Sony STR-DH810 Audio Video Receiver User Manual

4-168-075-13(1)

Multi Channel AV

Receiver

Operating Instructions

STR-DH810

To reduce the risk of fire or electric

shock, do not expose this apparatus to

rain or moisture.

To reduce the risk of fire, do not cover the

ventilation opening of the apparatus with

newspapers, tablecloths, curtains, etc. Do not place

the naked flame sources such as lighted candles on

the apparatus.

Do not install the appliance in a confined space, such

as a bookcase or built-in cabinet.

To reduce the risk of fire or electric shock, do not

expose this apparatus to dripping or splashing, and

do not place objects filled with liquids, such as

vases, on the apparatus.

As the main plug is used to disconnect the unit from

the mains, connect the unit to an easily accessible

AC outlet. Should you notice an abnormality in the

unit, disconnect the main plug from the AC outlet

immediately.

Do not expose batteries or apparatus with battery-

installed to excessive heat such as sunshine, fire or

the like.

The unit is not disconnected from the mains as long

as it is connected to the AC outlet, even if the unit

itself has been turned off.

Excessive sound pressure from earphones and

headphones can cause hearing loss.

This symbol is intended to alert

the user to the presence of the Hot

Surface that may be hot if it is

touched during the normal

operation.

For customers in the United

States

Owner’s Record

The model and serial numbers are located on the rear

of the unit. Record these numbers in the space

provided below. Refer to them whenever you call

upon your Sony dealer regarding this product.

Model No.

Serial No.

This symbol is intended to alert the

user to the presence of uninsulated

“dangerous voltage” within the

product’s enclosure that may be of

sufficient magnitude to constitute a

risk of electric shock to persons.

This symbol is intended to alert the

user to the presence of important

operating and maintenance

(servicing) instructions in the

literature accompanying the

appliance.

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as

radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce

heat.

9) Do not defeat the safety purpose of the polarized

or grounding-type plug. A polarized plug has

two blades with one wider than the other. A

grounding type plug has two blades and a third

grounding prong. The wide blade or the third

prong are provided for your safety. If the

provided plug does not fit into your outlet,

consult an electrician for replacement of the

obsolete outlet.

10)Protect the power cord from being walked on or

pinched particularly at plugs, convenience

receptacles, and the point where they exit from

the apparatus.

11)Only use attachments/accessories specified by

the manufacturer.

12)Use only with the cart, stand, tripod, bracket, or

table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to

avoid injury from tip-over.

WARNING

13)Unplug this apparatus during lightning storms or

when unused for long periods of time.

14)Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has

been damaged in any way, such as power-supply

cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

The following FCC statement

applies only to the version of

this model manufactured for

sale in the U.S.A. Other

versions may not comply with

FCC technical regulations.

NOTE:

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference in a residential installation.

This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However,

there is no guarantee that interference will not occur

in a particular installation. If this equipment does

cause harmful interference to radio or television

reception, which can be determined by turning the

equipment off and on, the user is encouraged to try

to correct the interference by one or more of the

following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment

and receiver.

– Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected.

– Consult the dealer or an experienced radio/TV

technician for help.

CAUTION

You are cautioned that any changes or modifications

not expressly approved in this manual could void

your authority to operate this equipment.

To reduce the risk of electric shock, the speaker cord

should be connected to the apparatus and the

speakers in accordance with the following

instructions.

1) Disconnect the AC power cord from the MAINS.

2) Strip 10 to 15 mm of the wire insulation of the

speaker cord.

3) Connect the speaker cord to the apparatus and

the speakers carefully so as not to touch the core

of speaker cord by hand. Also disconnect the AC

power cord from the MAINS before

disconnecting the speaker cord from the

apparatus and the speakers.

For customers in Europe

Disposal of Old Electrical &

Electronic Equipment

(Applicable in the European

Union and other European

countries with separate

collection systems)

This symbol on the product or on its packaging

indicates that this product shall not be treated as

household waste. Instead it shall be handed over to

the applicable collection point for the recycling of

electrical and electronic equipment. By ensuring this

product is disposed of correctly, you will help

prevent potential negative consequences for the

environment and human health, which could

otherwise be caused by inappropriate waste

handling of this product. The recycling of materials

will help to conserve natural resources. For more

detailed information about recycling of this product,

please contact your local Civic Office, your

household waste disposal service or the shop where

you purchased the product.

continued

Disposal of waste batteries

(applicable in the European

Union and other European

countries with separate

collection systems)

This symbol on the battery or on the packaging

indicates that the battery provided with this product

shall not be treated as household waste.

On certain batteries this symbol might be used in

combination with a chemical symbol. The chemical

symbols for mercury (Hg) or lead (Pb) are added if

the battery contains more than 0.0005% mercury or

0.004% lead.

By ensuring these batteries are disposed of correctly,

you will help prevent potentially negative

consequences for the environment and human health

which could otherwise be caused by inappropriate

waste handling of the battery. The recycling of the

materials will help to conserve natural resources.

In case of products that for safety, performance or

data integrity reasons require a permanent

connection with an incorporated battery, this battery

should be replaced by qualified service staff only.

To ensure that the battery will be treated properly,

hand over the product at end-of-life to the applicable

collection point for the recycling of electrical and

electronic equipment.

For all other batteries, please view the section on

how to remove the battery from the product safely.

Hand the battery over to the applicable collection

point for the recycling of waste batteries.

For more detailed information about recycling of

this product or battery, please contact your local

Civic Office, your household waste disposal service

or the shop where you purchased the product.

Notice for customers: The following

information is only applicable to

equipment sold in countries applying

EU Directives.

The manufacturer of this product is Sony

Corporation, 1-7-1 Konan Minato-ku Tokyo,

108-0075 Japan. The Authorized Representative for

EMC and product safety is Sony Deutschland

GmbH, Hedelfinger Strasse 61, 70327 Stuttgart,

Germany. For any service or guarantee matters

please refer to the addresses given in separate

service or guarantee documents.

For customers in Australia

Disposal of Old Electrical &

Electronic Equipment

(Applicable in the European

Union and other European

countries with separate

collection systems)

About This Manual

• The instructions in this manual are for model

STR-DH810. Check your model number by

looking at the lower right corner of the front panel.

In this manual, models of area code CEL is used

for illustration purposes unless stated otherwise.

Any difference in operation is clearly indicated in

the text, for example, “Models of area code CEK

only”.

• The instructions in this manual describe the

controls on the supplied remote. You can also use

the controls on the receiver if they have the same

or similar names as those on the remote.

This receiver incorporates Dolby* Digital and Pro

Logic Surround and the DTS** Digital Surround

System.

* Manufactured under license from Dolby

Laboratories. Dolby, Pro Logic, and the double-

D symbol are trademarks of Dolby Laboratories.

** Manufactured under license under U.S. Patent

#’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762;

6,226,616; 6,487,535; 7,212,872; 7,333,929;

7,392,195; 7,272,567 & other U.S. and

worldwide patents issued & pending. DTS is a

registered trademark and the DTS logos, Symbol,

DTS-HD and DTS-HD Master Audio are

This receiver incorporates High-Definition

Multimedia Interface (HDMI

) technology.

HDMI, the HDMI Logo, and High-Definition

Multimedia Interface are trademarks or registered

trademarks of HDMI Licensing LLC in the United

States and other countries.

“x.v.Colour (x.v.Color)” and “x.v.Colour

(x.v.Color)” logo are trademarks of Sony

Corporation.

“BRAVIA” is a trademark of Sony Corporation.

“S-AIR” and its logo are trademarks of Sony

Corporation.

“PLAYSTATION” is a trademark of Sony

Computer Entertainment Inc.

About area codes

The area code of the receiver you purchased is

shown on the lower right portion of the rear panel

(see the illustration below).

Any differences in operation, according to the area

code, are clearly indicated in the text, for example,

“Models of area code AA only”.

IN 1 TV OUT

ARC

LE (INPUT ONLY)

SURROUND

FRONT A

4-XXX-XXX-XX(X) AA

Area code

On Copyrights

Table of Contents

About This Manual........................................5

Supplied accessories......................................7

Description and location of parts...................8

Connections

1: Installing the speakers .............................17

2: Connecting the speakers..........................19

3: Connecting the TV ..................................21

4a: Connecting the audio components.........23

4b: Connecting the video components ........24

5: Connecting the antennas (aerials)............32

6: Inserting the wireless transmitter/

transceiver...............................................32

7: Connecting the AC power cord

(mains lead) ............................................33

Preparing the Receiver

Initializing the receiver................................34

Selecting the speaker system .......................34

Calibrating the appropriate speaker settings

automatically

(AUTO CALIBRATION) .......................35

Adjusting the speaker levels

(TEST TONE) ........................................42

Basic Operations

Playback ......................................................43

Viewing information on the display ............44

Using the Sleep Timer .................................45

Recording ....................................................45

Tuner Operations

Listening to FM/AM radio ..........................46

Presetting FM/AM radio stations ................48

Using the Radio Data System (RDS) ..........50

(Models of area code CEL, CEK, AU1

only)

Enjoying Surround Sound

Selecting the sound field............................. 51

Enjoying the surround effect at low

volume levels (NIGHT MODE) ............ 55

Resetting sound fields to the initial

settings ................................................... 55

“BRAVIA” Sync Features

What is “BRAVIA” Sync? .......................... 56

Preparing for the “BRAVIA” Sync............. 56

Playing back components with one-touch

operation (One-Touch Play)................... 57

Enjoying the TV sound from the

speakers connected to the receiver

(System Audio Control)......................... 58

Turning off the receiver with the TV

(System Power Off) ............................... 59

Enjoying movies with the optimum sound

field (Theatre/Theater Mode Sync)........ 59

Enjoying the TV sound via an HDMI

cable (Audio Return Channel) ............... 60

S-AIR Operations

About S-AIR products ................................ 60

Setting up an S-AIR product....................... 62

Enjoying the system’s sound in another

room ....................................................... 64

Changing the channel for better sound

transmission ........................................... 66

Stabilizing S-AIR reception........................ 67

Enjoying the S-AIR receiver while the

S-AIR main unit is in standby mode...... 68

Advanced Operations

Switching between digital and analog

audio (INPUT MODE) .......................... 69

Enjoying the sound/images from other

inputs...................................................... 69

Enjoying sound/images from the

components connected to the

DIGITAL MEDIA PORT....................... 71

Using a bi-amplifier connection.................. 71

Using the setting menu................................ 72

Using the Remote

Programming the remote............................. 85

Clearing all the contents of the remote’s

memory .................................................. 90

Additional Information

Glossary ...................................................... 90

Precautions .................................................. 93

Troubleshooting .......................................... 95

Specifications ............................................ 101

Index.......................................................... 103

Supplied accessories

• Operating instructions (this manual)

• Quick Setup Guide

• FM wire antenna (aerial) (1)

• AM loop antenna (aerial) (1)

• Remote commander (1)

– RM-AAP049 (Models of area code U2

only)

– RM-AAP050 (Models of area code CEL,

CEK, AU1 only)

• R6 (size-AA) batteries (2)

• Optimizer microphone (ECM-AC2) (1)

Description and location of parts

A ?/1 (on/standby) (page 34, 48, 55)

B TONE +/–, TONE MODE (page 81)

C INPUT SELECTOR (page 43)

D Display (page 9)

E Remote sensor

Receives signals from remote commander.

F DIMMER (page 85)

G MASTER VOLUME (page 42, 43)

H MUTING (page 43)

I VIDEO 2 IN jacks (page 30)

J AUTO CAL MIC jack (page 36)

K DISPLAY (page 44)

L 2CH/A.DIRECT, A.F.D., MOVIE, MUSIC

(page 51)

M TUNING MODE, TUNING +/–,

MEMORY/ENTER (page 46)

N INPUT MODE (page 69)

O PHONES jack (page 95)

P SPEAKERS (page 34)

Front panel

?/1

qa q; 9qsqdqf

7841 32

Indicators on the display

LFE

NEO

TrueHD

DTS

MSTR HI RESEQ RDS MEM LBR

AIR

PLII x z

HDMI COAXANALOG OPT ARC

D.RANGE ST

DTS

ES LPCM SLEEP

AMP

SP A B

96/24

L RC

SBL SBRSB

SL SRS

456 8213 7

9qaqsqdqfqhqj qg

Indicator and explanation

A SW

Lights up when the audio signal is output from

the SUBWOOFER jack.

B Dolby Pro Logic indicators

Lights up one of the respective indicators when

the receiver performs Dolby Pro Logic

processing. This matrix surround decoding

technology can enhance input signals.

PL II

PL IIx

PL IIz

Dolby Pro Logic

Dolby Pro Logic II

Dolby Pro Logic IIx

Dolby Pro Logic IIz

Note

These indicators may not light up depending on

the speaker pattern setting.

C Input indicators

Light up to indicate the current input.

ANALOG

Lights up when INPUT MODE is set to

“ANALOG” or no digital signals are detected

when INPUT MODE is set to “AUTO” (page

69).

HDMI

Lights up when the receiver recognizes a

component connected via an HDMI IN jack

(page 24).

COAX

Lights up when INPUT MODE is set to

“AUTO” and the source signal is a digital signal

being input through the COAXIAL jack (page

69).

OPT

Lights up when INPUT MODE is set to

“AUTO” and the source signal is a digital signal

being input through the OPTICAL jack (page

69).

Indicator and explanation

D ARC

Lights up when TV input is selected and the

Audio Return Channel (ARC) signals are

detected (page 60).

E Dolby Digital Surround indicators

Lights up one of the respective indicators when

the receiver is decoding the corresponding

Dolby Digital format signals.

D EX

D+

TrueHD

Dolby Digital

Dolby Digital Surround EX

Dolby Digital Plus

Dolby TrueHD

Note

When playing a Dolby Digital format disc, be

sure that you have made digital connections and

that INPUT MODE is set to “AUTO” (page 69).

F NEO:6

Lights up when DTS Neo:6 Cinema/Music

decoder is activated (page 51).

G DTS-HD indicators

Lights up one of the respective indicators when

the receiver is decoding the corresponding DTS-

HD format signals.

DTS-HD MSTR

DTS-HD HI RES

DTS-HD LBR

DTS-HD Master Audio

DTS-HD High Resolution

Audio

DTS-HD Low Bit Rate

Audio

H S-AIR

Lights up when the S-AIR transmitter (not

supplied) is inserted.

I SP A/SP B/SP A B

Lights up according to the speaker system used

(page 34). However, these indicators do not

light up if the speaker output is turned off or if

headphones are connected.

continued

Indicator and explanation

J BI-AMP

Lights up when surround back speakers

selection is set to “BI-AMP” (page 71).

K SLEEP

Lights up when the Sleep Timer is activated

(page 45).

L LPCM

Lights up when the receiver is decoding the

Linear PCM signals.

M DTS(-ES) indicators

Lights up when the receiver is decoding the

DTS or DTS-ES signals.

DTS

DTS-ES

DTS 96/24

DTS

DTS-ES

DTS 96 kHz/24 bit

Note

When playing a DTS format disc, be sure that

you have made digital connections and that

INPUT MODE is set to “AUTO” (page 69).

N Tuning indicators

Lights up when the receiver tunes in radio

stations.

RDS (Models of area code CEL, CEK,

AU1 only)

A station that provides RDS services is tuned in.

MEM

Lights up when a memory function, such as

Preset Memory (page 48), etc., is activated.

Stereo broadcast

O EQ

Lights up when the equalizer is activated.

P D.RANGE

Lights up when dynamic range compression is

activated (page 77).

Lights up when the disc being played back

contains an LFE (Low Frequency Effect)

channel and the LFE channel signal is actually

being reproduced.

LFE

Indicator and explanation

R Playback channel indicators

The letters (L, C, R, etc.) indicate the channels

being played back. The boxes around the letters

vary to show how the receiver downmixes or

upmixes the source sound (based on the speaker

settings).

SBL

SBR

Front Left High

Front Right High

Front Left

Front Right

Center (monaural)

Surround Left

Surround Right

Surround (monaural or the

surround components

obtained by Pro Logic

processing)

Surround Back Left

Surround Back Right

Surround Back (the

surround back components

obtained by 6.1 channel

decoding)

Example:

Speaker pattern: 3/0.1

Recording format: 3/2.1

Sound Field: A.F.D. AUTO

LFE

L RC

SL SR

Rear panel

EZW-T100

ANTENNA

DMPORT

IN 4 IN 3 IN 2 IN 1 TV OUT

ARC

DC5V

0.7A MAX

IN 3 IN 2 IN 1

OPTICAL

MONITOR

OUT

AUDIO

OUT

AUDIO

OUT

AUDIO

VIDEO

OUT

OPTICAL

SAT

CATV

COAXIAL

SA-CD

CD-R

SAT

CATV SUBWOOFER

AUDIO

VIDEO

AUDIO

OUT

VIDEO

OUT

AUDIO

VIDEO

VIDEO 1

MONITOR

HDMI

ASSIGNABLE (INPUT ONLY)

COMPONENT VIDEO

ASSIGNABLE (INPUT ONLY)

DIGITAL

)

LR LR

SPEAKERS

CENTER

SURROUND

FRONT A

SURROUND BACK/

FRONT HIGH/

BI-AMP/ FRONT B

645

4, 53421

A S-AIR section (page 32)

EZW-T100 slot

B DMPORT section (page 23)

DMPORT jack

C ANTENNA section (page 32)

FM ANTENNA jack

AM ANTENNA terminals

D Audio signal section

DIGITAL INPUT/OUTPUT jacks (page 21,

24, 27, 28, 29)

HDMI IN/OUT

OPTICAL IN

COAXIAL IN

ANALOG INPUT/OUTPUT jacks (page 21,

23, 27, 29, 30)

AUDIO

IN/OUT

AUDIO OUT

White (L)

Red (R)

Black

continued

* You can watch the selected input image when you

connect the HDMI TV OUT or MONITOR OUT

jack to a TV (page 21, 24).

You can use the supplied remote to operate the

receiver and to control the Sony audio/video

components that the remote is assigned to

operate.

You can also program the remote to control

non-Sony audio/video components. For details,

see “Programming the remote” (page 85).

• RM-AAP049 (Models of area

code U2 only)

• RM-AAP050 (Models of area

code CEL, CEK, AU1 only)

E Video signal section*

The image quality depends on the connecting

jack.

DIGITAL INPUT/OUTPUT

jacks (page 21, 24)

HDMI IN/OUT

COMPONENT VIDEO

INPUT/OUTPUT jacks (page

21, 27, 28, 29)

Y, PB/CB, PR/CR

IN/OUT

COMPOSITE VIDEO INPUT/

OUTPUT jacks (page 21, 27,

29, 30)

VIDEO IN/OUT

F SPEAKERS section (page 19)

Green

(Y)

Blue

B/CB)

Red

R/CR)

Yellow

Remote commander

BD DVD

SAT/

CATV

VIDEO 1 VIDEO 2

HDMI 3HDMI 2HDMI 1

HDMI 4

SA-CD/

TUNERDMPORT

High

quality


To control the receiver

Be sure to press AMP (C) to change the

remote button function to control the receiver.

The following buttons have tactile dots. Use the

tactile dots as references when operating the

receiver.

– number 5, VIDEO 1

– N

– PRESET +, TV CH + (RM-AAP049 only),

PROG + (RM-AAP050 only), c (RM-AAP050

only)

If you press ?/1 (A) and AV ?/1 (B)

simultaneously, the receiver and connected

components will turn off (SYSTEM STANDBY).

Press SHIFT (V) then only press this button.

Name and function

A ?/1

(on/standby)

Turns the receiver on or sets it to standby mode.

Saving the power in standby mode

When “CTRL: HDMI” is set to “CTRL OFF”

(page 76) and “S-AIR STBY” is set to “STBY

OFF” (page 76).

C AMP

The button lights up and activates the receiver

operation (page 38, 44, 45).

D Input buttons

Selects the component you want to play back or

record. When you press any of the input buttons,

the receiver turns on. The buttons are initial

assigned to control Sony components.

Numeric buttons

(number 5

)

Presets or tunes to preset stations.

ENTER

Enters the selection during tuner operation.

MEMORY

Stores a station during tuner operation.

E SOUND FIELD +/–

Selects a sound field (page 51).

G AMP MENU

Displays the menu to operate the receiver.

I MENU/HOME

Displays the receiver menus.

J TUNING +/–

Scans a station.

D.TUNING

Enters direct tuning mode.

K PRESET +

/–

Selects preset stations.

L SLEEP

Activates the Sleep Timer function and the

duration which the receiver turns off

automatically.

N MUTING (RM-AAP049 only)

(RM-AAP050 only)

Turns off the sound temporarily. Press again to

restore the sound.

O MASTER VOL +/– (RM-AAP049 only)

+/– (RM-AAP050 only)

Adjust the volume level of all speakers at the

same time.

Name and function

Q RETURN/EXIT O

Returns to the previous menu.

Press V/v/B /b to select the settings, then press

to enter the selection.

T DISPLAY

Views information on the display.

U NIGHT MODE

Activates the Night Mode function (page 55).

V SHIFT

The button lights up and activates the buttons

with pink printing.

Y RM SET UP

Set up the remote.

V/v/B/b

continued

To control a Sony TV

Press TV (W), then press the yellow printing

button to select the function you want.

The following buttons have tactile dots. Use the

tactile dots as references when operating the

receiver.

– number 5, VIDEO 1

– N

– PRESET +, TV CH + (RM-AAP049 only),

PROG + (RM-AAP050 only), c (RM-AAP050

only)

If you press ?/1 (A) and AV ?/1 (B)

simultaneously, the receiver and connected

components will turn off (SYSTEM STANDBY).

The function of AV ?/1 (B) changes

automatically each time you press the input

buttons (D).

Name and function

B AV ?/1

(on/standby)

Turns on or off the TV.

D Numeric buttons (number 5

)

Selects the TV channels.

-/--, >10

Selects the channel entry mode.

ENTER

Enters the value.

/ (Text) (RM-AAP050 only)

Displays text information.

F Color buttons

Displays an operation guide on the TV screen

when the color buttons are available. Follow the

operation guide to perform a selected operation.

H TOOLS/OPTIONS

Displays the TV options.

I MENU/HOME

Displays the TV menus.

K TV CH +

/– (RM-AAP049 only)

PROG +

/– (RM-AAP050 only)

Selects the preset TV channels.

/C (RM-AAP050 only)

In text mode: Selects the next or previous page.

M TV INPUT (RM-AAP049 only)

(Input select) (RM-AAP050 only)

Selects the input signal (TV or video).

(Text hold) (RM-AAP050 only)

In text mode: Holds the current page.

WIDE (RM-AAP049 only)

(Wide mode) (RM-AAP050 only)

Selects the wide picture mode.

N MUTING (RM-AAP049 only)

(RM-AAP050 only)

Activates the TV’s muting function.

O TV VOL +/– (RM-AAP049 only)

2 +/– (RM-AAP050 only)

Adjusts the TV volume.

Q RETURN/EXIT O

Returns to the previous TV menu.

S GUIDE (RM-AAP049 only)

(Guide) (RM-AAP050 only)

Displays the on-screen program guide.

Name and function

T DISPLAY (RM-AAP049 only)

Selects information of TV.

, (Info, Text reveal)

(RM-AAP050 only)

Displays information such as current channel

number and screen mode.

