GE - General Electric JCB730DF2WW GE 30" Electric Free User Manual

Coil Top and

Radiant Top Models

Self-Clean

Models

JCB530

JCB730

183D6379P073 29-5851

Safety Information

. . . . . . . . . . . 2–5

Operating Instructions

Clock, Timer and

Convenience Outlet . . . . . . . . . . . . . . 6, 17

Controls . . . . . . . . . . . . . . . . . . . . . . . . . . 9, 10

Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11, 12

Sabbath Feature . . . . . . . . . . . . . . . . 26, 27

Self-Cleaning . . . . . . . . . . . . . . . . . . . . 22, 23

Special Features . . . . . . . . . . . . . . . . 24, 25

Surface Units . . . . . . . . . . . . . . . . . . . . . . . . 6

Temperature Conversions . . . . . . . . . . 10

Thermostat . . . . . . . . . . . . . . . . . . . . . . . . .20

Timed Baking and Roasting . . . . . . . .13

Care and Cleaning

. . . . . . . . . 28–34

Troubleshooting Tips

. . . . . . 35–39

Accessories

. . . . . . . . . . . . . . . . . . . . . . 40

Consumer Support

Consumer Support . . . . . . . . . . . . . . . . .44

Product Registration . . . . . . . . . . . . 41, 42

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Write the model and serial

numbers here:

Model # __________________

Serial # __________________

You can find them on a label,

behind the storage drawer

on the oven frame.

Owner’s Manual

Ranges

Electric Coil & Radiant

www.GEAppliances.ca

Using the surface units . . . . . . . . . . . . . . 8

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

Consumer Support Troubleshooting Tips Care and Cleaning

Operating Instructions

Safety Instructions

Read all safety instructions before using the product Failure to follow these instructions may result in fire, electric

shock,serious injury or death

WARNING

ANTI-TIP DEVICE

To reduce the risk of tipping the range, the range must be

secured by a properly installed anti-tip bracket

See installation

instructions shipped with the bracket for complete details before

attempting to install

For Freestanding Ranges:

To check if the bracket is installed and engaged properly,

remove the storage drawer or kick panel and look underneath

the range to see that the leveling leg is engaged in the bracket

On models without a storage drawer or kick panel, carefully tip

the range forward The bracket should stop the range within

4 inches If it does not, the bracket must be reinstalled If the

range is pulled from the wall for any reason, always repeat this

procedure to verify the range is properly secured by the anti-tip

bracket

Never completely remove the leveling legs or the range will not

be secured to the anti-tip device properly

For Slide-In Ranges:

To check if the bracket is installed and engaged properly,

remove the storage drawer or kick panel and look underneath

the range to see that the leveling leg is engaged in the bracket

For Drop-In Ranges:

To check if the bracket is installed and engaged properly, lower

the oven door and gently apply medium force at the handle end

until movement of the range is detected

Continue pressing until

the anti-tip bracket is engaged and movement stops

Asmall

amount of movement is acceptable at the back of the range

top, but it should be stable and not tip once the anti-tip bracket

is engaged

If it does not, the bracket must be reinstalled

If you did not receive an anti-tip bracket with your purchase,

call.1

800 626 8774 to receive one at no cost (in Canada, call

1 800 561 3344) For installation instructions of the bracket, visit

GEAppliances com.(in Canada, GEAppliances ca)

GEAppliances.ca

Safety Instructions Operating Instructions

Care and Cleaning

Troubleshooting Tips

Consumer Support

Use this appliance for its intended purpose as described

in this Owner’s Manual

.Be sure your appliance is properly installed and

grounded by a qualified installer in accordance with the

provided installation instructions

Do not attempt to repair or replace any part of your

range unless it is specifically recommended in this

manual

All other servicing should be referred to a

qualified technician

Before performing any service, unplug the range

or disconnect the power supply at the household

distribution panel by removing the fuse or switching off

the circuit breaker

Do not leave children alone³children should not be left

alone or unattended in an area where an appliance is in

use

They should never be allowed to climb, sit or stand

on any part of the appliance

CAUTION:.Do not store items of interest to

children above a range or on the backguard of a

range³children climbing on the range to reach items

could be seriously injured

Use only dry pot holders³moist or damp pot holders on

hot surfaces may result in burns from steam Do not let

pot holders touch hot surface units or heating elements

Do not use a towel or other bulky cloth in place of pot

holders

Never use your appliance for warming or heating the

room

Do not touch the surface units, the heating elements

or the interior surface of the oven These surfaces may

be hot enough to burn even though they are dark in

color

During and after use, do not touch, or let clothing

or other flammable materials contact the surface units,

areas nearby the surface units or any interior area of

the oven; allow sufficient time for cooling first

Other

surfaces of the appliance may become hot enough

to cause burns Potentially hot surfaces include the

cooktop, areas facing the cooktop, oven vent opening,

surfaces near the opening and crevices around the

oven door

Do not heat unopened food containers Pressure could

build up and the container could burst, causing an

injury

Do not use aluminum foil to line drip pans or anywhere

in the oven, except as described in this manual Foil can

trap heat or melt, resulting in damage to the product

and a shock or fire hazard

Avoid scratching or impacting glass doors, cook tops or

control panels Doing so may lead to glass breakage Do

not cook on a product with broken glass Shock, fire or

cuts may occur

Cook meat and poultry thoroughly³meat.to at least an

internal temperature of 160°F and poultry to at least

an internal temperature of 180°F. Cooking to these

temperatures usually protects against foodborne illness

GENERAL SAFETY INSTRUCTIONS

Do not store or use flammable materials in an oven or

near the cooktop, including paper, plastic, pot holders,

linens, wall coverings, curtains, drapes and gasoline or

other flammable vapors and liquids

Never wear loose-fitting or hanging garments while

using the appliance

These garments may ignite if they

contact hot surfaces causing severe burns

Do not let cooking grease or other flammable materials.

accumulate in or near the range Grease in the oven or

on the cooktop may ignite

Clean ventilating hoods frequently Grease should not

be allowed to accumulate on the hood or filter

KEEP FLAMMABLE MATERIALS AWAY FROM THE RANGE

WARNING

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions

Safety Instructions

Do not use water on grease fires Never pick up a

flaming pan Turn the controls off Smother a flaming

pan on a surface unit by overing the pan completely

with a well-fitting lid, cookie sheet or flat tray

Use

a multi-purpose dry chemical or foam-type fire

extinguisher

If there is a fire in the oven during baking, smother the

fire by closing the oven door and turning the oven off or

by using a multi-purpose dry chemical or foam-type fire

extinguisher

If there is a fire in the oven during self-clean, turn the

oven off and wait for the fire to go out Do not force

the door open

Introduction of fresh air at self-clean

temperatures may lead to a burst of flame from the

oven

Failure to follow this instruction may result in

severe burns

IN THE EVENT OF A FIRE, TAKE THE FOLLOWING

STEPS TO PREVENT THE FIRE FROM SPREADING:

Never leave the surface units unattended at medium or

high heat settings Boilovers cause smoking and greasy

spillovers that may catch on fire

Never leave oil unattended while frying If allowed to

heat beyond its smoking point, oil may ignite resulting

in fire that may spread to surrounding cabinets

Use a

deep fat thermometer whenever possible to monitor oil

temperature

To avoid oil spillover and fire, use a minimum amount of

oil when shallow pan-frying and avoid cooking frozen

foods with excessive amounts of ice

Use proper pan size³select cookware having flat

bottoms large enough to cover the surface heating

element

The use of undersized cookware will expose

a portion of the surface unit to direct contact and may

result in ignition of clothing

Proper relationship of

cookware to surface unit will also improve efficiency

Only certain types of glass, glass/ceramic, earthenware

or other glazed containers are suitable for cooktop

service; others may break because of the sudden

change in temperature

To minimize the possibility of burns, ignition of

flammable materials and spillage, the handle of a

container should be turned toward the center of the

range without extending over nearby surface units

When preparing flaming foods under a hood, turn the

fan on

If power is lost to an electric cooktop while a surface

unit is ON, the surface unit will turn back ON as soon

as power is restored

In the event of power loss, failure

to turn all surface unit knobs to the OFF position may

result in ignition of items on or near the cooktop, leading

to serious injury or death

COOKTOP SAFETY INSTRUCTIONS

WARNING

GEAppliances.ca

Safety Instructions Operating Instructions Care and Cleaning

Troubleshooting Tips

Consumer Support

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

.Stand away from the range when opening the oven

door

Hot air or steam which escapes can cause burns

to hands, face and/or eyes

Keep the oven vent unobstructed

Keep the oven free from grease buildup Grease in the

oven may ignite

Place oven racks in desired location while oven is cool

If rack must be moved while oven is hot, do not let pot

holder contact hot heating element in oven

.When using cooking or roasting bags in the oven, follow

the manufacturer’s directions

Pull the oven rack to the stop-lock position when

loading and unloading food from the oven This helps

prevent burns from touching hot surfaces of the door

and oven walls

Do not leave items such as paper, cooking utensils or

food in the oven when not in use Items stored in an

oven can ignite

Do not use aluminum foil to line the oven bottom

Foil can trap heat or melt, resulting in damage to the

product and a shock or fire hazard

OVEN SAFETY INSTRUCTIONS

Use care when touching the cooktop The glass surface

of the cooktop will retain heat after the controls have

been turned off

Do not cook on a broken cooktop If glass cooktop

should break, cleaning solutions and spillovers

may penetrate the broken cooktop and create a

risk of electric shock

Contact a qualified technician

immediately

Avoid scratching the glass cooktop The cooktop can be

scratched with items such as knives, sharp instruments,

rings or other jewelry, and rivets on clothing

Do not place or store items that can melt or catch fire

on the glass cooktop, even when it is not being used

the cooktop is inadvertently turned on, they may ignite

Heat from the cooktop or oven vent after it is turned off

may cause them to ignite also

Use CERAMA BRYTE

ceramic.Cooktop Cleaner and

CERAMA BRYTE

Cleaning Pad to clean the cooktop

Wait until the cooktop cools and the indicator light goes

out before cleaning A wet sponge or cloth on a hot

surface can cause steam burns

Some cleaners can

produce noxious fumes if applied to a hot surface Note:.

Sugar spills are an exception They should be scraped

off while still hot using an oven mitt and a scraper

See

the Cleaning the glass cooktop section for detailed

instructions

Read and follow all instructions and warnings on the

cleaning cream label

RADIANT COOKTOP SAFETY INSTRUCTIONS (Some models)

WARNING

The self-cleaning feature operates the oven at temperatures high enough to burn away food soils in the oven.

Follow these instructions for safe operation.

Before operating the self-clean cycle, remove pans,

shiny metal oven racks and other utensils from the

oven

Only gray porcelain-coated oven racks may be

left in the oven Do not use self-clean to clean other

parts, such as drip pans or bowls

Before operating the self-clean cycle, wipe grease and

food soils from the oven

Excessive amount of grease

may ignite leading to smoke damage to your home

If the self-cleaning mode malfunctions, turn the oven off

and disconnect the power supply

Have it serviced by a

qualified technician

Do not clean the door gasket The door gasket is

essential for a good seal

Care should be taken not to

rub, damage or move the gasket

Do not use oven cleaners No commercial oven cleaner

or oven liner protective coating of any kind should be

used in or around any part of the oven

SELF-CLEANING OVEN SAFETY INSTRUCTIONS

(Some models)

WARNING

Using the radiant surface units. (on some models)

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions

Safety Instructions

Temperature Limiter

Every radiant surface unit has a

temperature limiter.

