Sony DAV-C900 Compact Av System User Manual

4-237-230-12(1)

DAV-C900

Compact AV

System

Operating Instructions

WARNING

To prevent fire or shock

hazard, do not expose the unit

to rain or moisture.

This symbol is intended to

alert the user to the

presence of uninsulated

“dangerous voltage”

within the product’s enclosure that

may be of sufficient magnitude to

constitute a risk of electric shock to

persons.

This symbol is intended to

alert the user to the

presence of important

operating and

maintenance (servicing) instructions

in the literature accompanying the

appliance.

Owner’s Record

The model and serial numbers are

located at the rear of the unit.

Record the serial number in the

space provided below. Refer to them

whenever you call upon your Sony

dealer regarding this product.

Model No. DAV-C900

Serial No.______________

CAUTION

As the laser beam used in this CD/

DVD player is harmful to eyes, do

not attempt to disassemble the

cabinet. Refer servicing to qualified

personnel only.

This label is located on the Laser

protective housing inside the

enclosure.

WARNING

This equipment has been tested and

found to comply with the limits for a

Class B digital device, pursuant to

Part 15 of the FCC Rules. These

limits are designed to provide

reasonable protection against

harmful interference in a residential

installation. This equipment

generates, uses, and can radiate radio

frequency energy and, if not

installed and used in accordance

with the instructions, may cause

harmful interference to radio

communications. However, there is

no guarantee that interference will

not occur in a particular installation.

If this equipment does cause harmful

interference to radio or television

reception, which can be determined

by turning the equipment off and on,

the user is encouraged to try to

correct the interference by one or

more of the following measures:

- Reorient or relocate the receiving

antenna.

- Increase the separation between

the equipment and receiver.

- Connect the equipment into an

outlet on a circuit different from

that to which the receiver is

connected.

- Consult the dealer or an

experienced radio/TV technician

for help.

CAUTION

You are cautioned that any change or

modifications not expressly

approved in this manual could void

your authority to operate this

equipment.

Note on CATV system installer:

This reminder is provided to call the

CATV system installer’s attention to

Article 820-40 of the NEC that

provides guidelines for proper

grounding and, in particular,

specifies that the cable ground shall

be connected to the grounding

system of the building, as close to

the point of cable entry as practical.

ENERGY STA R

is a U.S.

registered mark.

As an

ENERGY STA R

partner,

Sony Corporation has

determined that this product

meets the

ENERGY STA R

guidelines for energy efficiency.

Don’t throw a

battery, dipose it

as the injurious

wastes.

Welcome!

Thank you for purchasing this Sony

Compact AV System. Before

operating this system, please read

this manual thoroughly and retain it

for future reference.

Precautions

Safety

• If anything falls into the cabinet,

unplug the unit and have it

checked by qualified personnel

before operating it any further.

• The unit is not disconnected from

the mains as long as it is

connected to the mains outlet,

even if the unit itself has been

turned off.

• Unplug the unit from the wall

outlet if you do not intend to use it

for an extended period of time. To

disconnect the cord, pull it out by

the plug, never by the cord.

Installing

• Do not install the appliance in a

confined space, such as a bookcase

or built-in cabinet.

• Allow adequate air circulation to

prevent internal heat buildup.

• Do not place the unit on surfaces

(rugs, blankets, etc.) or near

materials (curtains, draperies) that

may block the ventilation slots.

• Do not install the unit near heat

sources such as radiators, or air

ducts, or in a place subject to

direct sunlight, excessive dust,

mechanical vibration, or shock.

• Do not install the unit in an

inclined position. It is designed to

be operated in a horizontal

position only.

• Keep the unit and discs away from

equipment with strong magnets,

such as microwave ovens, or large

loudspeakers.

• Do not place heavy objects on the

unit.

• If the unit is brought directly from

a cold to a warm location,

moisture may condense inside the

Compact AV System and cause

damage to the lenses. When you

first install the unit, or when you

move it from a cold to a warm

location, wait for about 30 minutes

before operating the unit.

• When you move the system, take out any discs.

If you don’t, the disc may be damaged.

• For power saving purposes, the system can be

completely turned off by the POWER button

on the main unit. Though the LED remains lit

for a while, the system is completely off.

On adjusting volume

Do not turn up the volume while listening to a

section with very low level inputs or no audio

signals. If you do, the speakers may be damaged

when a peak level section is played.

On cleaning

Clean the cabinet, panel, and controls with a soft

cloth slightly moistened with a mild detergent

solution. Do not use any type of abrasive pad,

scouring powder or solvent such as alcohol or

benzine.

If you have any questions or problems concerning

your system, please consult your nearest Sony

dealer.

On cleaning discs

Do not use a commercially available CD/DVD

cleaning disc. It may cause a malfunction.

On your TV’s color

If the speakers should cause the TV screen to have

color irregularity, turn off the TV at once then

turn it on after 15 to 30 minutes. If color

irregularity should persist, place the speakers

further away from the set.

IMPORTANT NOTICE

Caution: This system is capable of holding a

still video image or on-screen display image on

your television screen indefinitely. If you leave

the still video image or on-screen display image

displayed on your TV for an extended period of

time you risk permanent damage to your

television screen. Projection televisions are

especially susceptible to this.

Precautions

On safety

• Caution – The use of optical instruments with

this product will increase eye hazard.

• Should any solid object or liquid fall into the

cabinet, unplug the system and have it checked

by qualified personnel before operating it any

further.

On power sources

• The unit is not disconnected from the AC power

source as long as it is connected to the wall

outlet, even if the unit itself has been turned off.

• AC power cord must be changed only at the

qualified service shop.

On placement

• Place the system in a location with adequate

ventilation to prevent heat build-up in the

system.

• At high volume, over long periods of time, the

cabinet becomes hot to the touch. This is not a

malfunction. However, touching the cabinet

should be avoided. Do not place the unit in a

confined space where ventilation is poor as this

may cause overheating.

• Do not block the ventilation slots by putting

anything on the system. The system is

equipped with a high power amplifier. If the

ventilation slots on the top surface are blocked,

the unit can overheat and malfunction.

• Do not place the system on a soft surface such

as a rug that might block the ventilation holes

on the bottom.

• Do not place the system in a location near heat

sources, or in a place subject to direct sunlight,

excessive dust, or mechanical shock.

On operation

• If the system is brought directly from a cold to

a warm location, or is placed in a very damp

room, moisture may condense on the lenses

inside the system. Should this occur, the

system may not operate properly. In this case,

remove the disc and leave the system turned on

for about half an hour until the moisture

evaporates.

