all instructions before you
use your home theater. If damage is caused by
failure to follow instructions, the warranty does
not apply.
Safety
Risk of electric shock or re!
• Never expose the product and accessories
to rain or water. Never place liquid
containers, such as vases, near the product.
If liquids are spilt on or into the product,
disconnect it from the power outlet
immediately. Contact Philips Consumer
Care to have the product checked before
use.
• Never place the product and accessories
near naked ames or other heat sources,
including direct sunlight.
• Never insert objects into the ventilation
slots or other openings on the product.
• Where the mains plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
• Disconnect the product from the power
outlet before lightning storms.
• When you disconnect the power cord,
always pull the plug, never the cable.
Risk of short circuit or re!
• Before you connect the product to the
power outlet, ensure that the power
voltage matches the value printed on the
back or bottom of the product. Never
connect the product to the power outlet if
the voltage is different.
Risk of injury or damage to the home theater!
• For wall-mountable products, use only the
supplied wall mount bracket. Secure the
wall mount to a wall that can support the
combined weight of the product and the
wall mount. Koninklijke Philips Electronics
N.V. bears no responsibility for improper
wall mounting that results in accident, injury
or damage.
• For speakers with stands, use only the
supplied stands. Secure the stands to the
speakers tightly. Place the assembled stands
on at, level surfaces that can support the
combined weight of the speaker and stand.
SDHC Logo is a trademark of SD-3C, LLC.
CLASS 1
LASER PRODUCT
EN
9
English
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC. Please inform yourself about the local
separate collection system for electrical and
electronic products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste.
Correct disposal of your old product helps to
prevent potential negative consequences for the
environment and human health.
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot
be disposed with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries because correct
disposal helps to prevent negative consequences
for the environmental and human health.
3D health warning
If you or your family has a history of epilepsy
or photosensitive seizures, consult a medical
professional before exposing yourself to ashing
light sources, rapid image sequences or 3D
viewing.
To avoid discomfort such as dizziness, headache
or disorientation, we recommend not watching
3D for extended periods of time. If you
experience any discomfort, stop watching 3D
and do not immediately engage in any potentially
hazardous activity (for example driving a car)
until your symptoms have disappeared. If
symptoms persist, do not resume watching 3D
without consulting a medical professional rst.
Parents should monitor their children during 3D
viewing and ensure they do not experience any
discomfort as mentioned above. Watching 3D is
not recommended for children under six years of
age as their visual system is not fully developed
yet.
• Never place the product or any objects on
power cords or on other electrical equipment.
• If the product is transported in
temperatures below 5°C, unpack the
product and wait until its temperature
matches room temperature before
connecting it to the power outlet.
• Visible and invisible laser radiation when
open. Avoid exposure to beam.
• Do not touch the disc optical lens inside the
disc compartment.
• Parts of this product can be made of
glass. Handle with care to avoid injury and
damage.
Risk of overheating!
• Never install this product in a conned
space. Always leave a space of at least four
inches around the product for ventilation.
Ensure curtains or other objects never
cover the ventilation slots on the product.
Risk of contamination!
• Do not mix batteries (old and new or
carbon and alkaline, etc.).
• Remove batteries if they are exhausted or
if the remote control is not to be used for a
long time.
• Batteries contain chemical substances, they
should be disposed of properly.
Risk of swallowing batteries!
• The product/remote control may contain a
coin type battery, which can be swallowed.
Keep the battery out of reach of children at
all times!
Care for your product
• Do not insert any objects other than discs
into the disc compartment.
• Do not insert warped or cracked discs into
the disc compartment.
• Remove discs from the disc compartment
if you are not using the product for an
extended period of time.
• Use only microber cloth to clean the
product.
Care of the environment
Your product is designed and manufactured with
high quality materials and components, which
can be recycled and reused.
EN
10
a (Standby-On)
• Switch the home theater on or to
standby.
• When EasyLink is enabled, press
and hold for at least three seconds
to switch all connected HDMI CEC
compliant devices to standby.
b Source buttons / Color buttons
• Color buttons: Select tasks or options
for Blu-ray discs.
• DISC: Switch to disc source.
• DOCK for iPod: Switch to Philips dock
for iPod or iPhone.
• HELP: Access the onscreen help.
• SOURCE: Select an audio input
source or radio source.
c (Home)
Access the home menu.
a POP-UP MENU/DISC MENU
Access or exit the disc menu when you play
a disc.
b BACK
• Return to a previous menu screen.
• In radio mode, press and hold to erase
the current preset radio stations.
5 Your home theater
Congratulations on your purchase, and welcome
to Philips! To fully benet from the support that
Philips offers, register your home theater at
www.philips.com/welcome.
Main unit
a Disc compartment
b (Open/Close)
Press and hold for three seconds to open
or close the disc compartment, or eject the
disc.
c (Play/Pause)
Start, pause or resume play.
d (Stop)
Stop play.
e (Standby-On)
Switch the home theater on or to standby.
f SOURCE
Select an audio or video source for the
home theater.
g /
• Skip to the previous or next track,
chapter or le.
• In radio mode, select a preset radio
station.
h Display panel
i Volume control wheel
Remote control
This section includes an overview of the remote
control.
Overview
Control your home theater with the remote
control.
EN
11
English
b (Play)
Start or resume play.
c / (Previous/Next)
• Skip to the previous or next track,
chapter or le.
• In radio mode, select a preset radio
station.
d (Pause)
Pause play.
e / (Fast Backward/Fast Forward)
Search backwards or forward. Press
repeatedly to change the search speed.
a Alphanumeric buttons
• Enter values or letters (using SMS style
entry).
• In radio mode, select a preset radio
station.
b TOP MENU
Access the main menu of a video disc.
c SUBTITLE
Select subtitle language for video.
EasyLink controls
With Easylink, you can control your home
theater and the TV with the following buttons
on your home theater remote control (see
‘EasyLink’ on page 33).
• (Standby-On): Press and hold to switch
your home theater, TV and the connected
devices to standby.
• (Play): When a video disc is in the disc
compartment, wake up the TV from
standby, and then play a disc.
c SOUND SETTINGS
Access or exit sound options.
d OPTIONS
• Access more play options while playing
a disc or a USB storage device.
• In radio mode, set a radio station.
a OK
Conrm an entry or selection.
b Navigation buttons
• Navigate menus.
• In radio mode, press left or right to
start auto search.
• In radio mode, press up or down to
tune the radio frequency.
c (Mute)
Mute or restore volume.
d +/- (Volume)
Increase or decrease volume.
a (Stop) / (Eject/ Open/Close)
• Stop play.
• Press and hold for three seconds to
open or close the disc compartment,
or eject the disc.
EN
12
Note
• Surround sound depends on factors such as
room shape and size, type of wall and ceiling,
windows and reective surfaces, and speaker
acoustics. Experiment with the speaker
positions to nd the optimum setting for you.
Follow these general guidelines, and then set up
your speakers.
1 Seating position:
This is the center of your listening area.
2 FRONT CENTER (front center) speaker:
Place the center speaker directly in front of
the seating position, either above or below
your TV. Make sure that it is close to your
ear height when you are seated.
3 FRONT LEFT (front left) and FRONT
RIGHT (front right) speakers:
Place the left and right speakers in the front,
and equidistant from the center speaker in
an arc, so that all the three speakers are at
same distance from your seating position.
For best effect, point the speakers towards
the seating position and place the speakers
close to the ear level (when seated).
4 REAR LEFT (rear left) and REAR RIGHT
(rear right) speakers:
Place the rear surround speakers to the
left and right side of your seating position,
either in line with it or slightly behind it. For
best effect, point the speakers towards the
seating position and place the speakers just
above the ear level (when seated).
5 SUBWOOFER (subwoofer):
Place the subwoofer at least one meter to
the left or right of the TV. Leave about ten
centimeter clearance from the wall.
Connect
Connect your speakers and the subwoofer to
your home theater as described in the quick
start guide.
6 Connect your home
theater
This section helps you connect your home theater
to a TV and other devices.
For information about the basic connections of
your home theater and accessories, see the quick
start guide. For a comprehensive interactive guide,
see www.connectivityguide.philips.com.
Note
• For identication and supply ratings, refer to
the type plate at the back or bottom of the
product.
• Before you make or change any connections,
make sure that all devices are disconnected
from the power outlet.
Speakers
Position, connect, and set up your speakers for
best surround sound.
Position
Speaker position plays a critical role in setting up
a surround sound effect.
For best results, place your speakers and the
subwoofer as shown below.
EN
13
English
Connectors
Connect other devices to your home theater.
Front
a MIC (Available only in Asia Pacic and
China)
Audio input from a microphone.
b MUSIC iLINK
Audio input from an MP3 player.
c (USB)
• Audio, video or picture input from a
USB storage device.
• Connect to a Wi-Fi dongle (Model:
Philips WUB1110).
Rear left
a AC MAINS~
Connect to the power supply.
b SPEAKERS
Connect to the supplied speakers and
subwoofer.
c Wireless Rear Audio
Connect to a Philips wireless module.
(Model: Philips RWSS5510, sold separately)
Setup
Set up your speakers through the speaker setup
menu.
1 Connect your speakers and subwoofer as
described in the Quick start guide.
2 Press (Home) on your home theater
remote control, and select [Setup] >
[Audio] > [Speaker Setup].
3 Enter the distance for each speaker, and
then listen to the test tones and change the
volume. Experiment a little with the speaker
positions to nd the ideal setting.
Wireless rear speakers
Convert the rear speakers of your home theater
into wireless speakers by using a wireless
module.
• The wireless transmitter connects to the
Wireless Rear Audio connector on your
home theater.
• The wireless receiver connects to the rear
surround speakers and the power supply.
For more information, refer to the user manual
of your wireless module.
Wireless module - RWSS5510
Purchase the wireless module RWSS5510 (sold
separately) from a Philips authorized dealer.
Wireless transmitter:
Wireless receiver:
EN
14
c VIDEO OUT-VIDEO
Connect to the composite video input on
the TV.
d HDMI OUT (ARC)
Connect to the HDMI input on the TV.
e LAN
Connect to the LAN input on a broadband
modem or router.
Connect to TV
Connect your home theater to a TV to watch
videos. You can listen to audio from TV programs
through your home theater speakers. Use the best
quality connection available on your home theater
and TV.
Option 1: Connect to TV through HDMI
(ARC)
Best quality video
Your home theater supports HDMI version
1.4 - Audio Return Channel (ARC). If your TV
is HDMI ARC compliant, connect your home
theater to the TV through the HDMI ARC
connection for easy and quick setup.
With HDMI ARC, you do not need an additional
audio cable to play audio from TV through your
home theater.
