HTS3563
HTS3583
HTS3593
Register your product and get support at
www.philips.com/welcome
Brugervejledning
Gebruiksaanwijzing
Manuale utente
Manual do utilizador
Käyttöopas
Kullanım kılavuzu
User manual
Benutzerhandbuch
Mode d'emploi
Brukerhåndbok
Manual del usuario
Användarhandbok
Εγχειρίδιο χρήσης
1
English
EN
Contents
1 Help and support 2
Use onscreen Help (user manual) 2
2 Important 3
Safety 3
Care for your product 4
Care of the environment 4
3D health warning 4
3 Your home theater 5
Remote control 5
Main unit 7
Connectors 7
4 Connect and set up 8
Connect speakers 8
Connect to TV 9
Connect audio from TV and other devices 10
Set up speakers 11
Set up EasyLink (HDMI-CEC control) 12
Connect and set up a home network 13
5 Use your home theater 14
Access the home menu 14
Discs 14
Data les 16
USB storage devices 17
Audio, video, and picture options 17
Radio 18
MP3 player 19
iPod or iPhone 19
Smartphone control 20
Browse Net TV 21
Browse PC through DLNA 22
Choose sound 22
6 Change settings 23
Language settings 23
Picture and video settings 24
Audio settings 24
Parental control settings 24
Display settings 24
Energy saving settings 25
Speaker settings 25
Restore default settings 25
7 Update software 26
Check software version 26
Update software through USB 26
Update software through the Internet 27
Update the onscreen help 27
8 Product specications 28
9 Troubleshooting 31
10 Notice 33
Open source software 33
RMVB end user agreement (Asia Pacic
and China only) 33
Trademarks 33
11 Language code 35
12 Index 36
2 EN
1 Help and support
Philips provides extensive online support. Visit our
website at www.philips.com/support to:
• download the complete user manual
• print the quick start guide
• watch video tutorials (available only for
selected models)
• nd answers to frequently answered
questions (FAQs)
• email us a question
• chat with our support representative.
Follow the instructions on the website to select
your language, and then enter your product model
number.
Alternatively, you can contact Philips Consumer
Care in your country. Before you contact Philips,
note down the model number and serial number
of your product. You can nd this information on
the back or bottom of your product.
Use onscreen Help (user
manual)
For easy access, an onscreen help is stored on
your home theater.
The onscreen help has two panels.
• The left panel contains the Contents and
Index. Navigate the Contents or Index to
select a page. The legends used to display the
Contents entries are as follows:
• : Press OK to expand the sub entries.
• : Press OK to collapse the sub entries,
or press Navigation buttons (up/down)
to select a page.
• The right panel contains the content of each
page. Select Related topics for additional help
on the content.
Use the home theater remote control to select
and navigate the onscreen help.
Button Action
HELP Access or exit onscreen help.
OK Display the selected page, or
expand topics in Contents.
Navigation
buttons
Up: Scroll up or move to the
previous page.
Down: Scroll down or move to the
next page.
Right: Navigate to the right panel or
next index entry.
Left: Navigate to the left panel or
previous index entry.
BACK
Move up in the Contents or Index.
From the right panel, move to the
Contents on the left panel.
(Previous)
Display the last viewed page in
history.
(Next)
Display the next page from history.
3
English
EN
2 Important
Read and understand all instructions before you
use your product. If damage is caused by failure to
follow instructions, the warranty does not apply.
Safety
Risk of electric shock or re!
• Never expose the product and accessories to
rain or water. Never place liquid containers,
such as vases, near the product. If liquids are
spilt on or into the product, disconnect it
from the power outlet immediately. Contact
Philips Consumer Care to have the product
checked before use.
• Never place the product and accessories
near naked ames or other heat sources,
including direct sunlight.
• Never insert objects into the ventilation slots
or other openings on the product.
• Where the mains plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
• Disconnect the product from the power
outlet before lightning storms.
• When you disconnect the power cord, always
pull the plug, never the cable.
Risk of short circuit or re!
• Before you connect the product to the
power outlet, ensure that the power voltage
matches the value printed on the back or
bottom of the product. Never connect the
product to the power outlet if the voltage is
different.
Risk of injury or damage to the home theater!
• For wall-mountable products, use only the
supplied wall mount bracket. Secure the
wall mount to a wall that can support the
combined weight of the product and the
wall mount. Koninklijke Philips Electronics
N.V. bears no responsibility for improper wall
mounting that results in accident, injury or
damage.
• For speakers with stands, use only the
supplied stands. Secure the stands to the
speakers tightly. Place the assembled stands
on at, level surfaces that can support the
combined weight of the speaker and stand.
• Never place the product or any objects
on power cords or on other electrical
equipment.
• If the product is transported in temperatures
below 5°C, unpack the product and wait until
its temperature matches room temperature
before connecting it to the power outlet.
• Visible and invisible laser radiation when
open. Avoid exposure to beam.
• Do not touch the disc optical lens inside the
disc compartment.
• Parts of this product can be made of glass.
Handle with care to avoid injury and damage.
Risk of overheating!
• Never install this product in a conned space.
Always leave a space of at least four inches
around the product for ventilation. Ensure
curtains or other objects never cover the
ventilation slots on the product.
Risk of contamination!
• Do not mix batteries (old and new or carbon
and alkaine, etc.).
• Danger of explosion if batteries are
incorrectly replaced. Replace only with the
same or equivalent type.
• Remove batteries if they are exhausted or if
the remote control is not to be used for a
long time.
• Batteries contain chemical substances, they
should be disposed of properly.
Risk of swallowing batteries!
• The product/remote control may contain
a coin/button type battery, which can be
swallowed. Keep the battery out of reach of
children at all times! If swallowed, the battery
can cause serious injury or death. Severe
internal burns can occur within two hours of
ingestion.
• If you suspect that a battery has been
swallowed or placed inside any part of the
body, seek immediate medical attention.
• When you change the batteries, always
keep all new and used batteries out of
reach of children. Ensure that the battery
compartment is completely secure after you
replace the battery.
• If the battery compartment cannot be
completely secured, discontinue use of the
product. Keep out of reach of children and
contact the manufacturer.
4 EN
Care for your product
• Do not insert any objects other than discs
into the disc compartment.
• Do not insert warped or cracked discs into
the disc compartment.
• Remove discs from the disc compartment
if you are not using the product for an
extended period of time.
• Use only microber cloth to clean the
product.
Care of the environment
Your product is designed and manufactured with
high quality materials and components, which can
be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC. Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and do not
dispose of your old products with your normal
household waste.
Correct disposal of your old product helps to
prevent potential negative consequences for the
environment and human health.
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot be
disposed with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries because correct
disposal helps to prevent negative consequences
for the environmental and human health.
3D health warning
If you or your family has a history of epilepsy
or photosensitive seizures, consult a medical
professional before exposing yourself to ashing
light sources, rapid image sequences or 3D
viewing.
To avoid discomfort such as dizziness, headache or
disorientation, we recommend not watching 3D
for extended periods of time. If you experience
any discomfort, stop watching 3D and do not
immediately engage in any potentially hazardous
activity (for example driving a car) until your
symptoms have disappeared. If symptoms persist,
do not resume watching 3D without consulting a
medical professional rst.
Parents should monitor their children during 3D
viewing and ensure they do not experience any
discomfort as mentioned above. Watching 3D is
not recommended for children under six years of
age as their visual system is not fully developed yet.
5
English
EN
3 Your home theater
Congratulations on your purchase, and welcome
to Philips! To fully benet from the support that
Philips offers, register your product at www.philips.
com/welcome.
Remote control
This section includes an overview of the remote
control.
a (Standby-On)
• Switch the home theater on or to
standby.
• When EasyLink is enabled, press and hold
for at least three seconds to switch all
connected HDMI CEC compliant devices
to standby.
b (Home)
Access the home menu.
c Source buttons
• DISC/POP-UP MENU: Access or exit the
disc menu when you play a disc.
• RADIO: Switch to FM radio.
• AUDIO SOURCE: Select an audio input
source.
d TOP MENU
Access the main menu of a video disc.
a BACK
• Return to a previous menu screen.
• In radio mode, press and hold to erase
the current preset radio stations.
b Navigation buttons
• Navigate menus.
• In radio mode, press left or right to start
auto search.
• In radio mode, press up or down to tune
the radio frequency.
c OPTIONS
• Access more play options while playing a
disc or a USB storage device.
• In radio mode, set a radio station.
d OK
Conrm an entry or selection.
6 EN
a (Stop) / (Eject/Open/Close)
• Stop play.
• Press and hold for three seconds to open
or close the disc compartment, or eject
the disc.
b (Play)
Start or resume play.
c / (Previous/Next)
• Skip to the previous or next track,
chapter or le.
