OWNER’S MANUAL
MICROWAVE OVEN
Please read this owner’s manual thoroughly before operating.
www.lg.com
(optional, please check model specification)
MS304
***
MFL4025 7834
PRECAUTIONS
Precautions to avoid possible exposure to excessive microwave energy.
You cannot operate your oven with the door open due to the safety interlocks built into the door
mechanism. These safety interlocks automatically switch off any cooking activity when the door is opened;
which in the case of a microwave oven could result in harmful exposure to microwave energy.
It is important not to tamper with the safety interlocks.
Do not place any object between the oven front face and the door or allow food or cleaner residue to
accumulate on sealing surfaces.
Do not operate your oven if it is damaged. It is particularly important that the oven door closes properly and
that there is no damage to the: (1) door(bent), (2) hinges and latches (broken or loosened), (3) door seals
and sealing surfaces.
Your oven should not be adjusted or repaired by anyone except qualified service personnel.
Warning
Please ensure cooking times are correctly set as over cooking may result in the FOOD catching
fire and subsequent damage to your oven.
When heating liquids, e.g. soups, sauces and beverages in your microwave oven, overheating the liquid
beyond boiling point can occur without evidence of bubbling. This could result in a sudden boil over of the
hot liquid. To prevent this possibility the following steps should be taken:
1. Avoid using straight sided containers with narrow necks.
2. Do not overheat.
3. Stir the liquid before placing the container in the oven and again halfway through the heating time.
4. After heating, allow to stand in the oven for a short time and check the
temperature of the liquid
before
consumption to avoid burns (especially, contents of feeding bottles and baby
food jars).
Warning
Always allow food to stand after being cooked by microwaves and check the temperature of
them before consumption. Especially contents of feeding bottles and baby food jars.
Never leave lids on bottles when heating as they will explode and may cause personal injury
and damage the oven.
How the Microwave Oven Works
Microwaves are a form of energy similar to radio and television waves and ordinary daylight. Normally,
microwaves spread outwards as they travel through the atmosphere and disappear without effect.
Microwave ovens, however, have a magnetron which is designed to make use of the energy in microwaves.
Electricity, supplied to the magnetron tube, is used to created microwave energy.
These microwaves enter the cooking area through openings inside the oven. A turntable or tray is located
at the bottom of the oven. Microwaves cannot pass through metal walls of the oven, but they can penetrate
such materials as glass, porcelain and paper, the materials out of which microwave-safe cooking dishes are
constructed.
Microwaves do not heat cookware, though cooking vessels will eventually get hot from the heat generated
by the food.
A very safe appliance
Your microwave oven is one of the safest of all home appliances. When the door is opened, the
oven automatically stops producing microwaves. Microwave energy is converted completely to
heat when it enters food, leaving no “left over” energy to harm you when you eat your food.
2
PRECAUTIONS 2
CONTENTS 3
UNPACKING & INSTALLING 4
FEATURE DIAGRAM 6
CONTROL PANEL 6
OPERATING INSTRUCTIONS 7
SETTING CLOCK 7
CHILD LOCK 7
CONTENTS
MIDDLE EASTERN COOKING 12
MIDDLE EASTERN COOKING TABLE 12
MICROWAVE COOKING 13
13
13
13
2 STAGE TIMED COOKING
MICROWAVE POWER LEVELS
QUICK START
MELT 14
14
14
14
15
16
16
16
17
18
19
20
22
26
27
MELT TABLE
SOFTEN
SOFTEN TABLE
AUTO DEFROST
EXPRESS DEFROST
BREAD DEFROST
AUTO DEFROST TABLE
HEATING OR REHEATING GUIDE
FRESH VEGETABLE GUIDE
MICROWAVE-SAFE UTENSILS
FOOD CHARACTERISTICS & MICROWAVE COOKING
IMPORTANT SAFETY INSTRUCTIONS
QUESTION & ANSWERS
PLUG WIRING INFORMATION/TECHNICAL SPECIFICATIONS
ENERGY SAVING 7
3
AUSSIE COOKING 8
AUSSIE COOKING TABLE 8
FRENCH COOKING
9
FRENCH COOKING TABLE 9
ITALIAN COOKING
9
ITALIAN COOKING TABLE 11
UNPACKING & INSTALLING
Unpack your oven and place it on a flat level surface.
By following the basic steps on these two pages you will be able to quickly check that your oven
is operating correctly. Please pay particular attention to the guidance on where to install your
oven. When unpacking your oven make sure you remove all accessories and packing.
Check to make sure that your oven has not been damaged during delivery.
ROTATING RING
THIS OVEN SHOULD NOT BE USED FOR COMMERCIAL
CATERING PURPOSES, IT IS INTENDED FOR INDOOR
DOMESTIC USE ONLY.
GLASS TRAY
Place your oven on a flat, level surface but make sure there is at least 20 cm of space on the
top and FP on the rear and sides so there is air flow for ventilation. Exhaust outlets are
located in the back and side of your oven. Blocking the outlets can damage your oven. The microwave
oven must not be placed in a cabinet.
4
UNPACKING & INSTALLING
Open your oven door by pressing the DOOR OPEN button.
Place the ROTATING RING inside the oven and
place the GLASS TRAY on top.
Plug your oven into a standard household socket. Make sure your oven is the only appliance
connected to the socket. If your oven does not operate properly, unplug it from the
electrical socket and then plug it back in.
The DISPLAY will count down from 30 second
s. When it reaches 0 it will sound
BEEPS.
Open the oven door and test the temperature of the water. If your oven is operating the water
should be HOT. Be careful when removing the container it may be hot.
YOUR OVEN IS NOW INSTALLED
Fill a microwave safe container with 300 ml (1/2 pint) of water. Place on the GLASS TRAY
and close the oven door. If you have any doubts about what type of container to use please
refer to page 19.
Enter the time by touching [3] and [0].
And touch
30
SECONDS
automatically.
START/Q-START.
5
NOTE: A beep sounds when a pad on the control panel
is touched to indicate setting has been entered.
FEATURE DIAGRAM
CONTROL PANEL
Remove your Microwave Oven and all
material from the shipping carton.
Your oven will be packed with the
following materials:
Glass Turntable .........................1 each
Owner's Manual
ach
Rotating Ring.............................1 each
This microwave oven is designed
for household use only. It is not
recommended for commercial
purposes.
Oven Front Plate
Window Door Screen
Door Seal
Display Window
Control Panel
Door Open Button
Safety Door Lock System
Glass Turntable
Rotating Ring
.........................1 e
6
OPERATING INSTRUCTIONS
SETTING CLOCK
When your oven is plugged in for the first time or
when power resumes after a power interruption,
the numbers in the display reset to "0".
Example:To set 11:11.
1. Touch STOP/CLEAR.
2. Touch Clock twice.
3. Enter the time by using
the number key pads.
("11:11")
4. Touch
START/Q-START
CHILD LOCK
This is a unique safety feature that prevents
unwanted oven operations. Once the CHILD
LOCK is set, no cooking can take place.
Touch and hold STOP/CLEAR
or 0, until L appears in the
display and two beeps are
heard. If the time of day was
already set, the time of day will
disappear on the display window.
If the CHILD LOCK was already set and you
touch another cooking pad, the word L
shows in the display. You can cancel the
CHILD LOCK according to below procedure.
ENERGY SAVING
ECO ON feature saves energy by turning off
the display.This feature only operates when the
STOP/ CLEAR (ECO ON)
button is touched and
then cancels
when the door is opened or any button
is touched.
1. Touch STOP/CLEAR (ECO ON)
The display will go out
and
ECO ON will be
active.
Touch the STOP/CLEAR (ECO ON) or any
other button
to cancel this feature when it is on.