1 Using a High Speed HDMI cable, connect
the HDMI OUT (ARC) connector on your
home theater to the HDMI ARC connector
on the TV.
The HDMI ARC connector on the TV
might be labeled HDMI IN or HDMI. For
details on TV connectors, see the TV user
manual.
TV
Rear center
a DIGITAL IN-OPTICAL
Connect to an optical audio output on the
TV or a digital device.
b DIGITAL IN-COAXIAL
Connect to a coaxial audio output on the
TV or a digital device.
c AUDIO IN-AUX 2
Connect to an analog audio output on the
TV or an analog device.
d DOCK for iPod
Connect to a Philips dock for iPod or
iPhone.(Model: Philips DCK3060/DCK3061)
e ANTENNA FM 75
Signal input from an antenna, cable or
satellite.
Rear right
a AUDIO IN-AUX 1
Connect to an analog audio output on the
TV or an analog device.
b SD CARD (Not available in China)
Slot for SD card. The SD card is used to
rent online videos and access BD-Live.
EN
15
English
4 If audio from the TV does not play
automatically on your home theater, set up
the audio manually (see ‘Set up audio for
connected devices’ on page 16).
Note
• If your TV has a DVI connector, you can use an
HDMI/DVI adapter to connect to TV.
Option 3: Connect to the TV through
composite video
Basic quality video
If your TV does not have HDMI connectors,
connect your home theater to the TV through a
composite connection. A composite connection
does not support high-denition video.
With a composite connection, you need an
additional audio cable to play the audio from the
TV through your home theater (see ‘Connect
audio from TV and other devices’ on page 16).
1 Using a composite video cable, connect the
VIDEO connector on your home theater to
the composite video connector on the TV.
The composite video connector might be
labeled AV IN, VIDEO IN, COMPOSITE,
or BASEBAND.
2 On your TV, switch to the correct video
input.
3 To play audio from TV programs through
your home theater, connect an additional
audio cable (see ‘Connect audio from TV
and other devices’ on page 16).
On your home theater, press SOURCE
repeatedly to select the correct audio input.
TV
2 On your TV, turn on HDMI-CEC. For
details, see the TV user manual.
» When you play a disc on your home
theater, the video is automatically
displayed on TV and the audio is
automatically played on the home theater.
3 If audio from the TV does not play
automatically on your home theater, set up
the audio manually (see ‘Set up audio for
connected devices’ on page 16).
Option 2: Connect to TV through HDMI
Best quality video
If your TV is not HDMI ARC compliant, connect
your home theater to the TV through a standard
HDMI connection.
With a standard HDMI connection, you need an
additional audio cable to play the audio from the
TV through your home theater (see ‘Connect
audio from TV and other devices’ on page 16).
1 Using a High Speed HDMI cable, connect
the HDMI OUT (ARC) connector on your
home theater to the HDMI connector on
the TV.
The HDMI connector on the TV might be
labeled HDMI IN.
2 On your TV, turn on HDMI-CEC. For
details, see the TV user manual.
» When you play a disc on your home
theater, the video is automatically
displayed on TV and the audio is
automatically played on the home theater.
3 To play audio from TV programs through
your home theater, connect an additional
audio cable (see ‘Connect audio from TV
and other devices’ on page 16).
TV
EN
16
Option 3: Connect audio through analog
audio cables
Basic quality audio
Using an analog cable, connect the AUX
connectors on your home theater to the
AUDIO OUT connectors on the TV or other
device.
Set up audio for connected devices
When you connect a device to your home
theater, check the audio settings.
1 On your TV and other devices, turn on
HDMI-CEC. For details, see the user
manual of the TV and the other device.
2 Select ‘Amplier’ from the TV speakers
menu. For details, see the TV user manual.
3 On your home theater, turn on System
Audio Control, and then map the audio
of the connected device to the correct
connectors on your home theater (see ‘Play
audio from home theater’ on page 34).
If the connected device is not HDMI-CEC
compliant, press SOURCE repeatedly on your
home theater to select the correct audio input.
VCR
Connect audio from TV and
other devices
Play audio from TV or other devices through
your home theater.
Use the best quality connection available on your
TV, home theater, and other devices.
Note
• The audio connections in this user manual are
only recommendations. You can use other
connections too.
• When your home theater and TV are
connected through HDMI ARC, an audio
connection is not required.
Option 1: Connect audio through a digital
optical cable
Best quality audio
Using an optical cable, connect the OPTICAL
connector on your home theater to the
OPTICAL OUT connector on the TV or other
device.
The digital optical connector might be labeled
SPDIF, SPDIF OUT, or OPTICAL.
Option 2: Connect audio through a digital
coaxial cable
Good quality audio
Using a coaxial cable, connect the COAXIAL
connector on your home theater to the
COAXIAL/DIGITAL OUT connector on the TV
or other device.
The digital coaxial connector might be labeled
DIGITAL AUDIO OUT.
TV
EN
17
English
Set up the wired network
Connect your home theater to your router as
shown below, and then switch on the devices.
1 Connect the home theater to a network
router through a wired connection (see
‘Wired connection’ on page 17).
2 Turn on your TV, and switch to the correct
source for the home theater.
3 Press (Home).
4 Select [Setup], and then press OK.
5 Select [Network] > [Network Installation]
> [Wired (Ethernet)], and then press OK.
6 Follow the instructions on the TV to
complete the setup.
» The home theater connects to the
internet. If connection fails, select [Retry],
and then press OK.
7 Select [Finish], and then press OK to exit.
Check wired network settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Network] > [View Network
Settings], and then press OK.
» The current network settings are
displayed.
LAN
www
Computers and the Internet
Connect your home theater to your computer
network and the internet, and enjoy:
• Multimedia content streamed from your
computer: Play music, photo, and video
from a computer or other media server
on your network (see ‘Browse PC through
DLNA’ on page 29).
• Net TV (Not available in China):
Browse Net TV services to access online
information, games, news, music, and other
services (see ‘Browse Net TV’ on page 32).
• Software update:Update the home theater
software through the network (see ‘Update
software through the Internet’ on page 38).
Caution
• Before you try to connect the home theater to
a computer network, familiarize yourself with
the network router, media server software
and networking principles. If necessary, read
documentation that accompanies the network
components. Philips is not responsible for lost,
damaged, or corrupt data.
Wired connection
Connect your home theater to your router
through a network cable.
What you need
• A network router (with DHCP enabled).
• A network cable (RJ45 straight cable).
• A computer with media server software
installed (see ‘Set up media server software’
on page 29).
• For Net TV and software update, make sure
that the network router has access to the
Internet, and is not restricted by rewalls or
other security systems.
EN
18
Check wireless network settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Network] > [View Wireless
Settings], and then press OK.
» The current Wi-Fi settings are displayed.
Name your home theater
To easily identify your home theater on a
network, name your home theater.
1 Turn on your TV, and switch to the correct
source for the home theater.
2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Network] > [Name your Product:],
and then press OK.
5 Press the Alphanumeric buttons to enter
the name.
6 Select [Done], and then press OK to exit.
Wireless connection
Connect your home theater to your router
through a wireless connection.
What you need
• A network router (with DHCP enabled).
• A Wi-Fi dongle (Model: Philips WUB1110).
• A computer with media server software
installed (see ‘Set up media server software’
on page 29).
• For Net TV and software update, make sure
that the network router has access to the
Internet and is not restricted by rewalls or
other security systems.
Set up the wireless network
Connect your home theater to your router as
shown below, and then switch on the devices.
1 Connect the home theater to a network
router through a wireless connection (see
‘Wireless connection’ on page 18).
2 Turn on your TV, and switch to the correct
source for the home theater.
3 Press (Home).
4 Select [Setup], and then press OK.
5 Select [Network] > [Network Installation]
> [Wireless (Wi-Fi)], and then press OK.
6 Follow the instructions on the TV to
complete the setup.
» The home theater connects to the
internet. If connection fails, select [Retry],
and then press OK.
7 Select [Finish], and then press OK to exit.
EN
19
English
1 Press SOUND SETTINGS.
2 Select SOUND, and then press OK.
3 Press the Navigation buttons (up/down) to
select a setting on the display:
• MOVIE: Enjoy a cinematic audio
experience, specially enhanced for
movies.
• MUSIC: Recreate the original recording
environment of your music, in the
studio or at a concert.
• ORIGINAL: Experience the original
sound of your movies and music,
without added sound effects.
• NEWS: Hear every word with
optimized speech and clear vocals.
• GAMING: Enjoy thrilling arcade
sounds, ideal for action-packed video
games or loud parties.
4 Press OK to conrm.
Surround sound mode
Experience an immersive audio experience with
surround sound modes.
1 Press SOUND SETTINGS.
2 Select SURROUND, and then press OK.
3 Press the Navigation buttons (up/down) to
select a setting from your display:
• AUTO: Surround sound based on the
audio stream.
• 5CH STER: Enhanced stereo sound.
Ideal for party music.
• MULTI- CH: Immersive multi-channel
sound for an enhanced movie
experience.
• STEREO: Two-channel stereo sound.
Ideal for listening to music.
4 Press OK to conrm.
Equalizer
Change the high frequency (treble), mid
frequency (mid), and low frequency (bass)
settings of the home theater.
1 Press SOUND SETTINGS.
2 Select TREBLE, MID or BASS, and then
press OK.
3 Press the Navigation buttons (up/down) to
change the frequency.
4 Press OK to conrm.
7 Use your home
theater
This section helps you use the home theater to
play media from a wide range of sources.
Before you start
• Make the necessary connections described
in the quick start guide and the onscreen
help.
• Complete the rst-time setup. First-time
setup appears when you turn on the home
theater for the rst time. If you do not
complete the setup, you are prompted
to complete it each time you turn on the
home theater.
• Switch the TV to the correct source for the
home theater.
Choose sound
This section helps you choose the ideal sound for
your video or music.
1 Press SOUND SETTINGS.
2 Press the Navigation buttons (left/ right) to
access the sound options on the display.
Sound settings Description
SOUND Select a sound mode.
SURROUND Select surround sound or
stereo sound.
TREBLE Change the high frequency
output.
MID Change the middle frequency
output.
BASS Change the low frequency
output.
AUD SYNC Delay the audio to match the
video.
3 Select an option, and then press OK.
4 Press BACK to exit.
If you do not press a button within a
minute, the menu exits automatically.
Sound mode
Select predened sound modes to suit your
video or music.
EN
20
Play RMVB or RM le
Available only in Asia Pacic and China
An Real Media Variable Bitrate (RMVB) and
RealMedia (RM) le contains both audio and
video. You can copy an RMVB or RM le from
your computer onto a recordable disc or USB
storage device, and play them from your home
theater.
1 Play a disc (see ‘Play discs’ on page 20) or
USB storage device (see ‘Play les’ on page
23) that contains a RMVB or RM le.
