www.lg.com
Owner's Manual
IPS LED MONITOR
(LED MONITOR)
29UM65
29UB65
Please read the safety information carefully before using the
product.
IPS LED Monitor (LED Monitor) Model List
ENGLISH
background
2
ENG
ENGLISH
Contents
CONTENTS
24 CUSTOMIZING SETTINGS
24 ActivatingtheMainMenu
25 Customizingsettings
25 - MenuSettings
25 - -Easycontrol
26 - -Function
27 - -PBP
28 - -Screen
29 - -Settings
30 - -Reset
31 - ReaderSettings
32 TROUBLESHOOTING
34 SPECIFICATIONS
35 Factorysupportmode
(PresetMode,DVI-D/HDMI/PC
DisplayPort)
35 HDMITiming(Video)
35 PowerIndicator
36 PROPER POSTURE
36 ProperPostureforUsingtheMonitor
3 LICENSE
4 ASSEMBLING AND
PREPARING
4 ProductComponents
5 ComponentandButtonDescription
7 MovingandLiftingtheMonitor
8 InstallingtheMonitor
8 - Assemblingthestandbase
9 - Usingthecableholder
10 - Detachingthestandbase
12 - Installingontoatable
13 - Adjustingthestandheight
14 - Adjustingtheangle
15 - Pivotfeature
16 - UsingtheKensingtonlock
16 - Installingthewallmountplate
17 - Installingtoawall
18 USING THE MONITOR
18 ConnectingtoaPC
18 - DVIconnection
19 - DisplayPortconnection
19 - HDMIconnection
20 ConnectingtoAVDevices
20 - HDMIconnection
21 ConnectingtoExternalDevices
21 - Headphoneportconnection
22 INSTALLING LG MONITOR
SOFTWARE
background
3
ENG
ENGLISH
LICENSE
LICENSE
Eachmodelhasdifferentlicenses.Visitwww.lg.comformoreinformationonthelicense.
ThetermsHDMIandHDMIHigh-DefinitionMultimediaInterface,andthe
HDMIlogoaretrademarksorregisteredtrademarksofHDMILicensingLLC
intheUnitedStatesandothercountries.
VESA,VESAlogo,DisplayPortComplianceLogoandDisplayPort
ComplianceLogofordual-modesourceareallregisteredtrademarksofthe
VideoElectronicsStandardsAssociation.
background
4
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Product Components
Pleasecheckwhetherallthecomponentsareincludedintheboxbeforeusingtheproduct.Ifthereare
missingcomponents,contacttheretailstorewhereyoupurchasedtheproduct.Notethattheproductand
componentsmaylookdifferentfromthoseshownhere.
Alwaysusegenuinecomponentstoensuresafetyandproductperformance.
Theproductwarrantywillnotcoverdamageorinjurycausedbytheuseofcounterfeitcomponents.
Notethatthecomponentsmaylookdifferentfromthoseshownhere.
Withoutpriornotice,allinformationandspecificationsinthismanualaresubjecttochangetoim-
provetheperformanceoftheproduct.
Topurchaseoptionalaccessories,visitanelectronicsstoreoronlineshoppingsiteorcontactthe
retailstorewhereyoupurchasedtheproduct.
TheDisplayPortcablemaynotbeavailableinsomeareas.
CAUTION
NOTE
Power CordUser Manual/Card AC/DC Adapter
29UM65
OPTIONAL ACCESSORIES
TheDisplayPortcablemaynot
beavailableinsomeareas.
Display Port Cable
Stand Base
Stand Base
Stand Body
Cable Holder
Screws
(Black)
(Sliver)
HDMI Cable
29UM65
29UB65
DVI-D Dual Cable
(Thiscableisnotincludedinall
countries.)
background
5
ENG
ENGLISH
ASSEMBLING AND PREPARING
Component and Button Description
29UM65
Power Indicator
On:powerison
Off:powerisoff
Ports
(PowerButton)
background
6
ENG
ENGLISH
ASSEMBLING AND PREPARING
29UB65
Power Indicator
On:powerison
Off:powerisoff
Ports
(PowerButton)
background
7
ENG
ENGLISH
ASSEMBLING AND PREPARING
Moving and Lifting the Monitor
Whenmovingorliftingthemonitor,followthese
instructionstopreventthemonitorfrombeing
scratchedordamagedandtoensuresafetrans-
portationregardlessofitsshapeorsize.
Asfaraspossible,avoidtouchingthemoni-
torscreen.Thismayresultindamagetothe
screenorsomeofthepixelsusedtocreate
images.
Itisadvisabletoplacethemonitorinthe
originalboxorpackingmaterialbeforeat-
temptingtomoveit.
Beforemovingorliftingthemonitor,discon-
nectthepowercordandallcables.
Holdthetopandbottomofthemonitorframe
firmly.Donotholdthepanelitself.
Whenholdingthemonitor,thescreenshould
faceawayfromyoutopreventitbeing
scratched.
Whenmovingthemonitor,avoidanystrong
shockorvibrationstotheproduct.
Whenmovingthemonitor,keepitupright,
neverturnthemonitoronitssideortiltit
sideways.
CAUTION
29UM65
29UB65
Ifyouusethemonitorpanelwithoutthe
standbase,itsjoystickbuttonmaycause
themonitortobecomeunstableandfall,
resultingindamagetothemonitororhuman
injury.Inaddition,thismaycausethejoystick
buttontomalfunction.
background
8
ENG
ENGLISH
ASSEMBLING AND PREPARING
Installing the Monitor
Assembling the stand base
Toprotectthescreenfromscratches,cover
thesurfacewithasoftcloth.