In text mode: Reveals hidden information (e.g.

answers to a quiz).

X THEATER (RM-AAP049 only)

THEATRE (RM-AAP050 only)

Sets the optimal picture settings automatically

for watching movies when you connect a Sony

TV that is compatible with the THEATER or

THEATRE button function (page 59).

To control other Sony components

Name

Blu-ray

disc, DVD

player

Satellite

tuner

VCR PSX DVD/VCR

COMBO,

DVD/HDD

COMBO

VCD,

LD player

CD player,

MD/DAT/

Tape deck

B AV ?/1

Power Power Power Power Power Power Power

D Numeric

buttons

a)c)

Channel Channel Channel Channel Channel Track Track

-/--

, >10

Clear Channel

entry mode,

clear

Channel

entry mode

Clear Clear >10 >10

ENTER

Enter Enter Enter Enter Enter Enter

Enter

F Color

buttons

Menu,

guide

Menu,

guide

–––––

H TOOLS/

OPTIONS

Options

– – Options

Options

––

I MENU/HOME Menu Menu Menu Menu Menu – –

J ./>

Skip

track

–Skip

track

Skip

track

index

Skip

track

Skip

track

/ R epl ay /

Fast

forward

scene

– – – R ep la y/

Fast

forward

scene

––

m/M

forward,

backward

–Fast

forward,

rewind

forward,

backward

forward,

backward

forward,

backward

forward,

backward

a)k)

Play– PlayPlayPlayPlayPlay

Pause – Pause Pause Pause Pause Pause

Stop– StopStopStopStopStop

K PRESET

/–

Preset

channel

Preset

channel

Preset

channel

– Preset

channel

Side A, B

–

L F1 HDD mode – – – DVD mode – –

F2 BD,

DVD mode

–––VHS mode––

M BD/DVD

TOP MENU

On-screen

guide

– – On-screen

guide

On-screen

guide

––

BD/DVD

Menu – – Menu Menu – –

P DISC SKIP Skip disc––––Skip disc

Skip disc

Q RETURN/

EXIT O

Return Return,

exit

– Return Return Return –

R Enter Enter Enter Enter Enter – –

V/v/B/b Select Select Select Select Select – –

S GUIDE

(Guide)

EPGEPG–EPG–––

T DISPLAY Display Display Display Display Display Display Display

continued

The following buttons have tactile dots. Use the

tactile dots as references when operating the

receiver.

– number 5, VIDEO 1

– N

– PRESET +, TV CH + (RM-AAP049 only),

PROG + (RM-AAP050 only), c (RM-AAP050

only)

If you press ?/1 (A) and AV ?/1 (B)

simultaneously, the receiver and connected

components will turn off (SYSTEM STANDBY).

The function of AV ?/1 (B) changes

automatically each time you press the input

buttons (D).

Press SHIFT (V) then only press this button.

CD player, MD deck and tape deck only.

CD player and MD deck only.

CD player, MD deck and DAT deck only.

LD player only.

VCD player only.

RM-AAP049 only.

RM-AAP050 only.

This button is also available for DIGITAL MEDIA

PORT adapter operation. For details on the

function of the button, refer to the operating

instructions supplied with the DIGITAL MEDIA

PORT adapter.

Notes

• Some functions explained in this section may not

work depending on the model.

• The above explanation is intended to serve as an

example only. Therefore, depending on the

component, the above operation may not be

possible or may operate differently than described.

Inserting batteries into the

remote

Insert two R6 (size-AA) batteries in the

RM-AAP049 (Models of area code U2 only)

or RM-AAP050 (Models of area code CEL,

CEK, AU1 only) Remote Commander.

Observe the correct polarity when installing

batteries.

Notes

• Do not leave the remote in an extremely hot or

humid place.

• Do not use a new battery with old ones.

• Do not mix manganese batteries and other kinds of

batteries.

• Do not expose the remote sensor to direct sunlight

or lighting apparatuses. Doing so may cause a

malfunction.

• If you do not intend to use the remote for an

extended period of time, remove the batteries to

avoid possible damage from battery leakage and

corrosion.

• When you replace the batteries, the programmed

remote codes may be cleared. If this happens,

program the remote codes again (page 85).

• When the remote no longer operates the receiver,

replace all the batteries with new ones.

Connections

1: Installing the speakers

This receiver allows you to use a 7.1 channel

system (7 speakers and one subwoofer).

To fully enjoy theater-like multi channel

surround sound requires five speakers (two

front speakers, a center speaker, and two

surround speakers) and a subwoofer (5.1

channel).

You can enjoy high fidelity reproduction of

DVD software recorded sound in the Surround

EX format if you connect additional one

surround back speaker (6.1 channel) or two

surround back speakers (7.1 channel).

You can enjoy vertical sound effects if you

connect additional two front high speakers

(7.1 channel) in PLIIz mode (page 52).

Example of speaker system

configuration

AFront speaker (Left)

BFront speaker (Right)

CCenter speaker

DSurround speaker (Left)

ESurround speaker (Right)

FSurround back speaker (Left)*

GSurround back speaker (Right)*

HFront high speaker (Left)*

IFront high speaker (Right)*

JSubwoofer

* You cannot use the surround back speakers and the

front high speakers simultaneously.

Tips

• When you connect a 7.1 channel speaker system

with two surround back speakers, all angle A

should be the same.

Connections

continued

• When you connect a 7.1 channel speaker system

with two front high speakers, place the front high

speakers

– at an angle between 22° to 45°.

– at least 1 meter (3.3 feet) directly above the front

speakers.

• When you connect a 6.1 channel speaker system,

place the surround back speaker behind the

listening position.

• Since the subwoofer does not emit highly

directional signals, you can place it wherever you

want.

Connections

2: Connecting the speakers

Before connecting the cords, be sure to disconnect the AC power cord (mains lead).

ANTENNA

DMPORT

IN 4 IN 3 IN 2 IN 1 TV OUT

ARC

DC5V

0.7A MAX

OPTICAL

VIDEO

OUT

OPTICAL

SAT

CATV

DVD

COAXIAL

AUDIO

VIDEO

AUDIO

OUT

VIDEO

OUT

AUDIO

VIDEO

VIDEO 1

MONITOR

HDMI

ASSIGNABLE (INPUT ONLY)

DIGITAL

(ASSIGNABLE)

LR LR

FRONT A

SURROUND BACK/

FRONT HIGH/

BI-AMP/ FRONT B

AUDIO

OUT

SUBWOOFER

10 mm

(13/32 in)

SPEAKERS

CENTER

SURROUND

Right

Left

Right

A Monaural audio cord (not supplied)

B Speaker cord (not supplied)

LeftRight

Center speaker

Left

Surround speaker

Subwoofer

Surround back/

Front high/Bi-amplifier/

Front B speaker

Front A speaker

continued

Notes on the SPEAKERS SURROUND BACK/

FRONT HIGH/BI-AMP/FRONT B terminals

connection.

• If you connect only one surround back speaker,

connect it to L of this terminals.

• If you are not using surround back speaker or

front high speakers, and you have an additional

front speaker system, connect the additional

front speaker system to this terminals.

Set “SB ASSIGN” to “SPK B” in the SPEAKER

menu (page 80).

You can select the front speaker system you

want using the SPEAKERS button on the

receiver (page 34).

• If you are not using surround back speaker or

front high speakers, you can connect the front

speakers to this terminals using bi-amplifier

connection (page 20).

When you connect a subwoofer with an auto

standby function, turn off the function when

watching movies. If the auto standby function is

set to on, it turns to standby mode automatically

based on the level of the input signal to a

subwoofer, then sound may not be output.

Notes

• Before connecting the AC power cord (mains

lead), make sure that metalic wires of the speaker

cords are not touching each other between the

SPEAKERS terminals.

• After you have install and connect your speaker, be

sure to select the speaker pattern from SPEAKER

menu (page 78).

If you are not using surround back speakers or

front high speakers, you can connect the front

speakers to the SPEAKERS SURROUND

BACK/FRONT HIGH/BI-AMP/FRONT B

terminals using a bi-amplifier connection.

Connect the jacks on the Lo (or Hi) side of the

front speakers to the SPEAKERS FRONT A

terminals, and connect the jacks on the Hi (or

Lo) side of the front speakers to the

SPEAKERS SURROUND BACK/FRONT

HIGH/BI-AMP/FRONT B terminals.

Make sure that metal fittings of Hi/Lo attached

to the speakers have been removed from the

speakers. Not doing so may cause a

malfunction of the receiver.

After you have made the bi-amplifier

connection, set “SB ASSIGN” to “BI-AMP”

in the SPEAKER menu (page 71).

Bi-amplifier connection

EZW-T100

ANTENNA

DMPORT

IN 4 IN 3 IN 2 IN 1 TV OUT

ARC

DC5V

0.7A MAX

IN 3 IN 2 IN 1

OPTICAL

MONITOR

OUT

AUDIO

OUT

AUDIO

OUT

AUDIO

VIDEO

OUT

OPTICAL

SAT

CATV

SA-CD

CD-R

SAT

CATV SUBWOOFER

AUDIO

VIDEO

AUDIO

OUT

VIDEO

OUT

AUDIO

VIDEO

VIDEO 1

MONITOR

HDMI

ASSIGNABLE (INPUT ONLY)

COMPONENT VIDEO

ASSIGNABLE (INPUT ONLY)

(

)

LR LR

CENTER

SURROUND

FRONT A

SURROUND BACK/

FRONT HIGH/

BI-AMP/ FRONT B

LR LR

SPEAKERS

FRONT A

SURROUND BACK/

FRONT HIGH/

BI-AMP/ FRONT B

CENTER

SURROUND

SPEAKERS

Front speaker

(Right)

Front speaker

(Left)

Connections

3: Connecting the TV

Before connecting cords, be sure to disconnect the AC power cord (mains lead).

A Component video cord (not supplied)

B Video cord (not supplied)

C Optical digital cord (not supplied)

D Audio cord (not supplied)

E HDMI cable (not supplied)

We recommend that you use a Sony HDMI

cable.

Recommended connection

Alternative connection

To enjoy TV multi channel surround sound

broadcasting from the speakers connected to the

receiver, connect either C or E.

Be sure to turn off the TV’s volume or activate the

TV’s muting function.

If your TV is compatible with the Audio Return

Channel (ARC) function, the TV sound will output

from the speakers connected to the receiver via

HDMI TV OUT connection. In this case, set

“ARC” to “ARC ON” in HDMI menu (page 60).

EZW-T100

ANTENNA

DMPORT

DC5V

0.7A MAX

AUDIO

OUT

AUDIO

OUT

AUDIO

VIDEO

OPTICAL

SAT

CATV

DVD

COAXIAL

SA-CD

CD-R

SAT

CATV SUBWOOFER

AUDIO

VIDEO

AUDIO

OUT

VIDEO

OUT

AUDIO

VIDEO

VIDEO 1

DIGITAL

(ASSIGNABLE)

LR LR

SPEAKERS

CENTER

SURROUND

FRONT A

SURROUND BACK/

FRONT HIGH/

BI-AMP/ FRONT B

AUDIO

VIDEO

OUT

MONITOR

OPTICAL

IN 3 IN 2 IN 1

MONITOR

OUT

COMPONENT VIDEO

ASSIGNABLE (INPUT ONLY)

IN 4 IN 3 IN 2 IN 1 TV OUT

ARC

HDMI

ASSIGNABLE (INPUT ONLY)

Audio/Video

signals

Audio signals

a) b)

Video signals

continued

Notes

• Be sure to turn on the receiver when the video and

audio signals of a playback component are being

output to a TV via the receiver. Unless the power is

turned on, neither video nor audio signals will be

transmitted.

• Connect image display components such as a TV

monitor or a projector to the HDMI TV OUT or

MONITOR OUT jack on the receiver. You may

not be able to record, even if you connect recording

components.

• Depending on the status of the connection between

the TV and the antenna (aerial), the image on the

TV screen may be distorted. In this case, place the

antenna (aerial) farther away from the receiver.

• When connecting optical digital cords, insert the

plugs straight in until they click into place.

• Do not bend or tie optical digital cords.

Tips

• All the digital audio jacks are compatible with

32 kHz, 44.1 kHz, 48 kHz, and 96 kHz sampling

frequencies.

• The receiver has a video conversion function. For

details, see “Function for conversion of video

signals” (page 31).

Connections

4a: Connecting the audio

components

The following illustration shows how to

connect a Super Audio CD player, CD player,

CD recorder and DIGITAL MEDIA PORT

adapter. Before connecting cords, be sure to

disconnect the AC power cord (mains lead).

* You can enjoy the images from the components

connected to the DIGITAL MEDIA PORT adapter

when you connect the TV to the receiver.

Notes on connecting DIGITAL

MEDIA PORT adapter

• When connecting the DIGITAL MEDIA

PORT adapter, be sure the connector is

inserted with the arrow mark facing towards

the arrow mark on the DMPORT jack.

• Be sure to make DMPORT connections

firmly, insert the connector straight in.

• As the connector of the DIGITAL MEDIA

PORT adapter is fragile, be sure to handle

with care when placing or moving the

receiver.

• Do not connect an adapter other than the

DIGITAL MEDIA PORT adapter.

• Do not connect or disconnect the DIGITAL

MEDIA PORT adapter while the receiver is

turned on.

To detach the DIGITAL MEDIA

PORT adapter from DMPORT

jack

Press and hold both sides of the connector and

then pull out the connector.

EZW-T100

ANTENNA

IN 3 IN 2 IN 1

OPTICAL

MONITOR

OUT

AUDIO

OUT

AUDIO

VIDEO

OPTICAL

SAT

CATV

SAT

CATV SUBWOOFER

AUDIO

VIDEO

AUDIO

OUT

VIDEO

OUT

AUDIO

VIDEO

VIDEO 1

COMPONENT VIDEO

ASSIGNABLE (INPUT ONLY)

DIGITAL

SURR

BI-A

SA-CD

CD-R

DMPORT

DC5V

0.7A MAX

MONITOR

AUDIO

OUT

AUDIO

VIDEO

OUT

Super Audio

CD player,

CD recorder

A Audio cord (not supplied)

B Video cord (not supplied)

DIGITAL MEDIA

PORT adapter

TV*

DMPORT

DC5V

0.7A MAX

4b: Connecting the video components

Connect your video components according to

the table below.

* We recommend that you connect your video

components via HDMI connection if they have

HDMI jacks.

You can watch the selected input image when

you connect the HDMI TV OUT or

MONITOR OUT jack to a TV (page 21).

The receiver equipped with video signals

converting function. For details, see “Function

for conversion of video signals” (page 31).

If you want to connect several

digital components, but cannot

find an unused input

See “Enjoying the sound/images from other

inputs” (page 69).

Notes

• Before connecting cords, be sure to disconnect the

AC power cord (mains lead).

• It is not necessary to connect all the cords. Connect

according to the availability of jacks on the

connected components.

• Be sure to turn on the receiver when the video and

audio signals of a playback component are being

output to a TV via the receiver. Unless the power is

turned on, neither video nor audio signals will be

transmitted.

• When connecting optical digital cords, insert the

plugs straight in until they click into place.

• Do not bend or tie optical digital cords.

Tip

All the digital audio jacks are compatible with

32 kHz, 44.1 kHz, 48 kHz, and 96 kHz sampling

frequencies.

HDMI is the abbreviated name for High-

Definition Multimedia Interface. It is an

interface which transmits video and audio

signals in digital format.

HDMI features

• A digital audio signals transmitted by HDMI

can be output from the speakers connected to

the receiver. This signal supports Dolby

Digital, DTS, and Linear PCM.

• This receiver can receive multi channel

Linear PCM (up to 8 channels) with a

sampling frequency of 192 kHz or less with

an HDMI connection.

• This receiver supports High Bitrate Audio

(DTS-HD Master Audio, Dolby TrueHD)

and HDMI (Deep Colour (Deep Color),

x.v. Colour (x.v. Color)).

• This receiver supports the Control for HDMI

function. For details, see ““BRAVIA” Sync

Features” (page 56).

• Analog video signals input to the VIDEO

jack, or COMPONENT VIDEO jacks can be

output as HDMI signals (page 31). Audio

signals are not output from HDMI TV OUT

jack when the image is converted.

Components to be connected

Component Page

Blu-ray disc player* 24, 27

DVD player* 24, 28

DVD recorder* 24, 28, 30

Satellite tuner*, Cable TV tuner* 24, 29

“PlayStation 3”* 24

VCR 30

Camcorder, video game, etc. 30

Connecting components with

HDMI jacks

Connections

* See page 21 for the audio connection of TV to the

receiver.

Notes

• Be sure to change the initial setting of the HDMI

1–4 input button on the remote so that you can use

the button to control your components. For details,

see “Programming the remote” (page 85).

• You can also rename the HDMI input so that it can

be displayed on the receiver’s display. For details,

see “Naming inputs” (page 44).

EZW-T100

ANTENNA

DMPORT

DC5V

0.7A MAX

IN 3 IN 2 IN 1

OPTICAL

MONITOR

OUT

AUDIO

OUT

AUDIO

OUT

AUDIO

VIDEO

OUT

OPTICAL

SAT

CATV

DVD

COAXIAL

SA-CD

CD-R

SAT

CATV SUBWOOFER

AUDIO

VIDEO

AUDIO

OUT

VIDEO

OUT

AUDIO

VIDEO

VIDEO 1

MONITOR

COMPONENT VIDEO

ASSIGNABLE (INPUT ONLY)

DIGITAL

(ASSIGNABLE)

LR LR

SPEAKERS

CENTER

SURROUND

FRONT A

SURROUND BACK/

FRONT HIGH/

BI-AMP/ FRONT B

IN 4 IN 3 IN 2 IN 1 TV OUT

HDMI

ASSIGNABLE (INPUT ONLY)

ARC

Satellite tuner,

Cable TV tuner

DVD player, DVD recorder Blu-ray disc player

Audio/video

signals

Audio/video

signals

Audio/video

signals

TV, etc.*

Audio/video

signals

“PlayStation 3”

Audio/video

signals

A HDMI cable (not supplied)

We recommend that you use a Sony HDMI cable.

continued

Notes on connecting cables

• Use a High Speed HDMI cable. If you use a

Standard HDMI cable, 1080p or Deep

Colour (Deep Color) images may not be

displayed properly.

• Sony recommends that you use an HDMI

authorized cable or Sony HDMI cable.

• We do not recommend using an HDMI-DVI

conversion cable. When you connect an

HDMI-DVI conversion cable to a DVI-D

component, the sound and/or the image may

not be output. Connect other audio cords or

digital connecting cords, then set

“A. ASSIGN” in AUDIO menu (page 69)

when the sound is not output correctly.

Notes on HDMI connections

• An audio signal input to the HDMI IN jack

is output from the SPEAKERS jacks, HDMI

TV OUT jack and PHONES jack. It is not

output from any other audio jacks.

• Video signals input to the HDMI IN jack can

only be output from the HDMI TV OUT

jack. The video input signals cannot be

output from the VIDEO OUT jacks or

MONITOR OUT jacks.

• When you want to listen to the sound from

the TV speaker, set “AUDIO OUT” to

“TV+AMP” in the HDMI menu (page 84). If

you cannot play back multi channel

software, set to “AMP”. However, the sound

will not output from the TV speaker.

• DSD signals of Super Audio CD are not

input and output.

• The multi/stereo area audio signals of a

Super Audio CD are not output.

• Audio signals (sampling frequency, bit

length, etc.) transmitted from an HDMI jack

may be suppressed by the connected

component. Check the setup of the

connected component if the image is poor or

the sound does not come out of a component

connected via the HDMI cable.

• Sound may be interrupted when the

sampling frequency, the number of channels

or audio output signals from the playback

component is switched.

• When the connected component is not

compatible with copyright protection

technology (HDCP), the image and/or the

sound from the HDMI TV OUT jack may be

distorted or may not be output.

In this case, check the specification of the

connected component.

• Be sure to turn on the receiver when video

and audio signals of a playback component

are being output to a TV through this

receiver. If you set “PASS THRU” to

“OFF”, video and audio signals will not be

transmitted when the power is turned off.

• Set the image resolution of the player to

more than 720p/1080i to enjoy High Bitrate

Audio (DTS-HD Master Audio, Dolby

TrueHD).

• The image resolution of player may need

certain settings be made before you can

enjoy multi channel Linear PCM. Refer to

the operating instructions of the player.

• Not every HDMI component supports all

functions that are defined by the specified

HDMI version. For example, components

that support HDMI, version 1.4, may not

support Audio Return Channel (ARC).

• Refer to the operating instructions of each

connected component for details.

Connections

The following illustration shows how to connect a Blu-ray disc player.

A Component video cord (not supplied)

B Video cord (not supplied)

C Optical digital cord (not supplied)

D Coaxial digital cord (not supplied)

E Audio cord (not supplied)

Recommended connection

Alternative connection

* When you connect a component equipped with a

COAXIAL jack, set “A. ASSIGN” in the AUDIO

menu (page 69).

Notes

• The initial setting of the COMPONENT VIDEO

IN 1 jacks are Blu-ray disc player. If you want to

connect your Blu-ray disc player to the

COMPONENT VIDEO IN 2 or IN 3 jacks, set

“V. ASSIGN” in the VIDEO menu (page 69).

• To input multi channel digital audio from the Blu-

ray disc player, set the digital audio output setting

on the Blu-ray disc player. Refer to the operating

instructions supplied with the Blu-ray disc player.

Connecting a Blu-ray disc player

EZW-T100

ANTENNA

DMPORT

IN 4 IN 3 IN 2 IN 1 TV OUT

ARC

DC5V

0.7A MAX

OPTICAL

AUDIO

OUT

AUDIO

OUT

AUDIO

VIDEO

OUT

SA-CD

CD-R

SAT

CATV SUBWOOFER

AUDIO

OUT

VIDEO

OUT

AUDIO

VIDEO

VIDEO 1

MONITOR

HDMI

ASSIGNABLE (INPUT ONLY)

LR LR

SPEAKERS

CENTER

SURROUND

FRONT A

SURROUND BACK/

FRONT HIGH/

BI-AMP/ FRONT B

AUDIO

VIDEO

OPTICAL

SAT

CATV

COAXIAL

(ASSIGNABLE)

IN 3 IN 2

MONITOR

OUT

COMPONENT VIDEO

ASSIGNABLE (INPUT ONLY)

IN 1

DVD

DIGITAL

Blu-ray disc player

Video signals Audio signals

D* E

The following illustration shows how to connect a DVD player or DVD recorder.

A Component video cord (not supplied)

B Optical digital cord (not supplied)

C Coaxial digital cord (not supplied)

Recommended connection

Alternative connection

* When you connect a component equipped with an

OPTICAL jack, set “A. ASSIGN” in the AUDIO

menu (page 69).

Notes

• The initial setting for the DVD input button is as

follows:

– RM-AAP049: DVD player

– RM-AAP050: DVD recorder

To control other components, be sure to change the

initial setting of the DVD input button on the

remote. For details, see “Programming the remote”

(page 85).

• You can also rename the DVD input so that it can

be displayed on the receiver’s display. For details,

see “Naming inputs” (page 44).

• The initial setting of the COMPONENT VIDEO

IN 2 jacks are DVD player or DVD recorder. If you

want to connect your DVD player or DVD recorder

to the COMPONENT VIDEO IN 1 or IN 3 jacks,

set “V. ASSIGN” in the VIDEO menu (page 69).