Note
• Make sure that the le extension is ‘.RMVB’
or ‘.RM’.
• Make sure that the subtitle le has the exact
same name as the video le (see ‘Subtitles’ on
page 23).
• If the subtitles do not appear correctly, change
the character set (see ‘Subtitle character set’
on page 24).
Play buttons
Button Action
Navigation
buttons
Navigate menus.
OK Conrm an entry or selection.
(Play)
Start or resume play.
Pause play.
Stop play.
/
Skip to the previous or next
track, chapter or le.
/
Fast backwards or fast
forwards. Press repeatedly to
change the search speed.
Navigation
buttons (up/
down)
Rotate the picture clockwise or
counter-clockwise.
SUBTITLE Select subtitle language for
video.
POP-UP
MENU/DISC
MENU
Access or exit the disc menu.
OPTIONS
Access the advanced options
when you play your audio,
video, or media les (see
‘Audio, video, and picture
options’ on page 24).
Discs
Your home theater can play DVDs, VCDs, CDs,
and Blu-ray discs. It can also play discs that you’ve
made at home, such as CD-R discs of photos and
music.
What you need
For audio or 2D video:
• Audio and video connection between your
home theater and the TV.
• An audio or a video disc.
For 3D video:
• A 3D TV.
• An HDMI connection between your home
theater and the TV.
• A Blu-ray 3D disc.
• A pair of 3D glasses that are compatible
with your 3D TV.
Play discs
1 Insert a disc into the home theater.
» Your TV switches to the correct source
and the disc plays automatically.
2 If the disc does not play automatically, press
DISC or select [play Disc] in the home
menu, and then press OK.
3 For a 3D video, put on your 3D glasses.
4 Press the play buttons to control play (see
‘Play buttons’ on page 20).
Note
• For a 3D video, during search forward or
backward, and in some other play modes, the
video displays in 2D. It returns to 3D display
when you play normally again.
Tip
• To avoid ickering, change the brightness of
the display (see ‘Display panel’ on page 37).
EN
21
English
Bonus View on Blu-ray
On Blu-ray discs that support the Bonus
View, enjoy extra content, such as a director’s
commentary, while you watch the main feature.
Bonus View is also known as picture-in-picture.
1 Enable Bonus View (picture-in-picture) in
the Blu-ray disc menu.
2 While you play the main feature, press
OPTIONS.
» The options menu is displayed.
3 Select [PIP Selection] > [PIP], and then
press OK.
» Depending on the video, PIP option [1]
or [2] is displayed.
» The picture-in-picture video is displayed
in a small window.
4 Select [2nd Audio Language] or [2nd
Subtitle Language], and then press OK.
5 Select the language, and then press OK.
Note
• To turn off Bonus View, press OPTIONS,
select [PIP Selection] > [Off], and then press
OK.
BD-Live on Blu-ray
On Blu-ray discs with BD-Live content, access
additional features, such as internet chats with
the director, the latest movie trailers, games,
wallpaper, and ringtones.
What you need
• a Blu-ray disc with BD-Live content
• an internet connection
• a storage device:
• a USB storage device, with at least 1
GB of memory, or
• an SD memory card of type SDHC
Class 6, with at least 8 GB of memory.
Note
• BD-Live services vary from country to country,
and depend on the disc.
• When you use BD-Live, data on the disc and
home theater are accessed by the content
provider.
For video formats such as DivX and WMV:
• To stop play, press .
• To resume the video from where you
stopped, press (Play).
• To play the video from the start, press OK.
Play 3D discs in 2D mode
If you do not have a 3D TV, watch the 3D disc in
2D mode.
1 Press (Home).
2 Select [Setup] > [Video] > [Watch 3D
video] > [Off].
3 Press OK.
4 Play your Blu-ray 3D disc.
» The 3D video is displayed in 2D.
Display menu for VCD and SVCD
Display the content menu on VCD and SVCD
discs.
1 Press (Home).
2 Select [Setup] > [Preference], and then
press OK.
3 Select [VCD PBC] > [On], and then press
OK.
Note
• To skip the content menu, select [Off].
Synchronize picture and sound
If the audio and video are not synchronized,
delay the audio to match the video.
1 Press SOUND SETTINGS.
2 Select AUD SYNC, and then press OK.
3 Press the Navigation buttons (up/down) to
synchronize the audio with the video.
4 Press OK to conrm.
EN
22
Clear memory
If your storage device does not have enough
memory for the BD-Live content, clear the
memory on the storage device.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [Clear memory], and
then press OK.
» This clears the local memory and deletes
the BD-Live les that you downloaded
on your storage device.
Disable BD-Live
To restrict access to BD-Live, turn on the BD-
Live security.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [BD-Live security] >
[On], and then press OK.
» BD-Live access is restricted.
Note
• You cannot restrict internet access on
commercial Blu-ray discs.
USB storage devices
Enjoy pictures, audio and video on a USB storage
device.
What you need
• A USB storage device that is formatted for
FAT or NTFS le systems, and complies
with the Mass Storage Class.
• A USB extension cable, if the USB storage
device does not t into the connector.
Note
• You can use digital cameras connected by USB
if they can play the les without using a special
computer program.
• To play DivX DRM - protected les from
a USB storage device, connect your home
theater to a TV through an HDMI cable.
Access BD-Live with a USB storage
device
1 Connect your home theater to the home
network and internet (see ‘Computers and
the Internet’ on page 17).
2 Connect the USB storage device to the
home theater.
• The USB storage device is used
to store the downloaded BD-Live
content.
3 Press (Home).
4 Select [Setup], and then press OK.
5 Select [Advanced] > [Local Storage] >
[USB], and then press OK.
6 Select the BD-Live icon in the disc menu,
and then press OK.
» BD-Live starts to load. The loading time
depends on the disc and your internet
connection.
7 Press the Navigation buttons to navigate
BD-Live, and then press OK to select an
item.
Access BD-Live with an SD card
1 Connect your home theater to the home
network and internet. (see ‘Computers and
the Internet’ on page 17)
2 Insert the SD memory card into the SD
CARD slot on your home theater.
» The rst time you insert an SD memory
card, the card is formatted. After
formatting, leave the card in the home
theater (see ‘Format an SD card’ on page
32).
3 Press (Home).
4 Select [Setup], and then press OK.
5 Select [Advanced] > [Local Storage] > [SD
card], and then press OK.
6 Select the BD-Live icon in the disc menu,
and then press OK.
» BD-Live starts to load. The loading time
depends on the disc and your internet
connection.
7 Press the Navigation buttons to navigate
BD-Live, and then press OK to select an
item.
EN
23
English
DivX
Play DivX videos from :
• a disc (see ‘Discs’ on page 20),
• a USB storage device (see ‘USB storage
devices’ on page 22), or
• an online video store (see ‘Rent online
video’ on page 32).
Note
• To play DivX DRM protected les from a disc,
a USB storage device, or an online video store,
connect your home theater to a TV through
an HDMI cable.
VOD code for DivX
Before you purchase DivX videos and play them
on your home theater, register the home theater
on www.divx.com using the DivX VOD code.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [DivX® VOD Code],
and then press OK.
» The DivX VOD registration code for
your home theater is displayed.
Subtitles
If your video has subtitles in multiple languages,
select a subtitle language.
1 While playing video, press SUBTITLE to
select a language.
Note
• Make sure that the subtitle le has the same
name as the video le. For example, if the
video le is named ‘movie.avi’, save the subtitle
le as ‘movie.srt’ or ‘movie.sub’.
• Your home theater can play subtitle les in the
following formats: .srt, .sub, .txt, .ssa, .ass, smi,
and .sami. These les do not appear in the le
navigation menu.
• If the subtitles do not appear correctly, change
the character set.
Play les
1 Connect the USB storage device to the
home theater.
2 Press (Home).
» The home menu is displayed.
3 Select [browse USB], and then press OK.
» A content browser is displayed.
4 Select a le, and then press OK.
5 Press the playback buttons to control play
(see ‘Play buttons’ on page 23).
Play buttons
Button Action
Navigation
buttons
Navigate menus.
OK Conrm an entry or selection.
(Play)
Start or resume play.
Pause play.
Stop play.
/
Skip to the previous or next
track, chapter or le.
/
Fast backwards or fast forwards.
Press repeatedly to change the
search speed.
Navigation
buttons (up/
down)
Rotate the picture clockwise or
counter-clockwise.
SUBTITLE Select subtitle language for
video.
OPTIONS
Access the advanced options
when you play your audio,
video, or media les (see ‘Audio,
video, and picture options’ on
page 24).
For video formats such as DivX and WMV:
• To stop play, press .
• To resume the video from where you
stopped, press (Play).
• To play the video from the start, press OK.
EN
24
Audio, video, and picture
options
Use advanced features when you play audio, video,
or media les from a disc or a USB storage device.
Audio options
While playing audio, repeat an audio track, a disc,
or a folder.
1 Press OPTIONS repeatedly to cycle
through the following functions:
• RPT TRAC / RPT FILE: Repeat the
current track or le.
• RPT DISC / RPT FOLD: Repeat all the
tracks on the disc or the folder.
• RPT RAND: Play audio tracks in
random order.
• RPT OFF: Turn off the repeat mode.
Video options
While watching video, select options such as
subtitles, audio language, time search, and picture
settings. Depending on the video source, some
options are not available.
1 Press OPTIONS.
» The video options menu is displayed.
2 Press the Navigation buttons and OK to
select and change:
• [Audio Language]: Select audio
language for video.
• [Subtitle Language]: Select subtitle
language for video.
• [Subtitle Shift]: Change the subtitle
position on the screen.
• [Info]: Display information about what
is playing.
• [Character Set]: Select a character set
that supports the DivX subtitle.
• [Time Search]: Skip to a specic part
of the video by entering the time of
the scene.
• [2nd Audio Language]: Select the
second audio language for Blu-ray
video.
• [2nd Subtitle Language]: Select the
second subtitle language for Blu-ray
video.
• [Titles]: Select a specic title.
• [Chapters]: Select a specic chapter.
Subtitle character set
If the subtitles do not appear correctly, change
the character set that supports the DivX or
RMVB/RM subtitle.
1 Press OPTIONS.
» The options menu is displayed.
2 Press the Navigation buttons to select
[Character Set], and then press OK.