CAUTION
2
First,pleaseinsertStandBodytoStandBase,
Thentightentwoscrewsintothebackofthe
standbase.
1
Placethescreenfacedown.
29UM65
Applyingexcessiveforcewhentightening
thescrewsmaycausedamagetothemoni-
tor.Damagecausedinthiswaywillnotbe
coveredbytheproductwarranty.
CAUTION
3
Checkthedirectionofthestandbody
(front,back)andthenmountthestandbody
ontothestandhinge.
4
Tightentwoscrewsintothebackofthestand
body.
Itmayhurtyourfootoffthestand,sobe
careful.
CAUTION
Stand Body
Stand Body
Stand Base
(Silver)
(Black)
Or
120mm
100mm
(Black)
Stand Hinge
background
9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Toprotectthescreenfromscratches,cover
thesurfacewithasoftcloth.
CAUTION
1
Placethescreenfacedown.
29UB65
Using the cable holder
3
Fixbyturningthescrewtotherightwithacoin.
2
Insertthe
stand base
intothehookofthe
stand body
.
Itmayhurtyourfootoffthestand,sobe
careful.
CAUTION
29UM65
1
First,asshownintheillustration,pushthe
cableholderonthestandbody,Second,Fix
thecableholdertostandbody.
2
Putthecablesintothecableholder.
Stand Base
Stand Body
Stand Body
background
10
ENG
ENGLISH
ASSEMBLING AND PREPARING
Detaching the stand base
2
First,pressthethecableholderasshownin
theillustration,Second,Removethecable
holderfromthestandbody.
Toprotectthescreenfromscratches,cover
thesurfacewithasoftcloth.
CAUTION
Illustrationsinthisdocumentrepresenttypi-
calprocedures,sotheymaylookdifferent
fromtheactualproduct.
Donotcarrythemonitorupsidedownbyjust
holdingthestandbase.Thismaycausethe
monitortofalloffthestandandcouldresult
inpersonalinjury.
Whenliftingormovingthemonitor,donot
touchthemonitorscreen.Applyingforceor
pressuremaydamagethemonitorscreen.
Instead,holdthestandbodyortheplastic
frameoftheproduct.
CAUTION
1
Placethescreenfacedown.
29UM65
4
RemovethetwoscrewsfromtheStandBase.
RemovetheStandBasefromtheStandBody.
3
Removethetwoscrewsonthebackofstand
body
.

Asshownintheillustration,disconnectthe
stand body from the stand hinge.
Stand Hinge
Stand Body
Stand Body
Stand Body
Stand Base
(Black)
(Black)
(Silver)
or
background
11
ENG
ENGLISH
ASSEMBLING AND PREPARING
Toprotectthescreenfromscratches,cover
thesurfacewithasoftcloth.
CAUTION
1
Placethescreenfacedown.
29UB65
Thecomponentsintheillustrationsmaydif-
ferfromtheactualproduct.
Donotcarrythemonitorupsidedown,asthis
maycauseittofalloffitsstandandresultin
damageorinjury.
Toavoiddamagingthescreenwhenlifting
ormovingthemonitor,onlyholdthestandor
theplasticcover.Thisavoidsputtingunnec-
essarypressureonthescreen.
CAUTION
2
Turnthescrewtotheleftusingacoin.
Detachthe
stand base
.
1
2
3
Removethetwoscrewsfromthestandbody.
Stand Base
Stand Body
Stand Body
background
12
ENG
ENGLISH
ASSEMBLING AND PREPARING
Installing onto a table
1
Liftthemonitorandplaceitonthetableinan
uprightposition.
Placeatleast
10 cm
awayfromthewallto
ensuresufficientventilation.
2
Connecttheadaptertothemonitor,thenplug
thepowercordintothepoweroutlet.
3
Pressthe (Power)buttononthebottomof
themonitortoturniton.
Unplugthepowercordpriortomovingor
installingthemonitor.Thereisriskofelectric
shock.
CAUTION
29UM65
29UM65
29UB65
10cm
10cm
10cm
10cm
29UB65
10 cm
10 cm
10 cm
10 cm
background
13
ENG
ENGLISH
ASSEMBLING AND PREPARING
Oncethepinisremoved,itisnotnecessary
tore-insertittoadjusttheheight.
Adjusting the stand height
2
Removethe
tape attached to the bottom
back of the stand body and then pull out the
locking pin while pressing the head down-
ward.
3
Theheightcanbeadjustedupto
110.0 mm
.
Donotputyourfingersor
handbetweenthescreen
andthebase(chassis)when
adjustingthescreen'sheight.
Tape
Locking Pin
Stand Body
CAUTION
WARNING
Head
Locking pin
1
Standthemonitorassembledwiththestand
baseinanuprightposition
29UB65
110.0mm
background
14
ENG
ENGLISH
ASSEMBLING AND PREPARING
Adjusting the angle
1
Placethemonitorinanuprightposition,mount-
edonthestandbase.
2
Adjusttheangleofthescreen.Theangleofthe
screencanbeadjustedforwardsorbackwards
foracomfortableviewingexperience.
Toavoidinjurytothefingerswhenadjusting
thescreen,donotholdthelowerpartofthe
monitor'sframeasillustratedbelow.
Becarefulnottotouchorpressthescreen
areawhenadjustingtheangleofthemonitor.