The temperature limiter protects the

glass cooktop from getting too hot.

Thetemperaturelimitermay cycle the

units fora time if:

The pan boils dry.

The pan bottom is not flat.

The pan is off center.

There is no pan on the unit.

NOTE: Throughout this manual, features and appearance may vary from your model.

Never cook directly on the glass.

Always use cookware.

About the Radiant Surface Units

WARNING:

The surface

units are automatically disabled during

the self-clean cycle. Make sure that all

surface unit controls are turned off at all

times during the self-clean cycle. Any

surface unit that is set to an on position,

while the self-clean cycle is operating, will

automatically come on after the self-clean

cycle is finished, and could result in an

on, unattended surface unit. Wait until

the self-clean cycle is finished to set and

use the surface units.

The radiant cooktop features heating

units beneath a smooth glass surface.

Cooktop temperatures increase with

the number of surface units that are on.

With 3 or 4 units turned on, surface

temperatures are high. Always use

caution when touching the cooktop.

An indicator light will come on when

the surface unit is turned on.

The appropriate

HOT

surface indicator

light will glow when its corresponding

radiant element is turned on and will

remain on until the surface has cooled

below 65.5°C (150°F).

NOTE:

Hot surface indicator light will:

Come on when the surface unit is hot

to the touch.

Stay on even after the unit is turned off.

Glow brightly until the unit has cooled

below 65.5°C (150°F).

NOTE:

A slight odor is normal when a new

cooktop is used for the first time. It is caused by

the heating of new parts and insulating materials

and will disappear in a short time.

NOTE:

On models with light-colored glass

cooktops, it is normal for the cooking zones to

change color when hot or cooling down. This is

temporary and will disappear as the glass cools

to room temperature.

It is safe to place hot cookware from the

oven or surface on the glass cooktop

when the surface is cool.

Even after the surface units are turned

off, the glass cooktop retains enough

heat to continue cooking. To avoid

overcooking, remove pans from the

surface units when the food is cooked.

Avoid placing anything on the surface

unit until it has cooled completely.

Water stains (mineral deposits) are removable

using the cleaning cream or full strength white

vinegar.

Use of window cleaner may leave an iridescent

film on the cooktop. The cleaning cream will

remove this discoloration.

Don’t store heavy items above the cooktop.

If they drop onto the cooktop, they can cause

damage.

Do not use the surface as a cutting board.

SURFACE

COOKING

OFF CENTER

Always place the pan in the center of

the surface unit you are cooking on.

DRAGGING

Do not slide cookware across the

control or cooktop surface because

it can scratch the glass. The glass is

scratch-resistant, not scratchproof.

Selecting types of cookware. GEAppliances.ca

The following information will help you choose cookware which will give good performance on glass cooktops.

Stainless Steel:

recommended

Aluminum:

heavy weight recommended

Good conductivity. Aluminum residues

sometimes appear as scratches on the

cooktop, but can be removed if cleaned

immediately. Because of its low melting

point, thin-weight aluminum should not

be used.

Copper Bottom:

recommended

Copper may leave residues which can

appear as scratches. The residues can be

removed, as long as the cooktop is cleaned

immediately. However, do not let these pots

boil dry. Overheated metal can bond to glass

cooktops. An overheated copper bottom pot

will leave a residue that will permanently

stain the cooktop if not removed

immediately.

Porcelain Enamel-Covered Cast Iron:

recommended

As long as the cookware is covered

completely with porcelain enamel,

this cookware is recommended. Caution

is recommended for cast-iron cookware

that is not completely covered with

smooth porcelain enamel, as it may

scratch the glass-ceramic cooktop.

Glass-Ceramic:

usable, but not recommended

Poor performance. May scratch the surface.

Stoneware:

usable, but not recommended

Poor performance. May scratch the surface.

Home Canning Tips:

Be sure the canner is centered over

the surface unit.

Make sure the canner is flat on the bottom.

Use recipes and procedures from

reputable sources. These are available

from manufacturers such as Ball

and

Kerr

and the Department of Agriculture

Extension Service.

To prevent burns from steam or heat,

use caution when canning.

Check pans for at bottoms by using

a straight edge.

Pans with rounded, curved, ridged or

warped bottoms are not recommended.

Wok Cooking

We recommend that you use only a flat-

bottomed wok. They are available at your

local retail store.

Do not use woks that have support rings.

Use of these types of woks, with or without

the ring in place, can be dangerous.

Placing the ring over the surface unit will

cause a buildup of heat that will damage

the porcelain cooktop. Do not try to use

such woks without the ring. You could

be seriously burned if the wok tips over.

Use only at-bottomed woks.

Use medium- or heavy-weight cookware.

Aluminum cookware conducts heat faster

than other metals. Cast-iron and coated

cast-iron cookware are slow to absorb heat,

but generally cook evenly at low to medium

heat settings. Steel pans may cook unevenly

if not combined with other metals.

For best cooking results, pans should be

flat on the bottom. Match the size of the

saucepan to the size of the surface unit.

The pan should not extend over the edge

of the surface unit more than 1 inch.

Not over 1 inch

The following information will help you choose cookware which will give good performance on coil cooktops.

Surface Cookware Tips

Safety Instructions

Operating Instructions

Care and Cleaning

Troubleshooting Tips

Consumer Support

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions

Safety Instructions

A Hot indicator light will glow when any radiant

element is turned on, and will remain on until

the surface is cool enough to touch.

A Burner On indicator light will glow when

any surface unit is on.

NOTE: The Hot indicator light may glow between

the surface control settings of Min and OFF,

but there is no power to the surface units.

Using the surface units.

Throughout this manual, features and appearance may vary from your model.

How to Set

Push the knob in and turn in either direction

to the setting you want.

At both OFF and Max the control clicks into

position. You may hear slight clicking sounds

during cooking, indicating the control is

keeping the power level you set.

Be sure you turn the control knob

to OFF when you cooking.

Indicator Lights (on radiant glass models only)

Safety Instructions

Operating Instructions

Care and Cleaning Troubleshooting Tips

Consumer Support

Control graphics for All models.

Using the oven controls.

NOTE: Throughout this manual, features and appearance may vary from your model.

Features and appearance may vary.

BAKE Pad

BROIL Pad

START Pad

Display

SELF CLEAN Pad

If “F– and a number or letter” flash in the display and

the oven control signals, this indicates a function

error code.Touch the OFF pad. Allow the oven to cool

for one hour. Put the oven back into operation. If the

function error code repeats, disconnect the power to

the oven and call for service.

If your oven was set for a timed oven operation

and a power outage occurredt,he clock and all

programmed functions must be reset.

The time of day will flash in the display when there

has been a power outage.

Touch to select self-cleaning function.

See the Using the self-cleaning oven section.

Touch to select the bake function.

Touch to select the broil function.

Must be touched to start any cooking or

cleaning function.

Shows the time of day, oven temperature,

whether the oven is in the bake, broil or

self-cleaning mode and the times set for

the timer or automatic oven operations.

Oven Control, Clock and Timer Features and Settings

Using the oven controls.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions

Safety Instructions

LIGHT Pad

START TIME Pad

COOK TIME Pad

OFF Pad

CLOCK Pad

Oven Control, Clock and Timer Features and Settings

Fahrenheit° 140 150 170 200 250 275 300 325 350 375 400 425 450 475 500 525 550

Celsius° 60 65 75 95 120 135 150 160 175 190 205 220 230 245 260 275 290

Temperature Conversions

Touch to turn the oven light on or off.

Use along with COOK TIME or CLEAN

pads to set the oven to start and stop

automatically at a time you set.

Touch and then touch the number pads to

set the amount of time you want your food

to cook. The oven will shut off when the

cooking time has run out.

Touch to cancel ALL oven operations

except the clock and timer.

Use to set any function requiring numbers

such as the time of day on the clock, the

timer, the oven temperature, the internal

food temperature, the start time and

length of operation for timed baking

and self-cleaning.ore setting the clock.

Number Pads

Touch before setting the clock.

Touch to select the timer feature.

TIMER Pad

Do not place foods directly on the oven floor.

Ov e n rac k

Fl at r ack

Using the oven. www.GEAppliances.ca

How to Set the Oven for Baking or Roasting

Touch the

BAKE

pad.

Touch the number pads to set

the desired temperature.

Touch the

START

pad.

Check food for doneness at

minimum time on recipe. Cook

longer if necessary.

Touch the

OFF

pad when cooking

is complete.

Type of Food Rack Position

Frozen pies (on cookie sheet) D

Angel food cake A

Bundt or pound cakes B or C

Biscuits, muffins, brownies, C or D

cookies, cupcakes,

layercakes, pies

Casseroles C or D

AyekruT

Safety Instructions Operati ng I ns truc ti ons

Care and Cleaning

Troubl es hooti ng Ti ps

Consumer Support

CAUTION:

Before you begin…

The oven has 5 rack positiones.

It also has a special low rack position (R)

for extra large items,such as a large

turkey.

The racks have stops, so that when placed

correctly on the supports, they will stop

before coming completely out, and will

not tilt.

When placing and removing cookware,

pull the rack out until it stops.

To remove a rack, pull it toward you,

tilt the front end up and pull it out.

To replace, place the end of the rack

(stop-locks) on the support, tilt up the

front and push the rack in.

a rack in the lowest position (A), you will need

to use caution when pulling the rack out. We

recommend that you pull the rack out several

inches and then, using two pot holders, pull the

rack out by holding the sides of it. The rack is low

and you could be burned if you place your hand

in the middle of the rack and pull all the way ou t.

Be very careful not to burn your hand on the do or

when using the rack in the lowest position (A).

When you are using

Baking results will be better if baking

pans are centered in the oven as much

as possible. If baking with more than one

pan, place the pans so each has at least

2.5 cm to 3.8 cm (1” to 11 ⁄ 2”) of air space

around it.

If baking four cake layers at the same time,

place two layers on rack B and two layers on

rack D. Stagger pans on the rack so one is

not directly above the other.

A smaller sheet of foil may be used to

catch a spillover by placing it on a lower

rack several inches below the food.

Aluminum Foil

Do not use aluminum foil on the bottom

of the oven.

Never entirely cover a rack with

aluminum foil. This will disturb the heat

circulation and result in poor baking.

Preheating and Pan Placement

Preheat the oven if the recipe calls for it.

Preheating is necesary for good results

when baking cakes, cookies, pastry and

breads.

To preheat, set the oven at the correct

temperature. The control will beep when

the oven is preheated an the display will

show your set temperature.

The oven has 5 rack positions.

It also has a special low rack position (R)

for extra large items, such as a large

turkey.

Consumer Support Troubleshooting Tips

Care and Cleaning

Operating Instructions

Safety Instructions

Using the oven.

The size, w eight, thickness,

starti ng tem peratu re

and y our preference

of doneness w ill t

broiling times. This guide

is based on meats at

refrig erator temperature.

† The U.S. Department of Agriculture

says “Rare beef is popular, but you

should know that cooking it to only

60°C (140°F) means some food

poisoning organisms may survive.”