Table of Contents

WARNING.......................................................................................................... 2

Welcome!........................................................................................................... 3

Precautions........................................................................................................ 4

About this Manual .............................................................................................. 7

This system Can Play the Following Discs ........................................................ 7

Notes about the Discs........................................................................................ 9

Note on DVD 5-disc changer with EXCHANGE mechanism ........................... 10

Index to Parts and Controls ............................................................................. 11

Guide to the Control Menu Display (Magic Pad).............................................. 15

Getting Started................................................................17

Quick Overview................................................................................................ 17

Unpacking........................................................................................................ 17

Inserting Batteries into the Remote ................................................................. 18

Step 1: Speaker System Hookup ..................................................................... 18

Step 2: Antenna Hookups ................................................................................ 21

Step 3: TV and Video Component Hookups .................................................... 23

Speaker Setup ................................................................................................. 25

Presetting Radio Stations ................................................................................ 30

Playing Discs..................................................................32

Playing Discs ................................................................................................... 32

Resuming Playback from the Point Where You Stopped the Disc

(Resume Play) ........................................................................................... 34

Using the DVD’s Menu..................................................................................... 35

Playing VIDEO CDs with PBC Functions (PBC Playback) .............................. 36

Selecting the Disc Mode (One Disc or All Discs) ............................................. 37

Creating Your Own Program (Program Play) ................................................... 37

Playing in random order (Shuffle Play) ............................................................ 39

Playing repeatedly (Repeat Play) .................................................................... 40

Searching for a Scene .......................................................41

Searching for a Particular Point on a Disc (Scan, Slow-motion Play) .............. 41

Searching for a Title/Chapter/Track/Index/Scene............................................. 42

Viewing Information About the Disc .......................................44

Viewing the Playing Time and Remaining Time on the Front Panel Display.... 44

Checking the Playing Time and Remaining Time ............................................ 45

continued

Sound Adjustments...........................................................47

Changing the Sound ........................................................................................ 47

Selecting a Sound Field................................................................................... 49

Adjusting the level parameters......................................................................... 51

Enjoying Movies ..............................................................52

Changing the Angles ....................................................................................... 52

Displaying the Subtitles ................................................................................... 53

Checking the Play Information (ADVANCED) .................................................. 54

Using Various Additional Functions ....................................... 55

Locking Discs (CUSTOM PARENTAL CONTROL, PARENTAL CONTROL) ... 55

Other Operations .............................................................60

Controlling the TV with the Supplied Remote .................................................. 60

Watching the Video or other Unit ..................................................................... 61

Listening to the Radio ...................................................................................... 62

Naming Preset Stations ................................................................................... 63

Settings and Adjustments ................................................... 64

Using the Setup Display .................................................................................. 64

Setting the Display or Sound Track Language (LANGUAGE SETUP)............. 65

Settings for the Display (SCREEN SETUP)..................................................... 66

Custom Settings (CUSTOM SETUP)............................................................... 67

Settings for the Speakers (SPEAKER SETUP) ............................................... 68

Additional Information....................................................... 72

Troubleshooting ............................................................................................... 72

Self-diagnosis Function (When letters/numbers appear in the display)........... 75

Glossary .......................................................................................................... 75

Specifications................................................................................................... 78

Language Code List......................................................................................... 80

DVD Setup Menu List ...................................................................................... 81

Index ................................................................................................................ 82

Icon Meaning Icon Meaning

Functions

available in

DVD video

mode

Functions

available in

VIDEO

CD mode

Functions

available in

SACD

(Super

Audio CD)

and Audio

CD mode

convenient

features

About this Manual

• Instructions in this manual describe the

controls on the remote. You can also use

the controls on the system if they have the

same or similar names as those on the

remote.

• The icons used in this manual are

explained below:

This system Can Play the

Following Discs

The “DVD VIDEO” logo is a trademark.

Format of discs

DVD VIDEO

VIDEO CD

Music CD

Super Audio CD

Terms for discs

• Title

The longest sections of a picture or a

music piece on a DVD; a movie, etc., for a

picture piece on a video software; or an

album, etc., for a music piece on an audio

software. Each title is assigned a title

number enabling you to locate the title you

want.

• Chapter

Sections of a picture or a music piece that

are smaller than titles. A title is composed

of several chapters. Each chapter is

assigned a chapter number enabling you to

locate the chapter you want. Depending on

the disc, no chapters may be recorded.

• Track

Sections of a picture or a music piece on a

VIDEO CD, SACD, or CD. Each track is

assigned a track number enabling you to

locate the track you want.

• Index (SACD, CD) / Video Index

(VIDEO CD)

A number that divides a track into sections

to easily locate the point you want on a

VIDEO CD, SACD, or CD. Depending on

the disc, no indexes may be recorded.

• Scene

On a VIDEO CD with PBC functions

(page 36), the menu screens, moving

pictures and still pictures are divided into

sections called “scenes.” Each scene is

assigned a scene number enabling you to

locate the scene you want.

DVD

structure

VIDEO CD,

SACD, or

structure

Title

Disc

Index

Track

Chapter

Disc

continued

You can

Enjoy video playback

(moving pictures) as well

as music.

Play interactive software

using menu screens

displayed on the TV screen

(PBC Playback), in

addition to the video

playback functions of Ver

1.1 discs. Moreover, you

can play high-resolution

still pictures, if they are

included on the disc.

Note on PBC (Playback Control)

(VIDEO CDs)

This system conforms to Ver. 1.1 and Ver.

2.0 of VIDEO CD standards. You can enjoy

two kinds of playback depending on the disc

type.

Disc type

VIDEO CDs

without PBC

functions

(Ver. 1.1 discs)

VIDEO CDs

with PBC

functions

(Ver. 2.0 discs)

Region code

Your system has a region code printed on

the back of the unit and will only play

DVDs labelled with the same region code.

DVDs labelled

ALL

will also play on this

system.

If you try to play any other DVD, the

message “Playback prohibited by area

limitations.” will appear on the TV screen.

Depending on the DVD, no region code

indication may be labelled even though

playing the DVD is prohibited by area

restrictions.

Examples of discs that the system

cannot play

The system cannot play the following discs:

• CD-ROMs (PHOTO CDs included)

• All CD-Rs other than music and VCD

format CD-Rs

• Data part of CD-Extras

• DVD-ROMs

• DVD Audio discs

• A DVD with a different region code (page

8, 76).

• A disc that has a non-standard shape (e.g.,

card, heart)

• A disc with paper or stickers on it.

• A disc that has the adhesive, cellophane

tape, or a sticker still left on it.

Note

Some CD-Rs or CD-RWs cannot be played on this

system depending upon the recording quality or

physical condition of the disc, or the characteristics

of the recording device.

Furthermore, the disc will not play if it has not been

correctly finalized. For more information, see the

operating instructions for the recording device.

Note on playback operations of

DVDs and VIDEO CDs

Some playback operations of DVDs and

VIDEO CDs may be intentionally set by

software producers. Since this system plays

DVDs and VIDEO CDs according to the

disc contents the software producers

designed, some playback features may not

be available. Also, refer to the instructions

supplied with the DVDs or VIDEO CDs.

Copyrights

This product incorporates copyright

protection technology that is protected by

method claims of certain U.S. patents, other

intellectual property rights owned by

Macrovision Corporation, and other rights

owners. Use of this copyright protection

technology must be authorized by

Macrovision Corporation, and is intended

for home and other limited viewing uses

only unless otherwise authorized by

Macrovision Corporation. Reverse

engineering or disassembly is prohibited.

Notes about the Discs

On handling discs

• To keep the disc clean, handle the disc by

its edge. Do not touch the surface.

• Do not expose the disc to direct sunlight or

heat sources such as hot air ducts, or leave

it in a car parked in direct sunlight as the

temperature may rise considerably inside

the car.