• To input multi channel digital audio from the DVD

player or DVD recorder, set the digital audio

output setting on the DVD player or DVD recorder.

Refer to the operating instructions supplied with

the DVD player or DVD recorder.

Connecting a DVD player, DVD recorder

EZW-T100

ANTENNA

DMPORT

IN 4 IN 3 IN 2 IN 1 TV OUT

ARC

DC5V

0.7A MAX

OPTICAL

AUDIO

OUT

AUDIO

OUT

AUDIO

VIDEO

OUT

SA-CD

CD-R

SAT

CATV SUBWOOFER

AUDIO

VIDEO

AUDIO

OUT

VIDEO

OUT

AUDIO

VIDEO

VIDEO 1

MONITOR

HDMI

ASSIGNABLE (INPUT ONLY)

LR LR

SPEAKERS

CENTER

SURROUND

FRONT A

SURROUND BACK/

FRONT HIGH/

BI-AMP/ FRONT B

OPTICAL

SAT

CATV

COAXIAL

DIGITAL

IN 3 IN 1

MONITOR

OUT

COMPONENT VIDEO

ASSIGNABLE (INPUT ONLY)

IN 2

DVD

(ASSIGNABLE)

DVD player, DVD recorder

Video signals Audio signals

Connections

The following illustration shows how to connect a satellite tuner or cable TV tuner.

A Component video cord (not supplied)

B Video cord (not supplied)

C Optical digital cord (not supplied)

D Audio cord (not supplied)

Recommended connection

Alternative connection

Note

The initial setting of the COMPONENT VIDEO IN

3 jacks are satellite tuner or cable TV tuner. If you

want to connect your satellite tuner or cable TV

tuner to the COMPONENT VIDEO IN 1 or IN 2

jacks, set “V. ASSIGN” in the VIDEO menu (page

69).

Connecting a satellite tuner, cable TV tuner

EZW-T100

ANTENNA

DMPORT

IN 4 IN 3 IN 2 IN 1 TV OUT

ARC

DC5V

0.7A MAX

OPTICAL

AUDIO

OUT

AUDIO

OUT

AUDIO

VIDEO

OUT

SA-CD

CD-R

SUBWOOFER

AUDIO

VIDEO

AUDIO

OUT

VIDEO

OUT

AUDIO

VIDEO

VIDEO 1

MONITOR

HDMI

ASSIGNABLE (INPUT ONLY)

LR LR

SPEAKERS

CENTER

SURROUND

FRONT A

SURROUND BACK/

FRONT HIGH/

BI-AMP/ FRONT B

AUDIO

VIDEO

SAT

CATV

OPTICAL

SAT

CATV

DVD

COAXIAL

DIGITAL

(ASSIGNABLE)

IN 2 IN 1

MONITOR

OUT

COMPONENT VIDEO

ASSIGNABLE (INPUT ONLY)

IN 3

Audio signalsVideo signals

Satellite tuner, Cable TV tuner

The following illustration shows how to

connect a component which has analog jacks

such as a VCR, DVD recorder, etc.

Notes

• Be sure to change the initial setting of the VIDEO

1 input button on the remote so that you can use the

button to control your DVD recorder. For details,

see “Programming the remote” (page 85).

• You can also rename the VIDEO 1 input so that it

can be displayed on the receiver’s display. For

details, see “Naming inputs” (page 44).

Connecting components with

analog video and audio jack

AUTO CAL MIC

VIDEO 2 IN

VIDEO L AUDIO R

EZW-T100

ANTENNA

DMPORT

IN 4 IN 3 IN 2 IN 1 TV OUT

ARC

DC5V

0.7A MAX

IN 3 IN 2 IN 1

OPTICAL

MONITOR

OUT

AUDIO

OUT

AUDIO

OUT

AUDIO

VIDEO

OUT

OPTICAL

SAT

CATV

DVD

COAXIAL

SA-CD

CD-R

SAT

CATV SUBWOOFER

AUDIO

VIDEO

MONITOR

HDMI

ASSIGNABLE (INPUT ONLY)

COMPONENT VIDEO

ASSIGNABLE (INPUT ONLY)

DIGITAL

(ASSIGNABLE)

LR LR

SPEAKERS

CENTER

SURROUND

FRONT A

SURROUND BACK/

FRONT HIGH/

BI-AMP/ FRONT B

AUDIO

OUT

AUDIO

VIDEO

OUT

VIDEO

VIDEO 1

VCR, DVD recorder

Camcorder,

video game

Audio signals

Video signals

A Video cord (not supplied)

B Audio cord (not supplied)

C Audio/video cord (not supplied)

(On the front panel)

Connections

The receiver is equipped with a function for converting video signals.

Video signals and component video signals can be output as HDMI video signals (HDMI TV OUT

jack only).

: Same type of signal as that of the input signal is output.

: Video signals are upconverted and output.

As the initial setting, video signals input from the connected component are output as shown in the

table above. We recommend you set the video conversion function to match the resolution of the

monitor you are using. For details, see “RESOLUTION” (page 83).

Notes on converting video

signals

• When video signals from a VCR, etc., are

converted on this receiver and then output to

your TV, depending on the status of the

video signal output, the image on the TV

screen may appear distorted horizontally or

no image may be output.

• When you play a VCR with an image

improvement circuit, such as TBC, the

images may be distorted or may not be

output. In this case, set the image

improvement circuit function to off.

• Converted HDMI image output do not

support “x.v.Colour (x.v.Color)” and Deep

Colour (Deep Color).

• The resolution of signals that can be

converted by the receiver is 480i only. Refer

to the operating instructions of each

connected component for details on video

output setting.

• HDMI video signals cannot be converted to

component video signals and video signals.

• The converted video signals are not output

from the MONITOR VIDEO OUT and

COMPONENT VIDEO MONITOR OUT

jack.

• The resolution of the signals output to the

HDMI TV OUT jack are converted up to

1080p.

To connect a recording

component

When recording, connect the recording

component to the VIDEO OUT jacks of the

receiver. Connect cords for input and output

signals to the same type of jack, as VIDEO

OUT jacks do not have an up-conversion

function.

Note

Signals output from the HDMI TV OUT or

MONITOR OUT jacks may not be recorded

properly.

Function for conversion of video signals

INPUT jack OUTPUT jack

HDMI IN

COMPONENT VIDEO IN

VIDEO IN

HDMI TV OUT

COMPONENT VIDEO MONITOR OUT

MONITOR VIDEO OUT

5: Connecting the

antennas (aerials)

Connect the supplied AM loop antenna

(aerial) and FM wire antenna (aerial).

Before connecting antennas (aerials), be sure

to disconnect the AC power cord (mains lead).

Notes

• To prevent noise pickup, keep the AM loop

antenna (aerial) away from the receiver and other

components.

• Be sure to fully extend the FM wire antenna

(aerial).

• After connecting the FM wire antenna (aerial),

keep it as horizontal as possible.

6: Inserting the wireless

transmitter/transceiver

To use the S-AIR function, you need to insert

the wireless transmitter (not supplied) into the

S-AIR main unit (this receiver) and the

wireless transceiver (not supplied) into the

S-AIR sub unit.

Notes

• Before inserting the wireless transmitter/

transceiver, be sure to disconnect the AC power

cord (mains lead).

• Do not touch the terminals of the wireless

transmitter/transceiver.

To insert the wireless

transmitter into the S-AIR main

unit

Remove the screws.

Note

Remove the screws pointed with mark. Do not

remove other screws.

EZW-T100

DMPORT

DC5V

0.7A MAX

IN 3 IN 2 IN 1

OPTICAL

MONITOR

OUT

AUDIO

OUT

AUDIO

OUT

AUDIO

VIDEO

OUT

OPTICAL

SAT

CATV

SA-CD

CD-R

SAT

CATV SUBWOOFER

AUDIO

VIDEO

AUDIO

OUT

VIDEO

OUT

AUDIO

VIDEO

VIDEO 1

MONITOR

COMPONENT VIDEO

ASSIGNABLE (INPUT ONLY)

DIGITA

SUR

BI-

ANTENNA

FM wire antenna (aerial) (supplied)

AM loop antenna (aerial)

(supplied)

ANTENNA

DMPORT

IN 4

DC5V

0.7A MAX

IN 3 IN 2 IN 1

OPTICAL

MONITOR

OUT

AUDIO

OUT

AUDIO

OUT

AUDIO

VIDEO

OUT

OPTICAL

SAT

CATV

SA-CD

CD-R

SAT

CATV SUBWOOFER

AUDIO

VIDEO

AUDIO

OUT

VIDEO

OUT

AUDIO

VIDEO

VIDEO 1

MONITOR

COMPONENT VIDEO

ASSIGNABLE (INPUT ONLY)

DIGITAL

(ASSIGNABLE)

SURROUND BACK/

FRONT HIGH/

BI-AMP/ FRONT B

EZW-T100

Connections

2 Insert the wireless transmitter.

Notes

• Insert the wireless transmitter with the S-AIR

logo facing up.

• Insert the wireless transmitter so that the V

marks are aligned.

• Do not insert other than the wireless

transmitter into the EZW-T100 slot.

3 Use the screws that you removed from

step 1 to fasten the wireless

transmitter.

Note

Do not use other screws to fasten the wireless

transmitter.

To insert the wireless

transceiver into the S-AIR sub

unit

Refer to the operating instructions supplied

with the surround amplifier and S-AIR

receiver.

7: Connecting the AC

power cord (mains lead)

Connect the AC power cord (mains lead) to a

wall outlet.

Note

Before connecting the AC power cord (mains lead),

make sure that metallic wires of the speaker cords

are not touching each other between the

SPEAKERS terminals.

EZW-T100

Wireless transmitter

EZW-T100 slot

EZW-T100

V OUT

ARC

UND

T A

To the wall outlet

AC power cord (mains lead)

Initializing the receiver

Before using the receiver for the first time,

initialize the receiver by performing the

following procedure. This procedure can also

be used to return settings you have made to

their initial settings.

Be sure to use the buttons on the receiver for

this operation.

1 Press ?/1 to turn off the

receiver.

2 Hold down ?/1 for 5 seconds.

After “CLEARING” appears on the

display for a while, “CLEARED”

appears.

All the settings you have changed or

adjusted are reset to the initial settings.

Selecting the speaker

system

You can select the front speakers you want to

drive.

Be sure to use the buttons on the receiver for

this operation.

Press SPEAKERS repeatedly to

select the front speaker system

you want to drive.

* To select “SP B” or “SP A B”, set “SB ASSIGN”

to “SPK B” in the SPEAKER menu (page 80).

To turn off the speaker output

Press SPEAKERS repeatedly until the “SP A”,

“SP B” and “SP A B” indicators on the display

do not light up.

“SPK OFF” appears on the display.

Note

You cannot switch the front speaker system by

pressing SPEAKERS when the headphones are

connected.

Preparing the Receiver

?/1

When select front speakers

connected to

Light up

The SPEAKERS FRONT A

terminals

SP A

The SPEAKERS SURROUND

BACK/FRONT HIGH/BI-AMP/

FRONT B terminals

SP B*

Both the SPEAKERS FRONT A and

SPEAKERS SURROUND BACK/

FRONT HIGH/BI-AMP/FRONT B

terminals (parallel connection)

SP A B*

?/1

SPEAKERS

Preparing the Receiver

Calibrating the

appropriate speaker

settings automatically

(AUTO CALIBRATION)

This receiver is equipped with DCAC (Digital

Cinema Auto Calibration) Technology which

allows you to perform automatic calibration as

follows:

• Check the connection between each speaker

and the receiver.

• Adjust the speaker level.

• Measure the distance of each speaker from

your listening position.

a)b)

• Measure the speaker size.

• Measure the speaker polarity.

• Measure the frequency characteristics.

a)c)

The measurement result is not utilized when

Analog Direct is selected.

The measurement result is not utilized when

signals with a sampling frequency of more than

96 kHz are being received.

The measurement result is not utilized when

signals with a sampling frequency of more than

48 kHz are being received.

The DCAC is designed to obtain proper sound

balance in your room. However, you can

adjust the speaker levels manually according

to your preference. For details, see

“Adjusting the speaker levels (TEST TONE)”

(page 42).

Before you perform Auto Calibration, check

the following items.

• Set up and connect the speakers (page 17,

19).

• Connect only the supplied optimizer

microphone to the AUTO CAL MIC jack.

Do not connect other microphones to this

jack.

• Set “SB ASSIGN” to “BI-AMP” in

SPEAKER menu if you use bi-amplifier

connection (page 71).

• Set “SB ASSIGN” to “SPK B” in

SPEAKER menu if you use speakers front B

connection (page 80).

• Pair the surround amplifier to S-AIR main

unit if you want to use surround amplifier.

• Make sure the speaker output is not set to

“SPK OFF” (page 34).

• Disconnect the headphones.

• Remove any obstacles in the path between

the optimizer microphone and the speakers

to avoid measurement errors.

• Make sure the environment is quiet to avoid

the effect of noise and get a more accurate

measurement.

• Select the seating position as position 1, 2 or

3 to save the Auto Calibration result (page

40).

Notes

• During the calibration, the sound that comes out of

the speakers is very loud. The volume of the sound

cannot be adjusted. Pay attention to the presence of

children or to the effect on your neighborhood.

• If the muting function has been activated before

you perform Auto Calibration, the muting function

will be set to off automatically.

Before you perform Auto

Calibration

* Be sure to set the speaker pattern to a setting with

front high speakers (page 78).

1 Connect the supplied optimizer

microphone to the AUTO CAL

MIC jack.

2 Set up the optimizer

microphone.

Place the optimizer microphone at your

listening position. Use a stool or tripod so

that the optimizer microphone remains at

the same height as your ears.

On setting up the active

subwoofer

• When a subwoofer is connected, turn on the

subwoofer and turn up the volume

beforehand. Turn the MASTER VOLUME

knob to just before the mid-point.

• If you connect a subwoofer with a crossover

frequency function, set the value to the

maximum.

• If you connect a subwoofer with an auto

standby function, set this function to off

(deactivated).

Note

Depending on the characteristics of the subwoofer

you are using, the setup distance value may be

further away from the actual position.

1: Setting up the Auto

Calibration

?/1

AUTO CAL MIC

Optimizer

microphone

When using front high speakers

When using surround back speakers

Preparing the Receiver

1 Press AMP MENU.

2 Press V/v repeatedly to select

“<AUTO CAL>”, then press

or b.

3 Press V/v repeatedly to select

“A.CAL START”, then press .

Measurement starts in 5 seconds. A count

down is displayed.

The measurement process will take

approximately 30 seconds to complete.

The table below shows the display when

measurement starts.

* The corresponding speaker indicator lights

up on the display during measurement.

Tips

• Operations other than turning the receiver on or off

are deactivated during the measurement.

• The measurements may not be performed correctly

or Auto Calibration cannot be performed when

special speakers, such as dipole speakers are used.

To cancel Auto Calibration

The Auto Calibration function will be

canceled when you do the following during the

measurement process:

– Press ?/1.

– Press the input buttons or turn the INPUT

SELECTOR on the receiver.

– Change the volume level.

– Press MUTING (RM-AAP049 only) or

(RM-AAP050 only).

– Press SPEAKERS on the receiver.

– Connect headphones.

2: Performing Auto Calibration

DVD

VIDEO 1

HDMI 2

DMPORT

SAT/

CATV

VIDEO 2

HDMI 3HDMI 1

SA-CD/

TUNER

HDMI 4

Input

buttons

?/1

MUTING/

MASTER

VOL +/–/

+/–

V/v/B/b

AMP

MENU/

HOME

Measurement for Display

Speaker existence TONE

Speaker gain, distance,

frequency response

T.S.P.*

Subwoofer gain and distance WOOFER*

1 Confirm the measurement

result.

When the measurement ends, a beep

sounds and the measurement result

appears on the display.

2 View the measurement result.

Press AMP and then press V/v repeatedly

to select the item. Then, press .

3 Save the measurement result.

Select “SAVE EXIT” in step 2.

“COMPLETE” appears on the display

and the settings are registered as selected

position number.

4 Select the calibration type.

Press V/v repeatedly to select calibration

type, then press .

5 Disconnect the optimizer

microphone after you have

finished.

Note

If you have reposition your speaker, we recommend

that you perform Auto Calibration again to enjoy the

surround sound.

Tip

The size of a speaker (LARGE/SMALL) is

determined by the low frequency characteristics.

The measurement results may vary, depending on

the position of the optimizer microphone and

speakers, and the shape of the room. It is

recommended that you follow the measurement

results. However, you can change those settings in

the SPEAKER menu (page 74). Save the

measurement results first, then try to change the

settings if you want.

3: Confirming/saving the

measurement results

Measurement process

[Display]

Explanation

Completes properly

[SAVE EXIT]

Proceed to step

Fails

[E -

xxx

]

See “When error

codes appear”

(page 39).

Item and explanation

EXIT

Exits the setting process without saving the

measurement results.

LEVEL INFO.

Displays the measurement result for speaker

level.

DIST. INFO.

Displays the measurement result for speaker

distance.

PHASE INFO.

Displays the phase of each speaker (in phase/

out of phase). See “When you select “PHASE

INFO.”” (page 39).

WARN CHECK

Displays warning concerning the

measurement results. See “When you select

“WARN CHECK”” (page 39).

SAVE EXIT

Saves the measurement results and exits the

setting process.

RETRY

Performs the Auto Calibration again.

Calibration type and explanation

FULL FLAT

Makes the measurement of frequency from

each speaker flat.

ENGINEER

Sets the frequency characteristics to a set that

matches that of the Sony listening room

standard.

FRONT REF

Adjusts the characteristics of all speakers to

match the characteristics of the front speaker.

OFF

Sets the Auto Calibration equalizer level to

off.

Preparing the Receiver

When error codes appear

Check the problem of the error.

* xxx

represent a speaker channel

FFront

S Surround

SB Surround back

FH Front high

Depending on the error code, the speaker

channel may not appears.

2 Perform Auto Calibration again.

Press AMP, then press . Press V/v to

select “RETRY? YES”, then press .

3 Follow steps in “3: Confirming/saving

the measurement results” (page 38).

When you select “PHASE

INFO.”

You can check the phase of each speaker (in

phase/out of phase).

1 Press V/v repeatedly to select a

speaker you want to check.

2 Press to return to step 2 of

“3: Confirming/saving the

measurement results” (page 38).

When you select “WARN

CHECK”

If a warning on the measurement result is

present, detailed information is displayed.

Display and explanation

E -

xxx* : 31

SPEAKERS is set to “SPK OFF”. Set it to

others (page 34) and perform the measurement

again.

E -

xxx* : 32

None of the speakers were detected. Make sure

that the optimizer microphone is connected

properly and perform the measurement again. If

the optimizer microphone is connected properly

but the error code appears, the optimizer

microphone cable may be damaged or

improperly connected.

E -

xxx* : 33

• None of the front speakers are connected or

only one front speaker is connected.

• The optimizer microphone is not connected.

• Either the left or right surround speakers is not

connected.

• Surround back speakers or front high speakers

are connected even though surround speakers

are not connected. Connect the surround

speaker(s) to the SPEAKERS SURROUND

terminals.

The surround back speaker is connected only

to the SPEAKERS SURROUND BACK/

FRONT HIGH/BI-AMP/FRONT B R

terminals. When you connect only one

surround back speaker, connect it to the

SPEAKERS SURROUND BACK/FRONT

HIGH/BI-AMP/FRONT B L terminals.

• Either the front left high or front right high

speaker is not connected.

Checking the measurement

results

Display and explanation

xxx* : IN

The speaker is in phase.

xxx* : OUT

The speaker is out of phase. The “+” and “–”

terminals of the speaker may be connected the

other way around. However, depending on the

speakers, “

xxx : OUT” appears on the

display even though the speakers are connected

properly. This is because of the speakers’

specifications. In this case, you can continue to

use the receiver.

Display and explanation

W -

xxx*

: 40

The measurement has completed. However, the

noise level is high. You may be able to perform the

measurement properly if you try it again, even

though the measurement cannot be performed in all

environments. Try to perform the measurement in a

quiet environment.

W -

xxx*

: 41

The sound input from the optimizer microphone is

outside the acceptable range. It is louder than the

loudest sound that can be measured. Try to perform

the measurement when the environment is quiet

enough to allow proper measurement.

continued

* xxx

represent a speaker channel

FL Front left

FR Front right

CNT Center

SL Surround left

SR Surround right

SBL Surround back left

SBR Surround back right

LH Front left high

RH Front right high

SW Subwoofer

Depending on the measurement result, the speaker

channel may not appears.

To return to step 2 of

“3: Confirming/saving the

measurement results”

Press .

Tip

Depending on the position of the subwoofer, the

measurement results for polarity may vary.

However, there will be no problems even if you

continue to use the receiver with that value.

You can use the AUTO CAL menu to make

various adjustments for Auto Calibration

settings and to name the position.

For details on adjusting the parameters, see

“Using the setting menu” (page 72).

x A.CAL START

x CAL TYPE*

Lets you select the Auto Calibration type for

each seating position. For details, see step 4 of

“3: Confirming/saving the measurement

results” (page 38).

* You can select this parameter only when you have

performed the Auto Calibration and saved the

settings.

x POSITION

You can register three patterns as position 1, 2

and 3, depending on the seating positions,

listening environment, and measurement

conditions.

If you do not select the position number, the

Auto Calibration result will automatically save

as POS 1 (initial setting).

To register settings for the

listening environment

You can select the seating position you want

and register the measurement results of the

Auto Calibration for that seating position.

1 Press AMP MENU.

2 Press V/v repeatedly to select “<AUTO

CAL>”, then press or b.

3 Press V/v repeatedly to select

“POSITION”, then press or b.

4 Press V/v repeatedly to select the

position (POS 1, 2, 3) for which you

want to register the measurement

results, then press .

W - xxx*

: 42

The volume of the receiver is out of the acceptable

range. Try to perform the measurement when the

environment is quiet enough to allow proper

measurement.

W -

xxx*

: 43

The distance and position of a subwoofer cannot be

detected. This may be caused by noise. Try to

perform the measurement in a quiet environment.

NO WARN

There is no warning information.

Display and explanation

AUTO CAL menu

Preparing the Receiver

5 Perform Auto Calibration and save the

measurement results.

See “2: Performing Auto Calibration”

(page 37) and “3: Confirming/saving the

measurement results” (page 38).

The measurement results is registered as

the position you selected in step 4.

6 Repeat steps 1 to 5 to register another

seating position.

To select the registered seating

position

Repeat steps 1 to 3 of “To register

settings for the listening environment”

(page 40).

2 Press V/v repeatedly to select position

(POS 1, 2, 3) you want, then press .

The registered seating position is selected.

To exit the menu

Press MENU/HOME or AMP MENU.

x NAME IN (Naming position)

You can rename the position name.

1 Perform steps of “To select the

registered seating position” to select

the position you want to name.

2 Press V/v repeatedly to select “NAME

IN”, then press or b.

The cursor flashes and you can select a

character.

3 Press V/v to select a character, then

press B/b to move the cursor to the

next position.

If you made a mistake

Press B/b until the character you want to

change flashes, then press V/v to select the

correct character.