(Source: Safe Food Book. Y

our Kitchen

Guide. USDA Rev. June 1985.)

Quantity and/ Rack* First Side Second Side

Food or Thickness Position Time (min.) Time (min.) Comments

Ground Beef 454 g (1 lb.) (4 patties) C 10 7–10 Space evenly.

1.25 to 1.9 cm (

Ú2 to “

“

Ú4 )thick

1.8 kg (4 lbs.) (16 patties) C 15 11

Beef Steaks

Rare† 1.9 to 2.5 cm (

Ú4 to 1”) thick E 6 4 Steaks less than 1.9 cm

Medium 454 to 680 g (1 to 1

Ú2 lbs.) D 8 6 (

Ú4 ) thick are difficult

ot01–701DenoDlleW cook rare.

Slash fat.

Rare† 3.8 cm ”(1

Ú2 ) thick C 10 8

Medium

900 g to 1.14 kg (2 to 2

Ú2 lbs.)

C 15 10–12

0202DenoDlleW

Chicken 1 whole cut up B 25 25 Brush each side with

900 g to 1.14 kg (2 to 2

Ú2 lbs.),

melted butter.

nwod-edis-niksliorBesiwhtgneltilps

Breast B 25 15

Bakery Product

Bread (toast) 2 to 4 slices D 3 1 Space evenly. Place

English

2 (split) E 3-4 English cut-

side-up and brush

with butter if desired.

Lobster Tails fokcabhguorhttuCtonoD02–81B4–2

turn shell. Spread open.

over. Brush with melted

butter before broiling

and after half of

broiling time.

Fish Fillets 450 g (1 lb.) (0.6 to 1.25 cm D 5 5 Handle and turn very

[1/4 to 1/2” htiwhsurB.ylluferac)kciht]

lemon butter before

and during cooking,

if desired.

Salmon

Steaks 2 (2.5 cm [1”] thick) D 10 5 Turn carefully. Do not

Fillets

2(1.25to1.9cm [

Ú2 to “

Ú4 ]thick)

D 10 turn skin side down.

Ham Slices 1.25 cm “(

Ú2 ) thick C 6 6

(precooked) 2.5 cm (1”) thick C 8 8

Pork Chops 2 (1.25 cm “[

Ú2 ] thick) C 10 10 Slash fat.

Well Done

2(2.5cm[1”]thick)about454g(1lb.)

C15 15

Lamb Chops

Medium 2 (2.5 cm [1”] thick) about D 7 4 Slash fat.

Well Done 312 to 375 g (10 to 12 oz.) D 10 9

Medium 2 (3.8 cm [1 “

Ú2 ] thick) D 9 6

Well Done about 454 g (1 lb.) D 14 10

BroilingGuide

How to Set the Oven for Broiling

NOTE: Close the door before start any

broiling function.

Use LO Broil to cook foods such as poultry

or thick cuts of meat thoroughly without

over browning them.

Touch the BROIL HI/LO pad once

for HI Broil.

To change to LO Broil, touch

the BROIL HI/LO pad again.

Touch the START pad.

When broiling is finished, touch

the CLEAR/OFF pad.

Place the meat or fish on a broiler grid

in a broiler pan designed for broiling.

Follow suggested rack positions

in the Broiling Guide.

Safety Instructions Operating Instructions

Care and Cleaning

Troubleshooting Tips

Consumer Support

123

MIN MED MAX

4 5

6 7 8 9 0

123

MIN MED MAX

4 5

6 7 8 9 0

BAKE

CUIRE

COOK TIME

TEMPS DE

CUISSON

START

DÉPART

START

DÉPART

OFF

ARRÊT

123

MIN MED MAX

4 5

6 7 8 9 0

123

MIN MED MAX

4 5

6 7 8 9 0

COOK TIME

TEMPS DE

CUISSON

123

MIN MED MAX

4 5

6 7 8 9 0

BAKE

CUIRE

START

DÉPART

START

DÉPART

OFF

ARRÊT

START TIME

HEURE DE

DÉPART

Using the timed baking and roasting features.

www.GEAppliances.ca

NOTE:

Foods that spoil easily³such as milk, eggs, fish, stuffings, poultry and pork³should not be allowed to sit for

more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure that

the oven light is off because heat from the bulb will speed harmful bacteria growth.

How to Set an Immediate Start and Automatic Stop

The oven will turn on immediately and cook for

a selected length of time. At the end of the

cooking time the oven will turn off automatically.

Tou ch the

BAKE

pad.

Touch the number pads to set the

desired oven temperature.

Tou ch the

COOK TIME

pad.

NOTE:

If your receipe requires preheating,

you may need to add additional time to the

lenght of the cooking time.

Touch the number pads to set the

desired length of cooking time. The

minimum cooking time you can set

is 1 minute.

The oven temperature that you set

and the cooking time that you

entered will be in the display.

Tou ch the

START

pad.

NOTE:

An attention tone will sound if you are using

timed baking and d

not touch the

START

pad

The oven will turn

, and the display will

show the cooking time countdown and the

changing temperature starting at 37.8 °C

(100 °F). (The temperature display will

start to change once the oven temperature

reaches 37.8 °C [100 °F].) When the oven

reaches the temperature you set, 3 beeps

will sound.

The oven will continue to cook for

the set amount of time, then turn off

automatically.

Touch the

OFF

pad to clear the

display if necessary. Remove the

food from the oven. Remember,

even though the oven turns off

automatically, food left in the oven

will continue cooking after the

oven turns off.

How to Set a Delayed Start and Automatic Stop

The oven will turn on at the time of day you set,

cook for a specific lenght of time an then turn off

automatically.

Make sure the clock shows the correct

time of day.

Touch the

BAKE

pad.

Touch the number pads to set the

desired oven temperature.

Touch the

COOKTIME

pad.

NOTE:

If your receipe requires preheating,

you may need to add additional time to

the length of the cooking time.

Touch the number pads to set the

desired length of cooking time. The

minimum cooking time you can set

is 1 minute.

The oven temperaturethat youset

and the cooking time that you

entered will be in the display.

Touch the

START TIME

pad.

Touch the number pads to set the

time of day you want the oven to

turn on and startcooking.

Touch the

START

pad.

NOTE:

timed baking and do not touch the

START

COOK TIME

pad.

NOTE:

If you would like to check the times

you have set, touch the

pad to check the lenght of cooking

time you have set.

pad to START TIME

An attention tone will sound if you are using

When the oven turns

at the time

of dayyou set, the display will show

the cooking time countdown

temperature display

once

and the

changing temperature startin gat 37.8 °C

(100 °F). (The

will startto change the oven

temperature reaches 37.8 °C [100°F].)

When the oven reaches the temperature

you set, beeps will sound.

The oven will continue to cook for

the set amount of time, then turn off

automatically.

Touch the pad to clearthe

displayif necessary. Remove the food

fromthe oven. Remember, even

though the oven turns

automatically, food left in the oven

will continue cooking after the

oven turns .

OFF

off

The warming drawer will keep hot, cooked foods at serving temperature. Always start with hot food. Do not

use to heat cold food other than crisping crackers, chips or dry cereal.

To Use the Warming Drawer

Tou ch the

WARMING DRAWER

pad.

“WARMERON” and “1” are lit on

the display and “Set” begins to blink.

On the number pad, touch

for

Min,

for Med or

for Max.

The display “1” changes

corresponding to the number pad

selected.

The warming drawer starts

automatically after touching

. “WARMERON” and the number

remain lit. “Set” stops blinking.

To cancel, touch the

WARMING DRAWER

pad.

NOTE:

Touching the pad does not turn the

warming drawer off.

OFF

NOTES:

The warming drawer has three settings:

1, 2 and 3. These settings maintain different

temperature levels in the warming drawer.

On some models, if using the oven at the same

time as the warming drawer, only the oven

settings will be displayed.

The warming drawer cannot be used during a

self-cleaning cycle.

WARMING

DRAWER

TIROIR RÉCHAUD

ON / OFF

123

MIN MED MAX

WARMING DRAWER LEVEL

NIVEAU TIROIR RÉCHAUD

Using the warming drawer.

(on some models)

When Using the Warming Drawer

The warming drawer will keep hot,

cooked foods warm. Always start with hot

food. Do not use to heat cold food other

than crisping crackers, chips or dry

cereal.

Do not line the warming drawer or pan

with aluminum foil. Foil is an excellent heat

insulator and will trap heat beneath it. This

will upset the performance of the drawer

and could damage the interior finish.

Allow approximately 25 minutes for the

warming drawer to preheat.

Do not put liquid or water in the

warming drawer.

All foods placed in the warming

drawer should be covered with a lid or

aluminum foil. When warming pastries

or breads, the cover should be vented

to allow moisture to escape.

Food should be kept hot in its cooking

container or transferred to a heat-safe

serving dish.

CAUTION:

Plastic containers or plastic wrap will

melt if in direct contact with the drawer, pan or a

hot utensil. Melted plastic may not be removable

and is not covered under your warranty.

Remove serving spoons, etc., before

placing containers in warming drawer.

Consumer Support Troubleshooting Tips

Care and Cleaning

Operating Instructions

Safety Instructions

Operati ng I ns truc ti ons

Care and Cleaning

Troubl es hooti ng Ti ps

Consumer Support

Temperature Selection Chart

To keep several different foods hot,

set the control to the food needing the

highest setting.

The temperature, type and amount

of food, and the time held will affect

the quality of the food.

Repeated opening of the drawer

allows the hot air to escape and the

food to cool.

With large loads it may be necessary

to use a higher warming drawer setting

and cover some of the cooked food

items.

Do not use plastic containers or

plastic wrap.

CAUTION:

Do not keep food in

the warming drawer for more than two hours.

FoodType Control

Set

ting

3Bacon

1Breads

2Casserole

Chicken, fried 3

3Ham

1Muffins

1Pies

Pizza

Potatoes, baked

1Tortilla Chips

To Crisp Stale Items

Place food in low-sided dishes or pans.

Preheat on

setting.

Check crispness after 45 minutes. Add

time as needed.

To Warm Serving Bowls and Plates

To warm serving bowls and plates, set the

control on

Use onlyheat-safe dishes.

If you want to heat china, please

check with the manufacturerof the

dishes for their maximum heat

tolerance.

You maywarm empty serving dishes

while preheating the drawer.

CAUTION:

Dishes will be hot.

Use pot holders or mitts when removing hot

dishes.

www.GEAppliances.ca

Consumer Support Troub leshooting Tips

Care and Cleaning

Operating Instructions

Safety Instructions

CLOCK

HORLOGE

Make sure the clock is set to the

correct time of day.

TIMER

MINUTERIE

The Timer is a minute timer only.

The Timer does not control oven

operations. The maximum setting on

the Timer is 9 hoursand 59 minutes.

Using the clock, timer and convenience outlet.

To Set the Clock

The clock must be set to the correct time

of day for the automatic oven timing

functions to work properly. The time of

day cannot be changed during a timed

baking or self-cleaning cycle.

Touch the

CLOCK

pad.

Touch the number pads.

Touch the

START

pad.

To Set the Timer

Tou ch the

TIMER

pad.