7
To set the child lock
To set the ECO ON
To cancel the child lock
Touch and hold STOP/CLEAR
or 0, pad until L disappears
in the display.
After the CHILD LOCK is turned off, the time of
day will return to the display window. The oven
will operate normally.
OPERATING INSTRUCTIONS
AUSSIE COOKING
AUSSIE COOKING allows you to cook most
of your favorite food easily by selecting the food
type and the weight of the food.
AUSSIE COOKING TABLE
Example : One touch Auto Menu (popcorn 100 g )
1. Touch STOP/CLEAR.
2. Touch Aussie
once.
‘Ac-1’ appears in the display.
Example: To cook a 85 g. bag of microwave
popcorn.
Example: To cook 1 potato
1. Touch STOP/CLEAR.
3. Touch 2
number
‘85’ appears in the display.
4. Touch
START/Q-START.
2. Touch Aussie
twice.
‘Ac-2’ appears in the display.
1
3. Touch 1
number
‘1’ appears in the display.
4. Touch
START/Q-START.
Category
Weight
Limit
Utensil
Food
Temp.
Instructions
Popcorn
(Ac-1)
Potato
(Ac-2)
Vegetable
(Ac-3)
Dinner
plate
(Ac-4)
Porridge
(Ac-5)
Baked
beans
(Ac-6)
1 bag
(100g, 85g)
Bag
on the glass
tray
Room
1. Use popcorn product for microwave oven. Remove plastic overwrap.
2. Place unfolded bag in the oven. (Follow the package directions)
3. After popping, remove bag from the oven.
CAUTION : Product is HOT! Open bag carefully by pulling diagonally on
corners.
1-4 potatoes
(1 potato = 200g)
Paper towel
on
the glass
tray
Room
1. Choose medium sized potatoes 180 -220g. Wash and dry potatoes.
2. Pierce potatoes several times with a fork.
3. Place potatoes in the oven. Choose the menu and press start to cook.
4. After cooking, stand covered with aluminum foil for 5 minutes.
1-4 cups
(1cup = 130g)
Microwave-
safe bowl
Room
1. Place vegetables in a microwave-safe bowl.
2. Add the amount of water according to the quantity.
** 0.2kg - 0.4kg : 2 tablespoons of water
** 0.6kg - 0.8kg : 4 tablespoons of water
3. Cover with plastic wrap. Place food in the oven.
4. After cooking, stir for 3-4 seconds. Stand covered for 3 minutes.
1 serving
(300g, 454g)
Microwave-
safe plate
Refrig
erated
1. Place leftover food (meat, chicken, mashed potato, vegetable etc.) on a plate.
2. Cover with 2
㎝
vented plastic wrap.
3. Place plate in the oven. Choose the menu and weight, press start.
4. After cooking, allow to stand for 3 minutes.
1-4 servings
Microwave-
safe
bowl
Refrige
rated
1. Place oats and milk in a deep and large microwave-safe bowl. Do not cover.
2. Place food in the oven. Choose the menu and press start to cook.
3. After cooking, stir and stand for 1 minute.
0.2-0.8kg
Microwave-
safe
bowl
Room
1. Pour beans into a microwave-safe bowl.
2. Cover with plastic wrap. Place food in the oven.
3. After heating, stir and stand covered for 3 minutes.
1 serving 2 servings 3 servings 4 servings
Oats
package
(30-40g)
1 package 2 packages 3 packages 4 packages
Cold Milk 180ml 360ml 540ml 720ml
8
OPERATING INSTRUCTIONS
FRENCH COOKING TABLE
FRENCH COOKING
FRENCH COOKING allows you to cook most
of your favorite food easily by selecting the food
type.
Example: To cook 1.5kg French onion soup
1. Touch STOP/CLEAR.
2. Touch French
once.
‘Fc-1’ appears in the display.
3. Touch
START/Q-START.
ITALIAN COOKING
ITALIAN COOKING allows you to cook most
of your favorite food easily by selecting the food
type.
1. Touch STOP/CLEAR.
2. Touch Italian
twice.
‘Ic- 2’ appears in the display.
3. Touch
START/Q-START.
Example: To cook 1.5kg Stuffed pepper.
Category
Weight
Limit
Utensil
Food
Temp.
Instructions
French
onion
soup
(Fc-1)
1.5kg
Microwave-safe
bowl
Room
1. Cook onions in a frying pan with butter and sugar until golden brown.
2. Add cooked onions and flour in a deep and large bowl, mix well and add beef stock
and red wine. Cover with plastic wrap and vent.
3. Place food in the oven. Choose the menu and press start to cook. Stir at least twice
during cooking.
4. After cooking, stir and ladle soup into serving bowls.
5. Place 1 slice toasted bread on top of the soup in each bowl and spread cheese on
toasted bread. Cook for 1~2 minutes on Microwave 1100 watts until cheese melted.
Spinach
cream
soup
(Fc-2)
1.2kg
Microwave-safe
bowl
Room
1. Add all ingredients in a deep and large bowl and mix well. Cover with plastic wrap
and vent.
2. Place food in the oven. Choose the menu and press start to cook. Stir at least twice
during cooking.
Ingredients
4 onions, thinly sliced
50g butter
1 teaspoon white sugar
1 tablespoon all-purpose flour
3 cups beef stock
½ cup red wine
8 slices of toasted French bread
1cup grated cheese
Ingredients
600g vegetable purée
1 ½ cups chicken stock
2 tablespoons all-purpose flour
2 tablespoons butter
1 cup cream
Nutmeg, salt and pepper to taste
※
Vegetable purée
400g spinach, chopped
2 onions, chopped
4 tablespoons water
1. Place vegetables in a microwave-safe bowl.
2. Add water and cover with plastic wrap.
3. Place food in the oven. Cook for 7~9 minutes on Microwave 1100 watts.
4. After cooking, blend cooked vegetables using a blender or food processor
until the purée is smooth and uniform in texture.
Example: To cook 1.5kg French onion soup.
9
OPERATING INSTRUCTIONS
FRENCH COOKING TABLE
Category
Weight
Limit
Utensil
Food
Temp.
Instructions
Ratatouille 1.5kg
Microwave-safe
bowl
Room
1. Add all ingredients in a deep and large bowl and mix well. Cover with plastic wrap
and vent.
2. Place food in the oven. Choose the menu and press start to cook. Stir at least twice
during cooking.
Stuffed
tomatoes
1.2kg
Microwave-safe
dish
Room
1. Cut tops off tomatoes to form hats and remove seeds, taking care not
to pierce flesh
or skin. Then s
prinkle each tomatoes with salt and pepper.
2. Fill tomatoes with stuffing and replace hat.
3. Place stuffed tomatoes on a dish and cover with plastic wrap.
4. Place food in the oven. Choose the menu and press start to cook.
Stuffed
mushrooms
0.5kg
Microwave-safe
dish
Room
1. Remove stem of each mushroom and put on a dish.
2. Fill each mushroom cap with stuffing.
3. Add cheese o
n top of each stuffed mushroom.
4. Place food on the r
ack. Choose the menu and press start to cook.
Chicken
legs
with
prunes
1.2kg
Microwave-safe
bowl
Room
1. Add all ingredients in a deep and large bowl and mix well. Cover with plastic wrap
and vent.
2. Place food in the oven. Choose the menu and press start to cook. Stir at least twice
during cooking.
Ingredients
1 onion, cut into chunks
1 eggplant, cut into chunks
1 zucchini, cut into chunks
1 colored sweet pepper, cut into chunks
3 tomatoes, chopped
1 tablespoon tomato paste
2 garlic cloves, crushed
1 tablespoon fresh greens, chopped
2 tablespoons vinegar
1 teaspoon sugar
Salt and pepper to taste
Ingredients
4 medium tomatoes
Salt and pepper to taste
Stuffing
※
Stuffing
400g ground beef
½ cup bread crumbs
2 garlic cloves, crushed
1 tablespoon Dijon mustard
1 tablespoon dried greens
1 tablespoon parmesan cheese
1. Add all ingredients in a bowl, mix well, and cover with plastic wrap.
2. Place food in the oven. Cook for 3~5 minutes on Microwave 1100 watts. Stir at
least once during cooking.