Tips

• You can select the character type as follows by

pressing V/v.

Alphabet (upper case) t Numbers t

Symbols

• To enter a blank space, press b without

selecting a character.

4 Press .

The name you entered is registered.

Adjusting the speaker

levels

(TEST TONE)

You can adjust the speaker levels while

listening to the test tone from your listening

position.

1 Press AMP MENU.

2 Press V/v repeatedly to select

“<LEVEL>”, then press or b.

3 Press V/v repeatedly to select

“TEST TONE”, then press .

4 Press V/v repeatedly to select

“AUTO xxx*”.

The test tone is output from each speaker

in sequence.

* xxx represent a speaker channel.

Note

Depending on the speaker pattern setting, test

tone may not be output from all speakers even

though you select “AUTO xxx”.

5 Adjust the speaker levels using

the LEVEL menu so that the

level of the test tone sounds the

same from each speaker.

For details, see LEVEL menu (page 73).

Tips

• To adjust the level of all speakers at the same

time, press MASTER VOL +/–

(RM-AAP049 only) or

2 +/–

(RM-AAP050 only). You can also use

MASTER VOLUME on the receiver.

• The adjusted value are shown on the display

during adjustment.

6 Repeat steps 1 to 4 to select

“OFF”.

You can also press any input buttons.

The test tone turns off.

When a test tone is not output

from the speakers

• The speaker cords may not be connected

securely.

• The speaker cords may have the short-circuit

problem.

When a test tone is output from

a different speaker than the

speaker indicator showed in the

display

The speaker pattern to the connected speaker

is not set up correctly. Make sure the speaker

connection and the speaker pattern match.

Note

Test tone is not output from the headphones

connected to the S-AIR surround amplifier.

DVD

VIDEO 1

HDMI 2

DMPORT

HDMI 4

SAT/

CATV

VIDEO 2

HDMI 3HDMI 1

SA-CD/

TUNER

Input

buttons

MASTER

VOL +/–/

+/–

V/v/B/b

AMP

Basic Operations

Playback

Turn on the connected

component.

2 Turn on the receiver.

3 Press one of the input buttons

to select the component you

want.

You can also use INPUT SELECTOR on

the receiver.

The selected input appears on the display.

Note

When you press TUNER, “FM TUNER” or

“AM TUNER” appears for a while, then

frequency appears on the display.

4 Play back the source.

5 Press MASTER VOL +/–

(RM-AAP049 only) or +/–

(RM-AAP050 only) to adjust the

volume.

You can also use MASTER VOLUME on

the receiver.

6 Press SOUND FIELD +/– to

enjoy the surround sound.

You can also use 2CH/A.DIRECT,

A.F.D., MOVIE or MUSIC on the

receiver.

For details, see page 51.

To activate the muting function

Press MUTING (RM-AAP049 only) or

(RM-AAP050 only) on the remote.

The muting function will be canceled when

you do the following.

• Press MUTING (RM-AAP049 only) or

(RM-AAP050 only) again.

• Increase the volume.

• Turn off the receiver.

• Perform Auto Calibration.

To avoid damaging your

speakers

Before you turn off the receiver, be sure to turn

down the volume level.

Basic Operations

DVD

VIDEO 1

HDMI 2

DMPORT

SAT/

CATV

VIDEO 2

HDMI 3HDMI 1

HDMI 4

SA-CD/

TUNER

Input

buttons

MASTER

VOL +/–/

+/–

V/v/B/b

AMP

MUTING/

SOUND

FIELD +/–

You can enter a name of up to 8 characters for

inputs (except TUNER) and display it on the

receiver’s display.

This is convenient for labeling the jacks with

the names of the connected components.

1 Press one of the input buttons

to select the input you want to

create an index name for.

You can also use INPUT SELECTOR on

the receiver.

2 Press AMP MENU.

3 Press V/v repeatedly to select

“<SYSTEM>”, then press or

4 Press V/v repeatedly to select

“NAME IN”, then press or b.

The cursor flashes and you can select a

character.

5 Press V/v to select a character,

then press B/b to move the

cursor to the next position.

If you made a mistake

Press B/b until the character you want to

change flashes, then press V/v to select

the correct character.

Tips

• You can select the character type as follows

by pressing V/v.

Alphabet (upper case) t Numbers t

Symbols

• To enter a blank space, press b without

selecting a character.

6 Press .

The name you entered is registered.

Viewing information on

the display

You can check the sound field, etc., by

changing the information on the display.

Press AMP, then press DISPLAY

repeatedly.

You can also use DISPLAY on the receiver.

Each time you press DISPLAY, the display

changes cyclically as follows:

All inputs except the FM and AM

band

Index name of the input

t Selected input

t Sound field currently applied t Volume

level t Stream info

FM and AM band

Program Service name

or preset station

name

t Frequency t Program Type

indication

t Radio Text indication

Current Time indication (in 24-hour system

mode)

t Sound field currently applied t

Volume level

Index name appears only when you have assigned

one to the input or preset station (page 44, 49).

Index name does not appear when only blank

spaces have been entered, or it is the same as the

input name.

During RDS reception only (Models of area code

CEL, CEK, AU1 only) (page 50).

Note

Character or marks may not be displayed for some

languages.

Naming inputs

DVD

VIDEO 1

HDMI 2

DMPORT

SAT/

CATV

VIDEO 2

HDMI 3HDMI 1

SA-CD/

TUNER

HDMI 4

DISPLAY

AMP

Basic Operations

Using the Sleep Timer

You can set the receiver to turn off

automatically at a specified time.

Press AMP, then press SLEEP

repeatedly while the power is on.

“SLEEP” lights up in the display.

Each time you press SLEEP, the display

changes cyclically as follows:

0:30:00 t 1:00:00 t 1:30:00 t

2:00:00

t OFF

Tips

• To check the remaining time before the receiver

turns off, press SLEEP. The remaining time

appears on the display. If you press SLEEP again,

the Sleep Timer will be canceled.

• You can also set the Sleep Timer by using the

“SLEEP” in SYSTEM menu.

Recording

You can record from a video/audio component

using the receiver. Refer to the operating

instructions supplied with your recording

component.

You can record onto a CD-R using the

receiver. Refer to the operating instructions

supplied with your CD recorder.

1 Press one of the input buttons

to select the playback

component.

You can also use INPUT SELECTOR on

the receiver.

2 Prepare the playback

component for playing.

For example, tune to the radio station you

want to record (page 46).

3 Prepare the recording

component.

Insert a blank CD-R into the CD recorder

and adjust the recording level.

4 Start recording on the

recording component, then

start playback on the playback

component.

Note

Sound adjustments do not affect the signal output

from the SA-CD/CD/CD-R AUDIO OUT jacks.

BD DVD

SAT/

CATV

VIDEO 1 VIDEO 2

HDMI 3HDMI 2HDMI 1

HDMI 4

SA-CD/

TUNERDMPORT

SLEEP

AMP

Recording onto a CD-R

1 Press one of the input buttons

to select the playback

component.

You can also use INPUT SELECTOR on

the receiver.

2 Prepare the playback

component for playing.

For example, insert the video tape you

want to copy into the VCR.

3 Prepare the recording

component.

Insert a blank video tape, etc. into the

recording component (VIDEO 1) for

recording.

4 Start recording on the

recording component, then

start playback on the playback

component.

Notes

• Some sources contain copy guards to prevent

recording. In this case, you may not be able to

record from the source.

• Only analog signals are output from the analog

output jack (for recording).

• HDMI sound cannot be recorded.

Listening to FM/AM radio

You can listen to FM and AM broadcasts

through the built-in tuner. Before operation,

make sure you have connected the FM and

AM antennas (aerials) to the receiver (page

32).

Tip

The tuning scale for direct tuning differs depending

on the area code as shown in the following table. For

details on area codes, see page 5.

* The AM tuning scale can be changed (page 48).

Recording onto a recording

media

Tuner Operations

Area code FM AM

CEL, CEK, AU1 50 kHz 9 kHz

U2 100 kHz 10 kHz*

DVD

VIDEO 1

HDMI 2HDMI 1

HDMI 4

DMPORT

SAT/

CATV

VIDEO 2

HDMI 3

SA-CD/

TUNER

TUNING

+/–

Numeric

buttons

TUNER

ENTER

SHIFT

D.TUNING

V/v/b

AMP

Tuner Operations

1 Press TUNER repeatedly to

select the FM or AM band.

2 Press TUNING + or TUNING –.

Press TUNING + to scan from low to

high; press TUNING – to scan from high

to low.

The receiver stops scanning whenever a

station is received.

Using the controls on the

receiver

1 Turn INPUT SELECTOR to select the FM

or AM band.

2 Press TUNING MODE repeatedly to select

“AUTO”.

3 Press TUNING + or TUNING –.

In case of poor FM stereo

reception

If the FM stereo reception is poor and “ST”

flashes on the display, select monaural audio

so that the sound will be less distorted.

1 Press AMP MENU.

2 Press V/v repeatedly to select “<TUNER>”,

then press or b.

3 Press V/v repeatedly to select

“FM MODE”, then press

or b.

4 Press V/v repeatedly to select “MONO”.

5 To return to stereo mode, repeat steps 1 to 4

and select “STEREO” in step 4.

You can enter the frequency of a station

directly by using the numeric buttons.

1 Press TUNER repeatedly to

select the FM or AM band.

You can also use INPUT SELECTOR on

the receiver.

2 Press D.TUNING.

3 Press SHIFT.

4 Press the numeric buttons to

enter the frequency.

Example 1: FM 102.50 MHz

Select 1 b 0 b 2 b 5 b 0*

Example 2: AM 1,350 kHz

Select 1 b 3 b 5 b 0

* Press 0 for models of area code CEL, CEK,

AU1 only.

5 Press ENTER.

You can also use MEMORY/ENTER on

the receiver.

Tip

If you have tuned in an AM station, adjust the

direction of the AM loop antenna (aerial) for

optimum reception.

If you cannot tune in a station

Make sure you have entered the right

frequency. If not, repeat steps 2 to 5. If you

still cannot tune in a station, the frequency is

not used in your area.

Tuning into a station

automatically (Automatic

Tuning)

Tuning into a station directly

(Direct Tuning)

(Models of area code U2 only)

You can change the AM tuning scale to either

9 kHz or 10 kHz using the buttons on the

receiver.

1 Press ?/1 to turn off the

receiver.

2 While holding down TUNING

MODE, press ?/1.

3 Change the current AM tuning

scale to 9 kHz (or 10 kHz).

To reset the scale to 10 kHz (or 9 kHz),

repeat the procedure above.

Note

All preset stations will be erased when you change

the tuning scale.

Presetting FM/AM radio

stations

You can preset up to 30 FM stations and 30

AM stations. Then you can easily tune in the

stations you often listen to.

1 Press TUNER repeatedly to

select the FM or AM band.

You can also use INPUT SELECTOR on

the receiver.

2 Tune in the station that you

want to preset using Automatic

Tuning (page 47) or Direct

Tuning (page 47).

Switch the FM reception mode, if

necessary (page 47).

3 Press SHIFT.

Changing the AM tuning scale

?/1

TUNING MODE

DVD

VIDEO 1

HDMI 2HDMI 1

DMPORT

SAT/

CATV

VIDEO 2

HDMI 3

HDMI 4

SA-CD/

TUNER

Numeric

buttons

PRESET

+/–

TUNER

ENTER

SHIFT

AMP

V/v/B/b

MEMORY

Tuner Operations

4 Press MEMORY.

You can also use MEMORY/ENTER on

the receiver.

“MEM” lights up for a few seconds.

Perform steps 5 and 6 before “MEM”

goes out.

5 Press the numeric buttons to

select a preset number.

You can also press PRESET + or

PRESET – repeatedly to select a preset

number.

If “MEM” goes out before you select the

preset number, start again from step 3.

6 Press ENTER.

You can also use MEMORY/ENTER on

the receiver.

“MEM” lights off.

The station is stored as the selected preset

number.

7 Repeat steps 1 to 6 to preset

another station.

1 Press TUNER repeatedly to

select the FM or AM band.

2 Press PRESET + or PRESET –

repeatedly to select the preset

station you want.

Each time you press the button, you can

select a preset station as follows:

You can also press SHIFT and then press

the numeric buttons to select the preset

station you want. Then, press ENTER to

enter the selection.

Using the controls on the

receiver

1 Turn INPUT SELECTOR to select the FM

or AM band.

2 Press TUNING MODE repeatedly to select

“PRESET”.

3 Press TUNING + or TUNING – to select the

preset station you want.

1 Press TUNER repeatedly to

select the FM or AM band.

You can also use INPUT SELECTOR on

the receiver.

2 Tune in the preset station you

want to create an index name

for (page 49).

3 Press AMP MENU.

4 Press V/v repeatedly to select

“<TUNER>”, then press or

Tuning to preset stations

Naming preset stations

1 2 345 27...

30 29 28

continued

5 Press V/v repeatedly to select

“NAME IN”, then press or b.

The cursor flashes and you can select a

character.

6 Press V/v to select a character,

then press B/b to move the

cursor to the next position.

If you made a mistake

Press B/b until the character you want to

change flashes, then press V/v to select

the correct character.

Tips

• You can select the character type as follows

by pressing V/v.

Alphabet (upper case) t Numbers t

Symbols

• To enter a blank space, press b without

selecting a character.

7 Press .

The name you entered is registered.

Note (Models of area code CEL, CEK,

AU1 only)

When you name an RDS station and tune in that

station, the Program Service name appears instead

of the name you entered. (You cannot change the

Program Service name. The name you entered will

be overwritten by the Program Service name.)

Using the Radio Data

System (RDS)

(Models of area code CEL, CEK,

AU1 only)

This receiver allows you to use Radio Data

System (RDS), which enables radio stations to

send additional information along with the

regular program signal. This receiver offers

convenient RDS features, such as Program

Service name display.

Notes

• RDS is operable only for FM stations.

• Not all FM stations provide RDS service, nor do

they provide the same type of services. If you are

not familiar with the RDS services in your area,

check with your local radio stations for details.

Simply select a station on the FM

band using Direct Tuning (page 47),

Automatic Tuning (page 47), or

Preset Tuning (page 49).

When you tune in a station that provides RDS

services, “RDS” lights up and the program

service name appears on the display.

Note

RDS may not work properly if the station you tuned

to is not transmitting the RDS signal properly or if

the signal strength is weak.

Tip

When a Program Service name is displayed, you can

check the frequency by pressing DISPLAY

repeatedly (page 44).

Receiving RDS broadcasts

Enjoying Surround Sound

Selecting the sound field

This receiver can create multi channel

surround sound. You can select one of the

optimized sound fields from the receiver’s

preprogrammed sound fields.

Press SOUND FIELD +/– repeatedly

to select the sound field you want.

You can also use 2CH/A.DIRECT, A.F.D.,

MOVIE or MUSIC on the receiver.

You can switch the output sound to 2 channel

sound regardless of the recording formats of

the software you are using, the playback

component connected, or the sound field

settings of the receiver.

x 2CH ST. (2 Channel Stereo)

The receiver outputs the sound from the front

left/right speakers only. There is no sound

from the subwoofer.

Standard 2 channel stereo sources completely

bypass the sound field processing and multi

channel surround formats are downmixed to 2

channel except LFE signals.

x A. DIRECT (Analog Direct)

You can switch the audio of the selected input

to 2 channel analog input. This function

enables you to enjoy high quality analog

sources without any adjustment.

When using this function, only the volume and

front speaker level can be adjusted.

Note

You cannot select Analog Direct when you select

DVD, DMPORT and HDMI 1–4 as input.

The Auto Format Direct (A.F.D.) mode allows

you to listen to high fidelity sound and select

the decoding mode for listening to a 2 channel

stereo sound as multi channel sound.

x A.F.D. AUTO (A.F.D. Auto)

Presets the sound as it was recorded/encoded

without adding any surround effects.

x MULTI ST. (Multi Stereo)

Outputs 2 channel left/right signals from all

speakers. However, sound may not be output

from certain speakers depending on the

speaker settings.

You can take advantage of surround sound

simply by selecting one of the receiver’s pre-

programmed sound fields. They bring the

exciting and powerful sound of movie theaters

into your home.

x C.ST.EX A (Cinema Studio EX A

DCS )

Reproduces the sound characteristics of the

Sony Pictures Entertainment “Cary Grant

Theater” cinema production studio. This is a

standard mode, great for watching almost any

type of movie.

x C.ST.EX B (Cinema Studio EX B

DCS )

Reproduces the sound characteristics of the

Sony Pictures Entertainment “Kim Novak

Theater” cinema production studio. This mode

is ideal for watching science-fiction or action

movies with lots of sound effects.

Enjoying Surround Sound

2 channel sound mode

HDMI 4

SOUND

FIELD +/–

Auto Format Direct (A.F.D.)

mode

Movie mode

continued

x C.ST.EX C (Cinema Studio EX C

DCS )

Reproduces the sound characteristics of the

Sony Pictures Entertainment scoring stage.

This mode is ideal for watching musicals or

films where orchestra music is featured in the

soundtrack.

x V.MULTI DIM. (V. Multi

Dimension DCS )

Creates many virtual speakers from a single

pair of actual surround speakers.

x PLII MV (Pro Logic II Movie)

Performs Dolby Pro Logic II Movie mode

decoding. This setting is ideal for movies

encoded in Dolby Surround. In addition, this

mode can reproduce sound in 5.1 channel for

watching videos of overdubbed or old movies.

x PLIIx MV (Pro Logic IIx Movie)

Performs Dolby Pro Logic IIx Movie mode

decoding. This setting expands Dolby Pro

Logic II Movie or Dolby Digital 5.1 to discrete

7.1 movie channels.

x PLIIz (Pro Logic IIz)

Performs Dolby Pro Logic IIz mode decoding.

This setting increases flexibility to expand a

5.1 to a 7.1 channel system. Its vertical

component gives a dimension of presence and

depth.

x NEO6 CIN (Neo:6 Cinema)

Performs DTS Neo:6 Cinema mode decoding.

A source recorded in 2 channel format is

decoded into 7 channels.

You can take advantage of surround sound

simply by selecting one of the receiver’s

preprogrammed sound fields. They bring the

exciting and powerful sound of concert halls

into your home.

x HALL (Hall)

Reproduces the acoustics of a classical concert

hall.

x JAZZ (Jazz Club)

Reproduces the acoustics of a jazz club.

x CONCERT (Concert)

Reproduces the acoustics of a 300-seat live

house.

x STADIUM (Stadium)

Reproduces the feeling of a large open-air

stadium.

x SPORTS (Sports)

Reproduces the feeling of sports broadcasting.

x PORTABLE (Portable Audio

Enhancer)

Reproduces a clear enhanced sound image

from your portable audio device. This mode is

ideal for MP3 and other compressed music.

x PLII MS (Pro Logic II Music)

Perform Dolby Pro Logic II Music mode

decoding. This setting is ideal for normal

stereo sources such as CDs.

x PLIIx MS (Pro Logic IIx Music)

Performs Dolby Pro Logic IIx Music mode

decoding. This setting is ideal for normal

stereo sources such as CDs.

x PLIIz (Pro Logic IIz)

Performs Dolby Pro Logic IIz mode decoding.

This setting increases flexibility to expand a

5.1 to a 7.1 channel system. Its vertical

component gives a dimension of presence and

depth.

Music mode

Enjoying Surround Sound

x NEO6 MUS (Neo:6 Music)

Performs DTS Neo:6 Music mode decoding.

A source recorded in 2 channel format is

decoded into 7 channels. This setting is ideal

for normal stereo sources such as CDs.

You can only select the following sound fields

if the headphones are connected to the

receiver.

x HP 2CH (Headphones 2CH)

This mode is selected automatically if you use

headphones (except Analog Direct). Standard

2 channel stereo sources completely bypass

the sound field processing and multi channel

surround formats are downmixed to 2

channels except LFE signals.

Note

When headphones are connected to the S-AIR

surround amplifier, the sound field is automatically

set to “HP 2CH”.

x HP DIRECT (Headphones Direct)

This mode is selected automatically if you use

headphones when “A. DIRECT” is selected.

Outputs the analog signals without processing

by the equalizer, sound field, etc.

If you connect a subwoofer

This receiver will generate a low frequency

signal for output to the subwoofer when there

is no LFE signal, which is a low-pass sound

effect output from a subwoofer to a 2 channel

signal. However, the low frequency signal is

not generated for “NEO6 CIN” or “NEO6

MUS” when all speakers are set to “LARGE”.

In order to take full advantage of the Dolby

Digital bass redirection circuitry, we

recommend setting the subwoofer’s cut off

frequency as high as possible.

Notes on sound fields

• Depending on the speaker pattern settings,

some sound fields may not be available.

• The sound fields for music and movie do not

work in the following cases.

– Signals with a sampling frequency of more

than 48 kHz are being received.

– Signals with more than 5.1 channel are

being received (except PLIIz).

• You cannot select PLIIx and PLIIz at the

same time.

– PLIIx is available only when the speaker

pattern is set to a setting with surround

back speaker(s).

– PLIIz is available only when the speaker

pattern is set to a setting with front high

speakers.

• The effects provided by the virtual speakers

may cause increased noise in the playback

signal.

• When listening with sound fields that

employ the virtual speakers, you will not be

able to hear any sound coming directly from

the surround speakers.

• When one of the sound fields for music is

selected, no sound is output from the

subwoofer if all the speakers are set to

“LARGE” in the SPEAKER menu.

However, the sound will be output from the

subwoofer if the digital input signal contains

LFE signals, or if the front or surround

speakers are set to “SMALL”, the sound

field for movie is selected, or “PORTABLE”

is selected.

Tips

• You can identify the encoding format of DVD

software, etc., by looking at the logo on the

package.

• Dolby Pro Logic IIx and Dolby Pro Logic IIz

decoding are effective when multi channel signals

are input.

• Sound fields with DCS

marks use DCS

technology. For details on Digital Cinema Sound

(DCS), see “Glossary” (page 90).

When headphones are

connected

continued

To turn off the surround effect

for movie/music

Press SOUND FIELD +/– repeatedly to select

“2CH ST.” or “A.F.D. AUTO”.

You can also press 2CH/A.DIRECT

repeatedly on the receiver to select “2CH ST.”

or press A.F.D. repeatedly on the receiver to

select “A.F.D. AUTO”.

Digital audio formats that this receiver can decode depend on digital audio input jacks for the

connected component. This receiver supports the following audio formats.

Audio signals are output in another format if the playback component does not correspond to the format. For

details, refer to the operating instructions of the playback component.

Signals with a sampling frequency of more than 96 kHz are played back at 96 kHz or 88.2 kHz.

When connecting Blu-ray disc players and other next generation HD

players

Audio format

Maximum number

of channels

Connection of the playback component and

the receiver

COAXIAL/OPTICAL HDMI

Dolby Digital 5.1 aa

Dolby Digital EX 6.1 aa

Dolby Digital Plus

7.1

× a

Dolby TrueHD

7.1 × a

DTS 5.1 aa

DTS-ES 6.1 aa

DTS 96/24 5.1 aa

DTS-HD

High Resolution Audio

7.1

× a

DTS-HD

Master Audio

a)b)

7.1

× a

Multi channel Linear PCM

7.1 × a

Enjoying Surround Sound

Enjoying the surround

effect at low volume

levels

(NIGHT MODE)

This function allows you to retain a theater like

environment at low volume levels. This

function can be used with other sound fields.