• After playing, store the disc in its case.

On cleaning

• Before playing, clean the disc with a

cleaning cloth.

Wipe the disc from the center out.

• Do not use solvents such as benzine,

thinner, commercially available cleaners,

or anti-static spray intended for vinyl LPs.

This system incorporates Dolby* Digital,

Pro Logic Surround, and the DTS** Digital

Surround System.

* Manufactured under license from Dolby

Laboratories.

“Dolby”, “Pro Logic”, and the double-D symbol

are trademarks of Dolby Laboratories.

**Manufactured under license from Digital Theater

Systems, Inc. US Pat. No. 5,451,942 and other

worldwide patents issued and pending. “DTS” and

“DTS Digital Surround” are trademarks of Digital

Stocker

Disc

tray

Playing unit

Note on DVD 5-disc

changer with EXCHANGE

mechanism

You can change other discs while playing a

disc (EXCHANGE mechanism).

The disc changer consists of a playing

unit, trays which hold the discs, and a

stocker which transports the discs on

their trays to the disc slot and the

playing unit.

For example, if you press DISC 3, the

stocker moves until the DISC 3 tray

comes to the position of the playing unit

and then moves the DISC 3 tray over the

playing unit. If you press A of DISC 4

while playing DISC 3, the stocker leaves

the DISC 3 tray over the playing unit,

moves so that the DISC 4 tray comes to

the position of the disc cover, opens the

disc cover and pushes out the DISC 4

tray (EXCHANGE mechanism).

Note

Noise may come from the disc changer when

changing discs or turning the system on and off.

However, this is just noise produced by the

operation of the internal mechanisms and does

not indicate a malfunction.

Disc changer system

Index to Parts and Controls

For more information, refer to the pages indicated in parentheses.

Front Panel

1 POWER switch/indicator (32)

2 DISC 1 (play) / A (open/close)-DISC 5

(play) / A (open/close) (32)

3 Front panel display (12)

4 ./> PREV/NEXT, PRESET +/–

(30, 33)

5 H (play) (32)

6 X (pause) (33)

7 x (stop) (32)

8 PHONES jack (32)

9 VOLUME control (32)

q; SOUND FIELD +/– (49)

qa DISPLAY (49, 62)

qs BAND (30)

qd FUNCTION (61)

(remote sensor) (18)

qg Disc tray (32)

continued

Front Panel Display

When playing back a DVD

When playing back a SACD, CD, or VIDEO CD

When listening to the radio

ALL

PRO

LOGIC

DIGITAL

NTSCPBC ANGLE

TITLE TRACK

CHAPTER

INDEX H TUNED M MONO ST S

kHz

PROGRAM

MHz

SHUFFLE

REPEAT 1

FM AM

DISC1SAUTO

Current band

Preset number Monaural/Stereo effect

Current station

ALL

PRO

LOGIC

DIGITAL

NTSCPBC ANGLE

TITLE TRACK CHAPTER INDEX H TUNED M MONO ST S

kHz

PROGRAM

MHz

SHUFFLE

REPEAT 1

FM AM

DISC1SAUTO

Current

surround

format

Playing

status

Current title

number

Lights up when you

can change the angle

Playing time

Current sound

Current play mode

Current chapter numberDisc mode

Current play modeLights up during

PBC playback

(VIDEO CD only)

Playing time

ALL

PRO

LOGIC

DIGITAL

NTSCPBC ANGLE

TITLE TRACK CHAPTER INDEX H TUNED M MONO ST S

kHz

PROGRAM

MHz

SHUFFLE

REPEAT 1

FM AM

DISC1SAUTO

Current index number

(The index indicator does not

appear during SACD playback.)

Current sound

Playing status

Disc mode

Current track

number

1 AM antenna (21)

2 VIDEO 1 jacks (23)

3 VIDEO 2 jacks (23)

4 DIGITAL IN (OPTICAL) jack (24)

5 DIGITAL OUT (OPTICAL) jack

6 MONITOR OUT (VIDEO/S VIDEO)

jacks (23)

7 COMPONENT VIDEO OUT jacks (23)

8 SPEAKER jacks (19)

9 FM 75Ω COAXIAL antenna jack (22)

Rear Panel

VIDEO OUT

AUDIO OUT

VIDEO

AUDIO

VIDEO

AUDIO

OPTICAL

DIGITAL

(CD ONLY)

VIDEO

SVIDEO

(DVD ONLY)

/B-Y P

/R-Y

FRONT R

FRONT L

CENTER

SPEAKER

REAR R

REAR L

WOOFER

COAXIAL

75Ω

VIDEO 1

VIDEO 2

MONITOR

OUT

DIGITAL

OUT

COMPONENT VIDEO OUT

continued

Remote

123

456

10/0

1 TV [/1 (on/standby) (60)

2 OPEN/CLOSE (32)

3 NAME (63)

4 STEREO/MONO (62)

5 MEMORY (30)

6 CLEAR (37)

7 PLAY MODE (37)

8 AUDIO (47)

9 ANGLE (52)

q; SUBTITLE (53)

qa VOL +/– (62)

qs ./> PREV/NEXT, TV/PRESET

+/– (30, 33)

qd H PLAY/SELECT (32)

qf TITLE (35)

qg DVD DISPLAY (37)

qh C/X/x/c/ENTER (26)

qj DVD SETUP (56)

qk 1 (standby) (32)

ql DISC SKIP (32)

w; TV/VIDEO (60)

wa REPEAT (40)

ws MUTING (33)

wd TIME (45)

wf FUNCTION (61)

wg BAND (30)

wh Number buttons (35)

wj SOUND FIELD (49)

wk DISPLAY (49, 62)

wl ENTER (60)

e; CONTROL DVD/TV switch (60)

ea m/M/

/ SLOW, TUNING +/–

(30, 41)

es x STOP (32)

ed X PAUSE (33)

ef DVD MENU (35)

eg O RETURN (36)

eh AMP MENU (26)

Note

This remote control glows in the dark. However,

before glowing, the remote must be exposed to light

for awhile.

Guide to the Control Menu Display (Magic Pad)

Use the Control Menu to select a function that you’d like to use. The Control Menu display

appears when the DVD DISPLAY button is pressed. For details, refer to the page in

parentheses.

Control Menu

List of Control Menu Items

TITLE (DVD only) (page 42)/

SCENE (only VIDEO CD in PBC

playback) (page 42)/TRACK (VIDEO CD

only) (page 42)

CHAPTER (DVD only) (page

42)/INDEX (VIDEO CD only) (page 42)

TRACK (SACD/CD only)

(page 42)

INDEX (SACD/CD only) (page 42)

TIME/TEXT (page 42)

AUDIO (page 47)

Selects the title (DVD), the scene (VIDEO

CD in PBC playback), or the track

(VIDEO CD) to be played.

Selects the chapter (DVD) or the index

(VIDEO CD) to be played.

Selects the track (SACD/CD) to be played.

Selects the index (SACD/CD) to be played.

Checks the elapsed time and the remaining

playback time.

Inputs the time code for picture and music

searching.

Displays the DVD or the SACD/CD text.

Changes the audio setting.