Ingredients
15~20 champignon mushrooms, stemmed
Stuffing
50g grated cheese
※
Stuffing
2 tablespoons butter
Remaining mushroom stems, chopped
¼ cup red wine
30g bread crumbs
3 tablespoons fresh greens, chopped
½ cup cream
Salt and pepper to taste
1. Cook mushroom stems in a frying pan with butter. Add red wine, bread
crumbs and parsley, mix well.
2. Add cream and simmer on low heat until cream has thickened. Season with
salt and pepper.
Ingredients
1 onion, sliced
1 carrot, sliced
500g chicken legs
15 pitted prunes, halved
1 cup chicken stock
Salt and pepper to taste
(Fc-3)
(Fc-4)
(Fc-5)
(Fc-6)
10
OPERATING INSTRUCTIONS
ITALIAN COOKING TABLE
Category
Weight
Limit
Utensil
Food
Temp.
Instructions
Eggplant
with
tomato
and
cheese
1.0kg
Microwave-safe
dish
Room
1. Cut eggplants and tomatoes into 1.5cm slices and season with salt and pepper.
2. Layer the eggplants and tomatoes on a dish and add cheese on top of each tomatoes.
3. Place food on the rack. Choose the menu and press start to cook.
Stuffed
pepper
1.5kg
Microwave-safe
dish
Room
1. Cut tops off pepp
ers, remove seeds.
2. Mix tuna, bread, garlic, parmesan cheese, salt and pepper.
3. Stuff peppers
with tuna mixture and place stuffed peppers on a dish.
4. Add tomato puree on top and cover with plastic wrap.
5. Place food in the oven. Choose the menu and press start to cook.
Spaghetti
bolognais
e
1.0kg
Microwave-safe
bowl
Room
1. Add all ingredients of the bolognaise sauce in a deep and large bowl and mix
well.
cover with plastic wrap and vent.
2
. Place food in the oven. Choose the menu and press start to cook. Stir at least twice
during cooking.
3. Af
ter cooking, stir and add bolognaise sauce to cooked pasta and garnish with
parmesan cheese or as desired before serving.
Spaghetti
carbonar
a
0.4kg
Microwave-safe
bowl
Room
1. Cook bacon in a lightly oiled frying pan with garlic until lightly browned and drain away
excess fat.
2. Add cooked bacon, cream, egg yolks, parmesan cheese, salt and pepper in a deep and
large bowl and mix
well. Cover with plastic wrap and vent.
3. Place food in the oven. Choose the menu and press start to cook.
4. After cooking, stir and add carbonara sauce to cooked pasta and garnish with parmesan
cheese or as desired before serving.
Risotto 1.2kg
Microwave-safe
bowl
Room
1. Add all
ingredients in a deep and large bowl and mix well. Cover with plastic wrap and
vent.
2. Place food in the oven. Choose the menu and press start to cook. Stir at least twice
during cooking.
Ingredients
1~2 eggplants
1~2 tomatoes
Salt and pepper to taste
100g grated cheese
Ingredients
4 colored sweet peppers
2 canned tuna
2 piece dry black bread, chopped
1 garlic clove, crushed
100g parmesan cheese
Salt and pepper to taste
200g tomato puree
Ingredients for bolognaise sauce
1 tablespoon olive oil
1 onion, chopped
1 garlic clove, crushed
400g ground beef
100g tomato paste
2 chopped tomatoes
1 tablespoon dried greens
Salt and pepper to taste
Ingredients for pasta
150g pasta, cooked as package direction
1 tablespoon parmesan cheese
Ingredients for carbonara sauce
100g smoked bacon, chopped
1 garlic clove, crushed
½ cup cream
4 egg yolks
100g parmesan cheese
Salt and pepper to taste
Ingredients for pasta
150g pasta, cooked as package direction
1 tablespoon parmesan cheese
Ingredients
200g risotto rice
1 1/2 cups water or stock
½ cup milk
200g beef, chopped
2 eggs
1 onion, chopped
50g green peas
100g grated cheese
Salt and pepper to taste
(lc-1)
(lc-2)
(lc-3)
(lc-4)
(lc-5)
11
Category
Weight
Limit
Utensil
Food
Temp.
Instructions
Dolma
Rice pilaf
Curry
chicken
Shawarm
a
1.0kg
Microwave-safe
bowl
Room
1. Add cooked rice, ground beef, onion, salt and pepper in a bowl and mix well.
3. Place grape leaf on a flat surface and place 1 1/2 spoonfuls of the rice mixture in the
center of the leaf. Wrap rice mixture with leaf.
4. Put all wrapped leaves in rows into a deep and large bowl and add water. Cover with
plastic wrap.
5
. Place food in the oven. Choose the menu and press start to cook.
6. After cooking, serve with sour cream or as desired.
1.2kg
Microwave-safe
bowl
Room
1. Cook beef, onion, carrot and garlic in a lightly oiled frying pan until lightly browned. Add
tumeric, salt and pepper, mix well.
2. Place the cooked beef mixture into a deep and large bowl and add rice and water.
Cover with plastic wrap and vent.
3. Place food in the oven. Choose the menu and press start to cook. Stir at least twice
during cooking.
1.5kg
Microwave-safe
bowl
Room
1. Add all ingredients in a deep and large bowl and mix well. Cover with plastic
wrap and vent.
2. Place food in the oven. Choose the menu and press start to cook. Stir at least
twice during cooking.
0.8kg
Microwave-safe
dish
Room
1. Add chicken breasts, tomato, cucumber and greens in a deep and large bowl
and mix well.
2. Mixall ingredients of the sauce in anotherbowl.
3. Place lavashon a flat surface and put sauce and chicken mixture.
Wrap into rolls.
4. Place rolls on a dish and cover with plastic wrap.
5. Place food in the oven. Choose the menu and press start to cook.
Ingredients
1 pot of grapes leaves
200g cooked rice
500g ground beef
1 onion, chopped
Salt and pepper to taste
½ cup water
½ cup sour cream
Ingredients
300g beef, cut into chunks
1 onion, chopped
1 carrot, chopped
3 garlic cloves, crushed
1 teaspoon tumeric
Salt and pepper to taste
200g long grain rice, rinsed and drained
2 cups water or stock
Ingredients
4~6 lavash or thin bread
200g chicken breasts, cooked and chopped
1 tomato, chopped
1 cucumber, chopped
3 tablespoons fresh greens, chopped
Sauce :
1 tablespoon mayonnaise
1 tablespoon sour cream
1 tablespoon ketchup
1 garlic clove, crushed
Ingredients
400g chicken breasts, cut into chunks
¼ cup olive oil
2 onions, chopped
4 garlic cloves, crushed
1 ginger root, peeled
1 cinnamon stick
2 dried red chilies
1 teaspoon tumericpowder
400g tomato sauce
½ cup water or stock
½ cup plain yogurt
1 tablespoon lemon juice
Salt and pepper to taste
12
(Oc-1)
(Oc-2)
(Oc-3)
(Oc-4)
Example: To cook 1.0kg Dolma.
MIDDLE EASTERN COOKING
TABLE
OPERATING INSTRUCTIONS
MIDDLE EASTERN COOKING
MIDDLE EASTERN
COOKING allows you to cook
most
of your favorite food easily by selecting the food
type.
Example: To cook 0
1. Touch STOP/CLEAR.
2. Touch
Middle eastern
once.