3 Select a character set.
Europe, India, and Russia
Character
Set
Language
[Standard] English, Albanian, Danish, Dutch,
Finnish, French, Gaelic, German,
Italian, Kurdish (Latin), Norwegian,
Portuguese, Spanish, Swedish and
Turkish
[Central
Europe]
Albanian, Croat, Czech, Dutch,
English, German, Hungarian, Irish,
Polish, Romanian, Slovak, Slovene
and Sorbian
[Cyrillic] Bulgarian, Belorussian, English,
Macedonian, Moldavian, Russian,
Serbian and Ukrainian
[Greek] Greek
Asia Pacic and China
Character Set Language
[Standard] Albanian, Danish, Dutch,
English, Finnish, French, Gaelic,
German, Italian, Kurdish (Latin),
Norwegian, Portuguese, Spanish,
Swedish, Turkish
[Chinese] Simplied Chinese
[Chinese-
Traditional]
Traditional Chinese
[Korean] English and Korean
EN
25
English
Slideshows
While playing audio, access fun features such as
picture and musical slideshows.
Picture slideshows
View a slideshow of your pictures stored in your
disc or a USB storage device.
1 Select a picture from a disc or USB storage
device, and then press (Play).
2 Press OPTIONS.
3 Press Navigation buttons and OK to select
the following settings:
• [Slide Animation]: Select an animation
for the slideshow.
• [Duration per slide]: Select a display
speed for each picture in a slideshow.
4 Press to stop the slideshow.
Musical slideshows
Create a musical slideshow to play music and
pictures at the same time.
1 Select a music track, and then press OK.
2 Press BACK, and go to the picture
folder.
3 Select a picture, and then press (Play) to
start the slideshow.
4 Press to stop slideshow.
5 Press again to stop music.
Radio
Listen to FM radio on your home theater, and
store up to 40 radio stations.
What you need
• FM antenna.
Note
• AM and digital radio are not supported.
• If no stereo signal is detected, you are
prompted to install the radio stations again.
• For the best reception, place the antenna away
from the TV or other sources of radiation.
• [Karaoke] (Available only in Asia
Pacic and China): Change the karaoke
settings.
• [Angle List]: Select a different camera
angle.
• [Menus]: Display the disc menu.
• [PIP Selection]: Display Picture-in-
Picture window when playing a Blu-ray
disc that supports the Bonus View.
• [Zoom]: Zoom into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.
• [Repeat]: Repeat a chapter or title.
• [Repeat A-B]: Mark two points within
a chapter or track to repeat play, or
turn off the repeat mode.
• [Picture Settings]: Select a predened
color setting.
Picture options
While viewing a picture, zoom into the picture,
rotate it, add animation to a slideshow, and
change the picture settings.
1 Press OPTIONS.
» The picture options menu appears.
2 Press the Navigation buttons and OK to
select and change the following settings:
• [Rotate +90]: Rotate the picture 90
degree clockwise.
• [Rotate -90]: Rotate the picture 90
degree counter-clockwise.
• [Zoom]: Zoom into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.
• [Info]: Display picture information.
• [Duration per slide]: Select the display
speed for each picture in a slide show.
• [Slide Animation]: Select animation for
the slide show.
• [Picture Settings]: Select a predened
color setting.
• [Repeat]: Repeat a selected folder.
EN
26
Tuning grid
In some countries, you can toggle the FM tuning
grid between 50 kHz and 100 kHz. Switching the
tuning grid erases all preset radio stations.
1 Press SOURCE repeatedly until RADIO
appears on the display panel.
2 Press .
3 Press and hold (Play) to toggle between
50 kHz or 100 kHz.
MP3 player
Connect your MP3 player to play your audio les
or music.
What you need
• An MP3 player.
• A 3.5mm stereo audio cable.
Play music
1 Connect the MP3 player to the home
theater as described in the quick start guide.
2 Press SOURCE repeatedly until MUSIC
I-LINK appears on the display panel.
3 Press the buttons on the MP3 player to
select and play audio les or music.
iPod or iPhone
When you connect a Philips dock for iPod/iPhone,
you can use the home theater to play music,
movies and photos from your iPod or iPhone.
What you need
• A Philips dock (Model: Philips DCK3060/
DCK3061).
• A yellow composite cable.
Note
• Charge your iPod/iPhone on the dock while
the home theater is in iPod mode.
Tune stations
1 Connect the FM antenna as described in the
quick start guide.
2 Press SOURCE repeatedly until RADIO
appears on the display panel.
» If you have already installed the radio
stations, the last channel that you listened
to is played.
» If you have not installed any radio
stations, the message AUTO INSTALL...
PRESS PLAY appears on the display
panel. Press (Play).
3 Press the following buttons to listen or to
change radio stations:
Button Action
/ or
Alphanumeric
buttons
Select a preset radio station.
Navigation
buttons (left/
right)
Search for a radio station.
Navigation
buttons (up/
down)
Fine tune a radio frequency.
Press to stop the installation of
radio stations.
BACK
Press and hold to erase the
preset radio station.
OPTIONS
Manual: Press once to access
program mode, and press again
to store the radio station.
Automatic: Press and hold for
three seconds to reinstall the
radio stations.
Listen to radio
1 Press SOURCE repeatedly until RADIO
appears on the display panel.
• To listen to a preset station, press
or .
• To search for a radio station, and then
listen, press Navigation buttons (left/
right).
2 Press +/- (Volume) to change the volume.
EN
27
English
Use smartphone
Turn your iPhone or Android smartphone into
a virtual remote control, or use it to browse the
contents of a disc or USB storage device on your
home theater.
What you need
• An iPhone (iOS 3.1.3 and above) or
Android (Android 2.1 and above)
smartphone.
• A wired or wireless home network.
Before you start
• Connect your home theater to your home
network (see ‘Computers and the Internet’
on page 17).
• Name your home theater (see ‘Name your
home theater’ on page 18).
• Connect your smartphone to the same
home network. For details, see your
smartphone user manual.
Download MyRemote application
Download the Philips application, MyRemote
(MyRemote) to your smartphone. This
application is free.
Note
• Philips MyRemote is only available for iPhones
and Android smartphones.
1 Tap the App Store (App Store) icon on the
iPhone or the Market (Market) icon on the
Android smartphone.
2 Search for ‘Philips MyRemote’ application.
3 Follow the instructions on your smartphone
to download the application.
» The MyRemote (MyRemote) icon is
added to the home screen of your
smartphone.
Dock your iPod or iPhone
1 Move the slide at the bottom of the dock to
STANDARD, and then connect the dock to
the home theater.
2 Connect the yellow composite cable to the
dock and TV.
3 Switch on the iPod or iPhone, and place it
on the dock.
Play music
1 Dock your iPod or iPhone (see ‘Dock your
iPod or iPhone’ on page 27).
2 Press DOCK for iPod on the home theater
remote control.
3 Browse on the iPod or iPhone screen to
select music tracks.
• To view the playlist on your TV and
use the home theater remote control
to select a track, press DOCK for iPod
again.
Play video and slideshows
1 Dock your iPod or iPhone (see ‘Dock your
iPod or iPhone’ on page 27).
2 On the home theater remote control, press
(Home).
3 Select [browse iPod], and then press OK.
4 Switch the TV to the AV/VIDEO source
(corresponding to the yellow composite
cable).
» The TV screen goes blank.
5 Browse on the iPod or iPhone screen to
select videos or photos.
6 Press (Play) to play the videos or photos.
EN
28
Note
• Some control functions are not available on
smartphones.
Browse a disc or USB storage device
Browse a disc or USB storage device from
your smartphone, and play an audio, video, or
multimedia le.
1 Launch the remote control application on
your smartphone (see ‘Access MyRemote
application’ on page 28).
2 Load a data disc or connect a USB storage
device into your home theater.
3 On your smartphone, tap the Source
(Source) tab, and then select DISC (DISC)
or USB (USB).
» The folders in your disc or USB storage
device are displayed.
4 Select a folder to browse, and then select a
le to play.
» The relevant remote control buttons are
enabled on your smartphone.
5 To access the remote control while you
browse the contents, tap the Remote
(Remote) tab on your smartphone.
Karaoke
Available only in Asia Pacic and China
Play a Karaoke disc on your home theater and sing
along with the music.
What you need
• A Karaoke microphone.
• Karaoke discs.
Note
• To prevent loud feedback or unexpected
noise, turn the microphone volume to the
minimum before you connect the microphone
to your home theater.
Access MyRemote application
Access the MyRemote application from your
smartphone, and then identify your home
theater on the home network.
1 Tap MyRemote (MyRemote) on your
smartphone.
» Your home theater and the other
devices on the network are displayed on
your smartphone. A browsing bar with
Devices, Remote, and Source tabs is also
displayed.
2 If your home theater is not found, check the
network connection (see ‘Computers and
the Internet’ on page 17).
Then, tap the Devices (Devices) tab on
your smartphone to search again.
3 Tap the home theater icon on the
smartphone.
» The virtual remote control is displayed
on the smartphone.
4 To exit the application, press the home
button on your smartphone.
Use your smartphone as a remote
control
The virtual remote control is displayed in
multiple screens on the smartphone. To access
the buttons, swipe the smartphone screen to the
left or right.
Only the control buttons that are relevant to the
play mode are enabled on your smartphone. For
example, if you play pictures, only the remote
control buttons that are used to control the
pictures are enabled. However, if you play a
video, additional buttons, such as SUBTITLE and
TOP MENU, are enabled on your smartphone.
1 Launch the application on your smartphone
(see ‘Access MyRemote application’ on page
28).
» Depending on the play mode, the
relevant remote control buttons are
enabled.
2 If the remote control buttons do not
appear, tap the Remote (Remote) tab on
your smartphone.
3 Swipe to the left or right screen to access
more buttons.
EN
29
English
• Connect your computer to the same home
network.
• Make sure that your PC rewall allows you
to run Windows Media Player programs.
• Switch on your computer and the router.
Microsoft Windows Media Player 11
Note
• Depending on your version of Microsoft
Windows, the screens might look different to
the following screens.
1 Start Windows Media Player on your PC.
2 Click the Library tab, and then select Media
Sharing.
3 The rst time you select Media Sharing on
your PC,a pop-up screen appears. Check
the Share my media box and click OK.
» The Media Sharing screen is displayed.
4 In the Media Sharing screen, make sure
that you see a device marked as Unknown
Device.
» If you don’t see an unknown device
after a minute or so, check that your PC
rewall is not blocking the connection..
5 Select the unknown device and click Allow.
» A green tick appears next to the device.
Play karaoke music
1 While playing a karaoke disc, press
OPTIONS.
» The options menu is displayed.
2 Press the Navigation buttons to select
[Karaoke], and then press OK.
» The karaoke setup menu is displayed.
3 Press the Navigation buttons (up/down)
and OK to change the following settings:
• [Microphone]: Turn the microphone
on or off.
• [Microphone volume]: Change the
microphone volume.
• [Echo]: Change the echo level.
• [Key]: Change the pitch to match your
voice.
• [Vocal support]: Turn the vocals on
or off.
Browse PC through DLNA
When you connect your home theater to your
home network, you can enjoy music, photo, and
video stored on a computer or other media
server on the network.
