to be supplied by Kwong
KV-32XBR450 KV-36XBR450
© 2001 by Sony Corporation
4-082-506-23
Operating Instructions
TM
WARNING
To reduce the risk of fire or shock hazard, do not expose the TV to
rain or moisture.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
This symbol is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
CAUTION
When using TV games, computers, and similar products with your
TV, keep the brightness and contrast functions at low settings. If a
fixed (non-moving) pattern is left on the screen for long periods of
time at a high brightness or contrast setting, the image can be
permanently imprinted onto the screen. Continuously watching
the same program can cause the imprint of station logos onto the
TV screen. These types of imprints are not covered by your
warranty because they are the result of misuse.
Note on Caption Vision
This television receiver provides display of television closed
captioning in accordance with §15.119 of the FCC rules.
Note on Cleaning the TV
Clean the TV with a soft dry cloth. Never use strong solvents such
as thinner or benzine, which might damage the finish of the
cabinet.
Note to CATV System Installer
This reminder is provided to call the CATV system installer’s
attention to Article 820-40 of the NEC that provides guidelines for
proper grounding and, in particular, specifies that the cable ground
shall be connected to the grounding system of the building, as close
to the point of cable entry as practical.
Use of this television receiver for other than private viewing of
programs broadcast on UHF or VHF or transmitted by cable
companies for the use of the general public may require
authorization from the broadcaster/cable company and/or
program owner.
NOTIFICATION
This equipment has been tested and found to comply with the
limits for a Class B digital device pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference with radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
❑ Reorient or relocate the receiving antennas.
❑ Increase the separation between the equipment and receiver.
❑ Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
❑ Consult the dealer or an experienced radio/TV technician for
help.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your authority
to operate this equipment.
Safety
❑
Operate the TV only on 120 V AC.
❑ The plug is designed, for safety purposes, to fit into the wall
outlet only one way. If you are unable to insert the plug fully
into the outlet, contact your dealer.
❑ If any liquid or solid object should fall inside the cabinet,
unplug the TV immediately and have it checked by qualified
service personnel before operating it further.
Installing
❑
To prevent internal heat buildup, do not block the ventilation
openings.
❑ Do not install the TV in a hot or humid place, or in a place
subject to excessive dust or mechanical vibration.
❑ The AC power cord is attached to the rear of the TV with
hooks. Do not attempt to remove the cord from these hooks.
Doing so could cause damage to the TV.
TruSurround is a trademark of SRS Labs,
Inc. SRS and the SRS symbol are
registered trademarks of SRS Labs, Inc. in
the United States and selected foreign
countries. SRS and TruSurround are
incorporated under license from SRS
Labs, Inc. and is protected under United
States Patent Nos. 4,748,669 and 4, 841, 572 with numerous
additional issued and pending foreign patents. Purchase of this
product does not convey the right to sell recordings made with the
TruSurround technology.
BBE and BBE Symbol are trademarks of BBE Sound, Inc. and are
licensed by BBE Sound, Inc. under U.S. Patent No. 4,638,258 and
4,482,866.
FD Trinitron and the Wega logo are trademarks of Sony
Corporation.
Owner’s Record
The model and serial numbers are provided on the front of this
instruction manual and at the rear of the TV. Refer to them
whenever you call upon your Sony dealer regarding this product.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE,
NE PAS OUVRIR
ATTENTION
CAUTION
PRECAUCION
RIESGO DE CHOQUE ELECTRICO
NO ABRIR
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
As an ENERGY STAR Partner,
Sony has determined that this
product or product models meets
the E
NERGY STAR guidelines
for energy efficiency.
®
®
ENERGY STAR is a U.S. registered mark.
®
Important Safeguards
For your protection, please read these instructions completely, and
keep this manual for future reference.
Carefully observe and comply with all warnings, cautions and
instructions placed on the set or described in the operating
instructions or service manual.
WARNING
To guard against injury, the following basic safety precautions
should be observed in the installation, use and servicing of the set.
Use
Power Sources
This set should be operated only from the type
of power source indicated on the serial/model
plate. If you are not sure of the type of electrical
power supplied to your home, consult your
dealer or local power company. For those sets
designed to operate from battery power, refer
to the operating instructions.
Grounding or Polarization
This set is equipped with a polarized AC power cord plug (a plug
having one blade wider than the other), or with a three-wire
grounding type plug (a plug having a third pin for grounding).
Follow the instructions below:
For the set with a polarized AC power cord plug
This plug will fit into the power outlet only one
way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing
the plug. If the plug still fails to fit, contact your electrician to have
a suitable outlet installed. Do not defeat the safety purpose of the
polarized plug by forcing it in.
Alternate Warning
For the set with a three-wire grounding type AC plug
This plug will only fit into a grounding-type
power outlet. This is a safety feature. If you are
unable to insert the plug into the outlet, contact
your electrician to have a suitable outlet installed.
Do not defeat the safety purpose of the grounding plug.
Overloading
Do not overload wall outlets, extension cords or
convenience receptacles beyond their capacity,
since this can result in fire or electric shock.
Always turn the set off when it is not being
used. When the set is left unattended and
unused for long periods of time, unplug it
from the wall outlet as a precaution against
the possibility of an internal malfunction that
could create a fire hazard.
If a snapping or popping sound from a TV set is
continuous or frequent while the TV is operating,
unplug the TV and consult your dealer or service
technician. It is normal for some TV sets to make
occasional snapping or popping sounds,
particularly when being turned on or off.
Object and Liquid Entry
Never push objects of any kind into the set
through the cabinet slots as they may touch
dangerous voltage points or short out parts that
could result in a fire or electric shock. Never spill
liquid of any kind on the set.
Cleaning
Unplug the set from the wall outlet before
cleaning or polishing it. Do not use liquid
cleaners or aerosol cleaners. Use a cloth lightly
dampened with water for cleaning the exterior
of the set.
Installation
Attachments
Do not use attachments not recommended by the
manufacturer, as they may cause hazards.
Water and Moisture
Do not use power-line operated sets near
water — for example, near a bathtub,
washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
Accessories
Do not place the set on an unstable cart, stand,
table or shelf. The set may fall, causing serious
injury to a child or an adult and serious damage
to the set. Use only a cart or stand recommended
by Sony for the specific model of TV. No part of
the TV set should overhang any edge of the TV
cart or stand; any overhanging edge is a safety
hazard. An appliance and cart combination
should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause
the appliance and cart combination to overturn.
Ventilation
The slots and openings in the cabinet and in the back or bottom are
provided for necessary ventilation. To ensure reliable operation of
the set, and to protect it from overheating, these slots and openings
must never be blocked or covered.
❑ Never cover the slots and openings with a
cloth or other materials.
❑ Never block the slots and openings by
placing the set on a bed, sofa, rug or other
similar surface.
❑ Never place the set in a confined space, such
as a bookcase or built-in cabinet, unless
proper ventilation is provided.
❑ Do not place the set near or over a radiator
or heat register, or where it is exposed to
direct sunlight.
Power-Cord Protection
Do not allow anything to rest on or roll over the
power cord, and do not place the set where the
power cord is subject to wear or abuse.
Antennas
Outdoor Antenna Grounding
If an outdoor antenna is installed, follow the precautions below. An
outdoor antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or
where it can come in contact with such power lines or circuits.
WHEN INSTALLING AN OUTDOOR ANTENNA SYSTEM,
EXTREME CARE SHOULD BE TAKEN TO KEEP FROM
CONTACTING SUCH POWER LINES OR CIRCUITS AS
CONTACT WITH THEM IS ALMOST INVARIABLY FATAL.
Be sure the antenna system is grounded so as to provide some
protection against voltage surges and built-up static charges.
Section 810 of the National Electrical Code (NEC) in USA and
Section 54 of the Canadian Electrical Code in Canada provides
information with respect to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location of antenna
discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
Antenna Grounding According to the NEC
Refer to section 54-300 of Canadian Electrical Code for Antenna
Grounding.
Lightning
For added protection for this television receiver during a lightning
storm, or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the antenna.
This will prevent damage to the receiver due to lightning and
power-line surges.
Service
Damage Requiring Service
Unplug the set from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
❑ When the power cord or plug
is damaged or frayed.
❑ If liquid has been spilled into
the set.
❑ If the set has been exposed to
rain or water.
❑ If the set has been subject to
excessive shock by being
dropped, or the cabinet has
been damaged.
❑ If the set does not operate
normally when following the
operating instructions. Adjust
only those controls that are
specified in the operating
instructions. Improper
adjustment of other controls
may result in damage and
will often require extensive
work by a qualified technician
to restore the set to normal operation.
❑ When the set exhibits a distinct change in performance, it
indicates a need for service.
Servicing
Do not attempt to service the set yourself since
opening the cabinet may expose you to dangerous
voltage or other hazards. Refer all servicing to
qualified service personnel.
Replacement Parts
When replacement parts are required, be sure the service
technician certifies in writing that he has used replacement parts
specified by the manufacturer that have the same characteristics as
the original parts.
Unauthorized substitutions may result in fire, electric shock or
other hazards.
Safety Check
Upon completion of any service or repairs to the
set, ask the service technician to perform routine
safety checks (as specified by the manufacturer) to
determine that the set is in safe operating
condition, and to so certify. When the set reaches
the end of its useful life, improper disposal could
result in a picture tube implosion. Ask a qualified
service technician to dispose of the set.