Touch the number pads until the

amount of time you want shows

in the display. For example, to set

2 hours and 45minutes, touch

and If youmake a

mistake, touch the pad and

begin again.

2, 4

TIMER

5 in that order.

Touch the pad.

START

After touching the

START

pad,

SET

disappears;

this tells you the time is counting down, although

the display does not change until one minute has

passed. Seconds will not be shown in the display

until the last minute is counting down.

When the Timer reaches :00, the

control will beep 3 times followed by

one beep every 6 seconds until the

pad is touched.

The 6-second tone can be canceled by following

the steps in the Special features of your oven

control section under Tones at the End of a

Timed Cycle.

To Reset the Timer

If the display is still showing the time

remaining, you may change it by

touching the

TIMER

pad, then touch

the number pads until the time you

want appears in the display.

If the remaining time is not in the display

(clock, delay start or cooking time are in

the display), recall the remaining time

by touching the

TIMER

pad and then

touching the number pads to enter the

new time you want.

To CanceltheTimer

Touch the

TIMER

pad twi ce.

Convenience Outlet

(on some models)

The 120V convenience outlet located on

the top of the backguard may be used to

plug in small electrical appliances.

When using the outlet, be sure that the

electrical cord does not rest on or near a

surface unit. If the surface unit is turned

on, the cord will be damaged.

To reset the circuit breaker, press the

switch located near the outlet on top of

the backguard.

Safety Instructions Operating Instructions

Care and Cleaning

Troubleshooting Tips

Consumer Support

Using the convection oven.

(on some models)

www.GEAppliances.ca

The convection oven fan shuts off when the oven door is opened. DO NOT leave the door open for long periods of

time while using convection cooking or you may shorten the life of the convection heating element.

To help you understand the difference

between convection bake and roast and

traditi onal bake and roast, here are some

general guidelines.

Convection Bake

Ideal foor evenly browned baked foods cooked

on multiple racks.

Good for large quantities of baked foods.

Good results with cookies, biscuits, brownies,

cupcakes, cream puffs, sweet rolls, angel food

cake and bread.

Heat comes from the heating element in

the rear of the oven. The convection fan

circulates the heated air evenly over and

around the food. Preheating is not

necessary with foods having a bake time

of over 15 minutes.

Convection Roast

Good for large tender cuts of meat, uncovered.

Heat comes from the top heating

element. The convection fan circulates

the heated air evenly over and around

the food. Meat and poultry are browned

on all sides as if they were cooked on a

rotisserie. The heated air seals in juices

quicklyfor amoist and tender product

while,atthesametime,creatingarich

golden brown exterior.

When you are convection roasting, it is

important that you use a broiler pan and

grid designed for broiling for best

convection roasting results. The pan is

used to catch grease spills and the grid is

used to prevent grease spatters.

In a convection oven, a fan

circulates hot air over, under and

around the food. This circulating

hot air is evenly distributed

throughout the oven cavity. As a

result, foods are evenly cooked and

browned - often in less time than

with regular heat.

Adapting Recipes…

Youcanuseyourfavoriterecipes

in the convection oven.

Use pan size recommended.

Some package instructions for frozen

casseroles or main dishes have been

developed using commercial convection

ovens. For best results in this oven,

preheat the oven and use the

temperature on the package.

Cookware for Convection Cooking

Before using your convection oven, check

to see if your cookware leaves room for air

circulation in the oven. If you are baking

with several pans, leave space between

them. Also, be sure the pans do not touch

each other or the walls of the oven.

Heat-resistant paper and plastic

containers that arerecommended

for use in regular ovens can be used in

convection ovens. Plastic cookware that

is heat-resistant to temperatures of

205°C (400°F) can also be used, when

oven is below 205°C (400°F).

Paper

flat

and Plastic

Metaland Glass

Any type of cookware will work in your

convection oven. However, metal pans

heat the fastestand arerecommended

for convection baking.

Darkened on matte-finished pans will bake

faster than shiny pans.

Glass or ceramic pans cook more slowly.

When baking cookies, you will get the

best results if you use a cookie sheet

instead of a pan with low sides.

For recipes like oven-baked chicken,

use apanwith low sides.Hot air cannot

circulatewell around food in apanwith

high sides.

Because heated air is circulated evenly

throughout the oven, foods can be baked

with excellent results using multiple racks.

Multi-rack baking may increase cook times

slightly for some foods but the overall result

is time saved. Cookies, muffins, biscuits and

other quickbreads give very good results

with multi-rack baking.

When baking on 3 racks, place one

rack in the second (B) position, another rack

in the fourth (D) position and the third rack

in the sixth (F) position.

For two-rack baking, place one rack

in the second (B) rack position. Place

the other rack in the fifth (E) rack position.

Multi-Rack Convection Baking (on precise air convection models)

Multi-rack position.

When convection baking with only 1 rack,

place the food so that it is centered with

oven convection fan.

1-Rack Convection Baking

Consumer Support Troubleshooting Tips

Care and Cleaning Opera ti ng I ns truc ti ons

Safety Instructions

Using the convection oven.

Touch the CONVECTION BAKE

pad once for multi-rack convection

baking. This mode is used for cooking

food items on more than one rack

(i.e., 2, 3 or more racks) at the same

time in convection bake.

See the Multi-Rack Convection Baking

section for more information.

Touch the

CONVECTION BAKE

pad

twice for one-rack convection baking.

This mode is used for cooking food

items on only one rack in convection

bake.

Touch the CONVECTION ROAST pad

for convection roasting (on some

models).

Touch the number pads to set

the oven temperature.

Touch the START pad.

NOTE: If the Auto Recipe

™

Conversion

Feature is on, it will automatically reduce

the set regular baking temperature by

13.9°C (25°F) to the appropriate convection

temperature in convection bake mode.

See Auto Recipe

™

Conversion in the Special

Features section.

To change the oven temperature, touch

the CONVECTION BAKE or CONVECTION

ROAST pad and then the number pads

to set the new temperature.

When the oven starts to heat, the changing

temperature, starting at 37.8°C (100°F),

will be displayed. When oven reaches the

temperature you set, 3 beeps will sound.

Touch CLEAR/OFF pad when finished.

Youwillhearafanwhilecooking

with convection. The fan will stop when

the door is opened, but the heat will not

turn off.

You may hear the oven clicking during

baking. This is normal.

In convection bake modes, for maximum

cooking evenness, the fan is designed

to rotate in both directions, with a pause

in between. This is normal.

How to Set the Oven for Convection Baking or Roasting

Conversion de recettes

Convection

Auto Recipe Conversion

Bake

Cuire

Roast

Rôtir

Control Lockout

1 2 3

9 0

Start

Départ

Off

Arrêt

(On some models)

On some models

NOTE: For Airflow convection models Multi-

Rack Convection feature is disabled. Touch

the AIRFLOW CONVECTION BAKE pad

for one-rack convection baking.

Conversion de recettes

Airflow Convection

Auto Recipe Conversion

Bake

Cuire

Roast

Rôtir

You will hear a fan while cooking with these features. The fan will stop when the door is opened, but the heat

will not turn off.

NOTE: Foods that spoil easily―such as milk, eggs, fish, stuffings, poultry and pork―should not be allowed to

sit for more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria.

Be sure that the oven light is off because heat from the bulb will speed harmful bacteria growth.

How to Set an Immediate Start and Automatic Stop

Press desired convection function. Proceed to

step 2 of How to Set an Immediate Start and

Automatic Stop in Using the timed baking and

roasting features section.

How to Set a Delayed Start and Automatic Stop

Press desired convection function. Proceed to

step 2 of How to Set a Delay Start and

Automatic Stop in Using the timed baking and

roasting features section.

You will hear a fan while cooking with these features. The fan will stop when the door is opened, but the heat

will not turn off.

NOTE: Foods that spoil easily―such as milk, eggs, fish, stuffings, poultry and pork―should not be allowed to

sit for more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria.

Be sure that the oven light is off because heat from the bulb will speed harmful bacteria growth.

How

Using the timed features for convection baking.

to Set an Immediate Start and Automatic Stop

Press desired convection function. Proceed to

step 2 of How to Set an Immediate Start and

Automatic Stop in Using the timed baking and

roasting features section.

How to Set a Delayed Start and Automatic Stop

Press desired convection function. Proceed to

step 2 of How to Set a Delay Start and

Automatic Stop in Using the timed baking and

roasting features section.

Conversion de recettes

Convection

Auto Recipe Conversion

Bake

Cuire

Roast

Rôtir

Conversion de recettes

Convection

Auto Recipe Conversion

Bake

Cuire

Roast

Rôtir

Safety Instructions

Operati ng I ns truc ti ons

Care and Cleaning

Troubl es hooti ng Ti ps

Consumer Support

BAKE

CUIRE

BAKE

CUIRE

123

MIN MED MAX

4 5

6 7 8 9 0

START

DÉPART

START

DÉPART

BROIL

GRIL

BAKE

CUIRE

You may find that your new oven cooks differently than the one it replaced. Use your new oven for a few weeks to become more

familiar with it. If you still think your new oven is too hot or too cold, you can adjust the thermostat yourself.

Do not use thermometers, such as those found in grocery stores, to check the temperature setting of your oven. These

thermometers may vary 6–11 degrees Celsius (20–40 degrees Fahrenheit).

NOTE:

This adjustment will only affect baking and roasting temperatures; it will not affect broiling or self-cleaning temperatures.

The adjustment will be retained in memory after a power failure.

To Adjust the Thermostat

Tou ch the

BAKE

and

BROIL

pads at

thesametimefor3secondsuntil

the display shows

SF.

Tou ch the

BAKE

pad. A two digit

number shows in the display.

Tou ch

BAKE

again to alternate

between increasing and decreasing

the oven temperature.

The oven temperature can be

adjusted up to (+) 19°C (35ºF)

hotter or (-) 19°C (35ºF) cooler.

Touch the number pads the same

way you read them. For example, to

change the oven temperature 12°C

(15ºF), touch

and

When you have made the

adjustment, touch the

START

pad to

go back to the time of day display.

Use your oven as you would normally.

The type of margarine will affect baking performance.

Most recipes for baking have been developed using high fat products such as butter or margarine (80% fat). If you decrease the

fat, the recipe may not give the same results as with a higher fat product.

Recipe failure can result if cakes, pies, pastries, cookies or candies are made with low fat spreads. The lower the fat content of a

spread product, the more noticeable these differences become.

Federal standards require products labeled “margarine” to contain at least 80% fat by weight. Low fat spreads, on the other hand,

contain less fat and more water. The high moisture content of these spreads affects the texture and flavor of baked goods. For best

results with your old favorite recipes, use margarine, butter or stick spreads containing at least 70% vegetable oil.

Consumer Support Troubleshooting Tips

Care and Cleaning

Operating Instructions

Safety Instructions

OperatingInstructions

Care andCleaning TroubleshootingTips

ConsumerSupport

www.GEAppliances.ca

START

DÉPART

START

DÉPART

TIMER

MINUTERIE

PROOF

FERMENTATION

OFF

ARRÊT

Using the proofing feature.

(on some models)

The proofing feature maintains a warm environment useful for rising yeast-leavened products.

How to Set the Oven For Proofing

(on some models)

Place the covered dough in a dish

in the oven on rack B or C.