What you need
• A wired or wireless home network,
connected with a Universal Plug and Play
(uPnP) router.
• A Philips wireless USB adapter or a LAN
cable to connect your home theater to your
home network.
• A media server such as:
• PC running Windows Media Player 11
or higher; or
• Mac running Twonky Media Server.
Note
• For help to use other media servers, such as
TVersity, see the web site of the media server.
Set up media server software
To enable media sharing, set up the media server
software.
Before you start
• Connect your home theater to your home
network (see ‘Computers and the Internet’
on page 17).
EN
30
2 In Windows Media Player, click the Stream
tab, and then select Turn on media
streaming.
» The Media streaming options screen is
displayed.
3 Click Turn on media streaming.
» You return to Windows Media Player
screen.
4 Click the Stream tab and select More
streaming options.
» The Media streaming options screen is
displayed.
5 Make sure that you see a media program in
the Local network screen.
» If you don’t see a media program, check
that your PC rewall is not blocking the
connection.
6 Select the media program and click
Allowed.
» A green arrow appears next to the
media program.
6 By default, Windows Media Player shares
from these folders: My Music, My Pictures,
and My Videos.If your les are in other
folders, select Library > Add to Library.
» The Add to Library screen is displayed.
» If necessary, select Advanced options to
display a list of monitored folders.
7 Select My folders and those of others I can
access, and then click Add.
8 Follow the onscreen instructions to add the
other folders that contain your media les.
Microsoft Windows Media Player 12
Note
• Depending on your version of Microsoft
Windows, the screens might look different to
the following screens.
1 Start Windows Media Player on your PC.
EN
31
English
5 Back in the Twonky Media screen, select
Basic Setup and Sharing.
» The Sharing screen is displayed.
6 Browse and select folders to share, and
then select Save Changes.
» Your Macintosh rescans the folders
automatically so that they are ready to
share.
Play les from your PC
Note
• Before you play multimedia content from the
computer, make sure that the home theater
is connected to the home network, and the
media server software is properly set up.
1 Switch your TV to the correct HDMI source
for your home theater.
2 Press (Home).
» The home menu is displayed.
3 Select [browse PC], and then press OK.
» A content browser is displayed.
4 Select a le, and then press OK.
5 Press the playback buttons to control play
(see ‘Play buttons’ on page 23).
7 By default, Windows Media Player shares
from these folders: My Music, My Pictures,
and My Videos. If your les are in other
folders, click the Organize tab and select
Manage libraries > Music.
» The Music Library Locations screen is
displayed.
Follow the onscreen instructions to add the
other folders that contain your media les.
Macintosh OS X Twonky Media (v4.4.2)
Note
• Depending on which version of the Mac
operating system you use, your screens might
look different to the following screens.
1 Visit http://www.twonkymedia.com to
purchase the software, or download a free
30-day trial to your Macintosh.
2 Start Twonky Media on the Macintosh.
3 In the Twonky Media Server screen, select
Basic Setup and First Steps.
» The First steps screen is displayed.
4 Type a name for your media server, and
then click Save changes.
EN
32
• To clear the text in the address bar,
press BACK.
• To display the onscreen keyboard,
follow the instructions on the screen.
3 After you enter the URL, press the
Navigation buttons to select the arrow
next to the address bar, and then press OK
to conrm.
4 While browsing internet, press
OPTIONS to access the address bar,
shortcut keys and other advanced options.
5 Press BACK to return to the previous
page, or press (Home) to exit.
Clear browsing history
Clear the browsing history to remove passwords,
cookies, and browsing data from your home
theater.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Network] > [Clear Net TV
Memory], and then press OK.
Rent online video
Not available in China
Rent videos from online stores, through your
home theater. You can watch them right away or
later.
Many online video stores offer a huge choice of
video, with different rental prices, periods, and
conditions. For some stores, you must create an
account before you can rent.
What you need
• A high-speed internet connection to the
home theater.
• An HDMI connection between your home
theater and TV.
• An SD memory card of type SDHC Class 6,
with at least 8 GB of memory.
Format an SD card
Before you download any online video or BD-
Live content, your SD card must be in the SD
card slot of your home theater, and formatted.
1 Switch your TV to the correct HDMI source
for your home theater.
Browse Net TV
Not available in China
Use Net TV to access variety of internet
applications and specially adapted internet
websites.
For interactive discussions on Net TV services, visit
the Net TV forum at www.supportforum.philips.
com
Note
• Koninklijke Philips Electronics N.V. bears no
responsibility for content provided by Net TV
service providers.
Access Net TV
1 Connect your home theater to a home
network and the Internet (see ‘Computers
and the Internet’ on page 17).
2 Press (Home).
» The home menu is displayed.
3 Select [browse Net TV], and then press
OK.
» The Net TV home page is displayed. The
rst time you access Net TV, follow the
onscreen instructions to agree to the
terms and conditions, and then register
with Club Philips.
4 Press the Navigation buttons to select
App Gallery (App Gallery) or Internet
(Internet), and then press OK.
• Access App Gallery (App Gallery) to
add more Apps to your screen.
• Access Internet (Internet) to browse
the Internet.
5 Press BACK to return to the previous
page, or press (Home) to exit.
Browse internet
1 Press the Navigation buttons to select
Internet (Internet) from the Net TV home
page, and then press OK.
2 Select the address bar, and then press the
Alphanumeric buttons to enter the URL of
the website.
EN
33
English
• If you move the card and format it
in another device, your downloaded
video is erased. Download your video
again before you watch.
7 Press the play buttons on your remote
control to play, pause, search, or stop the
video.
EasyLink
The home theater supports Philips EasyLink, which
uses the HDMI-CEC (Consumer Electronics
Control) protocol. EasyLink-compliant devices that
are connected through HDMI can be controlled
by a single remote control.
Philips does not guarantee 100% interoperability
with all HDMI-CEC devices.
What you need
• HDMI-CEC compliant devices.
• An HDMI connection between the
connected devices.
Switch on
1 On the TV and other connected devices,
turn on the HDMI-CEC operations. For
details, see the manual of the TV or other
devices.
2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [EasyLink] > [EasyLink], and then
press OK.
5 Select [On], and then press OK.
Control devices
Control the home theater and the other
connected HDMI-CEC compliant devices with a
single remote control.
2 Insert the SD memory card into the SD
CARD slot on your home theater.
3 Follow the onscreen instructions to format
the card.
» Any content on the card is erased during
formatting.
4 After formatting, leave the card in the SD
CARD slot.
Rent and play online video
1 Connect your home theater to the home
network and internet (see ‘Computers and
the Internet’ on page 17).
2 Press (Home).
3 Select [browse Net TV], and then press
OK.
» The online services available in your
country are displayed.
4 Press the Navigation buttons to go to a
video store, and then press OK.
5 If prompted, follow the video store
instructions to register or log in to an
account.
» You see an option to rent videos.
» If you have rented videos and are still
within the rental period, you also see an
option to watch the videos.
6 Follow the video store instructions to rent
or watch a video.
• The video is downloaded to your SD
memory card. You can watch it now or
at any time within the rental period.
• When you have downloaded a video
to your card, you can watch it only on
your home theater. You can’t move the
card and watch it on another device.
EN
34
8 Change settings
This section helps you to change the settings of
your home theater.
Caution
• Most of the settings are already congured
with the best value for your home theater.
Unless you have a reason to change a setting, it
is best to leave it at the default value.
Note
• You cannot change a setting that is grayed out.
• To return to the previous menu, press
BACK. To exit the menu, press (Home).
Change the picture settings to suit your
preferences.
Note
• The best setting is automatically selected for
the TV. If you change the setting, make sure
that the TV supports the new settings.
Picture settings and format
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Video], and then press OK.
4 Change the following settings, and then
press OK:
• [TV Display]: Picture format.
• [Picture Settings]: Predened color
settings.
One-touch play
If you enable One-touch play, the TV
automatically switches to the correct channel
when you play a disc in your home theater.
One-touch standby
When you press and hold (Standby) on the
remote control, the home theater and all the
connected HDMI-CEC devices (that support
one-touch standby) switch to the standby mode.
If one-touch standby is enabled on your home
theater, you can switch to standby with the
remote control of the TV or other HDMI-CEC
devices.
System Audio Control
When you play a device that has its audio
output routed to the home theater, the home
theater switches to the corresponding audio
source automatically.
To use one-touch audio, turn on System Audio
Control and follow the instructions on the TV
to map connected devices to the audio input
connectors of the home theater.
Audio Input Mapping
When you connect a new device to your home
theater, map the device to the audio input
connector (see ‘Play audio from home theater’
on page 34).
Play audio from home theater
Play the audio from a connected device through
your home theater.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [EasyLink] > [System Audio
Control] > [On], and then press OK.
• To play the audio from the TV
speakers, select [Off], and skip the
following steps.
4 Select [EasyLink] > [Audio Input Mapping],
and then press OK.
5 Follow the instructions on the TV to map
the audio of the connected device to the
audio inputs on your home theater.
Note
• If you connect your home theater to the TV
through an HDMI ARC connection, make sure
that the TV audio is mapped to the ARC input
on your home theater.
EN
35
English
Sound
Change the sound settings to suit your preference.
HDMI audio
To hear an HDMI audio output from your TV,
connect your home theater to the TV through
an HDMI cable.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Audio] > [HDMI Audio], and then
press OK.
4 Select the following options, and then press
OK:
• [Bitstream]: Enable bitstream output
over HDMI.
• [Auto]: Automatically select the best
supported audio format.
• [Off]: Disable audio from the TV.
Audio post processing
To select a predened sound mode, enable
audio post processing at the speaker (see ‘Sound
mode’ on page 19).
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [Enhanced Audio] >
[On], and then press OK.
Note
• To play the original audio of the disc, select
[Off].
Night mode
For quiet listening, decrease the volume of loud
sounds when you play discs. Night mode is only
available for Dolby-encoded DVD and Blu-ray
discs.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Audio] > [Night Mode] > [On], and
then press OK.
Picture color
Deep Color recreates the natural world on your
TV screen and displays vivid images in over a
billion of colors.
If your TV supports Deep Color and is
connected to your home theater through an
HDMI cable, you can change the Deep Color.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Video] > [HDMI Deep Color], and
then press OK.
4 Select the following options, and then press
OK:
• [Auto]: Automatically select HDMI
Deep Color.
• [On]: View vivid images.
• [Off]: Display standard 24-bit color.
Picture resolution
For HDMI video settings, connect your home
theater to the TV through an HDMI cable.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Video] > [HDMI Video], and then
press OK.
4 Change the HDMI resolution setting, and
then press OK.
Blu-ray 3D video
To play 3D video, connect your home theater to
a 3D TV through an HDMI cable.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Video] > [Watch 3D video] >
[Auto], and then press OK.