OFF

1: ENGLISH

2: FRENCH

3: SPANISH

OFF

1 8

(

3 4

)

1 2

(

2 7

)

1 : 3 2 : 5 5

DVD

PLAY

SUBTITLE

Select: Cancel:

ENTER RETURN

Total number of titles or tracks recorded

Current playing chapter

number (Video CD/SACD/CD:

index number)

Current playing title number (Video

CD/SACD/CD: track number)

Playing time

Icon of selected

Control Menu item

Control Menu items

Function name of selected

Control Menu item

Operation message

Total number of chapters or indexes recorded

Playback status

(NPlayback, XPause, xStop, etc.)

Type of disc being

played back

Current setting

Options

continued

SUBTITLE (DVD only) (page

53)

ANGLE (DVD only) (page 52)

REPEAT (page 40)

ONE/ALL DISCS (page 37)

ADVANCED (DVD only)

(page 54)

CUSTOM PARENTAL

CONTROL (page 55)

SETUP (page 64)

Displays the subtitles.

Changes the subtitle language.

Changes the angle.

Plays the entire disc (all titles/all tracks)

repeatedly, or one title/chapter/track

repeatedly.

Selects play mode on one disc or all discs.

Checks the information (bit rate or layer)

on the disc while playing a DVD.

Sets the disc to prohibit playing.

CUSTOM Setup

By using the Setup Display, you can make

various adjustments to items such as

picture and sound. You can also set a

language for the subtitles and the Setup

Display, among other things.

RESET

Returns the settings in “SETUP” to the

default setting.

z Each time you press DVD DISPLAY, the Control Menu display changes as follows:

Control Menu display

ADVANCED display (Appears if you select any setting other than “OFF.” See page 54.)

Control Menu display off

The Control Menu items are different depending on the disc.

z The Control Menu icon indicator lights up in green t when you select “REPEAT” except

“OFF.” The “ANGLE” indicator lights up in green only when the angles can be changed.

Getting Started

Quick Overview

This chapter presents a quick overview so you can begin enjoying your new system right away.

For selecting a language used in the on-screen display, refer to the page 65.

For selecting the aspect ratio of the TV to be connected, refer to the page 66.

Unpacking

Check that you have the following items:

• Speakers (5)

• Subwoofer (1)

• AM loop antenna (1)

• FM wire antenna (1)

• Speaker cords (5m × 4, 15m × 2) (16ft. × 4, 49ft. × 2)

• Video cord (1)

• Remote commander (remote) RM-SS900 (1)

• R6 (size AA) batteries (2)

• Speakers-connection and Installation (card) (1)

• Quick reference for Remote commander (card) (1)

Getting Started

Notes

• Do not leave the remote in an extremely hot or humid place.

• Do not use a new battery with an old one.

• Do not drop any foreign object into the remote casing, particularly when replacing the batteries.

• Do not expose the remote sensor to direct light from the sun or lighting apparatus. Doing so may cause a

malfunction.

• If you do not use the remote for an extended period of time, remove the batteries to avoid possible damage from

battery leakage and corrosion.

Step 1: Speaker System Hookup

Connect the supplied speaker system using the supplied speaker cords by matching the colors

of the terminals to those of the cords. Do not connect any speakers other than those supplied

with this system.

To obtain the best possible surround sound, specify the speaker parameters (distance, level, etc.)

on page 25.

Required cords

Speaker cords

The connector and the color tube of the speaker cords are the same color as the label of the

terminals to be connected.

Inserting Batteries into the Remote

You can control the system using the supplied remote. Insert two R6 (size AA) batteries by

matching the 3 and # ends on the batteries to the markings inside the compartment. When

using the remote, point it at the remote sensor

on the system.

Grey

(+)

(–)

Black

Color tube

(–)

Getting Started

VIDEO OUT

AUDIO OUT

VIDEO

AUDIO

VIDEO

AUDIO

VIDEO

SVIDEO

(DVD ONLY)

/B-Y P

/R-Y

FRONT R

FRONT L

CENTER

SPEAKER

REAR R

REAR L

WOOFER

COAXIAL

75Ω

VIDEO 1

MONITOR

OUT

COMPONENT VIDEO OUT

OPTICAL

DIGITAL

(CD ONLY)

VIDEO 2

DIGITAL

OUT

Terminals for connecting the speakers

Connect the To the

Front speakers SPEAKER FRONT L (white) and R (red) terminals

Rear speakers SPEAKER REAR L (blue) and R (grey) terminals

Center speaker SPEAKER CENTER (green) terminal

Subwoofer SPEAKER WOOFER (purple) terminal

Front speaker (R)

Rear speaker (L)

Rear speaker (R)

Subwoofer

Center speaker

Front speaker (L)

The bottom face of

each front and rear

speaker

To detach the speakers

The front and rear speakers

can be detached from the

speaker stands. Push a pointed

object such as ball point pen

through the hole and tilt the

speaker as illustrated.

continued

To avoid short-circuiting the speakers

Short-circuiting of the speakers may damage the system. To prevent this, be sure to follow these

precautions when connecting the speakers. Make sure the bare wire of each speaker cord does

not touch another speaker terminal or the bare wire of another speaker cord.

Examples of bad conditions of the speaker cord

After connecting all the components, speakers, and AC power cord, output a test tone to check

that all the speakers are connected correctly. For details on outputting a test tone, see page 28.

If no sound is heard from a speaker while outputting a test tone, or a test tone is output from a

speaker other than the one currently displayed on the front panel display, the speaker may be

short-circuited. If this happens, check the speaker connection again.

Notes

• Be sure to match the speaker cord to the appropriate terminal on the components: 3 to 3, and # to #. If the

cords are reversed, the sound will be distorted and will lack bass.

• If you use front speakers with low maximum input rating, adjust the volume carefully to avoid excessive output

on the speakers.

To adjust the angle of the center speaker

You can adjust the angle of the center speaker as illustrated.

Exposed end cords are

touching each other due to

sloppy removal of insulation.

Exposed end speaker cord

is touching another speaker

terminal.

Adjust the center speaker.Loosen the screws at the bottom of

the center speaker as illustrated.

Getting Started

VIDEO OUT

AUDIO OUT

VIDEO

AUDIO

VIDEO

AUDIO

VIDEO

SVIDEO

(DVD ONLY)

/B-Y P

/R-Y

FRONT R

FRONT L

CENTER

SPEAKER

REAR R

REAR L

WOOFER

COAXIAL

75Ω

VIDEO 1

MONITOR

OUT

COMPONENT VIDEO OUT

OPTICAL

DIGITAL

(CD ONLY)

VIDEO 2

DIGITAL

OUT

AM loop antenna

FM wire antenna

continued

Step 2: Antenna Hookups

Connect the supplied AM/FM antennas for listening to the radio.

Terminals for connecting the antennas

Connect the To the

AM loop antenna AM terminals

FM wire antenna FM 75Ω COAXIAL terminal

Notes

• To prevent noise pickup, keep the AM loop antenna away from the system and other components.

• Be sure to fully extend the FM wire antenna.

• After connecting the FM wire antenna, keep it as horizontal as possible.

• When you connect the supplied AM loop antenna, connect the black cord (B) to the U terminal, and the white

cord (A) to the other terminal.