‘ Oc-1’ appears in the display.
3. Touch
START/Q-START.
Example: To cook 1.0kg Dolma.
OPERATING INSTRUCTIONS
MICROWAVE COOKING
Microwave Power Level Table
Power
Use
Level
• Boiling water
.
• Making candy
.
10
• Cooking poultry pieces, fish, & vegetables.
(High)
• Cooking tender cuts of meat.
• Whole poultry
.
9
• Reheating rice, pasta, & vegetables.
• Reheating prepared foods quickly
.
8
• Reheating sandwiches.
• Cooking egg, milk, & cheese dishes.
7
• Cooking cakes, breads.
• Melting chocolate.
• Cooking veal.
6
• Cooking whole fish.
• Cooking puddings & custard.
• Cooking ham, whole poultry, & lamb.
5
• Cooking rib roast, sirloin tip.
4
• Thawing meat, poultry, & seafood.
• Cooking less tender cuts of meat.
3
• Cooking pork chops, roast.
• Taking chill out of fruit.
2
• Softening butter.
• Keeping casseroles & main dishes warm.
1
• Softening butter & cream cheese.
0
• Standing time.
This function allows you to cook food for a
desired time. There are 11 power levels available.
The example below shows how to set 80% power
level for the desired time.
Example:To cook food on 80% Power (Power8)
for 5 minutes 30 seconds
1. Touch STOP/CLEAR.
2. Touch Time.
3. Enter 5 minutes
30 seconds by touching
[5], [3],and [0].
4. Touch Power.
P-HI appears in the
display. This is to tell you
that the oven is set on HI
unless a different power
setting is chosen.
5. Touch 8.
To select power level 80%.
Display shows P-80.
6. Touch
START/Q-START.
When cooking is complete, four short tones will
sound. The word End shows in the display window.
Then the oven shuts itself off.
NOTE:
If you do not select the power level, the oven will
operate at power HIGH. To set HI-POWER
cooking, skip steps 4 & 5 above.
2 STAGE TIMED COOKING
For Two Stage cooking, repeat timed cooking
steps 2 to 5 from the above example before
pressing
the START/Q-START button. The 2nd stage will
continue on from the 1st stage by applying the set
time and set
power level
automatically.
Auto Weight Defrost can be programmed before
the first stage to defrost first and then cook.
* The adjacent chart shows the power level settings
for your oven.
QUICK START
The QUICK START feature allows you to set 30
seconds intervals of HIGH power cooking with
a touch of the START/Q-START.
Example: Set 2 minutes of cooking on high power.
1.
1. Touch STOP/CLEAR.
2. Touch START/Q-START
2.
Four times on high power
The oven will start before you have
finished the
fourth touch.
During QUICK START cooking,you can extend the
cooking time up to 10 minutes by repeatedly touching
the START/Q-START key if longer cooking time are
required.
MICROWAVE POWER LEVELS
Your microwave oven is equipped with eleven
power levels to give you maximum flexibility and
control over cooking. The adjacent table will give you
some idea of which foods are prepared at each of
the various power levels.
13
OPERATING INSTRUCTIONS
MELMELTT SOFTENSOFTEN
SOFTEN TABLE
Amount
1, 2 or
3 sticks
Pint,
Quart,
Half
gallon
85 or
227 g
170, 340
or 454 g
Direction
Unwrap and place in
microwavable container.
No need to cover butter.
Butter will be at room
temperature and ready
for use in recipe.
Place container in oven.
Ice cream will be soft
enough to make
scooping easier.
Unwrap and place in
microwavable container.
Cream cheese will be at
room temperature and
ready for use in recipe.
Remove top.
Place in oven.
Frozen juice will be soft
enough to easily mix with
water.
Cate-
gory
Butter
Ice
Cream
Cream
Cheese
Frozen
Juice
1
2
3
4
Code
MELT TABLE
Cate-Cate-
CodeCode
DirectionDirection
AAmmoouunntt
gorygory
Unwrap and place inUnwrap and place in
Butter/Butter/
microwavable containermicrowavable container
1, 2 or1, 2 or
11
.
Marga-Marga-
No need to cover butterNo need to cover butter
.
3 sticks3 sticks
Stir at the end of cookingStir at the end of cooking
..
rinerine
to be moved down and over. to be moved down and over.
Choose the 4 or 8 oz.(actualChoose the 4 or 8 oz.(actual
weight) selection to meltweight) selection to melt
squares of baking chocolatesquares of baking chocolate
or chocolate morsels.or chocolate morsels.
Unwrap squares and placeUnwrap squares and place
22
ChocoChoco
--
them in a microwavablethem in a microwavable
113 or 113 or
latelate
container. Stir at the end of container. Stir at the end of
227 g227 g
the cycle to complete melting.the cycle to complete melting.
NOTE:NOTE:
Add time if necessary toAdd time if necessary to
complete melting.complete melting.
Use processed cheeseUse processed cheese
food onlyfood only. Cut into cubes.. Cut into cubes.
..
Place in a single layer inPlace in a single layer in
227 or 227 or
33
CheeseCheese
microwavable containermicrowavable container
454 g454 g
Stir at the end of cookingStir at the end of cooking
to complete melting.to complete melting.
Large or miniatureLarge or miniature
marshmallows may bemarshmallows may be
142 or142 or
Marsh-Marsh-
used. Place inused. Place in
44
..
mallowsmallows
microwavable containermicrowavable container
284 g284 g
Stir at the end of cycle toStir at the end of cycle to
complete melting.complete melting.
OPERATING INSTRUCTIONS
SOFTEN TABLE
Amount
1, 2 or
3 sticks
Pint,
Quart,
Half
gallon
85 or
227 g
170, 340
or 454 g
Direction
Unwrap and place in
microwavable container.
No need to cover butter.
Butter will be at room
temperature and ready
for use in recipe.
Place container in oven.
Ice cream will be soft
enough to make
scooping easier.
Unwrap and place in
microwavable container.
Cream cheese will be at
room temperature and
ready for use in recipe.
Remove top.
Place in oven.
Frozen juice will be soft
enough to easily mix with
water.
Cate-
gory
Butter
Ice
Cream
Cream
Cheese
Frozen
Juice
1
2
3
4
Code
MELT TABLE
The oven uses low power to melt foods (butter,
The oven uses low power to soften foods (butter, ice
chocolate, marshmallows and cheese). See the
cream, cream cheese, and frozen juice)
following table.
See the following table.
Example : To Melt 227g Chocolate.
1. Touch STOP/CLEAR.
2. Touch
Melt
two times.
‘2’ appears in the display.
3. Touch number 2.
‘227’ appears in the display.
4. Touch
START/Q-START.
When the cook time is over,
you will hear four beeps and
END will be displayed.
Example : To Soften 227g Cream Cheese.
1. Touch STOP/CLEAR.
2. Touch
Soften
three times.
‘3’ appears in the display.
3. Touch number 2.
‘227’ appears in the display.
4. Touch
START/Q-START.
When the cook time is over,
you will hear four beeps and
END will be displayed.
chocolate. 227g tleM o T:elpmaxE
14
OPERATING INSTRUCTIONS
AUTO DEFROST
Three defrost sequences are preset in the oven.
The auto defrost feature provides you with the best
defrosting method for frozen foods. The cooking guide
will show you which defrost sequence is recommende
for the food you are defrosting.
For added convenience, the Auto Defrost
includes a built-in beep mechanism that reminds
you to check, turn over, separate, or rearrange to get
the best defrost results. Three different defrosting leve
are provided.
1 MEAT
2 POULTRY
3 FISH
*Available weight is 0.1~4.0 kg.
d
ls
1. Touch STOP/CLEAR.
2. Touch
Auto Defrost
one time.