Ground clamp
Antenna lead-in wire
Antenna discharge unit
Ground clamps
Antenna lead-in wire
Power service grounding electrode
NEC: National Electrical Code
Electrical wire
(NEC Section 810-20)
system (NEC Art 250 Part H)
equipment
Contents
Introducing the FD Trinitron Wega
Overview................................................................1
Presenting the FD Trinitron Wega......................2
Package Contents..................................................3
Using the Remote Control...................................3
Installing the TV
Overview................................................................7
TV Controls and Connectors...............................8
Basic Connection
(Connecting Cable TV or Antenna)..........10
Connecting a VCR and Cable............................14
Connecting a VCR and Cable Box....................15
Connecting Two VCRs for Tape Editing.........18
Connecting a Satellite Receiver.........................19
Connecting a Satellite Receiver with a VCR ...20
Connecting an Audio Receiver.........................22
Connecting a DVD Player with
Component Video Connectors..................23
Connecting a DVD Player with
A/V Connectors..........................................24
Connecting a Digital TV Receiver ....................25
Connecting a Camcorder ...................................26
Using the CONTROL S Feature........................27
Setting Up the TV Automatically .....................28
Using the Features
Overview..............................................................29
Using Favorite Channels....................................30
Using Twin View................................................31
Using the Freeze Function.................................34
Using the Menus
Overview..............................................................35
Using the Video Menu.......................................36
Using the Audio Menu ......................................38
Using the Channel Menu...................................40
Using the Parent Menu ......................................42
Using the Timer Menu.......................................46
Using the Setup Menu........................................47
Other Information
Overview..............................................................49
Programming the Remote Control...................50
Operating Other Equipment with Your TV
Remote Control...........................................53
Troubleshooting..................................................55
Specifications.......................................................57
Index.....................................................................59
Introducing the FD Trinitron Wega
2
Presenting the FD Trinitron
Wega
The FD Trinitron Wega (pronounced VAY-GAH) is characterized by
outstanding contrast, uncompromising accuracy, and corner-to-
corner detail.
You’ll recognize the superiority of Wega technology almost
immediately. The first thing you’ll notice is minimal glare from the
flat picture tube. This flat-screen technology improves picture detail
without distortion, unlike conventional curved screens. The FD
Trinitron delivers outstanding image detail not only at the screen
center, but also at the corners — so you can enjoy a bright, clear
picture from any location in a room.
Features Some of the features that you will enjoy with your new TV include:
❑ DRC Mode (Digital Reality Creation): Unlike conventional line
doublers, the DRC feature doubles vertical and horizontal lines,
resulting in four times the density for quality sources such as
DVD, Satellite and Digital camcorder.
❑ Cinemotion: Provides an optimized display by automatically
detecting film content and applying a reverse 3/2 pulldown
process. Moving pictures will appear clearer and more natural-
looking.
❑ Twin View
™
: Using Multi-Image Driver (MIDX), Twin View
allows you to watch two programs side by side, with the ability
to zoom in one picture. You can watch pictures from two different
sources simultaneously.
❑ 16:9 Enhancement: Vertical Compression technology that
maximizes picture resolution on “anamorphic” or “enhanced for
widescreen” sources, including selected DVDs.
❑ Velocity Modulation: Vertical line enhancement that sharpens
picture definition.
❑ Steady Sound: Equalizes volume levels so there is consistent
output between programs and commercials.
❑ Parental Control: V-Chip technology allows parents to block
unsuitable programming for younger viewers.
❑ Component Video Inputs: Offers the best video quality for DVD
(480p, 480i), and Digital Set-top box (HD1080i) connections.
❑ S VIDEO Inputs: Provides a high-quality video signal from
connected equipment.
❑ Favorite Channel Preview: Preview up to eight favorite channels
without leaving the current channel.
Introducing the FD Trinitron Wega
3
Package Contents
Along with your new Trinitron TV, the packaging box contains a
remote control and two AA batteries. These items are all you need to
set it up and operate the TV in its basic configuration.
Most peripherals come with the necessary cables to connect them. If
you want to set up special configurations, you may need to buy extra
cables or connectors. It is best to ensure that you have all needed
materials on hand before beginning a special-connection project.
Using the Remote Control
The remote control is the primary mechanism for controlling your TV.
Handle the remote control with care; avoid dropping it, getting it wet,
placing it in direct sunlight, near a heater, or where the humidity is
high.
Inserting Batteries Insert two size AA (R6) batteries (supplied) by matching the + and –
on the batteries to the diagram inside the battery compartment.
✍ Remove the batteries to avoid damage from possible battery leakage whenever
you anticipate that the remote control will not be used for an extended period.
Introducing the FD Trinitron Wega
4
The following table describes the buttons on the remote control that
are for more advanced functions.
Button Descriptions
Button Description
1 MUTING Press to mute the sound. Press again or press VOL + to
restore the sound.
2 SLEEP Press repeatedly until the TV displays the time in
minutes (15, 30, 45, 60, or 90) that you want the TV to
remain on before shutting off automatically. Cancel
by pressing until SLEEP OFF appears. While Sleep
feature is set, press once to view remaining time.
3 DISPLAY Press once to display the current time and channel
label (if set) and channel number. Press again to turn
Display off. See page 46 for details on setting the time.
4 ANT Changes between the VHF/UHF input to the AUX
input.
5 JUMP Press to jump back and forth between two channels.
The TV alternates between the current channel and
the last channel that was selected.
6 DRC/
CINEMOTION
For high quality sources (i.e., DVD player, Satellite
Receiver), this button cycles through the available
high-resolution picture modes: Interlaced, Progressive,
Cinemotion. Also available in the Video menu. For
details, see “Selecting Video Options” on page 36.
7 PIC MODE Cycles through the available video picture modes:
Vivid, Standard, Movie, Pro. Also available in the Video
menu. For details, see “Selecting Video Options” on
page 36.
8 MENU Press to display the TV on-screen menu. Press again
to exit from the menus.
9 VOL +/- Adjusts the volume.
q; Joystick allows for movement of the on-screen cursor.
Pressing down on the center of the joystick selects the
item.
qa GUIDE Displays the satellite program guide.
qs RESET Press when in a menu to reset the settings to the
factory defaults.
qd POWER buttons
(GREEN)
Turn on and off the TV and SAT/CABLE equipment
you have programmed into the remote control. For
instructions, see “Programming the Remote Control”
on page 50.
qf FUNCTION
buttons
Select the equipment (TV or SAT/CABLE) that you
want to operate. The indicator lights up momentarily
when pushed to show which device the remote
control is operating.
1
4
9
q;
qd
qg
qh
ql
w;
3
5
D
R
C
/
C
I
N
E
M
O
T
I
O
N
7
qa
6
8
qf
qj
qk
qs
2
To scan rapidly through the
channels, press and hold down the
CH+ or CH- button.
z
Introducing the FD Trinitron Wega
5
qg TV/VIDEO
Cycles through the video equipment connected to you
TV’s video inputs:
TV
,
VIDEO 1
,
VIDEO 2
,
VIDEO 3
,
VIDEO 4
,
VIDEO 5
,
VIDEO 6
.
qh 0 – 9 and ENTER Press 0 - 9 to select a channel, the channel changes
after 2 seconds. Press ENTER to select immediately.
qj Turns on/off Twin View. For details, see “Using Twin
View” on page 31.
qk CH +/– Scan through channels.
ql FAVORITES Displays the Favorite Channels list. For details, see
“Using Favorite Channels” on page 30.
w; FREEZE Freezes the window picture. Press again to restore the
picture.
Button Description
(Continued on the next page)
Introducing the FD Trinitron Wega
6
wa SYSTEM OFF Powers off all Sony equipment at once. (This feature
may not work with older Sony equipment.)
ws VCR/DVD CONTROLS
m Rewind
REC Record
M Fast-forward
N Play
x Stop
X Pause
wd DVD MENU Displays the DVD Disc menu
wf
and ENTER
Used for DVD on-screen menu movement and
selection
wg MTS/SAP Cycles through the Multi-channel TV Sound (MTS)
options: Stereo, Auto-SAP (Second Audio Program), and
Mono. For details, see “Using the Audio Menu” on
page 38.
wh CODE SET Used for programming the remote control to operate
non-Sony video equipment. For details, see
“Programming the Remote Control” on page 50.
wj POWER button
(GREEN)
Turn on and off the VCR/DVD equipment you have
programmed into the remote control. For instructions,
see “Programming the Remote Control” on page 50.
wk Use to switch control for connected video equipment.
You can program one video source for each switch
position. (For details, see “Programming the Remote
Control” on page 50.)
wl MENU Used for DVD player setup menu.
e; Switches Steady Sound on/off. For details, see
page 38.
ws
wd
wf
wg
wl
e;
wj
wh
wk
wa
D
R
C
/
C
I
N
E
M
O
T
I
O
N
HOME THEATER CONTROL
(Continued from the previous page)
7
Installing the TV
Overview
This chapter includes illustrated instructions for setting up your TV.
Note About the AC
Power Cord
The AC power cord is attached to the rear of the TV with a hook. Use
caution when removing the AC plug from its holder. Gently slide the
plug in the upward direction to remove from hook. Once removed,
the AC power plug should automatically disengage from its stored
location.