• In radio mode, select a preset radio
station.
d (Pause)
Pause play.
e / (Fast Backward/Fast Forward)
Search backwards or forward. Press
repeatedly to change the search speed.
a +/- (Volume)
Increase or decrease volume.
b SOUND SETTINGS
Access or exit sound options.
c (Mute)
Mute or restore volume.
d AUDIO
Select an audio language or channel.
a Alphanumeric buttons
Enter values or letters (using SMS style entry).
b REPEAT
Select or turn off repeat mode.
c DOCK for iPod
Switch to Philips dock for iPod or iPhone.
d SUBTITLE
Select subtitle language for video.
e Color buttons
Select tasks or options for Blu-ray discs.
f HELP
Access the onscreen help.
7
English
EN
Main unit
This section includes an overview of the main unit.
a Disc compartment
b Display panel
c (Open/Close)
Open or close the disc compartment, or
eject the disc.
d (Play/Pause)
Start, pause or resume play.
e SOURCE
Select an audio or video source for the home
theater.
f (Standby-On)
Switch the home theater on or to standby.
Connectors
This section includes an overview of the
connectors available on your home theater.
Front connectors
a (USB)
Audio, video or picture input from a USB
storage device.
b MUSIC iLINK
Audio input from an MP3 player.
Rear left
a AC MAINS~
Connect to the power supply.
b SPEAKERS
Connect to the supplied speakers and subwoofer.
Rear center
a AUDIO IN-AUX
Connect to an analog audio output on the TV
or an analog device.
b ANTENNA FM 75
Signal input from an antenna, cable or satellite.
c DOCK for iPod
Connect to a Philips dock for iPod or iPhone.
(Model: Philips DCK306x)
d VIDEO OUT-VIDEO
Connect to the composite video input on the TV.
e DIGITAL IN-COAXIAL
Connect to a coaxial audio output on the TV
or a digital device.
f DIGITAL IN-OPTICAL
Connect to an optical audio output on the
TV or a digital device.
8 EN
Rear right
a HDMI OUT (ARC)
Connect to the HDMI input on the TV.
b LAN
Connect to the LAN input on a broadband
modem or router.
c SD CARD (Not available in China)
Slot for SD card. The SD card is used to rent
online videos and access BD-Live.
4 Connect and set up
This section helps you connect your home theater
to a TV and other devices, and then set it up.
For information about the basic connections of
your home theater and accessories, see the quick
start guide. For a comprehensive interactive guide,
visit www.connectivityguide.philips.com.
Note
• For identication and supply ratings, see the type
plate at the back or bottom of the product.
• Before you make or change any connections,
make sure that all devices are disconnected from
the power outlet.
Connect speakers
The speaker cables are color-coded for easy
connection. To connect a speaker to your home
theater, match the color on the speaker cable to
the color on the connector.
Speaker position plays a critical role in setting up
a surround sound effect. For best effect, position
all the speakers towards the seating position and
place them close to your ear level (seated).
9
English
EN
Note
• Surround sound depends on factors such as
room shape and size, type of wall and ceiling,
windows and reective surfaces, and speaker
acoustics. Experiment with the speaker positions
to nd the optimum setting for you.
Follow these general guidelines for speakers
placement.
1 Seating position:
This is the center of your listening area.
2 FRONT CENTER (front center) speaker:
Place the center speaker directly in front of
the seating position, either above or below
your TV.
3 FRONT LEFT (front left) and FRONT
RIGHT (front right) speakers:
Place the left and right speakers in the front,
and at equal distance from the center speaker.
Make sure that the left, right, and the center
speakers are at equal distance from your
seating position.
4 REAR LEFT (rear left) and REAR RIGHT
(rear right) speakers:
Place the rear surround speakers to the left
and right side of your seating position, either
in line with it or slightly behind it.
5 SUBWOOFER (subwoofer):
Place the subwoofer at least one meter
to the left or right of the TV. Leave about
10-centimeter clearance from the wall.
Connect to TV
Connect your home theater to a TV to watch
videos. You can listen to the TV audio through your
home theater speakers.
Use the best quality connection available on your
home theater and TV.
Option 1: Connect to TV through HDMI
(ARC)
Best quality video
Your home theater supports HDMI version
1.4 - Audio Return Channel (ARC). If your TV is
HDMI ARC compliant, you can hear the TV audio
through your home theater by using a single HDMI
cable.
1 Using a High Speed HDMI cable, connect
the HDMI OUT (ARC) connector on your
home theater to the HDMI ARC connector
on the TV.
• The HDMI ARC connector on the TV
might be labeled differently. For details,
see the TV user manual.
2 On your TV, turn on HDMI-CEC operations.
For details, see the TV user manual.
• If you cannot hear the TV audio through
your home theater, set up the audio
manually (see 'Set up the audio' on page
12).
TV
10 EN
Option 2: Connect to TV through
standard HDMI
Best quality video
If your TV is not HDMI ARC compliant, connect
your home theater to the TV through a standard
HDMI connection.
1 Using a High Speed HDMI cable, connect the
HDMI OUT (ARC) connector on your home
theater to the HDMI connector on the TV.
2 Connect an audio cable to hear the TV audio
through your home theater (see 'Connect
audio from TV and other devices' on page
10).
3 On your TV, turn on HDMI-CEC operations.
For details, see the TV user manual.
• If you cannot hear the TV audio through
your home theater, set up the audio
manually (see 'Set up the audio' on page
12).
Note
• If your TV has a DVI connector, you can use an
HDMI/DVI adapter to connect to TV. However,
some of the features may not be available.
TV
Option 3: Connect to the TV through
composite video
Basic quality video
If your TV does not have HDMI connectors, use
a composite video connection. A composite
connection does not support high-denition video.
1 Using a composite video cable, connect the
VIDEO connector on your home theater to
the VIDEO IN connector on the TV.
• The composite video connector might
be labeled AV IN, COMPOSITE, or
BASEBAND.
2 Connect an audio cable to hear the TV audio
through your home theater (see 'Connect
audio from TV and other devices' on page
10).
3 When you watch TV programs, press
SOURCE on your home theater repeatedly
to select the correct audio input.
4 When you watch videos, switch your TV to
the correct video input. For details, see the
TV user manual.
Connect audio from TV and
other devices
Play audio from TV or other devices through your
home theater speakers.
Use the best quality connection available on your
TV, home theater, and other devices.
Note
• The audio connections in this user manual
are only recommendations. You can use other
connections too.
• When your home theater and TV are connected
through HDMI ARC, an audio connection is not
required.
TV
11
English
EN
Option 1: Connect audio through a digital
optical cable
Best quality audio
1 Using an optical cable, connect the OPTICAL
connector on your home theater to the
OPTICAL OUT connector on the TV or
other device.
• The digital optical connector might be
labeled SPDIF or SPDIF OUT.
Option 2: Connect audio through a digital
coaxial cable
Good quality audio
1 Using a coaxial cable, connect the COAXIAL
connector on your home theater to the
COAXIAL/DIGITAL OUT connector on the
TV or other device.
• The digital coaxial connector might be
labeled DIGITAL AUDIO OUT.
TV
Option 3: Connect audio through analog
audio cables
Basic quality audio
1 Using an analog cable, connect the AUX
connectors on your home theater to the
AUDIO OUT connectors on the TV or other
device.
Set up speakers
Set up the speakers manually to experience
customized surround sound.
Before you start
Make the necessary connections described in the
quick start guide, and then switch the TV to the
correct source for your home theater.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Audio] > [Speaker setup]
4 Enter the distance for each speaker, and
then listen to the test tones and change
the volume. Experiment with the speaker
positions to nd the ideal setting.
VCR
12 EN
Set up EasyLink (HDMI-CEC
control)
This home theater supports Philips EasyLink,
which uses the HDMI-CEC (Consumer Electronics
Control) protocol. EasyLink-compliant devices that
are connected through HDMI can be controlled
by a single remote control.
Note
• Depending on the manufacturer, HDMI-CEC is
known by many names. For information on your
device, see the user manual of the device.
• Philips does not guarantee 100% interoperability
with all HDMI-CEC devices.
Before you start
• Connect your home theater to the HDMI-
CEC compliant device through HDMI
connection.
• Make the necessary connections described in
the quick start guide, and then switch the TV
to the correct source for your home theater.
Enable EasyLink
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [EasyLink] > [EasyLink] > [On] .
4 On your TV and other connected devices,
turn on HDMI-CEC control. For details, see
the user manual of the TV or other devices.
• On your TV, set the audio output to
'Amplier' (instead of TV speakers). For
details, see the TV user manual.
EasyLink controls
With EasyLink, you can control your home theater,
TV, and other connected HDMI-CEC compliant
devices with a single remote control.
• [One Touch Play] (One-touch play): When a
video disc is in the disc compartment, press
(Play) to wake up the TV from standby, and
then play a disc.