‘dEF1’ appears in the display.
3.
4
START/Q-START
START/Q-START
START/Q-START
t
*For best results, remove fish, shellfish, meat,
and poultry from its original wrapping paper or
plastic package. Otherwise, the wrap
will hold steam and juice close to the foods,
which can cause the outer surface of the foods
to cook.
*For best results, shape your ground meat into
the form of a doughnut before freezing. When
defrosting, separate any thawed meat when the
beep sounds and continue defrosting.
*Place foods in a shallow container or on a
microwave roasting rack to catch drippings.
*Food should still be somewhat icy in the center
when removed from the oven.
15
OPERATING INSTRUCTIONS
This feature should be used only when you defrost
0.5 kg of frozen ground beef.
EXPRESS DEFROST
BREAD DEFROST
The bread defrost feature provides you with the best
defrosting method for frozen bread.
*Available weight is 0.1~0.5 kg.
AUTO DEFROST TABLE
Category
MEAT
POULTRY
FISH
Food to be Defrosted
Beef
Ground beef, Round steak,
Cubes for stew, Tenderloin steak,
Pot roast, Rib roast, Rump roast,
Chuck roast, Hamburger patty
Lamb
Chops (25.4 mm thick), Rolled roast
Pork
Chops (
12.7 mm thick), Hot dogs,
Spareribs, Country-style ribs.
Rolled roast, Sausage
Veal
Cutlets (0.5 kg, 12.7 mm thick)
Poultry
Whole (under 4.0 kg.), Cut-up, Breast
(boneless)
Cornish Hens
Whole
Turkey
Breast
Steaks/Chops
Round beef steak, Tenderloin steak
Lamb chops (25.4 mm thick)
Pork chops (12.7 mm thick)
Veal cutlets (0.5 kg, 1/2 inch thick)
Fish
Fillets, Whole Steaks
Shellfish
Crab meat, Lobster tails, Shrimp,
Scallops
Example: To defrost 0.5 kg Ground beef.
1. Touch STOP/CLEAR.
2. Touch
Express Defrost
.
Example: To defrost 0.1 kg of bread.
1. Touch STOP/CLEAR.
2. Touch
Bread Defrost
.
3.
4
START/Q-START
16
OPERATING INSTRUCTIONS
Items Cook time Special Instructions
(at HIGH)
Sliced meat Place sliced meat on microwavable plate.
3 slices (0.5 cm thick) 1-2 minutes Cover with plastic wrap and vent.
*Note: Gravy or sauce helps to keep meat juicy.
Chicken pieces
1 breast 2-3 minutes Place chicken pieces on microwavable plate. Cover with plastic
1 leg and thigh 3-3
1
/
2
minutes wrap and vent.
Fish fillet Place fish on microwavable plate. Cover with plastic wrap and
(230 g) 1-2 minutes vent.
Lasagna Place lasagna on microwavable plate. Cover with plastic wrap
1 serving (300 g) 4-6 minutes and vent.
Casserole
1 cup 1 -3
1
/
2
minutes
4 cups 4 -7 minutes
Casserole –
cream or cheese
1 cup 1-2 minutes
1
/
2
4 cups 3
1
/
2
-6 minutes
Sloppy Joe or
Barbecued beef
1 sandwich 1 -2
1
/
2
minutes
(
1
/
2
cup meat filling)
without bun
Mashed potatoes
1 cup 1 -3 minutes
4 cups 6-9 minutes
Baked beans
1 cup
1
1
/
2
-3 minutes
Ravioli or pasta in sauce
1 cup 2
1
/
2
-4 minutes
4 cups 7
1
/
2
-11 minutes
Rice
1 cup 1-1
1
/
2
minutes
4 cups 3 -5 minutes
1
/
2
Sandwich roll or bun Wrap in paper towel and place on glass mircrowavable rack
1 roll
15-30 seconds
Vegetables
1 cup
1
1
/
2
-2
1
/
2
minutes
4 cups 4-6 minutes
Soup
1 serving (230 g
) 1
1
/
2
-2 minutes
1
/
2
1
/
2
1
/
2
HEATING OR REHEATING GUIDE
To heat or reheat successfully in the microwave, it is important to follow several guidelines. Measure the
amount of food in order to determine the time needed to reheat. Arrange the food in a circular pattern for
best results. Room temperature food will heat faster than refrigerated food. Canned foods should be taken
out of the can and placed in a microwavable container. The food will be heated more evenly if covered with
a microwavable lid or plastic wrap and vented. Remove cover carefully to prevent steam burns. Use the
following chart as a guide for reheating cooked food. Never cook or reheat with lids fitted to
containers or bottles.
COOK covered in microwavable casserole dish. Stir once halfway
through cooking.
COOK covered in microwavable casserole dish. Stir once halfway
through cooking.
Reheat filling and bread separately.
Cook filling covered in microwavable casserole dish. Stir once.
Heat bun as directed in chart below.
COOK covered in microwavable casserole dish. Stir once halfway
through cooking.
COOK covered in microwavable casserole dish. Stir once halfway
through cooking.
COOK covered in microwavable casserole dish. Stir once halfway
through cooking.
COOK covered in microwavable casserole dish. Stir once halfway
through cooking.
COOK covered in microwavable casserole dish. Stir once halfway
through cooking.
COOK covered in microwavable casserole dish. Stir once halfway
through cooking.
17
OPERATING INSTRUCTIONS
Cook time Standing
at HIGH Time
Artichokes 2 medium 4 ~7 Trim. Add 2 tsp water and 2 tsp juice. Cover. 2-3 minutes
(230 g each) 4 medium 10~12
Asparagus, 450 g 2 ~6 Add 1 cup water. Cover. 2-3 minutes
Fresh, Spears
Beans, Green & 450 g 7~11 Add
1
/
2
cup water in 1
1
/
2
qt. casserole dish. Stir 2-3 minutes
Wax halfway through cooking.
Beets, Fresh 450 g 11~16
Add
1
/
2
cup water in 1
1
/
2
qt. covered casserole dish. 2-3 minutes
Rearrange halfway through cooking.
Broccoli, Fresh, 450 g 5~8 Place broccoli in baking dish. Add
1
/
2
cup water. 2-3 minutes
Spears
Cabbage, Fresh, 450 g 4~7 Add
1
/
2
cup water in 1
1
/
2
qt. covered casserole dish. 2-3 minutes
Chopped Stir halfway through cooking.
Carrots, Fresh, 2 cups 2~3
Add
1
/
4
cup water in 1 qt. covered casserole dish. 2-3 minutes
Sliced Stir halfway through cooking.
Cauliflower, 450 g 5~7
Trim. Add
1
/
4
cup water in 1 qt. covered casserole dish. 2-3 minutes
Fresh, Whole Stir halfway through cooking.
Flowerettes, Fresh 2 cups
2
1
/
2
~4
1
/
2
2-3 minutes
Celery, Fresh, 4 cups 6~8 Stir halfway through cooking.
Sliced
Corn, Fresh 2
cobs
4~8 Husk. Add 2 tbsp water in 1
1
/
2
qt. baking dish. 2-3 minutes
Cover.
Mushrooms, 230 g 2 ~3
1
/
2
Place mushrooms in 1
1
/
2
qt. covered casserole dish. 2-3 minutes
Fresh, Sliced Stir halfway through cooking.
Parsnips, Fresh, 450 g 4~7
Add
1
/
2
cup water in 1
1
/
2
qt. covered casserole dish. 2-3 minutes
Sliced Stir halfway through cooking.
Peas, Green, 4 cups 6~9
Add
1
/
2
cup water in 1
1
/
2
qt. covered casserole dish. 2-3 minutes
Fresh Stir halfway through cooking.