WARNING
29UB65
29UM65
29UM65
29UM65
29UB65
29UB65
Front Side
Rear Side
Front Side
Rear Side
-520
-520
-520
background
15
ENG
ENGLISH
ASSEMBLING AND PREPARING
Toavoidscratchingthestandbase,make
surethatwhenrotatingthemonitorusing
thepivotfeature,thestanddoesnotmake
contactwiththemonitor.
WARNING
Pivot feature
Thepivotfeatureallowsthemonitortorotate90
clockwise.
29UB65
1
Raisethemonitoruptothemaximumheight.
2
Adjusttheangleofthemonitorinthedirection
ofthearrowasshowninthefigure.
3
Rotatethemonitorclockwiseasshowninthe
figure.
4
Completetheinstallationbyrotatingthe
monitor90°asshownbelow.
Takecarewhenrotatingthemonitorifthe
cableisconnected.
WARNING
Animagedisplayedonthemonitor'sscreen
doesnotrotateaccordingtothescreen
orientation.
NOTE
Head
Stand
background
16
ENG
ENGLISH
ASSEMBLING AND PREPARING
Installing the wall mount plate
Thismonitorsupportsthespecificationofthestan-
dardwallmountplateorcompatibledevice.
1
Placethescreenfacedown.Toprotectthe
screenfromscratches,coverthesurfacewitha
softcloth.
2
Placethewallmountplateontothemonitor
andalignitwiththescrewholes.
3
Usingascrewdriver,tightenthefourscrewsto
fixtheplateontothemonitor.
Thewallmountplateissoldseparately.
Formoreinformationoninstallation,referto
thewallmountplate'sinstallationguide.
Becarefulnottouseexcessiveforcewhen
mountingthewallmountplate,asthiscan
damagethemonitor'sscreen.
NOTE
Use oftheKensingtonlockisoptional.
Theaccessoriescanbepurchasedat
your localelectronicsstore.
NOTE
Using the Kensington lock
TheKensingtonsecuritysystemconnectorislocat-
edatthebackoftheMonitorset.
Formoreinformationoninstallationandusage,
refertotheKensingtonlockusermanualorvisit
thewebsiteathttp://www.kensington.com.
ConnecttheKensingtonsecuritysystemcable
betweentheMonitorsetandatable.
29UM65
29UB65
Wall Mount Plate
background
17
ENG
ENGLISH
ASSEMBLING AND PREPARING
Toinstallthemonitortoawall,attachawallmount-
ingbracket(optional)tothebackofthemonitor.
Makesurethatthewallmountingbracketissecurely
fixedtothemonitorandtothewall.
1Usethescrewsandwallmountingbracketthat
complywiththeVESAstandard.
2Screwswhicharelongerthanthestandard
lengthmaydamagetheinsideofthemonitor.
3Anon-VESAstandardscrewmaydamagethe
productandcausethemonitortofall.LGElec-
tronicsisnotliableforanyaccidentsrelatingto
theuseofnon-standardscrews.
4VESAcompatibleonlywithrespecttoscrew
mountinginterfacedimensionsandmounting
screwspecifications
5UseitaccordingtotheVESAstandardasspeci-
fiedbelow.
784.8mmorless
*Thicknessofthewallmountplate:2.6mm
*Fasteningscrew:Diameter4.0mmxPitch0.7
mmxLength10mm
787.4mmorgreater
*
Usethewallmountplateandscrewsthatcon-
formtotheVESAstandard
.
Installing to a wall
Installthemonitoratleast10cmawayfromthe
wallandleaveabout10cmofspaceateachside
ofthemonitortoensuresufficientventilation.De-
tailedinstallationinstructionscanbeobtainedfrom
yourlocalretailstore.Pleaserefertothemanual
toinstallandsetupatiltingwallmountingbracket.
10cm
10cm
10cm
10cm
Unplugthepowercordbeforemovingorin-
stallingthemonitortoavoidelectricshocks.
Installingthemonitorontheceilingorona
slantedwallmayresultinthemonitorfalling
off,whichcouldleadtoinjury.Pleaseuse
thegenuineLGwallmountingbracket.For
moreinformation,contactyourlocalretail
storeoraqualifiedinstaller.
Applyingexcessiveforcewhenfastening
screwsmaycausedamagetothemoni-
tor.Damagecausedinthiswaywillnotbe
coveredbytheproductwarranty.
Usethewallmountingbracketandscrews
thatconformtotheVESAstandard.Dam-
agecausedbytheuseormisuseofinap-
propriatecomponentswillnotbecovered
bytheproductwarranty.
Screwlengthfromoutersurfaceofback
covershouldbeunder8mm.
UsethescrewsspecifiedbytheVESAstan-
dard.
Thewallmountkitincludestheinstallation
guideandallnecessaryparts.
Thewallmountingbracketisoptional.The
accessoriescanbepurchasedatyourlocal
retailstore.
Thelengthofthescrewmaydifferforeach
wallmountingbracket.Ensurethecorrect
lengthscrewisused.
Formoreinformation,pleaserefertothe
usermanualforthewallmountingbracket.
CAUTION
NOTE
VESA (A x B)
75x75
Stand Screw
M4x10
Required Screws
4
WallmountPad
WallmountPad
BackCover
BackCover
Standardscrew
Max.8mm
background
18
ENG
ENGLISH
USING THE MONITOR
USING THE MONITOR
Connecting to a PC
Thismonitorsupportsthe*PlugandPlay
feature.