• [One Touch Standby] (One-touch standby):
If one-touch standby is enabled, your home
theater can switch to standby with the remote
control of the TV or other HDMI-CEC devices.
• [System Audio Control] (System audio
control): If system audio control is enabled,
the audio of the connected device is output
through your home theater speakers
automatically when you play the device.
• [Audio Input Mapping] (Audio input
mapping):If system audio control does not
work, map the connected device to the
correct audio input connector on your home
theater (see 'Set up the audio' on page 12).
Note
• To change the EasyLink control settings, press
(Home), select [Setup] > [EasyLink].
Set up the audio
If you cannot hear the audio output of a
connected device through your home theater
speakers, check that you have enabled Easylink on
all the devices (see 'Enable EasyLink' on page 12).
Then, set up the EasyLink audio control.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [EasyLink] > [System Audio Control]
> [On].
• To play the audio from the TV speakers,
select [Off], and skip the following steps.
4 Select [EasyLink] > [Audio Input Mapping].
5 Follow the onscreen instructions to map the
connected device to the audio inputs on your
home theater.
• If you connect your home theater to the
TV through an HDMI ARC connection,
make sure that the TV audio is mapped
to the ARC input on your home theater.
13
English
EN
Connect and set up a home
network
Connect your home theater to a network router
through wired or wireless network connection,
and enjoy:
• Streamed multimedia content (see 'Browse
PC through DLNA' on page 22)
• Smartphone control
• Net TV (Not available in China) (see 'Browse
Net TV' on page 21)
• Software update (see 'Update software
through the Internet' on page 27)
Caution
• Familiarize yourself with the network router,
media server software and networking
principles. If necessary, read documentation that
accompanies the network components. Philips is
not responsible for lost, damaged, or corrupt data.
Before you start
• For Net TV and software updates, make sure
that the network router has access to the
Internet with high-speed connection and is not
restricted by rewalls or other security systems.
• Make the necessary connections described in
the quick start guide, and then switch the TV
to the correct source for your home theater.
Set up the wired network
What you need
• A network cable (RJ45 straight cable).
• A network router (with DHCP enabled).
1 Using a network cable, connect the LAN
connector on your home theater to the
network router.
2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Network] > [Network installation]
> [Wired (Ethernet)].
5 Follow the onscreen instructions to complete
the setup.
• If connection fails, select [Retry], and
then press OK.
6 Select [Finish], and then press OK to exit.
• To view the network settings, select
[Setup] > [Network] > [View network
settings].
Personalize the network name
Name your home theater to easily identify it on
your home network.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Network] > [Name your Product:].
4 Press the Alphanumeric buttons to enter the
name.
5 Select [Done], and then press OK to exit.
LAN
www
14 EN
5 Use your home
theater
This section helps you use the home theater to
play media from a wide range of sources.
Before you start
• Make the necessary connections described in
the quick start guide and the user manual.
• Complete the rst-time setup. First-time
setup appears when you turn on your home
theater or if you do not complete the setup.
• Switch the TV to the correct source for your
home theater (for example, HDMI, AV IN).
Access the home menu
The home menu provides easy access to
connected devices, setup and other useful features
in your home theater.
1 Press (Home).
» The home menu is displayed.
2 Press the Navigation buttons and OK to
select the following:
• [play Disc]: Start disc play.
• [browse USB]: Access the USB content
browser
• [browse iPod]: Access the iPod or iPhone
content browser.
• [browse Net TV]: Access Net TV.
• [browse PC]: Access the computer
content browser.
• [Setup]: Access menus to change video,
audio and other settings.
• [Help]: Access onscreen user manual.
3 Press (Home) to exit.
Discs
Your home theater can play DVDs, VCDs, CDs,
and Blu-ray discs. It can also play discs that you’ve
made at home, such as CD-R discs of photos and
music.
1 Insert a disc into the home theater.
2 If the disc does not play automatically, press
DISC or select [play Disc] from the home
menu.
3 Use the remote control to control play (see
'Remote control' on page 5).
Note
• To avoid ickering, change the brightness of the
display.
Play buttons
Button Action
Navigation
buttons
Navigate menus.
Up/Down: Rotate the picture
clockwise or counter-clockwise.
OK Conrm an entry or selection.
(Play)
Start or resume play.
Pause play.
Stop play.
/
Skip to the previous or next track,
chapter or le.
/
When a video is paused, search
backwards or forward.
SUBTITLE Select subtitle language for video.
DISC/
POP-UP
MENU
Access or exit the disc menu.
OPTIONS
Access the advanced options when
you play your audio, video, or media
les (see 'Audio, video, and picture
options' on page 17).
15
English
EN
Synchronize picture and sound
If the audio and video are not synchronized, delay
the audio to match the video.
1 Press SOUND SETTINGS.
2 Select AUD SYNC, and then press OK.
3 Press the Navigation buttons (up/down) to
synchronize the audio with the video.
4 Press OK to conrm.
Play Blu-ray 3D disc
Your home theater can play Blu-ray 3D video. Read
the 3D health warning before playing a 3D disc.
What you need
• A 3D TV.
• A pair of 3D glasses that are compatible with
your 3D TV.
• A 3D Blu-ray video
• A high speed HDMI cable (preferably version
1.4)
1 Using the high speed HDMI cable, connect
your home theater to a 3D compatible TV.
2 Make sure that the 3D video setting is
enabled. Press (Home), select [Setup] >
[Video] > [Watch 3D video] > [Auto].
• To play 3D discs in 2D mode, select [Off].
3 Play a Blu-ray 3D disc and put on the 3D glasses.
• During video search and in certain play
modes, the video is displayed in 2D. The
video display returns to 3D when you
resume play.
Bonus View on Blu-ray
On Blu-ray discs that support the Bonus View,
enjoy extra content such as commentaries in a
small screen window. Bonus View is also known as
picture-in-picture.
1 Enable Bonus View in the Blu-ray disc menu.
2 While you play the movie, press
OPTIONS.
» The options menu is displayed.
3 Select [PIP selection] > [PIP].
• Depending on the video, PIP menu [1] or
[2] is displayed.
• To disable Bonus View, select [Off].
4 Select [2nd audio language] or [2nd Subtitle
Language].
5 Select the language, and then press OK.
BD-Live on Blu-ray
Access additional features on the Blu-ray discs with
BD-Live content, such as internet chats with the
director, the latest movie trailers, games, wallpaper,
and ringtones.
BD-Live services and content vary from disc to
disc.
What you need
• Blu-ray disc with BD-Live content.
• Storage device:
• a USB storage device, with at least 1 GB
of memory, or
• an SD memory card of type SDHC Class
6, with at least 8 GB of memory.
1 Connect your home theater to a home
network with Internet access (see 'Connect
and set up a home network' on page 13).
2 Connect a USB storage device or insert a SD
memory card to your home theater.
• If prompted, follow the onscreen
instructions to format the SD memory
card.
3 Press (Home) and select [Setup].
4 Select [Advanced] > [Local storage].
5 Select [USB] or [SD card].
• Use either a USB storage device or SD
memory card to store the downloaded
BD-Live content.
6 Select [Advanced] > [BD-Live security] >
[Off] to enable BD-Live.
• To disable BD-Live, select [On].
7 Select the BD-Live icon in the disc menu, and
then press OK.
» BD-Live starts to load. The loading time
depends on the disc and your internet
connection.
8 Press the Navigation buttons to navigate BD-
Live, and then press OK to select an option.
Note
• To clear the memory on the storage device,
press (Home), select [Setup] > [Advanced]
> [Clear memory].
16 EN
Data les
Your home theater can play pictures, audio and
video les contained in a disc or a USB storage
device. Before you play a le, check that the le
format is supported by your home theater (see
'File formats' on page 28).
1 Play the les from a disc or USB storage
device.
2 To stop play, press .
• To resume the video from where you
stopped, press (Play).
• To play the video from the start, press .
Note
• To play DivX DRM protected les, connect your
home theater to a TV through an HDMI cable.
Subtitles
If your video has subtitles in multiple languages,
select a subtitle language.
Note
• Make sure that the subtitle le has the exact
same name as the video le. For example, if the
video le is named 'movie.avi', name the subtitle
le as 'movie.srt' or 'movie.sub'.
• Your home theater supports the following le
formats: .srt, .sub, .txt, .ssa, .ass, smi, and .sami. If
the subtitles do not appear correctly, change the
character set.
1 While playing video, press SUBTITLE to
select a language.
2 For DivX or RMVB/RM videos, if the subtitles
do not appear correctly, continue the
following steps to change the character set.
3 Press OPTIONS.
» The options menu is displayed.
4 Select [Character set], and then select a
character set that supports the subtitle.
