User care Haier HFC9204ACW Freezer

Table of contents

  • FREEZER SAFETY
  • PARTS AND FEATURES
  • INSTALLATION REQUIREMENTS
  • Tools and Parts
  • Location Requirements
  • Electrical Requirements
  • FREEZER INSTALLATION
  • Step 1 - Unpack Freezer
  • Step 2 - Install Casters
  • Step 3 - Install Handle
  • Step 3 - Complete the Installation
  • FREEZER USE
  • Control
  • Alarm Indicator Light
  • Freezer Lock and Key
  • Freezer Baskets
  • FREEZER CARE
  • Cleaning
  • Defrosting and Draining
  • Light
  • Vacation and Moving
  • Reinstalling/Using Freezer Again
  • TROUBLESHOOTING
  • LIMITED WARRANTY

CONTROL

The control, located on the front of the freezer cabinet, is an adjustable dial with Temperature settings ranging from 1 (Least Cold) to 7 (Coldest), and Off.

The Power On Light (green) indicates that the freezer is properly connected to electrical power. The light glows even when the temperature is turned to OFF.

  1. Turn the temperature control dial to 4 (Recommended Setting).
  2. Allow the freezer to cool for several hours before adding food.

ADJUSTING THE TEMPERATURE

The recommended setting (4) is designed to maintain the temperature at or near 0°F (-17.8°C) under normal operating conditions.

To Adjust the Freezer Temperature:

  1. Adjust the control dial to one of the adjacent settings 3 (less cold) or 5 (colder).
    • NOTE: Except when starting the freezer, do not adjust the control more than one setting at a time.
  2. Wait 24 hours between adjustments for the freezer temperature to stabilize.

ALARM INDICATOR LIGHT

  • Your chest freezer is equipped with a RED indicator light. There is no audible alarm.
  • The Alarm indicator light will illuminate (red) when the freezer is first plugged in, and will remain lit until the freezer interior temperature reaches approximately 7°F (-13.9°C) below the set temperature.
  • Once the freezer interior temperature is lower than the set temperature, the Alarm indicator light will turn off.

FREEZER LOCK AND KEY

IMPORTANT:

  • Store the freezer key in a location away from the freezer and not easily accessible to children.
  • The freezer lock is spring loaded. The freezer key must be manually held in the lock to either lock or unlock the freezer.

To Lock/Unlock the Freezer:

Close the freezer lid, insert the key, push in and turn the key to lock. To unlock, insert the key, push in and turn the key in the opposite direction.