NOTE:

For best results, cover the dough with a

cloth or with greased plastic wrap (the plastic

may need to be anchored underneath the

container so the oven fan will not blow it off).

Touch the

PROOF

pad and then

the

START

pad.

The display will read

PrF

(proof).

The oven interior light turns on and

remains on during proofing.

The proofing feature automatically

provides the optimum temperature for

the proofing process, and therefore

does not have a temperature adjustment.

Set the

TIMER

for the minimum

proof time.

When proofing is finished, touch

the

OFF

pad.

To avoid lowering the oven temperature and

lengthening proofing time, do not open the

oven door unnecessarily.

Check bread products early to avoid

over-proofing.

NOTE:

Do not use the proofing mode for warming

food or keeping food hot. The proofing oven

temperature is not hot enough to hold foods

at safe temperatures. Use the WARM feature

to keep food warm.

Proofing will not operate when oven is above

52°C (125°F). “HOT” will show in the display.

ConsumerSupport TroubleshootingTips

Care andCleaning OperatingInstructions

Safety Instructions

123

MIN MED MAX

4 5

6 7 8 9 0

START

DÉPART

START

DÉPART

CLEAN

NETTOYAGE

Wipe up heavy soil on the oven

bottom.

Using theself-cleaning oven.

The oven door must be closed and all controls set correctly for the cycle to work properly.

Before a Clean Cycle

We recommend venting your kitchen

with an open window or using a

ventilation fan or hood during the

first self-clean cycle.

Remove broiler pan, broiler grid,

all cookware and any aluminum foil

from the oven.

NOTE:

If your oven is equipped with gray

porcelain-coated oven racks, they may be

left in the oven during the self-clean

cycle.

Soil on the front frame of the range and

outside the gasket on the door will need

to be cleaned by hand. Clean these areas

with hot water, soap-filled steel-wool pads

or cleansers such as Soft Scrub

. Rinse

well with clean water and dry.

Do not clean the gasket. The fiberglass

material of the oven door gasket cannot

withstand abrasion. It is essential for the

gasket to remain intact. If you notice it

becoming worn or frayed, replace it.

Wipe up any heavy spillovers on the

oven bottom.

Make sure the oven light bulb cover is

in place and the oven light is off.

IMPORTANT:

The health of some birds is

extremely sensitive to the fumes given off

during the self-cleaning cycle of any range.

Move birds to another well - ventilated room.

How to Set the Oven for Cleaning

WARNING:

The surface

units are automatically disabled during

the self-clean cycle. Make sure that all

surface unit controls are turned off at all

times during the self-clean cycle. Any

surface unit that is set to an on position,

while the self-clean cycle is operating, will

automatically come on after the self-clean

cycle is finished, and could result in an

on, unattended surface unit. Wait until

the self-clean cycle is finished to set and

use the surface units.

Touch the

CLEAN

pad.

Using the number pads, enter the

desired clean time, if a time other

than 4 hours, 20 minutes is needed.

Clean cycle time is normally 4 hours, 30

minutes. You can change the clean time

to any time between 3 hours and 5 hours,

depending on how dirty your oven is.

Touch the

START

pad.

The door locks automatically. The display

will show the clean time remaining. It will

not be possible to open the oven door

until the temperature drops below the

lock temperature and the

LOCKED

light

goes off.

When the

LOCKED

light goes off, you will

be able to open the door.

The words

LOCK DOOR

will flash if you

set the clean cycle and forget to close

the oven door.

To stop a clean cycle, touch the

OFF

pad. When the

LOCKED

light goes off,

indicating the oven has cooled below

the locking temperature, you

will be able to open the door.

123

MIN MED MAX

4 5

6 7 8 9 0

CLEAN

NETTOYAGE

123

MIN MED MAX

4 5

6 7 8 9 0

START

DÉPART

START

DÉPART

START TIME

HEURE DE

DÉPART

Safety Instructions Operating Instructions Care and Cleaning

Troubles hooti ng Ti ps Consumer Support

www.GEAppliances.ca

How to Delay the Start of Cleaning

Tou ch

the

CLEAN

pad.

Using the number pads, enter the

desired clean time, if a time other

than 4 hours, 20 minutes is needed.

You can change the clean time to any

time between 3 hours and 5 hours,

depending on how dirty your oven is.

Touch the

START TIME

pad.

Using the number pads, enter the

time of day you want the clean cycle

to start.

Touch the

START

pad.

The door locks automatically. The display

will show the start time. It will not be

possible to open the oven door until

the temperature drops below the lock

temperature and the

LOCKED

light

goes off.

When the

LOCKED

light goes off, you

will be able to open the door.

After a Clean Cycle

You may notice some white ash in the

oven. Wipe it up with a damp cloth after

the oven cools.

If white spots remain, remove them

with a soap-filled steel wool pad and rinse

thoroughly with a vinegar and water

mixture.

These deposits are usually a salt residue

that cannot be removed by the clean

cycle.

If the oven is not clean after one clean

cycle, repeat the cycle.

You cannot set the oven for cooking or another

self-clean cycle until the oven is cool enough

for the door to unlock.

While the oven is self-cleaning, you can touch

the

CLOCK

pad to display the time of day.

To return to the clean countdown, touch the

COOK TIME

pad.

If the racks become hard to slide, apply a small

amount of cooking oil to a paper towel and

wipe the edges of the oven racks with the

paper towel.

Consumer Support Troubleshooting Tips

Care and Cleaning

Operating Instructions

Safety Instructions

START

DÉPART

START

DÉPART

BROIL

GRIL

BAKE

CUIRE

START TIME

HEURE DE

DÉPART

BROIL

GRIL

START

DÉPART

START

DÉPART

BAKE

CUIRE

TIMER

MINUTERIE

Special features of your oven control.

Your new touch pad control has additional features that you may choose to use. The following are the features

and how you may activate them.

The special feature modes can only be activated while the display is showing the time of day. They remain in the

control’s memory until the steps are repeated.

When the display shows your choice, touch the START pad. The special features will remain in memory after

a power failure, except for the Sabbath feature, which will have to be reset.

12-Hour Shutdown

With this feature, should you forget and leave the

oven on, the control will automatically tyrn off

the oven after 12 hours during baking functions

of after 3 hours during a broil function.

If you wish to turn

OFF

this feature,

follow the steps below.

Touch the

BROIL

and

BAKE

pads

at the same time for 3 seconds until

the display shows

SF.

Touch the

START TIME

pad until

no shdn

(no shut-off) appears in the

display.

Touch the

START

pad to activate

the no shut-off and leave the control

set in this special features mode.

Fahrenheit or Celsius Temperature Selection

Your oven control is set to use the Fahrenheit

temperature selections but you may change this

to use the Celsious selections.

Touch the

BROIL

and

BAKE

pads

at the same time for 3 seconds until

the display shows

SF.

Touch the

BROIL

and

COOK TIME

pads. The display will show

(Fahrenheit).

Touch the

BROIL

and

COOK TIME

pads again. The display will show

(Celsius).

Touch the

START

pad.

Tones at the End of a Timed Cycle

At the end of a timed cycle, 3 short beeps will

sound followed by one beep every 6 seconds

until the

OFF

pad is touched. This continual

6-second beep may be canceled.

To cancel the 6-second beep:

Touch the

BROIL

and

BAKE

pads

at the same time for 3 seconds until

the display shows

SF.

Touch the

TIMER

pad. The display

shows

CON BEEP

(continuous beep).

Touch the

TIMER

pad again. The

display shows

BEEP.

(This cancels the

one beep every 6 seconds.)

Touch the

START

pad.

9 0

OVEN LOCKOUT

VERROUILLAGE FOUR

Oven Lockout

Your control will allow you to lock out the touch

pads so they cannot be activated when touched.

To activatethis feature:

Touch the

and

pads at the same

time for 5 seconds until the control

beeps twice. The display will show

LOC

continuously and the time of

day, if not blacked out.

NOTE:

All cooking and timing functions will be

cancelled when locking out the control.

To unlock the control, touch the

and

pads at the same time for

5 seconds until the control beeps

twice and

LOC

is removed from

the display.

Safety Instructions Operati ng I ns truc ti ons

Care and Cleaning

Troubl es hooti ng Ti ps

Consumer Support

START

DÉPART

START

DÉPART

BROIL

GRIL

BAKE

CUIRE

CLOCK

HORLOGE

www.GEAppliances.ca

12-Hour, 24-Hour or Clock Blackout

Your control is set to use a 12-hour clock.

If you would prefer to have a 24-hour

military time clock or black out the clock

display, follow the steps below.

Tou ch the

BROIL

and

BAKE

pads

atthesametimefor3secondsuntil

the display shows

SF.

Tou ch the

CLOCK

pad once. The

display will show

12 hr.

If this is

the choice you want, touch the

START

pad.

Touch the

CLOCK

pad again to

change to the 24 hour military time

clock. The display will show

24 hr.

If this is the choice you want, touch

the

START

pad.

Touch the

CLOCK

pad again to black

out the clock display. The display will

show

OFF.

If this is the choice you

want, touch the

START

pad.

NOTE:

If the clock is in the black-out mode you

will not be able to use the Start Time function.

Auto Recipe

™

Conversion (on some models)

When using convection bake, the

Auto Recipe™ Conversion feature will

automatically convert entered regular

baking temperatures to convection baking

temperatures.

This feature is activated so that the display

will show the actual converted (reduced)

temperature. For example, if you enter

a regular recipe temperature of 176.7°C

(350°F) and touch the START pad, the

display will show CON and the converted

temperature of 162.8°C (325°F).

To deactivate the feature:

Touch the upper oven BAKE and

BROIL HI/LO pads at the same time

until the display shows SF.

Touch the CONVECTION BAKE pad.

The display will show CON ON. Touch

the CONVECTION BAKE pad again.

The display will show CON OFF.

Touch the START pad.

To reactivate the feature, repeat steps

1–3 above but touch the START pad when

CON ON is in the display.

Bake

Cuire

Broil

Griller

Bake

Cuire

Start

Départ

START

DÉPART

START

DÉPART

START

DÉPART

START

DÉPART

BROIL

GRIL

BAKE

CUIRE

BAKE

CUIRE

123

MIN MED MAX

4 5

6 7 8 9 0

START TIME

HEURE DE

DÉPART

ConsumerSupport TroubleshootingTips

Care andCleaning OperatingInstructions

Safety Instructions

Using the Sabbath feature. (on some models)

(Designed for use on the Jewish Sabbath and Holidays)

Touch the

START

pad.

After a random delay period of

approximately 30 seconds to

1 minute, ⊃

⊃

will appear in the

display indicating that the oven is

baking/ roasting. If ⊃

⊃

doesn’t

appear in the display, start again

at Step 4.

To adjust the oven temperature, touch

the BAKE pad, enter the new temperature

using the number pads and touch the

START pad.

NOTE: The OFF and COOK TIME pads are active

during the Sabbath feature.

Touch and hold both the BROIL and

BAKE pads, at the same time, until the

display shows SF.

NOTE: If bake or broil appears in the

display, the BROIL and BAKE pads were

not touched at the same time. Touch the

OFF pad and begin again.

Tap the START TIME pad until

SAb bAtH appears in the display.

Touch the START pad and ⊃ will

appear in the display.

Touch the BAKE pad. No signal

will be given.