Topic Page
TV Controls and Connectors 8
Basic Connection (Connecting Cable TV or Antenna) 10
Connecting a VCR and Cable 14
Connecting a VCR and Cable Box 15
Connecting Two VCRs for Tape Editing 18
Connecting a Satellite Receiver 19
Connecting a Satellite Receiver with a VCR 20
Connecting an Audio Receiver 22
Connecting a DVD Player with Component Video
Connectors
23
Connecting a DVD Player with A/V Connectors 24
Connecting a Digital TV Receiver 25
Connecting a Camcorder 26
Using the CONTROL S Feature 27
Setting Up the TV Automatically 28
You can detach
the cord from
this hook
AC Power cord
Installing the TV
8
TV Controls and Connectors
Front Panel Menu
Controls
The front panel menu controls allow access to the on-screen menus
without the use of a remote control. Pressing the MENU button
brings up the on-screen menus. The arrow buttons move the
on-screen cursor in the menus and the SELECT button selects the
menu item.
TV Rear Panel
Connection Description
1 AUX Allows you to view local and cable channels if your
cable provider does not feature local channels. You
can switch between local and cable channels by
pressing ANT on the remote control. Devices
connected to the AUX input can be viewed only in
the Twin View left picture.
2 TO CONVERTER This is a VHF/UHF OUT jack that lets you set up
your TV to switch between scrambled channels
(through a cable box) and normal cable channels
(CATV). Use this jack instead of a splitter to get
better picture quality when switching between
scrambled and unscrambled cable channels.
3 VHF/UHF Connects to your VHF/UHF antenna or cable.
1
2
3
4
5
6
7
8
9
Installing the TV
9
4 CONTROL S
IN/OUT
Allows the TV to receive (IN) and send (OUT) remote
control signals to other Sony infrared-controlled
audio or video equipment.
5 S VIDEO Connects to the S VIDEO OUT jack of your VCR or
other S VIDEO-equipped video equipment. Provides
better picture quality than the VHF/UHF jacks or the
Video IN jack.
6 VIDEO/AUDIO
[L(MONO)/R]
Connect to the audio and video OUT jacks on your
VCR or other video equipment. A video input
(VIDEO 2) is located on the front panel of the TV. The
Audio and Video IN jacks provide better picture
quality than the VHF/UHF IN jack.
7 MONITOR OUT Lets you record the program you are watching to a
VCR. When two VCRs are connected, you can use
your TV as a monitor for tape-to-tape editing (not
available with 480p or 1080i when the input is to
VIDEO 5 or 6).
8 AUDIO OUT (VAR/FIX)
L (MONO)/R
Connect to the left and right audio inputs of your
audio or video equipment.
9 HD/DVD IN
(1080i/480p/480i)
Connect to your DVD player’s or Digital Set-top
box’s component video (Y, P
B, PR) and audio (L/R)
jacks.
Connection Description
Installing the TV
10
Basic Connection (Connecting Cable TV or Antenna)
Connecting Directly
to Cable or to an
Antenna
The connection you choose depends on the cable found in your
home.
Newer homes are usually equipped with standard coaxial cable:
VHF Only or VHF/UHF or Cable
Older homes may have 300-ohm twin lead cable:
VHF Only or UHF Only or VHF/UHF
Some homes may have both:
VHF and UHF
75-ohm
VHF/UHF
coaxial
cable
Rear of TV
300-ohm twin lead cable
VHF/UHF
Antenna connector
Rear of TV
75-ohm coaxial cable
VHF/UHF
300-ohm twin lead cable
U/V Splitter
(not supplied)
Rear of TV
Installing the TV
11
Cable and Antenna If your cable provider does not feature local channels, you may find
this set-up convenient.
Select CABLE or antenna (ANT) mode by pressing ANT on the remote
control.
To receive channels using an antenna, instead of the CATV cable:
1 Select antenna mode by pressing ANT on the remote control.
2 Turn the cable to OFF (see page 40).
3 Perform the Auto Program function (see page 40).
Cable Box
Connections
Cable Box and Cable
This is the preferred basic cable TV hookup to use if your cable TV
company scrambles some channels, but not all of them (pay channels
vs. regular cable channels), so you need to use a cable box.
With this setup you can:
❑ Use the TV remote control to change channels using your cable
box when the signal is scrambled.
❑ Use the TV remote control to change channels using your TV
when the signal is not scrambled. (Your TV’s tuner provides a
better signal than the cable box.)
❑ Use the Twin View feature. (When all channels are routed
through your cable box, only one signal is sent to the TV, so you
can not use the Twin View feature.)
❑ Use the Twin View feature normally with the CATV input.
❑ Use the Twin View feature partially with the cable box. (When
you switch the TV input to AUX - to use the cable box - the
unscrambled picture from the cable box will display. You can
display the signal from both AUX and VHF/UHF inputs in the
left Twin View picture, but you can display only the signal from
the VHF/UHF input in the right Twin View picture.
Rear of TV
AUX
TO CONVERTER
VHF/UHF
Antenna cable
(No connection to
CATV cable
TO CONVERTER)
Installing the TV
12
To set up your TV to use both a Cable Box and a direct-connect CATV cable:
1 Connect the Cable TV cable to the TV’s VHF/UHF jack.
2 Using a coaxial cable, connect the TV’s TO CONVERTER jack to
the cable box’s IN jack. The TV’s internal converter allows you to
switch between unscrambled signals coming straight into the TV
and scrambled signals coming in through the cable box,
eliminating the need for an external splitter.
3 Using a coaxial cable, connect the cable box’s OUT jack to the
TV’s AUX jack.
To switch between channels from Cable Box and channels coming directly into TV
❑
Press the ANT button on the TV remote control.
To use the TV remote control to switch channels on the cable box
❑
Program the remote control as necessary. (See “Programming the
Remote Control” on page 50.)
To use the cable box
❑
Have your TV tuner set to channel 3 or 4 (as appropriate) and
then use the Cable Box to change channels.
To prevent the accidental switching of TV channels
❑
When using the VCR or Cable Box, you can use the Channel Fix
feature to lock in a channel. The Channel Fix feature is under the
Channel menu. (See “Using the Channel Menu” on page 40.)
OUT
75-ohm coaxial cable (not supplied)
IN
AUX
TO CONVERTER
VHF/UHF
CATV cable (unscrambled channels)
Cable box
Signal
Rear of TV
Installing the TV
13
Cable Box Only
Use this hookup if:
❑ You subscribe to a cable TV system that uses scrambled or
encoded signals requiring a cable box to view all channels, and
❑ You do not intend to hook up any other audio or video
equipment to your TV.
When all channels are routed through your cable box, only one
unscrambled signal is sent to the TV, so you cannot use the Twin
View feature. If some channels are scrambled, but others are not,
consider using the hookup on page 12 instead.
1 Connect the coaxial connector from your cable service to the
cable box’s IN jack.
2 Using a coaxial cable, connect the cable box’s OUT jack to the
TV’s VHF/UHF jack.
To use the cable box
❑
Have the TV tuner set to channel 3 or 4 (as appropriate) and then
use the cable box to change channels.
To use the TV remote control to switch channels on the cable box
❑
Program the remote control as necessary. For details, see
“Programming the Remote Control” on page 50.
To prevent accidental switching of TV channels
❑
Use the Channel Fix feature to lock in a channel. The Channel Fix
feature is under the Channel menu. For details, see “Using the
Channel Menu” on page 40.
1
2
Rear of TV
OUT
Cable box
IN
CATV cable
VHF/UHF
Installing the TV
14
Connecting a VCR and Cable
Use this hookup if you have cable TV that does not require a cable
box.
1 Connect the cable TV cable to the VCR’s IN jack.
2 Using a coaxial cable, connect the VCR’s OUT jack to the TV’s
VHF/UHF jack.
3 Using an A/V cable, connect the VCR’s Audio and Video OUT
jacks to the TV’s Audio and Video IN jacks.
✍ If the VCR you are connecting has an S VIDEO jack, you can use an S VIDEO
cable for improved picture quality (compared to a combination audio/video
cable). Because an S VIDEO cable carries only the video signal, you will need
audio cables for sound.
VCR
TV
Cable
Coaxial cable
A/V cable
AUDIO-L (white)
AUDIO-R (red)
VIDEO (yellow)
Installing the TV
15
Connecting a VCR and Cable Box
Use this hookup if:
❑ Your cable TV company scrambles some channels, but not all of
them (pay channels vs. regular cable channels), so you need to
use a cable box, and
❑ You want to use the Twin View feature.
With this setup you can:
❑ Use the TV remote control to change channels using your cable
box when the signal is scrambled.
❑ Use the TV remote control to change channels using your TV
when the signal is not scrambled. (Your TV’s tuner provides a
better signal than the cable box.)
❑ Use the Twin View feature.
❑ Record both regular CATV and scrambled channels.
To connect a cable box and a VCR, you will need:
❑ A small, inexpensive device known as a splitter.
❑ Three coaxial cables.
❑ Either a combination audio/video cable, or an S VIDEO cable
and audio cables.
1 Connect the CATV cable to the single (input) jack of the splitter.
2 Use a coaxial cable to connect one of the two output jacks of the
splitter to the TV’s VHF/UHF jack.