Sweet Potatoes 2 medium 4~9 Pierce potatoes several times with fork. 2-3 minutes
Whole Baking 4 medium 6~12 Place on 2 paper towels. 2-3 minutes
(170~230 g each) Turn over halfway through cooking.
White Potatoes, 2 potatoes 5~8 Pierce potatoes several times with fork. 2-3 minutes
Whole Baking 4 potatoes 10~14 Place on 2 paper towels. 2-3 minutes
(
170~230 g
each) Turn over halfway through cooking.
Spinach, Fresh, 450 g 4~7
Add
1
/
2
cup water in 2 qt. covered casserole dish. 2-3 minutes
Leaf
Squash, Acorn or 1 medium 6~8 Cut squash in half. Remove seeds. 2-3 minutes
Butternut, Fresh Place in 8 x 8-inch baking dish. Cover.
Zucchini, Fresh, 450 g
4
1
/
2
~7
1
/
2
Add
1
/
2
cup water in 1
1
/
2
qt. covered casserole dish. 2-3 minutes
Sliced Stir halfway through cooking.
Zucchini, Fresh, 450 g 6~9 Pierce. Place on 2 paper towels. 2-3 minutes
Whole Turn zucchini over and rearrange halfway through
cooking.
VegetableAmountInstructions
1
/
2
1
/
2
1
/
2
FRESH VEGETABLE GUIDE
Slice. Add
1
/
1
2
cup water in 1
/
2
qt. covered casserole dish.
18
MICROWAVE-SAFE UTENSILS
Never use metal or metal trimmed utensils in Paper
your microwave oven Paper plates and containers are convenient and
Microwaves cannot penetrate metal. They will safe to use in your microwave oven, provided that
bounce off any metal object in the oven and the cooking time is short and foods to be cooked
cause arcing, an alarming phenomenon that are low in fat and moisture. Paper towels are also
resembles lightning. very useful for wrapping foods and for lining
Most heat resistant non metallic cooking utensils baking trays in which greasy foods such as bacon
are safe for use in your microwave oven. are cooked. In general, avoid colored paper
However, some may contain materials that products as the colour may run. Some recycled
render them unsuitable as microwave cookware. paper products may contain impurities which
If you have any doubts about a particular utensil, could cause arcing or fires when used in the
there’s a simple way to find out if it can be used microwave oven.
in your microwave oven. Plastic cooking bags
Place the utensil in question next to a glass bowl Provided they are made specially for cooking,
filled with water in the microwave oven. cooking bags are microwave safe. However, be
Microwave at power HIGH for 1 minute. If the sure to make a slit in the bag so that steam can
water heats up but the utensil remains cool to the escape. Never use ordinary plastic bags for
touch, the utensil is microwave-safe. However, if cooking in your microwave oven, as they will melt
the water does not change temperature but the and rupture.
utensil becomes warm, microwaves are being Plastic microwave cookware
absorbed by the utensil and it is not safe for use A variety of shapes and sizes of microwave
in the microwave oven. You probably have many cookware are available. For the most part, you
items on hand in your kitchen right now that can can probably use items you already have on
be used as cooking equipment in your microwave hand rather than investing in new kitchen
oven. Just read through the following checklist. equipment.
Dinner plates Pottery, stoneware and ceramic
Many kinds of dinner-ware are microwave-safe. If Containers made of these materials are usually
in doubt consult the manufacturer’s literature or fine for use in your microwave oven, but they
perform the microwave test. should be tested to be sure.
Glassware
Glassware that is heat-resistant is microwave-
CAUTION
safe. This would include all brands of oven
tempered glass cookware. However, do not use
Some items with high lead or iron content are
delicate glassware, such as tumblers or wine
not suitable for cooking utensils.
glasses, as these might shatter as the food
Do not use any China, pottery, or stoneware
warms.
utensils or items that are finished with reflective
Plastic storage containers
paint. Using these can cause arcing and damage
These can be used to hold foods that are to be
the utensil.
quickly reheated. However, they should not be
used to hold foods that will need considerable
time in the oven as hot foods will eventually warp
or melt plastic containers and cause them to
pressurize and possibly explode.
19
FOOD CHARACTERISTICS & MICROWAVE COOKING
Keeping an eye on things Moisture content of food
The recipes in this book have been formulated Since the heat generated from microwaves tends
with great care, but your success in preparing to evaporate moisture, relatively dry food such as
them depends on how much attention you pay to roasts and some vegetables should either be
the food as it cooks. Always watch your food sprinkled with water prior to cooking or covered to
while it cooks. Your microwave oven is equipped retain moisture.
with a light that turns on automatically when the Bone and fat content of food
oven is in operation so that you can see inside Bones conduct heat and fat cooks more quickly
and check the progress of your food. Directions than meat. Care must be taken when cooking
given in recipes to elevate, stir, and the like bony or fatty cuts of meat that they do not cook
should be thought of as the minimum steps unevenly and do not become overcooked.
recommended. If the food seems to be cooking Quantity of food
unevenly, simply make the necessary The number of microwaves in your oven remains
adjustments you think appropriate to correct the constant regardless of how much food is being
problem. cooked. Therefore, the more food you place in
Factors affecting microwave cooking times the oven, the longer the cooking time. Remember
Many factors affect cooking times. The to decrease cooking times by at least one third
temperature of ingredients used in a recipe when halving a recipe.
makes a big difference in cooking times. For Shape of food
example, a cake made with ice-cold butter, milk, Microwaves penetrate only about 2.5 cm into
and eggs will take considerably longer to bake food, the interior portion of thick foods are cooked
than one made with ingredients that are at room as the heat generated on the outside travels
temperature. All of the recipes in this book give a inward. Only the outer edge of food is cooked by
range of cooking times. In general, you will find microwave energy; the rest is cooked by
that the food remains under-cooked at the lower conduction. The worst possible shape for a food
end of the time range, and you may sometimes that is to be microwaved is a thick square. The
want to cook your food beyond the maximum time corners will burn long before the centre is even
given, according to personal preference. The warm . Round thin foods and ring shaped foods
governing philosophy of this book is that it is best cook successfully in the microwave.
for a recipe to be conservative in giving cooking Covering
times. While overcooked food is ruined for good. A cover traps heat and steam which causes food
Some of the recipes, particularly those for bread, to cook more quickly. Use a lid or microwave
cake, and custards, recommend that food be cling film with a corner folded back to prevent
removed from the oven when they are slightly splitting.
undercooked. This is not a mistake. When Browning
allowed to stand, usually covered, these foods Meats and poultry that are cooked fifteen minutes
will continue to cook outside of the oven as the or longer will brown lightly in their own fat. Food
heat trapped within the outer portions of the food that is cooked for a shorter period of time may be
gradually travels inward. If the food is left in the brushed with a browning sauce such as
oven until it is cooked all the way through, the Worcestershire sauce, soy sauce or barbecue
outer portions will become overcooked or even sauce to achieve an appetizing colour. Since
burnt. You will become increasingly skilful in relatively small amounts of browning sauce is
estimating both cooking and standing times for added to food, the original flavour of the recipe is
various foods. not altered.
Density of food Covering with greaseproof paper
Light, porous food such as cakes and bread cook Greaseproofing effectively prevents spattering
more quickly than heavy, dense foods such as and helps food retain some heat. But because it
roasts and casseroles. You must take care when makes a looser cover than a lid or clingfilm, it
microwaving porous food that the outer edges do allows the food to dry out slightly.
not become dry and over cooked. Over cooked Arranging and spacing
foods can be a fire hazard. Individual foods such as baked potatoes, small
Height of food
cakes and hors d’oeuvres will heat more evenly if
The upper portion of tall food, particularly roasts,
placed in the oven an equal distance apart,
will cook more quickly than the lower portion.
preferably in a circular pattern. Never stack foods
Therefore, it is wise to turn tall food during
on top of one another.
cooking, sometimes several times.