Subtitle position
Automatically change the position of the subtitles
to t your TV screen.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference] > [Auto Subtitle Shift]
> [On], and then press OK.
EN
36
Disc subtitle
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference] > [Subtitle], and then
press OK.
4 Select a subtitle language for discs, and then
press OK.
Disc menu
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference] > [Disc Menu], and
then press OK.
4 Select a menu language for discs, and then
press OK.
Note
• If your preferred disc language is not available,
select [Others] from the list, and enter the
4-digit language code found at the the end of
this user manual (see ‘Language code’ on page
46).
• If you select a language that is not available
on a disc, the home theater uses the default
language of the disc.
Parental control
Restrict access to discs that are recorded with
ratings.
Password
You can set or change your password to play a
restricted disc.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference] > [Change Password],
and then press OK.
» A change password menu is displayed.
4 Follow the instructions on the TV to set or
change password.
• If you do not have a password or you
have forgotten, enter 0000.
5 Press OK.
Restore sound mode settings
Restore the equalizer settings of all the sound
modes to the default values.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Audio] > [Default sound settings],
and then press OK.
Language
Select a language for the home menu, audio, and
subtitles.
Home menu
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference] > [Menu language], and
then press OK.
4 Select a menu language, and then press OK.
Disc audio
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference] > [Audio], and then
press OK.
4 Select an audio language for discs, and then
press OK.
Note
• If your preferred disc language is not available,
select [Others] from the list, and enter the
4-digit language code found at the end of this
user manual (see ‘Language code’ on page 46).
• If you select a language that is not available
on a disc, the home theater uses the default
language of the disc.
EN
37
English
5 Press OK to activate.
» The home theater switches to standby
after the specied time.
Screen saver
Automatically switch your home theater to
screen saver mode if:
• it is in pause or stop mode, and
• no button is pressed for 10 minutes.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference] > [Screen Saver] >
[On], and then press OK.
Display panel
Change the brightness of the home theater
display panel.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference] > [Display Panel], and
then press OK.
4 Select the brightness, and then press OK.
Apply factory settings
Reset your home theater to the default settings.
You cannot reset the parental control settings.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [Restore default
settings], and then press OK.
4 Select [OK], and then press OK.
Ratings
Some discs are recorded with ratings according
to age. You can set up your home theater to play
only discs with an age rating lower than your
child’s age.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference] > [Parental Control],
and then press OK.
» A message prompts you to enter the
password.
4 Enter the password with the Numeric
buttons.
5 Select an age rating, and then press OK.
• To play all discs irrespective of the
rating, select level 8 or [Off].
Energy saving
Save energy by changing the following settings.
Auto standby
When playing a disc or a USB storage device,
automatically switch your home theater to
standby if:
• it is in pause or stop mode, and
• no button is pressed for 30 minutes.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference] > [Auto Standby] >
[On], and then press OK.
Sleep timer
Set timers to switch the home theater to
standby after a specied time.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference] > [Sleep Timer], and
then press OK.
4 Select the duration of the sleep timer.
» The sleep timer can be set up to 60
minutes. If the sleep timer is set to [Off],
it switches off.
EN
38
Update software through USB
What you need
• A USB ash drive, with at least 75MB of
memory. The USB ash drive must be FAT
or NTFS formatted. Do not use a USB hard
drive.
• A computer with Internet access.
• An archive utility that supports the ZIP
le format (for example, WinZip® for
Microsoft® Windows® or Stuft® for
Macintosh®).
Step 1: Download the latest software
1 Connect a USB ash drive to your
computer.
2 In your web browser, go to www.philips.
com/support.
3 At the Philips Support website, nd your
product and locate the Software and
drivers.
» The software update is available as a zip
le.
4 Save the zip le in the root directory of
your USB ash drive.
5 Use the archive utility to extract the
software update le in the root directory of
the USB ash drive.
» The les are extracted under the UPG_
ALL folder of your USB ash drive.
6 Disconnect the USB ash drive from your
computer.
9 Update software
To continue to get the best features and support
for your home theater, update the software
regularly. Compare the version of your current
software with the latest version on
www.philips.com/support.
Check software version
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [Version Info.], and
then press OK.
» The software version is displayed.
Update software through the
Internet
1 Connect your home theater to the
network. Use a
• wired network connection (see ‘Set up
the wired network’ on page 17), or
• a wireless network connection (see
‘Set up the wireless network’ on page
18).
2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Advanced] > [Software Update] >
[Network].
» If an upgrade media is detected, you are
prompted to start or cancel the update.
5 Follow the instruction on the TV to conrm
the update.
» When the software update is complete,
the home theater automatically switches
off and restarts. If it does not, disconnect
the power cord for a few seconds and
then reconnect it.
Note
• If the home theater cannot connect to the
Philips server, press (Home), and then
select [Setup] > [Network] > [Network
Installation] to set up the network.
EN
39
English
10 Product
specifications
Note
• Specications and design are subject to change
without notice.
Region codes
The type plate on the back or bottom of the
home theater shows which regions it supports.
Media formats
• AVCHD, BD, BD-R/ BD-RE, BD-Video,
DVD-Video, DVD+R/+RW, DVD-R/-RW,
DVD+R/-R DL, CD-R/CD-RW, Audio CD,
Video CD/SVCD, Picture les, MP3 media,
WMA media, DivX Plus HD media, USB
storage device
Country
DVD BD
Europe,
United Kingdom
Korea
Latin America
Australia,
New Zealand
Russia, India
China
AA
AA
CC
CC
Asia Pacific, Taiwan,
Step 2: Update the software
Caution
• Before you connect the USB ash drive to
your home theater, make sure that there is
no disc in the disc compartment, and the disc
compartment is closed.
1 Connect the USB ash drive to your home
theater.
2 Switch your TV to the correct source for
your home theater.
3 Press (Home), and then select [Setup].
4 Select [Advanced] > [Software Update] >
[USB].
5 Follow the instructions on the TV to
conrm the update.
» When the software update is complete,
the home theater automatically switches
off and restarts. If it does not, disconnect
the power cord for a few seconds, and
then reconnect it.
Note
• When the software update is in progress, do
not turn off the power or remove the USB
ash drive.
EN
40
.avi les in AVI container
Audio
codec
Video codec Bit rate
PCM,
Dolby
Digital,
DTS
core,
MP3,
WMA
DivX 3.11, DivX 4.x,
DivX 5.x, DivX 6.x
10 Mbps max
MPEG 1, MPEG 2 20 Mbps (peak
40 Mbps)
MPEG 4 ASP 10 Mbps max
H.264/AVC
HP@4.1/4.0;
[email protected]/3.1/3.0
20 Mbps (peak
40 Mbps)
WMV9 20 Mbps
.divx les in AVI container
Audio
codec
Video codec Bit rate
PCM,
Dolby
Digital,
MP3,
WMA
DivX 3.11, DivX 4.x,
DivX 5.x, DivX 6.x
10 Mbps max
MPEG 1, MPEG 2 20 Mbps (peak
40 Mbps)
MPEG 4 ASP 10 Mbps max
.mp4 or .m4v les in MP4 container
Audio
codec
Video codec Bit rate
Dolby
Digital,
MPEG,
MP3,
AAC, HE-
AAC
MPEG 1, MPEG 2 20 Mbps (peak
40 Mbps)
MPEG 4 ASP 10 Mbps max
H.264/AVC
HP@4.1/4.0;
[email protected]/3.1/3.0
20 Mbps (peak
40 Mbps)
File formats
• Audio: .aac, .mka, .mp3, .wma, .wav, .mp4,
.m4a
• Video:
• .avi, .divx, .mp4, .mkv, .asf, .wmv, .mpg,
.mpeg,
• .rmvb, .rm (Available only in Asia
Pacic and China)
• Picture: .jpg, .jpeg, .gif, .png
Audio formats
Your home theater supports the following audio
les.
Extension Container Audio
codec
Bit rate
.mp3 MP3 MP3 32 kbps ~
320 kbps
.wma ASF WMA 64 kbps ~
160 kbps
.aac AAC AAC, HE-
AAC
192 kbps
.wav WAV PCM 1.4 Mbps
.m4a MKV AAC 192 kbps
.mka MKA PCM 27.648
Mbps
.mka MKA Dolby
Digital
640 kbps
.mka MKA DTS core 1.54 Mbps
.mka MKA MPEG 912 kbps
.mka MKA MP3 32 kbps ~
320 kbps
.mka MKA WMA 64 kbps ~
160 kbps
.mka MKA AAC, HE-
AAC
192 kbps
Video formats
If you have a high denition TV, your home
theater allows you to play your video les with:
• Resolution: 1920 x 1080 pixels at
• Frame rate: 6 ~ 30 frames per second.