COAXIAL

75Ω

Outdoor FM antenna

System

Earth wire (not

supplied)

To earth

z If you have poor FM reception

Use a 75-ohm coaxial cable (not supplied) to connect the system to an outdoor FM antenna as shown below.

Note

If you connect the system to an outdoor antenna, ground it to protect against lightning. To prevent a gas explosion,

do not connect the earth wire to a gas pipe.

Getting Started

Step 3: TV and Video Component Hookups

Required cords

Video cord for connecting a TV monitor

Audio/video cords (not supplied)

When connecting a cord, be sure to match the color-coded pins to the appropriate jacks on the

components.

Jacks for connecting video components

Connect a To the

TV monitor MONITOR OUT jack

VCR VIDEO 1 jacks

Digital satellite receiver VIDEO 2 jacks

z When using the S-video jack instead of the video jacks

Your TV monitor must also be connected via an S-video jack. S-video signals are on a separate bus from the video

signals and will not be output through the video jacks.

z When you are connecting the monitor, projector, or AV amplifier (receiver) having component

video input jacks (Y, PB, PR)

Connect the component via the COMPONENT VIDEO OUT jacks using a component video cord (not supplied) or

three video cords (not supplied) of the same kind and length. You will enjoy accurate color reproduction and high

quality images.

Notes

• When you select VIDEO 1 using the FUNCTION button, the signal is output from the front L/R speakers, but not

from the VIDEO 1 VIDEO OUT and AUDIO OUT L/R jacks.

• When you use the Video 1 line outputs, please set the unit to 2CH STEREO mode. If the unit is not in 2CH

STEREO mode, the line outputs may not function properly.

Red (R/audio)

Yellow

Yellow (Video)

White (L/audio)

Red (R/audio)

Yellow (Video)

White (L/audio)

continued

IN INOUT OUT OUT IN

VIDEO

OUT

VIDEO

AUDIO

OUT

AUDIO

VIDEO

OUT

AUDIO

OUT

OUTPUT

VIDEO

INPUT

OPTICAL

VIDEO OUT

AUDIO OUT

VIDEO

AUDIO

VIDEO

AUDIO

VIDEO

SVIDEO

(DVD ONLY)

/B-Y P

/R-Y

FRONT R

FRONT L

CENTER

SPEAKER

REAR R

REAR L

WOOFER

COAXIAL

75Ω

VIDEO 1

MONITOR

OUT

COMPONENT VIDEO OUT

COMPOMENT

VIDEO IN

/B-Y

/R-Y

OPTICAL

DIGITAL

(CD ONLY)

DIGITAL

OUT

If you connect a digital satellite receiver with the OPTICAL jack

The digital satellite receiver can be connected to the OPTICAL jack instead of the VIDEO IN

and AUDIO IN L/R jacks of the system.

The system can accept both the digital and analog signals. Digital signals have priority over

analog signals. If the digital signal ceases, the analog signal will be processed after 2 seconds.

If you connect a digital satellite receiver without the OPTICAL jack

Connect the digital satellite receiver to the VIDEO IN and AUDIO IN L/R jacks only of the

system.

Connecting the AC Power Cord

Before connecting the AC power cord of this system to a wall outlet, connect the speakers to the

system (see page 18).

Connect the AC power cord of your TV/video components to a wall outlet.

VCR

Digital satellite receiver TV monitor Equipment with component

video input jacks

Getting Started

Speaker Setup

For the best possible surround sound, all the speakers other than the subwoofer should be the

same distance from the listening position (A).

However, if necessary, this system allows you to place the center speaker up to 1.6 meters (5

feet) closer (B) and the rear speakers up to 4.6 meters (15 feet) closer (C) to the listening

position.

The front speakers can be placed from 1.0 to 15.0 meters (3 to 50 feet) (A) from the listening

position.

You can place the subwoofer in any position.

You can place the rear speakers either behind you or to the side, depending on the shape of your

room, etc.

Note

Do not place the center and rear speakers farther away from the listening position than the front speakers.

Specifying the speaker parameters

To obtain the best possible surround sound, first specify the distance of the speakers from your

listening position, then set the balance and level. Use the test tone to adjust the speaker volumes

to the same level.

You may adjust the speaker parameters using SPEAKER SETUP in the setup display (page 68).

When the rear speakers are placed to the side When the rear speakers are placed behind you

45°

90°

20°

A A

45°

90°

20°

A A

continued

C/X/x/c/ENTER

AMP MENU

To specify the size, distance, position and height of the speakers

1 Press AMP MENU repeatedly to display 9 SP. SETUP on the front panel display.

2 Sit in your listening position and select the item to be set using X/x.

• Items set in 9 SP. SETUP

–Size of the rear and center speakers

–Distance of the front, rear, and center speakers

–Front and rear speakers used with speaker stands (A) or without speaker stands (B)

–Position and height of the rear speakers

3 Set the parameter using C/c.

The selected parameter will appear on the front panel display.

4 Repeat Steps 2 and 3 to set other parameters in 9 SP. SETUP.

If you do not operate the remote for a few seconds, the parameter turns off and is stored in

the system.

xSIZE

When you do not connect center or rear speakers, or move the rear speakers, set the parameters

for FRONT, CENTER and REAR accordingly (see below). Since the subwoofer settings are

fixed, you cannot change the settings. The default settings are underlined.

• FRONT (front speakers)

–

A: The speakers are used with the speaker stands.

–B: The speakers are without the speaker stands.

• CENTER (center speaker)

–

YES: Normally select this.

–NO: Select this if no center speaker is used.

• REAR (rear speakers) See “Position diagram” on page 27 when you set this parameters.

–

BEHIND[A]: Select this if the rear speakers are used with the speaker stands and located in

section B.

–SIDE[A]: Select this if the rear speakers are used with the speaker stands and located in

section A.

123

456

10/0

Getting Started

xDISTANCE

You can vary the distance of each speaker as follows. The default adjustments are in

parentheses.

• F. D. 5 m (17 ft) (front speakers distance)

Front speaker distance can be set in 0.2 m (1 foot) steps from 1.0 to 15.0 m (3 to 50 feet).

• C. D. 5 m (17 ft) (center speaker distance)

Center speaker distance can be set in 0.2 m (1 foot) steps from the front speaker distance to

1.6 m (5 feet) closer to your listening position.

• R. D. 3.4 m (12 ft) (rear speakers distance)

Rear speaker distance can be set in 0.2 m (1 foot) steps from a distance equal to the front

speaker distance to a distance 4.6 m (15 feet) closer to your listening position.

Notes

• If each of the front or rear speakers are not placed an equal distance from your listening position, set the distance

of the closest speaker.

• In SPEAKER SETUP, the North American model's OSD displays both metric and imperial measurements.The

other model's displays metric measurements only. The manual also shows both.

Specifying the rear speaker position and height

If you select anything other than “NONE” in “REAR,” specify the position and height of the

rear speakers. The default settings are underlined.

Position diagram

• R. P. BEHIND

Select this if the rear speakers are located in the section B.

• R. P. SIDE

Select this if the rear speakers are located in the section A.

continued

Height diagram

• R. H. LOW

Select this if the rear speakers are located in the section D.