Europe, India, LATAM, and Russia
Character
Set
Language
[Standard] English, Albanian, Danish, Dutch,
Finnish, French, Gaelic, German,
Italian, Kurdish (Latin), Norwegian,
Portuguese, Spanish, Swedish and
Turkish
[Central
Europe]
Albanian, Croat, Czech, Dutch,
English, German, Hungarian, Irish,
Polish, Romanian, Slovak, Slovene
and Sorbian
[Cyrillic] Bulgarian, Belorussian, English,
Macedonian, Moldavian, Russian,
Serbian and Ukrainian
[Greek] Greek
Asia Pacic and China
Character
Set
Language
[Standard] Albanian, Danish, Dutch, English,
Finnish, French, Gaelic, German,
Italian, Kurdish (Latin), Norwegian,
Portuguese, Spanish, Swedish,
Turkish
[Chinese] Simplied Chinese
[Chinese-
Traditional]
Traditional Chinese
[Korean] English and Korean
VOD code for DivX
Before you purchase DivX videos and play them
on your home theater, register the home theater
on www.divx.com using the DivX VOD code.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [DivX® VOD Code].
» The DivX VOD registration code for
your home theater is displayed.
17
English
EN
USB storage devices
Enjoy pictures, audio, and video stored on a USB
storage device such as an MP4 player or digital
camera.
What you need
• A USB storage device that is formatted for
FAT or NTFS le systems, and complies with
the Mass Storage Class.
Note
• If you use a USB extension cable, USB HUB, or
USB multi-reader, the USB storage device may
not be recognized.
1 Connect a USB storage device to the
(USB) connector on your home theater.
2 Press (Home).
3 Select [browse USB], and then press OK.
» A content browser is displayed.
4 Select a le, and then press OK.
5 Press the play buttons to control play (see
'Play buttons' on page 14).
Audio, video, and picture
options
Use advanced features when you play pictures,
audio and video les from a disc or a USB storage
device.
Audio options
While playing audio, repeat an audio track, a disc,
or a folder.
1 Press OPTIONS repeatedly to cycle
through the following functions:
• RPT TRAC / RPT FILE: Repeat the
current track or le.
• RPT DISC / RPT FOLD: Repeat all the
tracks on the disc or the folder.
• RPT RAND: Play audio tracks in random
order.
• RPT OFF: Turn off the repeat mode.
Video options
While watching video, select options such as
subtitles, audio language, time search, and picture
settings. Depending on the video source, some
options are not available.
1 Press OPTIONS.
» The video options menu is displayed.
2 Press the Navigation buttons and OK to
select and change:
• [Audio language]: Select audio language
for video.
• [Subtitle Language]: Select subtitle
language for video.
• [Subtitle shift]: Change the subtitle
position on the screen.
• [Info]: Display information about what is
playing.
• [Character set]: Select a character set
that supports the DivX subtitle.
• [Time search]: Skip to a specic part of
the video by entering the time of the
scene.
• [2nd audio language]: Select the second
audio language for Blu-ray video.
• [2nd Subtitle Language]: Select the
second subtitle language for Blu-ray
video.
• [Titles]: Select a specic title.
• [Chapters]: Select a specic chapter.
• [Angle list]: Select a different camera
angle.
• [Menus]: Display the disc menu.
• [PIP selection]: Display Picture-in-Picture
window when playing a Blu-ray disc that
supports the Bonus View.
• [Zoom]: Zoom into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.
• [Repeat]: Repeat a chapter or title.
• [Repeat A-B]: Mark two points within a
chapter or track to repeat play, or turn
off the repeat mode.
• [Picture settings]: Select a predened
color setting.
18 EN
Picture options
While viewing a picture, zoom into the picture,
rotate it, add animation to a slideshow, and change
the picture settings.
1 Press OPTIONS.
» The picture options menu appears.
2 Press the Navigation buttons and OK to
select and change the following settings:
• [Rotate +90]: Rotate the picture 90
degree clockwise.
• [Rotate -90]: Rotate the picture 90
degree counter-clockwise.
• [Zoom]: Zoom into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.
• [Info]: Display picture information.
• [Duration per slide]: Select the display
speed for each picture in a slide show.
• [Slide animation]: Select animation for
the slide show.
• [Picture settings]: Select a predened
color setting.
• [Repeat]: Repeat a selected folder.
Musical slideshow
If the picture and audio les are from the same
disc or USB storage device, you can create a
musical slideshow.
1 Select an audio track, and then press OK.
2 Press BACK, and go to the picture folder.
3 Select a picture, and then press (Play) to
start the slideshow.
4 Press to stop slideshow.
5 Press again to stop music.
Radio
Listen to FM radio on your home theater, and
store up to 40 radio stations.
Note
• AM and digital radio are not supported.
• If no stereo signal is detected, or if fewer than
ve stations are found, you are prompted to
install the radio stations again.
1 Connect the FM antenna to the ANTENNA
FM 75 on your home theater.
• For the best reception, place the antenna
away from the TV or other sources of
radiation.
2 Press Source buttons repeatedly until
RADIO appears on the display panel.
» If you have already installed the radio
stations, the last channel that you listened
to is played.
» If you have not installed any radio
stations, the message AUTO
INSTALL...PRESS PLAY appears on
the display panel. Press (Play).
3 Use the remote control to listen or to
change radio stations.
19
English
EN
Play buttons
Button Action
/
or
Alphanumeric
buttons
Select a preset radio station.
Navigation
buttons
Left/Right: Search for a radio
station.
Up/Down: Fine tune a radio
frequency.
Press to stop the installation of
radio stations.
BACK
Press and hold to erase the
preset radio station.
OPTIONS
Manual: Press once to access
program mode, and press again
to store the radio station.
Automatic: Press and hold for
three seconds to reinstall the
radio stations.
SUBTITLE Toggle between the stereo and
mono sounds.
MP3 player
Connect a MP3 player to play audio les.
What you need
• An MP3 player.
• A 3.5mm stereo audio cable.
1 Using the 3.5mm stereo audio cable, connect
the MP3 player to the MUSIC iLINK
connector on your home theater.
2 Press AUDIO SOURCE repeatedly until
MUSIC I-LINK appears on the display panel.
3 Press the buttons on the MP3 player to select
and play audio les.
iPod or iPhone
Connect a Philips dock to play music, photos, and
videos from your iPod or iPhone.
What you need
• A Philips dock (model: Philips DCK306x).
• A yellow composite video cable.
1 Connect the Philips dock to the DOCK for
iPod connector on your home theater.
2 To view slideshow from your iPod or iPhone
on your TV, connect the dock to the TV by
using the yellow composite cable.
3 Switch on the iPod or iPhone, and place it on
the dock.
• Charge your iPod/iPhone on the dock
while the home theater is in iPod mode.
Play music
1 Dock your iPod or iPhone.
2 Press DOCK for iPod on the home theater
remote control.
3 Browse your iPod or iPhone screen to select
the music.
4 Play the music on your iPod or iPhone.
» The music is heard on your home theater.
Browse the audio content from your TV
(extended mode):
1 Press (Home).
2 Select [browse iPod], and then press OK.
» A content browser is displayed.
3 Press DOCK for iPod to browse the audio
content.
4 Press the play buttons to control play (see
'Play buttons' on page 14).
• The local keys on your iPod or iPhone
are disabled.
5 Press DOCK for iPod to exit the extended
mode.
20 EN
Play video and slideshow
1 Dock your iPod or iPhone (see 'iPod or
iPhone' on page 19).
2 Press DOCK for iPod on the home theater
remote control.
3 Switch the TV to the AV/VIDEO source
(corresponding to the yellow composite
cable).
» The TV screen goes blank.
4 From the iPod or iPhone screen, browse and
play a video or photo slideshow.
» The video or photo slideshow is
displayed on your TV.
Smartphone control
Use your mobile device such as iPhone (iOS 3.1.3
and above), Android phone (2.1 and above), iPad,
or tablet to:
• Control your home theater
• Browse a data disc or USB storage device
Before you start
• Connect your home theater, mobile device,
and other DLNA-compatible devices to the
same home network.
• For better video quality, use wired
connection whenever possible.
• Personalize the network name for your home
theater (see 'Personalize the network name'
on page 13).
• Download Philips MyRemote application on
your mobile device.
• For iPhone or iPad, search for the app in
App Store (App Store).
• For Android based phone or tablet,
search for the app in Market (Market).
Control your home theater
Control your home theater from the mobile
device.
1 On the mobile device, access MyRemote
(MyRemote) application.
2 Select your home theater (by its network
name) from the home screen.
» A browsing bar is displayed at the
bottom of the screen.
• If your home theater is not found, check
the network connection or tap the
Devices (Devices) tab on your mobile
device to search again.
3 Select one of the following tabs to access
more options.
• To return to the previous screen, press
back button.
Option Action
App
Home
(App
Home)
Return to your home screen.