3 Use a coaxial cable to connect the other output jack of the splitter
to the input jack of the cable box.
4 Use a coaxial cable to connect the output jack of the cable box to
the input jack of the VCR.
5 Use the video line (yellow) of a combination audio/video (A/V)
cable to connect the video output jack of the VCR to the video
input jack of the TV.
Connect the left (white) and right (red) audio output channels of
the VCR to the respective input channels on the TV.
✍ If your VCR has an S VIDEO jack, you can substitute an S VIDEO cable for
the video line of an A/V cable. The S VIDEO cable will provide improved
video signal quality. (You will need audio cables for sound.)
(Continued on the next page)
Installing the TV
16
To switch between channels from cable box and channels from CATV
❑
Press the TV/VIDEO button on the TV remote control.
To view cable box signals
❑
Match (channel 3 or 4) the channel setting of the VCR IN with the
cable box OUT.
To use the TV remote control to change channels on the cable box
❑
Program the remote control as necessary. (For details, see
“Programming the Remote Control” on page 50.) Then use the
remote control to change the cable box channels.
Cable box
CATV
A/V cable
Coaxial
cable
VCR
TV
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
Coaxial
cable
Coaxial
cable
Splitter
(not included)
(Continued from the previous page)
Installing the TV
17
To use Twin View with the cable box
❑
Turn on the VCR. (The VCR’s tuner is used as one of the Twin
View picture sources; if you do not turn on the VCR, the Twin
View will not work.) Use the remote control’s TV/VIDEO button to
set the Twin View output to VIDEO 1. Change one Twin View
channel by changing channels on the cable box.
Installing the TV
18
Connecting Two VCRs for Tape Editing
If you connect two VCRs, so you can record from one to the other,
you can connect the recording VCR into your TV to monitor what is
being recorded. The procedure below shows you how to do this.
1 Using an A/V cable, connect the playback VCR’s Audio and
Video OUT jacks to the recording VCR’s Audio and Video IN
jacks.
2 Using an A/V cable, connect the recording VCR’s Audio and
Video OUT jacks to the TV’s Audio and Video IN jacks.
To change the video input of the VCR
❑
See your VCR’s user guide for instructions.
To view what is being recorded
❑
Use the remote control to set the TV to the video input to which
the recording VCR is connected. (VIDEO 1 in the illustration
above.)
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
VCR (recording)
VCR (playback)
TV
A/V cable
A/V cable
✍ If the VCRs you are connecting have S VIDEO jacks, you can use S VIDEO
cables for improved picture quality (compared to a combination audio/video
cable). Because S VIDEO cables carry only the video signal, you will need audio
cables for sound.
Installing the TV
19
Connecting a Satellite Receiver
1 Connect the satellite antenna cable to the satellite receiver’s
SATELLITE IN jack.
2 Using an A/V cable, connect the satellite receiver’s Audio and
Video OUT jacks to the TV’s Audio and Video IN jacks.
3 Connect a coaxial cable from your cable or antenna to the TV’s
VHF/UHF jack.
✍ If the receiver you are connecting has an S VIDEO jack, you can use an S VIDEO
cable for improved picture quality (compared to a combination audio/video
cable). Because S VIDEO cables carry only the video signal, you will need audio
cables for sound.
TV
Satellite receiver
Satellite
cable
A/V cable
Coaxial
cable
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
antenna
Installing the TV
20
Connecting a Satellite Receiver with a VCR
1 Connect the satellite antenna cable to the satellite receiver’s
SATELLITE IN jack.
2 Connect the CATV cable to the VCR’s VHF/UHF IN jack.
3 Using a coaxial cable, connect the VCR’s OUT jack to the TV’s
VHF/UHF jack.
4 Using an A/V cable, connect the satellite receiver’s Audio and
Video OUT jacks to the VCR’s Audio and Video IN jacks.
5 Using an A/V cable, connect the VCR’s Audio and Video OUT
jacks to the TV’s Audio and Video IN jacks.
TV
Satellite receiver
VCR
A/V cable
Coaxial
cable
CATV
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
Satellite
antenna
cable
cable
✍ If the peripherals you are connecting have S VIDEO jacks, you can use S VIDEO
cables for improved picture quality (compared to combination audio/video
cables). Because S VIDEO cables carry only the video signal, you will need
audio cables for sound.
Installing the TV
21
6 If necessary, change the video input on your VCR. (See your
VCR’s user’s guide for instructions on how to do that.)
To watch satellite TV, or the VCR
❑
Press TV/VIDEO on the remote control to select a video source.
To watch cable TV
❑
Press TV/VIDEO on the remote control to select VHF/UHF (to select
the CATV cable on the TV).
Installing the TV
22
Connecting an Audio Receiver
For better sound quality, you may want to connect your TV to your
stereo system’s audio receiver.
To connect to an audio receiver
❑
Use audio cables to connect the TV’s Audio OUT jacks to the
audio receiver’s audio LINE IN jacks.
AUDIO-R AUDIO-L
Line
(red)
(white)
input
TV
Installing the TV
23
Connecting a DVD Player with Component
Video Connectors
This is the preferred hookup to use if your DVD player has
component (Y, P
B, PR) jacks.
1 Using three separate component video cables, connect the DVD
player’s Y, P
B and PR jacks to the Y, PB and PR jacks on the TV —
the number 5 or 6 connections under HD/DVD IN.
2 Using an audio cable, connect the DVD player’s Audio OUT
jacks to the TV’s Audio IN jacks. Be sure to use the same column
of inputs that you used for the video connection (HD/DVD IN 5
or 6).
✍ The Y, PB and PR jacks on your DVD player are sometimes labeled Y, CB and
C
R, or Y, B-Y and R-Y. If so, connect the cables to like colors.
Component video cables
DVD player
TV
AUDIO-R (red)
AUDIO-L (white)
Audio cable
✍ You cannot use the MONITOR OUT jacks to record the signal from any
equipment connected into the Y, P
B, PR jacks.
Installing the TV
24
Connecting a DVD Player with A/V Connectors
Use this hookup if your DVD player does not have component (Y, PB,
P
R) jacks.
1 Using audio cables, connect the DVD player’s Audio OUT jacks
to the TV’s Audio IN jacks.
2 Using an S VIDEO cable, connect the DVD player’s S VIDEO jack
to the TV’s S VIDEO jack.
To switch between your TV and DVD
❑
Use the TV/VIDEO button on the TV’s remote control to switch from
one input device to another.
✍ An S VIDEO connection will give a good-quality video signal, but if your DVD
player has component video, that connection (described on the previous page)
will give an even better signal.
Audio cable
DVD player
S VIDEO
cable
AUDIO-R (red)
AUDIO-L (white)
TV
Installing the TV
25
Connecting a Digital TV Receiver
1 Using three separate component video cables, connect the Digital
TV Set-top box’s Y, P
B and PR jacks to the TV.
2 Using an audio cable, connect the Digital TV Set-top box’s Audio
OUT jacks to the TV’s Audio IN jacks.
✍ If you prefer, you can use an S VIDEO cable instead of the Y, PB and PR
connections. The Y, P
B and PR connections will provide the best-quality
picture, but you cannot record the signal from any equipment connected
to the Y, P
B and PR inputs.
Be sure to read the
manual for the Set-top box.
z
S VIDEO
VIDEO
AUDIO
PB
Y
P
R
AUDIO/VIDEO OUT
12
3
(MONO)
AUDIO-R (red)
AUDIO-L (white)
Component video cables
Digital TV Set-top box
TV
Audio cable
Installing the TV
26
Connecting a Camcorder
For easy connection of the camcorder, the TV has front Audio and
Video inputs (shown below). If you prefer, you can connect the
camcorder to the TV’s rear Audio and Video IN jacks.
1 Using A/V cables, connect the camcorder’s Audio and Video
OUT jacks to the TV’s Audio and Video IN jacks.
If you have a mono camcorder, connect its audio output to the TV’s
AUDIO L jack.
To view the camera’s output
❑
Use the TV/VIDEO button on the front panel of the TV (or on the
remote control) to set the TV to the video input to which the
camcorder is connected. (VIDEO 2 in the illustration above.)
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
A/V output
✍ If the camcorder you are connecting has an S VIDEO jack, you can use an
S VIDEO cable for improved picture quality (compared to a combination audio/
video cable). Because S VIDEO cables carry only the video signal, you will also
need audio cables for sound.
Installing the TV
27
Using the CONTROL S Feature
The CONTROL S feature allows you to control your TV, plus other
Sony equipment (such as a DVD player or VCR) connected to the TV,
using only the TV’s remote control. In addition to allowing you to
control multiple devices with one remote control, the CONTROL S
feature allows you to always point your remote control at your TV,
instead of having to point it at the other equipment, which might be
hidden or out of direct line of sight.
TV
Installing the TV
28
Setting Up the TV Automatically
After you finish connecting your TV, you can run Auto Setup to set
up your channels. The Auto Setup screen appears when you turn
your TV on for the first time after installing it. If you do not want to
set up the channels at this time, you can do it later by using the Auto
Program feature in the Channel menu (see page 40 for information
regarding Channel menu).
Using Auto Setup 1 Turn on the TV.