• R. H. HIGH

Select this if the rear speakers are located in the section C.

These parameters are not available when “REAR“ is set to “NO”.

To specify the balance and level of the speakers

1 Press AMP MENU repeatedly to display 9 LEVEL on the front panel display.

2 Using X/x to select T.TONE and use C/c to set T.TONE to ON.

You will hear the test tone from each speaker in sequence.

3 Sit in your listening position and select the item to be adjusted using X/x.

• Items adjusted in 9 LEVEL

–Balance of the front and rear speakers

–Volume level of the center and rear speakers and subwoofer

4 Adjust the volume level so that the volume of the test tone from each speaker sounds the

same using C/c.

The adjusted value will appear on the front panel display.

5 Repeat Steps 3 and 4 to adjust other parameters in 9 LEVEL.

If you do not operate the remote for a few seconds, the value disappears from the display

and is stored in the system.

6 Using X/x to select T.TONE and use C/c to set T.TONE to OFF.

xBALANCE

You can vary the balance of each speaker as follows. The default adjustments are in the

parentheses.

• F ___I___ (center) (front speakers)

Adjust the balance between the front left and right speakers (You can adjust from center,

6 steps left or right).

• R ___I___ (center) (rear speakers)

Adjust the balance between the rear left and right speakers (You can adjust from center,

6 steps left or right).

Getting Started

xLEVEL

You can vary the level of each speaker as follows. The default adjustments are in parentheses.

• C. LEVEL (0 dB) (center speaker level)

Adjust the level of the center speaker (–6 dB to +6 dB, 1 dB steps).

• R. LEVEL (0 dB) (rear speakers level)

Adjust the level of the rear speakers (–6 dB to +6 dB, 1 dB steps).

• S. W. LEV. (0 dB) (subwoofer level)

Adjust the level of the subwoofer (–6 dB to +6 dB, 1 dB steps).

Notes

• When you select an item, the sound cuts off for a moment.

• Depending on the settings of other speakers, the subwoofer may output excessive sound.

To adjust the volume of all the speakers at one time

Use the VOLUME control.

Other AMP MENU settings

You can control the brightness of the front panel display, clear the preset stations and the station

names, and set the speaker parameters back to the default setting. Press AMP MENU repeatedly

to display 9 CUSTOMIZE. Use X/x to select the following items.

xDIMMER

You can change the brightness of the front panel display by two steps.

xMEMO. CLR.

• N (No): Skip back to previous menu.

• Y (Yes): If you select Y by pressing ENTER, “Really? N” and “Really? Y” appears.

If you select “Really? Y,” by pressing ENTER, “ALL CLEAR!” is displayed and all settings

such as preset stations and station names will be cleared, and speaker parameters will be

defaulted.

Presetting Radio Stations

You can preset 20 stations for FM and 10 stations for AM.

Before tuning, make sure to turn down the volume to minimum.

1 Press BAND repeatedly until the band you want appears on the front panel

display.

Every time you press BAND, the band changes to AM or FM alternately.

2 Press and hold TUNING + or – until the frequency indication starts to change,

then release.

Scanning stops when the system tunes in a station. “TUNED” and “ST” (for stereo

program) appear on the front panel display.

3 Press MEMORY.

A preset number appears on the front panel display.

4 Press PRESET + or – to select the preset number you want.

MEMORY

PRESET +/–

BAND

TUNING +/–

ENTER

123

456

10/0

ALL

PRO

LOGIC

DIGITAL

NTSCPBC ANGLE

TITLE TRACK CHAPTER INDEX H TUNED M MONO ST S

kHz

PROGRAM

MHz

SHUFFLE

REPEAT 1

FM AM

DISC1SAUTO

ALL

PRO

LOGIC

DIGITAL

NTSCPBC ANGLE

TITLE TRACK CHAPTER INDEX H TUNED M MONO ST S

kHz

PROGRAM

MHz

SHUFFLE

REPEAT 1

FM AM

DISC1SAUTO

ALL

PRO

LOGIC

DIGITAL

NTSCPBC ANGLE

TITLE TRACK CHAPTER INDEX H TUNED M MONO ST S

kHz

PROGRAM

MHz

SHUFFLE

REPEAT 1

FM AM

DISC1SAUTO

Getting Started

5 Press ENTER.

The station is stored.

6 Repeat 1 to 5 to store other stations.

To tune in a station with a weak signal

Press TUNING + or – repeatedly in 2 to tune in the station manually.

To change the preset number

Start over from 1.

To change the AM tuning interval

The AM tuning interval is factory set to 9 kHz (10 kHz in some areas).

To change the AM tuning interval, tune in any AM station first, then turn off 1 on the remote.

While holding down x (on the system), turn the power back on. When you change the interval,

AM preset stations will be erased.

To reset the interval, repeat the same procedure.

ALL

PRO

LOGIC

DIGITAL

NTSCPBC ANGLE

TITLE TRACK CHAPTER INDEX TUNEDH MONOMSTS

kHz

PROGRAM

MHz

SHUFFLE

REPEAT 1

FM AM

DISC1SAUTO

ALL

PRO

LOGIC

DIGITAL

NTSCPBC ANGLE

TITLE TRACK CHAPTER INDEX H TUNED M MONO ST S

kHz

PROGRAM

MHz

SHUFFLE

REPEAT 1

FM AM

DISC1SAUTO

Playing Discs

Depending on the DVD or VIDEO CD,

some operations may be different or

restricted.

Refer to the operating instructions supplied

with your disc.

1 Turn on your TV.

2 Switch the input selector on the TV

to this system.

3 Press POWER on the system.

The system enters standby mode and

the power indicator lights up in red.

Playing Discs

4 Press A of DISC 1-DISC 5 on the

system or OPEN/CLOSE on the

remote, and place a disc on the

disc tray.

The system automatically turns on and

the power indicator turns off.

Press A of the same disc tray number

to close the disc tray.

Press other A of DISC 1-DISC 5 to

place other discs.

5 Press H.

The system starts playback

(continuous play) of the disc whose

disc tray indicator is green.

To playback other discs, press DISC

SKIP on the remote or DISC 1-DISC 5

of the system.

Adjust the volume on the system.

After following Step 5

Depending on the disc, a menu may appear

on the TV screen. You can play the disc

interactively by following the instructions

on the menu. DVD (page 35), VIDEO CD

(page 36).

To turn on the system

Press POWER on the system. The system

enters standby mode and the power indicator

lights up in red. Press 1 on the remote. The

system turns on and the power indicator

turns off. In standby mode, the system also

turns on by pressing A on the system or by

pressing H.

With the playback side facing down

POWER

Power indicator

DISC 1 / A-DISC 5 / A

Adjust the volume Connect

headphones

123

456

10/0

OPEN/

DISC SKIP

Playing Discs

To turn off the system

Press 1 on the remote. The system enters

standby mode and the power indicator lights

up in red. To turn off the system completely,

press POWER on the system. While playing

a disc, do not turn off the system by pressing

POWER. Doing so may cancel the menu

settings. When you turn off the system, first

press x to stop playback and then press 1

on the remote.