Media
(Media)
DISC: Browse and play a le stored
on a data disc.
USB: Browse and play a le stored
on a USB storage device.
Remote
(Remote)
Access the remote control on your
mobile device. Swipe the screen
to the left or right to access more
buttons. Only the relevant buttons
are enabled on your mobile device.
Some functions such as standby and
long press, are not available on the
mobile device.
4 Follow the onscreen instructions to select an
option or complete the set up.
21
English
EN
Browse Net TV
Not available in China
Use Net TV to access variety of internet
applications and specially adapted internet
websites.
For interactive discussions on Net TV services, visit
the Net TV forum at www.supportforum.philips.
com
Note
• Koninklijke Philips Electronics N.V. bears no
responsibility for content provided by Net TV
service providers.
1 Connect your home theater to a home
network with high-speed Internet access (see
'Connect and set up a home network' on
page 13).
2 Press (Home).
3 Select [browse Net TV], and then press OK.
4 Follow the onscreen instructions to conrm
the onscreen message.
» The Net TV home page is displayed.
5 Use the remote control to select and
navigate the applications (see 'Navigate Net
TV' on page 21).
Navigate Net TV
Button Action
Navigation
buttons
Select an application or
navigate.
OK Conrm an entry or selection.
BACK
Return to the previous page or
clear text
OPTIONS
Access options related to
current activity
Alphanumeric
buttons
Enter text (for example in email
address, web URL, passwords,
etc)
DISC/ POP-UP
MENU
Exit Net TV portal and return
to home menu.
Clear browsing history
Clear the browsing history to remove passwords,
cookies, and browsing data from your home
theater.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Network] > [Clear Net TV
Memory].
4 Press OK to conrm.
Rent online video
Not available in China
Rent videos from online stores, through your
home theater. You can watch them right away or
later.
Many online video stores offer a huge choice of
video, with different rental prices, periods, and
conditions. For some stores, you must create an
account before you can rent.
What you need
• An SD memory card of type SDHC Class 6,
with at least 8GB of memory.
1 Connect your home theater to a home
network with high-speed Internet access (see
'Connect and set up a home network' on
page 13).
2 Insert a blank SD memory card into the SD
CARD slot on your home theater, and follow
the onscreen instructions to format the card.
• After formatting, leave the card in the SD
CARD slot.
3 Press (Home).
4 Select [browse Net TV], and then press OK.
» The online services available in your
country are displayed.
5 Select a video store, and then press OK.
6 Follow the onscreen instructions to rent
or watch a video. If prompted, enter the
necessary information to register or log in to
the store's account.
» The video is downloaded to your SD
memory card. You can watch it only on
your home theater.
7 Press the playback buttons to control play
(see 'Play buttons' on page 14).
22 EN
Browse PC through DLNA
Access and play the pictures, audio and video les
from a computer or media server on the home
network through your home theater.
Before you start
• Install a DLNA-compliant media server
application on your device. Make sure that
you download an application that works best
for you. For example,
• Windows Media Player 11 or higher for
PC
• Twonky Media Server for Mac or PC
• Enable media sharing of les. For details,
check the user manual of the media server
software software.
1 Connect your home theater to a home
network. For better video quality, use wired
connection whenever possible.
2 Connect the computer and other DLNA-
compatible devices to the same home
network.
3 Press (Home).
4 Select [browse PC], and then press OK.
» A content browser is displayed.
5 Select a device on the network.
» The folders in the selected device are
displayed. Depending on the media
server, the folder names may vary.
• If you cannot see the folders, make sure
that you enable media sharing on the
selected device so that the content is
available for sharing.
6 Select a le, and then press OK.
• Some media les may not play due
to compatibility issues. Check the le
formats supported by your home theater.
7 Press the play buttons to control play (see
'Play buttons' on page 14).
Choose sound
This section helps you choose the ideal sound for
your video or music.
1 Press SOUND SETTINGS.
2 Press the Navigation buttons (left/ right) to
access the sound options on the display.
Sound settings Description
SOUND Select a sound mode.
SURROUND Select surround sound or
stereo sound.
TREBLE Change the high frequency
output.
MID Change the middle frequency
output.
BASS Change the low frequency
output.
AUD SYNC Delay the audio to match the
video.
3 Select an option, and then press OK.
4 Press BACK to exit.
If you do not press a button within a minute,
the menu exits automatically.
Sound mode
Select predened sound modes to suit your video
or music.
1 Press SOUND SETTINGS.
2 Select SOUND, and then press OK.
3 Press the Navigation buttons (up/down) to
select a setting on the display:
• MOVIE: Enjoy a cinematic audio
experience, specially enhanced for
movies.
• MUSIC: Recreate the original recording
environment of your music, in the studio
or at a concert.
• ORIGINAL: Experience the original
sound of your movies and music, without
added sound effects.
• NEWS: Hear every word with optimized
speech and clear vocals.
• GAMING: Enjoy thrilling arcade sounds,
ideal for action-packed video games or
loud parties.
4 Press OK to conrm.
23
English
EN
Surround sound mode
Experience an immersive audio experience with
surround sound modes.
1 Press SOUND SETTINGS.
2 Select SURROUND, and then press OK.
3 Press the Navigation buttons (up/down) to
select a setting on the display:
• AUTO: Surround sound based on the
audio stream.
• MULTI-CH: Immersive multi-channel
sound for an enhanced movie
experience.
• STEREO: Two-channel stereo sound. Ideal
for listening to music.
4 Press OK to conrm.
6 Change settings
The home theater settings are already congured
for optimal performance. Unless you have a reason
to change a setting, we recommend that you keep
the default setting.
Note
• You cannot change a setting that is grayed out.
• To return to the previous menu, press
BACK. To exit the menu, press (Home).
Language settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Menu language]: Select a display
language for menu.
• [Audio]: Select an audio language for
discs.
• [Subtitle]: Select a subtitle language for
discs.
• [Disc menu]: Select a menu language for
discs.
Note
• If your preferred disc language is not available,
select [Others] from the list, and enter the
4-digit language code found at the end of this
user manual (see 'Language code' on page 35).
• If you select a language that is not available on a
disc, the home theater uses the default language
of the disc.
24 EN
Picture and video settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Video], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [TV display]: Select a picture format to t
the TV screen.
• [HDMI video]: Select the resolution of
video signal that is output from HDMI OUT
(ARC) on your home theater. To enjoy the
selected resolution, make sure that your TV
supports the selected resolution.
• [HDMI Deep Color]: Recreate the natural
world on your TV screen by displaying
vivid images using billion colors. Your home
theater must be connected to a Deep
Color enabled TV through an HDMI cable.
• [Picture settings]: Select pre dened
color settings for the video display. Select
[User] to create your own setting.
• [Watch 3D video]: Set HDMI video to
support 3D or 2D video.
• [User]: Select advanced settings for the
video. Available only after you create a
preset called 'User' under picture settings.
Note
• If you change a setting, make sure that the TV
supports the new setting.
Audio settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Audio], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Night mode]: For quiet listening,
decrease the volume of loud sounds on
your home theater. Night mode is only
available for Dolby-encoded DVD and
Blu-ray discs.
• [HDMI Audio]: Set the HDMI audio
output from your TV, or disable HDMI
audio output from the TV.
Parental control settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Change Password]: Set or change your
password for parental control access.
If you do not have a password or have
forgotten your password, enter 0000.
• [Parental control]: Restrict access to
discs that are recorded with age ratings.
To play all discs, irrespective of the ratings,
select 8 or [Off].
Display settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Auto subtitle shift]: Enable or disable
automatic repositioning of subtitles on
TVs that support this feature.
• [Display panel]: Set the brightness of the
home theater front panel display.
• [VCD PBC]: Enable or disable the content
menu navigation of VCD and SVCD discs
with Play Back Control feature.
25
English
EN
Energy saving settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Screen saver]: Switch the home theater
to screen saver mode after 10 minutes
of inactivity.
• [Auto standby]: Switch the home theater
to standby after 30 minutes of inactivity.
This timer works only when a disc or
USB play is paused or stopped.
• [Sleep timer]: Set the duration of the sleep
timer so that the home theater is switched
to standby after the specied period.
Speaker settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Enhanced audio]: Select [On] to enable
audio post processing at the speaker and
enable karaoke settings (if your product
supports Karaoke). To play the original
audio of the disc, select [Off].
Tip
• Enable audio post processing before you select a
predened sound mode (see 'Sound mode' on page
22).
Restore default settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [Restore default
settings], and then press OK.
4 Select [OK], and then press OK to conrm.
» Your home theater is reset to its default
settings except for some settings such
as parental control and DivX VOD
registration code.
26 EN
7 Update software
Philips continually tries to improve its products.
To get the best features and support, update your
home theater with the latest software.