When watching a movie late at night, you will

be able to hear the dialog clearly even at a low

volume level.

Press NIGHT MODE to select

“NIGHT ON”.

The NIGHT MODE function is activated.

Note

This function does not work in the following cases.

– Signals with a sampling frequency of more than

48 kHz are being received.

– Analog Direct is selected.

Tips

• While the NIGHT MODE is turned on,

“D. RANGE” is automatically set to

“COMP. MAX”.

• You can also set “NIGHT MODE” to “NIGHT

ON” in AUDIO menu (page 75).

Resetting sound fields to

the initial settings

Be sure to use the buttons on the receiver for

this operation.

1 Press ?/1 to turn off the

receiver.

2 While holding down MUSIC,

press ?/1.

“S.F. CLEAR” appears on the display and

all sound fields are reset to their initial

setting.

HDMI 4

NIGHT

MODE

?/1

MUSIC

What is “BRAVIA” Sync?

“BRAVIA” Sync is compatible with Sony TV,

Blu-ray Disc/DVD player, AV amplifier, etc.,

that is equipped with the Control for HDMI

function.

By connecting Sony components that are

compatible with the “BRAVIA” Sync with an

HDMI cable (not supplied), operation is

simplified as follows:

• One-Touch Play (page 57)

• System Audio Control (page 58)

• System Power Off (page 59)

• Theatre/Theater Mode Sync (page 59)

• Audio Return Channel (page 60)

Control for HDMI is a mutual control function

standard used by HDMI CEC (Consumer

Electronics Control) for HDMI (High-

Definition Multimedia Interface).

We recommend that you connect the receiver

to products featuring “BRAVIA” Sync.

Note

Depending on the connected component, the

Control for HDMI function may not work. Refer to

the operating instructions of the component.

Preparing for the

“BRAVIA” Sync

The receiver is compatible with the “Control

for HDMI-Easy Setting” function.

• If your TV is compatible with the “Control

for HDMI-Easy Setting” function, you can

set the Control for HDMI function of the

receiver and playback components

automatically by setting the TV (page 56).

• If your TV is not compatible with the

“Control for HDMI-Easy Setting” function,

set the Control for HDMI function of the

receiver, playback components and TV

individually (page 57).

If your TV is compatible with the

“Control for HDMI-Easy Setting”

function

The Control for HDMI function of the receiver

can be turned on simultaneously by turning on

the Control for HDMI function of the TV.

1 Connect the receiver, TV and playback

components via HDMI connection

(page 24).

(The respective components must be

compatible with the Control for HDMI

function.)

2 Turn on the receiver, TV and playback

components.

3 Turn on the Control for HDMI function

of the TV.

The Control for HDMI function of the

receiver and all the connected components

are turned on simultaneously. When the

setup is completed, “COMPLETE” will

appear.

For details on setting the TV, refer to the

operating instructions supplied with the TV.

“BRAVIA” Sync Features

If your TV is not compatible with

the “Control for HDMI-Easy

Setting” function

Perform the steps given in “If your TV is

compatible with the “Control for HDMI-

Easy Setting” function” (page 56).

2 Press AMP MENU.

3 Press V/v repeatedly to select

“<HDMI>”, then press

or b.

4 Press V/v repeatedly to select “CTRL:

HDMI”, then press or b.

5 Press V/v repeatedly to select “CTRL

ON”.

Control for HDMI function is turned on.

6 Set the Control for HDMI function for

the connected component to on.

If the Control for HDMI function for the

connected component is already set to on,

you do not need to change the setting.

For details on setting the TV and connected

components, refer to the operating

instructions of the respective components.

Notes

• Before you do the “Control for HDMI-Easy

Setting” from the TV, be sure to turn on the TV,

connected components and receiver.

• If the playback components cannot function after

you have made the settings for “Control for HDMI-

Easy Setting”, check the Control for HDMI setting

on your TV.

• If the connected components do not support

“Control for HDMI-Easy Setting”, you need to set

the Control for HDMI function for the connected

components to on before you perform the “Control

for HDMI-Easy Setting” from the TV.

Playing back components

with one-touch operation

(One-Touch Play)

By a simple operation (one-touch),

components connected to the receiver with

HDMI connections start automatically. You

can enjoy the sound/images from the

connected components.

When you set “PASS THRU” to “AUTO” or

“ON”, sound and images can be output only

from the TV while the receiver remains in

standby mode.

When you start playback a connected

component, the receiver and TV operation are

simplified as follow:

Receiver and TV

Turns on (if in standby mode)

Switches to appropriate HDMI input

Notes

• Depending on the TV, the start of the content may

not be output.

• Depending on the settings, the receiver may not

turns on when “PASS THRU” is set to “AUTO” or

“ON”.

Tip

You can also select a connected component, such as

DVD/Blu-ray disc player using the TV menu. The

receiver and TV will automatically switch to the

appropriate HDMI input.

AMP

V/v/B/b

Enjoying the TV sound

from the speakers

connected to the receiver

(System Audio Control)

You can enjoy the TV sound from the speakers

connected to the receiver by a simple

operation.

You can operate System Audio Control

function using the TV menu. For details, refer

to the operating instructions of the TV.

TV Receiver

You can also use the System Audio Control

function as follows.

• If you turn on the receiver while the TV is

turned on, the System Audio Control

function will automatically be set to on and

the TV sound will output from the speakers

connected to the receiver. However, if you

turn off the receiver, the sound will output

from the TV speakers.

• When you adjust the TV volume, the

receiver’s volume is adjusted

simultaneously.

Notes

• If System Audio Control does not function

according to your TV setting, refer to the operating

instructions of the TV.

• When “CTRL: HDMI” is set to “CTRL ON”, the

“AUDIO OUT” settings in the HDMI menu will

set automatically depending on the System Audio

Control settings.

• When you connect a TV that does not have System

Audio Control function, the System Audio Control

function does not work.

• If the TV is turned on before turning on the

receiver, the TV sound will not be output for a

moment.

Sets System Audio

•

Turns on (if in

Control to on standby mode)

•

Switches to

appropriate

HDMI input

Minimizes TV Outputs TV

volume sound

“BRAVIA” Sync Features

Turning off the receiver

with the TV

(System Power Off)

When you turn the TV off by using the

POWER button on the TV’s remote, the

receiver and the connected components turn

off automatically.

You can also use the receiver’s remote to turn

off the TV.

Press TV, then press AV ?/1.

The TV, receiver and the components

connected via HDMI are turned off.

Notes

• Set the TV Standby Synchro to “ON” before using

the System Power Off function. For details, refer to

the operating instructions of the TV.

• Depending on the status, the connected

components may not be turned off. For details,

refer to the operating instructions of the connected

components.

Enjoying movies with the

optimum sound field

(Theatre/Theater Mode Sync)

Press THEATER or THEATRE on

the remote of the receiver, TV, or

the Blu-ray disc player, while

pointing the remote toward the TV.

The sound field switches to “C.ST.EX B”.

To return to the previous sound field, press

THEATER or THEATRE again.

Note

The sound field may not switch depending on the

TV.

Tip

The sound field may be changed back to the

previous one when you change the TV’s input.

BD DVD

SAT/

CATV

AV ?/1

Enjoying the TV sound via

an HDMI cable

(Audio Return Channel)

The Audio Return Channel (ARC) function

enables the TV outputs the audio signals to the

receiver via a HDMI cable connected to the

HDMI TV OUT jack.

You can enjoy the TV sound from the speakers

connected to the receiver without connecting

the TV AUDIO IN or TV OPTICAL jacks.

1 Press AMP MENU.

2 Press V/v repeatedly to select

“<HDMI>”, then press or b.

3 Press V/v repeatedly to select

“ARC”, then press or b.

4 Press V/v repeatedly to select

“ARC ON”.

Notes

• This function does not work when you set “CTRL:

HDMI” to “CTRL OFF” in HDMI menu.

• This function is only available when

– your TV is compatible with Audio Return

Channel (ARC) function.

– INPUT MODE is set to “AUTO”.

About S-AIR products

This receiver is compatible with the S-AIR

function (page 93), which allows wireless

sound transmission between S-AIR products.

There are two types of S-AIR product.

• S-AIR main unit (this receiver):

The S-AIR main unit is for transmitting

sound.

You can use up to 3 S-AIR main units. (The

number of usable S-AIR main unit depends

on the use environment.)

• S-AIR sub unit (not supplied): The S-AIR

sub unit is for receiving sound.

– Surround amplifier: You can enjoy

surround and surround back speakers

sound wirelessly. For details, refer to the

operating instructions supplied with the

surround amplifier.

– S-AIR receiver: You can enjoy system

sound in another room.

These S-AIR products can be purchased as an

option (the S-AIR product lineup differs

depending on the area).

See the notes or instructions for the S-AIR sub

unit in this manual only when the S-AIR sub

unit is used.

Notes

• The S-AIR menu and parameters only available

when you have inserted the wireless transmitter.

• When the speaker pattern is set to a setting with

front high speakers, the surround back speakers

sound is not output from surround amplifier even if

the surround amplifier is connected.

AMP

V/v/B/b

S-AIR Operations

S-AIR products use a radio frequency of

2.4 GHz. Certain electronic equipment or

other factors may cause lost connection or

instability in S-AIR reception.

• Electronic equipment influence

The following may cause interference or

cross talk.

– Cellular phones, cordless phones

– Wireless LAN, personal computers

– Game machines using radio signals

– Microwave ovens

• Other factors

The following may cause poor reception.

– Materials or structures, such as walls and

floors

– The location where an S-AIR product is

placed

When using S-AIR products, place them as far

as possible from the above electronic

equipment, or place where S-AIR reception is

stable.

About environments where

S-AIR products (S-AIR main unit

and sub unit) are used

?/1

S-AIR sub unit

(S-AIR receiver)

S-AIR main unit

(this receiver)

S-AIR sub unit

(surround amplifier)

Room B

Room A

Setting up an S-AIR

product

Before using an S-AIR product, be sure to

perform the following settings to establish the

sound transmission.

• Inserting the wireless transmitter/

transceiver (page 32).

• Establishing sound transmission between

the S-AIR main unit and S-AIR sub unit (ID

setting) (page 62).

• Pairing the S-AIR main unit with a specific

S-AIR sub unit (Pairing operation) (page

63).

When you match the ID of the S-AIR main

unit and the S-AIR sub unit, you can establish

sound transmission. You can use multiple

S-AIR main unit by setting a different ID for

each unit.

To set the ID of the S-AIR main

unit

Press AMP MENU.

2 Press V/v repeatedly to select

“<S-AIR>”, then press or b.

3 Press V/v repeatedly to select “S-AIR

ID”, then press or b.

4 Press V/v repeatedly to select the ID

(A, B or C) you want, then press .

To exit the menu

Press MENU/HOME or AMP MENU.

To set the ID of the S-AIR sub

unit

Be sure to match the ID on S-AIR sub unit you

want to the S-AIR main unit.

For details on setting the ID of the surround

amplifier and S-AIR receiver, refer to the

operating instructions supplied with the

surround amplifier and S-AIR receiver.

Sound transmission is established as

follows (example):

Notes

• Sources with copyright protection may not be

playable on S-AIR sub unit.

• If you have connected surround amplifier,

surround sound will not be output from S-AIR

main unit.

Establishing sound transmission

between the S-AIR main unit and

S-AIR sub unit (ID setting)

AMP

V/v/B/b

MENU/

HOME

ID A ID A ID B

ID A ID B

?/1

S-AIR main unit

(this receiver)

Other S-AIR

main unit

S-AIR

sub unit

S-AIR

sub unit

S-AIR sub unit

S-AIR Operations

To establish sound transmission, you need to

set the same ID for your S-AIR main unit and

S-AIR sub unit.

However, if your neighbors have S-AIR

products and their IDs are the same as yours,

your neighbors could receive the sound of

your S-AIR main unit or vice versa.

To prevent this, you can pair the S-AIR main

unit with a specific S-AIR sub unit by

performing the pairing operation.

x Before pairing

Sound transmission is established by the ID

(example).

x After pairing

Sound transmission is established between the

paired S-AIR main unit and S-AIR sub unit(s)

only.

1 Place the S-AIR sub unit that

you want to pair near the S-AIR

main unit.

2 Match the IDs of the S-AIR main

unit and the S-AIR sub unit.

• To set the ID of the S-AIR main unit,

see “To set the ID of the S-AIR main

unit” (page 62).

• To set the ID of the S-AIR sub unit,

refer to the operating instructions

supplied with the S-AIR sub unit.

3 Press AMP MENU.

4 Press V/v repeatedly to select

“<S-AIR>”, then press or b.

5 Press V/v repeatedly to select

“PAIRING”, then press or b.

Pairing the S-AIR main unit with

a specific S-AIR sub unit

(Pairing operation)

ID A

?/1

our room

S-AIR main unit

(this receiver)

S-AIR sub unit S-AIR sub unit

Neighbor

ID A

?/1

Your room

S-AIR main unit

(this receiver)

S-AIR sub unit S-AIR sub unit

Neighbor

No transmission

Pairing

continued

6 Press V/v repeatedly to select

the setting you want, then

press .

• START: The S-AIR main unit starts

pairing. “SEARCHING” flashes on the

display.

• CONDITION: You can check the

current ID. When the pairing setting is

not made, “NO PAIRING” appears on

the display.

7 Start pairing of the S-AIR sub

unit.

Refer to the operating instructions

supplied with the surround amplifier and

S-AIR receiver respectively.

8 Pairing completed.

“COMPLETE” appears on the display.

To exit the menu

Press MENU/HOME or AMP MENU.

Note

Perform the pairing within several minutes after you

select “START” in step 6. Otherwise, the pairing is

canceled automatically and “INCOMPLETE”

appears on the display.

To cancel pairing

Reset the ID of the S-AIR main unit.

For details, see “To set the ID of the S-AIR

main unit” (page 62). You can select the same

ID as before.

Enjoying the system’s

sound in another room

(For the S-AIR receiver only (not

supplied))

You can enjoy the system’s sound in another

room by using the S-AIR receiver. The S-AIR

receiver can be placed in another room for

enjoying the system’s sound there.

For details of the S-AIR receiver, refer to the

operating instructions supplied with the S-AIR

receiver.

1 Set the ID of the S-AIR receiver

to match the ID of the S-AIR

main unit.

• To set the ID of the S-AIR main unit,

see “To set the ID of the S-AIR main

unit” (page 62).

• To set the ID of the S-AIR receiver,

refer to the operating instructions

supplied with the S-AIR receiver.

Notes

• When you are using another S-AIR sub unit,

such as a surround amplifier, do not change

the ID of the S-AIR main unit. Set the ID of

the S-AIR receiver to match the ID of the

S-AIR main unit.

• When you pair the S-AIR main unit and

another S-AIR sub unit, such as a surround

amplifier, you also need to pair the S-AIR

main unit and the S-AIR receiver. For details,

see “Pairing the S-AIR main unit with a

specific S-AIR sub unit (Pairing operation)”

(page 63).

2 Press AMP MENU.

AMP

V/v/B/b

S-AIR Operations

3 Press V/v repeatedly to select

“<S-AIR>”, then press or b.

4 Press V/v repeatedly to select

“S-AIR MODE”, then press

or b.

5 Press V/v repeatedly to select

the setting you want.

• PARTY: The S-AIR receiver outputs

sound according to the input selected on

the S-AIR main unit.

• SEPARATE: You can select the input

you want for the S-AIR receiver while

the input of the S-AIR main unit remain

unchanged. When “SEPARATE” is

selected, you can only select “SA-CD/

CD”, “DMPORT”, “FM TUNER”,

“AM TUNER” and the input that is

currently selected on the S-AIR main

unit.

Note

When “FM TUNER” or “AM TUNER” is

selected on the S-AIR main unit, you can only

select the same band for the tuner on the S-AIR

receiver. However, you can select input other

than TUNER on the S-AIR receiver.

6 Adjust the volume on the

S-AIR receiver.

Notes

• The sound of the S-AIR receiver may be cut off by

operation of the S-AIR main unit.

• When the sound is other than 2 channel stereo,

multi channel sound is downmixed to 2 channel.

• Signals with a sampling frequency of more than

96 kHz cannot output to the S-AIR receiver.

To control the system from the

S-AIR receiver

You can control the system from the S-AIR

receiver by using the following buttons.

For details, refer to the operating instructions

of the S-AIR receiver.

Press Operation

N, X, x,

./>

Share the same operations on the

remote.

S-AIR CH Change the function of the

system.

Changing the channel

for better sound

transmission

If you use multiple wireless systems which

sharing the 2.4 GHz band, such as wireless

LAN or Bluetooth, the transmission of S-AIR

products or other wireless systems may be

unstable. In this case, the transmission may be

improved by changing the following “RF

CHANGE” setting.

1 Press AMP MENU.

2 Press V/v repeatedly to select

“<S-AIR>”, then press or b.

3 Press V/v repeatedly to select

“RF CHANGE”, then press

or b.

4 Press V/v repeatedly to select

the setting you want, then

press .

• RF AUTO: Normally select this. The

system changes “RF CHANGE” to “RF

ON” or “RF OFF” automatically.

• RF ON: The system transmits sound by

searching the better channel for

transmitting.

• RF OFF: The system transmits sound by

fixing the channel for transmitting.

To exit the menu

Press MENU/HOME or AMP MENU.

Notes

• In most cases, you will not need to change this

setting.

• If “RF CHANGE” is set to “RF OFF”,

transmission between the S-AIR main unit and

S-AIR sub unit can be performed using one of the

following channels.

– S-AIR ID A: equivalent channel for IEEE

802.11b/g channel 1

– S-AIR ID B: equivalent channel for IEEE

802.11b/g channel 6

– S-AIR ID C: equivalent channel for IEEE

802.11b/g channel 11

• The transmission may be improved by changing

the transmission channel (frequency) of the other

wireless system(s). For details, refer to the

operating instructions of the other wireless

system(s).

AMP

V/v/B/b

MENU/

HOME

S-AIR Operations

Stabilizing S-AIR

reception

Check the following when S-AIR reception is

poor or unstable.

– Confirm the wireless adapters are inserted

correctly (page 32).

– Confirm that the S-AIR IDs of the S-AIR

main unit and sub unit are the same (page

62).

Check the following.

• Keep cords that are connected to the S-AIR

product (AC power cord (mains lead),

speaker cords, or other cords) away from the

wireless adapter and slot.

• Keep as much space as possible around

S-AIR products.

– Avoid placing S-AIR products on top of or

directly below other electronic equipment.

– Avoid placing S-AIR products in a closed

rack, metal rack or under a table.

• Adjust the location (height, orientation, and

place in the room) of S-AIR products until

reception is the most stable.

– Place so that the wireless adapters of the

S-AIR main unit and sub unit are closer.

– Place so that S-AIR products are separated

from other wireless devices.

– Place so that S-AIR products are separated

from metal doors or tables.

If you still cannot improve S-AIR reception,

change the “RF CHANGE” setting (page 66).

When S-AIR reception is poor

PTIC

OPTICAL

?/1

Enjoying the S-AIR

receiver while the S-AIR

main unit is in standby

mode

(For the S-AIR receiver only (not

supplied))

You can enjoy the S-AIR receiver while the

S-AIR main unit is in standby mode by setting

“S-AIR STBY” to “STBY ON”.

1 Press AMP MENU.

2 Press V/v repeatedly to select

“<S-AIR>”, then press or b.

3 Press V/v repeatedly to select

“S-AIR STBY”, then press

or b.

4 Press V/v repeatedly to select

the setting you want.

• STBY OFF: You cannot enjoy the

S-AIR receiver while the S-AIR main

unit is in standby mode.

• STBY ON: You can enjoy the S-AIR

receiver while the S-AIR main unit is in

standby mode or turned on.

To exit the menu

Press MENU/HOME or AMP MENU.

Notes

• When you set “S-AIR STBY” to “STBY ON”, the

power consumption increases during the standby

mode.

• When the wireless transmitter is removed from the

S-AIR main unit, “S-AIR STBY” is set to “STBY

OFF” automatically.

• If you have selected “FM TUNER” or “AM

TUNER” on the S-AIR main unit before you turn

it off and “S-AIR STBY” is set to “STBY ON”,

you can only select the same band for the tuner on

the S-AIR receiver. However, you can select input

other than TUNER on the S-AIR receiver.

• The sound of the S-AIR receiver may be cut off by

operation of the S-AIR main unit.

• When the receiver is in standby mode, “S-AIR”

indicator lights up on the display if “S-AIR STBY”

is set to “STBY ON”.

AMP

V/v/B/b

MENU/

HOME

Advanced Operations

Switching between

digital and analog audio

(INPUT MODE)

When you connect components to both digital

and analog input jacks on the receiver, you can

fix the audio input mode to either of them, or

switch from one to the other, depending on the

type of material you intend to watch.

1 Turn INPUT SELECTOR on the

receiver to select the input.

You can also use the input buttons on the

remote.

2 Press INPUT MODE repeatedly

on the receiver to select the

audio input mode.

The selected audio input mode appears on

the display.

Audio input modes

x AUTO

Gives priority to digital audio signals when

there are both digital and analog connections.

If there are no digital audio signals, analog

audio signals are selected.

x ANALOG

Specifies the analog audio signals input to the

AUDIO IN (L/R) jacks.

Notes

• Some audio input modes may not be set up

depending on the input.

• When the Analog Direct function is selected, audio

input is set to “ANALOG” automatically and you

cannot select other modes.

• When HDMI 1–4 or DMPORT input is selected,

“------” appears on the display, and you cannot

select other modes. Select an input mode other than

the HDMI 1–4 and DMPORT input, then set the

audio input mode.

Enjoying the sound/

images from other inputs

You can reassign audio and/or video signals to

another input when they are not currently

being used.

For example when you want to connect your

DVD player but cannot find an unused input:

1 Press AMP MENU.

2 Press V/v repeatedly to select

“<AUDIO>” or “<VIDEO>”, then

press or b.

3 Press V/v repeatedly to select

“A. ASSIGN” or “V. ASSIGN”,

then press or b.

4 Press V/v repeatedly to select

the input name you want to

assign (for example, “DVD”),

then press or b.

5 Press V/v repeatedly to select

the input jack you want to

assign to the input.

To return to the previous display

Press B.

Advanced Operations

?/1

DVD player

Receiver

To O P TIC A L

BD IN jack

(audio signal)

To COMPONENT

VIDEO IN 1 jacks

(video signal)

Assign to DVD input jack

– using “A. ASSIGN” in

AUDIO menu

– using “V. ASSIGN” in

VIDEO menu

continued

Assigning input jacks

* Initial setting

Notes

• You cannot assign optical signals from an input

source to the optical input jacks on the receiver.

• When you assign the digital audio input, the

INPUT MODE setting may change automatically

(page 69).

• You cannot reassign more than one HDMI input to

the same input.

• You cannot reassign more than one digital audio

input to the same input.

• You cannot reassign more than one component

video input to the same input.