*PlugandPlay:Afeaturethatallowsyouto
addadevicetoyourcomputerwithouthaving
toreconfigureanythingorinstallanymanual
drivers.
DVI connection
Transmitsdigitalvideosignalstothemonitor.Con-
nectthemonitorusingtheDVIcableasillustrated
below.
Pressthemenubuttonandthenselecttheinput
optionfromtheinputmenu.
TohearthesoundinDVIinputmode,connectthe
PC'sAUDIOOUTporttothemonitor'sAUDIOIN
(PC)portusingtheaudiocablethatcamewiththe
product.
Connecttheinputsignalcableand
turninthedirectionofthearrow.
Topreventdisconnectionsecure
thecabletightly.
Donotpressonthescreenfora
prolongedperiodoftime.Thismaycause
imagedistortion.
Donotdisplayastillimageonthescreen
foraprolongedperiodoftime.Thismay
causeimageretention.Ifpossible,usethe
screensaver.
CAUTION
Whenconnectingthepowercordtotheout-
let,useagrounded(3-hole)multi-socketora
groundedpoweroutlet.
Themonitormayflickerwhenturnedoninan
areaoflowtemperature.Thisisnormal.
Sometimesred,green,orbluespotsmayap-
pearonthescreen.Thisisnormal.
UsingaDVItoHDMIcablemaycausecom-
patibilityissues.
NOTE
29UM65
29UB65
(soldseparately)
(soldseparately)
(soldseparately)
(soldseparately)
background
19
ENG
ENGLISH
USING THE MONITOR
Theremaybenovideooraudiooutputde-
pendingontheDPversionofthePC.
TheDisplayPortcablemaynotbeavailable
insomeareas.
DisplayPort connection
Transmitsthedigitalvideoandaudiosignalsfrom
yourPCtothemonitor.ConnectyourPCtothe
monitorusingthedisplayportcableasillustrated
below.
Pressthemenubuttonandthenselecttheinput
optionfromtheinputmenu.
NOTE
HDMI connection
Transmitsthedigitalvideoandaudiosignalsfrom
yourPCandA/Vdevicestothemonitor.Connect
yourPCandAVdevicetothemonitorwiththe
HDMIcableasillustratedbelow.
Pressthemenubuttonandthenselecttheinput
optionfromtheinputmenu.
HDMIPCmaycausedevicecompatibility
issues.
UsingaDVItoHDMIcablemaycausecom-
patibilityissues.
NOTE
29UM65
29UB65
29UB65
29UM65
(soldseparately)
(soldseparately)
background
20
ENG
ENGLISH
USING THE MONITOR
Connecting to AV Devices
HDMI connection
Transmitsthedigitalvideoandaudiosignalsfrom
yourPCandA/Vdevicestothemonitor.Connect
yourPCandAVdevicetothemonitorwiththe
HDMIcableasillustratedbelow.
Pressthemenubuttonandthenselecttheinput
optionfromtheinputmenu.
UsingaDVItoHDMIcablemaycausecom-
patibilityissues.
NOTE
29UM65
29UB65
(soldseparately)
(soldseparately)
background
21
ENG
ENGLISH
USING THE MONITOR
Connecting to External Devices
Headphone port connection
Usetheheadphoneporttoconnectaperipheral
devicetothemonitor.Connectasillustrated.
29UM65
29UB65
DependingontheaudiosettingsofthePC
andexternaldevice,headphoneandspeaker
functionsmaybelimited.
NOTE
Foranangleplugearphone,itisdifficult
connectitwithaperipheraldevice,sousea
straighttype.
NOTE
AngleType StraightType
(soldseparately)
(soldseparately)
background
22
ENG
ENGLISH
INSTALLING LG Monitor Software
INSTALLING LG MONITOR SOFTWARE
1
SetthedefaultWebbrowsertoInternetExplorer.
Insertthetheowner'smanualCDincludedintheproductpackageintoyourPC'sCDdriverandinstallthe
LGMonitorSoftware.
2
Clickthe"LGMonitorSoftware"ontheCD's
mainscreen.Whenthefiledownloadwindow
appears,clicktheRunbutton.(Thefiledown-
loadwindowmayvarydependingontheoper-
atingsystemandtheInternetExplorerversion,
buttheinstallationproceduresaresame.)
ServicePack1orhigherisrequiredfor
Windows7.
3
Followtheinstructionstoproceedwiththe
installation.
4
Check"Iacceptthetermsoftheagreement"on
theLicenseAgreementscreenandthenclick
the[Next]button.
ScreenSplit:Thisprogramautomatically
splitstheprogramwindowasdesired.
ThisprogramnotsupportedWindowsXP.
AutoResolution:Thisisaprogramthat
automaticallychangestheresolutiontothe
optimalsettingswhenconnectingthemonitor
tothePCinPBPmode.
ThisprogramisnotsupportedinClone
Mode.
ExtendedModeisnotsupportedwhen
usingasingledisplay.
ThisprogramnotsupportedWindowsXP&
Vista.
5
Selecttheprogramthatyouwanttoinstall.
NOTE
CAUTION
background
23
ENG
ENGLISH
INSTALLING LG Monitor Software
6
TheLGMonitorSoftwareinstallationstartsas
shownbelow.
7
TheprogramyouselectedontheSelect
Featurespagewillinstallautomatically.
8
Whentheinstallationiscomplete,restartyour
system.