2 Press the TV FUNCTION button on the remote control.
3 Press CH+ to run Auto Setup.
4 After Auto Setup has run, press CH– to exit.
Reset TV to Factory Settings
To reset your TV to the factory settings
1 Turn on the TV.
2 Hold down the RESET button on the remote control.
3 Press and release the POWER button on the TV. (The TV will turn
itself off, then back on.)
4 Release the RESET button.
✍ The Auto Setup feature does not apply for installations that use a cable box for
all channel selection.
Using the Features
30
Using Favorite Channels
The Favorite Channel feature lets you select programs from a list of
favorite channels that you previously specified.
To display a list of your favorite channels:
1 If you have not already done so, create a list of favorite channels.
(For information on setting up Favorite Channels see “Selecting
Channel Options” on page 40.)
2 Press the FAVORITES button on the remote control.
3 Move the joystick V or v to highlight the channel you want to
watch. The program on that channel appears in the preview window.
4 Press the button to select the channel.
Preview window
Using the Features
31
Using Twin View
Twin View lets you see two pictures — from an antenna, a VCR, a
DVD, etc, — on the screen at the same time. (You can only hear the
sound associated with one of the pictures however. You choose which
picture’s sound is selected.) You can change the relative size of each
of the pictures.
Displaying Twin
Pictures
To display twin pictures
1 Press the button on your remote control. (A second picture-
window appears.)
2 To cancel twin pictures
❑ Press the button
or
❑ Press the button.
,
,
Using the Features
32
Activating the
With Twin View, the picture highlighted with a blue frame is active.
In the active picture, you can:
❑ Change channels
❑ Adjust the volume.
❑ Switch the input sources (to go from UHF/VHF to CATV cable,
for example, press TV/VIDEO on the remote control).
❑ Change the picture size by pressing V/v on the joystick.
Factors affecting Twin View include:
❑
Equipment connected to the AUX and HD/DVD IN (numbers 5
and 6) inputs cannot be displayed in the right Twin View picture.
✍ Normally the TV memorizes the last-used sizes; when Twin VIew is turned off,
then back on, the last-used sizes are displayed. If you are using the enhanced
16:9 picture, however, the aspect ratio changes to 4:3 in Twin View, and the
picture is reformatted to that ratio.
To activate the right picture
❑
Move the joystick to the
right (without pressing
down on it).
To activate the left picture
❑
Move the joystick to the left
(without pressing down on it).
,
,
Using the Features
33
Changing the
Picture Size
The zoom feature lets you vary the relative size of the left and right
pictures.
When you adjust the twin screen sizes, the TV memorizes the change.
The next time you use the Twin View function, the memorized sizes
appear.
1 Activate the picture whose
size you want to change.
2 Press V on the joystick to
enlarge the picture.
3 Press v on the joystick to
make the picture smaller.
Using the Features
34
Using the Freeze Function
The FREEZE button allows you to temporarily capture a program’s
picture. You can use this feature to write down information such as
phone numbers, recipes, etc.
The FREEZE feature works only in normal view; if you are in Twin
View, it will not work.
To use the FREEZE function
1 When the program information you want to capture is displayed,
press the FREEZE button, on the remote control.
2 The TV switches to Twin View mode and displays the “frozen”
picture on the right, while the current program continues on the
left.
3 To cancel and return to normal viewing, press the FREEZE button.
Current program
in progress
Frozen picture
Call 555-1234
FREEZE
35
Using the Menus
Overview
Opening and choosing a menu:
1 Press the MENU button to display the Menu screen.
2 Move the joystick to the desired menu icon and press to select
it.
3 Use the joystick to scroll through the features.
4 See the specific menu page for instructions on moving through
the menu.
The Menu gives you access to the following features:
Menu Icon Description Page
VIDEO allows you to make adjustments to your
picture settings. It also allows you to customize the
Picture Mode based on the type of program you are
viewing.
36
AUDIO offers enhanced audio options such as
listening to second audio programming (SAP), or
customizing the effect of the sound on your TV.
38
CHANNEL allows you to set up a Favorite Channel
list, run the Auto Program function, and more.
40
PARENT lets you control the viewing of programs
based on their ratings.
42
TIMER lets you set the clock on your TV and allows
you to program your TV for scheduled viewing
using the Timers.
46
SETUP provides several options for setting up your
channels, labeling your video inputs, and selecting
the language of the on-screen menus.
47
To end a menu session:
Press MENU button again.
To end one menu session
and move to another:
Move the joystick upward
to return to the menu
icons.
Move the joystick to
choose the next menu icon
and press to select it.
Using the Menus
36
Using the Video Menu
To select the Video Menu
1 Press MENU.
2 Move the joystick to the Video
icon and press .
3 Use the joystick to scroll through
the features.
4 Press to select a feature. That
feature’s adjustment appears.
5 Use the joystick to make the
desired adjustments.
6 Press to select the desired adjustment.
7 Press MENU to exit the menu screen.
To restore the factory default settings for Picture, Brightness, Color, Hue, and
Sharpness, Color Temp and VM.
❑ Press RESET on the remote control when in the Video menu.
Selecting Video
Options
The Video Menu includes the following options.
To change from one Video
Mode to another, use the
PICTURE MODE button on the
remote control.
z
Option Description
Mode
Customized
viewing
Vivid Select for enhanced picture contrast and
sharpness.
Standard Recommended for normal viewing
conditions.
Movie Select for soft, film like, picture.
Pro Select for professional monitor like
appearance.
✍ You can alter the Video Menu settings (Picture, Brightness, Color,
etc.) for each Mode.
Picture Adjust to increase picture contrast and deepen the color or
decrease picture contrast and soften the color.
Brightness Adjust to brighten or darken the picture.
Color Adjust to increase or decrease color intensity.
Hue Adjust to increase or decrease the green tones.
Sharpness Adjust to sharpen or soften the picture.
Using the Menus
37
Color Temp
White
intensity
adjustment
Choose from three color temperatures:
Cool Select to give the white colors a blue tint.
Neutral Select to give the white colors a neutral tint.
Warm Select to give the white colors a red tint
(NTSC-Standard).
VM
Velo city
Modulation
Sharpens picture definition to give every object a sharp, clean
edge. Select from High, Medium, Low, Off.
DRC mode
Digital
Reality
Creation
mode
Creates a high-resolution picture with 4x density, for high
quality sources (i.e., DVD player, Satellite receiver).
Select from Interlaced, Progressive, or CineMotion.
Interlaced Recommended for moving pictures.
Progressive Recommended for still images and text.
CineMotion Provides an optimized display by
automatically detecting film content and
applying a reverse 3/2 pulldown process.
Moving pictures will appear clearer and
more natural-looking.
Option Description
Using the Menus
38
Using the Audio Menu
To select the Audio Menu
1 Press MENU.
2 Move the joystick to the Audio
icon and press .
3 Use the joystick to scroll through
the options.
4 Press to select an option. That
option’s settings appear.
5 Use the joystick to make the
desired adjustments.
6 Press to select the desired adjustment.
7 Press MENU to exit the menu screen.
To restore the factory default settings for Treble, Bass, and Balance
❑ Press RESET on the remote control when in the Audio menu.
Selecting Audio
Options
The Audio Menu includes the following options:
Option Description
Treble Adjust to increase or decrease higher-pitched sounds.
Bass Adjust to increase or decrease lower-pitched sounds.
Balance Adjust to emphasize left or right speaker balance.
Steady Sound
ON Select to stabilize the volume.
OFF Select to turn off Steady Sound.
Effect TruSurround Select for surround sound (for stereo
programs only).
Simulated Adds a surround-like effect to mono
programs.
OFF Normal stereo or mono reception.
Using the Menus
39
MTS
Enjoy stereo,
bilingual and
mono programs
Stereo Select for stereo reception when viewing a
program broadcast in stereo.
Auto-SAP Select to automatically switch the TV to
second audio programs when a signal is
received. (If no SAP signal is present, the TV
remains in Stereo mode.)
Mono Select for mono reception. (Use to reduce
noise during weak stereo broadcasts.)
Speaker ON Select to turn on the TV speakers.
OFF Select to turn off the TV speakers and listen to
the TV's sound only through your external
audio system speakers.
Audio Out
Easy control of
volume
adjustments
This option can be set only when the Speaker option is set
to OFF.
Variable Sound output varies according to the TV
settings. Useful when you want to use the
TV’s remote control to adjust the output
through a separate audio system.
Fixed Sound output is held at a fixed level. Use
your audio receiver’s remote control to adjust
the volume.
Option Description
Using the Menus
40
Using the Channel Menu
To select the Channel Menu
1 Press MENU.
2 Move the joystick to the Channel
icon and press .
3 Use the joystick to scroll through
the features.
4 Press to select a feature. That
feature’s options appear.
5 Use the joystick to scroll through
the options.
6 Press to select the desired option.
7 Press MENU to exit the menu screen.
Selecting Channel
Options
The Channel Menu includes the following options:
Option Description
Favorite Channel
1 Press to select a favorite channel number.
2 Use the joystick to scroll through the channels until
you find the channel you want to add to your
favorites.
3 Press to select it.
Cable ON Select if you are receiving cable channels
with a CATV cable.
OFF Select if you are using an antenna.
✍ You should run Auto Program after changing the cable setting.