Compare the version of your current software
with the latest version on www.philips.com/
support. If the current version is lower than the
latest version available on the Philips support
website, upgrade your home theater with the
latest software.
Caution
• Do not install a lower version of software than
the current version installed on your product.
Philips is not liable for problems caused due to
software downgrade.
Check software version
Check the version of the current software installed
on your home theater.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [Version information].
» The software version is displayed.
• The last two digits indicate the current
version of the onscreen help installed
on your home theater. For example,
if the current version of the software
is 'Subsystem SW: 35-00-00-05', '05'
represents the current version of
onscreen help installed on your home
theater.
Update software through USB
What you need
• A USB ash drive that is FAT or NTFS-
formatted, with at least 75MB of memory. Do
not use a USB hard drive.
• A computer with Internet access.
• An archive utility that supports the ZIP le
format.
Step 1: Download the latest software
1 Connect a USB ash drive to your computer.
2 In your web browser, go to www.philips.com/
support.
3 At the Philips Support website, nd your
product and locate the Software and drivers.
» The software update is available as a zip le.
4 Save the zip le in the root directory of your
USB ash drive.
5 Use the archive utility to extract the software
update le in the root directory.
» The les are extracted under the UPG_
ALL folder of your USB ash drive.
6 Disconnect the USB ash drive from your
computer.
Step 2: Update the software
Caution
• Do not switch off the home theater or remove
the USB ash drive during the update.
1 Connect the USB ash drive containing the
downloaded le to your home theater.
• Make sure that the disc compartment is
closed and no disc inside.
2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Advanced] > [Software update] >
[USB].
5 Follow the onscreen instructions to conrm
the update.
» Once complete, the home theater
automatically switches off and restarts. If
it does not, disconnect the power cord
for a few seconds and then reconnect it.
27
English
EN
Update software through the
Internet
1 Connect your home theater to a home
network with a high-speed Internet access
(see 'Connect and set up a home network'
on page 13).
2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Advanced] > [Software update] >
[Network].
» If an upgrade media is detected, you are
prompted to start or cancel the update.
5 Follow the onscreen instructions to conrm
the update.
» Once complete, the home theater
automatically switches off and restarts. If
it does not, disconnect the power cord
for a few seconds and then reconnect it.
Update the onscreen help
If the current version of the onscreen help is
lower than the latest version available on www.
philips.com/support, download and install the latest
onscreen help (see 'Check software version' on
page 26).
What you need
• A USB ash drive that is FAT or NTFS-
formatted, with at least 35MB of memory. Do
not use a USB hard drive.
• A computer with internet access.
• An archive utility that supports the ZIP le
format.
Step 1: Download the latest onscreen
help
1 Connect a USB ash drive to your computer.
2 In your web browser, go to www.philips.com/
support.
3 At the Philips support website, nd your
product and click on User manuals, and then
locate the User Manual Upgrade Software.
» The help update is available as a zip le.
4 Save the zip le in the root directory of your
USB ash drive.
5 Use the archive utility to extract the help
update le in the root directory.
» A le named 'HTSxxxxeDFU.zip' is
extracted under the UPG_ALL folder
of your USB ash drive, 'xxxx' being the
model number of your home theater.
6 Disconnect the USB ash drive from your
computer.
Step 2: Update onscreen help
Caution
• Do not switch off the home theater or remove
the USB ash drive during the update.
1 Connect the USB ash drive containing the
downloaded le to your home theater.
• Make sure that the disc compartment is
closed and there is no disc inside.
2 Press (Home).
3 Enter 338 on the remote control.
4 Follow the onscreen instructions to conrm
the update.
5 Disconnect the USB ash drive from the
home theater.
28 EN
8 Product
specifications
Note
• Specications and design are subject to change
without notice.
Region codes
The type plate on the back or bottom of the
home theater shows which regions it supports.
Media formats
• AVCHD, BD, BD-R/ BD-RE, BD-Video,
DVD-Video, DVD+R/+RW, DVD-R/-RW,
DVD+R/-R DL, CD-R/CD-RW, Audio CD,
Video CD/SVCD, Picture les, MP3 media,
WMA media, DivX Plus HD media, USB
storage device
• RMVB (Available only in Asia Pacic and
China)
Country
DVD BD
Europe,
United Kingdom
Korea
Latin America
Australia,
New Zealand
Russia, India
China
AA
AA
CC
CC
Asia Pacific, Taiwan,
File formats
• Audio: .aac, .mka, .mp3, .wma, .wav, .mp4, .m4a
• Video:
• .avi, .divx, .mp4, .mkv, .asf, .mpg, .mpeg,
• .wmv, .rmvb, .rm (Available only in Asia
Pacic and China)
• Picture: .jpg, .jpeg, .gif, .png
Audio formats
Your home theater supports the following audio
les.
Extension Container Audio
codec
Bit rate
.mp3 MP3 MP3 32 kbps ~
320 kbps
.wma ASF WMA 64 kbps ~
160 kbps
.aac AAC AAC, HE-
AAC
192 kbps
.wav WAV PCM 1.4 Mbps
.m4a MKV AAC 192 kbps
.mka MKA PCM 27.648
Mbps
.mka MKA Dolby
Digital
640 kbps
.mka MKA DTS core 1.54 Mbps
.mka MKA MPEG 912 kbps
.mka MKA MP3 32 kbps ~
320 kbps
.mka MKA WMA 64 kbps ~
160 kbps
.mka MKA AAC,
HE-AAC
192 kbps
29
English
EN
Video formats
If you have a high denition TV, your home theater
allows you to play your video les with:
• Resolution: 1920 x 1080 pixels at
• Frame rate: 6 ~ 30 frames per second.
.avi les in AVI container
Audio
codec
Video codec Bit rate
PCM,
Dolby
Digital,
DTS core,
MP3,
WMA
DivX 3.11, DivX 4.x,
DivX 5.x, DivX 6.x
10 Mbps max
MPEG 1, MPEG 2 20 Mbps
(peak 40
Mbps)
MPEG 4 ASP 10 Mbps max
H.264/AVC
[email protected]/4.0;
[email protected]/3.1/3.0
20 Mbps
(peak 40
Mbps)
.divx les in AVI container
Audio
codec
Video codec Bit rate
PCM,
Dolby
Digital,
MP3,
WMA
DivX 3.11,
DivX 4.x, DivX 5.x,
DivX 6.x
10 Mbps max
MPEG 1, MPEG 2 20 Mbps
(peak 40
Mbps)
MPEG 4 ASP 10 Mbps max
.mp4 or .m4v les in MP4 container
Audio
codec
Video codec Bit rate
Dolby
Digital,
MPEG,
MP3, AAC,
HE-AAC
MPEG 1, MPEG
2
20 Mbps (peak
40 Mbps)
MPEG 4 ASP 10 Mbps max
H.264/AVC
[email protected]/4.0;
[email protected]/3.1/3.0
20 Mbps (peak
40 Mbps)
.mkv les in MKV container
Audio codec Video codec Bit rate
PCM, Dolby
Digital, DTS
core, MPEG,
MP3, WMA,
AAC, HE-
AAC
MPEG 1, MPEG 2 20 Mbps
(peak 40
Mbps)
MPEG 4 ASP 10 Mbps
max
H.264/AVC
[email protected]/4.0;
[email protected]/3.1/3.0
20 Mbps
(peak 40
Mbps)
.asf les in ASF container
Audio codec Video codec Bit rate
PCM, Dolby
Digital, MP3,
WMA
MPEG 4 ASP 10 Mbps max
H.264/AVC
[email protected]/4.0;
[email protected]/3.1/3.0
20 Mbps
(peak 40
Mbps)
.mpg and .mpeg les in PS container
Audio
codec
Video codec Bit rate
PCM, DTS
core, MPEG,
MP3
MPEG 1,
MPEG 2
20 Mbps (peak 40
Mbps)
MPEG 1,
MPEG 2
20 Mbps (peak 40
Mbps)
Amplier
• Total output power: 600W RMS (30% THD)
• Frequency response: 20 Hz-20 kHz / ±3 dB
• Signal-to-noise ratio: > 65 dB (CCIR) /
(A-weighted)
• Input sensitivity:
• AUX: 2 V
• Music iLink: 1 V
Video
• Signal system: PAL / NTSC
• HDMI output: 480i/576i, 480p/576p, 720p,
1080i, 1080p, 1080p24
30 EN
Audio
• S/PDIF Digital audio input:
• Coaxial: IEC 60958-3
• Optical: TOSLINK
• Sampling frequency:
• MP3: 32 kHz, 44.1 kHz, 48 kHz
• WMA: 44.1 kHz, 48 kHz
• Constant bit rate:
• MP3: 32 kbps - 320 kbps
• WMA: 48 kbps - 192 kbps
Radio
• Tuning range:
• Europe/Russia/China: FM 87.5-108 MHz
(50 kHz)
• Asia Pacic/Latin America: FM 87.5-108
MHz (50/100 kHz)
• Signal-to-noise ratio: FM > 45 dB
• Frequency response: FM 180 Hz-12.5 kHz /
±3 dB
USB
• Compatibility: Hi-Speed USB (2.0)
• Class support: USB Mass Storage Class
(MSC)
• File system: FAT16, FAT32, NTFS
• Maximum memory support: < 160 GB
Main unit
• Power supply:
• Europe/China/Russia/India: 220-240 V~,
50 Hz
• Latin America/Asia Pacic: 110-240 V~,
50-60 Hz
• Power consumption: 110 W
• Standby power consumption: 0.9 W - 0.5 W
• Dimensions (WxHxD): 360 x 58 x 325 mm
• Weight: 2.4 kg
Subwoofer
• Output power: 100 W RMS (30% THD)
• Impedance: 4 ohm
• Speaker drivers: 133 mm (5.25") woofer
• Dimensions (WxHxD): 160 x 267.5 x 265
mm
• Weight: 2.61 kg
Speakers
Center speaker:
• Output power: 100 W RMS (30% THD)
• Speaker impedance: 4 ohm
• Speaker drivers: 1 x 63.5 mm (2.5")
woofer
• Dimensions (WxHxD): 160 x 85 x 95
mm
• Weight: 0.26 kg
Front/Rear speaker:
• Output power: 4 x 100 W RMS (30% THD)
• Speaker impedance: 4 ohm
• Speaker drivers: 1 x 63.5 mm (2.5") woofer
• Dimensions (WxHxD):
• Satellite (small) speakers: 85 x160 x 95
mm
• Tallboy (tall) speakers: 240 x 1007 x 240
mm
• Weight:
• Satellite (small) speakers: 0.34 kg each
• Tallboy (tall) speakers: 1.57 Kg each
Remote control batteries
• 2 x AAA-R03-1.5 V
Laser
• Laser Type (Diode): InGaN/AIGaN (BD),
AIGaInP (DVD/CD)
• Wave length: 405 +7 nm/-7 nm (BD), 655
+10 nm/-10 nm (DVD), 790 +10 nm/-20 nm
(CD)
• Output power (Max. ratings): 20 mW (BD), 6
mW (DVD), 7 mW (CD)
31
English
EN
9 Troubleshooting
Warning
• Risk of electric shock. Never remove the casing
of the product.
