MODEL:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
KLV-21SG2
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
21" Flat Panel
LCD TV
24 7/8 " x 18 " x 4 " *
Approx 23 lbs
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 930 7891 • www.sony.com/dn
120V AC
60Hz
TOP VIEW
SIDE VIEW
FRONT VIEW
15 5/8"
TBD
2 3/8"
24 7/8"
11 3/4"
4 "
9 1/2"
18"
BACK VIEW
IR SENSOR
FRONT
AV INPUT
MEMORY
STICK
4"
4"
16 1/8"
12"
2"
3 1/2"
5 3/8"
10 3/8"
3 7/8"
* Without stand
RM-Y1106 REMOTE COMMANDER
VENTILATION
HOLES FOR
WALL MOUNTING
VENTILATION
VHF/UHF
S-VIDEO
VIDEO
AUDIO
L
R
COMPONENT
VIDEO
IN
AUDIO OUT
FIX/VAR
L
R
AUDIO
IN
L
R
S
P
E
A
K
E
R
S
S
P
E
A
K
E
R
S
OPTIONAL WALL MOUNT SU-W210
AC IN