Assignable input

jacks

Input name

VIDEO 1 VIDEO 2 BD DVD SAT/

CATV

SA-CD/

Video COMPONENT1 aaa* aaa

COMPONENT2 aaaa* aa

COMPONENT3 aaaaa* a

HDMI1 aaaaaa

HDMI2 aaaaaa

HDMI3 aaaaaa

HDMI4 aaaaaa

COMPOSITE a* a* a – a –

NONE – – – a – a*

Audio BD OPT aaa* a – a

SAT OPT aa– aa* a

DVD COAX aaaa* aa

ANALOG a* a* a – aa*

Advanced Operations

Enjoying sound/images

from the components

connected to the DIGITAL

MEDIA PORT

The DIGITAL MEDIA PORT (DMPORT)

allows you to enjoy sound/images from a

portable audio source or computer by

connecting a DIGITAL MEDIA PORT

adapter.

The DIGITAL MEDIA PORT adapters are

available for purchase depending on the area.

For details on connecting the DIGITAL

MEDIA PORT adapter, see “4a: Connecting

the audio components” (page 23).

Notes

• Depending on the DIGITAL MEDIA PORT

adapter, video output may not be possible.

• Depending on the type of DIGITAL MEDIA

PORT adapter, you can operate the connected

component by using the remote. For details on the

remote button operation, see page 15.

1 Press DMPORT.

You can also use the INPUT SELECTOR

on the receiver to select “DMPORT”.

2 Start playback of the connected

component.

The sound is played back on the receiver

and the image appears on the TV screen.

For details, refer to the operating

instructions supplied with the DIGITAL

MEDIA PORT adapter.

Tip

When listening to MP3 or other compressed music

using a portable audio source, you can enhance the

sound. Press SOUND FIELD +/– repeatedly to

select “PORTABLE” (page 52).

Using a bi-amplifier

connection

Press AMP MENU.

2 Press V/v repeatedly to select

“<SPEAKER>”, then press

or b.

3 Press V/v repeatedly to select

“SP PATTERN”, then press

or b.

4 Press V/v select the

appropriate speaker pattern so

that there are no surround back

speakers and front high

speakers.

5 Press or B.

6 Press V/v repeatedly to select

“SB ASSIGN”, then press or

7 Press V/v repeatedly to select

“BI-AMP”.

The same signals output from the

SPEAKERS FRONT A terminals can be

output from the SPEAKERS

SURROUND BACK/FRONT HIGH/

BI-AMP/FRONT B terminals.

To exit the menu

Press MENU/HOME or AMP MENU.

Notes

• Set “SB ASSIGN” to “BI-AMP” before you

perform Auto Calibration.

• If you set “SB ASSIGN” to “BI-AMP”, the speaker

level and distance settings of the surround back

speakers and front high speakers become invalid,

and those of the front speakers are used.

Using the setting menu

By using the setting menus, you can make

various adjustments to customize the receiver.

1 Press AMP MENU.

2 Press V/v repeatedly to select

the menu you want.

3 Press or b to enter the

menu.

4 Press V/v repeatedly to select

the parameter you want to

adjust.

5 Press or b to enter the

parameter.

6 Press V/v repeatedly to select

the setting you want.

The setting is entered automatically.

To return to the previous

display

Press B or RETURN/EXIT O.

To exit the menu

Press MENU/HOME or AMP MENU.

Note

Some parameters and settings may appear dimmed

on the display. This means that they are either

unavailable or fixed and unchangeable.

AMP

V/v/B/b

MENU/

HOME

RETURN/

EXIT O

Advanced Operations

The following options are available in each menu. For details, see the page in the parentheses.

Overview of the menus

[Display]

Parameters

[Display]

Settings Initial

setting

AUTO CAL

[<AUTO CAL>]

(page 40)

Starts Auto Calibration

[A.CAL START]

Calibration type

[CAL TYPE]

FULL FLAT, ENGINEER

FRONT REF, OFF

FULL FLAT

Position

[POSITION]

POS 1, POS 2, POS 3 POS 1

Naming position

[NAME IN]

For details, see “NAME IN (Naming

position)” (page 41).

LEVEL

[<LEVEL>]

(page 77)

Test tone

[TEST TONE]

OFF, AUTO xxx

OFF

Front left speaker level

[FL LEVEL]

FL –10.0 dB to FL +10.0 dB

(0.5 dB step)

FL 0 dB

Front right speaker level

[FR LEVEL]

FR –10.0 dB to FR +10.0 dB

(0.5 dB step)

FR 0 dB

Center speaker level

[CNT LEVEL]

CNT –20.0 dB to CNT +10.0 dB

(0.5 dB step)

CNT 0 dB

Surround left speaker level

[SL LEVEL]

SL –20.0 dB to SL +10.0 dB

(0.5 dB step)

SL 0 dB

Surround right speaker level

[SR LEVEL]

SR –20.0 dB to SR +10.0 dB

(0.5 dB step)

SR 0 dB

Surround back speaker level

[SB LEVEL]

SB –20.0 dB to SB +10.0 dB

(0.5 dB step)

SB 0 dB

Surround back left speaker level

[SBL LEVEL]

SBL –20.0 dB to SBL +10.0 dB

(0.5 dB step)

SBL 0 dB

Surround back right speaker

level

[SBR LEVEL]

SBR –20.0 dB to SBR +10.0 dB

(0.5 dB step)

SBR 0 dB

Front left high speaker level

[LH LEVEL]

LH –20.0 dB to LH +10.0 dB

(0.5 dB step)

LH 0 dB

Front right high speaker level

[RH LEVEL]

RH –20.0 dB to RH +10.0 dB

(0.5 dB step)

RH 0 dB

Subwoofer level

[SW LEVEL]

SW –20.0 dB to SW +10.0 dB

(0.5 dB step)

SW 0 dB

Dynamic range compressor

[D. RANGE]

COMP. MAX, COMP. STD,

COMP. AUTO, COMP. OFF

COMP. AUTO

continued

[Display]

Parameters

[Display]

Settings Initial

setting

SPEAKER

[<SPEAKER>]

(page 78)

Speaker pattern

[SP PATTERN]

For details, see page 78. 3/4.1

Front speakers size

[FRT SIZE]

LARGE, SMALL LARGE

Center speaker size

[CNT SIZE]

LARGE, SMALL LARGE

Surround speakers size

[SUR SIZE]

LARGE, SMALL LARGE

Front high speakers size

[FH SIZE]

LARGE, SMALL LARGE

Surround back speaker assign

[SB ASSIGN]

SPK B, BI-AMP, OFF OFF

Front left speaker distance

[FL DIST.]

FL 1.00 m to FL 10.00 m

(FL 3’3” to FL 32’ 9”)

(0.01 m (1 in) step)

FL 3.00 m

(FL 9’10”)

Front right speaker distance

[FR DIST.]

FR 1.00 m to FR 10.00 m

(FR 3’3” to FR 32’ 9”)

(0.01 m (1 in) step)

FR 3.00 m

(FR 9’10”)

Center speaker distance

[CNT DIST.]

CNT 1.00 m to CNT 10.00 m

(CNT 3’3” to CNT 32’ 9”)

(0.01 m (1 in) step)

CNT 3.00 m

(CNT 9’10”)

Surround left speaker distance

[SL DIST.]

SL 1.00 m to SL 10.00 m

(SL 3’3” to SL 32’ 9”)

(0.01 m (1 in) step)

SL 3.00 m

(SL 9’10”)

Surround right speaker distance

[SR DIST.]

SR 1.00 m to SR 10.00 m

(SR 3’3” to SR 32’ 9”)

(0.01 m (1 in) step)

SR 3.00 m

(SR 9’10”)

Surround back speaker distance

[SB DIST.]

SB 1.00 m to SB 10.00 m

(SB 3’3” to SB 32’ 9”)

(0.01 m (1 in) step)

SB 3.00 m

(SB 9’10”)

Surround back left speaker

distance

[SBL DIST.]

SBL 1.00 m to SBL 10.00 m

(SBL 3’3” to SBL 32’ 9”)

(0.01 m (1 in) step)

SBL 3.00 m

(SBL 9’10”)

Surround back right speaker

distance

[SBR DIST.]

SBR 1.00 m to SBR 10.00 m

(SBR 3’3” to SBR 32’ 9”)

(0.01 m (1 in) step)

SBR 3.00 m

(SBR 9’10”)

Front left high speaker distance

[LH DIST.]

LH 1.00 m to LH 10.00 m

(LH 3’3” to LH 32’ 9”)

(0.01 m (1 in) step)

LH 3.00 m

(LH 9’10”)

Front right high speaker

distance

[RH DIST.]

RH 1.00 m to RH 10.00 m

(RH 3’3” to RH 32’ 9”)

(0.01 m (1 in) step)

RH 3.00 m

(RH 9’10”)

Subwoofer distance

[SW DIST.]

SW 1.00 m to SW 10.00 m

(SW 3’3” to SW 32’ 9”)

(0.01 m (1 in) step)

SW 3.00 m

(SW 9’10”)

Advanced Operations

[Display]

Parameters

[Display]

Settings Initial

setting

Distance unit

[DIST. UNIT]

METER, FEET METER

Front speaker crossover

frequency

[FRT CROSS]

CROSS 40 Hz to CROSS 200 Hz

(10 Hz step)

CROSS 120 Hz

Center speaker crossover

frequency

[CNT CROSS]

CROSS 40 Hz to CROSS 200 Hz

(10 Hz step)

CROSS 120 Hz

Surround speaker crossover

frequency

[SUR CROSS]

CROSS 40 Hz to CROSS 200 Hz

(10 Hz step)

CROSS 120 Hz

Front high speaker crossover

frequency

[FH CROSS]

CROSS 40 Hz to CROSS 200 Hz

(10 Hz step)

CROSS 120 Hz

SURROUND

[<SURROUND>]

(page 81)

Sound field selection

[S.F. SELECT]

For details, see “Enjoying Surround

Sound” (page 51).

A.F.D. AUTO

Effect level

[EFFECT]

EFCT. MAX, EFCT. STD,

EFCT. MIN

EFCT. STD

[<EQ>]

(page 81)

Front speakers bass level

[BASS]

BASS –10 dB to BASS +10 dB

(1 dB step)

BASS 0 dB

Front speakers treble level

[TREBLE]

TREBLE –10 dB to TREBLE +10 dB

(1 dB step)

TREBLE 0 dB

TUNER

[<TUNER>]

(page 81)

FM station receiving mode

[FM MODE]

STEREO, MONO STEREO

Naming preset stations

[NAME IN]

For details, see “Naming preset

stations” (page 49).

AUDIO

[<AUDIO>]

(page 82)

Synchronizes audio with video

output

[A/V SYNC]

0 ms to 300 ms

(10 ms step)

0 ms

Digital broadcast language

selection

[DUAL MONO]

MAIN/SUB, MAIN, SUB MAIN

Digital audio input decoding

priority

[DEC. PRIO]

DEC. AUTO, DEC. PCM DEC. AUTO

Digital audio input assignment

[A. ASSIGN]

For details, see “Enjoying the sound/

images from other inputs” (page 69).

Night mode

[NIGHT MODE]

NIGHT ON, NIGHT OFF NIGHT OFF

VIDEO

[<VIDEO>]

(page 83)

Resolution

[RESOLUTION]

AUTO, 480/576p, 720p,

1080i, 1080p

AUTO

Video input assignment

[V. ASSIGN]

For details, see “Enjoying the sound/

images from other inputs” (page 69).

continued

xxx represent a speaker channel (FL, FR, CNT, SL, SR, SB, SBL, SBR, LH, RH, SW).

You can only select this parameter if “SP PATTERN” is not set to a setting with surround back or front high

speakers (page 78).

Depending on the speaker pattern setting, some parameters may not be available.

You cannot select this setting if your speaker is set to “LARGE”.

This parameter is only available when HDMI input signals is detected.

“FEET” for models of area code U2.

This parameter is only available if the S-AIR transmitter (not supplied) is inserted to the EZW-T100 slot on

the receiver.

[Display]

Parameters

[Display]

Settings Initial

setting

HDMI

[<HDMI>]

(page 83)

Control for HDMI

[CTRL: HDMI]

CTRL ON, CTRL OFF CTRL ON

HDMI Signal Pass Through

[PASS THRU]

ON, AUTO, OFF OFF

Setting HDMI audio input

[AUDIO OUT]

AMP, TV+AMP AMP

Subwoofer level for HDMI

[SW LEVEL]

SW AUTO, SW +10 dB, SW 0 dB SW AUTO

Subwoofer Low Pass Filter for

HDMI

[SW L.P.F.]

L.P.F. ON, L.P.F. OFF L.P.F. ON

Audio Return Channel

[ARC]

ARC ON, ARC OFF ARC ON

SYSTEM

[<SYSTEM>]

(page 85)

Brightness of the display

[DIMMER]

DIM MAX, DIM MID, DIM OFF DIM OFF

Sleep Timer

[SLEEP]

2:00:00, 1:30:00, 1:00:00, 0:30:00,

OFF

Auto standby mode

[AUTO STBY]

STBY ON, STBY OFF STBY ON

Naming inputs

[NAME IN]

For details, see “Naming inputs”

(page 44).

S-AIR

[<S-AIR>]

(page 85)

S-AIR ID

[S-AIR ID]

ID: A, ID: B, ID: C ID: A

Pairing

[PAIRING]

START, CONDITION START

S-AIR mode

[S-AIR MODE]

PARTY, SEPARATE PARTY

RF Change

[RF CHANGE]

RF AUTO, RF ON, RF OFF RF AUTO

S-AIR Standby

[S-AIR STBY]

STBY ON, STBY OFF STBY OFF

Advanced Operations

You can adjust the level of each speaker.

These settings are applied to all sound fields.

x TEST TONE

Lets you adjust the speaker levels while

listening to the test tone from your listening

position.

•OFF

The test tone is turned off.

• AUTO xxx

The test tone is output from each speaker in

sequence.

* xxx represent a speaker channel.

Adjusting the speaker level

You can adjust each speaker’s level using the

following parameters.

For front left/right speakers, you can adjust the

level from –10.0 dB to +10.0 dB in 0.5 dB

steps. For other speakers, you can adjust the

level from –20.0 dB to +10.0 dB in 0.5 dB

steps.

x FL LEVEL

x FR LEVEL

x CNT LEVEL

x SL LEVEL

x SR LEVEL

x SB LEVEL

x SBL LEVEL

x SBR LEVEL

x LH LEVEL

x RH LEVEL

x SW LEVEL

Note

Depending on the speaker pattern setting, some

parameters may not be available.

x D. RANGE

Lets you compress the dynamic range of the

soundtrack. This may be useful when you want

to watch movies at low volumes late at night.

Dynamic range compression is possible with

Dolby Digital sources only.

•COMP. MAX

The dynamic range is compressed

dramatically.

•COMP. STD

The dynamic range is compressed as

intended by the recording engineer.

•COMP. AUTO

The dynamic range is compressed

automatically.

• COMP. OFF

The dynamic range is not compressed.

Tip

Dynamic range compressor lets you compress the

dynamic range of the soundtrack based on the

dynamic range information included in the Dolby

Digital signal.

“COMP. STD” is the standard setting, but it only

enacts light compression. Therefore, we recommend

using the “COMP. MAX” setting. This greatly

compresses the dynamic range and lets you view

movies late at night at low volumes. Unlike analog

limiters, the levels are predetermined and provide a

very natural compression.

LEVEL menu

You can set the size and distance of the speakers connected to this receiver.

x SP PATTERN

Lets you set the number of speakers connected to this receiver. It should be synchronize with the

speakers settings.

For example:

SPEAKER menu

Speaker

pattern

Front

left/right

Front left/

right high

Center Surround

left/right

Surround

back left

Surround

back right

Subwoofer

5/2.1 aa aa ––a

5/2 a a a a –––

4/2.1 aa – a ––a

4/2 aa – a –––

3/4.1 a – aa a a a

3/4 a – aa a a –

2/4.1 a ––aaaa

2/4 a ––aaa –

3/3.1 a – aa a – a

3/3 a – aa a ––

2/3.1 a ––aa – a

2/3 a ––aa ––

3/2.1 a – aa ––a

3/2 a – aa –––

2/2.1 a ––a ––a

2/2 a ––a –––

3/0.1 a – a –––a

3/0 a – a ––––

2/0.1 a –––––a

2/0 a – –––––

5 / 2 1.

2 front +

2 front high

+ center

2 surround subwoofer

Advanced Operations

x FRT SIZE

• LARGE

If you connect large speakers that will

effectively reproduce bass frequencies,

select “LARGE”. Normally, select

“LARGE”. However, if you have selected a

speaker pattern without subwoofer, the front

speakers are automatically set to “LARGE”.

•SMALL

If the sound is distorted, or you feel a lack of

surround effects when using multi channel

surround sound, select “SMALL” to activate

the bass redirection circuitry and output the

front channel bass frequencies from the

subwoofer. When the front speakers are set

to “SMALL”, the center, surround and front

high speakers are also automatically set to

“SMALL”.

x CNT SIZE

• LARGE

If you connect a large speaker that will

effectively reproduce bass frequencies,

select “LARGE”. Normally, select

“LARGE”. However, if the front speakers

are set to “SMALL”, you cannot set the

center speaker to “LARGE”.

•SMALL

If the sound is distorted, or you feel a lack of

surround effects when using multi channel

surround sound, select “SMALL” to activate

the bass redirection circuitry and output the

center channel bass frequencies from the

front speakers (if set to “LARGE”) or

subwoofer.

x SUR SIZE

The surround back speakers will be set to the

same setting.

• LARGE

If you connect large speakers that will

effectively reproduce bass frequencies,

select “LARGE”. Normally, select

“LARGE”. However, if the front speakers

are set to “SMALL”, you cannot set the

surround speakers to “LARGE”.

•SMALL

If the sound is distorted, or you feel a lack of

surround effects when using multi channel

surround sound, select “SMALL” to activate

the bass redirection circuitry and output the

surround channel bass frequencies from the

subwoofer or other speaker that is set to

“LARGE”.

x FH SIZE

• LARGE

If you connect large speakers that will

effectively reproduce bass frequencies,

select “LARGE”. Normally, select

“LARGE”. However, if the front speakers

are set to “SMALL”, you cannot set front

high speakers to “LARGE”.

•SMALL

If the sound is distorted, or you feel a lack of

surround effects when using multi channel

surround sound, select “SMALL” to activate

the bass redirection circuitry and output the

front high channel bass frequencies from the

subwoofer or other speaker that is set to

“LARGE”.

continued

Tip

The “LARGE” and “SMALL” settings for each

speaker determine whether the internal sound

processor will cut the bass signal from that channel.

When the bass is cut from a channel, the bass

redirection circuitry sends the corresponding bass

frequencies to the subwoofer or other “LARGE”

speakers.

However, since bass sounds have a certain amount of

directionality, it is best not to cut them, if possible.

Therefore, even when using small speakers, you can

set them to “LARGE” if you want to output the bass

frequencies from that speaker. On the other hand, if

you are using a large speaker, but prefer not to have

bass frequencies output from that speaker, set it to

“SMALL”.

If the overall sound level is lower than you prefer, set

all speakers to “LARGE”. If there is not enough

bass, you can use the equalizer to boost the bass

levels. For details, see page 81.

x SB ASSIGN

•SPK B

If you connect an additional front speaker

system to the SPEAKERS SURROUND

BACK/FRONT HIGH/BI-AMP/FRONT B

terminals, select “SPK B”.

• BI-AMP

If you connect front speakers to the

SPEAKERS SURROUND BACK/FRONT

HIGH/BI-AMP/FRONT B terminals using a

bi-amplifier connection, select “BI-AMP”.

•OFF

If you connect surround back speakers or

front high speakers to the SPEAKERS

SURROUND BACK/FRONT HIGH/

BI-AMP/FRONT B terminals, select “OFF”.

Note

When you change the connection from bi-amplifier

or speaker front B to surround back or front high

speakers connection, set “SB ASSIGN” to “OFF”,

then perform the Auto Calibration again (page 37).

x FL DIST.

x FR DIST.

Lets you set the distance from your listening

position to the front speakers.

If both front speakers are not placed an equal

distance from your listening position, set the

distance to the closest speaker.

x CNT DIST.

Lets you set the distance from your listening

position to the center speaker.

x SL DIST.

x SR DIST.

Lets you set the distance from your listening

position to the surround speakers.

x SB DIST.

x SBL DIST.

x SBR DIST.

Lets you set the distance from your listening

position to the surround back speakers.

x LH DIST.

x RH DIST.

Lets you set the distance from your listening

position to the front high speakers.

x SW DIST.

Lets you set the distance from your listening

position to the subwoofer.

Notes

• Depending on the speaker pattern setting. Some

parameters may not be available.

• This function does not work in the following cases.

– Signals with a sampling frequency of more than

96 kHz are being received.

– Analog Direct is selected.

Advanced Operations

x DIST. UNIT

Lets you select the unit of measure for setting

distances.

• METER

The distance is displayed in meters.

•FEET

The distance is displayed in feet.

x FRT CROSS

Lets you set the bass crossover frequency of

the front speakers that have been set to

“SMALL” in the SPEAKER menu.

x CNT CROSS

Lets you set the bass crossover frequency of

the center speaker that have been set to

“SMALL” in the SPEAKER menu.

x SUR CROSS

Lets you set the bass crossover frequency of

the surround speakers that have been set to

“SMALL” in the SPEAKER menu.

x FH CROSS

Lets you set the bass crossover frequency of

the front high speakers that have been set to

“SMALL” in the SPEAKER menu.

You can select the sound field you want for

your listening pleasure.

x S.F. SELECT

Lets you select the sound field you want. For

details, see “Enjoying Surround Sound” (page

51).

Note

The receiver lets you apply the last selected sound

field to an input whenever it is selected (Sound Field

Link). For example, if you select “HALL” for the

DVD input, then change to a different input and then

return to DVD, “HALL” will automatically be

applied again.

x EFFECT

Lets you adjust the “presence” of the surround

effect for the Cinema Studio EX A/B/C sound

fields.

You can adjust the tonal quality (bass/treble

level) of the front speakers.

x BASS

x TREBLE

Note

This function does not work in the following cases.

– Signals with a sampling frequency of more than

48 kHz are being received.

– Analog Direct is selected.

Tip

You can also adjust the front speaker bass and treble

level with TONE MODE and TONE +/– on the

receiver.

You can set the FM station receiving mode and

name the preset stations.

x FM MODE

• STEREO

This receiver will decode the signal as stereo

signal when the radio station is broadcast in

stereo.

•MONO

This receiver will decode the signal as mono

signal regardless of the broadcast signal.

x NAME IN

Lets you set the name of preset stations. For

details, see “Naming preset stations” (page

49).

SURROUND menu

EQ menu

TUNER menu

You can make settings for the audio to suit

your preference.

x A/V SYNC

Lets you delay the output of audio to minimize

the time gap between audio output and visual

display. You can adjust from 0 ms to 300 ms

in 10 ms steps.

Notes

• This parameter is useful when you use a large LCD

or plasma monitor or a projector.

• This function does not work in the following cases.

– Signals with a sampling frequency of more than

96 kHz are being received.

– Analog Direct is selected.

x DUAL MONO

Lets you select the language you want to listen

to during digital broadcast. This feature only

functions for Dolby Digital sources.

• MAIN/SUB

Sound of the main language will be output

through the front left speaker and sound of

the sub language will be output through the

front right speaker simultaneously.

•MAIN

Sound of the main language will be output.

