Installation
Instructions
GPF325 SERIES KITS
1/4" Custom Dishwasher Door
and Access Panel Kit
GPF325A, Almond Trim Kit
GPF325B, Black Trim Kit
GPF325C, Bisque Trim Kit
GPF325W, White Trim Kit
WARNING:
To prevent electric shock, disconnect electrical
power supply to dishwasher before changing
panels. Do not operate dishwasher while
changing panels or when lower access panel
assembly is removed.
TOOLS AND MATERIALS
REQUIRED:
• 1/4" socket driver
• Phillips screwdriver
• Electric drill
• 1/8" drill bit
• Masking tape
• Safety glasses
• Center punch
• Gloves to protect against sharp edges
The GPF325 trim kits provide for the installa-
tion of 1/4" thick custom door and access
panels.
KIT INCLUDES:
• Left, right and bottom door trim
• Top and bottom access panel trim
• Color matched screws
Before you begin
Read these instructions completely
and carefully.
IMPORTANT – Save these instructions
for local inspector’s use.
IMPORTANT – Observe all governing
codes and ordinances.
Note to Installer – Be sure to leave these
instructions with the Consumer.
Note to Consumer – Keep these instructions
with your Owner’s Manual for future
reference.
STOP
1 CUT 1/4" THICK CUSTOM
PANELS TO SIZE
• Cut door panel and access panel to the
dimensions shown.
NOTE: The trim provided will conceal the cut
edges of the panels.
1/4" Thick
Door Panel
23-9/16"
3-11/16"
18-7/8"
1/4" Thick Access Panel