To keep the warranty valid, never try to repair the
product yourself.
If you have problems using this product, check the
following points before you request service. If you
still have a problem, get support at www.philips.
com/support.
Main unit
The buttons on the home theater do not work.
• Disconnect the home theater from the
power supply for a few minutes, then
reconnect.
No picture.
• Make sure that the TV is switched to the
correct source for the home theater.
No picture on a TV connected through HDMI.
• Make sure that you use a High Speed HDMI
cable to connect the home theater and TV.
Some Standard HDMI cables do not display
properly for some images, 3D video, or Deep
Color.
• Make sure that the HDMI cable is not faulty. If
it is faulty, replace it with a new cable.
• Press (Home) and then 731 on the
remote control to restore the default picture
resolution.
• Change the HDMI video setting, or wait for
10 seconds for auto recovery.
Disc does not play high-denition video.
• Make sure that the disc contains high-
denition video.
• Make sure that the TV supports high-
denition video.
• Use an HDMI cable to connect to the TV.
Sound
No sound from home theater speakers.
• Connect the audio cable from your home
theater to your TV or other devices. However,
you do not need a separate audio connection
when:
• the home theater and TV are connected
through an HDMI ARC connection, or
• a device is connected to the HDMI IN
connector on your home theater.
• Set up the audio for the connected device.
• Reset your home theater to its factory
settings, and then switch it off and switch on
again.
• On your home theater, press SOURCE
repeatedly to select the correct audio input.
Distorted sound or echo.
• If you play audio from the TV through the
home theater, make sure that the TV is
muted.
Audio and video are not synchronized.
• 1) Press SOUND SETTINGS. 2) Press
the Navigation buttons (left/right) to select
AUD SYNC, and then press OK. 3) Press
the Navigation buttons (up/down) to
synchronize the audio with the video.
Play
Cannot play a disc.
• Clean the disc.
• Make sure that the home theater supports
the type of disc (see 'Media formats' on page
28).
• Make sure that the home theater supports
the region code of the disc.
• If the disc is a DVD±RW or DVD±R disc,
make sure that it is nalized.
Cannot play a DivX le.
• Make sure that the DivX le is encoded
according to the 'Home Theater Prole' with
the DivX encoder.
• Make sure that the DivX le is complete.
DivX or RMVB/RM subtitles do not display
correctly.
• Make sure that the subtitle le name is the
same as the movie le name (see 'Subtitles'
on page 16).
• Select the correct character set: 1) Press
OPTIONS. 2) Select [Character set]. 3)
Select the supported character set. 4) Press
OK.
32 EN
Cannot read the contents of a USB storage
device.
• Make sure that the format of the USB
storage device is compatible with the home
theater.
• Make sure that the le system on the USB
storage device is supported by the home
theater.
'No entry' or 'x' sign appears on the TV.
• The operation is not possible.
EasyLink does not work.
• Make sure that the home theater is
connected to a Philips brand EasyLink TV, and
the EasyLink option is turned on (see 'Set up
EasyLink (HDMI-CEC control)' on page 12).
When you switch on the TV, the home theater
automatically switches on.
• This behavior is normal when you are using
Philips EasyLink (HDMI-CEC). To make the
home theater work independently, switch off
EasyLink.
Cannot access BD-Live features.
• Make sure that the home theater is
connected to the network. Use a wired
network connection or wireless network
connection.
• Make sure that the network is set up. Use
a wired network installation or wireless
network installation.
• Make sure that the Blu-ray disc supports BD-
Live features.
• Clear memory storage.
Cannot play video or photos from an iPod or
iPhone on the TV.
• Browse and select videos and photos from
the iPod or iPhone screen, and play them on
your TV.
• Make sure that the iPod or iPhone software
has not been tampered with or illegally
modied.
Cannot view pictures from an iPod or iPhone on
the TV.
• Connect a yellow composite cable to the
iPod dock and the TV.
• Switch the TV to the AV/VIDEO source
(corresponding to the yellow composite
cable).
• Press the play button on the iPod or iPhone
to start a slideshow.
• Make sure that the iPod or iPhone software
has not been tampered with or illegally
modied.
My 3D video played in 2D mode.
• Make sure that your home theater is
connected to a 3D TV through an HDMI
cable.
• Make sure that the disc is a Blu-ray 3D disc,
and the Blu-ray 3D video option is on.
TV screen is black when you play a Blu-ray 3D
video or a DivX copy protected video.
• Make sure that the home theater is
connected to the TV through an HDMI cable.
• Switch to the correct HDMI source on the
TV.
Cannot download video from an online video
store.
• Make sure that your home theater is
connected to the TV through an HDMI cable.
• Make sure that the SD card is formatted, has
enough memory to download the video, and
is of type SDHC Class 6.
• Make sure that you have paid for the video,
and it is within the rental period.
• Make sure that the network connection is
good. Use a wired network connection or a
wireless network connection.
• Visit the video store website for more
information.
Network
Wireless network distorted or not found.
• Make sure that the wireless network is not
disturbed by microwave ovens, DECT phones,
or other neighboring Wi-Fi devices.
• Place the wireless router and the home
theater within ve meters of each other.
• Use a USB extension cable to connect the
Wi-Fi dongle to the home theater.
• If the wireless network does not work
properly, try a wired network installation.
33
English
EN
10 Notice
This section contains the legal and trademark
notices.
Open source software
Philips Electronics Singapore Pte Ltd hereby offers
to deliver, upon request, a copy of the complete
corresponding source code for the copyrighted
open source software packages used in this
product for which such offer is requested by the
respective licenses. This offer is valid up to three
years after product purchase to anyone in receipt
of this information. To obtain source code, please
contact [email protected]. If you prefer not
to use email or if you do not receive conrmation
receipt within a week after mailing to this email
address, please write to "Open Source Team,
Philips Intellectual Property & Standards, P.O. Box
220, 5600 AE Eindhoven, The Netherlands". If you
do not receive timely conrmation of your letter,
please email to the email address above. The texts
of the licenses and acknowledgements for open
source software used in this product are included
in the user manual.
RMVB end user agreement
(Asia Pacic and China only)
Notes to End User:
By using this product with RealNetworks software
and services, the end user agrees to the following
terms of REALNETWORKS, INC:
• End User may only use the software for
private, non-commercial use in accordance
with the terms of RealNetworks EULA .
