[en] Instruction manual
Built-in oven
HBN531.1B
Table of contents[en] Instruction manual
: Important safety information
Read these instructions carefully. Only then will you be able to operate your appliance safely and correctly. Retain the instruction manual and installation instructions for future use or for subsequent owners.
This appliance is only intended to be fully fitted in a kitchen. Observe the special installation instructions.
Check the appliance for damage after unpacking it. Do not connect the appliance if it has been damaged in transport.
Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under warranty.
This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
This appliance is intended for use up to a maximum height of 2000 metres above sea level.
This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsi...
Children must not play with, on, or around the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
Always slide accessories into the cooking compartment correctly. See "Description of accessories in the instruction manual.
Risk of fire!
â Combustible items stored in the cooking compartment may catch fire. Never store combustible items in the cooking compartment. Never open the appliance door if there is smoke inside. Switch off the appliance and unplug it from the mains or switch ...
Risk of fire!
â A draught is created when the appliance door is opened. Greaseproof paper may come into contact with the heating element and catch fire. Do not place greaseproof paper loosely over accessories during preheating. Always weight down the greaseproof...
Risk of burns!
â The appliance becomes very hot. Never touch the interior surfaces of the cooking compartment or the heating elements. Always allow the appliance to cool down. Keep children at a safe distance.
Risk of serious burns!
â Accessories and ovenware become very hot. Always use oven gloves to remove accessories or ovenware from the cooking compartment.
Risk of burns!
â Alcoholic vapours may catch fire in the hot cooking compartment. Never prepare food containing large quantities of drinks with a high alcohol content. Only use small quantities of drinks with a high alcohol content. Open the appliance door with care
Risk of scalding!
â The accessible parts become hot during operation. Never touch the hot parts. Keep children at a safe distance.
Risk of scalding!
â When you open the appliance door, hot steam may escape. Open the appliance door with care. Keep children at a safe distance.
Risk of scalding!
â Water in a hot cooking compartment may create hot steam. Never pour water into the hot cooking compartment.
Risk of injury!
Scratched glass in the appliance door may develop into a crack. Do not use a glass scraper, sharp or abrasive cleaning aids or detergents.
Risk of electric shock!
â Incorrect repairs are dangerous. Repairs may only be carried out by one of our trained after-sales engineers. If the appliance is faulty, unplug the mains plug or switch off the fuse in the fuse box. Contact the after-sales service.
Risk of electric shock and serious injury!
â The cable insulation on electrical appliances may melt when touching hot parts of the appliance. Never bring electrical appliance cables into contact with hot parts of the appliance.
Risk of electric shock!
â Do not use any high-pressure cleaners or steam cleaners, which can result in an electric shock.
Risk of electric shock!
â When replacing the cooking compartment bulb, the bulb socket contacts are live. Before replacing the bulb, unplug the appliance from the mains or switch off the circuit breaker in the fuse box.
Risk of electric shock!
â A defective appliance may cause electric shock. Never switch on a defective appliance. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the after-sales service.
Risk of fire!
â Loose food residues, grease and meat juices may catch fire during the Self- cleaning cycle. Remove coarse dirt from the cooking compartment and from the accessories before every Self-cleaning cycle.
Risk of fire!
â The appliance will become very hot on the outside during the Self-cleaning cycle. Never hang combustible objects, e.g. tea towels, on the door handle. Do not place anything against the front of the oven. Keep children at a safe distance.
Risk of burns!
â The cooking compartment will become very hot during the Self-cleaning cycle. Never open the appliance door or move the locking latch by hand. Allow the appliance to cool down. Keep children at a safe distance.
Risk of burns!
â ; The appliance will become very hot on the outside during the Self-cleaning cycle. Never touch the appliance door. Allow the appliance to cool down. Keep children at a safe distance.
Causes of damage
Caution!
Your new oven
Control panel
Control knobs
Function selector
Buttons and display
Temperature selector
Grill settings
Cooking compartment
Oven light
Cooling fan
Caution!
Your accessories
Inserting the accessories
Note
Optional accessories
Oven door - Additional safety precautions
Before using the oven for the first time
Setting the clock
1. Press the 0 button. The time 12:00 appears in the display and the 0 symbol flashes.
2. Use the + or - button to change the clock.
Heating up the oven
1. Use the function selector to select the : 3D hot air type of heating.
2. Use the temperature selector to set the temperature to 240 °C.
Cleaning the accessories
Setting the oven
Types of heating and temperature
1. Use the function selector to select the required type of heating.
2. Use the temperature selector to set the temperature or the grill setting.
Switch off the oven
Changing the settings
If the oven is to switch off automatically
1. The function selector is used to set the type of heating.
2. The temperature selector is used to set the temperature or grill setting.
3. Press the 0 Clock button. The x Cooking time symbol flashes.
4. Use the @ or A button to set the cooking time. Default value for the @ button = 30 minutes Default value for the A button = 10 minutes
The cooking time has elapsed
Changing the setting
Cancelling the setting
Setting the cooking time if the clock is hidden
If the oven is to switch on and off automatically
1. The function selector is used to set the type of heating.
2. The temperature selector is used to set the temperature or grill setting.
3. Press the 0 Clock button.
4. Use the @ or A button to set the cooking time.
5. Press the 0 Clock button repeatedly until the y End symbol flashes. You can see in the display when the meal will be ready.
