Brother INNOV-IS NQ3700D Embroidery and Sewing Machine User Manual

Operation Manual

Embroidery and Sewing Machine

Product Code: 888-G30/G32/G34

Be sure to read this document before using the machine.

We recommend that you keep this document nearby for future reference.

Thank you for purchasing this machine. Before using this

machine, carefully read the “IMPORTANT SAFETY

INSTRUCTIONS”, and then study this manual for the

correct operation of the various functions.

In addition, after you have finished reading this manual,

store it where it can quickly be accessed for future

reference.

Please read these safety instructions before attempting to

use the machine.

DANGER

- To reduce the risk of electrical shock

1Always unplug the machine from the

electrical outlet immediately after using,

when cleaning, making any user

servicing adjustments mentioned in this

manual, or if you are leaving the

machine unattended.

WARNING

- To reduce the risk of burns, fire, electrical shock, or

injury to persons.

2Always unplug the machine from the electrical

outlet when making any adjustments mentioned in

the instruction manual.

• To unplug the machine, switch the machine to the

symbol “O” position to turn it off, then grasp the

plug and pull it out of the electrical outlet. Do not

pull on the cord.

• Plug the machine directly into the electrical outlet.

Do not use an extension cord.

• Always unplug your machine if there is a power

failure.

3Electrical Hazards:

• This machine should be connected to an AC power

source within the range indicated on the rating

label. Do not connect it to a DC power source or

inverter. If you are not sure what kind of power

source you have, contact a qualified electrician.

• This machine is approved for use in the country of

purchase only.

4Never operate this machine if it has a damaged cord

or plug, if it is not working properly, has been

dropped or damaged, or water is spilled on the unit.

Return the machine to the nearest authorized

Brother dealer for examination, repair, electrical or

mechanical adjustment.

• While the machine is stored or in use if you notice

anything unusual, such as an odor, heat,

discoloration or deformation, stop using the

machine immediately and unplug the power cord.

• When transporting the machine, be sure to carry it

by its handle. Lifting the machine by any other part

may damage the machine or result in the machine

falling, which could cause injuries.

• When lifting the machine, be careful not to make

any sudden or careless movements, which may

cause a personal injury.

5Always keep your work area clear:

• Never operate the machine with any air openings

blocked. Keep ventilation openings of the machine

and the foot controller free from the build up of lint,

dust, and loose cloth.

• Do not store objects on the foot controller.

• Never drop or insert foreign objects in any opening.

• Do not operate where aerosol (spray) products are

being used or where oxygen is being administered.

• Do not use the machine near a heat source, such as

a stove or iron; otherwise, the machine, power cord

or garment being sewn may ignite, resulting in fire

or an electric shock.

• Do not place this machine on an unstable surface,

such as an unsteady or slanted table, otherwise the

machine may fall, resulting in injuries.

6Special care is required when sewing:

• Always pay close attention to the needle. Do not use

bent or damaged needles.

• Keep fingers away from all moving parts. Special

care is required around the machine needle.

INTRODUCTION

IMPORTANT SAFETY

INSTRUCTIONS

• Switch the machine to the symbol “O” position to

turn it off when making any adjustments in the

needle area.

• Do not use a damaged or incorrect needle plate, as

it could cause the needle to break.

• Do not push or pull the fabric when sewing, and

follow careful instruction when free motion stitching

so that you do not deflect the needle and cause it to

break.

7This machine is not a toy:

• Your close attention is necessary when the machine

is used by or near children.

• The plastic bag that this machine was supplied in

should be kept out of the reach of children or

disposed of. Never allow children to play with the

bag due to the danger of suffocation.

• Do not use outdoors.

8For a longer service life:

• When using and storing this machine, avoid direct

sunlight and high humidity locations. Do not use or

store the machine near a space heater, iron, halogen

lamp, or other hot objects.

• Do not use cleansers or organic solvents, such as

thinner, petroleum ether or alcohol, to clean the

machine. Otherwise, the finish may peel off or

become scratched.

• Always consult the Operation Manual when

replacing or installing any assemblies, the presser

feet, needle or other parts to assure correct

installation.

9For repair or adjustment:

• If the light unit is damaged, it must be replaced by

an authorized Brother dealer.

• In the event a malfunction occurs or adjustment is

required, first follow the troubleshooting table in the

back of the Operation Manual to inspect and adjust

the machine yourself. If the problem persists, please

consult your local authorized Brother dealer.

Use this machine only for its intended use as described

in the manual.

Use accessories recommended by the manufacturer as

contained in this manual.

The contents of this manual and specifications of this

product are subject to change without notice.

For additional product information and updates, visit

our website at www.brother.com

SAVE THESE

INSTRUCTIONS

This machine is intended

for household use.

FOR USERS IN COUNTRIES

EXCEPT CENELEC COUNTRIES

This appliance is not intended for use

by persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience and

knowledge, unless they have been

given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

Children should be supervised to

ensure that they do not play with the

appliance.

FOR USERS IN CENELEC

COUNTRIES

This appliance can be used by children

aged from 8 years and above and

persons with reduced physical, sensory

or mental capabilities or lack of

experience and knowledge if they have

been given supervision or instruction

concerning use of the appliance in a

safe way and understand the hazards

involved. Children shall not play with

the appliance. Cleaning and user

maintenance shall not be made by

children without supervision.

FOR USERS IN THE UK,

EIRE, MALTA

AND CYPRUS ONLY

IMPORTANT

• In the event of replacing the plug fuse, use a fuse

approved by ASTA to BS 1362, i.e. carrying the

mark, rating as marked on plug.

• Always replace the fuse cover. Never use plugs with

the fuse cover omitted.

• If the available electrical outlet is not suitable for the

plug supplied with this equipment, you should

contact your authorized Brother dealer to obtain the

correct lead.