NOTE
IfyourunScreenSplit,theScreenSpliticon[
]appearsinthesystemtrayattherightbottomof
thePCscreen.
Right-clicktheScreenSpliticonandselecta
layoutyouwant.
background
24
ENG
ENGLISH
CUSTOMIZING SETTINGS
CUSTOMIZING SETTINGS
Activating the Main Menu
Button Description
Pressthepower
buttoncenter.
If the menu is
disabled
EnablesthenavigationOSD.
If the menu is
enabled
ClosethenavigationOSD.
(LongpressMonitoroff,Thisturnoffmethodcanworkinanycondition.Even
thoughOSDOff.)
Power Indicator Whenthemonitorisinoperatingmode,thepowerindicatorwillturnon.(powered
on).
Whenthemonitorisinpower-savingmode,thepowerindicatorwillblinking.
Jogthepower
buttonleft.
If the menu is
disabled
Adjuststhevolumelevelofthemonitor.
If the menu is
enabled
EntertoMenuOSD.Innosyncmode,enterInputchangeOSD.
Jogthepower
buttonright.
If the menu is
disabled
Adjuststhevolumelevelofthemonitor.
If the menu is
enabled
EntertoPBPOSD.
Jogthepower
buttonup.
If the menu is
disabled
EnablesthenavigationOSD.
If the menu is
enabled
EntertoReaderOSD.
Jogthepower
buttondown.
If the menu is
disabled
EnablesthenavigationOSD.
If the menu is
enabled
TurntheMinitoroff.
Navigation OSD
1
PressthePower( )button,thenavigationOSDappear.
2
JogthePowerbuttonleft(

),right(

),up(

),down(

)toadjusttheoptions.
3
PressandholdthePower( )buttontoexittheOSDmenu.
Power Indicator
Power buttons
background
25
ENG
ENGLISH
CUSTOMIZING SETTINGS
Eachoptionisdescribedbelow.
Customizing settings
Menu Settings
-Easy control
1
ToviewthenavigationOSD,pressthePowerbuttoncenter( ).
2
JogPowerbuttonleft(
)togoto
Menu
OSD.
3
PressPowerbuttoncenter( )orJogPowerbuttonright(
)
toselect
Easy control
.
4
Settheoptionsfollowuptheinstructionappearonrightbottomof
thescreen.
5
Toreturntotheuppermenuorsetothermenuitems,Jogthe
Powerleft(
).
Menu > Easy control Description
Brightness
Adjuststhecolorcontrastandbrightnessofthescreen.
Contrast
Volume Adjuststhevolume.
NOTE
JogPowerbuttondown(
)intheVolumemenuwillenable/disablethe
Mutefunction.
Input Selectsthecurrentinputmode.
Ratio Adjuststhescreenratio.
Wide Displaysthevideoinwide-screen,regardlessofthevideosignalinput.
Original Displaysavideoaccordingtotheinputvideosignalaspectratio.
Cinema 1
Enlargesthescreenwithanaspectratioof21:9.(at1080p)
Cinema 2 Enlargesthescreenwithanaspectratioof21:9includingtheblackboxarea
atthebottomforsubtitles.(at1080p)
1:1 Theaspectratioisnotadjustedfromtheoriginal.
NOTE
ThedisplaymaylookthesameforWide,Originaland1:1optionsattherecommendedresolution
(2560x1080).
Theratioisdisabledintheinterlacedsignal.
background
26
ENG
ENGLISH
CUSTOMIZING SETTINGS
Eachoptionisdescribedbelow.
-Function
1
ToviewthenavigationOSD,pressthePowerbutton
center( ).
2
JogPowerbuttonleft(
)togoto
Menu
OSD.
3
Jogthepowerbuttonup(
)ordown(
)togo
to
Function
.
4
PressPowerbuttoncenter( )orJogPowerbutton
right(
)toselect
Function
.
5
Settheoptionsfollowuptheinstructionappearon
rightbottomofthescreen.
6
Toreturntotheuppermenuorsetothermenuitems,
JogthePowerleft(
).
Menu > Func. Description
SUPER ENERGY
SAVING
High
Savesenergybyusingthehigh-efficiencySUPERENERGYSAVINGfunction.
Low
Savesenergybyusingthelow-efficiencySUPERENERGYSAVINGfunction.
Off
DisablestheSUPERENERGYSAVINGfunction.
Picture Mode Custom Allowstheusertoadjusteachelement.Thecolormodeofthemainmenucanbead-
justed.
Photo Optimizesthescreentoviewphotos.
Cinema Optimizesthescreentoimprovethevisualeffectsofavideo.
Game Optimizesthescreenforgameplay.
background
27
ENG
ENGLISH
CUSTOMIZING SETTINGS
-PBP
1
ToviewthenavigationOSD,pressthePowerbutton
center( ).
2
JogPowerbuttonleft(
)togoto
Menu
OSD.
3
Jogthepowerbuttonup(
)ordown(
)togo
to
PBP
.
4
PressPowerbuttoncenter( )orJogPowerbutton
right(
)toselect
PBP
.
5
Settheoptionsfollowuptheinstructionappearon
rightbottomofthescreen.
6
Toreturntotheuppermenuorsetothermenuitems,
JogthePowerleft(
).
Menu > PBP Description
PBP Displaysthescreensoftwoinputmodesononemonitor.
Input Main Displaysthevideoinwide-screen,regardlessofthevideosignalinput.
Sub Displaysavideoaccordingtotheinputvideosignalaspectratio.