20
FOOD CHARACTERISTICS & MICROWAVE COOKING
Stirring
Standing time
Stirring is one of the most important of all
Foods are often allowed to stand for 3 to 10
microwaving techniques. In conventional cooking,
minutes after being removed from the microwave
food is stirred for the purpose of blending.
oven. Usually the foods are covered during
Microwaved food, however, is stirred in order to
standing time to retain heat unless they are
spread and redistribute heat. Always stir from the
supposed to be dry in texture (some cakes and
outside towards the centre as the outside of the
biscuits, for example). Standing allows foods to
food heats first.
finish cooking and also helps flavour blend and
Turning over
develop.
Large, tall foods such as roasts and whole
chickens should be turned so that the top and
To Clean Your Oven
bottom will cook evenly. It is also a good idea to
1 Keep the inside of the oven clean
turn cut up chicken and chops.
Food spatters or spilled liquids stick to oven walls
and between the oven and door surface. It is best to
Placing thicker portions facing outwards
wipe up spillovers with a damp cloth immediately.
Since microwaves are attracted to the outside
Not doing so could cause the paint finish to become
portion of food, it makes sense to place thicker
damaged. Crumbs and spillovers will absorb microwave
portions of meat, poultry and fish to the outer
energy and lengthen cooking times. Use a damp
edge of the baking dish. This way, thicker
cloth to wipe out crumbs that fall between the
portions will receive the most microwave energy
door and the frame. It is important to keep this
and the food will cook evenly.
area clean to assure a tight seal. Remove greasy
Shielding
spatters with a soapy cloth then rinse and dry. Do
Strips of aluminium foil (which block microwaves)
not use harsh detergent or abrasive cleaners.
can be placed over the corners or edges of
The glass tray can be washed by hand or in the
square and rectangular food to prevent those
dishwasher.
portions from overcooking. Never use too much
2 Keep the outside of the oven clean
foil and make sure the foil is secured to the dish
Clean the outside of your oven with soap and
and does not come into contact with the oven
water then with clean water and dry with a soft
cavity as it may cause ‘arcing’ in the oven.
cloth or paper towel. To prevent damage to the
Elevating
operating parts inside the oven, the water should
Thick or dense foods can be elevated so that
not be allowed to seep into the ventilation
microwaves can be absorbed by the underside
openings. To clean control panel, open the door
and centre of the foods.
to prevent oven from accidentally starting, and
then wipe the control panel with a damp cloth,
Piercing
followed immediately by a dry cloth. Press STOP
Foods enclosed in a shell, skin or membrane are
after cleaning whilst the door is still open.
likely to burst in the oven unless they are pierced
3 If steam accumulates inside or around the
prior to cooking. Such foods include yolks and
outside of the oven door, wipe the panels with a
whites of eggs, clams and oysters and whole
soft cloth. Condensation may also form inside the door.
vegetables and fruits.
To prevent or reduce this occurrence, reduce the
Testing if cooked
cooking power, or reduce the cooking time.
Food cooks so quickly in a microwave oven, it is
This may occur when the microwave
necessary to test it frequently. Some foods are
oven is operated under high humidity conditions
left in the microwave until completely cooked, but
and in no way indicates a malfunction of the unit.
most foods, including meats and poultry, are
removed from the oven while still slightly
4 The door and door seals should be kept clean.
undercooked and allowed to finish cooking during
Use only warm, soapy water, rinse then dry
standing time. The internal temperature of foods
thoroughly.
will rise between 3°C and 8°C during standing
DO NOT USE ABRASIVE MATERIALS, SUCH
time.
AS CLEANING POWDERS OR STEEL AND
PLASTIC PADS.
Metal parts will be easier to maintain if wiped
frequently with a damp cloth.
21
IMPORTANT SAFETY INSTRUCTIONS
Please keep for future reference. Read and follow all instructions before using your oven to prevent the risk of fire,
This guide does not cover all possible conditions that may occur. Always contact your service agent or manufacturer
about problems that you do not understand.
WARNING
This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “WARNING” or “CAUTION”.
These word means :
CAUTION
WARNING
This symbol will alert you to hazards or unsafe practices which could cause serious bodily harm or death.
This symbol will alert you to hazards or unsafe practices which could cause bodily injury or property damage.
WARNING
1
2
3
It can be the cause of serious damage to safety such as a fire, a burn or a sudden death due to an electric shock.
Do not attempt to tamper with, or make any adjustments or repairs to the door, door seals,
control panel, safety interlock switches or any other part of the oven which would involve the
removal of any cover protecting against exposure to of service technician.the microwave oven
are faulty. Repairs should only be undertaken by a qualified service technician.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
Liquids or other foods must not be heated in sealed containers since they are liable to explode.
Remove the plastic wrapping from food before cooking or defrosting. Note though that in some
cases food should be covered with plastic film, for heating or cooking.
Do not use the oven for the purpose of dehumidification.(ex. Operating themicrowave oven
with wet newspapers, clothes, toys, electric devices, pet or child etc.)
Unlike other appliances, the microwave oven is a high-voltage and a highelectrical-current piece of equipment.
Improper use or repair could result in harmful exposure to excessive microwave energy or in electric shock.
4
A
ccessible parts may become hot during use. Young children should be kept away.
They may get a burn.
5
They could burst.
6
Be certain to use proper accessories on each operation mode
Improper use could result in damage to your oven and accessories, or could make spark and a fire.
.
22
7
T
he children should not allow to play with accessories or hang down from the door handle.
They may get hurt.
8 I
f the door or door seals are damaged, the oven must not be operated until it has been repaired
by a competent person.
9
I
t is hazardous for anyone other than a competent person to carry out any service or repair
operation that involves the removal of a cover which gives protection against exposure to
microwave energy.
10
W
hen the appliance is operated in the combination mode, children should only use the oven
under adult supervision due to the temperatures generated.
CAUTION
1
2
3
4
5
6
7
You cannot operate your oven with the door open due to the safety interlocks built into the door
mechanism. It is important not to tamper with the safety interlocks.
Do not place any object (such as kitchen towels, napkins, etc.) between the oven front face and
the door or allow food or cleaner residue to accumulate on sealing surfaces.
It could result in harmful exposure to excessive microwave energy.
Do not operate your oven if it is damaged. It is particularly important that the oven door closes
properly and that there is no damage to the:(1) door(bent), (2) hinges and latches (broken or
loosened), (3) door seals and sealing surfaces.
It could result in harmful exposure to excessive microwave energy.
Please ensure cooking times are correctly set, Small amounts of food require shorter cooking or
heating time.
When heating liquids, e.g. soups, sauces and beverages in your microwave oven,
Avoid using straight sided containers with narrow necks.
Do not overheat.
Stir the liquid before placing the container in the oven and again halfway through the
heating time.
After heating, let it stand in the oven for a short time; stir or shake it again carefully and check
the temperature of it before consuming to avoid burns
(especially, contents of feeding bottles and baby food jars).
Microwave heating of beverages can result in delayed eruptive boiling, therefore care has to
be taken when handling the container.
An exhaust outlet is located on the top, bottom or side of the oven.
Don't block the outlet.
It could result in damage to your oven and poor cooking results.
Do not operate the oven when empty. It is best to leave a glass of water in the oven when not
in use. The water will safely absorb all microwave energy, if the oven is accidentally started.
Improper use could result in damage to your oven.
23
8
Do not cook food wrapped in paper towels, unless your cook book contains instructions for the
food you are cooking. And do not use newspaper in place of paper towels for cooking.
9
Do not use wooden containers and ceramic containers that have metallic (e.g. gold or silver)
inlays. Always remove metal twist ties. Check that the utensils are suitable for use in
microwave ovens before use.