Using the number pads, enter the

desired temperature between 77°C

(170°F) and 288°C (550°F). No

signal or temperature will be given.

How to Set for Regular Baking/Roasting

Make sure the clock shows the correct time

of day and the oven is off.

The Sabbath feature can be used for baking/roasting only. It cannot be used for convection, broiling, self-cleaning or

Delay Start cooking.

NOTE: The oven light comes on automatically (on some models) when the door is opened and goes off when the

door is closed. The bulb may be removed. See the Oven Light Replacement section. On models with a light switch

on the control panel, the oven light may be turned on and left on.

When the display shows ⊃ the

oven is set in Sabbath. When the

display shows ⊃

⊃

the oven is

baking/roasting.

Safety Instructions Operating Instructions

Care and Cleaning

Troubleshooting Tips

Consumer Support

START

DÉPART

START

DÉPART

BROIL

GRIL

BAKE

CUIRE

123

MIN MED MAX

4 5

6 7 8 9 0

START

DÉPART

START

DÉPART

START

DÉPART

START

DÉPART

BAKE

CUIRE

123

MIN MED MAX

4 5

6 7 8 9 0

START TIME

HEURE DE

DÉPART

COOK TIME

TEMPS DE

CUISSON

START

DÉPART

START

DÉPART

BROIL

GRIL

BAKE

CUIRE

START TIME

HEURE DE

DÉPART

OFF

ARRÊT

When the displayshows the

ovenis set in Sabbath.When the

displayshows the ovenis

baking/roasting.

www.GEAppliances.ca

How to Set for Timed %DNLQJ5RDVWLQJ³,PPHGLDWH Start and Automatic Stop

Make sure the clock shows the correct time

of day and the oven is off.

Touch

If bake or broil appears inthe

display, the BROIL and BAKE pads were

not touched at the same time. Touch the

OFF pad and begin again.

and hold

both

the

BRO,/

BAKE

pads,

at the same time

until the

display shows

SF.

NOTE:

Tap the pad until

appears in the display.

SAb bAtH

67$577,0(

Touch the

START

pad and will

app ear in the display.

Touch the

COOK T,0E

pad.

Touch the number pads to set the

desired length of cooking time

between 1 minute and 9 hours and

99 minutes. The cooking time that

you entered will be displayed.

Touch the

START

pad.

Touch the

BAKE

pad. No signal will

be given.

Using the number pads, enter the

desired temperature. No signal or

temperature will be given.

Touch the

START

pad.

To adjust the oven temperature, touch

the

BAKE

pad, enter the new temperature

using the number pads and touch the

START

pad.

How to Exit the Sabbath Feature

Touch the

OFF

pad.

If the oven is cooking, wait for

a random delay period of

approximately 30 seconds to

1minute, until only is in the

display

Touch and hold

both

the

BRO,/

and

BAKE

pads,

atthe same time

until the

display shows

SF.

Tap the

START T,0E

pad until

12 shdn

no shdn

appears in the

display.

Choose 12 shdn, indicating that the

oven will automatically turn off after

12 hours or no shdn, indicating that

the oven will not automatically turn

off after 12 hours.

Press START when the option that

you want is in the display ( 12 shdn or

no shdn).

NOTE:

If a power outage ocurred while the oven

was in Sabbath, the oven will automatically

turn off and stay off even when the power returns.

The oven control must be reset.

After a random delay period of

approximately 30 seconds to 1

minute,

will appear in the

display indicating that the oven is

baking/roasting. If doesn’t

appear in the display, start again at

Step 7.

When cooking is finished, the display

will change from

to and 0:00

will appear, indicating that the oven

has turned OFF but is still set in Sabbath.

Remove the cooked food.

With proper care, the porcelain enamel finish

on the inside of the oven―top, bottom, sides,

back and inside of the door―will stay new-

looking for years.

Let the range cool before cleaning.

We recommend that you wear rubber

gloves when cleaning the range.

Soap and water will normally do the job.

Heavy spattering or spillovers may require

cleaning with a mild abrasive cleaner.

Soap-filled scouring pads may also be used.

Do not allow food spills with a high

sugar or acid content (such as milk,

tomatoes, sauerkraut, fruit juices or

pie filling) to remain on the surface. They may

cause a dull spot even after cleaning.

Household ammonia may make the cleaning

job easier. Place 1/2 cup in a shallow glass or

pottery container in a cold oven overnight.

The ammonia fumes will help loosen

the burned-on grease and food.

If necessary, you may use an oven cleaner.

Follow the package directions.

Do not spray oven cleaner on the electrical

controls and switches because it could cause

a short circuit and result in sparking or fire.

Do not allow a film from the cleaner to build

up on the temperature sensor―it could cause

the oven to heat improperly. (The sensor is

located at the top of the oven.) Carefully wipe

the sensor clean after each oven cleaning,

being careful not to move the sensor as

a change in its position could affect how

the oven bakes.

Do not spray any oven cleaner on the oven

door, handles or any exterior surface of

the oven, cabinets or painted surfaces.

The cleaner can damage these surfaces.

Oven Interior (non-self-clean models)

If your range is removed for cleaning,

servicing or any reason, be sure the

anti-tip device is re-engaged properly

when the range is replaced. Failure

to take this precaution could result in

tipping of the range and cause injury.

Be sure electrical power is off and all surfaces are cool before cleaning any part of the range.

Care and cleaning of the range.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions

Safety Instructions

The gasket is designed with a gap at the

bottom to allow for proper air circulation.

Do not rub or clean the door gasket—it has

an extremely low resistance to abrasion.

If you notice the gasket becoming worn,

frayed or damaged in any way or if it has

become displaced on the door, you should

have it replaced.

To clean the inside of the door:

Because the area inside the gasket is

cleaned during the self-clean cycle,

you do not need to clean this by hand.

The area outside the gasket and the door

liner can be cleaned with a soap-filled

or plastic scouring pad, hot water and

detergent. Rinse well with a vinegar

and water solution.

To clean the outside of the door:

Use soap and water to thoroughly clean the

top, sides and front of the oven door. Rinse

well. You may also use a glass cleaner to

clean the glass on the outside of the door.

Do not let water drip into the vent openings.

If any stain on the door vent trim is

persistent, use a soft abrasive cleaner

and a sponge-scrubber for best results.

Spillage of marinades, fruit juices, tomato

sauces and basting materials containing

acids may cause discoloration and should

be wiped up immediately. When surface is

cool, clean and rinse.

Do not use oven cleaners, cleaning powders

or harsh abrasives on the outside of the door.

Cleaning the Oven Door

Hinge

lock

Slot

GEAppliances.ca

Operating Instructions

Care and Cleaning Troubleshooting Tips

Consumer Support

The door is very heavy. Be careful when

removing and lifting the door.

Do not lift the door by the handle.

To remove the door:

Fully open the door.

Pull the hinge locks down toward the door

frame, to the unlocked position. A tool,

such as a small flat-blade screwdriver,

may be required.

Firmly grasp both sides of the door

at the top.

Close door to the door removal position,

which is halfway between the broil stop

position and fully closed.

Lift door up and out until the hinge arm

is clear of the slot.

To replace the door:

Firmly grasp both sides of the door

at the top.

With the

door at the

same angle

as the removal

position, seat the

indentation of the

hinge arm into the

bottom edge of the

the slot.

Fully open the door. If the door will not

fully open, the indentation is not seated

correctly in the bottom edge of the slot.

Lift-Off Oven Door (on some models)

Hinge

lock

Indentation

edge of

slot

Push hinge locks up to lock.

Hinge arm

Hinge

arm

Close the oven door.

Push the hinge locks up against the front

frame of the oven cavity to the locked

position.

hinge slot. The notch in the hinge arm

must be fully seated into the bottom of

Bottom

S ety nstructio saf I n

Pull hinge locks down to unlock.

Removal position

The oven door is removable for cleaning.

Do not lift the door by the handle. Make sure

the oven is completely cool.

To remove the door, open it to the special

stop position. Grasp firmly on each side and

lift the door straight up and off the hinges.

Do not place hands between the hinge

and the oven door frame.

To replace the door, make sure the hinges

are in the special stop position. Position

the slots in the bottom of the door squarely

over the hinges and slowly lower it over both

hinges.

To clean the inside of the door:

Do not allow excess water to run into

Lift the door straight up and o

the hinges.

Lift-Off Oven Door for JCBS250 model

GEAppliances.ca

CAUTION:Before

replacing your oven light bulb, turn the oven

light off and disconnect the electrical power

to the range at the main fuse or circuit

breaker panel.

Be sure to let the light cover and bulb cool

completely.

To remove the cover:

Hold a hand under the cover so it

doesn’t fall when released. With fingers

of the same hand, firmly push back

the wire cover holder. Lift off the cover.

Do not remove any screws to remove

the cover.

Replacebulbwitha40-watthousehold

appliance bulb.

To replace the cover:

Place it into groove of the lig

receptacle. Pull wire forward

the center of the cover until i

tsnaps

into place.

Connect electrical power to

the range.

Wire cover holder

Oven Light Replacement (on some models)

It will be necessary to grease all oven

rack side edges with a light coating of

vegetable oil after cleaning them by hand or

in the oven This will help maintain the ease or

sliding the racks in and out of the oven.

Oven Racks

Heating Elements

On some models, the bake element is not

exposed and is under the oven floor. If spillover

residue or ash accumulate on the oven floor,

wipe up before self-cleaning.

Oven rack

Pull the drawer out all the way.

Tilt up the front and remove it.

Insert glides at the back of the drawer

beyond the stop on range glides

Lift the drawer if necessary to insert

easily.

Let the front of the drawer d

own; then

push in to close.

Clean under the range.

Storage Drawer Removal (on some models)

Care and cleaning of the range.

Consumer Support

Troubleshooting Tips Care and Cleaning

Operating Instructions Safety Instructions

Do not clean the bake element or the broil

element. Any soil will burn off when the

elements are heated.

To clean the oven floor, gently lift

the bake element Clean with warm

soapy water.

Oven

To remove the storage drawer: To replace the storage drawer:

(on some models)

All oven racksmaybe cleaned byhand with an

abrasive cleaner or steel wool After cleaning,

rinse the racks with lean water and drywith a

clean cloth Gray porcelain-coated oven racks

may remain in the oven during the self-cleaning

cycle without being damaged. The shiny,

silver-colored oven racks may remain in the oven

during the self-cleaning cycle, but they will lose

their luster and become hard to slide.

GEAppliances.ca

Be sure all the controls are turned to OFF and

the surface units are cool before attempting

to remove them.

To clean the surface units, turn the control to

the highest setting for a minute. The coils will

burn off any soil.

To remove a surface unit:

To remove the drip pans for cleaning,

the surface units must be removed first.

Lift the surface unit about 1 inch above

the drip pan and pull it out.

Do not lift the surface unit more than 1". If you

do, it may not lie flat on the drip pan when

you plug it back in.

Repeated lifting of the surface unit more than

1 inch above the drip pan can permanently

damage the receptacle.

To replace a surface unit:

Replace the drip pan into the recess

in the cooktop. Make sure the opening

in the pan lines up with the receptacle.

Insert the terminals of the surface unit

through the opening in the drip pan and

into the receptacle.

Guide the surface unit into place so it rests

evenly.