Audio ChangestheaudiooutputinPBPmode.
Swap TogglesbetweenthemainscreenandsubscreeninPBPmode.
Sub Full ConvertsthesubscreenofPBPmodetothewidescreen.
Ratio Adjuststheaspectratioofthemainscreenorsubscreen.
Main Wide
DisplaysthevideotofittheMainscreen,regardlessofthevideosignalinput.
Original
DisplaysthevideointheinputvideosignalaspectratioontheMainscreen.
Sub Wide
DisplaysthevideotofittheSubscreen,regardlessofthevideosignalinput.
Original
DisplaysthevideointheinputvideosignalaspectratioontheSubscreen.
background
28
ENG
ENGLISH
CUSTOMIZING SETTINGS
Eachoptionisdescribedbelow.
-Screen
1
ToviewthenavigationOSD,pressthePowerbutton
center( ).
2
JogPowerbuttonleft(
)togoto
Menu
OSD.
3
Jogthepowerbuttonup(
)ordown(
)togo
to
Screen
.
4
PressPowerbuttoncenter( )orJogPowerbutton
right(
)toselect
Screen
.
5
Settheoptionsfollowuptheinstructionappearon
rightbottomofthescreen.
6
Toreturntotheuppermenuorsetothermenuitems,
JogthePowerleft(
).
Menu > Screen Description
Picture Sharpness Adjuststhesharpnessofthescreen.
Black Level Setstheoffsetlevel(forHDMIonly).
Offset:
asareferenceforavideosignal,thisisthedarkestcolorthemonitorcan
display.
High
Thepictureofthescreengetsbrighter.
Low
Thepictureofthescreengetsdarker.
Response Time Setsaresponsetimefordisplayedpicturesbasedonthespeedofthescreen.Foranor-
malenvironment,itisrecommendedthatyouuseNormal.Forafast-movingpicture,itis
recommendedthatyouuseHigh.
SettingtoHighmaycauseimagesticking.
High
SetstheresponsetimetoHigh.
Middle
SetstheresponsetimetoMiddle.
Low
SetstheresponsetimetoLow.
Off
SetstheresponsetimetoOff.
Color Gamma Customgammasetting:Whenusingthegamma0,gamma1,andgamma2monitorset-
tings,highergammasettingsmeanabrighterimageisdisplayedandviceversa.
Color Temp Custom
Red
Green
Blue
YoucancustomizethepicturecolorusingRed,Green,andBluecolors.
Selectsthefactorydefaultpicturecolor.
Warm:
Setsthescreencolortoareddishtone.
Medium:
Setsthescreencolorbetweenaredandbluetone.
Cool:
Setsthescreencolortoabluishtone.
Six Color Meetstheuserrequirementsforcolorsthroughadjustingthecolorandsaturationofthesix
colors(
red_Hue, red_Saturation, green_Hue, green_Saturation, blue_Hue, blue_Satu-
ration, cyan_Hue, cyan_Saturation, magenta_Hue, magenta_Saturation, yellow_Hue,
yellow_Saturation
)andsavingthesettings.
*Hue:Adjuststoneofthescreen.
*Saturation:Adjuststhesaturationofthescreencolors.Thelowerthevalue,lesssatu-
ratedandbrightthecolorsbecome.Thehigherthevalue,themoresaturatedanddarkthe
colorsbecome.
*Reset:Returnsthecolorsettingstothedefaultsettings.
Reset Returnsthecolorsettingstothedefaultsettings.
background
29
ENG
ENGLISH
CUSTOMIZING SETTINGS
-Settings
1
ToviewthenavigationOSD,pressthePowerbuttoncenter( ).
2
JogPowerbuttonleft(
)togoto
Menu
OSD.
3
Jogthepowerbuttonup(
)ordown(
)togoto
Settings
.
4
PressPowerbuttoncenter( )orJogPowerbuttonright(
)
toselect
Settings
.
5
Settheoptionsfollowuptheinstructionappearonrightbottomof
thescreen.
6
Toreturntotheuppermenuorsetothermenuitems,Jogthe
Powerleft(
).
Eachoptionisdescribedbelow.
Menu > Settings Description
Main Audio Mainaudiohavefouroptions.HDMI1,HDMI2,DP,Audio-In.
IfuserselectAudio-in,thensoundcomesfromstereocablesource.
Language Setsthemenuscreentothedesiredlanguage.
Power LED Turnsthepowerindicatoronthefrontsideofthemonitoron/off.
On Thepowerindicatorisautomaticallyturnedon.
Off Thepowerindicatoristurnedoff.
OSD Lock Preventsincorrectkeyinput.
On Keyinputisdisabled.
NOTE
AllfunctionsexceptfortheOSDLockmodeandtheExitbuttonforBrightness,Contrast,
Volume,Input,andSettingsaredisabled.
Off Keyinputisenabled.
background
30
ENG
ENGLISH
CUSTOMIZING SETTINGS
-Reset
1
ToviewthenavigationOSD,pressthePowerbutton
center( ).
2
JogPowerbuttonleft(
)togoto
Menu
OSD.
3
Jogthepowerbuttonup(
)ordown(
)togo
to
Reset
.
4
PressPowerbuttoncenter( )orJogPowerbutton
right(
)toselect
Reset
.
5
Settheoptionsfollowuptheinstructionappearon
rightbottomofthescreen.
6
Toreturntotheuppermenuorsetothermenuitems,
JogthePowerleft(
).
Eachoptionisdescribedbelow.