EN
41
English
Amplier
• Total output power:
• Europe and Asia: 1000W RMS (30%
THD)
• Latin America: 800W RMS (+/- 0.5 dB,
10% THD)
• Frequency response: 20 Hz-20 kHz / ±3 dB
• Signal-to-noise ratio: > 65 dB (CCIR) /
(A-weighted)
• Input sensitivity:
• AUX1, AUX2: 1000 mV
• Music iLink: 500 mV
Video
• Signal system: PAL / NTSC
• HDMI output: 480i/576i, 480p/576p, 720p,
1080i, 1080p, 1080p24
Audio
• S/PDIF Digital audio input:
• Coaxial: IEC 60958-3
• Optical: TOSLINK
• Sampling frequency:
• MP3: 32 kHz, 44.1 kHz, 48 kHz
• WMA: 44.1 kHz, 48 kHz
• Constant bit rate:
• MP3: 32 kbps - 320 kbps
• WMA: 48 kbps - 192 kbps
Radio
• Tuning range:
• Europe/China: FM 87.5-108 MHz (50
kHz)
• Asia Pacic/Russia/Latin America: FM
87.5-108 MHz (50/100 kHz)
• Signal-to-noise ratio: FM 50 dB
• Frequency response: FM 180 Hz-12.5 kHz
/ ±3 dB
USB
• Compatibility: Hi-Speed USB (2.0)
• Class support: USB Mass Storage Class
(MSC)
• File system: FAT16, FAT32, NTFS
• Maximum memory support: < 160 GB
.mkv les in MKV container
Audio codec Video codec Bit rate
PCM, Dolby
Digital, DTS
core, MPEG,
MP3, WMA,
AAC, HE-
AAC
MPEG 1, MPEG
2
20 Mbps (peak
40 Mbps)
MPEG 4 ASP 10 Mbps max
H.264/AVC
HP@4.1/4.0;
[email protected]/3.1/3.0
20 Mbps (peak
40 Mbps)
WMV9 20 Mbps
.asf and .wmv les in ASF container
Audio
codec
Video codec Bit rate
PCM,
Dolby
Digital,
MP3,
WMA
MPEG 4 ASP 10 Mbps max
H.264/AVC
HP@4.1/4.0;
[email protected]/3.1/3.0
20 Mbps (peak
40 Mbps)
WMV9 20 Mbps
.mpg and .mpeg les in PS container
Audio
codec
Video codec Bit rate
PCM,
DTS core,
MPEG,
MP3
MPEG 1,
MPEG 2
20 Mbps (peak 40
Mbps)
MPEG 1,
MPEG 2
20 Mbps (peak 40
Mbps)
.rm and .rmvb les in RM container (Available
only in Asia Pacic and China)
Audio
codec
Video
codec
Bit rate
AAC,
COOK
RV30,
RV40
20 Mbps (peak 40
Mbps)
EN
42
• Frequency response: 150 Hz-20 kHz
• Dimensions (WxHxD):
• HTS4561/HTS4562 : 161 x 95 x 92 mm
• HTS5561/HTS5562/HTS5581/
HTS5582/HTS5591/HTS5592: 280 x
95 x 92 mm
• Weight:
• HTS4561/HTS4562: 0.8kg
• HTS5561/HTS5562/HTS5581/
HTS5582/HTS5591/HTS5592: 1.40 kg
• Cable length: 2 m
Front / rear speakers:
• Output power:
• Europe and Asia: 4 x 135W RMS (30%
THD)
• Latin America: 4 x 108W RMS (+/- 0.5
dB, 10% THD)
• Speaker impedance: 5 ohm
• Speaker drivers:
• HTS4561/HTS4562: 2 x 76.2 mm (3”)
full range
• HTS5561/HTS5562/HTS5581/
HTS5582/HTS5591/HTS5592: 2 x 76.2
mm (3”) full range
• Frequency response: 150 Hz-20 kHz
• Dimensions (WxHxD):
• HTS4561/HTS4562: 95 x 161 x 87 mm
• HTS5561/HTS5562/HTS5581/
HTS5582/HTS5591/HTS5592 small
speakers: 100 x 280 x 104 mm
• HTS5561/HTS5562/HTS5581/
HTS5582/HTS5591/HTS5592 tall
speakers: 260 x 1101 x 260 mm
• Weight:
• HTS4561/HTS4562: 0.6 kg each
• HTS5561/HTS5562/HTS5581/
HTS5582/HTS5591/HTS5592 small
speakers: 0.98-1.07 kg each
• HTS5561/HTS5562/HTS5581/
HTS5582/HTS5591/HTS5592 tall
speakers: 3.81-3.89 kg each
• Cable length (front speakers): 4 m
• Cable length (rear speakers): 10 m
Remote control batteries
• 2 x AAA-R03-1.5 V
Main unit
• Power supply:
• Europe/China: 220-240 V~, 50 Hz
• Latin America/Asia Pacic: 110-127
V/220-240 V~, 50-60 Hz
• Russia/India: 220-240 V~, 50 Hz
• Power consumption: 105 W
• Standby power consumption: ≤ 0.5 W
• Dimensions (WxHxD): 435 x 57 x 356.5
mm
• Weight: 3.69 kg
Subwoofer
• Output power:
• Europe and Asia: 230W RMS (30%
THD)
• Latin America: 184W RMS (+/- 0.5 dB,
10% THD)
• Impedance: 3 ohm
• Speaker drivers:
• Europe and Asia:165 mm (6.5”) woofer
• India and Latin America: 203 mm (8”)
woofer
• Frequency response: 20 Hz-150 Hz
• Dimensions (WxHxD):
• HTS4561/HTS4562: 123x 309 x369
mm
• HTS5561/HTS5562/HTS5581/
HTS5582/HTS5591/HTS5592: 196 x
395 x 342 mm
• Weight:
• HTS4561/HTS4562: 3.6 kg
• HTS5561/HTS5562/HTS5581/
HTS5582/HTS5591/HTS5592: 4.8 kg
• Cable length: 3 m
Speakers
Center speaker:
• Output power:
• Europe and Asia: 230W RMS (30%
THD)
• Latin America: 184W RMS (+/- 0.5 dB,
10% THD)
• System: full range satellite
• Speaker impedance: 3 ohm
• Speaker drivers:
• HTS4561/HTS4562: 1 x 76.2 mm (3”)
full range
• HTS5561/HTS5562/HTS5581/
HTS5582/HTS5591/HTS5592: 2 x 76.2
mm (3”) full range
EN
43
English
11 Troubleshooting
Warning
• Risk of electric shock. Never remove the
casing of the product.
To keep the warranty valid, never try to repair the
product yourself.
If you have problems using this product, check the
following points before you request service. If you
still have a problem, register your product and get
support at www.philips.com/welcome.
Main unit
The buttons on the home theater do not work.
• Disconnect the home theater from the
power supply for a few minutes, then
reconnect.
No picture.
• Make sure that the TV is switched to the
correct source for the home theater.
No picture on a TV connected through HDMI.
• Make sure that you use a High Speed HDMI
cable to connect the home theater and TV.
Some Standard HDMI cables do not display
properly for some images, 3D video, or
Deep Color.
• Make sure that the HDMI cable is not faulty.
If it is faulty, replace it with a new cable.
• Press (Home) and then 731 on the
remote control to restore the default
picture resolution.
• Change the HDMI video setting, or wait for
10 seconds for auto recovery (see ‘Picture
resolution’ on page 35).
Disc does not play high-denition video.
• Make sure that the disc contains high-
denition video.
• Make sure that the TV supports high-
denition video.
• Use an HDMI cable to connect to the TV.
Laser
• Laser Type (Diode): InGaN/AIGaN (BD),
AIGaInP (DVD/CD)
• Wave length: 405 +7 nm/-7 nm (BD), 655
+10 nm/-10 nm (DVD), 790 +10 nm/-20
nm (CD)
• Output power (Max. ratings): 20 mW (BD),
6 mW (DVD), 7 mW (CD)
EN
44
• Select the correct character set: 1) Press
OPTIONS. 2) Select [Character Set].
3) Select the supported character set.
4) Press OK.
Cannot read the contents of a USB storage
device.
• Make sure that the format of the USB
storage device is compatible with the home
theater.
• Make sure that the le system on the USB
storage device is supported by the home
theater.
‘No entry’ or ‘x’ sign appears on the TV.
• The operation is not possible.
EasyLink does not work.
• Make sure that the home theater is
connected to a Philips brand EasyLink TV,
and the EasyLink option is on (see ‘EasyLink’
on page 33).
When you switch on the TV, the home theater
automatically switches on.
• This behavior is normal when you are using
Philips EasyLink (HDMI-CEC). To make the
home theater work independently, switch
off EasyLink.
Cannot access BD-Live features.
• Make sure that the home theater is
connected to the network. Use a
wired network connection (see ‘Wired
connection’ on page 17) or wireless
network connection (see ‘Wireless
connection’ on page 18).
• Make sure that the network is set up. Use
a wired network installation (see ‘Set up
the wired network’ on page 17) or wireless
network installation (see ‘Set up the
wireless network’ on page 18).
• Make sure that the Blu-ray disc supports
BD-Live features.
• Clear memory storage (see ‘Clear memory’
on page 22).
Cannot play video or photos from an iPod or
iPhone on the TV.
• Browse and select videos and photos from
the iPod or iPhone screen, and play them
on your TV.
• Make sure that the iPod or iPhone software
has not been tampered with or illegally
modied.
Cannot view pictures from an iPod or iPhone on
the TV.
• Connect a yellow composite cable to the
iPod dock and the TV.
Sound
No sound from home theater speakers.
• Connect the audio cable from your home
theater to your TV or other devices. You
do not need a separate audio connection
when:
• the home theater and TV are
connected through an HDMI ARC
connection, or
• a device is connected to the HDMI IN
connector on your home theater.
• Set up the audio for the connected device
(see ‘Set up audio for connected devices’ on
page 16).
• Reset your home theater to its factory
settings (see ‘Apply factory settings’ on page
37), and then switch it off and switch on
again.
• On your home theater, press SOURCE
repeatedly to select the correct audio input.
Distorted sound or echo.
• If you play audio from the TV through the
home theater, make sure that the TV is
muted.
Audio and video are not synchronized.
• 1) Press SOUND SETTINGS. 2) Press
the Navigation buttons (left/right) to select
AUD SYNC, and then press OK. 3) Press
the Navigation buttons (up/down) to
synchronize the audio with the video.
Play
Cannot play a disc.
• Clean the disc.
• Make sure that the home theater supports
the type of disc (see ‘Media formats’ on
page 39).
• Make sure that the home theater supports
the region code of the disc (see ‘Region
codes’ on page 39).
• If the disc is a DVD±RW or DVD±R disc,
make sure that it is nalized.
Cannot play a DivX le.
• Make sure that the DivX le is encoded
according to the ‘Home Theater Prole’
with the DivX encoder.
• Make sure that the DivX le is complete.
DivX or RMVB/RM subtitles do not display
correctly.
• Make sure that the subtitle le name is the
same as the movie le name (see ‘Subtitles’
on page 23).
EN
45
English
• Switch the TV to the AV/VIDEO source
(corresponding to the yellow composite
cable).
• Press the play button on the iPod or iPhone
to start a slideshow.
• Make sure that the iPod or iPhone software
has not been tampered with or illegally
modied.
Play 3D video in 2D mode.
• Make sure that your home theater is
connected to a 3D TV through an HDMI
cable.
• Make sure that the disc is a Blu-ray 3D disc,
and the Blu-ray 3D video option is on (see
‘Blu-ray 3D video’ on page 35).
TV screen is black when you play a Blu-ray 3D
video or a DivX copy protected video.
• Make sure that the home theater is
connected to the TV through an HDMI
cable.
• Switch to the correct HDMI source on the
TV.
Cannot download video from an online video
store.
• Make sure that your home theater is
connected to the TV through an HDMI
cable.
• Make sure that the SD card is formatted,
has enough memory to download the
video, and is of type SDHC Class 6.
• Make sure that you have paid for the video,
and it is within the rental period.
• Make sure that the network connection
is good. Use a wired network connection
(see ‘Wired connection’ on page 17) or a
wireless network connection (see ‘Wireless
connection’ on page 18).
• Visit the video store website for more
information.
Network
Wireless network distorted or not found.
• Make sure that the wireless network is
not disturbed by microwave ovens, DECT
phones, or other neighboring Wi-Fi devices.
• If the wireless network does not work
properly, try a wired network installation
(see ‘Set up the wired network’ on page
17).