On Auto-Function

If a disc is already placed on any disc tray, you can

play it back simply by pressing the H or its

corresponding DISC 1-DISC 5, even if the previous

music source was not a DVD. The function changes

to DVD and playback starts (Auto-Function).

However, if Program Play is on, you can only start

playback by pressing the H.

z On the disc tray indicators

The disc tray indicators change their colors as

follows:

– green: the disc tray is chosen, or the disc is being

playbacked.

– off: there is no disc.

– orange: a disc is placed on the disc tray, however,

the disc tray is not chosen.

Additional operations

To Operation

Stop Press x.

Pause Press X.

Resume play after Press X or H.

pause

Go to the next chapter, Press >.

track, or scene in

continuous play mode

Go back to the Press ..

preceding chapter, track,

or scene in continuous

play mode

Stop play and remove Press OPEN/CLOSE.

the disc

Mute the sound Press MUTING. To

cancel muting, press it

again or turn up the

volume.

Change a disc while Press DISC SKIP.

playing another disc

Notes

• Do not push the disc tray when closing it. Press

OPEN/CLOSE to close the disc tray.

• If there is no disc in any disc tray, “NO DISC”

appears on the front panel display.

OPEN/CLOSE

./>

123

456

10/0

MUTING

DISC SKIP

Notes

• Depending on where you stopped the disc, the

system may not resume playback from exactly the

same point.

• The point where you stopped playing is cleared

when:

– you turn the power off by pressing POWER on

the system.

– you change the play mode.

Resuming Playback from

the Point Where You

Stopped the Disc

(Resume Play)

When you stop the disc, the system

remembers the point where you pressed x

and “RESUME” appears on the front panel

display. As long as you do not open the disc

tray, Resume Play will work even if the

system enters standby mode by pressing 1.

1 While playing a disc, press x to

stop playback.

“RESUME” appears on the front panel

display, so you can restart the disc

from the point where you stopped the

disc.

If “RESUME” does not appear,

Resume Play is not available.

2 Press H.

The system starts playback from the

point where you stopped the disc in

Step 1.

z To play from the beginning of the disc, press x

twice, then press H.

10/0

Playing Discs

Using the DVD’s Menu

Some discs have a “title menu” or a “DVD

menu.” On some DVDs, this may simply be

called a “menu” or “title.”

Using the title menu

A DVD is divided into long sections of a

picture or a music feature called “titles.”

When you play a DVD which contains

several titles, you can select the title you

want using the title menu.

1 Press TITLE.

The title menu appears on the TV

screen.

The contents of the menu vary from disc

to disc.

2 Press C/X/x/c or the number buttons

to select the title you want to play.

3 Press ENTER.

The system starts playing the selected

title.

C/X/x/c

TITLE

ENTER

Number

buttons

123

456

10/0

Using the DVD menu

Some DVDs allow you to select the disc

contents using a menu. When you play these

DVDs, you can select items such as the

language for the subtitles and the language

for the sound using the DVD menu.

1 Press DVD MENU.

The DVD menu appears on the TV

screen. The contents of the menu vary

from disc to disc.

2 Press C/X/x/c or the number buttons

to select the item you want to change.

3 To change other items, repeat Step 2.

4 Press ENTER.

C/X/x/c

DVD MENU

ENTER

Number

buttons

123

456

10/0

To go back to the menu

Press O RETURN.

z To play without using PBC, press ./> or

the number buttons while the system is stopped to

select a track, then press H or ENTER.

“Play without PBC” appears on the TV screen and

the system starts continuous play. You cannot play

still pictures such as a menu. To return to PBC

playback, press x twice then press H.

Note

Depending on the VIDEO CD, “Press ENTER” in

Step 3 may appear as “Press SELECT” in the

instructions supplied with the disc. In this case, press

Playing VIDEO CDs with

PBC Functions

(PBC Playback)

With PBC (Playback Control) functions,

you can enjoy simple interactive operations,

search functions, and other such operations.

PBC playback allows you to play VIDEO

CDs interactively by following the menu on

the TV screen.

1 Start playing a VIDEO CD with PBC

functions.

The menu for your selection appears.

2 Select the item number you want

by pressing X/x or the number

buttons.

3 Press ENTER.

4 Follow the instructions in the

menu for interactive operations.

Refer to the instructions supplied with

the disc, as the operating procedure

may differ according to the VIDEO

CD.

O RETURN

./>

X/x

ENTER

Number

buttons

123

456

10/0

Playing Discs

PROGRAM

– – – –

ALL CLEAR

– – – –

ALL

–

– – – –

Creating Your Own

Program

(Program Play)

You can play the contents of a disc in the

order you want by arranging the order of the

titles, chapters or tracks on the disc to create

your own program. You can program up to

25 titles, chapters, and tracks.

1 In stop mode, press PLAY MODE

repeatedly until “PROGRAM”

appears on the front panel

display.

The programming display appears on

the TV screen.

PLAY MODE

ENTER

X/x/c

Number

buttons

CLEAR

123

456

10/0

REPEAT

Selecting the Disc Mode

(One Disc or All Discs)

Before setting Program Play, Shuffle Play, or

Repeat Play, you need to select whether to

set those play modes on one disc or all discs.

1 In stop mode, press DVD DISPLAY.

2 Press X/x to select (ONE/

ALL DISCS), then press ENTER.

xONE/ALL DISCS

•

ALL DISCS: allows you to set Program

Play, Shuffle Play, or Repeat Play for all

the discs.

• ONE DISC: allows you to set Shuffle Play

or Repeat Play for 1 disc only.

1 8

(

3 4

)

1 2

(

2 7

)

0 1 : 3 2 : 5 5

ALL DISCS

ONE DISC

DVD

PLAY

ENTER

X/x

DVD

DISPLAY

continued

ALL

PROGRAM

– – – –

ALL CLEAR

– – – –

–

– – – –

PROGRAM

1. CD

–

ALL CLEAR

– – – –

ALL

Next, press X/x or the number buttons

to select “03” under “C,” then press

ENTER.

xWhen playing a VIDEO CD or

For example, select track “02.”

Press X/x or the number buttons to

select “02” under “T,” then press

ENTER.

xWhen playing a SACD

For example, select track “002.”

Press X/x or the number buttons to

select “002” under “T,” then press

ENTER.

Selected track

PROGRAM

– – – –

ALL CLEAR

– – – –

ALL

DVD

Chapters recorded on a disc

Chapter

Title

2 Press ENTER, then press X/x to

select the disc.

3 Press c.

The cursor moves to the title or track

(in this case, “01”).

* “?” appears when the system has not loaded

the disc information in the memory.

4 Select the title, chapter, or track

you want to program.

xWhen playing a DVD

For example, select chapter “03” of

title “02.”

Press X/x or the number buttons to

select “02” under “T,” then press

ENTER.

Selected title and chapter

PROGRAM

– – – –

ALL CLEAR

– – – –

ALL

DVD

ALL

PROGRAM

1. DVD

–

0 2

–

0 3

ALL CLEAR

– – – –

–

– – – –

Disc type*

–

– – – –

PROGRAM

1. SACD

–

002

ALL CLEAR

– – – –

ALL

Selected track

Playing Discs

5 To program other discs, titles,

chapters, or tracks, repeat Step 2

to 4.