Menu > Reset Description
Do you want to reset your settings?
Reset Returnstothedefaultsettings.
Cancel Canceltheselect.
background
31
ENG
ENGLISH
CUSTOMIZING SETTINGS
Reader Settings
1
ToviewthenavigationOSD,pressthePowerbuttoncenter( ).
2
JogPowerbuttonup(
)togoto
Reader
OSD.
3
Settheoptionsfollowuptheinstructionappearonbottomofthe
screen.
Reader Mode
Description
Reader 1 Itisamodethatthescreenisadjustedtothebestforthenewspaper.Ifyou
wantscreenmorebright,youcancontrolbrightnessinMenuOSD.
Reader 2 Itisamodethatthescreenisadjustedtothebestforthecartoon.Ifyouwant
screenmorebright,youcancontrolbrightnessinMenuOSD.
Reader Off Itisamodethatreadermodeisoff.
Eachoptionisdescribedbelow.
background
32
ENG
ENGLISH
TROUBLESHOOTING
TROUBLESHOOTING
Nothing is displayed on the screen.
Isthemonitor'spowercordplugged
in?
Checkifthepowercordiscorrectlypluggedintothepoweroutlet.
Isthepowerindicatoron?
Checkthepowercableconnectionandpressthepowerbutton.
Isthepowerindicatordisplaying?
Checkthattheconnectedinputisenabled(Menu-Input).
Isthepowerindicatorblinking?
Ifthemonitorisinpower-savingmode,movethemouseorpressany
keyonthekeyboardtoswitchthedisplayon.
Checkifthecomputeristurnedon.
Isthe"OUTOFRANGE"message
displayed?
ThisoccurswhensignalstransferredfromthePC(videocard)areout
ofthehorizontalorverticalfrequencyrangeofthemonitor.Pleasesee
the"ProductSpecification"sectionofthismanualtosettheappropri-
atefrequency.
Isthe"CHECKSIGNALCONNEC-
TION"messageisdisplayed?
ThisisdisplayedwhenthesignalcablebetweenthePCandthemoni-
torismissingordisconnected.Checkthecableandreconnect.
The screen retains an image.
Doesimagestickingoccureven
whenthemonitoristurnedoff?
Displayingastillimageforaprolongedtimemaycausedamagetothe
screen,resultingintheretentionoftheimage.
Useascreensavertoprotectthescreenwhenusingthemonitorfora
prolongedperiodoftime.
Vertical Frequency:
Inordertodisplayanimage,thescreenmustberefresheddozensoftimesper
secondlikeafluorescentlamp.
Thenumberoftimesthescreenisrefreshedpersecondiscalledverticalfrequencyorrefreshrate
andisrepresentedbyHz.
Horizontal Frequency:
Thetimeittakestodisplayonehorizontallineiscalledthehorizontalcycle.
Thenumberofhorizontallinesdisplayedinonesecondcanbecalculatedbydividingonebythehori-
zontalcycle.ThisiscalledhorizontalfrequencyandisrepresentedbykHz.
NOTE
The screen is flickering.
Didyouselecttherecommended
resolution?
IftheselectedresolutionisHDMI1080i60/50Hz,thescreen
maybeflickering.Changetheresolutiontotherecommended
resolution1080P.
background
33
ENG
ENGLISH
TROUBLESHOOTING
Checkifthevideocard'sresolutionorfrequencyiswithintherangeallowedbythemonitorandsetto
therecommended(optimal)resolutionin
Control Panel > Display > Settings
.
Failingtosetthevideocardtotherecommended(optimal)resolutionmayresultinblurredtext,a
dimmedscreen,atruncateddisplayareaormisalignmentofthedisplay.
Theconfigurationproceduremaydifferdependingonyourcomputerand/oroperatingsystem.Also,
somevideocardsmaynotsupportcertainresolutions.Ifthisisthecase,contactthemanufacturerof
thecomputerorvideocardforassistance.
Somevideocardsmaynotsupportthe2560x1080resolution.
Iftheresolutioncannotbedisplayed,contactthemanufacturerofyourvideocard.
NOTE
The display color is abnormal.
Doesthedisplayappeardiscolored
(16color)?
Setthecolorto24bit(truecolor)orhigher.InWindows,gotoControl
Panel>Display>Settings>ColorQuality.
Doesthedisplaycolorappearun-
stableorinmonochrome?
Checkifthesignalcableisconnectedproperly.Reconnectthecable
orreinsertthePC'svideocard.
Aretherespotsonthescreen?
Whenusingthemonitor,pixilatedspots(red,green,blue,whiteor
black)mayappearonthescreen.ThisisnormalfortheLCDscreen.
Itisnotanerrornorisitrelatedtothemonitor'sperformance.
background
34
ENG
ENGLISH
SPECIFICATIONS
SPECIFICATIONS
29UM65 29UB65
LCDScreen Type 73.025cmTFT(ThinFilmTransistor)
LCD(LiquidCrystalDisplay)Screen
Diagonallengthofthescreen:73.025cm
PixelPitch 0.0876mmx0.2628mm
Resolution MaximumResolution 2560x1080@60Hz
RecommendedResolution 2560x1080@60Hz
VideoSignal
HorizontalFrequency 30kHzto90kHz
VerticalFrequency
DVI/DP:50Hzto75HzHDMI:25Hzto60Hz
Synchronization SeparateSync.
InputConnector
DVI-DIN,HDMIIN1,HDMIIN2,DisplayPort,AudioIn(PC),H/P
Power Voltage
19V 2.4A
Powerconsumption(Typ.)