EN
46
12 Language code
Abkhazian 6566
Afar 6565
Afrikaans 6570
Amharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Avestan 6569
Aymara 6589
Azerhaijani 6590
Bahasa Melayu 7783
Bashkir 6665
Belarusian 6669
Bengali 6678
Bihari 6672
Bislama 6673
Bokmål, Norwegian 7866
Bosanski 6683
Brezhoneg 6682
Bulgarian 6671
Burmese 7789
Castellano, Español 6983
Catalán 6765
Chamorro 6772
Chechen 6769
Chewa; Chichewa; Nyanja 7889
9072
Chuang; Zhuang 9065
Church Slavic; Slavonic 6785
Chuvash 6786
Corsican 6779
Česky 6783
Dansk 6865
Deutsch 6869
Dzongkha 6890
English 6978
Esperanto 6979
Estonian 6984
Euskara 6985
6976
Faroese 7079
Français 7082
Frysk 7089
Fijian 7074
Gaelic; Scottish Gaelic 7168
Gallegan 7176
Georgian 7565
Gikuyu; Kikuyu 7573
Guarani 7178
Gujarati 7185
Hausa 7265
Herero 7290
Hindi 7273
Hiri Motu 7279
Hrwatski 6779
Ido 7379
Interlingua (International)7365
Interlingue 7365
Inuktitut 7385
Inupiaq 7375
Irish 7165
Íslenska 7383
Italiano 7384
Ivrit 7269
Japanese 7465
Javanese 7486
Kalaallisut 7576
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kernewek 7587
Khmer 7577
Kinyarwanda 8287
Kirghiz 7589
Komi 7586
Korean 7579
Kuanyama; Kwanyama 7574
Kurdish 7585
Lao 7679
Latina 7665
Latvian 7686
Letzeburgesch; 7666
Limburgan; Limburger 7673
Lingala 7678
Lithuanian 7684
Luxembourgish; 7666
Macedonian 7775
Malagasy 7771
Magyar 7285
Malayalam 7776
Maltese 7784
Manx 7186
Maori 7773
Marathi 7782
Marshallese 7772
Moldavian 7779
Mongolian 7778
Nauru 7865
Navaho; Navajo 7886
Ndebele, North 7868
Ndebele, South 7882
Ndonga 7871
Nederlands 7876
Nepali 7869
Norsk 7879
Northern Sami 8369
North Ndebele 7868
Norwegian Nynorsk; 7878
Occitan; Provencal 7967
Old Bulgarian; Old Slavonic 6785
Oriya 7982
Oromo 7977
Ossetian; Ossetic 7983
Pali 8073
Panjabi 8065
Persian 7065
Polski 8076
Po
rtuguês 8084
Pushto 8083
Russian 8285
Quechua 8185
Raeto-Romance 8277
Romanian 8279
Rundi 8278
Samoan 8377
Sango 8371
Sanskrit 8365
Sardinian 8367
Serbian 8382
Shona 8378
Shqip 8381
Sindhi 8368
Sinhalese 8373
Slovensky 8373
Slovenian 8376
Somali 8379
Sotho; Southern 8384
South Ndebele 7882
Sundanese 8385
Suomi 7073
Swahili 8387
Swati 8383
Svenska 8386
Tagalog 8476
Tahitian 8489
Tajik 8471
Tamil 8465
Tatar 8484
Telugu 8469
Thai 8472
Tibetan 6679
Tigrinya 8473
To nga (Tonga Islands) 8479
Tsonga 8483
Tswana 8478
Türkçe 8482
Tu rkmen 8475
Tw i 8487
Uighur 8571
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapuk 8679
Walloon 8765
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 8973
Yo ruba 8979
Zulu 9085
Ё᭛
EN
47
English
USB storage device 22
C
care
environment 9
health 9
product 9
character set 24
close disc compartment 10
computer
connect to 17
DLNA 29
media server software 29
computer network 17
connect
audio (analog cable) 16
audio (coaxial cable - digital) 16
audio (optical cable - digital) 16
audio from TV and other devices 16
computer 29
home network 17
speakers 12
to Internet 17
TV (Composite) 15
TV (HDMI ARC) 14
TV (HDMI) 15
wireless speakers 13
connectors
back connectors - center 14
back connectors - left 13
back connectors - right 14
front connectors 13
control
disc play 20
Easylink (HDMI-CEC) 11
main unit 10
parental control 36
radio 26
USB storage device 23
D
disable
audio post processing 35
BD-Live 22
HDMI-CEC 33
discs
3D disc in 2D mode 21
audio 24
audio language 36
BD-Live 21
Bonus View 21
control buttons 20
DivX 23
13 Index
2
2D video 21
3
3D
3D disc in 2D mode 21
3D safety 9
A
advanced
BD-Live security 22
enhanced audio 35
restore default settings 37
software update 38
software version 38
amplier 41
audio
HDMI audio 35
night mode 35
post processing 35
predened modes 19
quality 16
settings 35
source 16
speaker setup 13
specications 41
audio formats 40
audio input mapping 34
audio language 36
audio options 24
auto standby 37
B
bass 19
BD-Live
BD-Live (SD card) 22
BD-Live (USB) 22
clear memory 22
disable 22
Blu-ray 20
Bonus View 21
brightness 37
browse
disc 20
from iPhone 28
from iPod 27
Net TV 32
online video stores 33
EN
48
HDMI-CEC 33
help
navigate 4
read 4
update 5
I
Internet
BD-Live 21
connect to 17
online video stores 33
update home theater software 38
iPod and iPhone
dock your iPod or iPhone 27
music 27
Philips dock 14
video and slideshow 27
K
karaoke 28
L
language
2nd audio language 21
2nd subtitle language 21
audio 36
disc menu 36
language code 46
onscreen menu 36
subtitle 36
legal notices 6
M
Macintosh Twonky Media 29, 31
main unit
overview 10
specications 42
troubleshooting 43
manually setup speakers 13
media formats 39
media server software 29
Microsoft Windows Media Player 11 29
Microsoft Windows Media Player 12 30
MP3
connector 13
play 26
multimedia content
from disc 20
from online stores 32
from PC 29
from USB storage device 22
menu language 36
options 24
picture 25
picture-in-picture 21
play 20
subtitle 36
synchronize picture and sound 21
time search 24
titles 24
display panel 10
DivX
character set 24
subtitles 23
VOD code 23
DLNA 29
dock your iPod or iPhone 27
E
EasyLink (HDMI-CEC)
audio input mapping 34
control buttons 11
one-touch play 33
one-touch standby 33
system audio control 33
eject disc 10
enable
auto standby 37
auto subtitle shift 35
BD-Live 22
HDMI-CEC 33
predened sound mode 35
screen saver 37
energy
auto standby 37
brightness 37
screen saver 37
sleep timer 37
F
factory settings 37
FAQs 6
FM antenna 14
format SD card 32
front connectors 13
H
HDMI
audio 35
Deep color 35
TV (HDMI ARC) 14
video 35
EN
49
English
rotate 25
settings 34
slideshows 25
troubleshooting 43
zoom 25
picture options 25
picture-in-picture
2nd audio language 21
2nd subtitle language 21
play
discs 20
DivX 23
from PC 31
iPod and iPhone 26
MP3 26
online video 33
radio 41
RMVB or RM les 20
slideshows 25
troubleshooting 44
USB 22
position
connectors 13
position 12
subtitle 35
power options
auto standby 37
brightness 37
screen saver 37
sleep timer 37
preference
audio 35
auto standby 37
auto subtitle shift 35
change password 36
disc menu 36
display panel 37
menu language 36
parental control 36
screen saver 37
sleep timer 37
subtitle 36
product specications 39
R
radio
control buttons 26
FM antenna 14
listen to radio 26
specications 41
tune stations 26
tuning grid 26
ratings 37
N
Net TV
access 32
clear browsing history 32
online video stores 33
watch Net TV page 32
network
home network 17
name a device 18
settings 17
troubleshooting 45
update home theater software 38
Wi-Fi 18
wired connection 17
wireless connection 18
night mode 35
O
one-touch play 33
one-touch standby 33
online video stores
format SD card 32
rent and play video 33
open disc compartment 10
open source software 6
options
audio 24
picture 25
video 24
overview
browse PC 29
connectors 13
HDMI-CEC 33
main unit 10
Net TV 32
online video stores 33
remote control 1010
settings 34
speaker setup 13
P
parental control
password 36
ratings 37
password 36
PC
connect to 17
DLNA 29
media server software 29
Philips Easylink 33
options 25
EN
50
software
check current version 38
electronic user manual 5
update 38
sound
bass 19
default sound mode 36
equalizer 19
predened sound mode 19
surround sound 19
synchronize picture and sound 21
treble 19
troubleshooting 44
speakers
connect 12
manual setup 13
position 12
setup 13
specications 42
surround sound 19
wireless 13
specications 39
subtitle
character set 24
language 36
position 35
subwoofer
specications 42
synchronize picture and sound 21
system audio control 33
T
time search 24
titles 24
trademarks 7
treble 19
troubleshooting
connection 43
main unit 43
network 45
picture 43
play 44
serial number 6
sound 44
tuning grid 26
tutorials 6
recycling 9
region codes 39
remote control
batteries 42
overview 10
virtual 27
rent video
format SD card 32
online video stores 33
repeat 24
RMVB or RM
play 20
S
safety
disposal 9
use of the product 8
watching 3D 9
screen saver 37
SD card 32
settings
3D video 35
audio 35
auto standby 37
auto subtitle shift 35
default 37
disc language 36
HDMI audio 35
HDMI video 35
HDMI-CEC 33
menu language 36
parental rating 37
password 36
picture 34
power 37
resolution 35
restore 37
screen saver 37
sleep timer 37
subtitle language 36
video 34
setup speakers
manually 13
sleep timer 37
slideshows
animation 25
duration 25
musical 25
picture 25
smartphone
browse disc or USB from smartphone 28
smartphone as remote control 28
EN
51
English
U
update software
check current version 38
electronic user manual 5
from a USB storage device 38
from network 38
USB
format 41
USB storage device
control buttons 23
options 24
play 23
specications 41
update home theater software 38
user manual
download 5
navigate 4
read 4
update 5
V
video
HDMI deep color 35
online video 33
picture resolution 35
picture settings 34
synchronize picture and sound 21
video and slideshow 27
VOD code for DivX 23
watch 3D 21
video formats 41
video on demand
format SD card 32
online video stores 33
video options 24
VOD code for DivX 23
W
wired network
settings 17
wired connection 17
wireless network
settings 18
Wi-Fi 18
Wi-Fi dongle 18
wireless connection 18
wireless speakers 13
EN
© 2011 Koninklijke Philips Electronics N.V.
All rights reserved.
sgpam_HTS4561-4562/12_1123_v3
bk.indd Sec4:48 1/12/2010 2:54:37 PM