Do not immerse the surface units

in liquids of any kind.

Do not clean the surface units

in a dishwasher.

Do not bend the surface unit plug

terminals.

Do not attempt to clean, adjust

or in any way repair the plug-in

receptacle.

Be sure all surface units are turned o

before raising the cooktop.

Some models have a cooktop that can

be lifted up for easier cleaning. The entire

cooktop may be lifted up and supported

in the up position.

The surface units do not need to be removed;

however, you may remove one to make

raising the cooktop easier. There are two

side supports that lock into position when

the cooktop is lifted up.

After cleaning under the cooktop with hot,

mild soapy water and a clean cloth, lower the

cooktop. Be careful not to pinch your fingers.

To lower the cooktop, push the rods back

and gently lower the cooktop until it rests

in place.

NOTE: Do not lift the cooktop on radiant top

models. Lifting the cooktop can lead to

damage and improper operation of the range.

The porcelain enamel finish is sturdy

but breakable if misused. This finish is

acid-resistant. However, any acidic foods

spilled (such as fruit juices, tomato or vinegar)

should not be permitted to remain on the

finish.

If acids spill on the cooktop while it is hot, use

a dry paper towel or cloth to wipe it up right

away. When the surface has cooled, wash

with soap and water. Rinse well.

For other spills such as fat spatterings, wash

with soap and water or cleansing powders

after the surface has cooled. Rinse well. Polish

with a dry cloth.

Porcelain Enamel Cooktop (on radiant models)

Surface unit

Drip pan

Receptacle

Remove the surface units. Then lift out

the drip pans.

Place them in a covered container. Add

1/4 cup ammonia and let soak several hours

or overnight. Wash, rinse well and dry.

The drip pans may also be cleaned

in the dishwasher.

Clean the area under the drip pans often.

Built-up soil, especially grease, may catch fire.

Do not cover the drip pans with foil. Using foil

so close to the receptacle could cause shock,

fire or damage to the range.

NOTE: Do not clean the drip pans

in a self-cleaning oven.

Drip Pans (on coil models)

Surface Units (on coil models)

Lift-Up Cooktop (on coil models)

Safety Instructions

Operating Instructions Care and Cleaning

Troubleshooting Tips

Consumer Support

Care and cleaning of the range.

Painted surfaces include the sides of the

range and the sides of the door trim.

To clean the painted surfaces, use a hot,

damp cloth with a mild detergent suitable for

these surfaces. Use a clean, hot, damp cloth

to remove soap. Dry with a dry, clean cloth.

Do not use steel-wood pads, commercial

oven cleaners, cleaning powders or other

abrasive cleaners. They will damage

the surface.

Painted Surfaces (on some models)

On glass cooktop models, the oven is vented

through an opening at the rear of the

cooktop.

On coil cooktop models, the oven is vented

through an opening under the right rear

surface unit.

Never cover the opening with aluminum foil

or any other material.

Oven Vent (on coil models)

To clean the outside glass finish, use a glass

cleaner. Rinse and polish with a dry cloth.

Glass Window (on some models)

Do not use a steel wool pad; it will scratch

the surface.

To clean the stainless steel surface,

use warm sudsy water or a stainless steel

cleaner or polish. Always wipe the surface

in the direction of the grain. Follow the

cleaner instructions for cleaning the stainless

steel surface.

To inquire about purchasing stainless

steel appliance cleaner or polish, or to find

the location of a dealer or Mabe Canada

Parts Store nearest you, please call our

toll-free number:

National Parts Center 1.800.661.1616

www.GEAppliances.ca

Stainless Steel Surfaces (on some models)

Consumer Support

Troubleshooting Tips

Care and Cleaning

Operating Instructions Safety Instructions

BOWL AND COIL ASSEMBLY (on coil models)

In order to do a right assembly of the bowl and

the coil into the cook top you need to insert both

components together as shown in the picture.

Avoid inserting components sparely, this will

cause wrong assemble issues.

Attention (on coil models)

When using the oven is normal to have an increase

of temperature on the cooktop surface, based on

the fact that the release of heat from the oven is

placed on the back right burner/coil of the range.

The Ceramic Cooktop Scraper and

all recommended supplies are

available through our dealers or

through a Mabe Canada Parts Store.

NOTE: Do not use a dull or nicked blade.

Use a Cleaning Pad for Ceramic

Cooktops.

Clean your cooktop after each spill.

Use Ceramic Cooktop Cleaner.

WARNING: DAMAGE to your

glass surface may occur if you use scrub

pads other than those recommended.

Allow the cooktop to cool.

Spread a few drops of Ceramic

Cooktop Cleaner on the entire burned

residue area.

Using the included Cleaning Pad for

Ceramic Cooktops, rub the residue

area, applying pressure as needed.

If any residue remains, repeat

the steps listed above as needed.

For additional protection, after all

residue has been removed, polish

the entire surface with Ceramic

Cooktop Cleaner and a paper towel.

Cleaning the glass cooktop. (on radiant models) GEAppliances.ca

Normal Daily Use Cleaning

ONLY use Ceramic Cooktop Cleaner on

the glass cooktop. Other types of cleaners

may not be as effective.

To maintain and protect the surface of

your glass cooktop, follow these steps:

Before using the cooktop for the

first time, clean it with Ceramic

Cooktop Cleaner. This helps protect

the top and makes cleanup easier.

Daily use of Ceramic Cooktop Cleaner

will help keep the cooktop looking

new.

Shake the cleaning cream well.

Apply a few drops of Ceramic Cooktop

Cleaner directly to the cooktop.

Use a paper towel for Ceramic

Cooktops to clean the entire cooktop

surface.

Use a dry cloth or paper towel

to remove all cleaning residue.

No need to rinse.

NOTE: It is very important that you DO NOT

heat the cooktop until it has been cleaned

thoroughly.

Burned-On Residue

Allow the cooktop to cool.

Use a single-edge razor blade scraper

at approximately a 45° angle against

the glass surface and scrape the soil.

It will be necessary to apply pressure

to the razor scraper in order to

remove the residue.

After scraping with the razor scraper,

spread a few drops of Ceramic

Cooktop Cleaner on the entire burned

residue area. Use the Cleaning Pad

to remove any remaining residue.

For additional protection, after all

residue has been removed, polish

the entire surface with Ceramic

Cooktop Cleaner and a paper towel.

Heavy, Burned-On Residue

Safety Instructions

Operating Instructions Care and Cleaning

Troubleshooting Tips

Consumer Support

Cleaning the glass cooktop. (on radiant models)

Sugary spillovers (such as jellies ,

fudge,candy, syrups) or melted

plastics can cause pitting of

the surface of your cooktop

(not covered by the warranty)

unless the spill is removed while

still hot. Special care should be taken

when removing hot substances.

Be sure to use a new, sharp razor

scraper.

Do not use a dull or nicked blade.

Be careful not to slide pots and pans

across your cooktop. It will leave metal

markings on the cooktop surface.

These marks are removable using

the Ceramic Cooktop Cleaner with

the Cleaning Pad for Ceramic Cooktops.

If pots with a thin overlay of aluminum

or copper are allowed to boil dry, the

overlay may leave black discoloration

on the cooktop.

This should be removed immediately

before heating again or the discoloration

may be permanent.

WARNING: Carefully check the

bottom of pans for roughness that would

scratch the cooktop.

Metal Marks and Scratches

To clean the cooktop seal around

the edges of the glass, lay a wet cloth

on it for a few minutes, then wipe clean

with nonabrasive cleaners.

Cooktop Seal

Glass surface³potencial for permanent damage.

Damage from Sugary Spills and Melted Plastic

Turn off all surface units. Remove

hot pans.

Wearing an oven mitt:

a. Use a single-edge razor blade scraper

to move the spill to a cool area on

the cooktop.

b. Remove the spill with paper towels.

Any remaining spillover should be left

until the surface of the cooktop has

cooled.

Don’t use the surface units again until

all of the residue has been completely

removed.

NOTE: If pitting or indentation in the glass

surface has already occurred, the cooktop

glass will have to be replaced. In this case,

service will be necessary.

Consumer Support

Troubleshooting Tips Care and Cleaning

Operating Instructions Safety Instructions

To order CERAMA BRYTE

Ceramic

Cooktop Cleaner and the cooktop

scraper, please call our toll-free number:

National Parts Centre

800.661.1616

CERAMA BRYTE

Ceramic

Cooktop Cleaner . . . . . . . .CERAMABRYTE

CERAMA BRYTE

Ceramic

Cooktop Scraper . . . . . . . . . . . . . . . . .

28001

Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45898

(Kit includes cream and cooktop scraper)

CERAMA BRYTE

Cleaning Pads for

Ceramic Cooktops . . . . . . .PB-28512

To Order Parts

Before you call for service… GEAppliances.ca

Troubleshooting Tips

Save time and money! Review the charts on the following

pages first and you may not need to call for service.

Problem Possible Causes What To Do

Radiant Cooktops

Surface units will not Improper cookware E Use pans which are flat and match the diameter

maintain a rolling boil being used. of the surface unit selected.

or cooking is not

fast enough

Surface units do A fuse in your home may be E Replace the fuse or reset the circuit breaker.

not work properly blown or the circuit breaker

tripped.

Cooktop controls E Check to see the correct control is set for the surface

improperly set. unit you are using.

Scratches (may appear Incorrect cleaning E Scratches are not removable. Tiny scratches will become

as cracks) on cooktop methods being used. less visible in time as a result of cleaning.

glass surface

Cookware with rough bottoms E To avoid scratches, use the recommended cleaning

being used or coarse particles procedures. Make sure bottoms of cookware are clean

(salt or sand) were between before use, and use cookware with smooth bottoms.

the cookware and the surface

of the cooktop.

Cookware has been slid

across the cooktop surface.

Areas of discoloration Food spillovers not cleaned E See the Cleaning the glass cooktop section.

on the cooktop before next use.

Hot surface on a model E This is normal. The surface may appear discolored

with a light-colored glass when it is hot. This is temporary and will disappear

cooktop. as the glass cools.

Plastic melted to Hot cooktop came into E See the Glass surface―potential for permanent damage

the surface contact with plastic placed section in the Cleaning the glass cooktop section.

on the hot cooktop.

Pitting (or indentation) Hot sugar mixture spilled E Call a qualified technician for replacement.

of the cooktop on the cooktop.

Frequent cycling Improper cookware E Use only flat cookware to minimize cycling.

off and on of being used.

surface units

Safety Instructions Operating Instructions Care and Cleaning

Troubleshooting Tips

Consumer Support

Surface indicator lights The self-clean cycle has

During a self-clean cycle, the surface units will not

turn on, but surface units been set.

work Press the OFF pad to stop the self-clean cycle

do not work

or wait until the self-clean cycle is finished to set

and use the surface units

See the About the radiant

surface units section

Surface unit stops This is normal. The unit

glowing when turned is still on and hot.

to a lower setting

Before you call for service…

Troubleshooting Tips

Problem Possible Causes What To Do

Coil Cooktops

Surface units The surface units are not • With the controls off, check to make sure the surface

not functioning plugged in solidly. unit is plugged completely into the receptacle.

properly

The surface unit controls • Check to see the correct control is set for the surface

improperly set. unit you are using.