• End User is not allowed to modify, translate,
reverse engineer, decompile, dissemble or
use other means to discover the source
code or otherwise replicate the functionality
of the Real Format Client Code, except to
the extent that this restriction is expressly
prohibited by applicable law.
• RealNetworks Inc. disclaims all warranties
and conditions other than those set forth in
this Agreement which are in lieu of all other
warranties, whether express and implied,
including but not limited to any implied
warranties or conditions of merchantability
and tness for a particular purpose; and
effectively exclude all liability for indirect,
special, incidental and consequential damages,
such as but not limited to lost prots.
Trademarks
"Blu-ray 3D" and "Blu-ray 3D" logo are trademarks
of Blu-ray Disc Association.
Java and all other Java trademarks and logos are
trademarks or registered trademarks of Sun
Microsystems, Inc. in the United States and/or
other countries.
34 EN
BONUSVIEW™
'BD LIVE' and 'BONUSVIEW' are trademarks of
Blu-ray Disc Association.
Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535;
7,392,195; 7,272,567; 7,333,929; 7,212,872 & other
U.S. and worldwide patents issued & pending.
DTS-HD, the Symbol, & DTS-HD and the Symbol
together are registered trademarks & DTS-HD
Master Audio | Essential is a trademark of DTS, Inc.
Product includes software. DTS, Inc. All Rights
Reserved.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
DivX , DivX Certied , DivX Plus HD
and associated logos are trademarks of Rovi
Corporation or its subsidiaries and are used under
license.
ABOUT DIVX VIDEO: DivX is a digital video
format created by DivX, LLC, a subsidiary of Rovi
Corporation. This is an ofcial DivX Certied
device that plays DivX video. Visit divx.com for
more information and software tools to convert
your les into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certied device must be registered in order to
play purchased DivX Video-on-Demand (VOD)
movies. To obtain your registration code, locate the
DivX VOD section in your device setup menu. Go
to vod.divx.com for more information on how to
complete your registration.
HDMI, the HDMI logo, and High-Denition
Multimedia Interface are trademarks or registered
trademarks of HDMI licensing LLC in the United
States and other countries.
SDHC Logo is a trademark of SD-3C, LLC.
CLASS 1
LASER PRODUCT
35
English
EN
11 Language code
Abkhazian 6566
Afar 6565
Afrikaans 6570
Amharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Avestan 6569
Aymara 6589
Azerhaijani 6590
Bahasa Melayu 7783
Bashkir 6665
Belarusian 6669
Bengali 6678
Bihari 6672
Bislama 6673
Bokmål, Norwegian 7866
Bosanski 6683
Brezhoneg 6682
Bulgarian 6671
Burmese 7789
Castellano, Español 6983
Catalán 6765
Chamorro 6772
Chechen 6769
Chewa; Chichewa; Nyanja 7889
9072
Chuang; Zhuang 9065
Church Slavic; Slavonic 6785
Chuvash 6786
Corsican 6779
Česky 6783
Dansk 6865
Deutsch 6869
Dzongkha 6890
English 6978
Esperanto 6979
Estonian 6984
Euskara 6985
6976
Faroese 7079
Français 7082
Frysk 7089
Fijian 7074
Gaelic; Scottish Gaelic 7168
Gallegan 7176
Georgian 7565
Gikuyu; Kikuyu 7573
Guarani 7178
Gujarati 7185
Hausa 7265
Herero 7290
Hindi 7273
Hiri Motu 7279
Hrwatski 6779
Ido 7379
Interlingua (International)7365
Interlingue 7365
Inuktitut 7385
Inupiaq 7375
Irish 7165
Íslenska 7383
Italiano 7384
Ivrit 7269
Japanese 7465
Javanese 7486
Kalaallisut 7576
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kernewek 7587
Khmer 7577
Kinyarwanda 8287
Kirghiz 7589
Komi 7586
Korean 7579
Kuanyama; Kwanyama 7574
Kurdish 7585
Lao 7679
Latina 7665
Latvian 7686
Letzeburgesch; 7666
Limburgan; Limburger 7673
Lingala 7678
Lithuanian 7684
Luxembourgish; 7666
Macedonian 7775
Malagasy 7771
Magyar 7285
Malayalam 7776
Maltese 7784
Manx 7186
Maori 7773
Marathi 7782
Marshallese 7772
Moldavian 7779
Mongolian 7778
Nauru 7865
Navaho; Navajo 7886
Ndebele, North 7868
Ndebele, South 7882
Ndonga 7871
Nederlands 7876
Nepali 7869
Norsk 7879
Northern Sami 8369
North Ndebele 7868
Norwegian Nynorsk; 7878
Occitan; Provencal 7967
Old Bulgarian; Old Slavonic 6785
Oriya 7982
Oromo 7977
Ossetian; Ossetic 7983
Pali 8073
Panjabi 8065
Persian 7065
Polski 8076
Po
rtuguês 8084
Pushto 8083
Russian 8285
Quechua 8185
Raeto-Romance 8277
Romanian 8279
Rundi 8278
Samoan 8377
Sango 8371
Sanskrit 8365
Sardinian 8367
Serbian 8382
Shona 8378
Shqip 8381
Sindhi 8368
Sinhalese 8373
Slovensky 8373
Slovenian 8376
Somali 8379
Sotho; Southern 8384
South Ndebele 7882
Sundanese 8385
Suomi 7073
Swahili 8387
Swati 8383
Svenska 8386
Tagalog 8476
Tahitian 8489
Tajik 8471
Tamil 8465
Tatar 8484
Telugu 8469
Thai 8472
Tibetan 6679
Tigrinya 8473
To nga (Tonga Islands) 8479
Tsonga 8483
Tswana 8478
Türkçe 8482
Tu rkmen 8475
Tw i 8487
Uighur 8571
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapuk 8679
Walloon 8765
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 8973
Yo ruba 8979
Zulu 9085
Ё᭛
36 EN
12 Index
2
2nd audio language 15
2nd subtitle language 15
3
3D disc in 2D mode 15
3D safety 4
3D video 15
5
5.1 speakers 8
A
advanced settings 25
amplier 29
audio connection (analog cable) 11
audio connection (coaxial cable) 11
audio connection (HDMI ARC) 9
audio connection (optical cable) 11
audio formats 28
audio from other devices 10
audio input mapping 12
audio language 23
audio options 17
audio post processing 25
audio settings 24
audio setup 12
auto standby 25
auto subtitle shift 24
B
batteries 30
BD-Live 15
Blu-ray 14
Bonus View 15
brightness 24
browse disc or USB from smartphone 20
browse PC 22
C
change password 24
character set 16
clear BD-Live memory 15
connect to TV 9
connectors 7
control buttons (disc) 14
control buttons (NetTV) 21
control buttons (radio) 19
control buttons (USB) 14
customer support 2
D
data les 16
deep color 24
default settings 25
device name 13
disc language 23
disc menu 23
display panel 24
disposal 4
DivX 16
DivX subtitles 16
DLNA 22
E
Easylink (HDMI-CEC) 12
eject disc 7
enhanced audio 25
environment 4
F
factory settings 25
FAQs 2
le formats 28
H
HDMI audio 24
HDMI-CEC 12
help 2
home menu 14
home network 13
37
English
EN
I
iPod music 19
iPod or iPhone 19
L
language code 35
M
main unit 7
manual setup 11
media formats 28
menu language 23
MP3 19
musical slideshows 18
N
Net TV 21
network 13
night mode 24
O
one-touch play 12
one-touch standby 12
online video stores 21
onscreen user manual 2
options 17
P
parental control 24
PBC (play back control) 24
picture options 18
picture resolution 24
picture settings 24
picture-in-picture 15
play disc 14
play from iPhone 20
play from iPod 19
play from PC 22
play music 19
play online video 21
play radio 18
play USB storage device 17
play video and slideshow from iPod 20
power settings 25
predened sound mode 22
preference 23
program radio stations 18
R
radio 18
recycling 4
region codes 28
remote control 5
S
SD card 21
sleep timer 25
slide animation 18
smartphone 20
software update 26
software version 26
sound 22
speaker position 8
speaker setup 11
speaker specications 28
subtitle language 23
subtitle position 24
surround sound 23
synchronize picture and sound 15
system audio control 12
38 EN
T
troubleshooting (network) 32
troubleshooting (picture) 31
troubleshooting (play) 31
troubleshooting (sound) 31
tune radio stations 18
U
update onscreen help (user manual) 27
update software (through Internet) 27
update software (through USB) 26
USB storage device 17
user manual 2
V
VCD 24
video connection (composite video) 10
video connection (HDMI ARC) 9
video connection (standard HDMI) 10
video formats 29
video options 17
video settings 24
VOD code (DivX) 16
W
watch 3D 15
wired network 13
© 2012 Koninklijke Philips Electronics N.V.
All rights reserved.
Sgpam_1201/HTS35x3_WE_v1