6. Use the @ button to set a later end time. The setting is adopted after a few seconds. The end time is shown in the display until the oven starts.
The cooking time has elapsed
Note
Setting the clock
1. Press the 0 Clock button. 12.00 appears in the display and the 0 symbol flashes.
2. Use the + or - button to change the clock. After a few seconds, the time is saved. The 0 symbol goes out.
Setting the timer
1. Press the S Timer button. The S symbol flashes.
2. Use the - or + button to change the timer duration. Default value for + button = 10 minutes Default value for - button = 5 minutes
Childproof lock
Oven
Notes
Care and cleaning
Notes
Cleaning agents
When cleaning the oven do not use
Cleaning the self-cleaning surfaces in the oven
1. First clean the oven floor.
2. Then set : 3D hot air function.
3. Heat the empty oven for approx. 2 hours at maximum temperature.
Caution!
Detaching and refitting the rails
Unhooking the rails
1. Hold the shelf frames from underneath and pull slightly forward. Pull the extension pins at the bottom of the rails out of the mounting holes (Fig. A).
2. Then fold the rails upwards and carefully remove them (Fig. B).
Installing the frames
1. Insert the two hooks carefully into the upper holes. (Figure A- B)
: Incorrect assembly!
2. the two hooks must be inserted fully into the upper holes. Now move the frame slowly and carefully downwards and insert in the lower holes (figure D).
3. Insert both frames into the side walls of the oven (figure E).
Detaching and attaching the oven door
: Risk of injury!
Detaching the door
1. Open the oven door fully.
2. Fold up the two locking levers on the left and right (figure A).
3. Close the oven door as far as the limit stop. With both hands, grip the door on the left and right-hand sides. Close the door a little further and pull it out (figure B).
Attaching the door
1. When attaching the oven door, ensure that both hinges are inserted straight into the opening (figure A).
2. The notch on the hinge must engage on both sides (figure B).
3. Fold back both locking levers (figure C). Close the oven door.
: Risk of injury!
Removing and installing the door panels
Removal
1. Detach the oven door and lay it on a cloth with the handle facing down.
2. Pull off the cover at the top of the oven door. Press in the tabs on the left and right using your fingers (fig. A).
3. Lift the top panel up and pull it out (fig. B).
4. Lift the panel up and pull it out (fig. C).
: Risk of injury!
Installation
1. Insert the panel at an angle towards the back (fig. A).
2. Insert the top panel at an angle towards the back into the brackets. The smooth surface must face outwards. (fig. B).
3. Put the cover back in place and press on it.
4. Attach the oven door.
Troubleshooting
Malfunction table
: Risk of electric shock!
Caution!
Replacing the bulb in the oven ceiling light
: Risk of electric shock!
1. Place a tea towel in the oven when it is cold to prevent damage.
2. Unscrew the glass cover by turning it anti-clockwise.
3. Replace the bulb with one of the same type.
4. Screw the glass cover back in.
5. Remove the tea towel and switch on the circuit breaker.
Glass cover
After-sales service
E number and FD number
To book an engineer visit and product advice
Energy and environment tips
Saving energy
Environmentally-friendly disposal
Measures to be noted during transport
If the original packaging is no longer available
Tested for you in our cooking studio
Notes
Cakes and pastries
Baking on one level
Baking and roasting on two or more levels
Baking tins
Tables
Note
Baking tips
Meat, poultry, fish
Ovenware
Roasting
Grilling
Roasting
Grilling
Tips for roasting and grilling
Special dishes
1. Bring 1 litre of milk (3.5 % fat) to the boil and cool down to 40 °C.
2. Stir in 150 g of yoghurt (at refrigerator temperature).
3. Pour into cups or small screw-top jars and cover with cling film.
4. Preheat the cooking compartment as indicated.
5. Place the cups or jars on the cooking compartment floor and incubate as indicated.
1. Prepare the dough as usual, place it in a heat-resistant ceramic dish and cover.
2. Preheat the cooking compartment as indicated.
3. Switch off the oven and place the dough in the cooking compartment and leave it to prove.
Defrosting
Drying
Acrylamide in foodstuffs
Test dishes
Baking
Grilling