Channel Fix
Useful when you
have a cable box or
satellite receiver
connected
2-6 “Fix” your TV’s channel setting to 3 or 4
and use the cable box, VCR or satellite
receiver to change channels. Select one of
these settings if you have connected the
device to the VHF/UHF jack.
AUX 2-6 Same as 2-6, except you select one of these
settings if you have connected the device to
the AUX jack (see page 8).
VIDEO 1 Use this setting if you have connected the
device to the Audio and Video IN jacks.
Auto Program Automatically programs the TV for all receivable channels
from both VHF/UHF and AUX inputs.
Using the Menus
41
Channel
Skip/Add
Removes and adds viewable channels.
1 Use the joystick to scroll through the channels until
you find the channel you want to skip/add.
2 Press to select it.
3 Press the joystick (V/v) to toggle between “Add” and
“Skip.”
4 Press to select.
Channel Label Label up to 20 channels with their station call letters.
Option Description
Using the Menus
42
Using the Parent Menu
The Parent menu allows you to set up the TV to block programs according to
their content and rating levels. These ratings are assigned by a federal rating
board. Not all programs are rated. Using the Parental Lock blocks programs
with a specific rating, but it does not block an entire channel.
To select the Parent Menu
1 Press MENU.
2 Move the joystick to the Parent
icon and press .
3 Use the 0-9 buttons on the remote
control to enter your four-digit
password.
4 Confirm your password by
entering it again. (The Parent
menu options appear.)
5 Use the joystick to scroll through the settings.
6 Press to select the desired option.
7 Press MENU to exit the menu screen.
✍ You need your password for any future access into the Parent menu. If you
lose your password, see “Lost password” on page 56.
Using the Menus
43
Using the Parent
Menu
The Parent menu includes the following options.
If you are not familiar with
the Parental Guideline rating
system, you should select Child,
Youth, or Young Adult to help
simplify the rating selection. To
set more restrictive ratings,
select Custom.
z
Option Description
Parental Lock
Turn ratings on/
off and select a
rating system
OFF Parental lock is off. No programs are
blocked from viewing.
Child Maximum ratings permitted are:
❏ US: TV-Y, TV-G, G
❏ Canada: TV-Y, C, G
Youth Maximum ratings permitted are:
❏ US: TV-PG, PG
❏ Canada: TV-PG, PG, 8 ans+
Young Adult Maximum ratings permitted are:
❏ US: TV-14, PG-13
❏ Canada: TV-14, 14+, 13 ans+
Custom Select to set ratings manually.
❏ US: See page 44 for details.
❏ Canada: See page 45 for details.
Change Password For changing your password.
For descriptions of Child,
Youth, and Young Adult
ratings, see page 44.
z
Using the Menus
44
US Models:
Selecting Custom
Rating Options
For US models, the Custom Rating Menu includes the following options.
(For Canadian models, see page 45.)
Option Description
Movie Rating G All children and General Audience.
PG Parental Guidance suggested.
PG-13 Parental Guidance for children under 13.
R Restricted viewing, parental guidance is
suggested for children under 17.
NC-17
and X
No one 17 and under allowed.
TV Rating
Block programs
by their rating,
content or both
Age-Based Options
TV-Y All children.
TV-Y7 Directed to older children.
TV-G General Audience.
TV-PG Parental Guidance suggested.
TV-14 Parents Strongly cautioned.
TV-MA Mature Audience only.
Content-Based Options
FV Fantasy Violence.
D Suggestive Dialogue.
L Strong Language.
S Sexual situations.
V Violence.
Unrated
Block programs
or movies that
are broadcast
without a rating
Block Blocks all programs and movies that are
broadcast without a rating.
Allow Allows programs and movies that are
broadcast without a rating.
The content ratings will
increase depending on the level
of the age-based rating. For
example, a program with a TV-
PG V (Violence) rating may
contain moderate violence,
while a TV-14 V (Violence)
rating may contain more intense
violence.
To ensure maximum
blocking capability, the age-
based ratings should be
blocked.
If you block unrated TV
programs, be aware that the
following types of programs
may be blocked: emergency
broadcasts, political programs,
sports, news, public service
announcements, religious
programs and weather.
z
z
z
Using the Menus
45
Canadian Models:
Selecting Custom
Rating Options
For Canadian models, the Custom Rating Menu includes the following
options. (For US models, see page 44.)
Viewing Blocked
Programs
You can view a blocked program by entering the password. Press the ENTER
button when tuned to a blocked program, and then enter the password. This
temporarily switches off the Parental Lock. To reactivate the Parental Lock
settings, turn off the TV. When the TV is turned on again, your Parental
Controls settings are reactivated.
Option Description
English Rating C All children.
C8+ Children 8 years and older.
G General programming.
PG Parental Guidance.
14+ Viewers 14 and older.
18+ Adult programming.
French Rating G General programming.
8 ans+ Not recommended for young children.
13 ans+ Not recommended for ages under 13.
16 ans+ Not recommended for ages under 16.
18 ans+ Programming restricted to adults.
USA Rating See “US Models” on page 44 for details.
Using the Menus
46
Using the Timer Menu
To select the Timer menu
1 Press MENU.
2 Use the joystick to move to the
Timer icon and press .
To set the Current Time
1 Use the joystick to select
“Current Time”, then press
.
2 If it is currently Daylight
Savings Time, be sure to set that mode to “ON”. (Daylight Savings
Time starts in the Spring and ends in the Fall.)
3 Use the joystick to enter the correct time, then press .
4 Press MENU to exit the menu screen.
To set the Timer
Before setting the timer, be sure to set your TV’s clock to the current time
(and, if appropriate, Daylight Savings Mode). To check the TV’s time
setting, press the DISPLAY button on the remote control.
1 Move the joystick to “Timer 1” or “Timer 2”, then press .
2 Use the joystick to enter your date, time and channel preferences,
then press to select each one.
3 Press MENU to exit the menu screen.
To reset the Clock or Timers
❑ Press RESET on the remote control after selecting that option in the Timer
menu. This resets to the factory defaults.
Selecting Timer
Options
The Timer Menu includes the following options:
Option Description
Timer 1
Timer 2
Program Select to set the Timer by day, time,
duration, and channel.
OFF Select to turn off the Timer. (Your previous
settings will be saved.)
Current Time Set the current time.
Daylight Savings ON Select in the spring to turn on this mode
during Daylight Saving Time.
OFF Select in the fall to turn of this mode at the
end of Daylight Saving Time.
Using the Menus
47
Using the Setup Menu
To select the Setup Menu
1 Press MENU.
2 Use the joystick to move to the
Setup icon and press .
3 Use the joystick to scroll through
the features.
4 Press to select a feature. (That
feature’s options appear.)
5 Use the joystick to scroll through
the options.
6 Press to select the desired option.
7 Press MENU to exit the menu screen.
Selecting
Setup Options
The Setup Menu includes the following options:
Option Description
Caption Vision Allows you to select from three closed-caption modes (for
programs that are broadcast with closed caption).
CC1, CC2,
CC3, CC4
Displays a printed version of the
dialog or sound effects of a
program. (Should be set to CC1 for
most programs.)
TEXT1, TEXT2,
TEXT3, TEXT4
Displays network/station
information presented using either
half or the whole screen (if
available). For closed captioning,
set to CC1.
XDS
(Extended Data
Service)
Displays a network name,
program name, program length,
and time of the show (if the
broadcaster offers this service).
OFF Turns off Caption Vision.
(Continued on the next page)
Using the Menus
48
Video Label Allows you to label the audio/video equipment you
connected to the TV, so you can identify it when using the
TV/VIDEO button. When in the Setup menu’s Video Label
feature, use the joystick to highlight an input to label, then
press to select it. Use the joystick to scroll through the
labels. Press to select the equipment you connected to
each of the input jacks on the back of your TV. Select
“Skip” if you do not have any equipment connected to a
particular set of input jacks.
VIDEO 1/2/3/4 VHS, 8mm, Beta, LD, Game, SAT,
DVD, Web, Receiver, DTV, Skip
VIDEO 5/6 HD, DVD, DTV, Skip
✍ If you select “Skip”, your TV skips this connection when
you press the TV/VIDEO button.
Tilt Correction Allows you to correct any tilt of the picture.
Language Select to display all on-screen menus in your language of
choice.
16:9 Enhanced Provides enhanced picture resolution for widescreen
sources, such as selected DVD titles (only available when
the TV is in VIDEO mode). Press TV/VIDEO and select from
one of the following options:
AUTO To activate automatically when a
16:9 signal is received.
ON To activate manually.
Demo Runs a demonstration of on-screen menus.
✍ AUTO/ON will appear when TV is in video mode 1-6.
ON/OFF will appear when TV is in VIDEO mode 5-6 and the 480p signal occurs.
Option Description
To use this feature with
widescreen DVDs, set your
DVD player to 16:9 aspect
ratio.
z
(Continued from the previous page)
Other Information
50
Programming the Remote Control
The remote control is preset to operate Sony brand video equipment.
If you have video equipment other than Sony brand that you want to
control with the TV’s remote control, use the following procedures to
program the remote control.
1 Check the list of the “Manufacturer’s Codes” listed on page 52,
and find the three-digit code number for the manufacturer’s code
for your equipment. (If more than one code number is listed, start
with the number listed first.)