The drip pans are not set securely • With the controls off, check to make sure the drip pan

in the cooktop. is in the recess in the cooktop and that the opening

in the pan lines up with the receptacle.

Oven–All Models

Oven light does not work Light bulb is loose or defective. • Tighten or replace the bulb.

Switch operating light is broken. • Call for service.

Oven will not work Plug on range is not completely • Make sure electrical plug is plugged into a live, properly

inserted in the electrical outlet. grounded outlet.

A fuse in your home may • Replace fuse or reset circuit breaker.

be blown or the circuit

breaker tripped.

Oven controls improperly set. • See the Using the oven section.

On self-cleaning models, door • If necessary, allow the oven to cool; then unlock the door.

left in the locked position.

Food does not bake Oven controls improperly set. • See the Using the oven section.

or roast properly

Rack position is incorrect or the • See the Using the oven section.

rack is not level.

Incorrect cookware or cookware • See the Using the oven section.

of improper size being used.

Oven thermostat needs • See the Adjust the oven thermostat―Easy to do

adjustment. yourself! section.

No power supply from Small appliance plug is not • Make sure the small appliance plug is properly

convenience outlet completely inserted in the inserted.

on top of backguard convenience outlet.

(on some models)

The backguard is too hot • Allow the range to cool; then reset the circuit

and the convenience outlet breaker by pressing the switch located near

breaker has tripped. the convenience outlet.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions

Safety Instructions

GEAppliances.ca

Problem Possible Causes What To Do

Food does not

broil properly

Improper rack position • See the Broiling guide.

being used.

Food being cooked in a hot pan. • Use the broiling pan and grid that came with your range.

Make sure it is cool.

Aluminum foil used on the • See the Using the oven section.

broiling pan and grid has

notbeenfittedproperly

and slit as recommended.

In some areas the power • Preheat the broil element for 10 minutes.

(voltage) may be low.

• Broil for the longest period of time recommended

in the Broiling guide.

Control signals after You forgot to enter a bake • Press the BAKE pad and desired temperature or the CLEAN

entering cooking time temperature or cleaning time. pad and desired clean time.

or delay start

Display flashes "bAd" The installed connection • Contact installer or electrician to correct miswire.

then "linE" with a from the house to the unit

loud tone is miswired.

Safety Instructions Operating Instructions Care and Cleaning

Troubleshooting Tips

Consumer Support

Surface units do

not work

There has been a main power

supply surge and/or a power

interruption and surge

• On the Control Panel, activate the Self Clean mode

(press the SELF CLEAN button)

• Wait for 30 seconds and then press the OFF button.

• The cooktop should now be ready to operate

The words “CLOSE

DOOR” flashes or

scrolls in the display

This is a normal condition.

The “CLOSE DOOR” is a reminder

message to keep the oven door

closed during broil mode

• This is normal. Keep oven door closed during broil mode

Before you call for service…

Problem Possible Causes What To Do

Oven temperature too Oven thermostat • See the Adjust the oven thermostat―Easy to do

hot or too cold needs adjustment. yourself! section.

Clock and timer do Plug on range is not completely • Make sure electrical plug is plugged into a live, properly

not work inserted in the electrical outlet. grounded outlet.

Afuseinyourhomemaybe • Replace fuse or reset circuit breaker.

blown or the circuit breaker

tripped.

Oven controls improperly set. • See the Using the clock, timer and convenience outlet

section.

Display goes blank Afuseinyourhomemaybe • Replace the fuse or reset the circuit breaker.

blown or the circuit breaker

tripped.

The clock is turned off from • See the Using the clock, timer and convenience outlet

showing in the display. section.

Oven door is crooked The door is out of position. • Because the oven door is removable, it sometimes

gets out of position during installation. To straighten

the door, push down on the high corner.

Oven makes This is the sound of the • This is normal.

clicking noise heating element turning

off and on during

cooking functions.

“F―and a number You have a function error code. • Press the OFF pad. Put the oven back into

or letter” flash in operation.

the display

If the function code repeats: • Disconnect all power to the range for at least 30

seconds and then reconnect power. If the function

error code repeats, call for service.

• On self-cleaning models, if a function error code

appears during the self-cleaning cycle, check the oven

door latch. The latch may have been moved, if only

slightly, from the locked position. Make sure the latch

is moved to the right as far as it will go. Press the

OFF pad. Allow the oven to cool for one hour. Put

the oven back into operation.

Power outage

clock flashes

Power outage or surge. • Some models will automatically resume their setting once

the power is restored. On models with a clock, you must

reset the clock. If the oven was in use, you must reset it by

pressing the OFF pad, setting the clock and resetting any

cooking function.

Display flashes Power failure. • Reset the clock.

Unable to get the display Oven control pads were not • The BAKE and BROIL pads must be pressed

to show “SF” pressed properly. at the same time and held for 3 seconds.

Troubleshooting Tips

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions

Safety Instructions

GEAppliances.ca

Problem Possible Causes What To Do

“Burning” or “oily” This is normal in a new oven • To speed the process, set a self-clean cycle for a

odor emitting from and will disappear in time. minimum of 3 hours. See the Using the self-cleaning

the oven vent oven section.

Strong odor An odor from the insulation • This is temporary.

around the inside of the oven

is normal for the first few times

the oven is used.

Self-Cleaning Models

Oven will not self-clean The oven temperature is too • Allow the range to cool to room temperature and

high to set a self-clean operation. reset the controls.

Oven controls improperly set. • See the Using the self-cleaning oven section.

Oven door is not in the locked • Make sure you move the door latch handle all the way

position. to the right.

Oven starts a self-clean Oven door locked during • Turn the Oven Temperature knob to OFF. Allow

cycle when you wanted cooking. the oven to cool. Never force the door latch handle.

to bake, roast or broil

“Crackling” or This is the sound of the metal • This is normal.

“popping” sound heating and cooling during both

the cooking and cleaning

functions.

Excessive smoking Excessive soil. • Press the OFF pad. Open the windows to rid the room

during a clean cycle of smoke. Wait until the light on the CLEAN pad goes

off. Wipe up the excess soil and reset the clean cycle.

Oven door will Oven too hot. • Allow the oven to cool below locking temperature.

not unlock

Oven not clean after a Oven controls not properly set. • See Using the self-cleaning oven section.

clean cycle

Oven was heavily soiled. • Clean up heavy spillovers before starting the clean

cycle. Heavily soiled ovens may need to self-clean

again or for a longer period of time.

Safety Instructions

Operating Instructions

Care and Cleaning

Troubleshooting Tips

Consumer Support

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions

Safety Instructions

Accessories. GEAppliances.com

Looking For Something More?

You can find these accessories and many more at www.GEAppliances.ca,

or call 800.661.1616 (during normal business hours). Have your model number ready.

Tired of discolored racks? Wishing you had extra-heavy-duty oven racks?

NOW AVAILABLE for your range:

GE’s innovative, self-cleanable porcelain-coated oven racks!

• Heavy Duty

• Durable

• Able to be cleaned in a self-cleaning oven

Visit www.GEAppliances.ca for more information.

Surface Elements & Drip Pans

Oven Racks Broiler Pan

Oven Elements Light Bulbs Knobs

Cleaner Cleaning Pads Scraper

OWNERSHIP REGISTRATION

P.O. BOX 1780

MISSISSAUGA, ONTARIO

L4Y 4G1

(FOR CANADIAN CONSUMERS ONLY)

Please place in envelope and mail to:

Veuillez mettre dans une enveloppe et envoyez à :

Safety Instructions Operating Instructions

Care and Cleaning

Troubleshooting Tips

Consumer Support

All warranty service provided by our Factory Service Centers,

or an authorized Customer Care

technician. To schedule

service, call 1.800.561.3344. Please have serial number

and model number available when calling for service.

For The Period Of: Mabe Will Provide:

One Year Any part of the range which fails due to a defect in materials or workmanship. During this

From the date of the limited one-year warranty, Mabe will also provide, free of charge, all labor and related service

original purchase to replace the defective part.

Service trips to your home to teach you how to use

the product.

Improper installation, delivery or maintenance.

Failure of the product if it is abused, misused, or used for

other than the intended purpose or used commercially.

Damage to the glass cooktop caused by use of cleaners

other than the recommended cleaning creams and pads.

Damage to the glass cooktop caused by hardened spills

of sugary materials or melted plastic that are not

cleaned according to the directions in the Owner’s

Manual.

Replacement of house fuses or resetting of circuit

breakers.

Damage to the product caused by accident, fire, floods

or acts of God.

Incidental or consequential damage caused by possible

defects with this appliance.

Damage caused after delivery.

Product not accessible to provide required service.

What Mabe Will Not Cover:

Staple your receipt here.

Proof of the original purchase

date is needed to obtain service

under the warranty.

GE Electric Range Warranty.

This warranty is extended to the original purchaser and any succeeding owner for products purchased in Canada

for home use within Canada. In-home warranty service will be provided in areas where it is available and deemed

reasonable by Mabe to provide.

Some provinces do not allow the exclusion or limitation of incidental or consequential damages, so the above

limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have

other rights which vary from province to province. To know what your legal rights are in your province, consult your

local or provincial consumer affairs office.

Warrantor: Mabe Canada Inc.,

Burlington, Ontario

EXCLUSION OF IMPLIED WARRANTIES―Your sole and exclusive remedy is product repair as provided

in this Limited Warranty. Any implied warranties, including the implied warranties of merchantability

or fitness for a particular purpose, are limited to one year or the shortest period allowed by law.

This book is printed on recycled paper.

Printed in Mexico

Consumer Support.

GE Appliances Website

www.geappliances.ca

Have a question or need assistance with your appliance? Visit our Website, www.geappliances.ca, 24 hours a day,

any day of the year!

Schedule Service 1.800.561.3344

GE repair service is close to you.

To arrange service for your GE appliance, all you have to do is call.

Parts and Accessories

Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes

(VISA, MasterCard and Discover cards are accepted).

Instructions contained in this manual cover procedures to be performed by any user. Other servicing

generallyshouldbereferredtoqualifiedservicepersonnel. Caution must be exercised, since improper

servicing may cause unsafe operation.

You will find the nearest Mabe Service Center number in the yellow pages of your phone book. Or, call us at

1.800.661.1616.

If you are not satisfied with the service you have received:

First of all, communicate with the people who repaired your appliance.

Then, if you are still not satisfied, send all information including telephone number to:

Director, Consumer Relations, Mabe Canada Inc.

Suite 310, 1 Factory Lane

Moncton, N.B. E1C 9M3

enhanced communication and prompt service under the terms of your warranty, should the need arise.

You may also mail in the pre-printed registration card included in the packing material.

GE - General Electric JCB730DF2WW GE 30" Electric Free Standing Range White -

Product's Documents

User Manual

Specifications

GE - General Electric JCB730DF2WW Questions and Answers

Related Products

GE - General Electric JCGBS10DEKWW GE 30" Gas Free Standing Range White

GE - General Electric JCB730DFWW GE 30" Electric Free Standing Range White

GE - General Electric JCGBS60DEK3WW GE 30" Gas Free Standing Range White

GE - General Electric JCGBS60DEK4WW GE 30" Gas Free Standing Range White

GE - General Electric WB28X29254 Range NG High Altitude Kit

GE - General Electric JV565C4WW GE range hood