•SUB

Sound of the sub language will be output.

x DEC. PRIO

Lets you specify the input mode for the digital

signal input to the DIGITAL IN or HDMI IN

jacks.

•DEC. AUTO

Automatically switches the input mode

between DTS, Dolby Digital, or PCM.

•DEC. PCM

When signals from the DIGITAL IN jack are

selected, PCM signals are given priority (to

prevent interruption when playback starts).

However, when other signals are input, there

may be no sound, depending on the format.

In this case, set this item to “DEC. AUTO”.

When signals from the HDMI IN jack are

selected, only PCM signals are output from

the connected player. When signals other

than PCM are received, set this item to

“DEC. AUTO”.

Notes

• Even when “DEC. PRIO” is set to “DEC. PCM”,

the sound may be interrupted at the very beginning

of the first track depending on the CD being played

back.

• When playback a DTS CD, set “DEC. PRIO” to

“DEC. AUTO”.

x A. ASSIGN

Lets you assign the digital audio input to other

input source. For details, see “Enjoying the

sound/images from other inputs” (page 69).

x NIGHT MODE

Lets you to retain a theater-like environment at

low volume levels. For details, see “Enjoying

the surround effect at low volume levels

(NIGHT MODE)” (page 55).

• NIGHT ON

• NIGHT OFF

AUDIO menu

Advanced Operations

You can make settings for video.

x RESOLUTION

Lets you convert the resolution of analog

video input signals (component video and

video) and output from the HDMI TV OUT

jack.

•AUTO

The resolution is set automatically,

depending on the connected TV.

• 480/576p

The resolution is set to 480p/576p. Video

signals are upconverted and output through

the receiver.

• 720p

The resolution is set to 720p. Video signals

are upconverted and output through the

receiver.

• 1080i

The resolution is set to 1080i. Video signals

are upconverted and output through the

receiver.

• 1080p

The resolution is set to 1080p. Video signals

are upconverted and output through the

receiver.

Note

If you select a resolution that the connected TV does

not support in “RESOLUTION”, the images from

the TV will not be output correctly.

x V. AS SI G N

Lets you assign the video input to other input

source. For details, see “Enjoying the sound/

images from other inputs” (page 69).

You can make various adjustments for HDMI

settings.

x CTRL: HDMI

Lets you turn the Control for HDMI function

on or off. For details, see ““BRAVIA” Sync

Features” (page 56).

x PASS THRU

Lets you output the HDMI signals to the TV

even when the receiver is in standby mode.

•ON

When the receiver is in the standby mode,

the receiver continuously outputs HDMI

signals from the receiver’s HDMI TV OUT

jack.

•AUTO

When the TV is turned on while the receiver

is in the standby mode, the receiver outputs

HDMI signals from the receiver’s HDMI TV

OUT jack. Sony recommends this setting if

you use a TV that is compatible with

“BRAVIA” Sync. This setting saves power

in the standby mode compared with the

“ON” setting.

•OFF

The receiver does not output HDMI signals

when in the standby mode. Turn on the

receiver to enjoy the connected component’s

source on the TV. This setting saves power in

the standby mode compared with the “ON”

setting.

Notes

• This parameter is not available when “CTRL:

HDMI” is set to “CTRL OFF”.

• When “AUTO” is selected, it may take a little more

time for the image and sound to be output to the TV

than when “ON” is selected.

• When the receiver is in standby mode, “HDMI”

indicator will lights up if “PASS THRU” is set to

“AUTO” or “ON”. However, when “PASS THRU”

is set to “AUTO”, this indicator will lights off if no

signals are detected.

VIDEO menu HDMI menu

continued

x AUDIO OUT

Lets you set the HDMI audio output from the

playback component connected to the receiver

via an HDMI connection.

•AMP

The HDMI audio signals from the playback

component are only output to the speakers

connected to the receiver. Multi channel

sound can be played back as it is.

Note

Audio signals are not output from the TV’s

speakers when “AUDIO OUT” is set to “AMP”.

• TV+AMP

The sound is output from TV’s speaker and

the speakers connected to the receiver.

Notes

• The sound quality of the playback component

depends on the TV’s sound quality, such as the

number of channels, and the sampling

frequency, etc. When the TV has stereo

speakers, the sound output from the receiver is

also stereo as that of the TV, even if you play

back multi channel software.

• When you connect the receiver to an image

display component (projector, etc.), sound may

not be output from the receiver. In this case,

select “AMP”.

x SW LEVEL

Lets you set the level of the subwoofer to 0 dB

or +10 dB when multi channel Linear PCM

signals are input via an HDMI connection. You

can set the level for each HDMI input

independently.

•SW AUTO

Automatically sets the level to 0 dB or

+10 dB depending on the frequency.

• SW +10 dB

•SW 0 dB

x SW L.P.F.

Lets you set the low pass filter of the

subwoofer when multi channel Linear PCM

signals are input via an HDMI connection.

Set the “SW L.P.F.” if your connected

subwoofer’s crossover frequency do not have

low pass filter.

• L.P.F. ON

The low pass filter of the subwoofer’s cut off

frequency is set to 120 Hz.

• L.P.F. OFF

The low pass filter of the subwoofer is

turned off.

x ARC

Lets you enjoy the TV sound from the

speakers connected to the receiver via an

HDMI cable. For details, see “Enjoying the

TV sound via an HDMI cable” (page 60).

• ARC ON

Audio signal is input to the HDMI TV OUT

jack.

• ARC OFF

Audio signal is input to the TV OPTICAL

IN or TV AUDIO IN jacks.

Note

This parameter is not available when “CTRL:

HDMI” is set to “CTRL OFF”.

Using the Remote

You can customize the settings of the receiver.

x DIMMER

Lets you adjust the brightness of the display in

3 levels.

Tip

You can also use DIMMER on the receiver.

x SLEEP

Lets you set the receiver to turn off

automatically at a specific time. For details,

see “Using the Sleep Timer” (page 45).

• 2:00:00

• 1:30:00

• 1:00:00

• 0:30:00

•OFF

x AUTO STBY

Lets you set the receiver switch to standby

mode automatically when you do not operate

the receiver or when there is no signals input

to the receiver.

• STBY ON

Switches to standby mode after

approximately 30 minutes.

• STBY OFF

Does not switch to standby mode.

Notes

• This function does not work in the following cases.

– TUNER input is selected.

– S-AIR receiver or surround amplifier is used.

• If you use the Auto Standby mode and the Sleep

Timer at the same time, the Sleep Timer has

priority.

x NAME IN

Lets you set the name of inputs. For details,

see “Naming inputs” (page 44).

For details on S-AIR, see “S-AIR Operations”

(page 60).

Programming the remote

You can program the remote to control non-

Sony components by changing the code. Once

the control signals have been memorized, you

can use those components as part of your

system.

Furthermore, you can also program the remote

for Sony components that the remote is unable

to control. Note that the remote can only

control components that accept infrared

wireless control signals.

Note

You cannot change the settings of DMPORT input

buttons.

1 Press AV ?/1 while pressing

RM SET UP.

The RM SET UP indicator slowly flashes.

2 Press the input button for the

component you want to control.

For example, if you are going to control a

CD player, press SA-CD/CD.

The RM SET UP and SHIFT indicator

light up.

SYSTEM menu

S-AIR menu

Using the Remote

DVD

VIDEO 1

HDMI 2

DMPORT

SAT/

CATV

VIDEO 2

HDMI 3HDMI 1

SA-CD/

TUNER

HDMI 4

Input

buttons

AV ?/1

ENTER

RM SET

Numeric

buttons

continued

3 Press the numeric buttons to

enter the numeric code (or one

of the codes if more than one

code exists) corresponding to

the component and the maker

of the component you want to

control (including TV button).

See the tables on page 86–89 for

information on the numeric code(s)

corresponding to the component and the

maker of the component (the first digit

and the last two digits of the numeric code

correspond to the category and the

maker’s code respectively).

Note

As a remote code value for the TV button, only

numbers in the 500’s are valid.

4 Press ENTER.

Once the numeric code has been verified,

the RM SET UP indicator slowly flashes

twice and the remote automatically exits

the programming mode.

5 Repeat steps 1 to 4 to control

other components.

Notes

• The indicator turns off while a valid button is

pressed.

• In step 2, if you press TUNER, you can only

program the button to control a tuner (page 86).

• For the numeric codes, only the last three numbers

entered are valid.

To cancel programming

Press RM SET UP during any step. The RM

SET UP indicator flashes 5 times in quick

succession. The remote automatically exits the

programming mode.

To activate the input after

programming

Press the programmed button to activate the

input you want.

If programming is

unsuccessful, check the

following:

• If the indicator does not light up in step 1, the

batteries are weak. Replace both batteries.

• If the indicator flashes 5 times in quick

succession while entering the numeric code,

an error has occurred.

Start again from step 1.

Use the numeric codes in the tables below to

control non-Sony components and also Sony

components that the remote is normally unable

to control. Since the remote signal that a

component accepts differs depending on the

model and year of the component, more than

one numeric code may be assigned to a

component. If you fail to program your remote

using one of the codes, try using other codes.

Notes

• The numeric codes are based on the latest

information available for each brand. There is a

chance, however, that your component will not

respond to some or all of the codes.

• All of the input buttons on this remote may not be

available when used with your particular

component.

To control a tuner

The numeric codes

corresponding to the component

and the maker of the component

Maker Code(s)

SONY 005

Using the Remote

To control a CD player

To control a DAT deck

To control a tape deck

To control an MD deck

To control an HDD recorder

To control a Blu-ray disc player/

recorder

To control a PSX

To control a DVD player

To control a DVD recorder

Maker Code(s)

SONY 101, 102, 103

DENON 104, 123

JVC 105, 106, 107

KENWOOD 108, 109, 110

MAGNAVOX 111, 116

MARANTZ 116

ONKYO 112, 113, 114

PANASONIC 115

PHILIPS 116

PIONEER 117

TECHNICS 115, 118, 119

YAMAHA 120, 121, 122

Maker Code(s)

SONY 203

PIONEER 219

Maker Code(s)

SONY 201, 202

DENON 204, 205

KENWOOD 206, 207, 208, 209

NAKAMICHI 210

PANASONIC 216

PHILIPS 211, 212

PIONEER 213, 214

TECHNICS 215, 216

YAMAHA 217, 218

Maker Code(s)

SONY 301

DENON 302

JVC 303

KENWOOD 304

Maker Code(s)

SONY 307, 308, 309

Maker Code(s)

SONY 310, 311, 312

PANASONIC 335

SAMSUNG 336

LG 337

Maker Code(s)

SONY 313, 314, 315

Maker Code(s)

SONY 401, 402, 403

BROKSONIC 424

DENON 405

HITACHI 416

JVC 415, 423

MITSUBISHI 419

ORITRON 417

PANASONIC 406, 408, 425

PHILIPS 407

PIONEER 409, 410

RCA 414

SAMSUNG 416, 422

TOSHIBA 404, 421

ZENITH 418, 420

Maker Code(s)

SONY 401, 402, 403

continued

To control a DVD/VCR COMBO

To control a DVD/HDD COMBO

To control a TV

To control an LD player

Maker Code(s)

SONY 411

Maker Code(s)

SONY 401, 402, 403

Maker Code(s)

SONY 501, 502

AIWA 501, 536, 539

AKAI 503

AOC 503

CENTURION 566

CORONADO 517

CURTIS-MATHES 503, 551, 566, 567

DAYTRON 517, 566

DAEWOO 504, 505, 506, 507,

515, 544

FISHER 508, 545

FUNAI 548

FUJITSU 528

GOLDSTAR/LG 503, 512, 515, 517,

534, 544, 556, 568

GRUNDIG 511, 533, 534

HITACHI 503, 513, 514, 515,

517, 519, 544, 557,

571

ITT/NOKIA 521, 522

J.C.PENNY 503, 510, 566

JVC 516, 552

KMC 517

MAGNAVOX 503, 515, 517, 518,

544, 566

MARANTZ 527

MITSUBISHI/MGA 503, 519, 527, 544,

566, 568

NEC 503, 517, 520, 540,

544, 554, 566

NORDMENDE 530, 558

NOKIA 521, 522, 573, 575

PANASONIC 509, 524, 553, 559,

572

PHILIPS 515, 518, 557, 570,

571

PHILCO 503, 504, 514, 517,

518

PIONEER 509, 525, 526, 540,

551, 555

PORTLAND 503

QUASAR 509, 535

RADIO SHACK 503, 510, 527, 565,

567

RCA/PROSCAN 503, 510, 523, 529,

544

SAMSUNG 503, 515, 517, 531,

532, 534, 544, 556,

557, 562, 563, 566,

569

SAMPO 566

SABA 530, 537, 547, 549,

558

SANYO 508, 545, 546, 560,

567

SCOTT 503, 566

SEARS 503, 508, 510, 517,

518, 551

SHARP 517, 535, 550, 561,

565

SYLVANIA 503, 518, 566

THOMSON 530, 537, 547, 549

TOSHIBA 535, 539, 540, 541,

551

TELEFUNKEN 530, 537, 538, 547,

549, 558

TEKNIKA 517, 518, 567

WARDS 503, 517, 566

YORK 566

ZENITH 542, 543, 567

GE 503, 509, 510, 544

LOEWE 515, 534, 556

Maker Code(s)

SONY 601, 602, 603

PIONEER 606

Maker Code(s)

Using the Remote

To control a video CD player

To control a VCR

* If an AIWA VCR does not work even though you

enter the code for AIWA, enter the code for Sony

instead.

To control a satellite tuner (box)

To control a cable box

Maker Code(s)

SONY 605

Maker Code(s)

SONY 701, 702, 703, 704,

705, 706

AIWA* 710, 750, 757, 758

AKAI 707, 708, 709, 759

BLAUPUNKT 740

EMERSON 711, 712, 713, 714,

715, 716, 750

FISHER 717, 718, 719, 720

GENERAL ELECTRIC

(GE)

721, 722, 730

GOLDSTAR/LG 723, 753

HITACHI 722, 725, 729, 741

ITT/NOKIA 717

JVC 726, 727, 728, 736

MAGNAVOX 730, 731, 738

MITSUBISHI/MGA 732, 733, 734, 735

NEC 736

PANASONIC 729, 730, 737, 738,

739, 740

PHILIPS 729, 730, 731

PIONEER 729

RCA/PROSCAN 722, 729, 730, 731,

741, 747

SAMSUNG 742, 743, 744, 745

SANYO 717, 720, 746

SHARP 748, 749

TOSHIBA 747, 756

ZENITH 754

Maker Code(s)

SONY 801, 802, 803, 804,

824, 825, 865

AMSTRAD 845, 846

BskyB 862

GENERAL ELECTRIC

(GE)

866

GRUNDIG 859, 860

HUMAX 846, 847

THOMSON 857, 861, 864, 876

PACE 848, 849, 850, 852,

862, 863, 864

PANASONIC 818, 855

PHILIPS 856, 857, 858, 859,

860, 864, 874

NOKIA 851, 853, 854, 864

RCA/PROSCAN 866, 871

BITA/HITACHI 868

HUGHES 867

JVC/Echostar/Dish

Network

873

MITSUBISHI 872

SAMSUNG 875

TOSHIBA 869, 870

Maker Code(s)

SONY 821, 822, 823

HAMLIN/REGAL 836, 837, 838, 839,

840

JERROLD/G.I./

MOTOROLA

806, 807, 808, 809,

810, 811, 812, 813,

814, 819

JERROLD 830, 831

OAK 841, 842, 843

PANASONIC 816, 826, 832, 833,

834, 835

PHILIPS 830, 831

PIONEER 828, 829

RCA 805

SCIENTIFIC ATLANTA 815, 816, 817, 844

TOCOM/PHILIPS 830, 831

ZENITH 826, 827

Clearing all the contents

of the remote’s memory

While holding down MASTER

VOL – (RM-AAP049 only) or

– (RM-AAP050 only), press

and hold ?/1, then press

AV ?/1.

The RM SET UP indicator flashes 3

times.

2 Release all buttons.

All the contents of the remote’s memory

(i.e., all the programmed data) are

cleared.

Glossary

x Cinema Studio EX

A surround sound mode that can be regarded

as the compilation of Digital Cinema Sound

technology, delivers the sound of a dubbing

theater using three technologies: “Virtual

Multi Dimensions,” “Screen Depth Matching,”

and “Cinema Studio Reverberation.”

“Virtual Multi Dimensions,” the virtual

speaker technology, creates a virtual multi-

surround environment with actual speakers up

to 7.1 channels, and brings the surround sound

experience of a theater with the latest facilities

into your home.

“Screen Depth Matching” reproduces treble

attenuation, fullness, and depth of sound

usually created in a theater using sound

emission from behind the screen. This is then

added to the front and center channels.

“Cinema Studio Reverberation” reproduces

the sound characteristics of state-of-the-art

dubbing theaters and recording studios,

including Sony Pictures Entertainment’s

dubbing studios. There are three modes, A/B/

C, available according to the studio type.

x Component video

A format for transmitting video signal

information consisting of three separate

signals: luminance Y, chrominance Pb, and

chrominance Pr. High quality pictures, such as

DVD video or HDTV pictures, are transmitted

more faithfully. The three jacks are color -

coded green, blue and red.

x Composite video

A standard format for transmitting video

signal information. The luminance signal Y

and chrominance signal C are combined and

transmitted together.

Additional Information

x Deep Colour (Deep Color)

Video signals for which the color depth of

signals passing through an HDMI jack have

been raised.

The number of colors that could be expressed

by 1 pixel was 24 bits (16,777,216 colors) with

the current HDMI jack. However, the number

of colors which can be expressed by 1 pixel

will be 36 bits, etc., when the receiver

corresponds to Deep Colour (Deep Color).

Since the gradation of the depth of a color can

be expressed more finely with more bits,

continuous color changes can be more

smoothly expressed.

x Digital Cinema Sound (DCS)

A unique sound reproduction technology for

home theater developed by Sony, in

cooperation with Sony Pictures Entertainment,

for enjoying the exciting and powerful sound

of movie theaters at home. With this “Digital

Cinema Sound” developed by integrating a

DSP (Digital Signal Processor) and measured

data, the ideal sound field intended by

filmmakers can be experienced at home.

x Dolby Digital

Digital audio encoding/decoding technology

developed by Dolby Laboratories, Inc. It

consists of front (left/right), center, surround

(left/right) and subwoofer channels. It is a

designated audio standard for DVD video and

also known as 5.1 channel surround. Since

surround information is recorded and

reproduced in stereo, more realistic sound with

fuller presence is delivered than with Dolby

surround.

x Dolby Digital Plus

Dolby Digital Plus provides the flexibility and

efficiency to deliver more channels of

compelling surround sound for high-definition

video media. Its superior coding efficiencies

enable up to 7.1 channel of high-quality

multichannel audio without negatively

impacting bit budgets allocated for video

performance or additional feature sets.

x Dolby Digital Surround EX

Acoustic technology developed by Dolby

Laboratories, Inc. Surround back information

is matrixed into regular left and right surround

channels so that the sound can be reproduced

in 6.1 channel. Active scenes, especially, are

recreated with a more dynamic and realistic

sound field.

x Dolby Pro Logic II

This technology converts 2 channel stereo

recorded audio into 5.1 channel for playback.

There is a MOVIE mode for movies and

MUSIC mode for stereo sources such as

music. Old movies encoded in the traditional

stereo format can be enhanced with 5.1

channel surround sound.

x Dolby Pro Logic IIx

Technology for 7.1 channel (or 6.1 channel)

playback. Along with audio encoded in Dolby

Digital Surround EX, 5.1 channel Dolby

Digital encoded audio can be reproduced in

7.1 channel (or 6.1 channel). Furthermore,

existing stereo recorded content can also be

reproduced in 7.1 channel (or 6.1 channel).

x Dolby Pro Logic IIz

Dolby Pro Logic IIz brings a vertical aspect to

the sound field through the addition of left and

right front high speakers. It decodes

nondirectional elements in the audio mix and

reproduces them from the high speakers,

giving an enhanced sense of depth and airiness

to the sound field.

x Dolby Surround (Dolby Pro

Logic)

Audio processing technology developed by

Dolby Laboratories, Inc. Center and mono

surround information is matrixed into two

stereo channels. When reproduced, audio is

decoded and output in 4 channel surround

sound. This is the most common audio

processing method for DVD video.

continued

x Dolby TrueHD

Dolby TrueHD is Dolby’s lossless audio

technology developed for high-definition

optical discs. Dolby TrueHD audio is bit-for-

bit identical to the original studio masters and

provides supreme-quality audio up to 8

channel at 96 kHz/24 bit and up to 6 channel at

192 kHz/24 bit. Together with high-definition

video, it offers an unprecedented home theater

experience.

x DTS 96/24

A high sound quality digital signal format. It

records audio at a sampling frequency and bit

rate of 96 kHz/24bit which is the highest

possible for DVD video. The number of

playback channels varies depending on the

software.

x DTS Digital Surround

Digital audio encoding/decoding technology

for theaters developed by DTS, Inc. It

compresses audio less than Dolby Digital,

delivering a higher quality sound

reproduction.

x DTS-ES

Format for 6.1 channel playback with

surround back information. There are two

modes, “Discrete 6.1” which records all

channels independently, and “Matrix 6.1”

which matrixes surround back channel into

surround left and surround right channels. It is

ideal for playback of motion picture

soundtracks.

x DTS-HD

Audio format which extends the conventional

DTS Digital Surround format.

This format consists of a core and an

extension, and the core part has DTS Digital

Surround compatibility. There are two kinds of

DTS-HD, DTS-HD High Resolution Audio

and DTS-HD Master Audio. DTS-HD High

Resolution Audio has a maximum

transmission rate of 6 Mbps, with lossy

compression (Lossy), and DTS-HD High

Resolution Audio corresponds to a maximum

sampling frequency of 96 kHz, and a

maximum of 7.1 channel. DTS-HD Master

Audio has a maximum transmission rate of

24.5 Mbps, and uses lossless compression

(Lossless), and DTS-HD Master Audio

corresponds to a maximum sampling

frequency of 192 kHz, and a maximum of

7.1 channel.

x DTS Neo:6

This technology converts 2 channel stereo

recorded audio for 7 channel playback. There

are two modes to select according to the

playback source or your preference, CINEMA

for movies, and MUSIC for stereo sources

such as music.

x HDMI (High-Definition

Multimedia Interface)

HDMI (High-Definition Multimedia

Interface) is an interface that supports both

video and audio on a single digital connection,

allowing you to enjoy high quality digital

picture and sound. The HDMI specification

supports HDCP (High-bandwidth Digital

Contents Protection), a copy protection

technology that incorporates coding

technology for digital video signals.

x PCM (Pulse Code Modulation)

A method of converting analog audio to digital

audio for easy enjoyment of digital sound.

Additional Information

x S-AIR (Sony Audio Interactive

Radio frequency)

Recent times have seen the rapid spread of

DVD media, Digital Broadcasting, and other

high quality media.

To ensure that the subtle nuances of these high

quality media are transmitted with no

deterioration, Sony has developed a

technology called “S-AIR” for the radio

transmission of digital audio signals with no

compression, and has incorporated this

technology into the EZW-RT10/EZW-T100.