2 Open the cover of the remote control and move the slide switch
to the desired equipment type.
3 Press CODE SET and close the cover of the remote control.
4 Enter the three-digit manufacturer’s code number.
5 Press ENTER.
6 To check if the code number works, aim the TV’s remote control
at the equipment and press the green POWER button that
corresponds with that equipment. If it responds, you are done. If
not, try using another code listed for that manufacturer.
Sony
Equipment
Switch Position
on Remote Control
Programmable
Code Number
Beta, ED Beta VCRs AV1 303
8 mm VCR AV2 302
VHS VCR AV3 301
DVD Player DVD 751
✍ The equipment must have infrared (IR) remote capability in order to be used
with the remote control.
✍ You must do step 4 within 10 seconds of step 3, or you must redo steps 2
and 3.
3
2
4
5
D
R
C
/
C
I
N
E
M
O
T
I
O
N
HOME THEATER CONTROL
D
R
C
/
C
I
N
E
M
O
T
I
O
N
Other Information
51
Tips
❑
If more than one code number is listed, try entering them one by
one until you come to the correct code for your equipment.
❑ If you enter a new code number, the code number you previously
entered at that setting is erased.
❑ In some cases, you may not be able to operate your equipment
with the Sony remote control. In such cases, use the equipment’s
own remote control unit.
❑ Whenever you remove the batteries to replace them, the code
numbers may revert to the factory setting and must be reset.
Other Information
52
Manufacturer’s Codes
VCRs
Laserdisc Players
DVD Players
Cable Boxes
Satellite Receivers
Manufacturer Code
Sony 301, 302, 303
Admiral
(M. Ward)
327
Aiwa 338, 344
Audio
Dynamic
314, 337
Broksonic 319, 317
Canon 309, 308
Citizen 332
Craig 302, 332
Criterion 315
Curtis Mathes 304, 338, 309
Daewoo 341, 312, 309
DBX 314, 336, 337
Dimensia 304
Emerson 319, 320, 316,
317, 318, 341
Fisher 330, 335
Funai 338
General
Electric
329, 304, 309
Go Video 322, 339, 340
Goldstar 332
Hitachi 306, 304,
305,338
Instant Replay 309, 308
JC Penney 309, 305, 304,
330, 314, 336,
337
JVC 314, 336, 337,
345, 346, 347
Kenwood 314, 336, 332,
337
LXI (Sears) 332, 305, 330,
335, 338
Magnavox 308, 309, 310
Marantz 314, 336, 337
Marta 332
Memorex 309, 335
Minolta 305, 304
Mitsubishi/
MGA
323, 324, 325,
326
Multitech 325, 338, 321
NEC 314, 336, 337
Olympic 309, 308
Optimus 327
Orion 317
Panasonic 308, 309, 306,
307
Pentax 305, 304
Philco 308, 309
Philips 308, 309, 310
Pioneer 308
Quasar 308, 309, 306
RCA/
PROSCAN
304, 305, 308,
309, 311, 312,
313, 310, 329
Realistic 309, 330, 328,
335, 324, 338
Sansui 314
Samsung 322, 313, 321
Sanyo 330, 335
Scott 312, 313, 321,
335, 323, 324,
325, 326
Sharp 327, 328
Shintom 315
Signature 2000
(M. Ward)
338, 327
SV2000 338
Sylvania 308, 309, 338,
310
Symphonic 338
Tashiro 332
Tatung 314, 336, 337
Teac 314. 336, 338,
337
Technics 309, 308
Toshiba 312, 311
Wards 327, 328, 335,
331, 332
Yamaha 314, 330, 336,
337
Zenith 331
Manufacturer Code
Sony 701
Panasonic 704, 710
Pioneer 702
Manufacturer Code
Manufacturer Code
Sony 751
GE 755
Hitachi 758
JVC 756
Magnavox 757
Mitsubishi 761
Oritron 759
Panasonic 753
Philips 757
Pioneer 752
RCA/
PROSCAN
755
Samsung 758
Toshiba 754
Zenith 760
Manufacturer Code
Sony 230
Hamlin/Regal 222, 223, 224,
225, 226
Jerrold/G. I. 201, 202, 203,
204, 205, 206,
207, 208, 218
Oak 227, 228, 229
Panasonic 219, 220, 221
Pioneer 214, 215
Scientific
Atlanta
209, 210, 211
Tocom 216, 217
Zenith 212, 213
Manufacturer Code
Sony 801
Dish Network 810
Echostar 810
General
Electric
802
Hitachi 805
Hughes 804
Mitsubishi 809
Panasonic 803
RCA/
PROSCAN
802, 808
Toshiba 806, 807
Other Information
53
Operating Other Equipment with Your TV Remote Control
Operating a VCR Open the cover of the remote control and move the slide switch to the
AV input you coded for the VCR.
Operating a DVD
Player
Open the cover of the remote control and move the slide switch to the
AV input you coded for the DVD player.
To Do This ... Press
Turn on/off green POWER button (under the cover)
Change channels CH +/-
Record N and REC simultaneously.
Play N
Stop x
Fast forward M
Rewind the tape m
Pause X
Search the picture
forward or backward
M or m during playback
(release to resume normal playback)
To Do This ... Press
Turn on/off green POWER button (under the cover)
Play N
Stop x
Pause X
Step through different
tracks of an audio disc
M to step forward or m to step backward
Step through different
chapters of a video disc
CH+ to step forward or CH- to step backward
Display the DVD menu DVD MENU
Display the menu
(Setup)
MENU
Other Information
54
Operating a Cable
Box
Operating a Satellite
Receiver
Operating an MDP
(Laserdisc Player)
Open the cover of the remote control and move the slide switch to the
AV input you coded for the MDP.
To Do This ... Press
Turn on/off SAT/CABLE (green POWER button)
Select cable box SAT/CABLE (FUNCTION button)
Select a channel 0-9 buttons, ENTER
Change channels CH +/-
Back to previous channel JUMP
To Do This ... Press
Turn on/off SAT/CABLE (green POWER button)
Select satellite receiver SAT/CABLE (FUNCTION button)
Select a channel 0-9 buttons, ENTER
Change channels CH +/-
Back to previous channel JUMP
Display channel number DISPLAY
Display SAT guide GUIDE
Display SAT menu MENU
Move highlight (cursor) Joystick
Select item button
To Do This ... Press
Turn on/off green POWER button (under the cover)
Play N
Stop x
Pause X
Search the picture
forward or backward
M or m during playback
(release to resume normal playback)
Search a chapter
forward or backward
CH +/-
Other Information
55
Troubleshooting
Problem Possible Remedies
No picture
(screen not lit),
no sound
❏ If your TV does not turn on, and a red light keeps flashing, your TV may
need service. Call your local Sony Service Center.
❏ Make sure the power cord is plugged in.
❏ Push the power button on the front of the TV.
❏ Check to see if the TV/VIDEO setting is correct: when watching TV, set to
TV; when watching connected equipment, set to VIDEO 1, 2, 3, 4, 5 or 6, as
appropriate.
❏ Try another channel; it could be station trouble.
Remote control
does not operate
❏ Batteries could be weak. Check the batteries and replace as necessary.
❏ Press TV (FUNCTION) when operating your TV.
❏ Make sure the TV’s power cord is connected securely to the wall outlet.
❏ Locate the TV at least 3-4 feet away from fluorescent lights.
❏ Check the orientation of the batteries.
Dark, poor or no
picture (screen lit),
good sound
❏ Adjust the Picture setting in the Video menu (see page 36).
❏ Adjust the Brightness setting in the Video menu (see page 36).
❏ Check antenna/cable connections.
Good picture,
no sound
❏ Press MUTING so that “MUTING” disappears from the screen (see page 4).
❏ Make sure Speaker is set to ON in the Audio menu (see page 38).
Cannot receive upper
channels (UHF) when
using an antenna
❏ Change Cable to OFF (see page 40).
❏ Use Auto Program in the Channel menu to add receivable channels that are
not presently in memory (see page 40).
No color ❏ Adjust the Color settings in the Video menu (see page 36).
Only snow and noise
appear on the screen
❏ Check the antenna/cable connections.
❏ Try another channel (it could be station trouble).
❏ Press ANT to change the input mode (see page 40).
Dotted lines
or stripes
❏ Adjust the antenna.
❏ Move the TV away from noise sources such as cars, neon signs, or hair-
dryers.
TV is fixed to one channel ❏ Use Auto Program in the Channel menu to add receivable channels that are
not presently in the TV’s memory (see page 40).
❏ Check your Channel Fix settings (see page 40).
Double images or ghosts ❏ Use a highly directional outdoor antenna or a cable (if the problem is
caused by reflections from nearby mountains or tall buildings).
Cannot operate menu ❏ If the item you want to choose appears in gray, you cannot select it.
Cannot receive any
channels when using
cable TV
❏ Use Auto Program in the Channel menu to add receivable channels that are
not presently in the TV’s memory (see page 40).
❏ Check your cable settings.
❏ Make sure Cable is set to ON in the Channel menu (see page 40).
Other Information
56
If, after reading these operating instructions, you have additional questions related to the use of your Sony
television, please call our Customer Information Services Center at 1-800-222-SONY (7669) (U.S. residents
only) or (416) 499-SONY (7669) (Canadian residents only).