Onmode:31W(ENERGYSTAR®standard)
*
PowerSavingMode≤0.5W
OffMode≤0.5W
AC/DCadaptor
DA-48F19type,AsianPowerDevicesInc.production,
OrLCAP35type,LIENCHANGELECTRONICENTERPRISEproduction.
Output:19V 2.53A
Environmental
Conditions
OperatingCondition Temperature:10°Cto35°C;Humidity:10%to80%
StoringCondition Temperature:-20°Cto60°C;Humidity:5%to90%
SpeakerWattage 7W+7W
29UM65
StandAngle
Adjustment
Forwards/Backwards:-5°to20°(Head)
Dimension MonitorSize(WidthxHeightxDepth)
WithStand
703.0mmx418.0mmx181.0mm
WithoutStand
703.0mmx328.0mmx64.0mm
Weight(Without
Packaging)
6.2kg
29UB65
StandAngle
Adjustment
Forwards/Backwards:-5°to15°(Head)
Dimension MonitorSize(WidthxHeightxDepth)
WithStand
703.0mmx425.0mmx225.0mm
WithoutStand
703.0mmx418.0mmx124.0mm
Weight(Without
Packaging)
6.8kg
Thespecificationsaresubjecttochangewithoutnotice.
*Thepowerconsumptionlevelcanbedifferentbyoperatingconditionandmonitorsetting.
*TheOnmodepowerconsumptionismeasuredwithENERGYSTAR
®
teststandard.
*ENERGYSTAR
®
isaUSregisteredmarkoftheUnitedStatesEnvironmentalProtectionAgency.
background
35
ENG
ENGLISH
SPECIFICATIONS
Factory support mode
(Preset Mode, DVI-D/HDMI/PC DisplayPort)
Preset Mode
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Polarity (H/V) Remarks
720x400 31.468 70.08 -/+
640x480 31.469 59.94 -/-
640x480 37.5 75 -/-
800x600 37.879 60.317 +/+
800x600 46.875 75 +/+
1024x768 48.363 60 -/-
1024x768 60.123 75.029 +/+
1152x864 67.5 75 +/+
1280x720 45 60 +/+
1280x1024 63.981 60.02 +/+
1280x1024 79.976 75.025 +/+
1600x900 60 60 +/+
1680x1050 65.290 59.954 -/+
1920x1080 67.5 60 +/-
2560x1080 66.7 60 -/+
HDMI Timing (Video)
Preset Mode
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
Remarks
480P 31.50 60
576P 31.25 50
720P 37.50 50
720P 45.00 60
1080P 56.25 50
1080P 67.50 60
Power Indicator
Mode LED Color
OnMode
LightOn
Power-saving
Blinking
OffMode Off
background
36
ENG
ENGLISH
PROPER POSTURE
PROPER POSTURE
Proper Posture for Using the Monitor
Adjustthescreensothatyoucancomfortablyviewataslightdownwardanglefromyournaturaleyelevel.
Takeabreakforapproximatelytenminuteseveryhourtoreduceanyfatiguecausedbylong-time
usage.
Thestandofthetouchmonitorallowstheproducttobeusedintheoptimumposition.
Adjustthestandangletoobtainthebestviewofthescreen.
Youshouldbelooking
slightlydownatthescreen.
Placeyourhandsgentlyon
thekeyboard,keepingyour
armsbentattheelbowsand
extendedhorizontallyinfront
ofyou.
Adjusttheangle
Sothatthereisnoreflection
orglarefromthescreen.
background
MakesuretoreadtheSafetyPrecautions
beforeusingtheproduct.
KeeptheOwner'sManual(CD)inan
accessibleplaceforfuturereference.
ThemodelandserialnumberoftheSET
islocatedonthebackandonesideofthe
SET.Recorditbelowshouldyoueverneed
service.
MODEL
SERIAL
Declaration of Conformity
Trade Name: LG
Model : 29UM65D,29UB65D
Responsible Party: LG Electronics Inc.
Address : 1000 Sylvan Ave. Englewood Cliffs
NJ 07632 U.S.A
TEL: 201-266-2534
*above information is only for USA FCC Regulatory

Specifications

Indexed Terms: Monitor, IPS Panel

LG Electronics 29UB65 Questions and Answers

Find answers or ask new question.
Questions and Answers

Related Products

Product LG Electronics 29UM58 image
LG Electronics 29UM58 29” Ultrawide Full Hd Ips Monitor
2020-12-12 3 docs
Product LG Electronics 29WQ50T B image
LG Electronics 29WQ50T-B 29'' 219 Ultrawide Full Hd Ips Monitor With Amd Freesync
2022-10-10 3 docs
Product LG Electronics 29BN650 B image
LG Electronics 29BN650-B 29” Hdr10 Ips Full Hd Ultrawide Monitor 2560x1080 With Amd Freesync, Maxxaudio, Flicker Safe, Reader Mode, Dynamic Action Sync, Black Stabilizer & Ergonomic Design
2021-09-03 1 docs
Product LG Electronics 29UC97 image
LG Electronics 29UC97 29'' Ultrawide Monitor
2020-12-12 3 docs
Product LG Electronics 34UM57 image
LG Electronics 34UM57 Ultrawide Ips Monitor
2020-10-26 2 docs
No image
LG Electronics 29UM67 Lg Ultrawide Ips Monitor
2020-10-26 2 docs