This technology transfers digital audio signals

with no compression using the 2.4 GHz band

range of ISM band (Industrial, Scientific, and

Medical band), such as wireless LANs and

Bluetooth applications.

x Sampling frequency

To convert analog audio to digital, analog data

should be quantified. This process is called

sampling, and the number of times per second

the analog data is quantified is called the

sampling frequency. A standard music CD

stores data quantified at 44,100 times per

second, which is expressed as a sampling

frequency of 44.1 kHz. Generally speaking, a

higher sampling frequency means better sound

quality.

x x.v.Colour (x.v.Color)

x.v.Colour (x.v.Color) is a more familiar term

for the xvYCC standard proposed by Sony,

and is a trademark of Sony. xvYCC is an

international standard for color space in video.

This standard can express a wider colour range

than the currently used broadcast standard.

Precautions

On safety

Should any solid object or liquid fall into the

cabinet, unplug the receiver and have it

checked by qualified personnel before

operating it any further.

On power sources

• Before operating the receiver, check that the

operating voltage is identical with your local

power supply.

The operating voltage is indicated on the

nameplate on the back of the receiver.

• The unit is not disconnected from the AC

power source (mains) as long as it is

connected to the wall outlet, even if the unit

itself has been turned off.

• If you are not going to use the receiver for a

long time, be sure to disconnect the receiver

from the wall outlet. To disconnect the AC

power cord (mains lead), grasp the plug

itself; never pull the cord.

• (Models of area code U2 only)

One blade of the plug is wider than the other

for the purpose of safety and will fit into the

wall outlet only one way. If you are unable to

insert the plug fully into the outlet, contact

your dealer.

• The AC power cord (mains lead) must be

changed only at a qualified service shop.

On heat buildup

Although the receiver heats up during

operation, this is not a malfunction. If you

continuously use this receiver at a large

volume, the cabinet temperature of the top,

side and bottom rises considerably. To avoid

burning yourself, do not touch the cabinet.

continued

On placement

• Place the receiver in a location with adequate

ventilation to prevent heat buildup and

prolong the life of the receiver.

• Do not place the receiver near heat sources,

or in a place subject to direct sunlight,

excessive dust, or mechanical shock.

• Do not place anything on top of the cabinet

that might block the ventilation holes and

cause malfunctions.

• Do not place the receiver near equipment

such as a TV, VCR, or tape deck. (If the

receiver is being used in combination with a

TV, VCR, or tape deck, and is placed too

close to that equipment, noise may result,

and picture quality may suffer. This is

especially likely when using an indoor

antenna (aerial). Therefore, we recommend

using an outdoor antenna (aerial).)

• Use caution when placing the receiver on

surfaces that have been specially treated

(with wax, oil, polish, etc.) as staining or

discoloration of the surface may result.

On operation

Before connecting other components, be sure

to turn off and unplug the receiver.

On cleaning

Clean the cabinet, panel, and controls with a

soft cloth slightly moistened with a mild

detergent solution. Do not use any type of

abrasive pad, scouring powder, or solvent,

such as alcohol or benzine.

On S-AIR function

• As the S-AIR product(s) transmits sound by

radio waves, sound may skip when radio

waves are obstructed. This is a characteristic

of radio waves and is not malfunction.

• As the S-AIR product(s) transmits sound by

radio waves, equipment that generates

electromagnetic energy, such as a

microwave oven, may prevent sound

transmission.

• As the S-AIR function uses the radio waves

that share the same frequency as other

wireless systems, such as wireless LAN or

Bluetooth devices, interference or poor

transmission may result. In this case, take

the following steps:

– Avoid placing the S-AIR product(s) near

other wireless systems.

– Avoid using the S-Air product(s) and the

other wireless systems spontaneously.

– The transmission may be improved by

changing the transmission channel

(frequency) of the other wireless

system(s). For details, refer to the

operating instructions of the other wireless

system(s).

• The transmission distance differs depending

on the usage environment. Find a location

where transmission between the S-AIR main

unit and sub unit is most effective, and

install the S-AIR main unit and sub unit

there.

• Place the S-AIR product(s) on the stable

surface off the floor.

• Poor transmission may occur and the

transmission distance may be too short if the

following conditions exist:

– There is a wall/floor made of reinforced

concrete or stone between the S-AIR

product(s).

– There is an iron divider/door or furniture/

electric product made of fireproof glass,

metal, etc., between the S-AIR product(s).

If you have any questions or problems

concerning your receiver, please consult your

nearest Sony dealer.

Additional Information

Troubleshooting

If you experience any of the following

difficulties while using the receiver, use this

troubleshooting guide to help you remedy the

problem.

There is no sound, no matter which

component is selected, or only a very

low-level sound is heard.

• Check that the speakers and components

are connected correctly and securely.

• Check that all speaker cords are connected

correctly.

• Check that both the receiver and all

components are turned on.

• Check that MASTER VOLUME is not set

to “VOL MIN”.

• Check that the SPEAKERS is not set to

“SPK OFF” (page 34).

• Check that headphones are not connected

to the receiver or S-AIR surround

amplifier.

• Press MUTING (RM-AAP049 only) or

(RM-AAP050 only) on the remote to

cancel the muting function.

• Check that you have selected the correct

component with the input buttons (page

43).

• The protective device on the receiver has

been activated. Turn off the receiver,

eliminate the short-circuit problem, and

turn on the power again.

There is no sound from a specific

component.

• Check that the component is connected

correctly to the audio input jacks for that

component.

• Check that the cord(s) used for the

connection is (are) fully inserted into the

jacks on both the receiver and the

component.

There is no sound from one of the front

speakers.

• Connect a pair of headphones to the

PHONES jack to verify that sound is

output from the headphones. If only one

channel is output from the headphones, the

component may not be connected to the

receiver correctly. Check that all the cords

are fully inserted into the jacks on both the

receiver and the component. If both

channels are output from the headphones,

the front speaker may not be connected to

the receiver correctly. Check the

connection of the front speaker which is

not outputting any sound.

• Make sure you have connected to both the

L and R jacks of an analog component, and

not only to either the L or R jack. Use an

audio cord (not supplied).

There is no sound from analog 2

channel sources.

• Check that the INPUT MODE is not set to

“AUTO” (page 69) and the DIGITAL

connection is not made for the selected

input.

• Check that the INPUT MODE is not set to

“AUTO” (page 69) and the “A. ASSIGN”

function is not used to reassign the audio

input of another source to the selected

input (page 69).

There is no sound from digital sources

(from COAXIAL or OPTICAL input jack).

• Check that the INPUT MODE is not set to

“ANALOG” (page 69).

• Check that the Analog Direct is not

selected.

• Check that the “A. ASSIGN” function is

not used to reassign the audio input of

another source to the selected input (page

69).

• Set “ARC” to “ARC OFF” when no sound

is output from TV OPTICAL IN jack

during TV input (page 60).

Audio

continued

The left and right sounds are

unbalanced or reversed.

• Check that the speakers and components

are connected correctly and securely.

• Adjust the level parameters using the

LEVEL menu.

There is severe hum or noise.

• Check that the speakers and components

are connected securely.

• Check that the connecting cords are away

from a transformer or motor, and at least

3 meters (10 feet) away from a TV set or

fluorescent light.

• Move your audio components away from

the TV.

• The plugs and jacks are dirty. Wipe them

with a cloth slightly moistened with

alcohol.

There is no sound, or only a very low-

level sound is heard from the center/

surround/surround back/front high

speakers.

• Select a CINEMA STUDIO EX mode

(page 51).

• Check that the speaker settings are

appropriate using the AUTO CAL menu

or “SP PATTERN” in the SPEAKER

menu. Then check that sound is output

from each speaker correctly, using “TEST

TONE” in the LEVEL menu.

• Adjust the speaker level (page 42).

There is no sound from the subwoofer.

• Check that the subwoofer is connected

correctly and securely.

• Make sure you have turned on your

subwoofer.

• Depending on the selected sound field, no

sound output from the subwoofer.

• When all speakers are set to “LARGE”

and “NEO6 CIN” or “NEO6 MUS” is

selected, there is no sound from the

subwoofer.

• Check “SP PATTERN” setting (page 78).

The surround effect cannot be

obtained.

• Make sure you have selected the sound

field for movie or music (page 51 or 52).

• Sound fields do not function for signals

with a sampling frequency of more than

48 kHz.

Dolby Digital or DTS multi channel

sound is not reproduced.

• Check that the DVD, etc. you are playing

is recorded in Dolby Digital or DTS

format.

• When connecting the DVD player, etc., to

the digital input jacks of this receiver,

check the audio setting (the settings for the

audio output) of the connected component.

For example, when connecting the

“PlayStation 3”, set the BD/DVD audio

output format to “Bitstream” on the

“PlayStation 3”.

• Set “AUDIO OUT” to “AMP” in the

HDMI menu.

Recording cannot be carried out.

• Check that the components are connected

correctly.

• Select the source component using the

input buttons (page 43).

There is no sound from the component

connected to the DIGITAL MEDIA

PORT adapter.

• Adjust the volume of this receiver.

• The DIGITAL MEDIA PORT adapter

and/or component is not connected

correctly. Turn off the receiver, then

reconnect the DIGITAL MEDIA PORT

adapter and/or component.

• Check the DIGITAL MEDIA PORT

adapter and/or component device to make

sure it supports this receiver.

Additional Information

There is no picture or an unclear

picture appears on the TV screen or

monitor.

• Select the appropriate input using the input

buttons.

• Set your TV to the appropriate input mode.

• Move your audio components away from

the TV.

• Assign the component video input

correctly.

• Depending on the DIGITAL MEDIA

PORT adapter, video output may not be

possible.

Recording cannot be carried out.

• Check that the components are connected

correctly.

• Select the source component using the

input buttons (page 43).

The FM reception is poor.

• Use a 75-ohm coaxial cable (not supplied)

to connect the receiver to an outdoor FM

antenna (aerial) as shown below. If you

connect the receiver to an outdoor antenna

(aerial), ground it against lightning. To

prevent a gas explosion, do not connect the

ground (earth) wire to a gas pipe.

Radio stations cannot be tuned in.

• Check that the antennas (aerials) are

connected securely. Adjust the antennas

(aerials) and connect an external antenna

(aerial), if necessary.

• The signal strength of the stations is too

weak (when tuning in with automatic

tuning). Use direct tuning.

• Make sure you set the tuning interval

correctly (when tuning in AM stations

with direct tuning).

• No stations have been preset or the preset

stations have been cleared (when tuning

by scanning preset stations). Preset the

stations (page 48).

• Press AMP, then press DISPLAY

repeatedly on the remote so that the

frequency appears on the display.

RDS does not work.*

• Make sure that you are tuned to an FM

RDS station.

• Select a stronger FM station.

The RDS information that you want

does not appear.*

• Contact the radio station and find out

whether they actually provide the service

in question. If so, the service may be

temporarily out of order.

* Models of area code CEL, CEK, AU1 only.

Video

Tuner

ANTENNA

Receiver

To ground

Ground (earth)

wire (not

supplied)

Outdoor FM antenna (aerial)

The source sound input to the HDMI

jack is not output from the receiver or

the TV speaker.

• Check the HDMI connection (page 24).

• You cannot listen to the Super Audio CD

by connecting HDMI.

• Depending on the playback component,

you may need to set up the component.

Refer to the operating instructions

supplied with each component.

• Be sure to use a High Speed HDMI cable

when you view images or listen to sound

during Deep Colour (Deep Color)

transmission.

The source image input to the HDMI

jack is not output from the TV.

• Check the HDMI connection (page 24).

• Depending on the playback component,

you may need to set up the component.

Refer to the operating instructions

supplied with each component.

• Be sure to use a High Speed HDMI cable

when you view images or listen to sound

during Deep Colour (Deep Color)

transmission.

The Control for HDMI function does not

work.

• Check the HDMI connection (page 24).

• Make sure “CTRL: HDMI” is set to

“CTRL ON” in the HDMI menu.

• Make sure the connected component is

compatible with the Control for HDMI

function.

• Check the Control for HDMI settings on

the connected component. Refer to the

operating instructions of the connected

component.

• Repeat the procedures of “Preparing for

the “BRAVIA” Sync” if you change the

HDMI connection, connect/disconnect the

AC power cord (mains lead), or when

there is a power failure (page 56).

No sound is output from the receiver

and TV speaker while using the System

Audio Control function.

• Make sure the TV is compatible with the

System Audio Control function.

• If the TV does not have System Audio

Control function, set the “AUDIO OUT”

settings in HDMI menu to

– “TV+AMP” if you want to listen to the

sound from the TV speaker and receiver.

– “AMP” if you want to listen to the sound

from the receiver.

• When you connect the receiver to a video

component (projector, etc.), sound may

not be output from the receiver. In this

case, select “AMP”.

• If you cannot listen to the sound of a

component connected to the receiver

– Change the input of the receiver to

HDMI when you want to watch a

program on a component connected via

HDMI connection to the receiver.

– Change the TV channel when you want

to watch a TV broadcast.

– Select the component or input you want

to watch when you watch a program on

the component connected to the TV.

Refer to the operating instructions of the

TV on this operation.

When the receiver is in standby mode,

there is no image or sound output from

the TV.

• When the receiver is in standby mode,

image and sound are output from the

HDMI component selected the last time

you turned off the receiver. If you are

enjoying other component, play the

component and perform the One-Touch

Play operation, or turn on the receiver to

select the HDMI component you want to

enjoy.

• Make sure “PASS THRU” is set to “ON”

in the HDMI menu if you connect

components not compatible with the

“BRAVIA” Sync to the receiver (page 56).

HDMI

Additional Information

S-AIR connection is not established

(sound transmission is not

established), e.g., the indicator of the

S-AIR sub unit turns off, flashes, or

turns red.

• If you use another S-AIR main unit, place

it more than 8 meters (26 feet) away from

this S-AIR main unit.

• Confirm the S-AIR IDs of the S-AIR main

unit and S-AIR sub unit (page 62).

• Another S-AIR sub unit is paired to the

S-AIR main unit. Pair the desired S-AIR

sub unit with the S-AIR main unit (page

63).

• Place the S-AIR main unit and S-AIR sub

unit separately from other wireless

devices.

• Avoid using any other wireless devices.

• The S-AIR sub unit is turned off. Make

sure the AC power cord (mains lead) is

connected and turn on the S-AIR sub unit.

No sound is heard from the S-AIR

receiver.

• Check that the components are connected

to the receiver.

No sound is heard from the S-AIR

product.

• If you use another S-AIR main unit, place

it more than 8 meters (26 feet) away from

this S-AIR main unit.

• Confirm the S-AIR IDs of the S-AIR main

unit and S-AIR sub unit (page 62).

• Confirm the pairing setting (page 63).

• Place the S-AIR main unit and S-AIR sub

unit closer to each other.

• Avoid use of equipment that generates

electromagnetic energy, such as a

microwave oven.

• Place the S-AIR main unit and S-AIR sub

unit separately from other wireless

devices.

• Avoid using any other wireless devices.

• Change the “RF CHANGE” setting (page

66).

• Change the S-AIR ID settings of the

S-AIR main unit and S-AIR sub unit.

• Turn off the system and S-AIR sub unit,

then turn on them.

• Check that headphones are not connected

to the S-AIR sub unit.

There is noise or the sound skips.

• If you use another S-AIR main unit, place

it more than 8 meters (26 feet) away from

this S-AIR main unit.

• Place the S-AIR main unit and S-AIR sub

unit closer to each other.

• Avoid use of equipment that generates

electromagnetic energy, such as a

microwave oven.

• Place the S-AIR main unit and S-AIR sub

unit separately from other wireless

devices.

• Avoid using any other wireless devices.

• Change the “RF CHANGE” setting (page

66).

• Change the S-AIR ID settings of the

S-AIR main unit and S-AIR sub unit.

S-AIR function

continued

100

“HP NO LINK” and “VOL MIN” appear

alternately on the display and the

volume of the receiver becomes

minimum.

• Volume becomes minimum when you turn

off the surround amplifier with

headphones connected or if the radio

reception is poor. In these cases, check the

radio reception and adjust the volume level

to restore sound from the headphones.

The remote does not function.

• Point the remote at the remote sensor on

the receiver.

• Remove any obstacles in the path between

the remote and the receiver.

• Replace all the batteries in the remote with

new ones, if they are weak.

• Make sure you select the correct input on

the remote.

• When you operate a programmed non-

Sony component, the remote may not

function properly depending on the model

and the maker of the component.

The receiver is turned off

automatically.

• The “AUTO STBY” function is working

(page 85).

If there is a malfunction, the display shows a

message. You can check the condition of the

system by the message. See the following table

to solve the problem. If any problem persists,

consult your nearest Sony dealer.

If an error message appears while you perform

Auto Calibration, see “When error codes

appear” (page 39) to solve the problem.

PROTECTOR

Irregular current is output to the speakers, or

the upper panel of the receiver is covered

with something. The receiver will

automatically turn off after a few seconds.

Check the speaker connection and turn on

the power again.

Clearing the receiver’s memory may remedy

the problem (page 34). However, note that all

memorized settings will be reset to their initial

settings and you will have to readjust all

settings on the receiver.

Consult your nearest Sony dealer. Note that if

service personnel changes some parts during

repair, these parts may be retained.

In the event of a problem with S-AIR function,

have a Sony dealer check the entire system

together (S-AIR main unit and S-AIR sub

unit).

Remote commander

Others

Error messages

If you are unable to remedy the

problem using the

troubleshooting guide

If the problem persist

101

Additional Information

Specifications

AUDIO POWER

SPECIFICATIONS

POWER OUTPUT AND TOTAL

HARMONIC DISTORTION:

(Models of area code U2 only)

With 8 ohm loads, both channels driven, from

20 – 20,000 Hz; rated 100 watts per channel

minimum RMS power, with no more than

0.09% total harmonic distortion from 250

milliwatts to rated output.

Amplifier section

Models of area code CEL, CEK, AU1

Stereo Mode Output Power

(8 ohms, 1 kHz, THD 1%)

100 W + 100 W

Surround Mode Output Power

(8 ohms, 1 kHz, THD 10%)

140 W per channel

Models of area code U2

Minimum RMS Output Power

(8 ohms, 20 Hz – 20 kHz, THD 0.09%)

100 W + 100 W

Stereo Mode Output Power

(8 ohms, 1 kHz, THD 1%)

110 W + 110 W

Surround Mode Output Power

(8 ohms, 1 kHz, THD 10%)

150 W per channel

Measured under the following conditions:

Reference power output for front, center,

surround, surround back and front high speakers.

Depending on the sound field settings and the

source, there may be no sound output.

Reference sections for clearing

the receiver’s memory

To clear See

All memorized settings page 34

Customized sound fields page 55

Area code Power requirements

CEL, CEK, AU1 230 V AC, 50 Hz

U2 120 V AC, 60 Hz

continued

102

Frequency response

Analog 10 Hz – 70 kHz,

+0.5/–2 dB (with sound

field and equalizer

bypassed)

Input

Analog Sensitivity: 500 mV/

50 kohms

S/N

: 96 dB

(A, 500 mV

)

Digital (Coaxial) Impedance: 75 ohms

S/N: 100 dB

(A, 20 kHz LPF)

Digital (Optical) S/N: 100 dB

(A, 20 kHz LPF)

Output (analog)

AUDIO OUT Voltage: 500 mV/

10 kohms

SUBWOOFER Voltage: 2 V/1 kohm

Equalizer

Gain levels ±10 dB, 1 dB step

INPUT SHORT (with sound field and equalizer

bypassed).

Weighted network, input level.

FM tuner section

Tuning range 87.5 MHz – 108.0 MHz

Antenna (aerial) FM wire antenna (aerial)

Antenna (aerial) terminals

75 ohms, unbalanced

Intermediate frequency

10.7 MHz

AM tuner section

Tuning range

Antenna (aerial) Loop antenna (aerial)

Intermediate frequency

450 kHz

Video section

Inputs/Outputs

Video: 1 Vp-p, 75 ohms

COMPONENT VIDEO:

Y: 1 Vp-p, 75 ohms

B/CB: 0.7 Vp-p, 75 ohms

R/CR: 0.7 Vp-p, 75 ohms

80 MHz HD Pass Through

General

Power requirements

Power output (DIGITAL MEDIA PORT)

DC OUT: 5V, 0.7 A MAX

Power consumption

Dimensions (width/height/depth) (Approx.)

430 mm × 157.5 mm ×

322 mm (17 in × 6 1/4 in ×

12 3/4 in) including

projecting parts and

controls

Mass (Approx.)

Models of area code CEL, CEK, AU1

8.2 kg (18 lb 2 oz)

Models of area code U2

7.9 kg (17 lb 7 oz)

Design and specifications are subject to

change without notice.

Area code Tuning scale

10 kHz step 9 kHz step

CEL, CEK, AU1 – 531 kHz –

1,602 kHz

U2 530 kHz –

1,710 kHz

531 kHz –

1,710 kHz

Area code Power requirements

CEL, CEK 230 V AC, 50/60 Hz

U2 120 V AC, 60 Hz

AU1 230 V AC, 50 Hz

Area code Power consumption

CEL, CEK, U2, AU1 240 W

For details on the area code of the

component you are using, see page 5.

• Standby power consumption: 0.3 W

• Halogenated flame retardants are not used

in the certain printed wiring boards.

103

Additional Information

Index

Numerics

2 Channel Stereo 51

5.1 channel 17

A.F.D. mode 51

Analog Direct 51

Audio Return Channel

(ARC) 60

AUTO CALIBRATION 35

BI-AMP 80

Bi-amplifier connection 71

Blu-ray disc player

connecting 27

Cable TV tuner

connecting 29

Camcorder

connecting 30

Clear

remote 90

DIGITAL MEDIA PORT

connecting 23

enjoying 71

Dolby Digital 91

Dolby Digital EX 54

DTS 92

DVD player

connecting 28

DVD recorder

connecting 30

Error messages 100

HDMI

connecting 25

HDMI Signal Pass Through

Initial setup 34

INPUT MODE 69

AUDIO 82

AUTO CAL 40

EQ 81

HDMI 83

LEVEL 77

S-AIR 85

SPEAKER 78

SURROUND 81

SYSTEM 85

TUNER 81

VIDEO 83

Movie mode 51

Music mode 52

Muting 43

Naming 41, 44, 49

NIGHT MODE 55

One-Touch Play 57

PAIRING 63

“PlayStation 3”

connecting 25

RDS 50

Recording

onto a CD-R 45

onto a recording media

Remote commander 12

S-AIR 60

Satellite tuner

connecting 29

Selecting speaker system 34

Sleep Timer 45

Sound fields

resetting 55

selecting 51

Speakers

connecting 19

installing 17

System Audio Control 58

System Power Off 59

Test Tone 42

Theatre/Theater Mode Sync

Tuner

connecting 32

Tuning

automatically 47

directly 47

to preset stations 49

connecting 21

VCR

connecting 30

Video game

connecting 30

Sony Corporation Printed in Malaysia

(1)

Sony STR-DH810 Audio Video Receiver

Product's Documents

User Manual

Specifications

Sony STR-DH810 Questions and Answers

Related Products

Sony STR-DH800 Audio Video Receiver

Sony STR-DH700 Audio/video Receiver

Sony IFT-R10 Audio/Video Infrared Receiver

Sony STR-D665 AV Receiver Audio/Video Home Theater Receiver, AM/FM Stereo

Sony STR-DG710 Channel Audio/video Receiver