The programmed discs, titles, chapters,

and tracks are displayed in the selected

order.

6 Press H to start Program Play.

Program Play begins.

When the program ends, you can

restart the same program again by

pressing H.

To return to normal play

Press CLEAR during playback.

To turn off the program menu

In stop mode, press PLAY MODE to turn

off the program menu.

To change the program

To change the disc, select the program

number you want to change using X/x after

Step 1 or 4, then press ENTER.

To change the title, chapter, or track, select

the desired one in Step 4.

To cancel the programmed order

To cancel all the titles, chapters, or tracks in

the programmed order, press X, and select

“ALL CLEAR” in Step 2. To cancel the

selected program, select the program using

X/x in Step 2, then press CLEAR.

You can do Repeat Play of the programmed titles,

chapters, or tracks. Press REPEAT, or set “REPEAT”

to on in the Control Menu display during Program

Play.

Note

The number of titles, chapters, or tracks displayed are

the same number of titles, chapters, or tracks

recorded on a disc.

Playing in random order

(Shuffle Play)

You can have the system “shuffle” titles,

chapters, or tracks and play them in random

order. Subsequent “shuffling” may produce

a different playing order.

1 In stop mode, press PLAY MODE

repeatedly until “SHUFFLE”

appears on the front panel

display.

2 Press H.

To return to normal play

In stop mode, press PLAY MODE twice, or

during playback, press CLEAR to return to

normal play.

Note

You may not be able to do Shuffle Play depending on

the DVD.

PLAY MODE

CLEAR

123

456

10/0

3 Select the Repeat Play setting.

When playing a DVD and when

Program Play is set to OFF

•

OFF: does not play repeatedly.

• DISC: repeats all the titles (except ALL

DISCS SHUFFLE).

• TITLE: repeats the current title on a disc.

• CHAPTER: repeats the current chapter

(except ALL DISCS SHUFFLE).

When playing a VIDEO CD/SACD/CD

and when Program Play is set to OFF

•

OFF: does not play repeatedly.

• DISC: repeats all the tracks on a disc.

(except ALL DISCS SHUFFLE)

• TRACK: repeats the current track

When Program Play is set to ON

•

OFF: does not play repeatedly.

• ON: repeats Program Play.

To cancel Repeat Play

Press CLEAR.

You can set Repeat Play during stop

mode

After selecting the “REPEAT” item, press H.

The system starts Repeat Play.

z You can quickly display the “REPEAT”

status

Press REPEAT on the remote.

Note

If you set the DISC repeat or DISC repeat with

Program Play, the maximum program repetition is 5.

1 8

(

3 4

)

1 2

(

2 7

)

1 : 3 2 : 5 5

CHAPTER

DISC

OFF

TITLE

OFF

DVD

PLAY

Playing repeatedly (Repeat

Play)

You can play all the titles/tracks or a single

title/chapter/track on a disc.

In Shuffle or Program Play mode, the

system repeats the titles or tracks in the

shuffled or programmed order.

You cannot perform Repeat Play during

PBC playback of VIDEO CDs (page 36).

You may not be able to perform Repeat Play

depending on the DVD.

CLEAR

REPEAT

PLAY MODE

123

456

10/0

DVD DISPLAY

X/x

1 Press DVD DISPLAY.

The Control Menu appears.

2 Press X/x to select

(REPEAT) then press ENTER.

If you do not select “OFF,” the

indicator of the “REPEAT” lights in

green.

ENTER

Searching for a Scene

Watching frame by frame (Slow-

motion play)

You can use this function only for DVDs or

VIDEO CDs. Press

or when the

system is in the pause mode. To return to the

normal speed, press H.

Each time you press

or during Slow-

motion play, the playback speed changes.

Two speeds are available. With each press

the indication changes as follows:

Playback direction

SLOW 2

y SLOW 1

Opposite direction (DVD only)

SLOW 2

y SLOW 1

The SLOW 2 /SLOW 2 playback speed

is slower than SLOW 1

/SLOW 1 .

Searching for a Particular

Point on a Disc

(Scan, Slow-

motion Play)

You can locate a particular point on a disc

quickly by monitoring the picture or playing

back slowly.

Note

Depending on the DVD/VIDEO CD, you may not be

able to do some of the operations described.

Locating a point quickly by playing

a disc in fast forward or fast

reverse (Scan)

Press m or M while playing a disc.

When you find the point you want, press

H to return to normal speed.

Each time you press m or M during

scan, the playback speed changes. Three

speeds are available. With each press the

indication changes as follows:

Playback direction

×2B (DVD/SACD/CD only) t FF1M t FF2M

Opposite direction

×2b (DVD only) t FR1m t FR2m

The ×2B/×2b playback speed is about twice

the normal speed. The FF2M/FR2m

playback speed is faster than FF1M/

FR1m.

SLOW /

m/M

1 8

(

3 4

)

1 2

(

2 7

)

1 : 3 2 : 5 5

DVD

PLAY

Searching for a Title/

Chapter/Track/Index/

Scene

You can search a DVD disc by title or

chapter, and you can search a VIDEO CD or

CD by track, index, or scene. As titles and

tracks are assigned unique numbers on the

disc, you can select the desired one by

entering its number. Or, you can search for a

scene using the time code. (TIME SEARCH)

1 Press DVD DISPLAY.

The Control Menu appears.

2 Press X/x to select the search

method.

xWhen playing a DVD

(TITLE),

(CHAPTER), or

(TIME/TEXT)

Select TIME/TEXT for TIME

SEARCH.

xWhen playing a VIDEO CD

(TRACK) or

(INDEX)

DVD

DISPLAY

X/x

ENTER

Number

buttons

xWhen playing a VIDEO CD with

PBC Playback

(SCENE)

xWhen playing a SACD/CD

(TRACK) or

(INDEX)

Example: when you select

(CHAPTER)

“

(

)” is selected (

refers to a

number).

The number in parentheses indicates

the total number of titles, chapters,

tracks, indexes, or scenes.

3 Press ENTER.

“

(

)” changes to “— (

)”.

4 Press X/x or the number buttons

to select the title, chapter, track,

index, or scene number you want

to search.

If you make a mistake

Cancel the number by pressing

CLEAR, then select another number.

CLEAR

Selected row

123

456

10/0

1 2

(

2 7

)

1 : 3 2 : 5 5

DVD

PLAY

– –

(

3 4

)

Searching for a Scene

5 Press ENTER.

The system starts playback from the

selected number.

To turn off the Control Menu

Press DVD DISPLAY repeatedly until the

Control Menu is turned off.

To search for a scene using the time

code (TIME SEARCH) (DVD only)

1 In Step 2, select (TIME/

TEXT).

“T

” (playing time of the

current title) is selected.

2 Press ENTER.

“T

” changes to “T --:--:--.”

3 Input the time code using the number

buttons, then press ENTER.

For example, to find the scene at

2 hours, 10 minutes, and 20 seconds

after the beginning, just enter “2:10:20.”

Note

The title, chapter or track number displayed is the

same number recorded on the disc.

TITLE TRACK CHAPTER INDEX TUNEDH MONOMSTS

kHz

PROGRAM

MHz

SHUFFLE

REPEAT 1