Cannot gain enough volume
when using a cable box
❏ Increase the volume of the cable box using the cable box’s remote control.
Then press TV (FUNCTION) and adjust the TV’s volume.
Cannot receive channels ❏ Use Auto Program in the Channel menu to add receivable TV channels that
are not presently in TV memory (see page 40).
Unable to select a channel ❏ Use Auto Program in the Channel menu to add receivable TV channels that
are not presently in TV memory (see page 40).
Lost password ❏ In the password screen (see page 42), enter the following master password:
4357. The master password clears your previous password; it cannot be
used to temporarily unblock channels.
Cannot change channels
with the remote control
❏ Be sure you have not inadvertently switched your TV from channel 3 or 4
setting if you are using another device to change channels.
❏ If you are using another device to control channels, be sure the “function”
button for that device has been pressed.
Cannot cycle through the
other video equipment
connected to the TV
❏ Be sure the Video Label feature has not been set to Skip (see page 48).
There is a black box on the
screen
❏ You have selected a text option in the Setup menu and no text is available.
(See page 47 to reset Setup selections.) To turn this feature off, select OFF in
the Caption Vision option. If you were trying to get closed captioning,
select CC1 instead of Text 1-4.
There is no twin picture
or it is just static
❏ Be sure your twin picture is set to a video source/channel that has a
program airing.
❏ You may be tuned to a video input with nothing connected to it. Try
cycling through your video inputs using the TV/VIDEO button.
❏ Twin View is not set to receive a signal from the AUX input. If you have
connected a VCR or satellite receiver to the AUX input on the TV, it will not
show in the right picture.
I get the same program
in both Twin View pictures
❏ Both may be set to the same channel. Try changing channels in either the
left or right picture.
❏ You may be running all your channels through a cable box. The cable box
will only unscramble one signal at a time. If possible, run a direct cable to
your TV’s VHF/UHF input. (This will only work if your cable system
provides an unscrambled signal.)
I cannot get anything
but TV channels in my left or
right Twin View picture
❏ Be sure the video label has not been set to skip your video inputs. See the
Setup menu on pages 47 and 48.
Problem Possible Remedies
Other Information
57
Specifications
All Models (General)
Picture Tube FD Trinitron
®
tube
Antenna 75 ohm external terminal for VHF/UHF
Television System NTSC, American TV Standard
Channel Coverage
VHF 2-13
UHF 14-69
CATV 1-125
Power Requirements 120V, 60 Hz
Number of Inputs/Outputs
Video (IN) 4 1 Vp-p, 75 ohms unbalanced, sync negative
S Video (IN) 3 Y: 1 Vp-p, 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
Audio (IN) 6 500 mVrms (100% modulation)
Impedance: 47 kilohm
Audio (OUT) 1 More than 408 mVrms at the maximum
volume setting (Variable)
More than 408 mVrms (Fixed)
Impedance (output): 2 kilohms
Monitor Out 1 1 Vp-p, 75 ohms unbalanced, sync negative
CONTROL S (IN/OUT) 1
Component Video Input 2 (Y, P
B
, P
R
) Y: 1.0 Vp-p, 75 ohms unbalanced, sync
negative; P
B
: 0.7 Vp-p, 75 ohms
P
R
: 0.7 Vp-p, 75 ohms
Other Information
58
Design and specifications are subject to change without notice.
KV-32XBR450
Supplied Accessories
Remote Control RM-Y184
AA (R6) Batteries 2 supplied for remote control
Optional Accessories
AV Cable VMC-810/820/830 HG
Audio Cable RKC-515HG
S-LINK Cable RK-G69HG
Component Video Cable VMC-10/30 HG
TV Stand SU-32XBR45 (also SU-32HS2 in Canada)
Visible Screen Size 32 in (812.8 mm) picture measured diagonally
Actual CRT Size 34 in (863.4 mm) picture measured diagonally
Speaker Output 15W x 2
Dimensions (W x H x D) 898.0 x 678.0 x 579.5 mm (35 3/8 x 26 3/4 x 27 7/8 in)
Mass 84 kg (185 lbs)
Power Consumption
In Use 245 W
In Standby 2 W
KV-36XBR450
Supplied Accessories
Remote Control RM-Y184
AA (R6) Batteries 2 supplied for remote control
Optional Accessories
AV Cable VMC-810/820/830 HG
Audio Cable RKC-515HG
Component Video Cable VMC-10/30 HG
TV Stand SU-36XBR45 (also SU-36HS2 in Canada)
Visible Screen Size 36 in (914 mm) picture measured diagonally
Actual CRT Size 38 in (965.2 mm) picture measured diagonally
Speaker Output 15W x 2
Dimensions (W x H x D) 994 x 754.5 x 622 mm (39 1/4 x 29 3/4 x 24 1/2 in)
Mass 108 kg (238 lbs)
Power Consumption
In Use 245 W
In Standby 2 W
59
Index
16:9 (widescreen) 2, 48
A
Adding channels to the channel list 40
Adjusting the picture definition 36
Adjusting the audio
Steady sound 38
Activating Twin View 31
ANT button 4
antenna, connecting 10
Aspect ratio, 16:9
in Twin View 32
Audio menu 35, 38
audio receiver, connecting 22
Auto-SAP 39
Auto Program (channel setup) 28, 40
Auto setup 28, 40
B
balance, adjusting 38
bass, adjusting 38
batteries
inserting in remote 3
bilingual audio 39
blocking programs. See ratings.
brightness, adjusting
36
C
cable
box, connecting with VCR 15
connecting 10-13
setting ON/OFF
40
with VCR, connecting
14
cable box, using with TV remote control 54
camcorder, connecting 26
Caption Vision 47
CATV. see cable
Channel list, adding channels
30, 40
Channel menu 35, 40
Channel Setup menu 40
Channel Skip/Add 41
channels
creating labels 41
setting up
28
closed caption modes 47
Code Set button 6
color temperature, adjusting 37
color, adjusting 36
Connecting:
Audio receiver 22
Cable or antenna 10-13
Cable box 11-13, 15-16
Camcorder
26
Digital TV receiver 25
DVD player 23, 24
Satellite receiver 19
-21
VCR
14-18
with Satellite receiver 20
Contents of package 3
CONTROL S 27
Controls and connectors 8-9
Converter 12
D
Demo, menus 48
Digital Reality Creation 2, 37
Display button 4
Display, turning off 4
DRC, see Digital Reality Creation
DVD player
using with TV remote control 53
with A/V connectors, connecting
24
with component video connectors,
connecting
23
E
Enhanced picture resolution, 16:9 48
enlarging picture, a Twin View picture 33
Extended Data Service 47
Index
60
F
Favorite Channel
setting up 40
using
30
Favorites button 5
features 2
Freeze, using 34
Front Panel controls 8
G
Guide button 4
H
Hookups 10-26
hue, adjusting 36
I
inputs, labeling 48
Installation 10-26
J
Jump button 4
L
label
channels 41
video inputs
48
Languages, setting for closed captioning 48
Locking programs 42-45
M
Manufacturer’s codes 52
MDP, using with TV remote control 54
Menu button 5
menus
Audio 35, 38
Channel
35, 40
Channel Setup
40
Parent
35, 42
Parental Control
42
Setup
35, 47
Timer
35, 46
Video
35, 36
Muting 4
P
Parent menu 35, 42
parental control, described 2
password
changing 43, 56
picture contrast, adjusting 36
picture definition, adjusting 37
Picture Mode 4, 36
Picture size, adjusting in Twin View 33
power cord, removing from holder 7
presetting channels 40
problems, troubleshooting 55-56
R
ratings
setting
42-45
viewing blocked programs 45
Rear panel controls and connections 8-9
remote control
inserting batteries 3
programming
50-52
Remote control, operating other equipment
with
Cable box 54
DVD
53
MDP 54
Satellite receiver 54
VCR 53
Remote control, buttons 4-6
Reset button 4
resetting
Audio options 38
factory settings
28
Timer options
46
Video options
36
S
SAT/CABLE Function button 4
SAT/CABLE Power button 4
satellite receiver
connecting 19, 20
using with TV remote control 54
Setting favorite channel 40
setting up channels 28
Setup menu 35, 47
sharpness, adjusting 36
SLEEP button 4
Index
61
sound effect, adjusting 38
speakers
turning on/off 39
using external speakers
22, 39
specifications 57-58
Steady Sound, adjusting 38
Steady Sound, described 2
Surround Sound 38
T
tape-to-tape editing 18
Time
set current 46
set daylight saving
46
Timer setting 46
tilt, correcting 48
Timer menu 35, 46
treble, adjusting 38
troubleshooting 55-56
TV Function button 4
TV Power button 4
TV/VIDEO button 5
Twin View 31
Twin View
activating a picture 32
changing the picture size
33
displaying a picture
31
V
VCR
connecting two, for tape editing 18
using with TV remote control
53
with cable box, connecting
15
with cable, connecting
14
with satellite receiver, connecting
20
VCR/DVD Power button 6
Velocity Modulation 2, 37
video inputs, labeling 48
Video menu 35, 36
Video Modes, selecting 36
W
Wega, described 2
widescreen 48
widescreen, described 2
Z
zoom feature, with Twin View 33
Printed in U.S.A.