Metallic containers for food and beverages are not allowed during microwave cooking.
They may heat-up and char. Metal objects in particular may arc in the oven, which can cause serious damage.
10
11
12
13
14
15
16
17
Do not use recycled paper products.
Do not rinse the tray and rack by placing it in water just after cooking. This may cause breakage
or damage.
Improper use could result in damage to your oven.
Be certain to place the oven so the front of the door is 8 cm or more behind the edge of the
surface on which it is placed, to avoid accidental tipping of the appliance.
Improper use could result in bodily injury and oven damage.
Before cooking, pierce the skin of potatoes, apples or any such fruit or vegetable.
They could burst.
Do not cook eggs in their shell. Eggs in their shell and whole hardboiled eggs should not be
heated in microwave ovens since they may explode, even after microwave heating has ended.
Pressure will build up inside the egg which will burst.
D
o not attempt deep fat frying in your oven.
This could result in a sudden boil over of the hot liquid.
If smoke is observed (or emitted), switch off or unplug the appliance and keep the door closed
When food is heated or cooked in disposable containers made of plastic, paper or other
combustible materials, keep an eye on the oven and check it frequently.
19
18
20
The temperature of accessible surfaces may be high when the appliance is operating. Do not
touch the oven door, outer cabinet, rear cabinet, oven cavity, accessories and dishes during
grill mode, convection mode and auto cook operations, before clearing make sure they are
not hot.
As they will become hot, there is the danger of a burn unless wearing thick culinary gloves .
The oven should be cleaned regularly and any food deposits should be removed.
Failure to maintain the oven in a clean condition could lead to deterioration of the surface that
could adversely affect the life of the appliance and possibly result in a hazardous situation.
Only use the temperature probe recommended for this oven.
You can not ascertain that the temperature is accurate with an unsuitable temperature probe.
24
21
Follow exact directions given by each manufacturer for their popcorn product. Do not leave the
oven unattended while the corn is being popped. If corn fails to pop after the suggested times,
discontinue cooking. Never use a brown paper bag for popping corn. Never attempt to pop
leftover kernels.
22
T
his appliance must be earthed.
The wires in the mains lead are colored in accordance with the following codes
BLUE ~ Neutral
BROWN ~ Live
GREEN & YELLOW ~ Earth
23
As the colours of the wires in the mains lead of this appliance may not correspond with the
coloured markings identifying the terminals in your plug proceed as follows:
The wire which is colored BLUE must be connected to the terminal which is marked with the letter
N or Colored BLACK. The wire which is colored BROWN must be connected to the terminal which
is marked with the letter L or colored RED. The wire which is colored GREEN & YELLOW or
GREEN must be connected to the terminal which is marked with the letter E or .
If the supply cord is damaged, it must be replaced by the manufacturer, a service
Improper use may cause serious electric damage.
This oven should not be used for commercial catering purposes.
Improper use could result in damage to your oven.
24
25
26
27
28
29
30
31
32
33
T
he connection may be achieved by having the plug accessible or by incorporating a switch in
Children should be supervised to ensure that they do not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
The appliance is not intended to be operated by means of an external timer or separate
remote-control system.
Only use utensils that are suitable for use in microwave ovens.
This microwave oven must not be placed in a cabinet.
This microwave oven is intended to be used freestanding.
Keep the appliance and its cord out of reach of children less than 8 years.
The door or the outer surface may get hot when the appliance is operating.
This appliance is intended to be used in
hou
sehold
and similar applications
such as
- farm houses
- by clients in hotels, motels and other residential environments
- bed and breakfast type environments
The microwave oven is intended for heating food and beverages. Drying of food or clothing
and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of
25
34
35
T
he contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature
checked before consumption, in order to avoid burns.
According to the installation requirements set, otherwise the impact of heat, prone to danger.
36
37
S
team cleaner is not to be used.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervisionor instruction concerning use of the appliance by a person responsiblefor their safety.
Children should be supervised to ensure that they do not play with the appliance.
QUESTION & ANSWERS
Q What’s wrong when the oven light will not
glow?
A There may be several reasons why the oven light
will not glow.
Light bulb has blown.
Door is closed.
FOLLOW EXACT DIRECTIONS GIVEN BY
Q Does microwave energy pass through the
EACH MANUFACTURER FOR THEIR
viewing screen in the door?
POPCORN PRODUCT. DO NOT LEAVE THE
A No. The holes, or ports, are made to allow light
OVEN UNATTENDED WHILE THE CORN IS
to pass; they do not let microwave energy
BEING POPPED. IF CORN FAILS TO POP
through.
AFTER THE SUGGESTED TIMES,
Q Why does the beep tone sound when a pad
DISCONTINUE COOKING. OVERCOOKING
on the Control Panel is touched?
COULD RESULT IN THE CORN CATCHING
A The beep tone sounds to assure that the setting
FIRE.
is being properly entered.
Q Will the microwave oven be damaged if it
CAUTION
operates empty?
NEVER USE A BROWN PAPER BAG FOR
A Yes. Never run it empty or without the glass
POPPING CORN. NEVER ATTEMPT TO POP
tray.
LEFTOVER KERNELS.
Q Why do eggs sometimes pop?
A When baking, frying, or poaching eggs, the yolk
Q Why doesn’t my oven always cook as fast as
may pop due to steam build up inside the yolk
the cooking guide says?
membrane. To prevent this, simply pierce the
A Check your cooking guide again to make sure
yolk before cooking. Never microwave eggs in
you’ve followed directions correctly, and to see
the shell.
what might cause variations in cooking time.
Cooking guide times and heat settings are
Q Why is standing time recommended after
suggestions, chosen to help prevent
microwave cooking is over?
overcooking, the most common problem in
A After microwave cooking is finished, food keeps
getting used to a microwave oven. Variations in
on cooking during standing time. This standing
the size, shape, weight and dimensions of the
time finishes cooking evenly throughout the food.
food require longer cooking time. Use your own
The amount of standing time depends on the
judgement along with the cooking guide
density of the food.
suggestions to test food condition, just as you
Q Is it possible to pop corn in a microwave
would do with a conventional cooker.
oven?
A Yes, if using one of the two methods described
:
1 Popcorn-popping utensils designed specifically
for microwave cooking.
2 Prepackaged microwave popcorn that contains
specific times and power outputs needed for
an acceptable final product.
26
TECHNICAL SPECIFICATIONS
*IEC 60705 RATING STANDARD
Specifications subject to change without prior notice.
MODEL
Power Supply
Rated Power Consumption
Microwave
Frequency
Overall Dimensions(WXHXD)
Oven Cavity Dimensions(WXHXD)
NET WEIGHT
SHIPPING WEIGHT
1500 W
*1100 W
2450 MHz
505 X 291X 395
358 X 226X 364
(mm)
(mm)
230 / 240 V
~
50 Hz
MS3042G1 /MS3042X1
Output power.
12.9
Kg
/
15.7
Kg
/
13.1
Kg
15.9
Kg
27
The wires in this mains lead are colored in accordance with the
following codes
BLUE ~ Neutral
BROWN ~ Live
GREEN & YELLOW ~ Earth
As the colours of the wires in the mains lead of this appliance may
not correspond with the coloured markings identifying the terminals
in your plug proceed as follows:
The wire which is colored BLUE must be connected to the terminal
which is marked with the letter N or Colored BLACK.
The wire which is colored BROWN must be connected to the
terminal which is marked with the letter L or colored RED.
The wire which is colored GREEN & YELLOW or GREEN must be
connected to the terminal which is marked with the letter E or .
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person in
order to avoid a hazard;
PLUG WIRING INFORMATION
Warning
This appliance must be earthed
Printed in China
LGEAP
